Chery A15 Maintenance Manual
Align tapping screw expansion nut hole center, tighten 2 tapping screws with
tightening torque 1.5±0.2N·m. Assemble license light guard board
Align trunk lock barrel with hole location so as to ensure good adaptation of
guard board and body;
Tighten 2 tapping screws, pay attention to adjust the surface difference and
movable part between the said screws and body/movable parts, feel height
difference manually, adjust based on the hand feel while tightening;
Open trunk lid;
Tighten nuts of 2 square fixed bolts;
Properly assemble connecting rod and cover plate of lock barrel (refer to
body description), and lay down trunk lid.
7. Assembling of interior dome lamp
Properly connect harness pin;
Embed ceiling mounting hole according to right position and direction, with
one end properly connected with ceiling first, and then press in dome lamp
manually.
8. Assembling of trunk light
Open trunk lid;
Properly connect harness pin;
Firstly match a wedge-position end with rear speaker cover, and then press in
lamp manually. And lay down trunk lid.
9. Assembling of high mount stop lamp
Press both ends to separate lamp holder and lamp body, pull out wire
connector;
Plug two single-end sockets of wire to male tab of windshield;
Properly assemble lamp body according to slot combination structure, pay
attention to the matching of back trough and anchor pin so as to fix lamp
body to the right position;
Properly plug wire and lamp holder, and fix the lamp holder and lamp body
to the right position.
10. Adjustment of front headlight light beam
Whether the adjustment of front headlight light beam is correct or not influences
running security directly. So dedicated instrument is allowable exclusively for the
adjustment of light beam. When adjusting, pay attention to legal regulations.
11. The following particulars shall be satisfied prior to adjustment:
Auto tire pressure meets the standard;
- 42 - CHERY AUTOMOBILE CO., LTD
