Overview

Presentation

Instruments and controls

These illustrations and descriptions are intended

as a guide. The presence and location of some

components varies according to the version or

trim level.

Glove box

Deactivation of the front passenger airbag

12 V (120 W) accessory sockets

USB socket

JACK socket

Instrument panel

Storage

Cup/can holder

Storage compartment

Upper storage compartment

220 V (120 W) accessory socket

10.

Horn

11.

Courtesy lamp

Warning lamps display for seat belts and

front passenger airbag

Interior rear view mirror

Monitoring mirror

Emergency and assistance call buttons

12.

Heating/Air conditioning

Front demisting – de-icing

Rear screen demisting – de-icing

13.

"START/STOP" button

14.

Gearbox or drive selector

Choice of driving mode

15.

Monochrome screen with audio system

Touch screen

16.

Bonnet release

17.

Dashboard fuses

18.

Head-up display

19.

Electric parking brake

Depending on the vehicle's equipment,

the storage compartments may be open

or closed. This configuration is shown as an

example.

Steering-mounted controls

Exterior lighting/Direction indicators control

stalks

Wiper controls/Screenwash/Trip computer

Audio system setting controls

Controls for Cruise control/Speed limiter/

Adaptive cruise control

Instrument panel display mode selection

wheel

Voice synthesis control

Volume adjustment

Audio system setting controls

Central control bar

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Overview

Locking/unlocking from the inside

Left-hand electric sliding side door

Electric child lock

Right-hand electric sliding side door

Cab/loading area selectivity

Hazard warning lamps

DSC/ASR system

Tyre under-inflation detection

Stop & Start (Diesel)

Side control bar

Advanced Grip Control

Head-up display

Parking sensors

Additional heating/ventilation system (Diesel)

Alarm (Diesel or Electric)

Headlamp beam height adjustment

Lane departure warning system

Blind spot monitoring system

Automatic headlamp dipping

Electric motor

Charging connectors

Traction battery

12 V accessory battery

On-board charger

Electric motor

Charging cable

The charging connectors

allow 3 types of

charging:

– Domestic charging in mode 2 using a domestic

socket and associated charging cable

– Accelerated charging in mode 3 using an

accelerated charging unit (Wallbox).

– Superfast charging in mode 4 using a fast

public charger.

The 400 V traction battery

uses Lithium-Ion

technology. It stores and supplies the energy

required for the operation of the electric motor,

air conditioning and heating. Its charge level is

represented by an indicator and a reserve power

warning lamp on the instrument panel.

The 12 V accessory battery

powers the

vehicle’s conventional electrical system. It is

recharged automatically by the traction battery

via the on-board charger.

The on-board charger

provides domestic

charging (mode 2) and accelerated charging

(mode 3) of the traction battery as well as

recharging of the 12 V accessory battery.

The electric motor

provides propulsion in

accordance with the selected driving mode and

driving conditions. It recovers energy during

vehicle braking and deceleration phases.

Labels

"Access - Side-hinged rear doors" section:

"Ease of use and comfort - Moduwork"

section:

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Overview

"Ease of use and comfort - Precautions for

seats and bench seats" section:

"Ease of use and comfort - Retractable

sliding table" section:

"Ease of use and comfort - Additional

heating/ventilation" section:

"Safety - Deactivating the front passenger

airbag" section:

"Safety - ISOFIX child seats" section:

"Safety - Manual child lock" section:

"Driving - Electric parking brake" section:

"Practical information - Compatibility of

fuels" section:

"Practical information - Charging system

(Electric)" section:

"Practical information - Charging the traction

battery (Electric)" section:

"Practical information - Bonnet" section:

"Practical information - Checking levels"

section:

"In the event of a breakdown - Spare wheel"

section:

"In the event of a breakdown - 12 V battery/

Accessory battery" section:

24V

12V

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Eco-driving

Eco-driving refers to a range of everyday

practices that allow the motorist to optimise

the vehicle's energy consumption (fuel and/or

electricity) and CO

emissions.

Optimise your use of the gearbox

With a manual gearbox, move off gently and

change up promptly. While accelerating, change

up early.

With an automatic gearbox, favour automatic

mode. Do not depress the accelerator pedal

heavily or suddenly.

The gear shift indicator prompts you to engage

the most suitable gear. Whenever this indication

is displayed on the instrument panel, follow it

straight away.

With an automatic gearbox, this indicator

appears only in manual mode.

Drive smoothly

Maintain a safe distance between vehicles, use

engine braking rather than the brake pedal and

press the accelerator gradually. These practices

help to save on energy consumption, reduce

emissions and decrease general traffic

noise.

When the traffic is flowing smoothly, select the

cruise control.

Control the use of electrical equipment

Before moving off, if the passenger compartment

is too warm, ventilate it by opening the windows

and air vents before using the air conditioning.

At speeds above 31 mph (50 km/h), close the

windows and leave the air vents open.

Consider using equipment that can help keep

the temperature in the passenger compartment

down (e.g. sunroof blind, window blinds).

Unless automatically regulated, switch off the air

conditioning as soon as the desired temperature

has been reached.

Switch off the demisting and defrosting functions,

if they are not managed automatically.

Switch off the heated seat as soon as possible.

Adapt your use of the headlamps and/or

foglamps to the level of visibility, in accordance

with current legislation in the country in which

you are driving.

Avoid running the engine before moving off,

particularly in winter (other than in severe wintry

conditions: temperature below -23°C). The

vehicle will warm up much faster while driving.

As a passenger, avoid connecting your

multimedia devices (e.g. film, music, video

game) to help reduce the consumption of energy.

Disconnect all portable devices before leaving

the vehicle.

Limit the causes of excess consumption

Spread loads throughout the vehicle. Place the

heaviest items in the boot as close as possible to

the rear seats.

Limit the loads carried in the vehicle and

minimise wind resistance (e.g. roof bars, roof

rack, bicycle carrier, trailer). Preferably, use a

roof box.

Remove roof bars and roof racks after use.

At the end of winter, remove snow tyres and refit

summer tyres.

Comply with the servicing instructions

Check tyre pressures regularly, with the tyres

cold, referring to the label in the door aperture on

the driver's side.

Carry out this check in particular:

– before a long journey.

– at each change of season.

– after a long period out of use.

Do not forget the spare wheel and, where

applicable, the tyres on your trailer or caravan.

Have your vehicle serviced regularly (e.g. engine

oil, oil filter, air filter, passenger compartment

filter, etc.). Observe the schedule of operations in

the manufacturer's service schedule.

With a BlueHDi Diesel engine, if the SCR system

has a fault, your vehicle will emit pollution. Visit

a CITROËN dealer or a qualified workshop

as soon as possible to restore your vehicle's

nitrogen oxide emissions to legal levels.

When filling the fuel tank, do not continue after

the third cut-out of the nozzle, to avoid overflow.

You will only see the fuel consumption of your

new vehicle settle down to a consistent average

after the first 1,900 miles (3,000 kilometres).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Instrument panel

Speedometer

Analogue speedometer (mph or km/h).

Indicators and displays

With LCD text or matrix display

Fuel gauge

Engine coolant temperature indicator

With matrix display (Electric)

Thermal comfort consumption indicator

Charge level indicator

With LCD display

With LCD text display

With matrix display

With matrix display (Electric)

When travelling abroad, you may need to

change the distance unit: the speed must

be displayed in the country’s official unit (mph

or km/h). The unit is changed via the screen's

configuration menu, with the vehicle

stationary.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Cruise control or speed limiter settings

Display of speed limit signs

Gear shift indicator (Diesel)

Gear with an automatic gearbox (Diesel) or

Drive selector position (Electric)

Digital speedometer (mph or km/h) with LCD

and LCD text instrument panel (Diesel)

Display area with matrix instrument panel:

alert or function status message, trip

computer, digital speedometer (mph or km/h),

power flow/vehicle charge state (Electric),

etc.

Service indicator, then total distance recorder

(miles or km)

Trip distance recorder (miles or km) (Diesel)

Remaining range/Driving mode selected

(Electric)

Display area with LCD text instrument

panel: alert or function status message, trip

computer, etc.

Engine coolant temperature gauge

Engine oil level indicator

Fuel gauge

Control buttons

With LCD display

With LCD text display

With matrix display

With matrix display (Electric)

Resetting the service indicator.

Temporary reminder of servicing information.

Reminder of driving range with the AdBlue

system.

Depending on version: go back up a level or

cancel the current operation.

General lighting dimmer.

Depending on version: browse a menu or list,

or change a value.

Resetting the trip distance recorder.

Depending on version: enter the configuration

menu (long press), confirm a choice (short

press).

Reminder of servicing information or driving

range with the SCR system and the AdBlue

Resetting the selected function (service

indicator or trip distance recorder).

Depending on version: enter the configuration

menu (long press), confirm a choice (short

press).

With the touch screen, it is also possible

to adjust the lighting dimmer.

Rev counter

Rev counter (x 1000 rpm).

Power indicator (Electric)

Power indicator

CHARGE

ECO

POWER

NEUTRAL

For more information on the

Indicators

please refer to the corresponding

section.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Warning and indicator

lamps

Displayed as symbols, the warning and indicator

lamps inform the driver of the occurrence of a

malfunction (warning lamps) or of the operating

status of a system (operation or deactivation

indicator lamps). Certain lamps light up in two

ways (fixed or flashing) and/or in several colours.

Associated warnings

The illumination of a lamp may be accompanied

by an audible signal and/or a message displayed

in a screen.

Relating the type of alert to the operating status

of the vehicle allows you to determine whether

the situation is normal or whether a fault has

occurred: refer to the description of each lamp

for further information.

When the ignition is switched on

Certain red or orange warning lamps come on

for a few seconds when the ignition is switched

on. These warning lamps should go off as soon

as the engine is started.

For more information on a system or a function,

refer to the corresponding section.

Persistent warning lamp

If a red or orange warning lamp comes on, there

may be fault which needs further investigation.

If a lamp remains lit

The references

(1)

(2)

and

(3)

in the warning

and indicator lamp description indicate whether

you should contact a qualified professional in

addition to the immediate recommended actions.

(1)

You must stop the vehicle

Stop as soon as it is safe to do so and switch off

the ignition.

(2)

: Contact a CITROËN dealer or a qualified

workshop.

(3)

: Visit a CITROËN dealer or a qualified

workshop.

List of warning and

indicator lamps

Red warning/indicator lamps
STOP

Fixed, associated with another warning

lamp, accompanied by the display of a

message and an audible signal.

A serious fault with the engine, braking system,

power steering or automatic gearbox or a major

electrical fault has been detected.

Carry out (1) and then (2).

Maximum engine coolant temperature

Fixed (warning lamp or LED), with

the needle in the red zone

(depending on version).

The temperature of the cooling system is too

high.

Carry out (1), then wait until the engine has

cooled down before topping up the level, if

necessary (Diesel). If the problem persists, carry

out (2).

Engine oil pressure

Fixed.

There is a fault with the engine lubrication

system.

Carry out (1) and then (2).

System malfunction (Electric)

Fixed.

A fault involving the electric motor or

traction battery has been detected.

Carry out (1) and then (2).

Cable connected (Electric)

Fixed when the ignition is switched on.

The charging cable is connected to the

vehicle's connector.

Fixed when the ignition is switched on,

accompanied by a message.

It is not possible to start the vehicle while the

charging cable is connected to the vehicle’s

connector.

Disconnect the charging cable and close the

flap.

Battery charge

Fixed.

The battery charging circuit has a fault

(dirty terminals, slack or cut alternator belt, etc.).

Clean and retighten the lugs. If the warning lamp

does not go off when the engine is started, carry

out (2).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Seat belts not fastened/unfastened

Fixed or flashing, accompanied by

an increasing audible signal.

A seat belt has not been fastened or has been

unfastened (depending on version).

Door open

Fixed, associated with a message

indicating which access is open.

An audible signal supplements the alert if the

speed is higher than 6 mph (10 km/h).

A door, the boot, the tailgate or the opening rear

screen is still open (depending on version).

Close whichever access is open.

If your vehicle is equipped with a right-hand side-

hinged door, this warning lamp will

not

indicate

that it is open.

Electric parking brake

Fixed.

The electric parking brake is applied.

Flashing.

Application/release is faulty.

Carry out (1): park on flat ground (on a level

surface).

With a manual gearbox, engage a gear.

With an automatic gearbox or drive selector,

select mode

Switch off the ignition and carry out (2).

Manual parking brake

Fixed.

The parking brake is applied or not

properly released.

Braking

Fixed.

The brake fluid level in the braking circuit

has dropped significantly.

Carry out (1), then top up with fluid that complies

with the manufacturer's recommendations. If the

problem persists, carry out (2).

Fixed.

The electronic brake force

distribution (EBFD) system is faulty.

Carry out (1) and then (2).

Orange warning/indicator lamps
Service

Temporarily on, accompanied by the

display of a message.

One or more minor faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel.

You may be able to deal with some faults

yourself, such as changing the battery in the

remote control.

For other faults, such as with the tyre under-

inflation detection system, carry out (3).

Fixed, accompanied by the display of a

message.

One or more major faults, for which there is/are

no specific warning lamp(s), have been detected.

Identify the cause of the fault using the message

displayed on the instrument panel, then carry

out (3).

Fixed, accompanied by the message

Parking brake fault

Automatic release of the electric parking brake is

unavailable.

Carry out (2).

Service warning lamp fixed and

service spanner flashing then

fixed.

The servicing interval has been exceeded.

The vehicle must be serviced as soon as

possible.

Only with BlueHDi Diesel engines.

Anti-lock braking system (ABS)

Fixed.

The anti-lock braking system has a fault.

The vehicle retains conventional braking.

Drive carefully at moderate speed, then carry

out (3).

AdBlue

(Euro 6.2/6.3)

On for around 30 seconds when starting

the vehicle, accompanied by a message

indicating the driving range.

The driving range is between 1,500 and 500

miles (2,400 and 800 km).

Top up the AdBlue

Fixed, on switching on the ignition,

accompanied by an audible signal and a

message indicating the driving range.

The driving range is between 500 and 62 miles

(800 and 100 km).

Promptly

top up the AdBlue

, or carry out (3).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Flashing, accompanied by an audible

signal and a message indicating the

driving range.

The driving range is less than 62 miles (100 km).

You

must

top up the AdBlue

avoid engine

starting being prevented

, or carry out (3).

Flashing, accompanied by an audible

signal and a message indicating that

starting is prevented.

The AdBlue

tank is empty: the legally required

engine immobiliser system prevents the engine

from starting.

To restart the engine, top up the AdBlue

or carry

out (2).

It is

essential

to add at least 5 litres of AdBlue

to the tank.

SCR emissions control system (BlueHDi)

Fixed when the ignition is

switched on, accompanied

by an audible signal and a message.

A malfunction of the SCR emissions control

system has been detected.

This alert disappears once the exhaust

emissions return to normal levels.

Flashing AdBlue

warning

lamp on switching on the

ignition, with the Service and Engine self-

diagnostics warning lamps on fixed,

accompanied by an audible signal and a

message indicating the driving range.

Depending on the message displayed, it is

possible to drive for up to 685 miles (1,100 km)

before the engine immobiliser is triggered.

Carry out (3) without delay, to

avoid starting

being prevented

Flashing AdBlue

warning

lamp on switching on the

ignition, with the Service and Engine self-

diagnostics warning lamps on fixed,

accompanied by an audible signal and a

message indicating that starting is prevented.

The engine immobiliser prevents the engine from

restarting (the permitted driving limit has been

exceeded after confirmation of a malfunction of

the emissions control system).

To start the engine, carry out (2).

Engine self-diagnosis system

Flashing.

The engine management system has a

fault.

There is a risk that the catalytic converter will be

destroyed.

Carry out (2)

without fail

Fixed.

The emission control system has a fault.

The warning lamp should go off when the engine

is started.

Carry out (3) quickly.

Fixed.

A minor engine fault has been

detected.

Carry out (3).

Fixed.

A major engine fault has been

detected.

Carry out (1) and then (2).

Automatic functions deactivated (electric

parking brake)

Fixed.

The "automatic application" (on switching

off the engine) and "automatic release" (on

acceleration) functions are deactivated.

If automatic application/release is no longer

possible:

► Start the engine.

► Use the control to apply the electric parking

brake.

► Take your foot fully off the brake pedal.

► Hold the control pressed in the release

direction for between 10 and 15 seconds.

► Release the control.

► Depress and hold the brake pedal.

► Pull the control in the application direction for

2 seconds.

► Release the control and the brake pedal.

Malfunction (with electric parking brake)

Fixed, accompanied by the

message "

Parking brake fault

The vehicle cannot be immobilised with the

engine running.

If manual application and release commands are

not working, the electric parking brake control is

faulty.

The automatic functions must be used at all

times and are automatically reactivated in the

event of a fault with the control.

Carry out (2).

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Fixed, accompanied by the

message "

Parking brake

fault

The electric parking brake is faulty: manual and

automatic functions may not be working.

When stationary, to immobilise the vehicle:

► Pull the electric parking brake control and

hold it for approximately 7 to 15 seconds, until

the indicator lamp lights up on the instrument

panel.

If this procedure does not work, secure the

vehicle:

► Park on a level surface.

► With a manual gearbox, engage a gear.

► With an automatic gearbox or drive selector,

select

, then place the supplied chock against

one of the wheels.

Then carry out (2).

Braking

Fixed.

A minor fault with the braking system has

been detected.

Drive carefully.

Carry out (3).

Collision Risk Alert/Active Safety Brake

Flashing.

The system activates and brakes the

vehicle momentarily to reduce the speed of

collision with the vehicle in front.

For more information, refer to the

Driving

section.

Fixed, accompanied by a message and

an audible signal.

The system has a fault.

Carry out (3).

Fixed, accompanied by the display of a

message.

The system has been deactivated via the vehicle

configuration menu.

Dynamic stability control (DSC)/Anti-slip

regulation (ASR)

Flashing.

DSC/ASR system regulation is activated

in the event of a loss of grip or trajectory.

Fixed.

The DSC/ASR system has a fault.

Carry out (3).

Emergency brake malfunction (with

electric parking brake)

Fixed, accompanied by the

message "

Parking brake fault

Emergency braking does not deliver optimal

performance.

If automatic release is not available, use manual

release or carry out (3).

Hill start assist

Fixed, accompanied by the

message "

Anti roll-back system

fault

The system has a fault.

Carry out (3).

Dynamic stability control (DSC)/Anti-slip

regulation (ASR)

Fixed.

The system is deactivated.

The DSC/ASR system is reactivated

automatically when the vehicle is restarted,

and at speeds above approximately 31 mph

(50 km/h).

At speeds below 31 mph (50 km/h), it can be

reactivated manually.

Under-inflation

Fixed, accompanied by an audible signal

and a message.

The pressure in one or more tyres is too low.

Check the pressure of the tyres as soon as

possible.

Reinitialise the detection system after adjusting

the pressure.

Under-inflation warning lamp

flashing then fixed and Service

warning lamp fixed.

The tyre pressure monitoring system is faulty.

Under-inflation detection is no longer monitored.

Check the tyre pressures as soon as possible

and carry out (3).

Engine preheating (Diesel)

Temporarily on

(up to approximately 30 seconds in

severe weather conditions).

When switching on the ignition, if the weather

conditions and the engine temperature make it

necessary.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

Wait until the warning lamp goes off before

starting.

When the warning lamp goes off, starting will

occur immediately if you press and hold:

– the clutch pedal with a manual gearbox.

– the brake pedal with an automatic gearbox.

If the engine does not start, make the engine

starting request again, while keeping your foot

on the pedal.

Front passenger airbag (ON)

Fixed.

The front passenger airbag is activated.

The control is in the "

" position.

In this case, do NOT install a "rearward

facing" child seat on the front passenger seat

- Risk of serious injury!

Front passenger airbag (OFF)

Fixed.

The front passenger airbag is deactivated.

The control is set to the “

OFF

” position.

A "rearward facing" child seat can be installed,

unless there is a fault with the airbags (Airbags

warning lamp on).

Airbags

Fixed.

One of the airbags or seat belt

pyrotechnic pretensioners is faulty.

Carry out (3).

Low fuel level (Diesel)

Fixed (warning lamp or LED) and

needle in the red zone (depending

on version), accompanied by an audible signal

and a message.

When it first comes on, there remains

less than

8 litres

of fuel in the tank.

Until the fuel level is topped up, this alert will

be repeated every time the ignition is switched

on, with increasing frequency as the fuel level

decreases and approaches zero.

Refuel without delay to avoid running out of fuel.

Never drive until completely empty

, as

this could damage the emissions control and

injection systems.

Low traction battery level (Electric)

0 %

100

Fixed LED and needle in the red zone,

accompanied by an audible signal and a

message.

The state of charge of the traction battery is low.

View the remaining range.

Put the vehicle on charge as soon as possible.

Tortoise mode with limited driving range

(Electric)

Fixed.

The state of charge of the traction battery

is critical.

The engine power gradually decreases.

You must put the vehicle on charge.

If the warning lamp remains lit, carry out (2).

Pedestrian horn (Electric)

Fixed.

Horn fault detected.

Carry out (3).

Water in Diesel fuel filter (Diesel)

Fixed (with LCD instrument panel).

The Diesel fuel filter contains water.

Carry out (2) without delay. Risk of damaging the

fuel injection system!

Particle filter (Diesel)

Fixed, accompanied by an audible signal

and a message about the risk of particle

filter blockage.

The particle filter is nearing saturation.

As soon as traffic conditions allow, regenerate

the filter by driving at a speed of at least 37 mph

(60 km/h), with an engine speed of above 2,500

rpm, until the warning lamp goes off.

Fixed, accompanied by an audible signal

and a message indicating that the

additive level in the particle filter is too low.

The low level in the additive tank has been

reached.

Top up without delay: carry out (3).

Power steering

Fixed.

The power steering has a fault.

Drive carefully at moderate speed, then carry

out (3).

Rear foglamp

Fixed.

The lamp is on.

Foot on the brake

Fixed.

Insufficient or no pressure on the brake

pedal.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

With the automatic gearbox or the drive selector,

it may be necessary to depress the brake pedal

to unlock the gearbox from mode

Foot on the clutch

Fixed.

Stop & Start: the change to START mode

is rejected because the clutch pedal is not fully

depressed.

Fully depress the clutch pedal.

Green warning/indicator lamps
Automatic wiping

Fixed.

Automatic windscreen wiping is activated.

Automatic headlamp dipping

Fixed.

The function has been activated

via the vehicle’s configuration menu.

The lighting control stalk is in the "AUTO"

position.

For more information, refer to the

Lighting and

visibility

section.

Stop & Start

Fixed.

When the vehicle stops, the Stop & Start

system puts the engine into STOP mode.

Flashing temporarily.

STOP mode is momentarily unavailable

or START mode is automatically triggered.

For more information, refer to the

Driving

section.

Vehicle ready to drive (Electric)

Fixed, accompanied by an audible signal

when it comes on.

The vehicle is ready to drive and the thermal

comfort systems are available.

The indicator lamp goes out upon reaching a

speed of approximately 3 mph (5 km/h) and

lights up again when the vehicle stops moving.

The lamp will go out when you switch off the

motor and exit the vehicle.

Blind spot monitoring

Fixed.

The function has been activated.

Lane departure warning system

Flashing, accompanied by an audible

signal.

A lane marking has been crossed on the left or

right.

Turn the steering wheel in the opposite direction

to return to the correct trajectory.

For more information, refer to the

Driving

section.

Fixed, accompanied by an onscreen

message.

The system has a fault.

Stay alert and drive carefully, then carry out (3).

Direction indicators

Flashing with audible signal.

The direction indicators are on.

Sidelamps

Fixed.

The lamps are on.

Dipped beam headlamps

Fixed.

The lamps are on.

Front foglamps

Fixed.

The front foglamps are on.

Blue warning/indicator lamps
Main beam headlamps

Fixed.

The lamps are on.

Black/white warning lamps
Foot on the brake

Fixed.

Insufficient or no pressure on the brake

pedal.

With an automatic gearbox, with the engine

running, before releasing the parking brake, to

move out of position

Indicators

Service indicator

The service indicator is displayed on the

instrument panel. Depending on the vehicle

version:

– the distance recorder display line indicates

the distance remaining before the next service

is due, or the distance travelled since it was due

preceded by the sign “-”.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dashboard instruments

– an alert message indicates the distance

remaining, as well as the period before the next

service is due or how long it is overdue.

Service spanner

On temporarily when the ignition is

switched on.

Between 620 and 1,860 miles (1,000 and 3,000

km) remain before the next service is due.

Fixed, when the ignition is switched on.

The next service is due in less than 620

miles (1,000 km).

Have your vehicle serviced very soon.

Service spanner flashing

Flashing then fixed, when the

ignition is switched on.

(With BlueHDi Diesel engines, associated with

the Service warning lamp.)

The servicing interval has been exceeded.

Have your vehicle serviced as soon as possible.

Resetting the service indicator

The service indicator must be reset after each

service.

► Switch the ignition off.

► Press and hold this button.

► Switch on the ignition; the distance recorder

display begins a countdown.

► Release the button when

is displayed; the

spanner disappears.

If you have to disconnect the battery

following this operation, lock the vehicle

and wait at least 5 minutes for the reset to be

registered.

Retrieving the service information

The service information can be accessed at any

time.

► Press this button.

The service information is displayed for a few

seconds, then disappears.

The distance indicated (in miles or

kilometres) is calculated according to the

distance covered and the time elapsed since

the last service.

The alert may be triggered close to a due

date.

Coolant temperature

indicator (Diesel)

With the engine running:

– In zone

, the temperature is correct.

– In zone

, the temperature is too high.

The associated warning lamp and the

STOP

warning lamp light up in red on the

instrument panel, accompanied by the display of

a message and an audible signal.

You must stop the vehicle as soon as it is

safe to do so.

Wait a few minutes before switching off the

engine.

After switching off the ignition, carefully

open the bonnet and check the coolant

level.

For more information on

Checking

levels

, refer to the corresponding

section.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Citroën Jumpy-Dispatch (2022 year). Manual in english - page 1
