117

Continued

Adjusting the Mirrors

Interior Rearview Mirror

Adjust the angle of the rearview mirror when you are sitting in the correct
driving position.

When driving after dark, the automatic
dimming rearview mirror reduces the glare
from headlights behind you. Press the auto
button to turn this function on and off.
When activated, the auto indicator comes on.

Power Door Mirrors

You can adjust the door mirrors when the
ignition switch is in ON

 (

w .

■

Mirror position adjustment

L/R selector switch: Select the left or right
mirror. After adjusting the mirror, return the
switch to the center position.

Mirror position adjustment switch: Press
the switch left, right, up, or down to move
the mirror.

■

Automatic Dimming Rearview Mirror

1

Adjusting the Mirrors

Keep the inside and outside mirrors clean and
adjusted for best visibility.

Adjust the mirrors before you start driving.

2 Adjusting the Seat Positions P. 119

1

Automatic Dimming Rearview Mirror

The auto dimming function cancels when the shift
position is in

 (

R

.

Indicator

Auto Button

Sensor

Selector Switch

Adjustment Switch

14 ACURA TSX 5D-31TL76300.book  117 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

118

uu

Adjusting the Mirrors

u

Power Door Mirrors

If activated, the passenger side door mirror
automatically tilts downward when you put
the shift lever in

 (

R ; this improves close-in

visibility on the passenger side of the vehicle
when backing up. The mirror automatically
returns to its original position when you shift
out of

 (

R .

To activate this feature, turn the ignition
switch to ON

 (

w  and slide the selector switch

to the passenger’s side.

■

Reverse Tilt Door Mirror

Selector Switch

14 ACURA TSX 5D-31TL76300.book  118 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

119

Continued

Adjusting the Seats

Adjusting the Seat Positions

Adjust the driver’s seat as far back as possible
while allowing you to maintain full control of
the vehicle. You should be able to sit upright,
well back in the seat and be able to
adequately press the pedals without leaning
forward, and grip the steering wheel
comfortably. The passenger’s seat should be
adjusted in a similar manner, so that it is as far
back from the front airbag in the dashboard
as possible.

■

Adjusting the front seat

1

Adjusting the Seats

The National Highway Traffic Safety Administration
and Transport Canada recommend that drivers allow
at least 10 inches (25 cm) between the center of the
steering wheel and the chest.

Always make seat adjustments before driving.

3

WARNING

Sitting too close to a front airbag can result
in serious injury or death if the front
airbags inflate.

Always sit as far back from the front
airbags as possible while maintaining
control of the vehicle.

Move back.

Allow sufficient
space.

Horizontal Position
Adjustment

Height Adjustment
(Driver’s seat only)

Seat-back Angle
Adjustment

Driver’s seat is shown

14 ACURA TSX 5D-31TL76300.book  119 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Adjusting the Seats

u

Adjusting the Seat Positions

120

Adjust the driver’s seat-back to a comfortable,
upright position, leaving ample space
between your chest and the airbag cover in
the center of the steering wheel.

The front seat passenger should also
adjust their seat-back to a comfortable,
upright position.

Reclining a seat-back so that the shoulder part of the belt no longer rests against the
occupant’s chest reduces the protective capability of the belt. It also increases the
chance of sliding under the belt in a crash and being seriously injured. The farther a
seat-back is reclined, the greater the risk of injury.

■

Adjusting the Seat-Backs

1

Adjusting the Seat-Backs

Do not put a cushion, or other object, between the
seat-back and your back.

Doing so may interfere with proper seat belt or airbag
operation.

If you cannot get far enough away from the steering
wheel and still reach the controls, we recommend
that you investigate whether some type of adaptive
equipment may help.

3

WARNING

Reclining the seat-back too far can result in
serious injury or death in a crash.

Adjust the seat-back to an upright position,
and sit well back in the seat.

14 ACURA TSX 5D-31TL76300.book  120 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

Continued

121

uu

Adjusting the Seats

u

Adjusting the Seat Positions

Your vehicle is equipped with head restraints
in all seating positions.

Head restraints are most effective for
protection against whiplash and other rear-
impact crash injuries when the center of the
back of the occupant’s head rests against the
center of the restraint. The tops of the
occupant’s ears should be level with the
center height of the restraint.

■

Adjusting the front and rear outer head restraint positions

To raise the head restraint: Pull it upward.
To lower the head restrain: Push it down
while pressing the release button.

■

Adjusting the Head Restraints

1

Adjusting the Head Restraints

The driver’s and front passenger’s seats have active
head restraints.

2 Active Head Restraints P. 125

3

WARNING

Improperly positioning head restraints
reduces their effectiveness and increases
the likelihood of serious injury in a crash.

Make sure head restraints are in place and
positioned properly before driving.

Position head in the center
of the head restraint.

14 ACURA TSX 5D-31TL76300.book  121 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Adjusting the Seats

u

Adjusting the Seat Positions

122

A passenger sitting in the center back seating
position should adjust the height of their head
restraint to an appropriate position before the
vehicle begins moving.

To raise the head restraint:
Pull it upward.

To lower the head restraint:
Push it down while pressing the
release button.

Head restraints can be removed for cleaning or repair.

To remove a head restraint:
Pull the restraint up as far as it will go. Then push the release button, and pull the
restraint up and out.

To reinstall a head restraint:
Insert the legs back in place, then adjust the head restraint to an appropriate height
while pressing the release button. Pull up on the restraint to make sure it is locked
in position.

■

Changing the Rear Center Seat Head Restraint Position

■

Removing and Reinstalling the Head Restraints

1

Removing and Reinstalling the Head Restraints

3

WARNING

Failure to reinstall, or correctly reinstall, the
head restraints can result in severe injury
during a crash.

Always replace the head restraints before
driving.

14 ACURA TSX 5D-31TL76300.book  122 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

123

uu

Adjusting the Seats

u

Adjusting the Seat Positions

Continued

The firmness of the seat-back can be adjusted.

To make it firmer:
Push the lever forward.

To make it less firm:
Pull the lever backward.

■

Adjusting the Driver’s Seat Lumbar Support

14 ACURA TSX 5D-31TL76300.book  123 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Adjusting the Seats

u

Adjusting the Seat Positions

124

After all occupants have adjusted their seats and head restraints, and put on their
seat belts, it is very important that they continue to sit upright, well back in their
seats, with their feet on the floor, until the vehicle is safely parked and the engine
is off.

Sitting improperly can increase the chance of injury during a crash. For example, if
an occupant slouches, lies down, turns sideways, sits forward, leans forward or
sideways, or puts one or both feet up, the chance of injury during a crash is
greatly increased.

In addition, an occupant who is out of position in the front seat can be seriously or
fatally injured in a crash by striking interior parts of the vehicle or being struck by an
inflating front airbag.

■

Maintain a Proper Sitting Position

1

Maintain a Proper Sitting Position

3

WARNING

Sitting improperly or out of position can
result in serious injury or death in a crash.

Always sit upright, well back in the seat,
with your feet on the floor.

14 ACURA TSX 5D-31TL76300.book  124 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

125

uu

Adjusting the Seats

u

Adjusting the Seat Positions

The driver’s and front passenger’s seats have active head restraints. In a rear impact,
an occupant properly secured by a seat belt will be pushed against the seat-back and
the head restraint will move forward. This reduces the distance between the
restraint and the occupant’s head, which helps reduce the likelihood of whiplash
and injuries to the neck and upper spine.

■

Active Head Restraints

1

Active Head Restraints

In order for the active head restraints to operate
properly:

•

Do not hang any items on the head restraints, or
from the restraint legs.

•

Do not place any object between an occupant and
the seat-back.

•

Install each restraint in its proper location.

After a collision, the activated restraint should return
to its normal position. If the restraint does not return
to its normal position, or in the event of a severe
collision, have the vehicle inspected by a dealer.

14 ACURA TSX 5D-31TL76300.book  125 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

126

uu

Adjusting the Seats

u

Rear Seats

Rear Seats

1. Unlatch the detachable anchor from the

anchor buckle and store the detachable
anchor in the retractor housing.

2. Pull the release lever and fold down the

seat-back.

If the rear head restraints get caught on the
front seat-backs, remove the head restraints.

2 Removing and Reinstalling the Head

Restraints P. 122

■

Folding Down the Rear Seats

1

Folding Down the Rear Seats

The rear seat-backs can be folded down to
accommodate bulkier items in the cargo area.

Never drive with a seat-back folded down and the
tailgate open.

2 Carbon Monoxide Gas P. 61

To lock a seat-back upright, push it backwards until it
locks.

When returning a seat-back to it’s original position,
push it firmly back. Also, make sure all rear shoulder
belts are positioned in front of the seat-back, and the
center shoulder belt is re-positioned in the guide.

Make sure that the folded seat-back does not press
against the front passenger seat, as this can cause the
weight sensors in the front passenger seat to work
improperly.

2 Passenger Airbag Off Indicator P. 46

Anchor Buckle

Lever

14 ACURA TSX 5D-31TL76300.book  126 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

127

uu

Adjusting the Seats

u

Armrest

Armrest

The console lid can be used as an armrest.

To adjust:
Push the release lever and slide the armrest to
a desired position. Release the lever to lock
the position.

Pull down the armrest in the center seat-back.

■

Using the Front Seat Armrest

■

Using the Rear Seat Armrest

14 ACURA TSX 5D-31TL76300.book  127 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

128

Interior Lights/Interior Convenience Items

Interior Lights

■

ON

The interior lights come on regardless of
whether the doors are open or closed.

■

Door activated

The interior lights come on in the following
situations:
• When any of the doors are opened.

• You unlock the driver’s door.

• You remove the key from the ignition

switch.

■

OFF

The interior lights remain off regardless of
whether the doors are open or closed.

The map lights can be turned on and off by
pressing the lenses.

■

Interior Light Switches

1

Interior Light Switches

In the door activated position, the interior lights fade
out and go off about 30 seconds after the doors are
closed.

The lights go off after 30 seconds in the following
situations:

•

When you unlock the driver’s door but do not open
it.

•

When you remove the key from the ignition switch
but do not open a door.

You can change the interior lights dimming time.

2 Customized Features P. 79

The interior lights go off immediately in the following
situations:

•

When you lock the driver’s door.

•

When you close the driver’s door with the key in
the ignition switch.

•

When you turn the ignition switch to ON

 (

w

.

If you leave any of the doors open without the key in
the ignition switch, the interior lights go off after
about 15 minutes.

Door Activated Position

Off

Front

Door Activated Position

On

Off

Rear

On

■

Map Lights

1

Map Lights

When the ceiling light switch is in the door activated
position and any door is open, the map light will not
go off when you press the lens.

14 ACURA TSX 5D-31TL76300.book  128 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

129

uu

Interior Lights/Interior Convenience Items

u

Interior Lights

■

ON

The light comes on when you open the
tailgate, and goes off when closed.

■

OFF

The light stays off with or without opening
the tailgate.

■

Cargo Area Light

On

Off

14 ACURA TSX 5D-31TL76300.book  129 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

130

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Interior Convenience Items

Pull the handle to open the glove box. You
can lock the glove box with the master key.

■

Detachable shelf

The shelf in the glove box is detachable. To
remove it, disengage the tabs.

■

Glove Box

1

Glove Box

The glove box light comes on when the parking lights
are on.

3

WARNING

An open glove box can cause serious injury
to your passenger in a crash, even if the
passenger is wearing the seat belt.

Always keep the glove box closed while
driving.

Glove Box

To Lock

Shelf

14 ACURA TSX 5D-31TL76300.book  130 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

Continued

131

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Pull the handle to open the
console compartment.

To use the console lid as an armrest, slide it to
the desired position while pulling up the
release lever.

You can keep beverage bottles and cans cool
with the air conditioning system.

1. Turn the dial counterclockwise to open the

air vent in the console compartment.

2. Turn on the climate control system and

adjust the temperature to cool.

3. Set the mode control

 or

.

u

The cool air is diverted through the

air vent.

■

Console Compartment

1

Console Compartment

Use only resealable containers or keep unopened
cans in the console compartment.

Spilled liquids can damage the upholstery and
electrical components in the console compartment.

When the heater begins to divert warm air, the
airflow into the console compartment is shut off.

Close

Open

14 ACURA TSX 5D-31TL76300.book  131 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

132

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Lift up the handle and put the lid on
the notch.

Hold the strap and raise the lid.

■

Under-floor Storage Area

Handle

Lid

Notch

■

Floor Storage Compartments

Strap

Strap

14 ACURA TSX 5D-31TL76300.book  132 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon
