Kia Sedona (2008 year). Manual - part 397

Courtesy of KIA MOTORS AMERICA, INC.

3. Disconnect the lock rod (A) and outside handle rod (B).

Fig. 55: Identifying Lock Rod And Outside Handle Rod
Courtesy of KIA MOTORS AMERICA, INC.

4. Loosen the door module mounting bolts, then remove the door module (A).

Fig. 56: Identifying Door Module, Bolts, Nut And Screws And Torque Specifications



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 40

© 2006 Mitchell Repair Information Company, LLC.

Courtesy of KIA MOTORS AMERICA, INC.

5. Installation is the reverse of removal.

OUTSIDE HANDLE REPLACEMENT

1. Remove the door trim. See REPLACEMENT.

2. Remove the door trim seal.

3. Disconnect the connector (A).

Fig. 57: Identifying Connector
Courtesy of KIA MOTORS AMERICA, INC.

4. Disconnect the lock rod (A) and outside handle rod (B).

NOTE:



Make sure the connector is plugged in properly and each rod is
connected securely.



Make sure the door locks and opens properly.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 41

© 2006 Mitchell Repair Information Company, LLC.

Fig. 58: Identifying Lock Rod And Outside Handle Rod
Courtesy of KIA MOTORS AMERICA, INC.

5. Loosen the outside handle mounting bolts, remove the outside handle bracket (A).

Fig. 59: Identifying Outside Handle Bracket, Bolts And Torque Specifications
Courtesy of KIA MOTORS AMERICA, INC.

6. After removing the outside handle mounting bolts, remove the outside handle (A).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 42

© 2006 Mitchell Repair Information Company, LLC.

Fig. 60: Identifying Outside Handle, Bolt And Torque Specifications
Courtesy of KIA MOTORS AMERICA, INC.

7. Installation is the reverse the removal.

DOOR BELT WEATHERSTRIP REPLACEMENT

1. Loosen the mounting screw, then remove the door belt weather strip (A).

NOTE:



Make sure the door locks and opens properly.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 43

© 2006 Mitchell Repair Information Company, LLC.
