Citroen C-Crosser Dag (2008 year). Instruction - part 3

I N S T R U M E N T S a n d C O N T R O L S

Restoring the manufacturer’s
parameters (REINITIALISE)

You can restore all of the manufacturer’s
settings for all of the functions.

On the menus screen:


press the INFO button to select

“REINITIALISE” (located on menu
2/2) .



press and hold the INFO button for

at least 5 seconds .

An audible signal is heard and all of the
manufacturer’s settings are restored for
all of the functions.

The manufacturer’s settings are:

LIGHTING RHEOSTAT

With the lights on or off, press the button
to change the intensity of the lighting of
the instruments and controls in “day” or
“night” mode.

When the lighting reaches the maximum

setting,  press  again  to  change  to  the
minimum setting.
When the lighting reaches the required
intensity, release the button.
The  setting  is  saved  when  the  ignition
switch is turned to OFF.

An audible signal is heard and the
intensity of the lighting increases
each time the button is pressed.

System for manual adjustment of the
brightness of the instruments and

controls in relation to the exterior

brightness.

Functions

Manufacturer’s

setting

Reinitialisation
of the average
consumption and
average speed

1 (automatic)

Fuel consumption
units

L/100 km

Temperature
display unit

°C

Display language

ENGLISH

INFO button
sound

ON (activated)

Displaying of
the “BREAK
ADVISED”
message

OFF (deactivated)

MONOCHROME DISPLAY

This provides the following information:
-

the time,

the audio equipment displays (refer
to the “Audio and Telematics” sec-
tion).

Setting the time

The digital clock can be set in automatic
mode or in manual mode .

Selecting the Setting

Select the automatic mode or the
manual mode as follows:



Press button A “PWR” to switch on

the audio system.



Access the setting mode by press-

ing button B

“TUNE” for approxi-

mately 2 seconds.



Press button B “TUNE” several

times  to  scroll  through  the  various
menus  and  select  the   CT  menu
(clock time).

The order of the menus is the
following: AF / CT / REG / TP-S / PTY
display language / SCV / PHONE /
Functions setting mode OFF.

  Automatic mode
This mode permits automatic setting of
the local time using the signal from the
RDS stations.
The  symbol   “CT”   appears  on  the
display.

  Manual mode
This  mode  permits  manual  setting  of
the  time  using  the  audio  equipment
buttons.
It can also be used when the “Automatic
mode” displays an inaccurate time, when
the local RDS stations are broadcasting
from a different time zone.

I N S T R U M E N T S a n d C O N T R O L S

Set the time using the buttons as
indicated below:


with the ignition on or in the ACC

(Accessories) position, press and
hold the CLOCK button until the

time display ﬂ ashes.

 Press the appropriate button to set

the time:

Button H: setting of the hour
The hours digits scroll when you press
this button.
  Button M:  setting of the minutes
The  minutes  digits  scroll  when  you
press this button.
  Button :00:  resetting of the minutes to
zero.
   -

from 1 to 29 min : rounded down to
the previous hour,

from 30 to 59 min: rounded up to

the next hour.

Manual mode

Automatic mode

In this mode, setting is automatic using
the signal from the RDS radio stations.



After setting the time, press the

DISP button; the time display stops

ﬂ ashing.

The digital clock does not display
seconds.
When the “minutes” display is set or
reset to zero, the clock starts at the
zero second of the minute selected.
The time setting is lost if the battery
is disconnected.



Turn button B “TUNE” to the left or

to the right to select “CT ON” (auto-
matic mode) or “CT OFF” (manual
mode).



After selecting the mode, you can

exit the “Functions setting mode”

menu by pressing button B “TUNE”

for approximately 2 seconds.

If no action is carried out within

10 seconds, the system will exit

the “functions setting mode” menu
automatically.

I N S T R U M E N T S a n d C O N T R O L S

COLOUR DISPLAY

This permits displaying of the following
main menus:

On  the  control  panel,  press  button   B
(SET)  to access the  “Settings”  screen
and select:
   -

“Display Deactivated” to switch

off the display,

“Sound control” for the sound dis-

tribution or volume, the type of mu-

sic and the sound ﬁ eld (surround),

“Picture control” to set the colour,

the intensity, the brightness, the
contrast and the level of black,

“System” to change the time zone,

the language, the units and other
settings,

“Wide Screen” to change the size

of the DVD picture to 4/3 format,
wide screen mode, centred wide
screen mode or enlargement,

“Equipment” to set certain equip-

ment offered in the vehicle,

“Col Contrast” to select the con-

trast of the display in relation to the

exterior light (Day, Night or Auto),

“TP standby” to activate or deacti-

vate the trafﬁ c information.

“Audio-video” menu

“Navigation-guidance” menu

On  the  control  panel,  press  button   A
(MODE)   to  access  the   “AV  mode”
screen and select:
   -

the radio (FM, MW, LW),

the CD (audio, MP3 or WMA),

the Music Server,

the DVD,

- the Auxiliary (Rear Display).

“Settings” menu

On  the  control  panel,  press  button   C
(MENU)  to access the  “Menu”  screen
and select:
   -     “Address/Junction”   to  search  for

a location using the address or the
name of the street,

- “POI name” to search for a location

using the name of a point of interest
(POI),

- “Advanced search” to search for a

location using an advanced search
based on a POI,

- “20 Previous” to search for a

location using one of the 20 previous
destinations,

- “Address book” to search for a

location using a stored address,

- “Return to the initial screen” to

enter a return home,

- “Navigation

settings”

set

functions linked with the navigation,

- “Navigation

tools”

access

the basic information or a pre-set
demonstration.

The  “CD”  and  “DVD”  buttons  are
active  if  you  insert  a  CD  or  DVD  in
the player.

I N S T R U M E N T S a n d C O N T R O L S

Setting the time

The digital clock is set  automatically .
This  mode  enables  the  system  to  set
the  local  time  automatically  using  the
signal from the RDS stations.
   

On the control panel, press button

A (SET) to access the “Settings”
menu.



On the touch screen, press button

B to access the “System” menu.

The

system

settings

screen

displayed.

“Information” menu

On  the  control  panel,  press  button   D
(INFO)  to access the  “Info”  screen and
consult:
   -     “Support

info”

display

the

software and data versions,

- “Vehicle position” to display the

GPS location of the vehicle,

- “Calendar” to make a note of events,

birthdays, etc.,

- “Journey” to display the average

speed,

the

consumption,

the

distances and the duration of driving,

- “Environment”

display

the

altitude, the atmospheric pressure,

the exterior temperature (the ice

symbol is displayed if there is a risk
of ice),

- “Air

conditioning”

display

the information relating to the air
conditioning,

- “Mobile telephone” to enter a

number, delete a character, make or
receive a call.

“Map” menu

On  the  control  panel,  press  button   E
(NAVI)   to  access  the   “Routes  Menu”
screen and select:
   -

“Detour” to make a detour through

a speciﬁ ed region,

“Route” to change the route,

“Display a route” to display a route
in different ways,

“Delete a route” to delete a route,

“Local POI” to search for the POIs
in the surrounding area.

I N S T R U M E N T S a n d C O N T R O L S

1. RDS Auto Correction:

Activate / deactivate the automatic
adjustment.

2. GMT / GMT+1 / GMT+2

Select the time zone.

3. Summer Time:

Activate / deactivate summer time.



Press button D

to conﬁ rm and re-

turn to the previous menu.



Press button C to access the “Time”

menu .

Once this menu has been selected, you
can access the following functions:

It  is  essential  to  deactivate  the
automatic  adjustment  (RDS  Auto
Correction)  in  order  to  be  able  to
change  the  time  zone  and  summer
time.
On  each  screen,  you  can  return  to
the  previous  screen  by  pressing
button  D “Return” .

Select  the   “AV  Mode”   menu  by
pressing  the  “MODE”  button  on  the
control panel.
From  the   “AV  MODE”   menu  on  the
touch screen, press:
   -    the   “RearDisplay”   button  to  access

the Auxiliary menu,

- the “Video parameters” button to

set the display format, the brightness,
the contrast and the colours.

VIDEO MENU

You can connect video equipment
(camcorder, digital camera,...) to the
three video sockets located on the back
of the front central armrest.

Video sources can only be displayed
when stationary.

Press the “Back”

button to exit video

mode.

C O M F O R T

For even air distribution, take care not

to obstruct the exterior air intake grille

located at the bottom of the windscreen,
the vents, the air outlets under the front

seats and the air extractor located be-

hind the ﬂ aps in the boot.

The water formed by the air conditioning
condensation is discharged via an open-
ing provided for this purpose. Therefore,
a puddle of water may form underneath
the vehicle when stationary.
If the system does not produce cold air,
do not use it and have it checked by a
CITROËN dealer.

THE AIR CONDITIONING

Do  not  cover  the  temperature  and  hu-
midity  sensor   2   and  the  sunshine  sen-
sor  7 .
They  are  required  for  regulation  of  the
air conditioning.

Advice on operation

In hot weather, in order to obtain in-
tense  ventilation,  it  is  advisable  to
use vents  1  and  4  only.
If, when the vehicle has been parked
in the sun for a long time, the interior
temperature  remains  very  high,  do
not hesitate to ventilate the passen-
ger compartment for a few minutes.

Switch off the air conditioning when
the climatic conditions permit.

Use of the automatic regulation of the
air conditioning is recommended. It per-
mits automatic and optimised control of

all of the following functions: air ﬂ ow,

passenger compartment temperature
and air distribution, by means of vari-

ous sensors (exterior temperature, in-

terior temperature, sunshine), so pre-
venting the need for you to change your
reference settings other than the value
displayed.

In certain cases of particularly arduous

use (towing the maximum load on a

steep gradient in hot weather), cutting
off the air conditioning permits recovery
of the engine power and therefore im-
provement of the towing capacity.

Close the windows to beneﬁ t from the

full effectiveness of the air condition-
ing.

Ensure that the passenger compart-

ment ﬁ lter is in good condition. Have

the ﬁ lter elements replaced periodically.

If you drive in a dusty environment, re-
place it twice as often.

The air conditioning system does not
contain chlorine and is not harmful to
the ozone layer.
Operate the air conditioning system for
5 to 10 minutes, once or twice a month,
to keep it in perfect working order.

   1.   Centre panel vents.
  2.   Temperature sensor.
  3.   Air outlet to passenger footwells.
  4.   Side vents.
  5.    Front windows de-icing or demisting

vents.

6. Windscreen de-icing or demisting

vents.

7. Sunshine sensor.

C O M F O R T

C O M F O R T

AUTOMATIC AIR
CONDITIONING

Automatic operation



Set the temperature control dial 1 to

the temperature required.



Place the air ﬂ ow control dial 2 in

the “AUTO” position.



Place the air distribution adjustment

dial 3 in the “AUTO” position.

When the engine is cold, to avoid an

excessive distribution of cold air, the

ventilation will reach its optimum lev-
el gradually.
On  entering  the  vehicle,  the  interior
temperature may be much colder (or
warmer)  than  the  comfort  tempera-
ture. There is no need to change the
temperature  displayed  in  order  to
reach the comfort required rapidly.
The  automatic  regulation  of  the  air

conditioning will operate at maxi-

mum performance to eliminate the
temperature difference as quickly as
possible.

1. Temperature adjustment
2.

Air ﬂ ow adjustment

3. Air distribution adjustment
4.

Intake of exterior air / Recirculation

of interior air

5. Air conditioning On / Off
6. Rear screen de-icing

In automatic mode:


when the temperature is set to max-

imum (Rapid heating), the intake of

exterior air is activated and the air

conditioning stops.



when the temperature is set to mini-

mum (Rapid cooling), the air recir-
culation is activated and the air con-
ditioning operates.

In accordance with the level of comfort
selected, the system controls the air

distribution, the ﬂ ow, the temperature

and the air intake to guarantee comfort

and a sufﬁ cient circulation of air in the

passenger compartment. No further ac-
tion on your part is required.

C O M F O R T

  Manual operation
It  is  possible  to  set  one  or  more  func-
tions  manually  while  leaving  the  other
functions in automatic mode.

Switching  to  manual  mode  may  result
in  discomfort  (temperature,  humidity,
odour,  condensation)  and  does  not  of-
fer optimum comfort.

Temperature adjustment (1)

Air ﬂ ow adjustment (2)



Turn the dial to the
right to increase the

air ﬂ ow or to the left to

decrease it.



Turn  the  temperature
control dial to the right
to  increase  the  tem-
perature  and  to  the
left to decrease it.



Place  the  dial  in  the
position  required  to
direct the air towards:

To avoid condensation and deterio-
ration of the quality of the air in the
passenger compartment, ensure that

a sufﬁ cient ﬂ ow of air is maintained.

the central and side vents,

the central and side vents and
the footwells,

the footwells,

the windscreen, the side win-
dows and the footwells,

the windscreen and the side
windows.

The air distribution can be adapted by
placing the adjustment dial in the inter-
mediate positions.

Air distribution adjustment (3)

C O M F O R T

Air conditioning On / Off (5)



Press button 5 to activate the air
conditioning.

The indicator light comes on.

Intake of exterior air /
Recirculation of interior
air (4)

This function insulates the passenger

compartment from exterior odours and

smoke.


Press button 4 to select the air in-
take mode.

When the indicator light on button 4 is

off, the exterior air intake function is ac-

tivated.
When the indicator light on button 4 is

on, the intake of exterior air is deacti-

vated and the system is in air recircula-
tion mode.

Do not drive for long periods in interior

air recirculation mode, except in truly

exceptional atmospheric conditions.

  Personalisation of the Exterior air
intake / Interior air recirculation
function
This  function  is  controlled  automati-
cally.  However,  you  can  deactivate  its
automatic control if you wish to change
the air intake mode at any time.

  Personalisation of the Air
Conditioning On / Off function
This  function  is  controlled  automati-
cally.  However,  you  can  deactivate  its
automatic control if you wish to activate
or deactivate the air conditioning at any
time.

The settings are retained, even after
switching off the ignition.

Changing the status
Press the Air intake / Interior air recircu-
lation button for at least 10 seconds.
When the status changes from active to
inactive, three bleeps are heard and the

indicator light ﬂ ashes three times.
When the status changes from inactive
to active, two bleeps are heard and the

indicator light ﬂ ashes three times.

Automatic control active
If the air distribution adjustment dial and

the air ﬂ ow adjustment dial are placed

in the “AUTO” position, the Air intake /
Interior air recirculation function is also
controlled automatically.

Automatic control inactive
Even if the air distribution adjustment

dial and the air ﬂ ow adjustment dial are

placed in the “AUTO” position, the Air
intake / Interior air recirculation function
is no longer controlled automatically.

Changing the status
Press the Air Conditioning On / Off but-
ton for at least 10 seconds.
When the status changes from active to
inactive, three bleeps are heard and the

indicator light ﬂ ashes three times.
When the status changes from inactive
to active, two bleeps are heard and the

indicator light ﬂ ashes three times.

Automatic control active
If the air distribution adjustment dial and

the air ﬂ ow adjustment dial are placed

in the “AUTO” position, or if the temper-
ature control dial is set to the minimum
temperature, the air conditioning sys-
tem is controlled automatically.

Automatic control inactive
The air conditioning system is no longer
controlled automatically.

C O M F O R T

Windows and windscreen de-icing

De-icing
1. Press button A

to select “exterior air

intake”. The indicator light on this
button is switched off.

2. Place the air distribution dial in the

“windscreen, side windows and foot-
wells” position.

Select the air ﬂ ow required.

4. Select the temperature required.
5. Press the “air conditioning on / off”

button   B   to  activate  the  air  condi-
tioning.  The  indicator  light  on  this
button comes on.

Rapid de-icing
1. Place the air distribution dial in the

“windscreen and side windows”
position.

Select the maximum air ﬂ ow.

Select the maximum temperature.

Rear screen de-icing (6)

With the engine running, press but-
ton 6 to activate the de-icing of the rear

screen and exterior mirrors.
The indicator light on the button comes
on while the de-icing is in operation.
The de-icing switches off automatically

to prevent an excessive consumption of

current.
The operation of the de-icing can be
stopped before it is switched off auto-
matically by pressing the button again.

It  is  advisable  to  switch  off  the  rear
screen  de-icing  as  soon  as  possible
as lower current consumption reduc-
es the fuel consumption.

C O M F O R T

FRONT SEATS

Manual mode

  Forwards-backwards adjustment
Raise the control bar and slide the seat
forwards or backwards.
When  your  seat  is  at  the  correct  dis-
tance, move it forwards and backwards
slightly without using the control bar to
check that it is secured correctly.

  Driver’s seat cushion height and
angle adjustment
Pull  and/or  push  the  control  several
times to adjust the height of the seat.

  Seat back angle adjustment
Pull  the  control  upwards  to  adjust  the
seat back.
When  the  seat  back  is  at  the  correct
angle, release the control.

To  prevent  the  seat  back  from
moving  forward  sharply  and
knocking  you,  press  on  it  with
your  back  or  push  it  with  your
hand while operating the lever.

  Seat consisting of a seat cushion, seat
back  and  head  restraint  which  can  all
be  adjusted  to  your  optimum  driving
and comfort position.

C O M F O R T

Electric mode (driver’s seat only)

  Forwards-backwards adjustment
Push the control forwards or rearwards
to  move  the  seat  to  the  position
required.

  Driver’s seat cushion height and
angle adjustment
Pull  or  push  the  front  of  the  control
to  raise  or  lower  the  front  of  the  seat
cushion.
Pull  or  push  the  rear  of  the  control
to  raise  or  lower  the  rear  of  the  seat
cushion.
Pull or push the entire control to raise or
lower the entire seat cushion.

Seat back angle adjustment
Tilt the control forwards or rearwards to
straighten or tilt the seat back.

Seat consisting of a seat cushion, seat
back and head restraint which can all
be adjusted to your optimum driving
and comfort position.

To avoid discharging the battery, use
the electric mode with the engine
running.

C O M F O R T

Head restraint height adjustment

Front armrest

Heated seats adjustment

The  adjustment  is  correct  when  the
top  of  the  head  restraint  is  aligned
with the top of the head of the seated
person.

Never drive with the removed
head restraints in the vehicle
as

they

could

thrown

around the vehicle on sharp braking.
They  must  be  in  place  and  adjusted
correctly.
After  installing  the  head  restraint,
check  that  the  height  adjustment
button is locked correctly.

You can move the console housing
cover in order to use it as an armrest.

With the engine running , tilt the button
to the position required.
The temperature of the seat is regulat-
ed automatically.
There are two setting positions:
-

“HI”: High heating

“LO”: Low heating

When the button is in the intermediate
position, the heating is switched off.
The indicator lights A comes on when
the system is activated.

To  raise  the  head  restraint,  pull  it
upwards.
To  lower  the  head  restraint,  push  it
downwards pressing the height adjust-
ment button at the same time.
To remove the head restraint, bring it to
the  uppermost  position  then  remove  it
pressing  the  height  adjustment  button
at the same time.
To  reﬁ t  the  head  restraint,  engage  the

stems of the head restraint in the holes
pressing the height adjustment button
at the same time.

C O M F O R T

REAR SEATS (ROW 2)

Seat back angle adjustment

Pull the control and adjust.
When  the  seat  back  is  at  the  correct
angle, release the control.
Sit in the centre of the rear bench seat
to  check  that  the  two  seats  are  at  the
same  level  and  that  the  angle  of  their
seat backs is the same.

Forwards-backwards adjustment

Pull the control towards the outside and
adjust.
When your seat is at the correct
distance, release the control.
To ensure that the seat is secured
correctly,

move

forwards

and

backwards slightly without using the
control.

When manoeuvring the seats,
ensure that no person or ob-
ject is in the vicinity of the mov-

ing parts to avoid any risk of injury or
damage.
To  prevent  the  seat  back  from  mov-
ing  forwards  sharply  and  knocking
you,  press  on  it  with  your  back  or
push it with your hand while operat-
ing the lever.

The rear seats can be folded in two
parts (1/3 - 2/3).

Content .. 1 2 3 4 ..
