TCS Switch
TCS Control Unit
Test
1. Remove the TCS/CRUISE switch from the switch
panel.
Replacement
TCS/CRUISE SWITCH
2. Check for continuity between terminal No. 1 and
No. 2 (Illumination light circuit) and between termi-
nal No. 3 and No. 4 (switch circuit).
There should be continuity when the switch is
pushed, and there should be no continuity when the
switch is released.
1. Remove the rear seat-back (see
).
2. Disconnect the connectors from TCS control unit.
TCS CONTROL UNIT
3. Remove the three bolts and the TCS control unit.
4. Install in the reverse order of removal.
