Acura ILX (2018 year). Manual - part 31

485

Continued

Han

d

lin
g the U

n

expected

If a Tire Goes Flat

Temporarily Repairing a Flat Tire

If the tire has a large cut or is otherwise severely damaged, you will need to have the
vehicle towed. If the tire only has a small puncture, from a nail for instance, you can
use the temporary tire repair kit so that you can drive to the nearest service station
for a more permanent repair.

If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then stop in a safe place.

1. Park the vehicle on a firm, level, and non-slippery surface and apply the parking

brake.

2. Move the shift lever to

(

P.

3. Turn on the hazard warning lights and set the power mode to VEHICLE OFF

(LOCK).

1

Temporarily Repairing a Flat Tire

The kit should not be used in the following situations.
Instead, contact a dealer or roadside assistance to
have the vehicle towed.

•

The tire sealant has expired.

•

More than one tire is punctured.

•

The puncture or cut is larger than 3/16 inch (4 mm).

•

The tire side wall is damaged or the puncture is
outside the contact area.

•

Damage has been caused by driving with the tire
extremely under inflated.

•

The tire bead is no longer seated.

•

The rim is damaged.

Do not remove a nail or screw that punctured the
tire. If you remove it from the tire, you may not be
able to repair the puncture using the kit.

NOTICE

Do not use a puncture-repairing agent other than the
one provided in the kit that came with your vehicle. If
a different agent is used, you may permanently
damage the tire pressure sensor.

When the puncture is:

Kit Use

Smaller than 3/16 inch

(4 mm)

Yes

Larger than 3/16 inch

(4 mm)

No

Contact
Area

18 ACURA ILX-31TX66500.book  485 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

486

Han

d

lin
g the U

n

expected

1. Open the trunk floor lid.

■

Getting Ready to Temporarily Repair the Flat Tire

1

Getting Ready to Temporarily Repair the Flat Tire

Repair notification label and speed restriction label
are applied to the side of temporary tire repair kit.

When making a temporary repair, carefully read the
instruction manual provided with the kit.

Instruction Manual

Air Only Hose (Black)

Speed Restriction Label

Repair Notification Label

Pressure Relief
Button

Inflator Switch

Selector Switch

SEALANT/AIR side

Sealant/Air Hose (Clear)

AIR ONLY side

Power Plug

Pressure Gauge

Tire Sealant
Expiration Date

U.S.

Canada

U.S.

Canada

18 ACURA ILX-31TX66500.book  486 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

487

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Continued

Han

d

lin
g the U

n

expected

2. Remove the kit.
3. Place the kit face up, on flat ground near

the flat tire, and away from traffic. Do not
place the kit on its side.

18 ACURA ILX-31TX66500.book  487 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

488

Han

d

lin
g the U

n

expected

1. Remove the valve cap from the tire valve

stem.

2. Remove the sealant/air hose from the

packaging.

3. Attach the sealant/air hose onto the tire

valve stem. Screw it until it is tight.

■

Injecting Sealant and Air

1

Injecting Sealant and Air

In cold temperatures, the sealant may not flow easily.
In this situation, warm it up for five minutes before
using.

The sealant can permanently stain clothing and other
materials. Be careful during handling and wipe away
any spills immediately.

3

WARNING

Tire sealant contains substances that are
harmful and can be fatal if swallowed.

If accidentally swallowed, do not induce
vomiting. Drink plenty of water and get
medical attention immediately.

For skin or eye contact, flush with cool
water and get medical attention if
necessary.

Valve Stem

Valve Cap

Sealant/Air Hose

Valve Stem

Sealant/Air Hose

18 ACURA ILX-31TX66500.book  488 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

489

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Han

d

lin
g the U

n

expected

4. Plug in the compressor to the accessory

power socket.

u

Be careful not to pinch the cord in a
door or window.

u

Do not plug any other electronic
devices into other accessory power
sockets.

2 Accessory Power Socket P. 162

5. Start the engine.

u

Keep the engine running while injecting
sealant and air.

2 Carbon Monoxide Gas P. 63

6. Turn the selector switch to SEALANT/

AIR.

1

Injecting Sealant and Air

NOTICE

Do not operate the temporary tire repair kit
compressor for more than 15 minutes. The
compressor can overheat and become permanently
damaged.

Until the sealant injection is complete, the pressure
shown on the pressure gauge will appear higher than
actual. After the sealant injection is complete the
pressure will drop and then begin to rise again as the
tire is inflated with air. This is normal. To accurately
measure the air pressure using the gauge, turn the air
compressor off only after the sealant injection is
complete.

3

WARNING

Running the engine with the vehicle in an
enclosed or even partly enclosed area can
cause a rapid build-up of toxic carbon
monoxide.

Breathing this colorless, odorless gas can
cause unconsciousness and even death.
Only run the engine to power the air
compressor with the vehicle outdoors.

SEALANT/AIR side

18 ACURA ILX-31TX66500.book  489 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

490

Han

d

lin
g the U

n

expected

7. Press the inflator switch to turn on the

compressor.

u

The compressor starts injecting sealant
and air into the tire.

u

When the sealant injection is complete
continue to add air.

8.

After the air pressure reaches front: 35 psi
(240 kPa)/rear: 33 psi (230 kPa), turn off
the kit.

After the air pressure reaches front: 33 psi
(230 kPa)/rear: 32 psi (220 kPa), turn off
the kit.

u

To check the pressure, occasionally turn
off the compressor and read the gauge.

9. Unplug the power plug from the accessory

power socket.

10. Unscrew the sealant/air hose from the tire

valve stem. Reinstall the valve cap.

Pressure Gauge

ON

OFF

Models with P215/45R17 87V tires

Models with 225/40R18 92V tires

1

Injecting Sealant and Air

If the required air pressure is not reached within 15
minutes, the tire may be too severely damaged for
the kit to provide the necessary seal, and your vehicle
will need to be towed.

See an Acura dealer for a replacement sealant bottle
and proper disposal of an empty bottle.

Sealant/Air Hose

Valve Stem

18 ACURA ILX-31TX66500.book  490 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

491

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Continued

Han

d

lin
g the U

n

expected

11. Press the pressure relief button until the

gauge returns to 0 psi (0 kPa).

12. Apply the repair notification label to the

flat surface of the wheel.

u

The wheel surface must be clean to
ensure the label adheres properly.

Pressure Relief Button

Repair Notification Label

U.S.

Canada

18 ACURA ILX-31TX66500.book  491 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

492

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Han

d

lin
g the U

n

expected

1. Apply the speed restriction label to the

location as shown.

2. Drive the vehicle for about 10 minutes.

u

Do not exceed 50 mph (80 km/h).

3. Stop the vehicle in a safe place.

■

Distributing the Sealant in the Tire

Speed Restriction Label

U.S.

Canada

18 ACURA ILX-31TX66500.book  492 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

493

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Continued

Han

d

lin
g the U

n

expected

4. Recheck the air pressure using the air only

hose on the compressor.

5. Turn the selector switch to AIR ONLY.

u

Do not turn the air compressor on to
check the pressure.

2 Inflating an Under-inflated Tire P. 496

6. If the air pressure is

• Less than 19 psi (130 kPa):

Do not add air or continue driving. The leak
is too severe. Call for help and have your
vehicle towed.

2 Emergency Towing P. 522

• Front: 35 psi (240 kPa)/rear: 33 psi

(230kPa) or more:

• Front: 33 psi (230 kPa)/rear: 32 psi

(220kPa) or more:

• Specified pressure or more:

Continue driving for another 10 minutes or
until you reach the nearest service station,
whichever is sooner. Do not exceed 50 mph
(80 km/h). If you have not reached a service
station, stop and check the tire pressure.

u

If the air pressure does not go down after
the 10 minute driving, you do not need
to check the pressure any more.

AIR ONLY
side

ON

Air Only Hose

Models with P215/45R17 87V tires

Models with 225/40R18 92V tires

18 ACURA ILX-31TX66500.book  493 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

494

Han

d

lin
g the U

n

expected

• Greater than 19 psi (130 kPa), but less

than front: 35 psi (240 kPa)/rear: 33 psi
(230kPa):
Turn the air compressor on to inflate the
tire until the tire pressure reaches to
front: 35 psi (240 kPa)/rear: 33 psi
(230kPa).

• Greater than 19 psi (130 kPa), but less

than front: 33 psi (230 kPa)/rear: 32 psi
(220kPa):
Turn the air compressor on to inflate the
tire until the tire pressure reaches to
front: 33 psi (230 kPa)/rear: 320 psi
(220kPa).

2 Inflating an Under-inflated Tire P. 496

Then drive carefully for 10 more minutes or
until you reach the nearest service station.
Do not exceed 50 mph (80 km/h).

u

You should repeat this procedure as long
as the air pressure is within this range.

Models with P215/45R17 87V tires

AIR ONLY
side

ON

Models with 225/40R18 92V tires

1

Distributing the Sealant in the Tire

3

WARNING

Running the engine with the vehicle in an
enclosed or even partly enclosed area can
cause a rapid build-up of toxic carbon
monoxide.

Breathing this colorless, odorless gas can
cause unconsciousness and even death.
Only run the engine to power the air
compressor with the vehicle outdoors.

18 ACURA ILX-31TX66500.book  494 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

495

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Continued

Han

d

lin
g the U

n

expected

7. Unplug the kit from the accessory power

socket.

8. Unscrew the air only hose from the tire

valve stem. Reinstall the valve cap.

9. Press the pressure relief button until the

gauge returns to 0 psi (0 kPa).

10. Repackage and properly stow the kit.

Pressure Relief Button

18 ACURA ILX-31TX66500.book  495 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

496

Han

d

lin
g the U

n

expected

You can use the kit to inflate a non-punctured under-inflated tire.

1. Open the trunk floor lid.

2 Getting Ready to Temporarily Repair

the Flat Tire P. 486

2. Remove the kit from the case.
3. Place the kit, face up, on flat ground near

the flat tire, away from traffic. Do not
place the kit on its side.

4. Remove the air only hose from the kit.

5. Remove the valve cap.

6. Attach the air only hose onto the tire valve

stem. Screw it until it is tight.

■

Inflating an Under-inflated Tire

1

Inflating an Under-inflated Tire

NOTICE

Do not operate the temporary tire repair kit
compressor for more than 15 minutes. The
compressor can overheat and become permanently
damaged.

Air Only Hose

Valve Cap

Valve Stem

Air Only Hose

18 ACURA ILX-31TX66500.book  496 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

Continued

497

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Han

d

lin
g the U

n

expected

7. Plug in the kit to the accessory power

socket.

u

Be careful not to pinch the cord in a
door or window.

u

Do not plug any other electronic
devices into other accessory power
sockets.

2 Accessory Power Socket P. 162

8. Start the engine.

u

Keep the engine running while injecting
air.

2 Carbon Monoxide Gas P. 63

9. Turn the selector switch to AIR ONLY.

10. Press the inflator switch to turn on the kit.

u

The compressor starts to inject air into
the tire.

11. Inflate the tire to the specified air pressure.

1

Inflating an Under-inflated Tire

3

WARNING

Running the engine with the vehicle in an
enclosed or even partly enclosed area can
cause a rapid build-up of toxic carbon
monoxide.

Breathing this colorless, odorless gas can
cause unconsciousness and even death.
Only run the engine to power the air
compressor with the vehicle outdoors.

AIR ONLY
side

ON

18 ACURA ILX-31TX66500.book  497 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

498

uu

If a Tire Goes Flat

u

Temporarily Repairing a Flat Tire

Han

d

lin
g the U

n

expected

12. Turn off the kit.

u

Check the pressure gauge on the air
compressor.

u

If overinflated, press the pressure relief
button.

13. Unplug the kit from the accessory power

socket.

14. Unscrew the air only hose from the tire

valve stem. Reinstall the valve cap.

15. Press the pressure relief button until the

gauge returns to 0 psi (0 kPa).

16. Repackage and properly stow the kit.

Pressure Relief Button

18 ACURA ILX-31TX66500.book  498 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

499

uu

If a Tire Goes Flat

u

Changing a Flat Tire

Continued

Han

d

lin
g the U

n

expected

Changing a Flat Tire

If a tire goes flat while driving, grasp the steering wheel firmly, and brake gradually
to reduce speed. Then, stop in a safe place. Replace the flat tire with a compact
spare tire. Go to a dealer as soon as possible to have the full size tire repaired or
replaced.

1. Park the vehicle on firm, level, and non-slippery surface and apply the parking

brake.

2. Move the shift lever in

(

P.

3. Turn on the hazard warning lights and set the power mode to VEHICLE OFF

(LOCK).

Vehicles with optional spare tire

1

Changing a Flat Tire

Periodically check the tire pressure of the compact
spare. It should be set to the specified pressure.
Specified Pressure: 60 psi (420 kPa, 4.2 kgf/cm

2

)

When driving with the compact spare tire, keep the
vehicle speed under 50 mph (80 km/h). Replace with
a full size tire as soon as possible.

The compact spare tire and wheel in your vehicle are
specifically for this model. Do not use them with
another vehicle. Do not use another type of compact
spare tire or wheel with your vehicle.

Do not mount tire chains on a compact spare tire.
If a chain-mounted front tire goes flat, remove one of
the full-size rear tires and replace it with the compact
spare tire. Remove the flat front tire and replace it
with the full size tire that was removed from the rear.
Mount the tire chains on the front tire.

Do not use a puncture-repairing agent on a flat tire,
as it can damage the tire pressure sensor.

Do not mount the compact spare on the front. If
mounted on the front, the compact spare, smaller in
size than the full-size tire, may damage the
differential.

If either front tire goes flat, remove the rear tire on
the same side, and mount the compact spare on the
rear and the rear tire on the front.

18 ACURA ILX-31TX66500.book  499 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分

uu

If a Tire Goes Flat

u

Changing a Flat Tire

500

Han

d

lin
g the U

n

expected

1. Open the trunk floor lid.

2. Take the tool case out of the trunk. Take

the jack and wheel nut wrench out of the
tool case.

3. Unscrew the wing bolt, and remove the

spacer cone. Then, remove the spare tire.

4. Place a wheel block or rock in front and rear

of the wheel diagonal to the flat tire.

■

Getting Ready to Replace the Flat Tire

1

Getting Ready to Replace the Flat Tire

The shape of the tool case varies by model.

Spare Tire

Tool Case

Wheel
Blocks

The tire to be replaced.

18 ACURA ILX-31TX66500.book  500 ページ  ２０１７年８月２５日　金曜日　午前１１時３１分
