Kia Sorento (2024 year). Manual in english

*The information provided may differ depending on which functions are applicable to

your vehicle.

9. Reset

Features of your vehicle

LCD display

Items

Explanation

Fuel Economy Unit

• L/100 km, US gallon, UK gallon
To select the Fuel economy unit.

For more details, refer to "Trip information (trip computer)" on page 4-
88.

Temperature Unit

• °F/°C
To select the Temperature unit.

Tire Pressure Unit

• psi, kPa
To select the Tire Pressure Unit

CarManuals2.com

Items

Explanation

Reset

You can reset the menus in the User Settings mode. All menus in the
User Settings mode are reset to factory settings, except language and
service interval.

Features of your vehicle

LCD displays

LCD displays show the following infor

mation to drivers.
• Trip information

僅

LCD modes

• Warning messages

Trip information (trip computer)

The trip computer is a microcomputer-
controlled driver information system that
displays information related to driv

ing.

NOTICE

Some driving information stored in the trip
computer resets if the battery is dis

connected.

Trip modes

To change the trip mode, toggle the
switch (

) on the steering wheel.

Fuel economy

This information is always displayed at
the bottom center of the Full LCD clus

ter.

Average Fuel Economy (1)

• The average fuel economy is calcu

lated by the total driving distance and
fuel consumption since the last aver

age fuel economy resets.

- Fuel economy range: L/100 km or

0~99.9 mpg

NOTICE

The average fuel economy is not dis

played for more accurate calculation if
the vehicle does not drive more than 10
seconds or 0.03 mi (50 m) since the
ignition switch or ENGINE
START/STOP button is turned to ON.

Instant Fuel Economy (2)

• This mode displays the instant fuel

economy during the last few seconds
when the vehicle speed is more than
10 km/h (6.2 mph).

- Fuel economy range:

0.0 ~ 30 km/L, L/100 km or 0.0 ~
50.0 mpg

OMQ4A041558

OKA4040530

CarManuals2.com

Features of your vehicle

LCD displays

Accumulated

driving

information

mode

This display shows the accumulated trip
distance, the average fuel efficiency, and
the total driving time.

• Accumulated information is calculated

after the vehicle has run for more than
300 m (0.19 miles).

• If you press "OK" button for more than 1

second after the Cumulative Infor

mation is displayed, the information
will be reset.

• If the engine is running, even when

the vehicle is not in motion, the infor

mation will be accumulated.

Drive Info display

This display shows the trip distance, the
average fuel efficiency, and the total
driving time information once per one
ignition cycle.

• Fuel efficiency is calculated after the

vehicle has run for more than 300 m
(0.19 miles).

• The information will automatically reset

when the driver's door is opened after
the ignition is turned off, or
approximately 3 minutes have passed
after the ignition is turned off.

• If the engine is running, even when

the vehicle is not in motion, the infor

mation will be accumulated.

Information since refueling

This display shows the trip distance, the
average fuel efficiency, and the instant
fuel efficiency (or the total driving time)
since refueling.

OMQ4040138L

OMQ4040139L

OMQ4A041139L

CarManuals2.com

Features of your vehicle

LCD displays

• Information since refueling is calcu

lated after the vehicle has run for
more than 300 m (0.19 miles).

• If you press "OK" button for more than 1

second after the information since
refueling is displayed, the information
will be reset.

• If the engine is running, even when

the vehicle is not in motion, the infor

mation will be accumulated.

NOTICE

The vehicle must be driven for a mini

mum of 300 m (0.19 miles) since the last
ignition cycle before the average accu

mulated driving information is recalcu

lated.

Digital speedometer

This digital speedometer display shows
the speed of the vehicle.

Service mode

This mode reminds you of scheduled
maintenance information.

Service Interval

It calculates and displays when you need
a scheduled maintenance service (mile

age or days).

If the remaining mileage or time reaches
1,500 km (900 miles) or 30 days, "Ser

vice interval" message is displayed for
several seconds each time you set the
ignition switch or ENGINE START/STOP
Button to the ON position.

Service required

If you do not have your vehicle serviced
according to the already inputted ser

vice interval, "Service required" message
is displayed for several seconds each
time you set the ignition switch or
ENGINE START/STOP Button to the
ON position.

To reset the service interval to the mile

age and days you inputted before:
• Select 'Vehicle settings →

Service Interval

→ Reset'.

NOTICE

If any of the following conditions occurs,
the mileage and days may be incorrect.
• The battery cable is disconnected.
• The battery is discharged.

OKA4040532N

OMQ4040127L

CarManuals2.com

Features of your vehicle

LCD displays

LCD display messages

Door, hood, liftgate, sunroof
open

• This warning is displayed indicating

which door, the hood, the liftgate or
the sunroof is open.

Low pressure warning display

This warning message is displayed if the
tire pressure is low. The corresponding
tire on the vehicle will be illuminated.

* For more details, refer to "Tire Pressure

Monitoring System (TPMS)" on page 6-
9.

Lights mode

This indicator displays which exterior
light is selected using the lighting con

trol.

You can activate or deactivate Wiper/
Lights Display function from the User
Settings mode in the cluster LCD display.

Wiper mode

This indicator displays which wiper
speed is selected using the wiper con

trol.

You can activate or deactivate Wiper/
Lights Display function from the User
Settings mode in the cluster LCD display.

OMQ4040130

OMQ4040126L

OMQ4AH040161

OMQ4AH040162

CarManuals2.com

Features of your vehicle

LCD displays

Low washer fluid

This warning message is displayed if the
washer fluid level in the reservoir is nearly
empty.

Have the washer fluid reservoir refilled.

Icy road warning

This warning is to warn the driver the
road may be icy.

When the following conditions occur, the
warning light (including outside tem

perature gauge) blinks 5 times and then
illuminates, and also warning chime
sounds once.
• The temperature on the outside tem

perature gauge is below approxi

mately 4

°C (40 °F).

NOTICE

If the icy road warning appears while
driving, you should drive more atten

tively and safely refraining from over-
speeding, rapid acceleration, sudden
braking or sharp turning, etc.

Engine overheated

• This warning message illuminates

when the engine coolant temperature
is above 120

°C (248 °F). This means

that the engine is overheated and may
be damaged.

*If your vehicle is overheated, refer to "If

the engine overheats" on page 6-7.

Low engine oil

• This warning message appears when

the engine oil level is insufficient.

• Refill the engine oil.
For more details, refer to "Engine oil and
filter" on page 7-13.

W ARNING

When the engine oil level warning light
appears, it is necessary to check
whether maintenance schedule (Engine
oil replacement) in owner's manual has
been followed before replenishing the oil,
and if not followed, the engine oil must
be replaced first.

Engine oil change due soon.
Reset oil life after oil change

• This warning message appears when

the remaining engine oil life reaches
5% or below.

• Replace engine oil from an authorized

Kia dealer. After that, select 'Conve

nience

→ Oil Change Reminder' from

OMQ4H040108L

OMQ4040163L

CarManuals2.com

Features of your vehicle

LCD displays

the User Settings menu on the cluster
or 'Vehicle

→ Cluster → Oil Change

Reminder’ from Settings menu on the
infotainment system screen to reset
the remaining oil life.

For more details, refer to "Engine oil and
filter" on page 7-13.

CarManuals2.com

Engine oil change due now. Reset
oil life after oil change

• This warning message appears when

the remaining engine oil life reaches
1% or below.

• Replace engine oil immediately from

an authorized Kia dealer. After that,
select 'Convenience

→ Oil Change

Reminder' from the User Settings
menu on the cluster or 'Vehicle

→

Cluster

→ Oil Change Reminder’ from

Settings menu on the infotainment
system screen to reset the remaining
oil life.

For more details, refer to "Engine oil and
filter" on page 7-13.

Low key battery (for smart key
system)

• This warning message illuminates if

the battery of the smart key is dis

charged when the ENGINE START/
STOP Button changes to the OFF
position.

Press START button while turn

ing wheel (for smart key system)

• This warning message illuminates if

the steering wheel does not unlock
normally when the ENGINE START/
STOP Button is pressed.

• It means that you should press the

ENGINE START/STOP Button
while

turning the steering wheel right and
left.

Steering wheel not locked (for
smart key system)

• This warning message illuminates if

the steering wheel does not lock when
the ENGINE START/STOP Button
changes to the OFF position.

Check steering wheel lock system
(for smart key system)

• This warning message illuminates if

the steering wheel does not lock nor

mally when the ENGINE
START/STOP Button changes to the
OFF position.

Key not in vehicle (for smart key
system)

• This warning message illuminates if

the smart key is not in the vehicle
when you press the ENGINE
START/ STOP Button.

• It means that you should always have

the smart key with you.

Key not detected (for smart key
system)

• This warning message illuminates if

the smart key is not detected when
you

press

the

ENGINE

START/STOP Button.

Shift to P or N to start engine (for
smart key system)

• This warning message illuminates if

you try to start the engine with the
gear not in the P (Park) or N (Neutral)
position.

Features of your vehicle

CarManuals2.com

LCD displays

Press brake pedal to start engine
(for smart key system)

• This warning message illuminates if

the ENGINE START/STOP Button
changes to the ACC position twice by
pressing the button repeatedly with

out depressing the brake pedal.

• It means that you should depress the

brake pedal to start the engine.

Battery discharging due to exter

nal electrical devices

The vehicle can detect self-discharge of
the battery due to over-current that is
generated by unauthorized electrical
devices such as dashboard camera
(dash cam) mounting during parking.

If the warning continues even after
external electrical devices are removed,
have your vehicle inspected by an
authorized Kia dealer.

Press START button again (for
smart key system)

• This warning message illuminates if

you can not operate the ENGINE
START/STOP Button when there is
a problem with the ENGINE START/
STOP Button system.

• It means that you could start the

engine by pressing the ENGINE
START/STOP button once
more.

• If the warning illuminates each time

you press the ENGINE START/STOP
Button, have the vehicle inspected by
an authorized Kia dealer.

Press START button with key (for
smart key system)

• This warning message illuminates if

you press the ENGINE
START/STOP

Button while the warning message
"Key not detected" is illuminating.

• At this time, the immobilizer indicator

light blinks.

Check BCW system (if equipped)

This warning message is displayed if
there is a problem with Blind spot Colli

sion Warning. In this case, have the vehi

cle inspected by an authorized Kia
dealer.

Headlights are Off

This warning message illuminates if the
headlights are off when the surrounding
is dark.

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP Button to
the ON position.

- It illuminates for approximately 3

seconds

- It remains on if the parking brake is

applied.

• When the parking brake is applied.
• When the brake fluid level in the res

ervoir is low.

- If the warning light illuminates with

the parking brake released, it indi

cates the brake fluid level in reser

voir is low.

If the brake fluid level in the res

ervoir is low:

1. Drive carefully to the nearest safe

location and stop your vehicle.

2. With the engine stopped, check the

brake fluid level immediately and add
fluid as required (For more details,
refer to "Brake fluid" on page 7-15).
Then check all brake components for
fluid leaks. If any leak on the brake
system is still found, the warning light
remains on, or the brakes do not
operate properly, do not drive the
vehicle.

In this case, have your vehicle towed
to an authorized Kia dealer and
inspected.

Dual-diagonal braking system

Your vehicle is equipped with dual-diag

onal braking systems. This means you
still have braking on two wheels even if
one of the dual systems should fail.

Features of your vehicle

Warning and indicator lights

The warning light and indicator light
indicate a situation where the driver
should be careful and whether the vari

ous functions are activated.

Warning lights

The warning light indicates situations
that require the driver to pay attention.

NOTICE

Warning lights
Make sure that all warning lights are
OFF after starting the engine. If any light
is still ON, this indicates a situation that
needs attention.

Air bag warning light

This warning light illuminates:
• Once you set the ignition switch or

ENGINE START/STOP Button to
the ON position.

- It illuminates for approximately 3 ~ 6

seconds and then goes off.

• When there is a malfunction with the

SRS. In this case, have the vehicle
inspected by an authorized Kia dealer.

Seat belt warning light

This warning light informs the driver
that the seat belt is not fas

tened.

*For more details, refer to "Seat belts" on

page 3-21.

Parking brake & brake fluid

warning light

CarManuals2.com

Features of your vehicle

Warning and indicator lights

With only one of the dual systems work

ing, more than normal pedal travel and
greater pedal pressure is required to stop
the vehicle.

Also, the vehicle will not stop in as short
a distance with only a portion of the
brake system working.

If the brakes fail while you are driving,
shift to a lower gear for additional
engine braking and stop the vehicle as
soon as it is safe to do so.

NOTICE

Parking brake & brake fluid warning
light

Driving the vehicle with a warning light
ON is dangerous. If the Parking Brake &
Brake Fluid Warning Light illuminates
with the parking brake released, it indi

cates that the brake fluid level is low.

In this case, have your vehicle inspected
by an authorized Kia dealer.

Anti-lock brake system (ABS)

warning light

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP button to
the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When there is a malfunction with the

ABS (The normal braking system will
still be operational without the assis

tance of the anti-lock brake system).

this

case,

have

the

vehicle

inspected by an authorized Kia dealer.

Electronic Brake Force Distribu

tion (EBD) system warning light

These two warning lights illumi

nate at the same time while driv

ing:

• When the ABS and regular brake sys

tem are not working, have your vehi

cle inspected by an authorized Kia
dealer.

W ARNING

Electronic Brake Force Distribution
(EBD) system warning light

When both ABS and parking brake &
brake fluid warning lights are on, the
brake system will not work normally and
you may experience an unexpected and
dangerous situation during sudden
braking.

In this case, avoid high speed driving
and abrupt braking.

Have your vehicle inspected by an
authorized Kia dealer as soon as possi

ble.

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP button to
the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When there is a malfunction with the

EPB.

In this case, have the vehicle
inspected by an authorized Kia dealer.

Electronic Parking Brake (EPB)

warning light

EPB

(if equipped)

CarManuals2.com

Features of your vehicle

Warning and indicator lights

NOTICE

Electronic Parking Brake (EPB) warn

ing light

The Electronic Parking Brake (EPB)
warning light may illuminate when the
Electronic Stability Control (ESC)
Indica

tor Light comes on to indicate

that the ESC is not working properly
(This does not indicate malfunction of
the EPB).

Electric Power Steering (EPS)

warning light

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP Button to
the ON position.

- This indicator light comes on after

the ignition switch or ENGINE
START/STOP button is in the ON
position and then goes out after
approximately 3 seconds.

• When there is a malfunction with the

EPS.

In this case, have the vehicle
inspected by an authorized Kia dealer.

Charging system warning light

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP button to
the ON position.

• When there is a malfunction with

either the alternator or electrical
charging system.

If there is a malfunction with either
the alternator or electrical charging
system:

1. Drive carefully to the nearest safe

location and stop your vehicle.

2. Turn the engine off and check the

alternator drive belt for looseness or
breakage.

In this case, have the vehicle
inspected by an authorized Kia dealer.

Malfunction Indicator Lamp (MIL)

This warning light illuminates:

• When you set the ignition switch or

the ENGINE START/STOP button
to the ON position.

- The malfunction indicator light illu

minates for about 3 seconds and
then goes off.

• Whenever there is a malfunction with

either the emission control system or
the engine or the vehicle powertrain.

this

occurs,

have

the

vehicle

inspected by an authorized Kia dealer.

CAUTION

Malfunction Indicator Lamp (MIL)
• Driving with the Malfunction Indicator

Lamp (MIL) on may cause damage to
the emission control systems which
could effect drivability and/or fuel
economy.

• If the enhanced engine protection

system becomes activated due to lack
of engine oil, engine power will be lim

ited. If such condition continues
repeatedly, the Malfunction Indicator
Lamp will illuminate.

CarManuals2.com

Features of your vehicle

Warning and indicator lights

CAUTION

If the oil pressure lowers due to insuffi

cient engine oil, etc., the engine oil pres

sure warning light turns on and an
enhanced engine protection system that
limits the engine's power is activated.
After that, engine warning light turns on if
driving repeatedly and continuously.

CAUTION

If the Malfunction Indicator Lamp (MIL)
illuminates, potential catalytic converter
damage is possible which could result in
loss of engine power. In this case, have
the vehicle inspected by an authorized
Kia dealer.

Engine oil pressure warning light

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP Button to
the ON position.

- It remains on until the engine is

started.

• When the engine oil pressure is low.

If the engine pressure is low:

• Drive carefully to the nearest safe

location and stop your vehicle.

• Turn the engine off and check the

engine oil level (For more details, refer
to "Engine oil and filter" on page 7-
13“). If the level is low, add oil as
required.

• If the warning light remains on after

adding oil or if oil is not available, have
the vehicle inspected by an authorized
Kia dealer. Continued driv

ing with the warning light on may
cause engine failure.

NOTICE

• When engine oil pressure decreases

due to insufficient engine oil, etc., the
Engine Oil Pressure warning light will
illuminate.

• The enhanced engine protection sys

tem which limits engine power will be
activated. If the engine oil pressure is
restored, the Engine Oil Pressure
warning light and the enhanced
engine protection system will turn off.

• When the engine oil pressure is

restored, the warning light and the
enhanced engine protection system
will turn off after the engine is
restarted.

CAUTION

Engine overheating
Do not continue driving with the engine
overheated. Otherwise, the engine may
be damaged.

CAUTION

Engine damage
If the engine is not stopped immediately
after the engine oil pressure warning light
illuminates and stays on while the engine
is running, serious engine dam

age may

result.

Exhaust system (GPF) warning

light (Gasoline Engine)

This warning light illuminates:

• When there is a malfunction with Gas

oline Particulate Filter (GPF) system.

CarManuals2.com

Features of your vehicle

Warning and indicator lights

• When this warning light illuminates, it

may turn off after driving the vehicle:

- The vehicle should be driven for

more than 30 minutes at a speed of
80 km/h (50 mph) and faster.

- Ensure the following conditions are

all met: safe road conditions, trans

mission 3rd gear or above, and
engine speed of 1,500 - 4,000 rpm.

If this warning light blinks in spite of the
procedure (at this time the LCD warning
message will be displayed), have the
GPF system checked by a professional
workshop. Kia recommends to visit an
authorized Kia dealer/ service partner.

CAUTION

Gasoline engine with GPF (if
equipped)

If you continue to drive with the GPF
warning light blinking for a long time,
the GPF system can be damaged
and fuel consumption can worsen.

Low fuel level warning light

This warning light illuminates:

When the fuel tank is nearly empty.

If the fuel tank is nearly empty:

Add fuel as soon as possible.

CAUTION

Low fuel level
Driving with the Low Fuel Level warning
light on or with the fuel level below "E"
can cause the engine to misfire and
damage the catalytic converter.

Master warning light

This indicator light illuminates:

• This warning light informs the driver

the following situations

- LED headlamp malfunction (if

equipped)

- Lamp malfunction
- High Beam Assist malfunction (if

equipped)

To identify the details of the warning
look at the LCD display.

If the warning situation is solved, the
master warning light will turn off.

Low tire pressure warning light

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP button to
the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When one or more of your tires are

significantly under inflated. (The loca

tion of the underinflated tires are dis

played on the LCD display).

* For more details, refer to "Tire Pressure

Monitoring System (TPMS)" on page 6-
9.

This warning light remains on after
blinking for approximately 6 0
seconds or repeats blinking on and
off at the intervals of approximately
3 seconds:

• When there is a malfunction with the

TPMS.

CarManuals2.com

Features of your vehicle

100

Warning and indicator lights

this

case,

have

the

vehicle

inspected by an authorized Kia dealer.

* For more details, refer to "Tire Pressure

Monitoring System (TPMS)" on page 6-
9.

W ARNING

Low tire pressure
• Significantly low tire pressure makes

the vehicle unstable and can contrib

ute to loss of vehicle control and
increased braking distances.

• Continued driving with low pressure

tires will cause the tires to overheat
and fail.

W ARNING

Safe stopping
• The TPMS cannot alert you about

severe and sudden tire damage
caused by external factors.

• If you notice any vehicle instability,

immediately take your foot off the
accelerator pedal, apply the brakes
gradually with light force, and slowly
move to a safe position off the road.

LED headlamp warning light

This warning light illuminates:

僅

Once you set the ENGINE START/

STOP button to the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When there is a malfunction with the

LED headlamp.

In this case, have the vehicle inspected
by an authorized Kia dealer.

This warning light blinks:

• When there is a malfunction with a

LED headlamp related part.

In this case, have the vehicle inspected
by an authorized Kia dealer.

CAUTION

LED headlamp warning light
Continuous driving with the LED Head

lamp Warning Light on or blinking can
reduce LED headlamp (low beam) life.

Forward Safety warning light (if

equipped)

This indicator light illuminates:

• When there is a malfunction with For

ward Collision-Avoidance Assist.

In this case, have the vehicle inspected
by an authorized Kia dealer.

Icy road warning light

(if

equipped)

This warning light is to warn the driver
the road may be icy. When the tempera

ture on the outside temperature gauge
is approximately below 4

°C(39 °F) the

Icy road warning light and outside tem

perature gauge blinks and then illumi

nates. Also, the warning chime sounds 1
time.

All Wheel Drive (AW D) warning

light

(if equipped)

This warning light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP button to
the ON position.

CarManuals2.com

101

Features of your vehicle

Warning and indicator lights

- It illuminates for approximately 3

seconds and then goes off.

• When there is a malfunction with the

AWD.

In this case, have your vehicle
inspected by an authorized Kia dealer.

Indicator lights

Electronic stability control (ESC)

indicator light

This indicator light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP Button to
the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When there is a malfunction with the

ESC system.

In this case, have the vehicle
inspected by an authorized Kia dealer.

This indicator light blinks:

While the ESC is operating.
*For more details, refer to "Electronic

Stability Control (ESC) system" on
page 5-46.

Electronic stability control (ESC)

OFF indicator light

This indicator light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP Button to
the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When you deactivate the ESC

system by pressing the ESC OFF
button.

*For more details, refer to "Electronic

Stability Control (ESC) system" on
page 5-46.

Auto stop indicator light

This indicator will illuminate when the
engine enters the Idle Stop mode of ISG
(Idle Stop and Go) system.

When the automatic starting occurs, the
auto stop indicator on the cluster will
blink for 5 seconds.

*For more details, refer to "Idle Stop and

Go (ISG) system" on page 5-54.

NOTICE

When the engine automatically starts by
ISG system, some warning lights (ABS,
ESC, ESC OFF, EPS or Parking brake
warning light) may turn on for a few sec

onds. This happens because of the low
battery voltage. It does not mean the
system is malfunctioning.

AUTO HOLD indicator light
(AUTO HOLD) (if equipped)

This indicator light illuminates:

僅

White When you activate the auto

hold system by pressing the AUTO

HOLD button.

• Green When you stop the vehicle

completely by depressing the brake
pedal with the auto hold system acti

vated.

• Yellow When there is a malfunction

with the auto hold system. In this case,
have the vehicle inspected by an
authorized Kia dealer.

*For more details, refer to "AUTO HOLD

(if equipped)" on page 5-42.

CarManuals2.com

Features of your vehicle

102

Warning and indicator lights

Immobilizer indicator light (with

out

smart key)

(if equipped)

This indicator light illuminates:

• When the vehicle detects the immobi

lizer in your key properly while the
ignition switch is ON.

- At this time, you can start the

engine.

- The indicator light goes off after

starting the engine.

This indicator light blinks:

• When there is a malfunction with the

immobilizer system.

In this case, have the vehicle
inspected by an authorized Kia dealer.

Immobilizer indicator light (with
smart key)

This indicator light illuminates for up
to 30 seconds:

• When the vehicle detects the smart

key in the vehicle properly while the
ENGINE START/STOP button is
ACC or ON.

- At this time, you can start the

engine.

- The indicator light goes off after

starting the engine.

This indicator light blinks for a
few seconds:

• When the smart key is not in the vehi

cle.

- At this time, you can not start the

engine.

This indicator light illuminates for 2
seconds and goes off:

• When the vehicle can not detect the

smart key which is in the vehicle while
the ENGINE START/STOP Button is
ON.

In this case, have the vehicle
inspected by an authorized Kia dealer.

This indicator light blinks:

• When the battery of the smart key is

weak.

- At this time, you can not start the

engine. However, you can start the
engine if you press the ENGINE
START/STOP Button with the smart
key. (For more details, refer to
"Immobilizer system" on page 4-14).

• When there is a malfunction with the

immobilizer system.

In this case, have the vehicle
inspected by an authorized Kia dealer.

Turn signal indicator light

This indicator light blinks:

• When you turn the turn signal light on.
If any of the following occurs, there may
be a malfunction with the turn signal
system. In this case, have the vehicle
inspected by an authorized Kia dealer.
• The indicator light does not blink, but

illuminates.

• The indicator light blinks more rapidly.

僅

The indicator light does not illuminate
at all.

CarManuals2.com

103

Features of your vehicle

Warning and indicator lights

Low beam indicator light

This indicator light illuminates:

• When the headlamps are on.

High beam indicator light

This indicator light illuminates:

• When the headlamps are on and in

the high beam position.

• When the turn signal lever is pulled

into the Flash-to-Pass position.

High Beam Assist indicator light

(if equipped)

This indicator light illuminates:

• When the high beam is on with the

light switch in the AUTO light position.

• If your vehicle detects oncoming or

preceding vehicles, High Beam Assist
will switch the high beam to low beam
automatically.

*For more details, refer to "High Beam

Assist (HBA)" on page 4-125.

Light ON indicator light

This indicator light illuminates:

• When the taillamps or headlamps are

on.

Front fog indicator light

(if

equipped)

This indicator light illuminates:

• When the front fog lights are on.

Lane Safety indicator light
(if equipped)

Lane Safety indicator will illuminate
when you turn Lane Keeping Assist on
by pressing and holding Lane Safety
button.

If there is a problem with Lane Keeping
Assist, the yellow Lane Safety indicator
will illuminate.

*For more details, refer to "Lane Keeping

Assist (LKA)" on page 5-88.

Cruise Control indicator light (if
equipped)

This indicator light illuminates:

• When the cruise control system is

enabled.

*For more details, refer to "Cruise Con

trol (CC) (if equipped)" on page 5-131.

Downhill Brake Control (DBC)

indicator light

This indicator light illuminates:

僅

When you set the ignition switch or

ENGINE START/STOP Button to the

ON position.
- It illuminates for approximately 3

seconds and then goes off.

• When you activate the system by

pressing the DBC button.

This indicator light blinks:

• When the DBC is operating.

This indicator light illuminates
yellow:

• When there is a malfunction with the

DBC system.

CarManuals2.com

Features of your vehicle

104

Warning and indicator lights

If this occurs, have your vehicle
inspected by an authorized Kia dealer.

*For more details, refer to "Downhill

Brake Control (DBC)" on page 5-49.

All Wheel Drive (AW D) LOCK

indicator light

(if equipped)

This indicator light illuminates:

• Once you set the ignition switch or

ENGINE START/STOP button to
the ON position.

- It illuminates for approximately 3

seconds and then goes off.

• When you select AWD lock mode by

pressing the AWD LOCK button.

- The AWD lock mode is to increase

the drive power when driving on wet
pavement, snow covered roads
and/or off-road.

NOTICE

AW D lock mode
Do not use AWD LOCK mode on dry
paved roads or highways, it can cause
noise, vibration or damage of AWD
related parts.

SPORT Mode indicator light

This indicator light illuminates :

• When you select "SPORT" mode

as drive mode.

For more details, refer to "Drive mode
integrated control system" on page 5-57.

ECO Mode indicator light

This indicator light illuminates:

• When you select "ECO" mode as drive

mode.

For more details, refer to "Drive mode
integrated control system" on page 5-57.

CarManuals2.com

105

Features of your vehicle

Head-Up Display (HUD)

Head-Up Display (HUD) (if
equipped)

The Head-Up Display is a transparent
display that projects an image of certain
information from the instrument cluster
and navigation system on the windshield
glass.

• The head-up display image on the

HUD screen may be invisible when:

- Sitting posture is bad.

- Wearing a polarized sunglasses.
- There is an object on the cover of

the head-up display.

- Driving on a wet road.
- An inadequate lighting is turned on

inside the vehicle.

- Any light comes from the outside.
- Wearing an inadequate glasses to

your eyesight.

• If the head-up display image is not

shown well, adjust the height, rotation
or illumination of the head up display in
the LCD display.

• When the Head-Up Display needs

inspection or repair, have your vehicle
inspected or repaired by an autho

rized Kia dealer.

W ARNING

Head-Up Display

• Make sure the front windshield glass

does not have window tint or other
types of metallic coating. Otherwise,
the Head-Up Display image may be
invisible.

• Do not place any accessories on the

crash pad or attach any objects on the
windshield glass.

• As Blind-Spot Collision Warning is a

supplemental device for your safe
driving, it may be dangerous to rely on
only the BCW information of the Head-
Up Display image when chang

ing

the lane. Always pay attention to drive
safely.

CAUTION

When replacing the front windshield
glass of the vehicles equipped with the
Head-Up Display, replace it with a wind

shield glass designed for the Head-Up
Display operation. Otherwise, dupli

cated images may be displayed on the
windshield glass.

Head-Up Display Information

1. Turn By Turn navigation information

(if equipped)

2. Road signs (if equipped)

3. Speedometer

OMQ4AH040038

OMQ4A040449MX

CarManuals2.com

Features of your vehicle

106

Rear View Monitor (RVM)

SCC setting speed information (if
equipped)

SCC vehicle distance information (if
equipped)

Lane Safety information (if equipped)

Blind-Spot Safety information (if
equipped)

Warning lights (Low fuel)

AV mode information

10.

Lane Following Assist information (if
equipped)

11.

Highway Driving Assist information (if
equipped)

12.

Navigation-based Smart Cruise Con

trol information (if equipped)

NOTICE

Road signs and Turn By Turn navigation
information is available depending on the
region.

Head-Up Display Setting

On the LCD display, you can change the
head up display settings as follows.

1. Display height

2. Rotation

3. Brightness

4. Content selection
*For more details, refer to "User settings

mode" on page 4-82.

Rear View Monitor (RVM) (if
equipped)

Rear View Monitor will show the area
behind the vehicle to assist you when
parking or backing up.

W ARNING

The outside rear view camera does not
cover the complete area behind the
vehicle. The driver should always check
the rear area directly through the rear
view mirror and side view mirrors before
parking or backing up.

Detecting sensor

Wide-rear view camera

OMQ4A042040

OMQ4A042593

CarManuals2.com

107

Features of your vehicle

Rear View Monitor (RVM)

Refer to the picture above for the detailed
location of the detecting sensor.

Rear View Monitor Settings

• You can change Rear View Monitor

settings by pressing the setup icon

「」

on the screen while the func

tion is operating, or select 'Driver
Assistance

→ Parking Safety →

Cam

era Settings' from the Settings

menu while the ENGINE
START/STOP but

ton is in the ON

position.

• Display Contents: To change the set

tings of Rear view parking guide and
Extended Rear View Monitor use.

Parking/View button

Press the Parking/View button (1) to turn
Rear View Monitor on or off.

Warning Methods

You can adjust the Warning Methods
with the ignition switch or ENGINE
START/ STOP button in the ON
position.
• Parking Safety Priority: Select 'Set

tings

→ Vehicle → Driver Assistance

→ Warning Methods → Parking

Safety

Priority’ on the Infotainment

system for safe parking. For safe
parking, the audio volume will tempo

rarily decrease while Rear View Moni

tor is operating.

NOTICE

• Ensure that warning sound you have

set may apply to the warning volume
of other driver assistance systems.

• If not equipped with the navigation

system, select User Settings

→

Driver Assistance to adjust the Warn

ing Volume.

• The settings menu content may vary

depending of the vehicle specifica

tions.

• Descriptions of each Driver Assistance

system may be slightly different from
the owner's manual after updating the
software of your infotainment system.

OMQ4A052386

OMQ4A040041

OMQ4A052388

CarManuals2.com

Features of your vehicle

108

Rear View Monitor (RVM)

In this case, scan the QR code in the
infotainment system manual to
access the web manual for checking
the changes.

• Depending on your region or update,

the menu may be displayed as 'Warn

ing Sound' or 'Warning Methods'.

Rear View Monitor Operation

Rear view

The function will operate when the fol

lowing conditions are satisfied:
• ENGINE START/STOP button in

the ON position

• The gear is changed to R

(Reverse) and the back-up light
turns on

Extended Rear View Monitor

• When parking, the rear view will main

tain showing on the screen if the fol

lowing conditions are satisfied:

- The gear is changed from R

(Reverse) to N (Neutral) or D (Drive)

- Vehicle speed is below 10 km/h (6

mph)

• The rear view will turn off when vehi

cle speed is above 10 km/h (6 mph).

Rear Top View

When you touch the icon (1), the rear top
view is displayed on the screen and
shows the distance from the vehicle in
the back of your vehicle while parking.

Rear View Monitor Malfunction
and Limitations

Rear View Monitor malfunction

When Rear View Monitor is not working
properly, or the screen flickers, or the
camera image does not display nor

mally, have the function be inspected by
an authorized Kia dealer.

Limitations of Rear View Monitor

When the vehicle is stopped for a long
time in winter or when the vehicle is
parked in an indoor parking lot, the
exhaust fumes may temporarily blur the
image.

W ARNING

The image shown on the screen may dif

fer from the actual distance of the
object. Make sure to directly check the
vehicle's surroundings for safety.

OMQ4A052387

CarManuals2.com

109

Features of your vehicle

360

° camera monitoring system

360

° camera monitoring sys

tem (if equipped)

360

° camera monitoring system will

assist in parking by allowing the driver to
see around the vehicle.

W ARNING

ALWAYS look around your vehicle to
make sure there are no objects or obsta

cles before moving the vehicle. What
you see on the screen may differ from the
actual vehicle's location.

CAUTION

360

° camera monitoring system is

designed to be used on a flat surface.
Therefore, if used on roads with differ

ent heights such as curbs and speed
bumps, the image in the screen may not
look correct.

Detecting sensor

(1) 360

° camera monitoring system -

front view camera, (2, 3) 360

° camera

monitoring system -side view camera

(under the outside rear view mirror)

(4) 360

° camera monitoring system-

rear view camera

Refer to the picture above for the
detailed location of the detecting sen

sors.

W ARNING

The image shown on the screen may dif

fer from the actual distance of the
object. Make sure to directly check the
vehicle's surroundings for safety.

CAUTION

If the camera lens is covered with for

eign material, Surround View Monitor
may not operate normally. Always keep
the camera lens clean.

OMQ4A042468

OMQ4041404

OMQ4A042405

CarManuals2.com

Features of your vehicle

110

360

° camera monitoring system

However, do not use chemical solvents
such as strong detergents containing
high alkaline or volatile organic solvents
(gasoline, acetone etc.). This may dam

age the camera lens.

360

° camera monitoring system

Settings

Setting

• You can change 360° camera moni

toring system settings by pressing the
setup icon

「」

on the screen while

the function is operating or select
'Driver Assistance

→ Parking Safety

→ Camera Settings' from the Settings
menu while the ENGINE
START/STOP button is in the ON
position.

• Display Contents: To change the set

tings of Top view parking guidance,
Parking guide in rear view, and Park

ing distance warning function.

• Display Settings: To change the

screen's brightness and contrast.

NOTICE

The settings menu on your vehicle may
not be necessarily be available due to
the selected options.

360

° camera monitoring system

Auto On

With the vehicle on, select 'Settings

→

Vehicle

→ Driver assistance → Parking

safety

→ 360° camera monitoring sys

tem auto On' from the infotainment sys

tem screen to use the function.

NOTICE

For more details on 360

° camera moni

toring system Auto On, refer to "360

camera monitoring system Auto On" on
page 4-110.

Warning Methods

You can adjust the Warning Methods
with the ignition switch or ENGINE
START/ STOP button in the ON
position.
• Parking Safety Priority: Select 'Set

tings

→ Vehicle → Driver Assistance

→ Warning Methods → Parking

Safety

Priority’ on the Infotainment

system for safe parking. For safe
parking, the audio volume will tempo

rarily decrease while 360

° camera

monitoring system is operating.

OMQ4A042591

OMQ4A052388

CarManuals2.com

111

Features of your vehicle

360

° camera monitoring system

NOTICE

• Ensure that warning sound you have

set may apply to the warning volume
of other driver assistance systems.

• If not equipped with the navigation

system, select User Settings

→

Driver Assistance to adjust the Warn

ing Volume.

• The settings menu content may vary

depending of the vehicle specifica

tions.

• Descriptions of each Driver Assistance

system may be slightly different from
the owner's manual after updating the
software of your infotainment system.
In this case, scan the QR code in the
infotainment system manual to
access the web manual for checking
the changes.

• Depending on your region or update,

the menu may be displayed as 'Warn

ing Sound' or 'Warning Methods'.

Parking/View button

Press the Parking/View button (1) to turn
Rear View Monitor on or off.

360

° camera monitoring system

Operation

Parking assist view

Operating Conditions

• The function will operate when the

following conditions are satisfied:

- The gear is changed to R (Reverse)
- The gear is changed from R

(Reverse) to N (Neutral) or D (Drive)
when vehicle speed is below 15 km/
h (9 mph)

- Parking/View button is pressed

with the gear in D (Drive) or N (Neu

tral) when vehicle speed is below 15
km/h (9 mph)

- Parking/View button is pressed

with the gear in P (Parking)

- Parking Distance Warning warns

the driver when the gear is in D
(Drive)

• An indicator on the screen appears

when:

- The liftgate is opened
- The driver or front passenger door

is opened

- The outside rear view mirror is

folded

• Other view modes can be selected by

touching the view icons on the Sur

round View Monitor screen.

Off Conditions

• Parking/View button is repressed.
• When vehicle speed is above 15 km/h

(9 mph), Surround View Monitor will
turn off and the screen will change
back to the previous infotainment sys

tem screen.

OMQ4A040041

CarManuals2.com

Features of your vehicle

112

Reverse Parking Distance Warning (PDW)

• When the gear is in R (Reverse), Sur

round View Monitor will turn ON
regardless of vehicle speed or button
status. However, if vehicle speed is
above 15 km/h (9 mph) with the gear
in D (Drive), the function will turn off.

• Any button on the infotainment sys

tem is pressed without the gear in R
(Reverse). The screen will change
back to the previous infotainment sys

tem screen

360

° camera monitoring system

Malfunction and Limitations

360

° camera monitoring system

malfunction

When 360

° camera monitoring system is

not working properly, or the screen flick

ers, or the camera image does not dis

play normally, have the function be
inspected by an authorized Kia dealer.

Limitations of 360

° camera moni

toring system

When the vehicle is stopped for a long
time in winter or when the vehicle is
parked in an indoor parking lot, the
exhaust fumes may temporarily blur the
image.

Reverse Parking Distance
Warning (PDW) (if equipped)

Reverse Parking Distance Warning will
warn the driver if an obstacle is detected
when the vehicle is backing up at low
speeds.

Detecting sensor

Rear ultrasonic sensors

Refer to the picture above for the
detailed location of the detecting sen

sors.

Reverse Parking Distance Warn

ing Settings

Turning On/Off

• Press the Parking Distance Warning

Off (

) button to turn on Reverse

Parking Distance Warning.

• With the ENGINE START/STOP

button in the ON position, the Parking
Dis

tance Warning Off (

) button indi

cator light will appear. The function
will operate when vehicle speed is
below 10 km/h (6 mph).

If vehicle speed is above 10 km/h (6
mph), the function will not warn the

OMQ4A042045

CarManuals2.com

113

Features of your vehicle

Reverse Parking Distance Warning (PDW)

driver even though objects are
detected.

Warning Methods

You can adjust the Warning Methods
with the ignition switch or ENGINE
START/ STOP button in the ON
position.

With the vehicle on,
• Warning Volume: Select 'User Settings

→ Driver Assistance → Warning Vol

ume' on the instrument cluster or 'Set

tings

→ Vehicle → Driver Assistance

→ Warning Methods' on the infotain

ment system to change the Warning
Methods. Even if '0' or 'Off' is selected,
the function's Warning Volume will not
turn off but the volume will sound as '1'
or 'Low'.

NOTICE

• Ensure that Warning Sound and Hap

tic you have set may apply to the
Warning volume of other Driver Assis

tance systems.

• Warning Sound and Haptic will main

tain its last setting even if the vehicle
is restarted.

• If not equipped with the navigation

system, select 'User Settings

→ Driver

Assistance' to adjust the Warning Vol

ume.

• The setting menu may not be avail

able for your vehicle depending on
the vehicle features and specifica

tions.

• Descriptions of each Driver Assistance

• Depending on your update, the menu

may be displayed as 'Warning Sound'
or 'Warning Methods'.

Reverse Parking Distance Warn

ing Operation

Operating conditions

• This function will activate when back

ing

with

the

ENGINE

START/STOP button ON.

• The function displays a warning on

the instrument cluster or infotainment
system and the warning sound is gen

erated when an obstacle is detected.

• When more than two objects are

sensed at the same time, the closest
one will be recognized first.

Types of warning sound and indi

cator

OMQ4A052388

Types of warning sound

Indicator

When an object is 24 inches ~ 48 inches
(60 cm ~ 120 cm) from the rear bumper:
Buzzer beeps intermittently

When an object is 12 inches ~ 24 inches
(30 cm ~ 60 cm) from the rear bumper:
Buzzer beeps more frequently.

CarManuals2.com

Features of your vehicle

114

Reverse Parking Distance Warning (PDW)

• The audible warning does not sound.

僅

The buzzer sounds intermittently.

• The 'Ultrasonic sensor error or block

age' warning message appears on the
cluster.

The detecting range may
decrease when:

• The sensor is covered with foreign

matter such as snow or water, (The
sensing range will return to normal
when removed.)

• The weather is extremely hot or cold

The following objects may not be
recognized by the sensor:

• Sharp or slim objects such as ropes,

chains or small poles

• Objects, which tend to absorb sensor

frequency, such as clothes, spongy
material or snow

• Objects smaller than 40 in (100 cm) in

length and narrower than 6 in (14 cm)
in diameter

Reverse Parking Distance Warn

ing Malfunction and Precautions

Reverse Parking Distance Warn

ing malfunction

Reverse Parking Distance Warning has a
self-diagnosis function that can deter

mine whether the ultrasonic sensor is
working properly. After starting the
engine, a beep will sound when the gear
is shifted to R (Reverse) to indicate the
function is operating normally.

However, if one or more of the following
occurs, first check whether the ultra

sonic sensor is damaged or whether the
function is in a non-operating condition. If
it still does not work properly, have your
vehicle inspected by an authorized Kia
dealer.

NOTICE

• Reverse Parking Distance Warning is

a supplemental function. The opera

tion of the function can be affected by
several factors (including environ

mental conditions). It is the responsi

bility of the driver to always check the
front and rear views before and while
parking.

• Always look around your vehicle to

make sure there are no objects or
obstacles before moving the vehicle in
any direction to prevent a collision.

• Your new vehicle warranty does not

cover any accidents or damage to the
vehicle or injuries to its occupants
related to a Reverse Parking Distance
Warning.

• Pay close attention when driving near

objects, pedestrians, and especially
children. Some objects may not be
detected by the ultrasonic sensors,
due to the objects distance, size or
material, all of which can limit the
effectiveness of the sensor.

Types of warning sound

Indicator

When an object is within 12 inches (30 cm)
of the rear bumper: Buzzer beeps continu

ously.

OMQ4A041510

CarManuals2.com

115

Features of your vehicle

Reverse Parking Distance Warning (PDW)

• Reverse Parking Distance Warning

may not operate normally when:

- Moisture is frozen to the sensor (It

will operate normally when the fro

zen moisture melts)

- Sensor is covered with foreign mat

ter, such as snow or water (It will
operate normally when the material
is removed or the sensor is no lon

ger blocked.)

- The weather is extremely hot or

cold

- The sensor is pushed, scratched or

struck with any hard and sharp
objects that could damage the sur

face.

- High pressure water is directly

applied to ultrasonic sensor.

- Heavy rain or water spray is pres

ent.

- The sensor is covered with snow.
- Affected by another vehicle's sen

sors

- Water flows on the surface of the

sensor

- Driving on uneven road surfaces

such as unpaved roads, gravel,
bumps, or gradient.

- Wireless transmitters or mobile

phones present near the sensor.

- Installing the license plate differ

ently from the original location

- Accessories, such as license plate

molding or sticker, are installed on
the sensor area.

- The vehicle bumper height or sen

sor installation has been modified.

• The following objects may not be rec

ognized by the sensor:

- Sharp or slim objects such as ropes,

chains or small poles.

- Undetectable objects smaller than

40 in (100 cm) and narrower than
5.5 in (14 cm) in diameter.

- Objects, which tend to absorb sen

sor frequency such as clothes,
spongy material or snow.

• If it does not work properly, have your

vehicle inspected by an authorized
Kia dealer.

Precautions of Reverse Parking
Distance Warning

• Reverse Parking Distance Warning

may malfunction if the vehicle
bumper height or sensor installation
has been modified or damaged. Any
non-factory installed equipment or
accessories may also interfere with
the sensor performance.

• When the sensor is frozen or covered

with snow, dirt, or water, the sensor
may be inoperative until the material
is removed using a soft cloth.

• Do not push, scratch or strike the

ultrasonic sensor. Sensor damage
could occur.

• Do not spray the ultrasonic sensors or

its surrounding area directly with a
high pressure washer.

NOTICE

CarManuals2.com

Make sure that high pressure is not
directly applied to the surface of the
ultrasonic sensor while using use high-
pressure car washes.

This function can only sense objects
within the range and location of the sen

sors; It can not detect objects in other
areas where sensors are not installed.
Also, small or slim objects, such as poles
or objects located between sensors may
not be detected by the sensors.

Features of your vehicle

116

Forward/Reverse Parking Distance Warning (PDW)

Always visually check behind the vehicle
when backing up.

Be sure to inform any drivers of the vehi

cle that may be unfamiliar with the func

tion regarding the functions capabilities
and limitations.

W ARNING

Pay close attention when the vehicle is
driven close to objects on the road, par

ticularly pedestrians, and especially chil

dren. Be aware that some objects may
not be detected by the sensors, due to
the object's distance, size or material, all
of which can limit the effectiveness of the
sensor. Always perform a visual
inspection to make sure the vehicle is
clear of all obstructions before moving
the vehicle in any direction.

Forward/Reverse Parking Dis

tance Warning (PDW) (if
equipped)

Forward/Reverse Parking Distance
Warning will warn the driver if an obsta

cle is detected when the vehicle is mov

ing forward or backward at low speeds.

Detecting sensor

Front ultrasonic sensors

Rear ultrasonic sensors

Refer to the picture above for the detailed
location of the detecting sensor.

CAUTION

Take the following precautions to main

tain optimal performance of the detect

ing sensor:

OMQ4041047

OMQ4A042045

CarManuals2.com

117

Features of your vehicle

Forward/Reverse Parking Distance Warning (PDW)

• Never disassemble the detecting sen

sor or sensor assembly, or apply any
impact on it.

• If the detecting sensors have been

replaced or repaired, have the vehicle
be inspected by an authorized Kia
dealer.

• Forward/Reverse Parking Distance

Warning may not operate normally
when:

- Moisture is frozen to the sensor
- Sensor is covered with foreign

material, such as snow or water
(The function will operate normally
when such foreign material are
removed.)

• Forward/Reverse Parking Distance

Warning may malfunction when:

- Driving on uneven road, gravel

roads or bushes

- Objects that generate ultrasonic

waves such as vehicle horns, loud
motorcycle engine sound or truck
air brakes are near the sensor

- Heavy rain or water spray is pres

ent

- Wireless transmitters or mobile

phones are present near the sensor

- The sensor is covered with snow
- Affected by another vehicle's sen

sors

- Water flows on the surface of the

sensor

- Installing the license plate differ

ently from the original location

• Detecting range may decrease when:

- Sensor is covered with foreign

material, such as snow or water
(The function will operate normally
when such foreign material are
removed.)

- The weather is extremely hot or

cold

• The following objects may not be

detected:

- Sharp or slim objects, such as

ropes, chains or small poles.

- Objects, which tend to absorb sen

sor frequency, such as clothes,
spongy material or snow.

- Objects smaller than 100 cm (40

inches) in length and narrower than
14 cm (6 inches) in diameter.

Forward/Reverse Parking Dis

tance Warning Settings

Turning On/Off

• Press the Parking Safety (

) button

to turn on Forward/Reverse Parking
Distance Warning. Press the button
again to turn off the function.

• With the Engine Start/Stop button in

the ON position, if 'Driver Assistance

→ Parking Safety → Parking Distance

Warning Auto On' is selected from the
Settings menu, the Parking Safety
(

) button indicator light will

appear. The function will operate
when vehicle speed is below 10 km/h
(6 mph).

If vehicle speed is above 10 km/h (6
mph), the function will not warn the
driver even though objects are
detected.

CarManuals2.com

Features of your vehicle

118

Forward/Reverse Parking Distance Warning (PDW)

Warning Methods

With the vehicle on, select 'User Settings

→ Driver Assistance → Warning Volume'

on the instrument cluster or 'Settings

→

Vehicle

→ Driver Assistance → Warning

Methods' on the infotainment system to
change the Warning Methods.
• Warning Volume: You can adjust the

Warning Volume from level 0 to 3.
However, even if '0' or 'Off' is selected,
the function's Warning Volume will not
turn off but the volume will sound as '1'
or 'Low'.

NOTICE

• Ensure that Warning Sound and Hap

tic you have set may apply to the
Warning volume of other Driver Assis

tance systems.

• Warning Sound and Haptic will main

tain its last setting even if the vehicle
is restarted.

• If not equipped with the navigation

system, select 'User Settings

→ Driver

Assistance' to adjust the Warning Vol

ume.

• The setting menu may not be avail

able for your vehicle depending on
the vehicle features and specifica

tions.

• Descriptions of each Driver Assistance

• Depending on your update, the menu

may be displayed as 'Warning Sound'
or 'Warning Methods'.

Forward/Reverse Parking Dis

tance Warning Operation

Parking Safety button

appear and will operate when the
vehicle moves forward or backward.

• When the button is off (button indica

tor light off), if you shift the gear to R
(Reverse), the function will automati

cally turn on.

• Forward/Reverse Parking Distance

Warning may not operate properly at
speeds above 5 km/h (3 mph). If vehi

cle speed is above 6 mph (10 km/h),
the function will not warn the driver,
and if vehicle speed is above 30 km/h

OMQ4A052388

OMQ4A040407

• When the Parking Safety (

) but

ton is pressed while the engine run

ning, the button indicator light will

CarManuals2.com

Kia Sorento (2024 year). Manual in english - page 6
