Acura ILX (2018 year). Manual - part 30

469

uu

Checking and Maintaining Tires

u

Tire Rotation

Main

tenan

ce

Tire Rotation

Rotating tires according to the maintenance messages on the multi-information
display helps to distribute wear more evenly and increase tire life.

■

Tires without rotation marks

Rotate the tires as shown here.

■

Tires with rotation marks

Rotate the tires as shown here.

1

Tire Rotation

Tires with directional tread patterns should only be
rotated front to back (not from one side to the other).
Directional tires should be mounted with the rotation
indication mark facing forward, as shown below.

Front

Direction Mark

Front

Front

18 ACURA ILX-31TX66500.book  469 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

470

uu

Checking and Maintaining Tires

u

Winter Tires

Main

tenan

ce

Winter Tires

If driving on snowy or frozen roads, mount all season marked M+S tires, snow tires,
or tire chains; reduce speed; and maintain sufficient distance between vehicles when
driving.

Be particularly careful when operating the steering wheel or brakes to prevent
skidding.

Use tire chains, snow tires, or all season tires when necessary or according to the law.

When mounting, refer to the following points.

For winter tires:
• Select the size and load ranges that are the same as the original tires.
• Mount the tires to all four wheels.
For tire chains:
• Install them on the front tires only.
• Because your vehicle has limited tire clearance, we strongly recommend using the

chains listed below:

• Follow the chain manufacturer's instruction when installing. Mount them as

tightly as you can.

• Check that the chains do not touch the brake lines or suspension.
• Drive slowly.

Cable-type: SCC Radial Chain SC1032

Cable-type: SCC Radial Chain SC1036

1

Winter Tires

NOTICE

Traction devices that are the wrong size or improperly
installed can damage your vehicle's brake lines,
suspension, body, and wheels. Stop driving if they are
hitting any part of the vehicle.

When tire chains are mounted, follow the chain
manufacturer's instructions regarding vehicle
operational limits.

If your vehicle is equipped with summer tires, be
aware that these tires are not designed for winter
driving conditions. For more information, contact a
dealer.

3

WARNING

Using the wrong chains, or not properly
installing chains, can damage the brake
lines and cause a crash in which you can be
seriously injured or killed.

Follow all instructions in this owner's
manual regarding the selection and use of
tire chains.

Models with P215/45R17 87V tires

Models with 225/40R18 92V tires

18 ACURA ILX-31TX66500.book  470 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

471

Main

tenan

ce

Battery

Checking the Battery

The condition of the battery is monitored by a
sensor located on the negative terminal of the
battery. If there is a problem with this sensor,
the multi-information display will display a
warning message. If this happens, have you
vehicle inspected by a dealer.

Check the battery terminals for corrosion
monthly.

If your vehicle’s battery is disconnected or goes dead:
• The audio system is disabled.

2 Reactivating the audio system P. 173

• The clock resets.

2 Clock P. 110

• The navigation system

*

 is disabled.

2 Refer to the navigation system manual

Charging the Battery

Disconnect both battery cables to prevent damaging your vehicle's electrical system.
Always disconnect the negative (–) cable first, and reconnect it last.

1

Battery

WARNING: Battery post, terminals,
and related accessories contain lead
and lead compounds.
Wash your hands after handling.

When you find corrosion, clean the battery terminals
by applying a baking powder and water solution.
Clean the terminals with a damp towel. Cloth/towel
dry the battery. Coat the terminals with grease to
help prevent future corrosion.

When replacing the battery, the replacement must be
of the same specifications.
Consult a dealer for more information.

3

WARNING

The battery gives off explosive hydrogen
gas during normal operation.

A spark or flame can cause the battery to
explode with enough force to kill or
seriously hurt you.

When conducting any battery
maintenance, wear protective clothing and
a face shield, or have a skilled technician do
it.

Battery

* Not available on all models

18 ACURA ILX-31TX66500.book  471 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

472

Main

tenan

ce

Remote Transmitter Care

Replacing the Button Battery

If the indicator does not come on when the button is pressed, replace the battery.

1. Remove the built-in key.

2. Remove the upper half of the cover by

carefully prying on the edge with a coin.

u

Remove carefully to avoid losing the
buttons.

u

Wrap a coin with a cloth to prevent
scratching the keyless access remote.

3. Make sure to replace the battery with the

correct polarity.

1

Replacing the Button Battery

NOTICE

An improperly disposed of battery can damage the
environment. Always confirm local regulations for
battery disposal.

Replacement batteries are commercially available or
at a dealer.

3

WARNING

CHEMICAL BURN HAZARD
The battery that powers the remote
transmitter can cause severe internal burns
and can even lead to death if swallowed.
Keep new and used batteries away from
children.
If you suspect that a child has swallowed
the battery, seek medical attention
immediately.

Models without remote control engine start system

Battery type: CR2032

Battery

18 ACURA ILX-31TX66500.book  472 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

473

uu

Remote Transmitter Care

u

Replacing the Button Battery

Main

tenan

ce

If the indicator does not come on when the button is pressed, replace the battery.

1. Remove the built-in key.

u

As a convenience, lightly place masking
tape over the remote buttons to hold
them in place.

2. Remove the upper half of the cover by

carefully prying on the edge with a coin.

u

Wrap a coin with a cloth to prevent
scratching the transmitter.

3. Press down on the center of the assembly

and remove the battery.

u

When removing the button battery, be
careful not to touch parts around it.

4. Make sure to replace the battery with the

correct polarity.

1

Replacing the Button Battery

NOTICE

The Remote transmitter is equipped with two
batteries: A standard replaceable CR2032 coin
button battery and an integral non-replaceable
rechargeable battery. To prevent permanent damage
to the rechargeable battery, replace the CR2032
battery every three to four years.

Models with remote control engine start system

Models with remote control engine start system

Battery type: CR2032

Battery

18 ACURA ILX-31TX66500.book  473 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

474

Main

tenan

ce

Climate Control System Maintenance

Dust and Pollen Filter

The climate control system is equipped with a dust and pollen filter that collects
pollen, dust, and other debris in the air. The Maintenance Minder

TM

 messages will let

you know when to replace the filter.

We recommend that you replace the dust and pollen filter sooner when using your
vehicle in areas with high concentrations of dust.

1

Dust and Pollen Filter

If the airflow from the climate control system
deteriorates noticeably, and the windows fog up
easily, the filter may need to be replaced. Please
contact a dealer for replacement.

18 ACURA ILX-31TX66500.book  474 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

475

Continued

Main

tenan

ce

Cleaning

Interior Care

Use a damp cloth with a mixture of mild detergent and warm water to remove dirt.
Use a clean cloth to remove detergent residue.

Use a soft brush with a mixture of mild soap and warm water to clean the seat belts.
Let the belts air dry. Wipe the openings of the seat belt anchors using a clean cloth.

■

Cleaning Seat Belts

1

Interior Care

Do not spill liquids inside the vehicle. Electrical
devices and systems may malfunction if liquids are
splashed on them.

Do not use silicone based sprays on electrical devices
such as audio devices and switches. Doing so may
cause the items to malfunction or cause a fire inside
the vehicle.
If a silicone based spray is inadvertently used on
electrical devices, consult a dealer.

Depending on their composition, chemicals and
liquid aromatics may cause discoloration, wrinkles,
and cracking to resin-based parts and textiles.
Do not use alkali solvents or organic solvents such as
benzene or gasoline.

After using chemicals, make sure to gently wipe them
away using a dry cloth.
Do not place used cloths on top of resin based parts
or textiles for long periods of time without washing.

Opening

18 ACURA ILX-31TX66500.book  475 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

Cleaning

u

Interior Care

476

Main

tenan

ce

Wipe using a glass cleaner.

The front and rear floor mats hook over floor
anchors, which keep them from sliding
forward. To remove a mat for cleaning, turn
the anchor knobs to the unlock position.
When reinstalling the mat after cleaning, turn
the knobs to the lock position.

Do not put additional floor mats on top of
the anchored mats.

■

Cleaning the Window

■

Floor Mats

1

Cleaning the Window

Wires are mounted to the inside of the rear window.
Wipe along the same direction as the wires with a
soft cloth so as not to damage them.

Be careful not to spill fluids, such as water or glass
cleaner, on or around the cover of both the front
sensor camera and the rainfall/light

*

 sensor.

2 Automatic Lighting Control P. 140
2 Automatic Intermittent Wipers

*

 P. 144

2 Front Sensor Camera

*

 P. 370

Models with front sensor camera

1

Floor Mats

If you use any floor mats that were not originally
provided with your vehicle, make sure they are
designed for your specific vehicle, fit correctly, and
are securely anchored by the floor anchors.
Position the rear seat floor mat properly. If they are
not properly positioned, the floor mat can interfere
with the front seat functions.

Unlock

Lock

* Not available on all models

18 ACURA ILX-31TX66500.book  476 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

477

uu

Cleaning

u

Interior Care

Main

tenan

ce

To properly clean leather:
1. Use a vacuum or soft dry cloth first to remove any dirt or dust.
2. Clean the leather with a soft cloth dampened with a solution comprised of 90%

water and 10% neutral soap.

3. Wipe away any soap residue with a clean damp cloth.
4. Wipe away residual water and allow leather to air dry in the shade.

■

Maintaining Genuine Leather

1

Maintaining Genuine Leather

It is important to clean or wipe away dirt or dust as
soon as possible. Spills can soak into leather resulting
in stains. Dirt or dust can cause abrasions in the
leather. In addition, please note that some dark
colored clothing can rub onto the leather seats
resulting in discoloration or stains.

18 ACURA ILX-31TX66500.book  477 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

478

uu

Cleaning

u

Exterior Care

Main

tenan

ce

Exterior Care

Dust off the vehicle body after you drive.
Regularly inspect your vehicle for scratches on painted surfaces. A scratch on a
painted surface can result in body rust. If you find a scratch, promptly repair it.

Wash the vehicle regularly. Wash more frequently when driving in the following
conditions:
• If driving on roads with road salt.
• If driving in coastal areas.
• If tar, soot, bird droppings, insects, or tree sap are stuck to painted surfaces.

• Make sure to follow the instructions indicated on the automated car wash.
• Fold in the door mirrors.
• For models equipped with automatic intermittent wipers, turn the wipers off.

• Keep sufficient distance between the cleaning nozzle and the vehicle body.
• Take particular care around the windows. Standing too close may cause water to

enter the vehicle interior.

• Do not spray high pressure water directly into the engine compartment. Instead,

use low pressure water and a mild detergent.

■

Washing the Vehicle

■

Using an Automated Car Wash

■

Using High Pressure Cleaners

1

Washing the Vehicle

Do not spray water into the air intake vents. It can
cause a malfunction.

Air Intake Vents

18 ACURA ILX-31TX66500.book  478 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

479

uu

Cleaning

u

Exterior Care

Main

tenan

ce

A good coat of automotive body wax helps protect your vehicle’s paint from the
elements. Wax will wear off over time and expose your vehicle’s paint to the
elements, so reapply as necessary.

If you get gasoline, oil, engine coolant, or battery fluid on resin coated parts, they
may be stained or the coating may peel. Promptly wipe it away using a soft cloth and
clean water.

Wipe using a glass cleaner.

Aluminum is susceptible to deterioration caused by salt and other road
contaminants. When necessary, as early as possible use a sponge and mild detergent
to wipe away these contaminants. Do not use a stiff brush or harsh chemicals
(including some commercial wheel cleaners). These can damage the protective finish
on aluminum alloy wheels, resulting in corrosion. Depending on the type of finish,
the wheels also may lose their luster or appear burnished. To avoid water stains,
wipe the wheels dry with a cloth while they are still wet.

■

Applying Wax

■

Maintaining the Bumpers and Other Resin Coated Parts

■

Cleaning the Window

■

Maintaining Aluminum Wheels

1

Applying Wax

NOTICE

Chemical solvents and strong cleaners can damage
the paint, metal, and plastic on your vehicle. Wipe
away spills immediately.

1

Maintaining the Bumpers and Other Resin Coated Parts

Ask a dealer about the correct coating material when
you want to repair the painted surface of the parts
made of resin.

18 ACURA ILX-31TX66500.book  479 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

480

uu

Cleaning

u

Exterior Care

Main

tenan

ce

The inside lenses of exterior lights (headlights, brake lights, etc.) may fog temporarily
if you have driven in the rain, or after the vehicle has been run through a car wash.
Dew condensation also may build up inside the lenses when there is a significant
enough difference between the ambient and inside lens temperatures (similar to
vehicle windows fogging up in rainy conditions). These conditions are natural
processes, not structural design problems in the exterior lights.
Lens design characteristics may result in moisture developing on the light lens frame
surfaces. This also is not a malfunction.
However, if you see large amounts of water accumulation, or large water drops
building up inside the lenses, have your vehicle inspected by a dealer.

■

Fogged Exterior Light Lenses

18 ACURA ILX-31TX66500.book  480 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

481

Main

tenan

ce

Accessories and Modifications

Accessories

When installing accessories, check the following:
• Do not install accessories on the windshield. They can obstruct your view and

delay your reaction to driving conditions.

• Do not install any accessories over areas marked SRS Airbag, on the sides or backs

of the front seats, on front or side pillars, or near the side windows.
Accessories installed in these areas may interfere with proper operation of the
vehicle’s airbags or may be propelled into you or another occupant if the airbags
deploy.

• Be sure electronic accessories do not overload electrical circuits or interfere with

proper operation of your vehicle.

2 Fuses P. 519

• Before installing any electronic accessory, have the installer contact a dealer for

assistance. If possible, have a dealer inspect the final installation.

1

Accessories and Modifications

Acura Genuine accessories are recommended to
ensure proper operation on your vehicle.

3

WARNING

Improper accessories or modifications can
affect your vehicle's handling, stability, and
performance, and cause a crash in which
you can be seriously hurt or killed.

Follow all instructions in this owner's
manual regarding accessories and
modifications.

18 ACURA ILX-31TX66500.book  481 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

482

uu

Accessories and Modifications

u

Modifications

Main

tenan

ce

Modifications

Do not modify your vehicle in a manner that may affect its handling, stability, or
reliability, or install non-genuine Acura parts or accessories that may have a similar
effect.

Even minor modifications to vehicle systems can affect overall vehicle performance.
Always make sure all equipment is properly installed and maintained, and do not
make any modification to your vehicle or its systems that might cause your vehicle
to no longer meet federal, state, province, territory, and local regulations.

The on-board diagnostic port (OBD-II/SAE J1962 connector) installed on this vehicle
is intended to be used with automobile system diagnostic devices or with other
devices that Acura has approved. Use of any other type of device may adversely
affect the vehicle’s electronic systems or allow them to be compromised, possibly
resulting in a system malfunction, drained battery, or other unexpected problems.

Do not modify or attempt to repair any of the electrical components.

18 ACURA ILX-31TX66500.book  482 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

483

Handling the Unexpected

This chapter explains how to handle unexpected troubles.

Tools

Types of Tools .................................. 484

If a Tire Goes Flat

Temporarily Repairing a Flat Tire....... 485

Changing a Flat Tire ......................... 499

Engine Does Not Start

Checking the Engine ........................ 506
If the Keyless Access Remote Battery is

Weak ............................................. 507

Emergency Engine Stop ................... 508

Jump Starting.................................... 509

Vehicles with optional spare tire

Shift Lever Does Not Move.............. 512
Overheating

How to Handle Overheating............. 513

Indicator, Coming On/Blinking

If the Low Oil Pressure Indicator Comes

On ............................................. 515

If the Charging System Indicator Comes

On ................................................. 515

If the Malfunction Indicator Lamp Comes

On or Blinks ................................... 516

If the Brake System Indicator (Red)

Comes On.................................. 517

If the Electric Power Steering (EPS) System

Indicator Comes On......................... 517

If the Low Tire Pressure/TPMS Indicator

Comes On or Blinks ....................... 518

Fuses

Fuse Locations ................................. 519
Inspecting and Changing Fuses........ 521

Emergency Towing........................... 522

18 ACURA ILX-31TX66500.book  483 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

484

Han

d

lin
g the U

n

expected

Tools

Types of Tools

1

Types of Tools

The tools are stored in the cargo area.

Jack

Tool Case

Wheel Nut Wrench/Jack Handle

Jack Handle Bar

Vehicles with optional spare tire

18 ACURA ILX-31TX66500.book  484 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分
