Fig. 10: View Of Washer Solvent Container & Screws
Courtesy of GENERAL MOTORS CORP.
1. Transfer washer pumps and level indicator to the new washer solvent container.
Fig. 11: View Of Wheelhouse & Windshield Washer Solvent Container Assembly
Courtesy of GENERAL MOTORS CORP.
2. Install the windshield washer container assembly.
3. Install the upper windshield washer container bolt to the auxiliary battery tray, if equipped.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
4. Install the upper windshield washer solvent container bolts.
Tighten: Tighten the bolts to 9 N.m (80 lb in).
5. Install the auxiliary battery tray, if equipped. Refer to Battery Tray Replacement .
6. Install the windshield washer solvent cap.
7. Connect the electrical connectors.
Fig. 12: Locating Washer Pump Hoses
Courtesy of GENERAL MOTORS CORP.
NOTE:
Refer to Fastener Notice .
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
8. Connect the washer pump hoses (1, 2). Refer to Windshield Washer Hose Replacement.
9. Install the lower outer washer container bolt.
10. Install the left front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement -
Left Side (Chevrolet) or Front Wheelhouse Liner Replacement - Left Side (GMC) .
11. Install the left front wheel assembly. Refer to Tire and Wheel Removal and Installation .
12. Fill the washer solvent container with windshield solvent. Refer to Fluid and Lubricant
Recommendations .
WASHER PUMP REPLACEMENT (SILVERADO)
Fig. 13: View Of Windshield Washer Pump (Silverado)
Courtesy of GENERAL MOTORS CORP.
Callout
Component Name
Preliminary Procedures
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
WINDSHIELD WASHER SOLVENT LEVEL SWITCH REPLACEMENT (GMC)
Fig. 14: View Of Windshield Washer Solvent Level Switch (GMC)
Courtesy of GENERAL MOTORS CORP.
1. Remove the windshield washer system container. Refer to Windshield Washer
Solvent Container Replacement.
2. Place the washer container on a bench top and secure.
3. Using two flat-bladed tools, pry gently upward on the pump in order to disengage the
pump from the washer container grommet.
4. Discard the grommet.
1
Windshield Washer Pump
Tip: Use full strength windshield washer solvent for a lubricant on the pump
spout in order to ease the installation of the new washer pump into the new
grommet.
Callout
Component Name
Preliminary Procedures
1. Remove the windshield washer container. Refer to Windshield Washer Solvent
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
