Air Condition System

65

Once cooling capacity and volume of air

decrease, please shut down air

conditioning system and let professional

technician to check it.

Rear window defroster/ rearview

mirror heating

The switch button for the rear window

defroser is located at the center console of

instrument panel.

To defrost the rear window, switch on the

rear window defroster,

The rear window defroster will work,

when iginition key is turned on. To

open/close heating system, please switch

on the button. Once the heating system is

powered on, the indicator lights up and

indicates that it is working.

Notice

Once the rear window’s fog disappears,

please shut down rear window defroster

to save energy and decrease fuel

consumption.

The rear window defrosting process stops

after ten minutes or when ignition key is

turned off. If you want to stop defrosting,

please press “ windshield defroster”

button.

The rear mirror defroster and rear window

defroster start at the same time.

Light Control

66

Lighting Control

Please comply with the traffic regulations,

when you use the following lighting

equipments.

Headlamps Switch

OFF - switch off outside lights

First Gear

- switch on parking

lamp/position lamp, instrument, switch

and other part lamp/license lamp.

Second Gear

 - switch on

headlight (low beam/high beam).

Notice:

Headlamps are only able to work after the

ignition switch is on. The headlamps will

be winked automatically when engine is

starting or after ignition switch is off.

Headlamps dimmer

Moving the handle to instrument panel and

cross impacted point to switch to high

beam when the lights switch is on. At the

same time, the indicator lamp of high

beam will be also turned on the instrument

panel. Moving the handle to original

position (steering wheel direction) return

to low beam.

Headlamps Flashing

Moving handle to impacted point (steering

wheel direction) and release it, when you

need to flash headlamps on the way.

Repeating this again, the headlamps are

able to flash continuously.

Light Control

67

Front/rear

fog

lamp

switch

The front/rear fog lamp switch are placed

on the central console of instrument panel

(Under the audio control panel).

When headlight switch is on the position

of first gear, pressing the front fog lamp

switch is able to switch on front fog lamp,

but not able to switch on rear fog lamp.

When headlight switch is on the position

of second gear, pressing front and rear fog

lamp switch is able to switch on front and

rear fog lamp. And also can press rear fog

lamp switch to switch on rear fog lamp

only.

Please use the fog lamp correctly,

according to the traffic

regulations

The indicator lamp of front fog lamp

switch will be switched on ,when the front

fog lamp is switched on.

The front fog lamp only can be used under

the circumstances of   fog, snow, rain and

other limited visibility.

The indicator lamp of rear fog lamp switch

will be switched on ,when the rear fog

lamp is switch on.

The rear fog lamp only can be used on

poor visibility due to its discomfort glare.

Turn signal lamp

The turn signal lamp only can work after

the ignition switch is on.

Left-turn signal lamp – move the handle

down.

Rear fog lamp
switch

Front fog lamp
switch

Light Control

68

Right-turn signal lamp – move the handle

up.

The turn signal indicator lamp will twinkle

when the turn signal lamp is switched on.

Changing lane
signal lamp

When move handle up/down to impacted

point ,the relevant turn light will flash. At

the same time, the turn signal lamp will

also flash on the instrument panel.

Instrument lighting
dimmer

The intensity of instrument lighting could

be adjusted by using dimmer, during the

operating of outside lights.

Front roof light

Press left switch: left light remains

lighting. Press again for switch off.

Press right switch: right light remains

lighting. Press again for switch off.

Sunglass case

Left
light

Right
light

switch

switch
