133

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Continued

Located on the side panel in the cargo area.
Pull up the handle and remove the lid.

■

Side Storage Compartment

Handle

14 ACURA TSX 5D-31TL76300.book  133 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

134

■

Front seat beverage holders

Press the raised detent to open the lid. To
close the lid, push it down until it latches.

■

Rear seat beverage holders

Fold the armrest down to use the rear seat
beverage holders.

■

Beverage Holders

1

Beverage Holders

NOTICE

Spilled liquids can damage the upholstery, carpeting,
and electrical components in the interior.

Be careful when you are using the beverage holders.
Hot liquid can scald you.

Push

14 ACURA TSX 5D-31TL76300.book  134 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

Continued

135

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

There are three accessory power sockets; one
in the console compartment, one in the front
of the center console, and one in the left side
panel in the cargo area.They can be used
when the ignition switch is in ACCESSORY

 (

q

or ON

 (

w .

Open the cover to use it.

■

Accessory Power Sockets

1

Accessory Power Sockets

NOTICE

Do not insert an automotive type cigarette lighter
element.
This can overheat the power socket.

NOTICE

Do not operate the tire repair kit compressor for
more than 15 minutes. The accessory power socket
and compressor can overheat and become
permanently damaged.

The accessory power socket is designed to supply
continuous electrical power for 12 volt DC
accessories that are rated 120 watts or less (10
amps).

To prevent battery drain, only use the power socket
with the engine running.

14 ACURA TSX 5D-31TL76300.book  135 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

136

There is a coat hook on the rear grab handle
of both sides. Pull it down to use it.

■

Coat Hooks

1

Coat Hooks

The coat hooks are not designed for large or heavy
items.

14 ACURA TSX 5D-31TL76300.book  136 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

Continued

137

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

Use the tie-down anchors to secure luggage in
the cargo area.

The cargo hooks on both sides of the luggage
area can be used to hang a light items.

■

Tie-down Anchors

Anchors

■

Cargo Hooks

1

Cargo Hooks

NOTICE

Do not hang a large object or an object that weighs
more than 6lbs (3kg) on the side cargo hooks.
Hanging heavy or large objects may damage the
hooks.

Hooks

14 ACURA TSX 5D-31TL76300.book  137 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

138

To open the sunglasses holder, push and
release the indent. To close, push it again until
it latches.

You can store eyeglasses and other small
items in this holder.

■

Sunglasses Holder

1

Sunglasses Holder

Keep the holder closed while driving except when
accessing stored items.

Push

14 ACURA TSX 5D-31TL76300.book  138 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

Continued

139

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

The ignition switch must be in ON

 (

w  to use

the seat heaters. The HI setting heats the seats
faster than the LO setting.

There is no heater in the passenger’s seat-
back due to the side airbag cutoff system.

While in HI, the heater cycles on and off.

u

The appropriate indicator will be on
while the seat heater is on. Briefly
press the button on the opposite side
to turn the heater off. The indicator
will be off. When a comfortable
temperature is reached, select LO to
keep the seat warm.

■

Seat Heaters

1

Seat Heaters

Do not use the seat heaters even in LO when the
engine is off. Under such conditions, the battery may
be weakened, making the engine difficult to start.

In the LO setting, the heater runs continuously and
does not automatically turn off.

3

WARNING

Heat induced burns are possible when
using seat heaters.

Persons with a diminished ability to sense
temperature (e.g., persons with diabetes,
lower-limb nerve damage, or paralysis) or
with sensitive skin should not use seat
heaters.

14 ACURA TSX 5D-31TL76300.book  139 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Interior Lights/Interior Convenience Items

u

Interior Convenience Items

140

The tonneau cover can be used to
conceal your parcels and protect them
from direct sunlight.

■

To extend:

Pull the handle on the center edge, then clip
the mounting rods in the hooks on both sides
of the hatch opening.

■

To retract:

Slip the rods out of the hooks, then slowly roll
it back until it is completely retracted.

■

To remove:

Push either end of the housing inward, then
lift it out of its position.

■

Tonneau Cover

1

Tonneau Cover

Do not access parcels in the cargo area while driving.
This may cause injury if you have to brake hard.

Do not stack objects higher than the top of the seat
in the cargo area. They could block your view and be
thrown about the vehicle during a sudden stop.

To prevent tonneau cover damage:

•

Do not place items on the tonneau cover.

•

Do not put weight on the tonneau cover.

Handle

Hook

Mounting Rod

14 ACURA TSX 5D-31TL76300.book  140 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

141

Continued

Climate Control System

Using Automatic Climate Control

The automatic climate control system maintains the interior temperature you select.
The system also selects the proper mix of heated or cooled air that raises or lowers
the interior temperature to your preference as quickly as possible.

Use the system when the engine is running.
1. Press the AUTO button.

2. Adjust the interior temperature using the driver’s side or passenger’s side control

switch.

3. Press the

 button to cancel.

■

Switching between the recirculation and fresh air modes

Press the

 (recirculation) button and switch the mode depending on

environmental conditions.

Recirculation mode (indicator on): Recirculates air from the vehicle’s interior through
the system.

Fresh air mode (indicator off): Maintains outside ventilation. Keep the system in
fresh air mode in normal situations.

1

Using Automatic Climate Control

If any buttons are pressed while using the climate
control system in AUTO, the function of the button
that was pressed will take priority.

The AUTO indicator will go off, but functions
unrelated to the button that was pressed will be
controlled automatically.

To prevent cold air from blowing in from outside, the
fan may not start immediately when the AUTO
button is pressed.

If the interior is very warm, you can cool it down
more rapidly by partially opening the windows,
turning the system on AUTO, and setting the
temperature to low. Change the fresh air mode to
recirculation mode until the temperature cools down.

When you set the temperature to the lower or upper
limit, Lo or Hi is displayed.

Pressing the

 button switches the climate

control system between on and off. When turned on,
the system returns to your last selection.

Floor and
defroster
vents

Floor vents

Dashboard and floor
vents, and back of
the center console

Dashboard vents
and back of the
center console

AUTO Button

Driver’s Side
Temperature
Control Switch

 (Recirculation) Button

 (Fan Control) Bar

A/C (Air Conditioning)
Button

Passenger’s Side
Temperature
Control Switch

14 ACURA TSX 5D-31TL76300.book  141 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

uu

Climate Control System

u

Using Automatic Climate Control

142

Pressing the

 button turns the air

conditioner system on and automatically
switches the system to fresh air mode.

Press the

 button again to turn off, the

system returns to the previous settings.

■

To rapidly defrost the windows

1. Press the

 button.

2. Press the

 button.

■

Defrosting the Windshield and Windows

1

Defrosting the Windshield and Windows

For your safety, make sure you have a clear view
through all the windows before driving.

Do not set the temperature near the upper or lower
limit.

When cold air hits the windshield, the outside of the
windshield may fog up.

If the side windows fog up, adjust the vents so that
the air hits the side windows.

1

To rapidly defrost the windows

After defrosting or defogging the windows, switch
over to fresh air mode. If you keep the system in
recirculation mode, the windows may fog up from
humidity. This impedes visibility.

14 ACURA TSX 5D-31TL76300.book  142 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

143

uu

Climate Control System

u

Synchronized Mode

Synchronized Mode

You can set the temperature synchronously for the driver side and the passenger
side in synchronized mode.

1. Press the SYNC button.

u

The system will switch to synchronized mode.

2. Adjust the temperature using driver’s side temperature control switch.

Press the SYNC button to return to dual mode.

1

Synchronized Mode

When you press the

 button, the system changes

to synchronized mode.

When the system is in dual mode, the driver side
temperature and the passenger side temperature can
be set separately.

14 ACURA TSX 5D-31TL76300.book  143 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

144

uu

Climate Control System

u

Automatic Climate Control Sensors

Automatic Climate Control Sensors

The automatic climate control system is
equipped with sensors. Do not cover or spill
any liquid on them.

Sensor

Sensor

14 ACURA TSX 5D-31TL76300.book  144 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

C

ont

rol
s

TOC

2014 TSX Sport Wagon

146



Fea

tu

res

Audio System

About Your Audio System

See the Navigation System Manual for operation of the audio system, AcuraLink

*

,

Bluetooth® HandsFreeLink®, and voice commands for these features.

The audio system features AM/FM radio and the XM® Radio service. It can also play
CDs, WMA/MP3/AAC files, USB flash drives, and iPod® and Bluetooth® devices.

You can operate the audio system from the buttons and switches on the panel, or
the remote controls on the steering wheel.

1

About Your Audio System

XM® Radio is available on a subscription basis only.
For more information on XM® Radio, contact a
dealer.

2 General Information on the Audio System



P. 169

XM® Radio is available in the United States and
Canada, except Hawaii, Alaska, and Puerto Rico.

XM® is a registered trademark of Sirius XM Radio, Inc.

Video CDs, DVDs, and 3-inch (8-cm) mini CDs are not
supported.

iPod® is a registered trademark owned by Apple Inc.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

Models with navigation system

Models without navigation system

Remote Control

iPod®

USB Flash
Drive

XM® Radio

* Not available on all models

14 ACURA TSX 5D-31TL76300.book  146 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

TOC

2014 TSX Sport Wagon

147

uu

Audio System

u

USB Adapter Cable

USB Adapter Cable

1. Unclip the USB connector and loosen the

adapter cable.

2. Connect the iPod® dock connector or the

USB flash drive to the USB connector.

Audio Antenna

Your vehicle is equipped with a removable
antenna at the rear of the roof.

1

USB Adapter Cable

•

Do not leave the iPod® or USB flash drive in the
vehicle. Direct sunlight and high temperatures may
damage it.

•

Do not use an extension cable with the USB
adapter cable.

•

Do not connect the iPod® or USB flash drive using a
hub.

•

Do not use a device such as a card reader or hard
disk drive, as the device or your files may be
damaged.

•

We recommend backing up your data before using
the device in your vehicle.

•

Displayed messages may vary depending on the
device model and software version.

If the audio system does not recognize the iPod®, try
reconnecting it a few times or reboot the device. To
reboot, follow the manufacturer’s instructions
provided with the iPod® or visit www.apple.com/
ipod.

1

Audio Antenna

NOTICE

Before using a “drive-through” car wash, remove the
antenna by unscrewing it by hand. This prevents the
antenna from being damaged by the car wash
brushes.

14 ACURA TSX 5D-31TL76300.book  147 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Fea

tu

res

TOC

2014 TSX Sport Wagon

148

uu

Audio System

u

Auxiliary Input Jack



Auxiliary Input Jack

Use the jack in the console compartment to connect standard audio devices.

1. Open the AUX cover.

2. Connect a standard audio device to the

input jack using a 1/8 inch (3.5 mm)

stereo miniplug.

u

The audio system automatically switches
to the AUX mode.

Audio System Theft Protection

The audio system is disabled when it is disconnected from the power source, such as
when the battery is disconnected or goes dead.

■

Entering the audio security code

ENTER CODE appears on the display when the power is reconnected.

1. Turn on the audio system.

2. Enter the audio security code using the preset buttons. If you enter an incorrect

digit, continue to the last digit, then try again. If you do not enter the code
correctly after 10 tries, you need to visit a dealer to have the system reset.

1

Auxiliary Input Jack

To switch the mode, press any of the audio mode
buttons. You can return to the AUX mode by
pressing the AUX button.

You cannot use the auxiliary input jack if you replace
the audio system.

State or local laws may prohibit the operation of
handheld electronic devices while operating a
vehicle.

1

Audio System Theft Protection

Find the audio system’s security code and serial
number on the radio code card.

Do not store the card in your vehicle. If you lose the
radio code card, you must obtain the information
from a dealer.

You can register the security code at Acura Owners
(owners.acura.com.), and find information on how to
retrieve the serial number and obtain the code at
radio-navicode.acura.com.

14 ACURA TSX 5D-31TL76300.book  148 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Fea

tu

res

TOC

2014 TSX Sport Wagon

149

Audio System Basic Operation

To use the audio system function, the ignition switch must be in ACCESSORY

 (

q  or

ON

 (

w .

Use the selector knob or MENU button to
access some audio functions.

Press

 to switch between the normal and

extended display for some functions. The
extended display has three segments to
display detailed information.

Selector knob: Rotate left or right to scroll
through the available choices. Press

 to set

your selection.

MENU button: Press to select any setting
such as the clock, sound control, or the
compass. Press this button again to cancel the
menu display mode.

RETURN button: Press to go back to the
previous display.

1

Audio System Basic Operation

These indications are used to show how to operate
the selector knob.

Rotate

 to select.

Press

 to ENTER.

RETURN



Button

Selector
Knob

MENU



Button

Menu Display

14 ACURA TSX 5D-31TL76300.book  149 ページ  ２０１３年６月１７日　月曜日　午後３時２１分

QRG

Index

Fea

tu

res

TOC

2014 TSX Sport Wagon
