Chevrolet Silverado / GMC Sierra. Manual - part 3012
WINDSHIELD WASHER SOLVENT CONTAINER REPLACEMENT
Removal Procedure
Fig. 7: View Of Washer Solvent Container & Screws
1
Windshield Washer Hose Retainer Clip
2
Windshield Washer Nozzle Hose
Tip: Disconnect the hose at the left rear fender flange.
3
Windshield Washer Pump Hose Assembly
Tip: Route the new hose in the same location as the old hose was removed
from.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Courtesy of GENERAL MOTORS CORP.
1. Raise and support the vehicle. Refer to Lifting and Jacking the Vehicle .
2. Remove the left front wheel assembly. Refer to Tire and Wheel Removal and
Installation .
3. Remove the left front wheelhouse liner. Refer to Front Wheelhouse Liner Replacement -
Left Side (Chevrolet) or Front Wheelhouse Liner Replacement - Left Side (GMC) .
4. Remove the lower outer bolt (1) from the washer container prior to lowering the vehicle.
Fig. 8: Locating Washer Pump Hoses
Courtesy of GENERAL MOTORS CORP.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
5. Disconnect the washer pump hoses (1, 2) from the left side fender flange. Refer to
Windshield Washer Hose Replacement.
6. Drain the windshield washer solvent into a suitable container.
7. Disconnect the electrical connectors.
8. Lower the vehicle in order to access the hood latch.
9. Open the hood.
10. Remove the windshield washer solvent cap.
11. Remove the auxiliary battery tray, if equipped. Refer to Battery Tray Replacement .
Fig. 9: View Of Wheelhouse & Windshield Washer Solvent Container Assembly
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
Courtesy of GENERAL MOTORS CORP.
12. Remove the upper windshield washer container bolt from under the auxiliary battery tray, if
equipped.
13. Remove the upper windshield washer solvent container bolts.
14. Remove the windshield washer solvent container assembly (2).
Installation Procedure
IMPORTANT: Remove the washer container from the underside of the
vehicle through the wheelhouse opening.
2008 Chevrolet Silverado 1500
2008 ACCESSORIES & EQUIPMENT Wipers and Washers - Cab & Chassis Sierra, Cab & Chassis Silverado, Sierra &
Silverado
