119

Features of your vehicle

Forward/Reverse Parking Distance Warning (PDW)

(18 mph), the function will turn off
(button indicator light off).

• Although you drive below 30 km/h (18

mph) again, the function will not turn
on. If necessary, press the Parking
Safety (

) button.

• When an obstacle is detected, it is dis

played on the cluster and infotain

ment system screen.

• When more than two objects are

detected at the same time, the closest
one will be warned with an audible
warning.

Types of warning sound and indicator

• The corresponding indicator will

appear whenever each ultrasonic
senor detects an object in its sensing
range.

• Only the front ultrasonic sensors warn

the driver when moving forward. The
rear and front sensors warn the driver
when moving backward. However, the
object must be within 60 cm (24
inches) from the front-side sensors to
operate.

• If an object is within 30 cm (12 inches)

from the ultrasonic sensors, the sen

sors may not detect the object, or a
sensor out of the detecting range may
warn the driver.

• Distance warning may not occur

sequentially depending on vehicle
speed or obstacle shape.

• Indicators and warning sounds may

differ from the illustration when
obstacles are located in the center of
the sensor, obstacles are located in
close proximity to the vehicle, or in
various circumstances.

• The shape of the indicator in the illus

tration may differ from the actual
vehicle.

Distance from object

Warning indicator

Warning sound

Driving forward

Driving backward

60 ~ 100 cm

(24 ~ 40

inches)

Front

Buzzer beeps intermittently

60 ~ 120 cm

(24 ~ 48

inches)

Rear

Buzzer beeps intermittently

30 ~ 60 cm

(12 ~ 24

inches)

Front

Beeps more frequently

Rear

within 30 cm

(12 inches)

Front

Beeps continuously

Rear

CarManuals2.com

Features of your vehicle

120

Forward/Reverse Parking Distance Warning (PDW)

Forward/Reverse Parking Dis

tance Warning Malfunction and
Precautions

Forward/Reverse Parking Dis

tance Warning malfunction

Forward/Reverse Parking Distance
Warning has a self-diagnosis function
that can determine whether the ultra

sonic sensor is working properly. After
starting the engine, a beep will sound
when the gear is shifted to R (Reverse)
to indicate the function is operating nor

mally.

However, if one or more of the following
occurs, first check whether the ultra

sonic senior is damaged or whether the
function is in a non-operating condition. If
it still does not work properly, have your
vehicle inspected by an authorized Kia
dealer.
• The audible warning does not sound.

僅

The buzzer sounds intermittently.

• The 'Ultrasonic sensor error or block

age' warning message appears on the
cluster.

Precautions of Forward/Reverse
Parking Distance Warning

• Forward/Reverse Parking Distance

Warning may malfunction if the vehi

cle bumper height or ultrasonic sen

sor installation has been modified or
damaged. Any non-factory installed
equipment or accessories may also
interfere with the sensor perfor

mance.

• When the ultrasonic sensor is frozen

or covered with snow, dirt, or water,
the sensor may not operate until the
degree has been removed using a
soft cloth.

• Do not push, scratch or strike the

ultrasonic sensor. Sensor damage
could occur.

• Do not spray the ultrasonic sensors or

its surrounding area directly with a
high pressure washer.

OMQ4A041557

CarManuals2.com

121

If the driver exits the vehicle through
another door besides the driver door,
the battery saver function does not
operate and the headlamp delay func

tion does not turn OFF automatically.

This may cause the battery to discharge.
To avoid battery discharge, turn OFF the
headlamps manually from the headlamp
switch before exiting the vehicle.

Features of your vehicle

Lighting

This vehicle is equipped with a variety of
lights to illuminate the interior and exte

rior of the vehicle.

CAUTION

To prevent the battery from being dis

charged, do not leave the headlamp and
interior light on for a prolonged time while
the engine is not running.

Battery saver function

The purpose of this feature is to prevent
the battery from being discharged if the
lights are left in the ON position. The
system automatically shuts off the park

ing lights after the engine is off and the
driver's door is opened.

However, the position lamps stay ON
even when the driver-side door is
opened if the light switch is operated
after the engine is turned off.

If necessary, to keep the lamps on turn
the position lamps OFF and ON again
using the headlamp switch on the steer

ing column after the engine is turned off.

Headlamp delay function

If you place the ignition switch or
ENGINE START/STOP button in the
ACC or OFF position with the headlamps
ON, the headlamps (and/or parking
lights) remain on for about 5 minutes.
How

ever, with the engine off if the

driver's door is opened and closed, the
head

lamps (and/or parking lights) are

turned off after 15 seconds.

The headlamps (and/or parking lights)
can be turned off by pressing the lock
button on the remote key or smart key
twice or turning the light switch to the
OFF or AUTO position. However, if you
turn the light switch to the AUTO posi

tion when it is dark outside, the head

lamps will not be turned off.

You can activate or deactivate the Head

lamp Delay function from the User Set

tings Mode in the LCD display. For more
details, refer to "User settings mode" on
page 4-82. If your vehicle is equipped
with additional navigation, please refer to
the infotainment system manual sep

arately supplied.

NOTICE

Daytime Running Light (DRL) (if
equipped)

The Daytime Running Light (DRL) can
make it easier for others to see the front
of your vehicle during the day.

The DRL can be helpful in many differ

ent driving conditions, and it is especially
helpful after dawn and before sunset.

The DRL will turn the dedicated lamp
OFF when:
• The headlamps are ON.

僅

The vehicle is off.

• The front fog light is on. (if equipped)

僅

Engaging the parking brake.

Lighting control

The light switch has a headlamp and a
position lamp position.

CarManuals2.com

Features of your vehicle

122

Lighting

To operate the lights, turn the knob at
the end of the control lever to one of the
following positions:

1. OFF position

2. Auto light position

3. Position & Tail lamp

4. Headlamp position

Auto head lamp (OFF position)

The lights turn on or off depending on
the amount of daylight detected from the
sensor when the parking brake is not
activated or vehicle speed is above 5
km/h (3 mph).

Activating the parking brake when the
vehicle speed is less than 5 km/h (3
mph) turns the headlamps off automati

cally by the amount of daylight detected
from the sensor.

AUTO headlamp position

The parking lamp and headlamp will be
turned ON or OFF automatically
depending on the amount of daylight as
measured by the ambient light sensor on
the center dashboard.

NOTICE

Even with the AUTO headlamp feature
in operation, it is recommended to man

ually turn ON the headlamps when driv

ing at night or in a fog, driving in the rain,
or when you enter dark areas, such as
tunnels and parking facilities.
• Do not cover or spill anything on the

sensor located in front of the instru

ment panel.

• Do not clean the sensor using a win

dow cleaner, the cleanser may leave a
light film which could interfere with
sensor operation.

• If your vehicle has window tint or other

types of metallic coating on the front
windshield, the AUTO headlamp
system may not work properly.

OMQ4AH040051

OKA4040580CF

OMQ4AH040059

CarManuals2.com

123

Features of your vehicle

Lighting

Position & Taillamp

When the light switch is in the lamp posi

tion, the front position lamp, taillamp, and
the license plate lamp will turn ON.

Headlamp (Low Beam)

When the light switch is in the headlamp
position, headlamp (low beam), tail,
license light will turn ON.

• Never place anything over the sensor

(1) located on the instrument panel as
this will ensure better auto-light sys

tem control.

• Don't clean the sensor using a window

cleaner, the cleaner may leave a light
film which could interfere with sensor
operation.

• If your vehicle has window tint or other

types of metallic coating on the front
windshield, the Auto light system may
not work properly.

NOTICE

The ignition switch or ENGINE START/
STOP button must be in the ON position
to turn on the headlamps.

Auto light

When the light switch is in the AUTO
light position, the taillamps and head

lamps will turn ON or OFF automatically
depending on the amount of light out

side the vehicle.

CAUTION

OMQ4AH040055

OMQ4AH040053

OMQ4AH040052

CarManuals2.com

Features of your vehicle

124

Lighting

Operating high beam

To turn on the high beam headlamp:

僅

Push the lever away from you.

The lever will return to its original
position.

The high beam indicator will light
when the headlamp high beams are
switched on.

W ARNING

High beams
Do not use high beam when there are
other vehicles in front of or approaching
your vehicle. Using high beam could
obstruct the other driver's vision.

To flash the headlamps:
• Pull the lever towards you.

It will return to the normal (low beam)
position when released. The head

lamp switch does not need to be on to
use this flashing feature.

Operating turn signals and lane
change signals

The ENGINE START/STOP button
must be on for the turn signals to
function.

To turn on the turn signals:
• Move the lever up or down (A).

The green arrow indicators on the
instrument panel indicate which turn
signal is operating.

They will self-cancel after a turn is
completed. If the indicator continues
to flash after a turn, manually return
the lever to the OFF position.

To signal a lane change:
• Move the turn signal lever slightly and

hold it in position (B).

The lever will return to the OFF posi

tion when released.

If an indicator stays on and does not
flash or if it flashes abnormally, one of the
turn signal bulbs may be burned out and
will require replacement.

One-touch lane change function

To activate a one-touch lane change
function, move the turn signal lever

OMQ4AH040056

OMQ4AH040054

OMQ4AH040057

CarManuals2.com

125

Features of your vehicle

Lighting

slightly and then release it. The lane
change signals will blink 3, 5 or 7 times.

You can activate or deactivate the One
Touch Turn Signal function or choose
the number of blinking (3, 5, or 7) by
selecting "User Settings

→Lights → One

Touch Turn Signal".

NOTICE

If an indicator flash is abnormally quick
or slow, a bulb may be burned out or
have a poor electrical connection in the
circuit. The bulb may require replace

ment.

Operating front fog light

(if

equipped)

Fog lights are designed to provide
improved visibility when visibility is poor
due to fog, rain or snow, etc.

The fog lights will turn on when the fog
light switch (1) is turned to the on posi

tion after the headlamp is turned on.

To turn off the fog lights:
• Turn the fog light switch (1) to the ON

position.

CAUTION

When in operation, the fog lights con

sume large amounts of vehicle electrical

power. Only use the fog lights when visi

bility is poor.

High Beam Assist (HBA)

High Beam Assist is a function that auto

matically adjusts the headlamp range
(switches between high beam and low
beam) depending on the brightness of
detected vehicles and certain road con

ditions.

Detecting sensor

Front view camera

The front view camera is used as a
detecting sensor to detect ambient light
and brightness while driving.

Refer to the picture above for the detailed
location of the detecting sensor.

OMQ4AH040058

OMQ4AH040059

OMQ4051078

CarManuals2.com

Features of your vehicle

126

Lighting

NOTICE

• Always keep the front view camera in

good condition to maintain optimal
performance of High Beam Assist.

• For more details on the precautions of

the front view camera, refer to"For

ward Collision-Avoidance Assist (FCA)
(Front view camera only) (if equipped)"
on page 5-62.

High Beam Assist setting

With the ENGINE START/STOP button
in the ON position, select 'Lights

→ High

Beam Assist' from the Settings menu to
turn on High Beam Assist and deselect
to turn off the function.

W ARNING

For your safety, adjust your high beam
settings only after parking the vehicle at
a safe location.

High Beam Assist operation

Display and control

• After selecting 'High Beam Assist' in

the Settings menu, High Beam Assist
will operate by following the proce

dure below.

- Place the headlamp switch in the

AUTO position and push the head

lamp lever towards the instrument

cluster. The High Beam Assist (

)

indicator light will illuminate on the
cluster and the function will be
enabled.

- When the function is enabled, high

beam will turn on when vehicle
speed is above 40 km/h (25 mph).
When vehicle speed is below 25
km/h (15 mph), high beam will not
turn on.

- The High Beam (

) indicator light

will illuminate on the cluster when
high beam is on.

• When High Beam Assist is operating,

if the headlamp lever or switch is
used, the function operates as follows:

- If the headlamp lever is pulled

towards you when the high beam is
off, the high beam will turn on with

out High Beam Assist canceled.
When you let go of the headlamp
lever, the lever will move to the
middle and the high beam will turn
off.

- If the headlamp lever is pulled

towards you when the high beam is
on by High Beam Assist, low beam
will be on and the function will turn
off.

- If the headlamp switch is placed

from AUTO to another position
(headlamp/position/off), High
Beam Assist will turn off and the
corresponding lamp will turn on.

• When High Beam Assist is operating,

high beam switches to low beam if
any of the following conditions occur:

- When the headlamp of an oncom

ing vehicle is detected.

- When the taillamp of a vehicle in

front is detected.

- When the headlamp or taillamp of a

motorcycle or a bicycle is detected.

- When the surrounding ambient

light is bright enough that high
beams are not required.

- When streetlights or other lights are

detected.

CarManuals2.com

127

Features of your vehicle

Lighting

Malfunction and limitations

Malfunction

When High Beam Assist is not working
properly, the 'Check High Beam Assist
(HBA) system' warning message will

appear and warning light (

) will illu

minate on the cluster. Have the function
be inspected by an authorized Kia
dealer.

Limitations

High Beam Assist may not work properly
in the following situations:
• Light from a vehicle is not detected

because of lamp damage, or because
it is hidden from sight, etc.

• Headlamp of a vehicle is covered with

dust, snow or water.

• A vehicle's headlamps are off but the

fog lamps are on and etc.

• There is a lamp that has a similar

shape as a vehicle's lamp.

• Headlamps have been damaged or

not repaired properly.

• Headlamps are not aimed properly.

僅

Driving on a narrow curved road,
rough road, uphill or downhill.

• Vehicle in front is partially visible on a

crossroad or curved road.

• There is a traffic light, reflecting sign,

flashing sign or mirror ahead.

• There is a temporary reflector or flash

ahead (construction area).

• The road conditions are bad such as

being wet, iced or covered with snow.

• A vehicle suddenly appears from a

curve.

• The vehicle is tilted from a flat tire or

is being towed.

• Light from a vehicle is not detected

because of exhaust fume, smoke, fog,
snow, etc.

NOTICE

For more details on the limitations of the
front view camera, refer to "Forward Col

lision-Avoidance Assist (FCA) (Front view
camera only) (if equipped)" on page 5-
62.

NOTICE

• At times, High Beam Assist may not

work properly. The function is for your
convenience only. It is the responsibil

ity of the driver for safe driving prac

tices and always check the road
conditions for your safety.

• When High Beam Assist does not

operate normally, change the head

lamp position manually between high
beam and low beam.

OMQ4HQ010031L

CarManuals2.com

Features of your vehicle

128

Wipers and washers

The wipers and washers remove foreign
substances from the windshield and rear
window, helping to maintain visibility.

A: Wiper speed control
• MIST – Single wipe

僅

OFF

– Off

• INT – Intermittent wipe

AUTO*

– Auto control wipe

僅

– Low wiper speed

• HI – High wiper speed
B: Intermittent control wipe time
adjustment/Auto control wipe time
adjustment*

C: Wash with brief wipes (Pull lever
towards you)

D: Rear wiper/washer control
• HI - Continuous wipe

• LO - Intermittent wipe

僅

OFF - Off

E: Wash with brief wipes (Rear/Push
lever away from you)

*: if equipped

Windshield wipers

Operate as follows when the ignition
switch or ENGINE START/STOP button
is ON.
• MIST: For a single wiping cycle, move

the lever to this position and release it.
The wipers will operate continuously if
the lever is held in this position.

• OFF: Wiper is not in operation
• INT: Wiper operates intermittently at

the same wiping intervals. Use this
mode in light rain or mist. To vary the
speed setting, turn the speed control
knob.

• LO: Normal wiper speed

僅

HI: Fast wiper speed

NOTICE

If there is heavy accumulation of snow or
ice on the windshield, defrost the
windshield for about 10 minutes, or until
the snow and/or ice is removed before
using the windshield wipers to ensure
proper operation. If you do not remove
the snow and/or ice before using the
wiper and washer, it may damage the
wiper and washer system.

W ARNING

Do not use the washer in freezing tem

peratures without first warming the
windshield with the defrosters; the
washer solution could freeze on the
windshield and obscure your vision.

OMQ4040061

OMQ4040062

CarManuals2.com

129

• When washing the vehicle, set the

wiper switch in the OFF position to
stop the auto wiper operation.

The wiper may operate and be dam

aged if the switch is set in the AUTO
mode while washing the vehicle.

• Do not remove the sensor cover

located on the upper end of the pas

senger side windshield glass. Damage
to system parts could occur and may
not be covered by your vehicle war

ranty.

• When starting the vehicle in winter, set

the wiper switch in the OFF posi

tion.

Otherwise, wipers may operate and
ice may damage the windshield wiper
blades. Always remove all snow and
ice and defrost the windshield properly
prior to operating the wind

shield

wipers.

• When tinting the windshield, be care

ful of any fluid getting into the sensor
located in the top center of the front
windshield. It may damage related
parts.

Features of your vehicle

Wipers and washers

Auto control (if equipped)

The rain sensor (A) located on the upper
end of the windshield glass senses the
amount of rainfall and controls the wip

ing cycle for the proper interval. The
more it rains, the faster the wiper oper

ates. When the rain stops, the wiper
stops.

To vary the speed setting, turn the
speed control knob (B).

If the wiper switch is set in AUTO mode
when the ignition switch or ENGINE
START/STOP button is ON, the wiper
will operate once to perform a self-check
of the system. Set the wiper to OFF
position when the wiper is not in use.

W ARNING

When the ignition switch or ENGINE
START/STOP button is ON and the
wind

shield wiper switch is placed in the

AUTO mode, use caution in the following
situations to avoid any injury to the hands
or other parts of the body:
• Do not touch the upper end of the

windshield glass facing the rain sen

sor.

• Do not wipe the upper end of the

windshield glass with a damp or wet
cloth.

• Do not put pressure on the windshield

glass.

CAUTION

OMQ4040064

CarManuals2.com

Features of your vehicle

130

Wipers and washers

Operating windshield washers

1. Move the wiper speed control switch

to the OFF position.

2. Pull the lever gently toward you to

spray washer fluid on the windshield
and to run the wipers 1-3 cycles. Use
this function when the windshield is
dirty. The spray and wiper operation
will continue until you release the
lever.

If the washer does not work, check the
washer fluid level. If the fluid level is not
sufficient, you will need to add appropri

ate non-abrasive windshield washer
fluid to the washer reservoir.

The reservoir filler neck is located in the
front of the engine compartment on the
passenger side.

CAUTION

To prevent possible damage to the
washer pump, do not operate the
washer when the fluid reservoir is
empty.

W ARNING

Do not use the washer in freezing tem

peratures without first warming the
windshield with the defrosters; the

washer solution could freeze on the
windshield and obscure your vision.

CAUTION

• To prevent possible damage to the

wipers or windshield, do not operate
the wipers when the windshield is dry.

• To prevent damage to the wiper

blades, do not use gasoline, kerosene,
paint thinner, or other solvents on or
near them.

• To prevent damage to the wiper arms

and other components, do not attempt
to move the wipers manually.

• To prevent possible damage to the

wipers and washer system, use anti-
freezing washer fluids in the winter
season or cold weather.

Operating rear window wiper and
washer switch

The rear window wiper and washer
switch is located at the end of the wiper
and washer switch lever.
• Turn the switch to the desired position

to operate the rear wiper and washer.

• HI - Normal wiper operation
• LO - Intermittent wiper operation

僅

OFF - Wiper is not in operation

OMQ4040066

OMQ4AH040495

CarManuals2.com

Headlamp (headlamp) escort
function

The headlamps (and/or taillamps)
remain on for approximately 5 minutes
after the ignition key is removed or
turned to the ACC or LOCK position.
However, if the driver's door is opened
and closed, the headlamps are turned
off after 15 seconds.
The headlamps can be turned off by
pressing the lock button on the transmit

ter or smart key twice or turning off the

131

Features of your vehicle

Welcome system

• Push the lever away from you to spray

rear washer fluid and to run the rear
wipers several times.

The spray and wiper operation will con

tinue until you release the lever.

When the front wiper is activated and the
gear is switched to R (Reverse) posi

tion, the rear wiper will be activated once
to provide better visibility.

Welcome system (if equipped)

The welcome system is a function that
illuminates the surroundings or the inte

rior when the driver approaches or exits
the vehicle.

Door handle lamp (if equipped)

When all the doors (and liftgate) are
closed and locked, the door handle lamp
will come on for about 15 seconds if any
of the below is performed.
• When the door unlock button is

pressed on the smart key.

• When the button of the outside door

handle is pressed.

• When the vehicle is approached with

the smart key in possession.

OMQ4040067

OMQ4041050

CarManuals2.com

Features of your vehicle

132

Interior lights

light switch from the headlamp or Auto
light position.

Interior light

When the interior light switch is in the
DOOR position and all doors (and lift

gate) are locked and closed, the room
lamp will come on for 30 seconds if any
of the following occurs:
• With the smart key system

- When the door unlock button is

pressed on the smart key.

- When the button of the outside

door handle is pressed.

At this time, if you press the door lock
button, the lamps will turn off immedi

ately.

Interior lights

This vehicle is equipped with lights
throughout the vehicle to illuminate the
interior.

CAUTION

Do not use the interior lights for extended
periods when the engine is not running.

It may cause battery discharge.

W ARNING

Do not use the interior lights when driv

ing in the dark. Accidents could happen
because the view may be obscured by
interior lights.

Automatic turn off function

The interior lights automatically turn off
approximately 20 minutes after the
ENGINE START/STOP button is
turned off, if the lights are in the ON
position.

If your vehicle is equipped with the theft
alarm system, the interior lights auto

matically turn off approximately 5 sec

onds after the system is armed.

Map lamp

Type A

OMQ4AH040087

CarManuals2.com

133

Features of your vehicle

Interior lights

Type B

• Press the lens (1) to turn ON the map

lamp.

To turn the map lamp OFF press the
lens (1) again.

•

(2): DOOR mode

- The map lamp and room lamp

come on when a door is opened.
The lamps go out after approxi

mately 30 seconds.

- The map lamp and room lamp

come on for approximately 30 sec

onds when doors are unlocked with
a smart key as long as the doors
are not opened.

- The map lamp and room lamp will

stay on for approximately 20 min

utes if a door is opened with the
ENGINE START/STOP button in
the ACC or OFF position.

- The map lamp and room lamp will

stay on continuously if the door is
opened with the ENGINE START/
STOP button in the ON position.

- The map lamp and room lamp will

go out immediately if the ENGINE
START/STOP button is changed
to the ON position or all doors are
locked.

- To turn off the DOOR mode, press

the DOOR button (2) once again
(not pressed).

•

(3): Press this switch to turn the

front and rear room lamps on and off.

NOTICE

The DOOR mode and ROOM mode
can not be selected at a time.

Room lamp (if equipped)

Personal lamp

Press the switch to turn the room lamp
on and off.

Luggage room lamp

•

: The lamp will always turn on

when the liftgate is opened/closed.

OMQ4AH040567

OMQ4040411

OMQ4040412

CarManuals2.com

Features of your vehicle

134

Interior lights

•

: The lamp is on when the liftgate

is opened, and off when the liftgate is
closed.

•

: The lamp will always turn off

when the liftgate is opened/closed.

Type A

Type B

The luggage room lamp comes on when
the liftgate is opened.

CAUTION

The luggage room lamp comes on as
long as the liftgate opens. To prevent
unnecessary charging system drain,
close the liftgate securely after using the
luggage room.

Vanity mirror lamp

Push the switch to turn the light on or
off.
•

: The lamp will turn on if this but

ton is pressed.

•

: The lamp will turn off if this button

is pressed.

CAUTION

Vanity mirror lamp
Always close the lid of the vanity mirror
in the off position when the vanity mirror
lamp is not in use. If the sun visor is
closed without the lamp off, it may dis

charge the battery or damage the sun
visor.

Glove box lamp

OMQ4040410

OMQ4040409

OMQ4040092

OMQ4040417

CarManuals2.com

135

Features of your vehicle

Climate control system

The glove box lamp comes on when the
glove box is opened.

NOTICE

To prevent unnecessary charging sys

tem drain, close the glove box securely
after using the glove box.

Climate control system

The climate control system uses cooling
and heating to help maintain a pleasant
environment inside the vehicle.

System operation

Ventilation

1. Set the mode to the

position.

2. Set the air intake control to the out

side (fresh) air position.

3. Set the temperature control to the

desired position.

4. Set the fan speed control to the

desired speed.

Heating

1. Set the mode to the

position.

2. Set the air intake control to the out

side (fresh) air position.

3. Set the temperature control to the

desired position.

4. Set the fan speed control to the

desired speed.

5. If dehumidified heating is desired,

turn the air conditioning system on.

僅

If the windshield fogs up, set the

mode to the

position.

Operation tips

• To keep dust or unpleasant fumes

from entering the vehicle through the
ventilation system, temporarily set the
air intake control to the recirculated air
position. Be sure to return the con

trol

to the fresh air position when the
irritation has passed to keep fresh air
in the vehicle. This will help keep the
driver alert and comfortable.

CarManuals2.com

Features of your vehicle

136

Climate control system

• Air for the heating/cooling system is

drawn in through the grilles just at the
base of the windshield. Care should
be taken that these are not blocked by
leaves, snow, ice or other obstruc

tions.

• To prevent fog from forming on the

inside of the windshield:

- Set the air intake control to the fresh

air position and the fan speed to the
desired position.

- Turn on the air conditioning sys

tem, and adjust the temperature
control to desired temperature.

Air conditioning (A/C)

All Kia air conditioning systems are filled
with R-1234yf refrigerant.

1. Start the vehicle. Press the A/C but

ton.

2. Set the mode to the

position.

3. Set the air intake control to the out

side-air or recirculated air position.

4. Adjust the fan speed control and tem

perature control to maintain maxi

mum

comfort.

CAUTION

• The refrigerant system should only be

serviced by trained and certified tech

nicians to insure proper and safe
operation.

• The refrigerant system should be ser

viced in a well-ventilated place.

• The air conditioning evaporator (cool

ing coil) shall never be repaired or
replaced with one removed from a
used or salvaged vehicle and new
replacement MAC evaporators shall
be certified (and labeled) as meeting
SAE Standard J2842.

CAUTION

Excessive air conditioning use
When using the air conditioning system,
monitor the temperature gauge closely
while driving up hills or in heavy traffic
when outside temperatures are high. Air
conditioning system operation may
cause vehicle overheating. Continue to
use the blower fan but turn the air con

ditioning system off if the temperature
gauge indicates vehicle overheating.

CAUTION

The air conditioning system should only
be used with the windows and sunroof
closed to prevent condensation inside
the vehicle that may cause damage to
electrical components.

Air conditioning system opera

tion tips

• If the vehicle has been parked in

direct sunlight during hot weather,
open the windows for a short time to
let the hot air inside the vehicle
escape.

• To help reduce moisture inside of the

windows on rainy or humid days,
decrease the humidity inside the vehi

cle by operating the air conditioning
system.

• During air conditioning system opera

tion, you may occasionally notice a
slight change in vehicle speed as the
air conditioning compressor cycles.
This is a normal characteristic of sys

tem operation.

• To ensure maximum system perfor

mance, the air conditioning system
should be run for a few minutes each
month.

CarManuals2.com

137

Features of your vehicle

Climate control system

• When using the air conditioning sys

tem, you may notice clear water drip

ping (or even puddling) on the ground
under the passenger side of the vehi

cle. This is a normal characteristic of
system operation.

• Operating the air conditioning system

in the recirculated air position pro

vides maximum cooling; however,
continual operation in this mode may
cause the air inside the vehicle to
become stale.

• During cooling operation, you may

occasionally notice a misty air flow
because of rapid cooling and humid
air intake. This is a normal character

istic of system operation.

Climate control air filter

The climate control air filter installed
behind the glove box filters the dust or
other pollutants that come into the vehi

cle from the outside through the heating
and air conditioning system.

A: Outside air

B: Recirculated air

C: Climate control air filter

D: Blower

E: Evaporator core

F: Heater core

If dust or other pollutants accumulate in
the filter over a period of time, the air flow
from the air vents may decrease. This
leads to moisture accumulating on the
inside of the windshield even when the
outside (fresh) air position is selected. If
this happens, have the cli

mate control

air filter replaced by an authorized Kia
dealer.

NOTICE

• Replace the filter according to the

Maintenance Schedule. If the vehicle
is being driven in severe conditions
such as dusty or rough roads, more
frequent air conditioner filter inspec

tions and changes are required.

• When the air flow rate suddenly

decreases, have the system checked
by an authorized Kia dealer.

Checking the amount of air con

ditioner refrigerant and compres

sor lubricant

When the amount of refrigerant is low,
the performance of the air conditioning
is reduced. Overfilling also has a nega

tive impact on the air conditioning sys

tem.

Therefore, if abnormal operation is found,
have the system inspected by an
authorized Kia dealer.

W ARNING

The oil and refrigerant in your vehicle's
air conditioning system is under very high
pressure. If proper service proce

dures

are not followed, an explosion may result.
To reduce the risk of serious injury or
death, the air conditioning sys

tem in

your vehicle should only be ser

viced by

trained and certified technicians.

ODEEV068230NR

CarManuals2.com

Features of your vehicle

138

Climate control system

CAUTION

It is important that the correct type and
amount of oil and refrigerant is used,
otherwise damage to the vehicle may
occur. To prevent damage, the air condi

tioning system in your vehicle should only
be serviced by trained and certified
technicians.

W ARNING

Vehicles equipped with R-1234yf*

Since the refrigerant is mildly flammable
and operated at high pressure, the air
conditioning system should only be ser

viced by trained and certified techni

cians.

It is important that the correct type and
amount of oil and refrigerant are used. All
refrigerants should be reclaimed with
proper equipment. Venting refrigerants
directly to the atmosphere is harmful to
individuals and environment. Failure to
heed these warnings can lead to serious
injuries.

CarManuals2.com

Features of your vehicle

140

Manual climate control system

3rd row seat

1. Fan speed control knob

2. Air intake control button

3. Mode selection knob

4. Rear window defroster button

5. Front windshield defroster button

6. Temperature control knob

7. Air conditioning (A/C) button

8. 3rd row seat Air conditioning ON/OFF button (if equipped)

9. 3rd row seat Air conditioning Fan speed control knob (if equipped)

CAUTION

Operating the blower when the ignition
switch or ENGINE START/STOP button
is in the ON position could cause the bat

tery to discharge. Operate the blower
when the engine is running.

OMQ4040302

CarManuals2.com

141

Features of your vehicle

Manual climate control system

Heating and air conditioning

1. Start the engine.

2. Set the mode to the desired position.

For improving the effectiveness of heating and cooling;

• Heating:

• Cooling:

3. Set the temperature control to the desired position.

4. Set the air intake control to the outside (fresh) air position.

5. Set the fan speed control to the desired speed.

If air conditioning is desired, turn the air conditioning system on.

OMQ4A031334

CarManuals2.com

Features of your vehicle

142

Manual climate control system

Mode selection

The mode selection buttons control the
direction of the air flow through the ven

tilation system.

Air can be directed to the floor, dash

board outlets, or windshield. Five sym

bols are used to represent Face, Bi-
Level, Floor, Floor-Defrost and Defrost
air position.

Face-Level (B, D, H)

Air flow is directed toward the upper
body and face. Additionally, each outlet
can be controlled to direct the air dis

charged from the outlet.

Bi-Level (B, C, D, E, F, H)

Air flow is directed towards the face and
the floor.

Floor-Level (A, C, D, E, F, H)

Most of the air flow is directed to the
floor, with a small amount of the air
being directed to the windshield, side
window defrosters and side air vents.

Floor/Defrost-Level (A, C, D, E, F,

H)
Most of the air flow is directed to the
floor and the windshield with a small

amount directed to the side window
defrosters and side air vents.

Defrost-Level (A, D)

Most of the air flow is directed to the
windshield with a small amount of air
directed to the side window defrosters
and side air vents.

Instrument panel vents

Front

Center console

OMQ4040303

OMQ4041336L

OMQ4040335

CarManuals2.com

143

Features of your vehicle

Manual climate control system

Rear

You can adjust the direction of air deliv

ered from these vents using the vent
control lever as shown.

Temperature control

The temperature control knob allows you
to control the temperature of the air
flowing from the ventilation system.

To change the air temperature in the
passenger compartment, turn the knob
to the right for warm and hot air or to the
left for cooler air.

NOTICE

When starting the vehicle in cold weather
using manual temperature con

trol,

operate the system in the following
method to improve heating:

• Turn off or lower the blower, right

after starting the engine.

• Allow the engine to warm up during

this time since the air flow from the
heater is still cold.

• After a few minutes of engine warm

up, turn on or set the fan to a higher
level and adjust the temperature set

ting to hot.

Max A/C selection

To operate the MAX A/C, turn the tem

perature knob all the way to the left. Air
flow is directed toward the upper body
and face.

In this mode, the air conditioning and the
recirculated air position will be selected
automatically.

Controlling air intake

The air intake control is used to select the
outside (fresh) air position or recircu

lated

air position.

OMQ4A030337

OMQ4040305

OMQ4040304

CarManuals2.com

Features of your vehicle

144

Manual climate control system

Type A

Type B

To change the air intake control position.
Push the control button.

Recirculated air position

The indicator light on the
button illuminates when the
recirculated air position is
selected.

With the recirculated air

position selected, air from the passenger
compartment will be drawn through the
heating system and heated or cooled
according to the function selected.

Outside (fresh) air position

Type A

Type B

The indicator light on the button will turn
ON or OFF when the outside (fresh) air
position is selected.

With the outside (fresh) air position
selected, air enters the vehicle from out

side and is heated or cooled according
to the function selected.

NOTICE

Prolonged operation of the heater in the
recirculated air position (without air con

ditioning selected) may cause fogging of
the windshield and side windows and
make the air in the passenger compart

ment stale.

In addition, prolonged use of the air con

ditioning with the re-circulated air posi

tion selected will result in excessively dry
air, musty/stale smells and/or odors in the
passenger compartment.

W ARNING

• Continued use of the climate control

system in the recirculated air position
may allow humidity to increase inside
the vehicle which may fog the glass
and obscure visibility.

• Do not sleep in a vehicle with the air

conditioning or heating system on. It
may cause serious harm or death due
to a drop in the oxygen level and/or
body temperature.

• Continuously using the climate control

system in the recirculated air position
can cause drowsiness or sleepiness,
and loss of vehicle control. Set the air

OMQ4040306

OMQ4040307

CarManuals2.com

145

Features of your vehicle

Manual climate control system

intake control to the outside (fresh) air
position as much as possible while
driving.

Controlling fan speed

The fan speed control knob allows you
to control the fan speed of the air flow

ing from the ventilation system.

The

ENGINE

START/STOP

button

must be in the ON position for fan
operation.

僅

To change the fan speed:

• Turn the knob to the right for higher

speed or left for lower speed.

To turn off the blowers:
• Turn the fan speed control knob to

the "0" position.

Air conditioning (A/C)

• Press the A/C button to turn the air

conditioning system on (indicator light
will illuminate).

• Press the button again to turn the air

conditioning system off.

3rd row air conditioning (if
equipped)

To turn on the 3rd row air conditioning
control system.

1. You can operate the third row air con

ditioning system from the first row
control panel. When the front row air
conditioning has been turned off and
you want to stop the A/C in the third
row, press the third row air condition

ing select button one more time.
Then, the third row's A/C will also turn
off.

2. The third row A/C system can be sep

arately controlled by the control but

tons in the third row. When the A/C is
ON or OFF, the third row A/C control
button in the front row will turn ON or
OFF, informing the front passengers
of the situation.

3. The fan speed of the third row air con

ditioning can also be separately con

trolled by turning the fan speed
control knob.

OMQ4040308

OMQ4040312

OMQ4H040302

CarManuals2.com

147

Features of your vehicle

Automatic climate control system

3rd row seat

Driver's temperature control button

Passenger's temperature control button

AUTO (automatic control) button

OFF button

Fan speed control button

Mode selection button

Front windshield defroster button

Rear window defroster button

SYNC button

10.

Air intake control button

11.

Air conditioning (A/C) button

12.

3rd row air conditioning ON/OFF button (if equipped)

13.

3rd row air conditioning fan speed control knob (if equipped)

14.

Climate control display

NOTICE

Operating the blower when the ignition
switch or ENGINE START/STOP button
is in the ON position could cause the bat

tery to discharge. Operate the blower
when the engine is running.

OMQ4040302L

CarManuals2.com

Features of your vehicle

148

Automatic climate control system

Heating and air conditioning
automatically

Automatic climate control system but

tons are touch sensitive, and must be
touched in the center of the button, for
proper activation.

1. Press the AUTO button.

The modes, fan speeds, air intake and
air-conditioning will be controlled
automatically by setting the tempera

ture.

2. Press the temperature control button

to the desired temperature.

NOTICE

• To turn the automatic operation off,

select any button or switch of the fol

lowing:

- Mode selection button

- Air conditioning button
- Front windshield defroster button

(Press the button one more time to
deselect the front windshield
defroster function. The AUTO sign
will illuminate on the information
display once again.)

- Fan speed control knob
The selected function will be con

trolled manually while other functions
operate automatically.

• For your convenience and to improve

the effectiveness of the climate con

trol, use the AUTO button and set the
temperature to 22

°C (72 °F).

NOTICE

Never place anything over the sensor
located on the instrument panel to ensure
better control of the heating and cooling
system.

Level

Indicator

LCD Display

Air flow

High

2~8

Medium

1~7

Low

1~5

OMQ4040350L

OMQ4040351L

CarManuals2.com

Features of your vehicle

150

Automatic climate control system

Heating and air conditioning manually

The heating and cooling system can be controlled manually by pressing buttons
other than the AUTO button.

In this case, the system works sequentially according to the order of buttons selected.

1. Start the vehicle.

2. Set the mode to the desired position.

For improving the effectiveness of heating and cooling;

• Heating:

• Cooling:

3. Set the temperature control to the desired position.

4. Set the air intake control to the outside (fresh) air position.

5. Set the fan speed control to the desired speed.

If air conditioning is desired, turn the air conditioning system on.

Press the AUTO button in order to convert to fully automatic control of the system.

OMQ4A031339

CarManuals2.com

Kia Sorento (2024 year). Manual in english - page 7
