Fig. 61: Identifying Door Belt Weather Strip And Screw
Courtesy of KIA MOTORS AMERICA, INC.

2. Installation is the reverse of removal.

REAR CHANNEL REPLACEMENT

1. Remove the door trim. See REPLACEMENT.

2. Remove the glass. See GLASS REPLACEMENT.

3. Loosen the rear channel mounting nuts.

4. After disconnecting the glass molding, remove the rear channel (A).



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 44

© 2006 Mitchell Repair Information Company, LLC.

Fig. 62: Identifying Rear Channel, Nuts And Torque Specifications
Courtesy of KIA MOTORS AMERICA, INC.

5. Installation is the reverse of removal.

DOOR WEATHERSTRIP REPLACEMENT

1. Loosen the checker mounting bolts.

2. Release the clips then remove the door weatherstrip (A).

Fig. 63: Identifying Door Weatherstrip
Courtesy of KIA MOTORS AMERICA, INC.

3. Installation is the reverse of removal.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 45

© 2006 Mitchell Repair Information Company, LLC.

POWER WINDOW SWITCH REPLACEMENT

1. Remove the front door trim. See REPLACEMENT.

2. Loosen the mounting screws (B).

3. Disconnect the connector (A).

Fig. 64: Identifying Connector And Screws
Courtesy of KIA MOTORS AMERICA, INC.

4. Remove the power window switch (A).

Fig. 65: Identifying Power Window Switch
Courtesy of KIA MOTORS AMERICA, INC.



2008 Kia Sedona EX

2008 ACCESSORIES & BODY, CAB Exterior - Sedona



Microsoft



Monday, May 24, 2010 4:07:09 PM

Page 46

© 2006 Mitchell Repair Information Company, LLC.

5. Installation is the reverse the removal.

ADJUSTMENT

GLASS ADJUSTMENT

1. Remove the following parts.



Quadrant cover



Door trim.

2. Carefully move the glass until you can see the glass mounting bolts, then loosen them.

3. Check that the glass moves smoothly.

4. Raise the glass fully, and check for gaps.

Check that the glass contacts the glass run channel evenly.

5. Check for water leaks. See Fig. 66. Run water over the roof and on the sealing area and note these items:



Use a 12 mm (1/2 in.) diameter hose (A).



Adjust the rate of water flow as shown (B) in illustration.



Do not use a nozzle.



Hold the hose about 300 mm (12 in.) away from The door (C).

Fig. 66: Checking For Water Leaks
Courtesy of KIA MOTORS AMERICA, INC.

DOOR POSITION ADJUSTMENT

NOTE:



Check the glass run channel for damage or deterioration, and replace
them necessary.
