Light Control

69

Switch connects with
gating system
automatically. The cabin
light will be on when the
door is opened (the
switch is placed on gating
position). The cabin light
remains lighting for 8
seconds when the door is
closed (convenient for
passengers Rear
roof light

OFF position: light switch off.

ON position: light remains on.

Middle (gating) position: the cabin light is

switched on with the door opened. The

cabin light remains on for 8 seconds when

the door is closed (convenient for

passenger to sit).

Luggage boot lamp

The light is on with boot hood opened

(this light without control by

ignition switch). Please pay attention to

close the boot hood when stopping.

The light is also to be OFF status (not to

be switched on with boot hood opened)

with pressing the trigger switch to locked

position. You must release the trigger

switch if you want to turn the light on.

Lighting of
sun visor/vanity mirror

Opening the cover of vanity mirror to

switch on the light of vanity mirror.

Front doorsill light and
key-hole light

The key-hole light and front doorsill light

will be on with front door open.

The front doorsill light is placed in the

interior decoration panels of both front

doors. If open the doors, doorsill light will

be switched on to lighted foot region and

Light Control

70

direct driver whatever ignition switch is on

or not. This light will be switched off

when the door is closed.

Key-hole light is installed around the

ignition key-hole. The light will be

switched on to help the driver insert

ignition key, if any front door is opened.

This light will be switched off when the

key is turned to “ON” position.

Hazard warning flasher
switch

Only use it in an emergency, to warn the

following vehicles. Press the switch down

to switch on/off this system. This hazard

warning flasher is also illuminated even

the ignition switch is switched off.

The button indicator light flashes, when

warning flasher is switched on. The turn

signal lamp will also flash on the

instrument panel, when the ignition switch

is on.

Operation and Adjustment of Interior Devices

71

Interior devices operation and adjustment

Operation and Adjustment of Interior Devices

72

Steering

wheel

lock/

ignition switch

Steering wheel lock/ignition switch

includes the following key positions:

LOCK – the ignition is switched off, and

steering wheel is locked.

After removing the key, turn the steering

wheel slightly to the left or right until you

hear the lock engage.

ACC - Steering system unlocked.

Individual electrical equipments and

accessories are available for use. But

ignition switch and primary electrical loop

are not available for use.

If it is not able (or hard) to turn ignition

key to ACC position from LOCK position,

you can move the steering wheel slightly

to help disengage the locking mechanism.

To avoid exhausting the power of storage

battery, ignition switch should be not in

this position for a long time.

ON– To switch on the ignition circuit, all

electrical equipment and accessories are

available for use. And caution lights and

indicator lights are switched on. This is the

correct position of the key for driving. And

it is also the requested position for towing

vehicle.

START - Switch on the motor to start the

engine.

When the key-hole is on this position, the

front headlamps and power-waste

electrical equipments are cut off.

There is prevention of repeat-starts unit in

the ignition switch. Once the engine starts

this unit can prevent the engine

mis-starting and avoid damaging the

engine and its flywheel.

If you fail to start the engine, release the

ignition key to LOCK position and turn

back again before next starting. Let it go

to release the ignition key toON position

after starting.
