Acura TSX (2014 year). Manual - part 7

101

uu

Security System

u

Security System Alarm

■

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The ignition switch is in LOCK

 (

0 , and the key has been removed from the

ignition switch.

• The hood is closed.

• All doors and the tailgate are locked with the remote transmitter.

■

When the security system alarm sets

The security system alarm indicator in the instrument panel blinks. When the
blinking interval changes after about 15 seconds, the security system alarm is set.

■

To cancel the security system alarm

The security system alarm is canceled when the vehicle is unlocked using the key or
remote transmitter. The security system alarm indicator goes off at the same time.

■

The  PA N IC button  on the

remote transmitter

If you press the PANIC button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.

• Some exterior lights flash.

■

Canceling panic mode

Press any button on the remote transmitter, or turn the ignition switch to ON

 (

w .

■

Panic Mode

1

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

•

Unlocking the door with the lock tab or the master
door lock switch.

•

Opening the tailgate with the power tailgate
button on the driver’s door.

If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.

If this occurs, deactivate the security system alarm by
unlocking a door using the key or remote transmitter.

Do not attempt to alter this system or add another
device to it.

Model with power tailgate

PANIC



Button

14 ACURA TSX 5D-31TL76300.book  101 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

102

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the ignition switch is in ON

 (

w , using the switches on the doors. The driver’s side switches can be used to open

and close all the windows.

The power window lock button on the driver’s side must be switched off (not
pushed in, indicator off) to open and close the windows from anywhere other than
the driver’s seat.

When the power window lock button is turned on (pushed in, indicator on), you can
only operate the driver’s window. Turn the power window lock button on when
children are in the vehicle.

■

Automatic operation

To open: Push the switch down firmly.

To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

■

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.

To close: Pull the switch up lightly, and hold it
until the desired position is reached.

■

Opening/Closing Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you turn the ignition switch off.
Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

On
Off

Indicator

Driver’s
Window
Switch

Front Passenger’s Window Switch

Power Window
Lock Button

14 ACURA TSX 5D-31TL76300.book  102 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

103

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Continued

To open: Push the switch down.

To close: Pull the switch up.

Release the switch when the window reaches
the desired position.

To open: Press the unlock button twice
within 10 seconds and hold it down for the
second time. If the windows stop midway,
repeat the procedure.

■

Opening/Closing Windows without
Auto-Open/Close Function

Close

Open

■

Opening Windows and Moonroof
with the Remote Transmitter

Unlock
Button

14 ACURA TSX 5D-31TL76300.book  103 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

104

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

To open: Unlock the driver’s door with the
key. Within 10 seconds of returning the key to
the central position, turn the key in the unlock
direction and hold it there.

To close: Lock the driver’s door with the key.
Within 10 seconds of returning the key to the
central position, turn the key in the lock
direction and hold it there.

Release the key to stop the windows/
moonroof at the desired position. If you want
further adjustment, repeat the same
operation.

■

Opening/Closing the Windows/Moonroof with the Key

Close

Open

14 ACURA TSX 5D-31TL76300.book  104 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

105

Opening and Closing the Moonroof

You can only operate the moonroof when the ignition switch is in ON

 (

w . Use the

switch in the front of the ceiling to open and close the moonroof.

■

Automatic operation

To open: Pull the switch back firmly.

To close: Push the switch forward firmly.

The moonroof will automatically open or close
all the way. To stop the moonroof midway,
touch the switch briefly.

■

Manual operation

To open: Pull the switch back lightly, and
hold it until the desired position is reached.

To close: Push the switch forward lightly, and
hold it until the desired position is reached.

■

Tilting the moonroof up

To tilt: Push on the center of the
moonroof switch.

To close: Push the switch forward firmly.

■

Opening/Closing the Moonroof

1

Opening/Closing the Moonroof

NOTICE

Opening the moonroof in below freezing
temperature or when it is covered with snow or ice
can damage the moonroof panel or motor.

The power moonroof can be operated for up to 10
minutes after you turn the ignition switch off.
Opening either front door cancels this function.

When resistance is detected, the auto reverse
function causes the moonroof to change directions,
then stop. Auto reverse stops sensing when the
moonroof is almost closed to ensure that it fully
closes.

3

WARNING

Opening or closing the moonroof on
someone's hands or fingers can cause
serious injury.

Make sure all hands and fingers are clear of
the moonroof before opening or closing it.

14 ACURA TSX 5D-31TL76300.book  105 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

106

Operating the Switches Around the Steering Wheel

Ignition Switch

1

Ignition Switch

You cannot take the key out unless the shift lever is
in

 (

P

.

If you open the driver’s door when the key is in LOCK

 (

0

 or ACCESSORY

 (

q

, a warning buzzer will sound

to remind you to take the key out.

When this happens, the following messages appear
on the multi-information display:

•

In LOCK

 (

0

: REMOVE KEY.

•

In ACCESSORY

 (

q

: REMOVE KEY. The buzzer will

stop when you take the key out.

If the key won’t turn from LOCK

 (

0

 to ACCESSORY



(

q

, turn the key while moving the steering wheel left

and right. The steering wheel will unlock, allowing
the key to turn.



0

 LOCK: Insert and remove the key in this

position.



q

 ACCESSORY: Operate the audio system and

other accessories in this position.



w

 ON: This is the position when driving.



e

 START: This position is for starting the engine.

The switch returns to ON

w

 when you let go of

the key.

14 ACURA TSX 5D-31TL76300.book  106 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

107

uu

Operating the Switches Around the Steering Wheel

u

Turn Signals

Continued

Turn Signals

The turn signals can be used when the ignition
switch is in ON

 (

w .

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the position of the
ignition switch.

■

High beams

Push the lever forward until you hear a click.

■

Low beams

When in high beams, pull the lever back to
return to low beams.

■

Flashing the high beams

Pull the lever back, and release it.

Right Turn

Left Turn

■

Manual Operation

1

Light Switches

If you remove the key from the ignition switch while
the lights are on, a chime sounds when the driver’s
door is opened.

Repeatedly turning the headlights on and off reduces
the life of the HID headlight bulbs.

If you sense that the level of the headlights is
abnormal, have the vehicle inspected by a dealer.

Do not leave the lights on when the engine is off
because it will cause the battery to discharge.

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail and license plate lights

Turns on headlights, parking, side
marker, tail, and license plate
lights

14 ACURA TSX 5D-31TL76300.book  107 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

108

Automatic lighting control can be used when
the ignition switch is in ON

 (

w .

When you turn the light switch to AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

u

You can change the auto light

sensitivity  setting.

2 Customized Features P. 79

■

Automatic lighting off feature

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you remove the key, and close the driver’s door.

u

 You can change the headlight auto off timer setting.

2 Customized Features P. 79

If you turn the ignition switch to LOCK

 (

0  with the headlight switch on, but do not

open the door, the lights turn off after 10 minutes (3 minutes, if the switch is in the
AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

■

Automatic Operation (automatic lighting control)

1

Automatic Operation (automatic lighting control)

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Adjust the auto light sensitivity as follows:

Setting

The exterior lights come on

when the ambient light is at

MAX

HIGH

MID

LOW

MIN

Light Sensor

Bright

Dark

14 ACURA TSX 5D-31TL76300.book  108 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

109

uu

Operating the Switches Around the Steering Wheel

u

Fog Lights

Fog Lights

When the low beam headlights are on, turn
the fog light switch on to use the fog lights.

Daytime Running Lights (DRL)

The high beam headlights come on slightly dimmer than normal when the following
conditions have been met:

• The ignition switch is in ON

 (

w .

• The headlight switch is off, or in

.

• The parking brake is released.

The lights remain on even if you set the parking brake. Turning off the ignition
switch will turn off the daytime running lights.

The high beam headlights return to the original brightness once the headlight
switch is turned on.

1

Fog Lights

When the fog lights are on, the indicator in the
instrument panel will be on.

2 Indicators P. 64

Fog Light Switch

14 ACURA TSX 5D-31TL76300.book  109 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

110

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

Wipers and Washers

The windshield wipers and washers can be
used when the ignition switch is in ON

 (

w .

■

MIST

The wipers run at high speed until you release
the lever.

■

Wiper switch (OFF, INT, LO, HI)

Change the wiper switch setting according to
the amount of rain.

■

Adjusting the delay

Turn the adjustment ring to adjust the
wiper delay.

■

Washer

Sprays while you pull the lever toward you.
When you release the lever, the wipers make
two or three more sweeps before stopping.

■

Windshield Wiper/Washer

1

Wipers and Washers

NOTICE

Do not use the wipers when the windshield is dry.
The windshield will get scratched, or the rubber
blades will get damaged.

NOTICE

In cold weather, the blades may freeze to the
windshield, becoming stuck.

Operating the wipers in this condition may damage
the wipers. Use the defroster to warm the
windshield, then turn the wipers on.

If the vehicle speeds up while the wipers are
operating intermittently, the length of the wipe
interval shortens. When the vehicle starts moving, the
wipers make a single sweep.

When the vehicle speeds up, the wiper operation's
shortest delay setting (   ) and the LO setting
become the same.

Turn the washers off if no washer fluid comes out.
The pump may get damaged.

Intermittent Time
Adjustment Ring

MIST

Pull to
use
washer.

OFF
INT: Low speed with
intermittent

LO: Low speed wipe

HI: High speed wipe

Long delay

Short delay

14 ACURA TSX 5D-31TL76300.book  110 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

111

uu

Operating the Switches Around the Steering Wheel

u

Wipers and Washers

The rear wiper and washer can be used when
the ignition switch is in ON

 (

w .

■

Wiper switch (OFF, ON)

The wiper operates intermittently after
completing a few sweeps.

■

Washer (

)

Sprays while you rotate the switch to
this position.

Hold it to activate the wiper and to spray the
washer. Once released, it stops operating
after a few more sweeps.

■

Operating in reverse

When you shift the transmission to

 (

R  with the front wiper activated, the rear wiper

operates automatically as follows even if its switch is off.

■

Rear Wiper/Washer

1

Wipers and Washers

If the wiper stops operating due to any obstacle such
as the build-up of snow, park the vehicle in a safe
place.

Rotate the wiper switch to OFF, and turn the ignition
switch to ACCESSORY

 (

q

 or LOCK

 (

0

, then remove

the obstacle.

The wiper motor is equipped with a breaker that may
stop motor operation temporarily to prevent an
overload. Wiper operation will return to normal
within a few minutes, once the circuit has returned to
normal.

ON: Intermittent

OFF

Washer

Front Wiper Position

Rear Wiper Operation

INT (Intermittent)

Intermittent

LO (Low speed wipe)
HI (High speed wipe)

Continuous

14 ACURA TSX 5D-31TL76300.book  111 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

112

uu

Operating the Switches Around the Steering Wheel

u

Brightness Control

Brightness Control

When the parking lights are turned on and the
ignition switch is in ON

 (

w , you can use the

brightness control knob to adjust instrument
panel brightness.

Brighten: Turn the knob to the right.

Dim: Turn the knob to the left.

You will hear a beep when the brightness
reaches minimum or maximum. The multi-
information display will return to its original
state several seconds after you adjust the
brightness.

■

Brightness level indicator

The brightness level is shown on the multi-
information display while you are adjusting it.

1

Brightness Control

Instrument panel brightness varies, depending on
whether the exterior lights are on or off. The
instrument panel dims to reduce glare when they are
on.

Pressing either

 (information) button

switches the display.

If you turn the knob to the right until the brightness
display is up to max, the beeper sounds. This cancels
the reduced instrument panel brightness when the
exterior lights are on.

The brightness can be set differently for when the
exterior lights are on, and when they are off.

Control Knob

14 ACURA TSX 5D-31TL76300.book  112 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

113

uu

Operating the Switches Around the Steering Wheel

u

Rear Defogger/Heated Door Mirror Button

Rear Defogger/Heated Door Mirror Button

Press the rear defogger and heated door
mirror button to defog the rear window and
mirrors when the ignition is in ON

 (

w .

The rear defogger and heated door mirrors
automatically switch off after 10-30 minutes
depending on the outside temperature.
However, if the outside temperature is 32°F
(0°C) or below, they do not automatically
switch off.

1

Rear Defogger/Heated Door Mirror Button

NOTICE

When cleaning the inside of the rear window, be
careful not to damage the heating wires.

It is critical to wipe the window from side to side
along the defogger heating wires.

This system consumes a lot of power, so turn it off
when the window has been defogged.

Also, do not use the system for a long period when
the engine is idling. This may weaken the battery,
making it difficult to start the engine.

14 ACURA TSX 5D-31TL76300.book  113 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

114

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

Driving Position Memory System

You can store two driver’s seat positions with the driving position memory system.
When you unlock and open the driver’s door with a remote transmitter, the seat
adjusts automatically to one of the two preset positions.

The multi-information display shows you which remote transmitter you used to
unlock the vehicle when you enter.
• DRIVER 1 transmitter is linked to memory button

 (

1 .

• DRIVER 2 transmitter is linked to memory button

 (

2 .

1

Driving Position Memory System

Using the multi-information display, you can disable
the automatic seat adjustment function.

2 Customized Features P. 79

DRIVER 1

DRIVER 2

14 ACURA TSX 5D-31TL76300.book  114 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

115

uu

Operating the Switches Around the Steering Wheel

u

Driving Position Memory System

1. Adjust the driver’s seat to the

desired  position, and turn the ignition
switch to ON



(

w

 .

2. Press the SET button.

u

You will hear the beeper, and the
memory button indicator light will blink.

3. Press memory button

 (

1  or

 (

2  within five

seconds of pressing the SET button.

u

Once the seat position has been
memorized, the indicator light on the
button you pressed stays on.

1. Move the shift lever to

 (

P .

2. Apply the parking brake.

3. Press a memory button (

 (

1  or

 (

2 ).

u

You will hear the beeper, and the
indicator light will blink.

The seat will automatically move to the
memorized position. When it has finished
moving, you will hear the beeper, and the
indicator light stays on.

■

Storing a Position in Memory

1

Storing a Position in Memory

After you press the SET button, the storing operation
will be canceled when:

•

You do not press the memory button within five
seconds.

•

You readjust the seat position before the double-
beep.

•

You turn the ignition switch to any position except
ON

 (

w

.

Memory Button 1

Memory Button 2

Set Button

■

Recalling the Stored Position

1

Recalling the Stored Position

The seat will stop moving if you:

•

Press the SET button, or a memory button (



(

1

 or

 (

2

).

•

Adjust the seat position.

•

Shift into any position except

 (

P

.

Memory Buttons

14 ACURA TSX 5D-31TL76300.book  115 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

116

uu

Operating the Switches Around the Steering Wheel

u

Adjusting the Steering Wheel

Adjusting the Steering Wheel

The steering wheel height and distance from your body can be adjusted so that you
can comfortably grip the steering wheel in an appropriate driving posture.

1. Pull the steering wheel adjustment lever up.

u

The steering wheel adjustment lever is
under the steering column.

2. Move the steering wheel up or down, and

in or out.

u

Make sure you can see the instrument
panel gauges and indicators.

3. Push the steering wheel adjustment lever

down to lock the steering wheel in position.

u

After adjusting the position, make sure
you have securely locked the steering
wheel in place by trying to move it up,
down, in, and out.

1

Adjusting the Steering Wheel

Make any steering wheel adjustments before you
start driving.

3

WARNING

Adjusting the steering wheel position while
driving may cause you to lose control of the
vehicle and be seriously injured in a crash.

Adjust the steering wheel only when the
vehicle is stopped.

To adjust

To lock

Lever

14 ACURA TSX 5D-31TL76300.book  116 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon
