18

Dashboard instruments

Checking

After driving for a few minutes, the temperature

and pressure in the cooling system increase.

To top up the level:

►  wait at least one hour for the engine to cool,

►  unscrew the cap by two turns to allow the

pressure to drop,

►  when the pressure has dropped, remove the

cap,

►  top up the level to the "MAX" mark.

For more information on

Checking levels

, refer

to the corresponding section.

Be aware of the risk of scalding when

topping up the coolant. Do not fill above

the maximum level (indicated on the

reservoir).

Engine oil level indicator

(Depending on version)

On versions fitted with an electric gauge, the

engine oil level status is displayed on the

instrument panel for a few seconds when the

ignition is switched on, at the same time as the

servicing information.

The level read will only be correct if the

vehicle is on level ground and the engine

has been off for more than 30 minutes.

Oil level correct





This is indicated by a message on the instrument

panel.

Low oil level





This is indicated by a message on the instrument

panel.

If a low oil level is confirmed by a check using

the dipstick, the level must be topped up to avoid

damage to the engine.

For more information on

Checking levels

, refer

to the corresponding section.

Oil gauge malfunction





This is indicated by the display of a message on

the instrument panel.

Contact a CITROËN dealer or a qualified

workshop.

In the event of a malfunction of the

electric gauge, the oil level is no longer

monitored.

If the system is faulty, you must check the

engine oil level using the manual dipstick

located in the engine compartment.

For more information on

Checking levels

,

refer to the corresponding section.

AdBlue

®

 range indicators

(BlueHDi)

The Diesel BlueHDi engines are equipped with

a system that associates the SCR (Selective

Catalytic Reduction) emissions control system

and the Diesel particle filter (DPF) for the

treatment of exhaust gases. They cannot

function without AdBlue

®

 fluid.

When the level of AdBlue

®

 falls below the

reserve level (between 1,500 and 0 miles (2,400

and 0 km)), a warning lamp lights up when

the ignition is switched on and an estimate

of the distance that can be travelled before

engine starting is prevented is displayed in the

instrument panel.

The engine starting prevention system

required by regulations is activated

automatically once the AdBlue

®

 tank is empty.

It is then no longer possible to start the

engine until the minimum level of AdBlue

®

 has

been topped up.

19

Dashboard instruments

1

Manual display of driving range

While the driving range is greater than

1,500 miles (2,400 km), it is not displayed

automatically.









►  Press this button to temporarily display the

driving range.

With touch screen

You can view the range information in the

"

Driving/Vehicle

" menu.

Actions required related to a lack of

AdBlue

®

The following warning lamps light up when the

quantity of AdBlue

®

 is below the reserve level:

driving range of 1,500 miles (2,400 km).

Together with the warning lamps, messages

regularly remind you of the need to top up to

avoid engine starting being prevented. Refer to

the

Warning and indicator lamps

 section for

details of the messages displayed.

For more information on

AdBlue

®



(BlueHDi)

 and in particular on topping

up, refer to the corresponding section.

With BlueHDi (Euro 6.2/6.3) engines

Warning/

indicator

lamps on

Action

Remaining

range





Top up.

Between

1,500 miles

and 500

miles (2,400

km and 800

km)





Top up as

soon as

possible.

Between

500 miles

and 62

miles (800

km and

100 km)





A top-up is

vital

, there is

a risk that the

engine will

be prevented

from starting.

Between 62

miles and 0

miles (100

km and 0

km)





To be able

to restart the

engine, add at

least 5 litres of

AdBlue

®

 to the

tank.

0 miles (km)

Malfunction of the SCR emissions

control system

Malfunction detection





If a malfunction is detected,

these warning lamps come

on, accompanied by an

audible signal and the

display of an "

Emissions

control fault

" or "

NO START

IN

" message.

The alert is triggered while driving when the

fault is detected for the first time, and thereafter

when switching on the ignition for subsequent

journeys, for as long as the cause of the fault

persists.

If the fault is temporary, the alert

disappears during the next journey, after

self-diagnostic checks of the SCR emissions

control system.

Malfunction confirmed during the

permitted driving phase (between 685

miles and 0 miles (1,100 km and 0 km))

If the fault indication is still displayed

permanently after 31 miles (50 km) of driving, the

fault in the SCR system is confirmed.

The AdBlue warning lamp flashes and

a message is displayed ("

Emissions

control fault: starting prevented in X miles

(kms)

" or "

NO START IN X miles (kms)

"),

20

Dashboard instruments

indicating the driving range in miles or

kilometres.

While driving, the message is displayed every 30

seconds. The alert is repeated when switching

on the ignition.

You can continue driving for up to 685 miles

(1,100 km) before the

engine starting

prevention

 system is triggered.

Have it checked by a CITROËN dealer or

a qualified workshop.

Starting prevented

Every time the ignition is switched on, the

message "

Emissions control fault: Starting

prevented

" or "

NO START IN

" is displayed.

To restart the engine

Contact a CITROËN dealer or a qualified

workshop.

Power indicator (Electric)





CHARGE

Traction battery charging during deceleration

and braking.

ECO

Moderate energy consumption and optimised

driving range.

POWER

Energy consumption by the drive train during

acceleration.

NEUTRAL

When the ignition is switched on, the vehicle’s

electric drive train neither consumes nor

generates energy; after sweeping over the

indicator, the needle returns to its "neutral"

position: between ECO and CHARGE.

With the ignition off, opening the driver's

door activates the indicator, which moves

to the "neutral" position: between ECO and

CHARGE.

Charge level indicator

(Electric)





The traction battery's actual charge level and

the remaining range are displayed continuously

when the vehicle is started.

With the ignition off, opening the driver's

door activates the indicator.

Associated warning lamps

Two successive alert levels indicate that the

energy available has dropped to a low level:

1st level: Reserve

0 %

100

The state of charge of the traction battery

is low.

21

Dashboard instruments

1

Fixed LED and needle in the red zone,

accompanied by an audible signal.

►  View the remaining range on the instrument

panel.

►  Put the vehicle on charge as soon as

possible.

2nd level: Critical

The state of charge of the traction battery

is critical.

Fixed, together with the reserve LED,

accompanied by an audible signal.

►  You must put the vehicle on charge.

The remaining range is no longer

calculated. The drive train power

gradually decreases.

The heating and air conditioning are switched

off (even if the needle indicating their

consumption is not at the "

ECO

" position).

Thermal comfort

consumption indicator

(Electric)





The gauge shows the consumption of the

traction battery's electrical energy by the thermal

comfort devices in the passenger compartment.

The devices in question are the heating and air

conditioning systems.

This equipment can be used:

–  If the vehicle is not plugged in, when the

READY

 lamp is lit.

–  If the vehicle is plugged in, when the ignition is

switched on ("Lounge" mode).

Selecting

ECO

 mode limits the performance

of some of this equipment. The needle on the

thermal comfort consumption indicator then

moves into the "

ECO

" zone.

To quickly heat or cool the passenger

compartment, feel free to temporarily

select the maximum heating or cooling

setting.

When the heating is on maximum, the gauge

on the thermal comfort consumption indicator

is in the

MAX

 zone. When the air conditioning

is on maximum, it stays in the

ECO

 zone.

Excessive use of thermal comfort equipment,

particularly at low speed, can significantly

decrease the vehicle's range.

Remember to optimise equipment settings

upon achieving the desired level of comfort,

and adjust them if necessary whenever you

start the vehicle.

After an extended period without using the

heating, you may notice a slight odour during

the first few minutes of use.

Distance recorders

The total and trip distances are displayed for

thirty seconds when the ignition is switched off,

when the driver's door is opened and when the

vehicle is locked or unlocked.

22

Dashboard instruments

Total distance recorder









This measures the total distance travelled by the

vehicle since its initial registration.

Trip distance recorder (Diesel)









This measures the distance travelled since it was

last reset by the driver.

Resetting the trip recorder





►  With the ignition on, press the button until

zeros appear.

Lighting dimmer

This system allows the brightness of the

instruments and controls to be adjusted manually

to suit the ambient light level.

With buttons









With the lamps on, press button

A

 to increase

the brightness of the lighting, or button

B

 to

decrease it.

Release the button when the desired brightness

is reached.

With touch screen





►  In the

Settings

 menu, select "

Brightness

"

or "

OPTIONS

", "

Screen configuration

" then

"

Brightness

".

►  Adjust the brightness by pressing the arrows

or moving the slider.

The brightness can be set differently for

day mode and night mode.

Trip computer

Displays information related to the current trip

(range, fuel consumption, average speed, etc.).

Information display

To display the various trip computer tabs in turn:

23

Dashboard instruments

1









►  Press the button located on the end of the

wiper control stalk

.

With steering-mounted controls





►  Press the knob on the

steering wheel

.

On the instrument panel









►  Press this button.

The following current information is shown in

turn:

–  Driving range (Diesel).

–  Current consumption.

–  Stop & Start time counter (Diesel).

–  Trip "

1

" followed by (depending on version)

trip "

2

" including average speed, average

consumption and distance travelled for each trip.

Trips "

1

" and "

2

" are independent but their use

is identical.

For example, trip "

1

" can be used for daily

figures and trip "

2

" for monthly figures.

Trip reset

The reset is performed when the trip counter is

displayed.









►  Press the button on the end of the

wiper

control stalk

 for more than two seconds.





►  Press the knob on the

steering wheel

 for

more than two seconds.









►  Press this button for more than 2 seconds.

Definitions

Range

(miles or km)

(Traction battery charge level percentage)

(Electric)

Distance that can still be travelled with the

fuel remaining in the tank (based on the

average fuel consumption over the last few miles

(kilometres) travelled).

This value may vary following a change in driving

style or terrain, leading to a significant change in

current fuel consumption.

When the range falls below 19 miles (30 km),

dashes are displayed.

After filling with at least 5 litres of fuel, the range

is recalculated and is displayed if it exceeds 62

miles (100 km).

Dashes appearing permanently in place of

numbers while driving indicates a malfunction.

24

Dashboard instruments

Contact a CITROËN dealer or a qualified

workshop.

Current consumption

(mpg or l/100 km or km/l)

(miles/kWh or kWh/100 km or km/kWh) (Electric)

/

Calculated during the last few

seconds.

This function is only displayed at speeds above

19 mph (30 km/h) (Diesel).

Average consumption

(mpg or l/100 km or km/l)

(miles/kWh or kWh/100 km or km/kWh) (Electric)

/

Calculated since the last trip

computer reset.

Average speed

(mph or km/h)

Calculated since the last trip computer

reset.

Distance travelled

(miles or km)

Calculated since the last trip computer

reset.

Stop & Start time counter

(minutes/seconds or hours/minutes)

If your vehicle is fitted with the Stop & Start

function, a time counter calculates the time spent

in STOP mode during a journey.

The time counter is reset each time the ignition is

switched on.

Touch screen

This system gives access to the following

elements:

–  Permanent display of the time and outside

temperature (a blue warning lamp appears if

there is a risk of ice).

–  Vehicle functions and equipment setting

menus.

–  Audio system and telephone controls and

display of related information.

–  Display of visual manoeuvring aid functions

–  Internet services and display of related

information.

–  Navigation system controls and

display of related information (depending on

version).

For safety reasons, always stop the

vehicle before performing operations

that require sustained attention.

Some functions are not accessible while

driving.

Recommendations

This screen uses capacitive sensing technology.

–  Do not use pointed objects on the touch

screen.

–  Do not touch the touch screen with wet hands.

–  Use a soft, clean cloth to clean the touch

screen.

Principles

►  Use the buttons on each side of the touch

screen to access the menus, then press the

buttons that appear on the touch screen.

Some menus may display across two pages:

press the "

OPTIONS

" button to access the

second page.

After a few moments with no action on

the second page, the first page is

displayed automatically.

To deactivate/activate a function, select "

OFF

"

or "

ON

".

Configuring a function



Access to additional information on the

function

Confirm



Return to the previous page or confirm



Menus





25

Dashboard instruments

1

Press the touch screen with three fingers

to show all of the menu buttons.

For more information about the menus,

refer to the sections describing the audio

and telematics systems.

Radio/Media



Navigation

 (Depending on equipment)

Driving or Vehicle

 (Depending on

equipment)

Activation, deactivation and settings for certain

functions.

The functions are organised in 2 tabs: "

Driving

functions

" and "

Vehicle settings

".

Telephone



Applications

Display of available connected services.

Energy

Access the specific Electric functions

(energy flow, consumption statistics, deferred

charge) organised in the corresponding 3 tabs.

or

Settings

Main settings for the audio system and

touch screen.

Audio system on/off

Volume adjustment/mute

Upper bar

Certain information is displayed permanently in

the upper bar of the touch screen:

–  Time and outside temperature (a blue warning

lamp appears if there is a risk of ice).

–  Reminder of information from the

RadioMedia

 and

Telephone

 menus and

navigation instructions (depending on

equipment).

–  Notifications.

–  Access to the

Settings

.

Energy menu (Electric)

This menu is only available with MyCitroën

Drive.

Depending on version, this is accessible either:

–  directly, by pressing the button near the

touch screen.

–  via the

Applications

 menu.

Flow

The page displays a real-time representation of

the electric drive train’s operation.





1.

Active driving mode

2.

Electric motor

3.

Estimated traction battery charge level

4.

Energy flows

The energy flows have a specific colour for each

type of driving:

A.

Blue: energy consumption

B.

Green: energy recovery

Statistics

This page shows electrical energy consumption

statistics.





–  Blue bar chart: directly consumed energy

supplied by the traction battery.

–  Green bar chart: energy recovered during

deceleration and braking, used to recharge the

battery.

26

Dashboard instruments

The average result for the current trip is stated in

kWh/100 km.

►  You can change the displayed time scale by

pressing the

-

 or

+

 buttons.

A current trip is any trip of more than 20

minutes without switching off the ignition.

Charging

This page allows you to programme deferred

charging.

For more information on

Charging the traction

battery (Electric)

, refer to the corresponding

section.

Additional remotely

operable functions

(Electric)

(Depending on country of sale)





The following functions are

available from the

MyCitroën

App

 application, which is

accessible from a smartphone:

–  Managing the traction battery charging

(deferred charging).

–  Managing the temperature pre-conditioning.

–  Viewing the state of charge and range of the

vehicle.

Installation procedure

►  Download the

MyCitroën App

 application

from the appropriate online store for your

smartphone.

►  Create an account.

►  Enter the vehicle’s VIN (code beginning with

"VF" on the vehicle registration certificate).

For more information on

Identification

markings

, refer to the corresponding section.

Network coverage

In order to be able to use the various

remotely operable features, ensure that your

vehicle is located in an area covered by the

mobile network.

A lack of network coverage may prevent

communication with the vehicle (for example,

if it is in an underground car park). In such

cases, the application will display a message

indicating that the connection with the vehicle

could not be established.

Setting the date and time

With audio system

►  Press the

MENU

 button for access to the

main menu

.

►  Press the "

7

" or "

8

" button to select the

"

Personalisation-configuration

" menu, then

confirm by pressing the

OK

 button.

►  Press the "

5

" or "

6

" button to select the

Display configuration

 menu, then confirm by

pressing the

OK

button.

►  Press the "

5

" or "

6

" and "

7

" or "

8

" buttons

to adjust the date and time values, then confirm

by pressing the

OK

 button.

With MyCitroën Play

►  Select the

Settings

 menu in the upper

banner of the touch screen.

►  Select "

Configuration

".

►  Select "

Date and time

".

►  Select "

Date

" or "

Time

".

►  Choose the display formats.

►  Change the date and/or time using the

numeric keypad.

►  Confirm with "

OK

".

With MyCitroën Drive

Time and date settings are only available if GPS

synchronisation is deactivated.

►  Select the

Settings

 menu in the

banner of the touch screen.

►  Press the "

OPTIONS

" button to access the

secondary page.

►  Select "

Setting the time-date

".

►  Select the "

Date:

" or "

Time

" tab.

►  Set the date and/or time using the numeric

keypad.

►  Confirm with "

OK

".

27

Dashboard instruments

1

Additional settings

You can choose:

–  To change the time zone.

–  To change the display format of the date and

time (12h/24h).

–  To activate or deactivate the summer time

management function (+1 hour).

–  To activate or deactivate GPS synchronisation

(UTC).

The system does not automatically

change between winter and summer time

(depending on the country of sale).

28

Access

Electronic key with

remote control function

and built-in key

Advice

If one of the doors or the boot is still open

or if the electronic key for the Keyless

Entry and Start  system has been left inside

the vehicle, central locking will not take place.

However, if the vehicle is fitted with an alarm,

it will be activated after 45 seconds.

If the vehicle is unlocked but the doors or

boot are not subsequently opened, the

vehicle will automatically lock itself again after

about 30 seconds. If the vehicle is fitted with

an alarm, it will be reactivated automatically.

Automatic door mirror folding and

unfolding can be deactivated by a

CITROËN dealer or a qualified workshop.

As a safety measure, never leave the

vehicle, even for a short time, without

taking the Keyless Entry and Start system’s

electronic key with you.

Be aware of the risk of theft of the vehicle if

the key is present in one of the defined areas

while the vehicle is unlocked.

If a door is not properly closed (except the

right-hand door with side-hinged rear

doors):

–  when the vehicle is stationary and engine

running, this warning lamp comes on,

accompanied by a warning message for a few

seconds,

–  when the vehicle is moving (at speeds above

6 mph (10 km/h)), this warning lamp comes on,

accompanied by an audible signal and a warning

message for a few seconds.

Remote control key

This allows the central locking or unlocking of the

vehicle using the door lock or from a distance.

It also allows the vehicle to be located, the fuel

filler cap and charging flap to be opened and

closed and the engine to be started or switched

off, as well as providing protection against theft.

The remote control buttons are not active

with the ignition switched on.

Unfolding / Folding the key





►  Press this button to unfold or fold the key.

The remote control may be damaged if

you do not press the button.

Keyless Entry and Start

This allows the central locking or unlocking of the

vehicle from a distance.

It is also used to locate and start the vehicle, as

well as providing protection against theft.

Integral key

This is used to lock and unlock the vehicle when

the remote control cannot operate:

–  cell battery flat, vehicle battery discharged or

disconnected, etc.

–  vehicle located in an area with strong

electromagnetic signals.



29

Access

2



►  Keep this button

1

 pulled while removing

key

2

 from the housing.

If the alarm is activated, the audible

signal triggered on opening a door with

the key (integral with the remote control) will

stop when the ignition is switched on.

Once the built-in key is ejected, always

keep it with you to be able to carry out

the corresponding back-up procedures.

"Keyless Entry and Start" on your

person





It allows the unlocking, locking and starting of the

vehicle while carrying the remote control on your

person in recognition zone "

A

".

In the ignition on (accessories) position,

with the "START/STOP" button, the

hands-free function is deactivated and it is

impossible to open the doors.

For more information on

Starting/switching

off the engine, Keyless Entry and Start

 and

in particular the "ignition on" position, refer to

the corresponding section.

Locating the vehicle

This function helps you to spot your vehicle from

a distance, with the vehicle locked:

–  The direction indicators flash for approximately

10 seconds.

–  The courtesy lamps come on.

►  Press this button.



Remote operation of lighting

If fitted to the vehicle.

A short press on this button switches on

the lighting remotely (lighting of

sidelamps, dipped beam headlamps and number

plate lamps).

A second press on the button before the end of

the timed period cancels the remote lighting.

Advice

Remote control

The remote control is a sensitive, high-

frequency device; avoid handling it in your

pocket, due to the risk of unintentionally

unlocking the vehicle.

Avoid pressing the remote control buttons

while out of range of the vehicle, due to

the risk of rendering the remote control

inoperative. It would then be necessary to

reset it.

The remote control does not work when the

key is in the ignition switch, even when the

ignition is switched off.

Anti-theft protection

Do not modify the electronic vehicle

immobiliser, as this might result in

malfunctions.

For vehicles with a key ignition switch,

remember to remove the key and turn the

steering wheel to engage the steering lock.

Locking the vehicle

Driving with the doors locked could make

it more difficult for the emergency services

to enter the passenger compartment in an

emergency.

As a safety precaution, remove the key from

the ignition or take the electronic key with you

when leaving the vehicle, even for a short

time.

30

Access

Purchasing a second-hand vehicle

Have the key codes memorised by a

CITROËN dealer, to ensure that the keys in

your possession are the only ones able to

start the vehicle.

To preserve the battery charge in the

electronic key and the vehicle's battery,

the "hands-free" functions are set to

hibernation mode after 21 days without use.

To restore these functions, press one of the

remote control buttons or start the engine with

the electronic key in the reader.

For more information on starting with the

Keyless Entry and Start system, refer to the

corresponding section.

Electrical interference

The electronic key may not work if it is

close to an electronic device (e.g. mobile

telephone (switched on or on standby), laptop

computer, strong magnetic fields). If this

occurs, move the electronic key away from

the electronic device.

Accumulations (water, dust, grime, salt,

etc.) on the inner surface of the door

handle may affect detection.

If cleaning the inner surface of the door

handle using a cloth does not restore

detection, contact a CITROËN dealer or a

qualified workshop.

A sudden splash of water (stream of water,

high pressure jet washer, etc.) may be

identified by the system as the desire to open

the vehicle.

Unlocking/Complete or

selective unlocking

What is the purpose of total

or selective unlocking?









Total unlocking unlocks

all

 the vehicle’s doors

(front, side and rear).





Selective unlocking unlocks either the

cab

 doors,

or the doors of the

loading area

 (side and rear).

The separated unlocking system

between

cab

 and

loading area

 is a

security measure. This prevents access to the

part of the vehicle where the driver is not

present.

Activation/Deactivation









►  To

activateselective

 unlocking

between the

cab

 and the

loading

area

 or to

deactivate

 selective unlocking and

return to

total

 unlocking mode, switch on the

ignition and press this button for more than two

seconds.

An audible signal and, depending on equipment,

a display message, confirm that the request has

been acknowledged.

Selective unlocking between

cab

 and

loading area

 is activated by default.

31

Access

2

Unlocking/Complete

unlocking

Unlocking is signalled by rapid flashing of

the direction indicators for a few

seconds.

Depending on version, the door mirrors unfold

and the alarm is deactivated.

With the key

►  To unlock the vehicle

fully

, turn the key in the

front left-hand door lock towards the front of the

vehicle.

If the vehicle has an alarm, it will not be

deactivated. Opening a door will trigger the

alarm, which can be stopped by switching the

ignition on.

With the remote control

►  Depending on equipment,

press one of these buttons to

unlock the vehicle.

Using the remote control with electric

sliding side door(s)

►  To

fully

 unlock the vehicle and open

the side door, press and hold this button

until the door has opened.

With Keyless Entry and Start on your

person

To unlock the vehicle, the remote control must be

in recognition zone

A

.

►  To unlock the vehicle

fully

, pass your hand

behind one of the door handles (front door(s),

manual sliding side door(s) or left-hand side-

hinged door) and then pull the handle to open

the corresponding door.

With electric sliding side door(s)





►  With the Keyless Entry and Start on your

person, pass your hand behind the handle

to unlock the vehicle, then pull and release

the handle. This action also causes the

corresponding door to open.

With tailgate





►  With the Keyless Entry and Start on your

person, to unlock the

vehicle

, pull the tailgate

handle and then lift it up to open it.

With an opening rear screen in the tailgate





►  With the Keyless Entry and Start on your

person, to unlock the vehicle, press the tailgate

opening rear screen unlocking control. The

screen will open slightly; then, lift it up to open it.

Selective unlocking





32

Access

Unlocking is signalled by rapid flashing of

the direction indicators for a few

seconds.

Depending on version, the door mirrors unfold

and the alarm is deactivated.

With the remote control

►  To unlock the

cabin

 doors alone,

press this button

once

.

►  To unlock the side and rear doors of the

loading area

, press this button a

second time

.

If the vehicle is fitted with this function:

►  Press this button to unlock the

loading area

 only.

Using the remote control with electric

sliding side door(s)

►  To unlock the

loading area

 alone

without opening the side door, press the

relevant door button or keep the button pressed

down to open the door.

With Keyless Entry and Start on your

person





►  To unlock the

cabin

 alone, pass your hand

behind a handle of the front left or right doors,

then pull the handle to open the door.

The door locking state of the

loading

area

 remains unchanged.





►  To unlock the loading area alone, the remote

control on your person in

recognition zone



A

,

B



or

C

, pass your hand behind a handle of the front

left or right doors, then pull the handle to open

the corresponding door.

Depending on the version, the door

mirrors unfold only when the cabin is

unlocked, the alarm is deactivated.

With electric sliding side door(s)





►  With the Keyless Entry and Start on your

person, pass your hand behind the left-hand or

right-hand door handle to unlock the

loading

area

, then pull and release the handle. This

action also causes the corresponding door to

open.

With tailgate





►  With the Keyless Entry and Start on your

person, to unlock the

loading area

, pull the

tailgate handle and then lift it up.

Unlocking is signalled by rapid flashing of

the direction indicators for a few

seconds.

33

Access

2

Locking

With the key

►  To lock the vehicle

fully

, turn the key in the

front left-hand door lock towards the rear of the

vehicle.

If your vehicle has an alarm, it will not be

activated.

With the remote control

►  To lock the vehicle

completely

, press

this button.

With Keyless Entry and

Start on your person

To lock the vehicle, the remote control must be in

recognition zone

A

.





►  To lock the vehicle, press the markings on

one of the door handles (front door(s), manual

sliding side door(s) or left-hand side-hinged

door).

With electric sliding side door(s)

►  With the Keyless Entry and Start on your

person, to lock the vehicle

fully

, press the

markings on one of the

front

 door handles.

With tailgate





►  With the Keyless Entry and Start on your

person, press the tailgate locking control to lock

the vehicle.

Depending on version, keeping

the locking controls depressed

closes the windows. If the control is released,

the window stops in its current position.

Ensure that no person or object might

prevent the windows from closing

properly.

Pay particular attention to children when

operating windows.

If the vehicle is not fitted with an alarm,

locking is signalled by fixed lighting of the

direction indicators for approximately two

seconds.

Depending on version, the door mirrors fold at

the same time.

Driving with the doors locked could make

it more difficult for the emergency

services to enter the passenger compartment

in an emergency.

As a safety measure, never leave the vehicle

without taking the remote control with you,

even for a short time.

Deadlocking

Deadlocking deactivates the exterior and

interior door controls, as well as the

central locking button on the dashboard.

The horn remains operational.

You must therefore never leave anyone inside

the vehicle when it is deadlocked.

With the key

►  To deadlock the vehicle, turn the key in the

front left-hand door lock towards the rear of the

vehicle.

►  Then,

within five seconds

, turn the key

towards the rear again.

With the remote control

►  To deadlock the vehicle, press this

button.

►  Then

within five seconds after locking

,

press this button again.

Depending on version, the electric door

mirrors fold at the same time.
