Citroen C-Crosser Dag (2008 year). Instruction

C O M F O R T

BOOT LAYOUT

12 volt socket (120 W max).

2. Open storage compartment.
3. Right-hand side enclosed storage

compartment.

Storage compartment in the ﬂ oor * .

5. Stowing rings.
6. Left-hand side storage compartment

or audio equipment.

7. Load space cover.

* 5-seat version only.

C O M F O R T

12 volt socket (120 W max)

This operates when the ignition switch
is in the “ON” or “ACC” position.
Lift the cover to gain access to the
socket.

Check that the electrical equip-
ment operates with 12 volts

and that its maximum electri-

cal power is 120 W.
The prolonged use of electri-

cal equipment without running the
engine may discharge the battery.

Stowing rings

There are four stowing rings in the boot
for securing luggage:
-

two rings are located on the boot

ﬂ oor,

two rings are located on the rear
side pillars.

* On 5-seat version only.

Raise the boot ﬂ oor to gain access to

this compartment.

Right-hand side enclosed storage
compartment
This storage compartment contains the
tools for changing a wheel.

Storage compartment in the ﬂ oor *

C O M F O R T

Load space cover

Unroll the load space cover and install it
in the securing groove  A .
To  store  the  load  space  cover,  release
it from the securing groove, it rolls up to
its initial position.

  Second installation position.
The  load  space  cover  can  be  secured
in two different positions  B , so that the
row 2 seat backs can be tilted.
   1.   Roll up the load space cover.
  2.   Move  one  of  the  slides   C   towards

the  inside  of  the  vehicle  and  insert
the  tab   D   in  the  installation  hole  to
be used.
Move the opposite slide in the same
way.

3. After changing the position, check

that the load space cover is secured
correctly.

  Removing the load space cover.
   1.   Roll up the load space cover.
  2.   Move one of the slides  C  towards the

inside of the vehicle and raise it.

Release the opposite slide in the
same way.

To put the load space cover in place,
carry out the operations in reverse
order.

Take care not to place heavy
objects on the load space cover
when it is unfolded.

The load space cover can be stored
along the lower tailgate, unless audio
equipment is present.

A C C E S S

III

Unfolding the key


First press button A to unfold the

key.

Unlocking the vehicle



Press the open padlock
to unlock the vehicle.

Unlocking using the remote control

REMOTE CONTROL KEY

System  which  permits  central  unlock-
ing  or  locking  of  the  vehicle  using  the
lock or from a distance. It also folds and
unfolds  the  mirrors,  closes  the  electric
windows and starts the vehicle, as well
as providing protection against theft.

Locking the vehicle

Unlocking using the key


Turn  the  key  to  the  right  in  the
driver’s  door   lock  to  unlock  the
vehicle.



Press the closed padlock

to lock the vehicle.

If one of the doors or the tailgate is
still open, the central locking will not
take place.

Unlocking is conﬁ rmed by the interior

lighting which comes on for approxi-

mately 15 seconds and the direction

indicators which ﬂ ash  twice .
If you press the open padlock  twice in
succession   within  30  seconds  after

unlocking the vehicle, the exterior mir-

rors unfold.

Normal locking using the key


Turn the key to the left in the driver’s
door lock to lock the vehicle.

Locking is conﬁ rmed by the direction in-

dicators which come on  once .
If  you  press  the  closed  padlock   twice
in succession  within 30 seconds after

locking the vehicle, the exterior mirrors

fold.
An extended press on the closed pad-
lock within 30 seconds after locking the
vehicle permits automatic closing of the
windows.

Normal locking using the remote
control

A C C E S S

III

The  vehicle  will  relock  automatically
after thirty seconds unless a door or
the  tailgate  is  opened.  This  function
prevents inadvertent unlocking.
The duration which precedes the au-
tomatic  relocking  of  the  vehicle  can

be conﬁ gured via the colour display

“Equipment” menu.

Folding the key


First press button A to fold the key.

  Electronic engine immobiliser
The  key  contains  an  electronic  chip
which has a special code. When the ig-
nition is switched on, this code must be
recognised to permit starting.
This electronic engine immobiliser locks
the  engine  management  system  a  few
moments  after  the  ignition  is  switched
off  and  prevents  starting  of  the  engine
by anyone who does not have the key.

Anti-theft protection

   In  the  event  of  a  malfunction  and  if
your  vehicle  does  not  start;  contact  a
CITROËN  dealer as soon as possible.

A C C E S S

III

Starting the vehicle



Insert the key in the ignition switch.



Operate the starter by turning the

key to position 4 (START) .



When the engine turns over, release

the key. The ignition switch is placed
in position 3 (ON) automatically.

Switching the vehicle off



Park the vehicle.



While pressing the key, turn it to-

wards you to position 1 (LOCK) .



Remove the key from the ignition

switch.

Changing the battery

Battery reference: CR1616 / 3 volts.



Unclip the casing using a coin at the

notch.



Slide the ﬂ at battery out of its hous-

ing.



Slide the new battery into its hous-

ing observing the original direction.



Clip the casing.

Key in ignition

A buzzer sounds on opening the
driver’s door, if the key has been left
in the ignition.

A C C E S S

III

Do not throw the remote control batteries away, they contain metals which are harmful to the environment.
Take them to an approved collection point.

Keys

Make a careful note of the number of each key. This number is coded on the label attached to the key.
If the keys are lost, a CITROËN dealer can supply you with new keys.

Remote control

The high frequency remote control is a sensitive system; do not operate it while it is in your pocket as there is a possibility
that it may unlock the vehicle, without you being aware of it.
Do not repeatedly press the buttons of your remote control out of range and out of sight of your vehicle.
You run the risk of stopping it from working. The remote control does not operate when the key is in the ignition, even when
the ignition is switched off.

Locking the vehicle

Driving with the doors locked may make access to the passenger compartment by the emergency services more difﬁ cult

in an emergency.
As a safety precaution (with children on board), remove the key from the ignition when you leave the vehicle, even for a
short time.

Anti-theft protection

Do not make any modiﬁ cations to the electronic engine immobiliser system, this could cause malfunctions.

When purchasing a second-hand vehicle

Have the key codes memorised by a CITROËN dealer, to ensure that the keys in your possession are the only ones which
can start the vehicle.

A C C E S S

III

be conﬁ gured via the colour display

“Equipment” menu.

Folding the key


First press button A to fold the key.

Anti-theft protection

   In  the  event  of  a  malfunction  and  if
your  vehicle  does  not  start;  contact  a
CITROËN  dealer as soon as possible.

A C C E S S

III

The electric window switches can

be conﬁ gured via the colour display

“Equipment” menu.
The electric window switches remain

operational

for

approximately

30 seconds  after  the  ignition  is
switched  off  and  the  switch  on  the
driver’s door remains operational for
a further 30 seconds when the door
is opened.
The  windows  can  no  longer  be
opened  or  closed  after  the  driver’s
door is closed.
The rear windows do not lower fully.

ELECTRIC WINDOWS

   1.    Driver’s electric window switch.
  2.    Passenger’s electric window switch.
  3.    Rear right electric window switch.
  4.    Rear left electric window switch.
  5.    Disarming  of  the  passenger  and

rear electric window switches.

In the event of unwanted opening of

the window on closing (for example

in the presence of frost), reinitialise
the electric windows (refer to the cor-
responding paragraph).

  Safety auto-reverse
In  automatic  mode,  when  the  window
rises  and  meets  an  obstacle,  it  stops
and lowers again.

Operation

With the ignition on, you have two op-
tions:

manual mode



Press the switch gently to open or
pull it gently to close. The window
stops as soon as the switch is re-
leased.

automatic mode



Press the switch fully to open or
pull it fully to close. The window
opens or closes completely when
the switch is released.



Pressing the switch again stops
the movement of the window.

System which opens or closes a win-

dow manually or automatically. It is ﬁ t-

ted  with  a  system  which  provides  pro-
tection  if  an  obstacle  is  detected  on
one-touch  models  and  a  deactivation
system  to  prevent  misuse  of  the  rear
controls.

A C C E S S

Disarming the passenger and rear
electric window switches

Reinitialising the electric
windows

Following reconnection of the battery or
after the safety auto-reverse has been
triggered three times in succession, you
must reinitialise the safety auto-reverse
function:


with the door closed, lower the win-

dow completely then raise it again, it
will rise in steps of a few centimetres
each time the switch is pressed, re-
peat the operation until the window
is fully closed,



continue to press the switch for at

least one second after reaching the
window closed position.

Always remove the key from
the ignition when leaving the
vehicle, even for a short time.

In the event of contact during opera-
tion of the windows, you must reverse
the  movement  of  the  window. To  do
this, press the switch concerned.
When  the  driver  operates  the  pas-
senger electric window switches, he
must ensure that no one is prevent-
ing correct closing of the windows.
The driver must ensure that the pas-
sengers  use  the  electric  windows
correctly.
Be aware of children when operating
the windows.



For the safety of your children, press

switch 5 to prevent operation of the
passenger and rear electric windows
irrespective of their position.

When the button is pressed down,
disarming is active.
When the button is raised, disarming is
deactivated.

When  the  button  is  pressed  down,
you  can  open  or  close  all  of  the
windows  using  the  switches  on  the
driver’s door.

The safety auto-reverse function is
not active during these operations.

A C C E S S

III

DOORS

From outside


After unlocking the vehicle using the

remote control or the key, pull the
door handle.

From inside



Pull the front or rear door control to

open the door.

If the doors are locked, opening the
driver’s door unlocks all of the doors.
The front passenger door or the rear

doors must ﬁ rst be unlocked manually

using the locking control before being
opened.

Closing

If a door is not closed correctly,
this  warning  light  comes  on  on
the  instrument  panel  display
until  the  door  concerned  is
closed.

Manual centralised control

System which provides full manual
locking or unlocking of the doors and
tailgate from the inside.

Locking
 Press the front of button A to lock

the vehicle.

If the driver’s door is open when you
operate the central locking from in-

side, all of the doors lock with the ex-

ception of the driver’s door.

Unlocking


Press the rear of button A to unlock

the vehicle.

Opening

A C C E S S

III

Emergency control

System which locks or unlocks the
doors mechanically in the event of a
malfunction of the central locking.

Locking the driver’s door


Insert the key in the lock, then turn it

to the left.

Unlocking the driver’s door


Insert the key in the lock, then turn it

to the right.

Unlocking the front and rear doors
(from inside)


Tilt the interior control B rearwards.

Using the key

Locking the front passenger door
and the rear doors (from inside)


Tilt the interior control B forwards.

A C C E S S

III

Opening



After unlocking the vehicle using the

remote control or the key, press the
handle A and raise the tailgate.

“Tailgate open” warning

This warning light comes on on
the instrument panel display
when the tailgate is not closed
correctly.

TAILGATE

LOWER TAILGATE

Opening



Push the handle C to the right and

tilt the tailgate D gently.

Closing



Pull the handle B downwards to

guide the tailgate,



release the handle and press the

exterior surface of the tailgate gently

to close it.

Closing



Raise the tailgate D , push it to close

it, then check that it is secured
correctly.

Before  opening  the  tailgate,  ensure
that  no  one  is  within  the  radius  of
opening.
For reasons of safety and correct op-
eration, do not drive with the tailgate
open.
If  the  battery  is  disconnected,  the
tailgate cannot be opened.
Do  not  climb  onto  the  lower  tailgate
and do not subject it to heavy knocks,
it may be damaged.
Always  close  the  lower  tailgate  and
check that it is secured correctly be-
fore closing the main tailgate.
When closing the lower tailgate, en-
sure that no person or object is in the

proximity of the moving parts to avoid

any risk of injury or damage.
Do not open the lower tailgate when

a towbar is ﬁ tted.

Maximum authorised weight on the

lower tailgate when open: 200 kg .

A C C E S S

III

Tailgate release

This enables the tailgate to be unlocked
in the event of a central locking fault.

Fold back the rear seats to gain
access to the tailgate release from
inside the boot.

Remove the plastic cap from the
opening A in the tailgate interior
pillar.

SUNROOF

Complete opening


With the ignition on, push the control

rearwards (in the direction 1 ).

A deﬂ ector is deployed gradually on

opening to prevent unwanted gusts of
air.

Operation

Complete closing


With the ignition on, push the control

forwards (in the direction 2 ).

The deﬂ ector folds down gradually on

closing.

Temporary stop


To stop opening or closing, press

part 3 of the control or push the
control in the opposite direction.

Partial opening


To open , with the ignition on, press

part 3 of the control.

The rear part of the sunroof opens.


To close , with the ignition on, press

part 3 of the control.

The rear part of the sunroof closes.

Move the control B to the right to
unlock and open the tailgate.

The sunroof stops automatically just
before complete opening. Push the
control again for complete opening.

System which improves the ventilation
and light in the passenger compartment.

It is ﬁ tted with a protection system to

prevent pinching and a shutter to help
maintain a comfortable temperature.

A C C E S S

III

Tailgate release

This enables the tailgate to be unlocked
in the event of a central locking fault.

Fold back the rear seats to gain
access to the tailgate release from
inside the boot.

Remove the plastic cap from the
opening A in the tailgate interior
pillar.

SUNROOF

Complete opening


With the ignition on, push the control

rearwards (in the direction 1 ).

A deﬂ ector is deployed gradually on

opening to prevent unwanted gusts of
air.

Operation

Complete closing


With the ignition on, push the control

forwards (in the direction 2 ).

The deﬂ ector folds down gradually on

closing.

Temporary stop


To stop opening or closing, press

part 3 of the control or push the
control in the opposite direction.

Partial opening


To open , with the ignition on, press

part 3 of the control.

The rear part of the sunroof opens.


To close , with the ignition on, press

part 3 of the control.

The rear part of the sunroof closes.

Move the control B to the right to
unlock and open the tailgate.

The sunroof stops automatically just
before complete opening. Push the
control again for complete opening.

System which improves the ventilation
and light in the passenger compartment.

It is ﬁ tted with a protection system to

prevent pinching and a shutter to help
maintain a comfortable temperature.

A C C E S S

III

Safety auto-reverse and
reinitialisation
If the roof meets an obstacle while it is
closing, it stops and opens again.

Always remove the key from
the ignition when leaving the
vehicle, even for a short time.

If  the  roof  meets  an  obstacle  dur-
ing  operation,  you  must  reverse  the
movement  of  the  roof.  To  do  this,
press the control concerned.
When  the  driver  operates  the  roof
control, he must ensure that no one
is  preventing  the  roof  from  closing
correctly.
The driver must ensure that passen-
gers use the sunroof correctly.
Be aware of children when operating
the roof.

In the event of unwanted opening of

the roof on closing (for example, in

the presence of ice) and immediately
after the roof has stopped, or after
the safety auto-reverse has been

triggered ﬁ ve times in succession:


press part 3 of the control several

times to partially open the roof,



when the roof partially opens,

continue to press for more than
3 seconds .



open and close the sunroof com-

pletely.

  The    safety    auto-reverse    function
is  not    operational  during    t  hese
operations.

SHUTTER

The shutter is manual, slide it.
It is stored automatically when the roof
is opened.

Check  that  the  sunroof  is
not  open   in  tilt  mode   before
closing the shutter.
The  shutter  cannot  be  closed

when the sunroof is open in sliding
mode .

Citroen C-Crosser Dag (2008 year). Instruction - part 5
