Kia Sorento (2024 year). Manual in english

151

Features of your vehicle

Automatic climate control system

Mode selection

The mode selection button controls the
direction of the air flow through the ven

tilation system.

The air flow outlet ports are switched in
the following sequence:

Face-Level (B, D, H)

Air flow is directed toward the upper
body and face. Additionally, each outlet
can be controlled to direct the air dis

charged from the outlet.

Bi-Level (B, C, D, E, F, H)

Air flow is directed towards the face and
the floor.

Floor-Level (A, C, D, E, F, H)

Most of the air flow is directed to the
floor, with a small amount of the air
being directed to the windshield, side
window defrosters and side air vents.

Floor/Defrost-Level (A, C, D, E, F,

H)
Most of the air flow is directed to the
floor and the windshield with a small
amount directed to the side window
defrosters and side air vents.

Defrost-Level (A, D)

Most of the air flow is directed to the
windshield with a small amount of air
directed to the side window defrosters
and side air vents.

Instrument panel vents

Front

Center console

OMQ4040319L

OMQ4041336L

OMQ4040335

CarManuals2.com

Features of your vehicle

152

Automatic climate control system

Rear

You can adjust the direction of air deliv

ered from these vents using the vent
control lever as shown.

Temperature control

The temperature will increase to the
maximum (HI) by moving the switch
upwards.

The temperature will decrease to the
minimum (Lo) by moving the switch
downwards.

When moving the switch, the tempera

ture will increase or decrease by 0.5

°F.

When set to the lowest temperature set

ting, the air conditioning will operate
continuously.

NOTICE

When starting the vehicle in cold
weather using manual temperature con

trol, operate the system in the following
method to improve heating:
• Turn off or lower the blower, right

after starting the engine.

• Allow the engine to warm up during

this time since the air flow from the
heater is still cold.

• After a few minutes of engine warm

up, turn on or set the fan to a higher
level and adjust the temperature set

ting to hot.

Adjusting the driver and passen

ger side temperature equally

Type A

OMQ4A030337

OMQ4040321

OMQ4040322L

CarManuals2.com

153

Features of your vehicle

Automatic climate control system

Type B

1. Press the "SYNC" button to adjust the

driver and passenger side tempera

ture equally.

The passenger side temperature will
be set to the same temperature as the
driver side temperature.

2. Move the driver side temperature

control switch. The driver and passen

ger side temperature will be adjusted
equally.

3. If you move the passenger's tempera

ture control switch, the SYNC button
is off and the passenger side tem

perature can be operated individually.

Adjusting the driver and passen

ger side temperature individually

Press the "SYNC" button again to adjust
the driver and passenger side tempera

ture individually. The button indicator will
turn off.

Changing temperature scale

You can switch the temperature mode
from Centigrade to Fahrenheit as fol

lows:
• While pressing the OFF button, press

the AUTO button for 3 seconds or
more.

The display will change from Centigrade
to Fahrenheit, or from Fahrenheit to

Centigrade. If the battery has been dis

charged or disconnected, the tempera

ture mode display will reset to
Centigrade.

Controlling air intake

This is used to select the outside (fresh)
air position or recirculated air position.

Type A

Type B

To change the air intake control position:

僅

Push the desired control button.

Recirculated air position

With the recirculated air
position selected, air from
the passenger compartment
will be drawn through the
heating system and heated

or cooled according to the function
selected.

Outside (fresh) air position

Type A

Type B

The indicator light on the button will turn
ON or OFF when the outside (fresh) air
position is selected.

With the outside (fresh) air position
selected, air enters the vehicle from out

side and is heated or cooled according to
the function selected.

NOTICE

Prolonged operation of the heater in the
recirculated air position (without air con

OMQ4040322

CarManuals2.com

Features of your vehicle

154

Automatic climate control system

ditioning selected) may cause fogging of
the windshield and side windows and the
air within the passenger compart

ment

may become stale.

In addition, prolonged use of the air con

ditioning with the recirculated air posi

tion

selected will result in excessively dry air,
musty/stale smells and/or odors in the
passenger compartment.

W ARNING

• Continued climate control system

operation in the recirculated air posi

tion may allow humidity to increase
inside the vehicle which may fog the
glass and obscure visibility.

• Do not sleep in a vehicle with the air

conditioning or heating system on. It
may cause serious harm or death due
to a drop in the oxygen level and/or
body temperature.

• Continued climate control system

operation in the recirculated air posi

tion can cause drowsiness or sleepi

ness, and loss of vehicle control. Set
the air intake control to the outside
(fresh) air position as much as possi

ble while driving.

Controlling fan speed

The fan speed can be set to the desired
speed by operating the fan speed con

trol button.

To change the fan speed:
• Press right button for higher speed, or

press left button for lower speed.

Type A

Type B

To turn the fan speed control off:

僅

Press the OFF button.

Air conditioning (A/C)

OMQ4040327L

OMQ4040327

OMQ4040328L

CarManuals2.com

155

Features of your vehicle

Automatic climate control system

• Press the A/C button to turn the air

conditioning system on (indicator light
will illuminate).

• Press the button again to turn the air

conditioning system off.

Turning off the front air climate
control

• Press the OFF button to turn off the

air climate control system.

However, you can still operate the
mode and air intake buttons as long
as the ENGINE START/STOP button
is in the ON position.

Clean air (if equipped)

When the ignition switch or ENGINE
START/STOP button is in the ON posi

tion, the clean air function turns on auto

matically.

Also, the clean air function turns off
automatically, when the ignition switch or
ENGINE START/STOP button is in the
OFF position.

3rd row air conditioning (if
equipped)

To turn on the 3rd row air conditioning
control system.

1. You can operate the third row air con

ditioning system from the first row
control panel. Changing the front row's
fan speed by pressing the con

trol

button will automatically change the
third row's fan speed as well. When the
front row air conditioning has been
turned off and you want to stop the
A/C in the third row, press the third
row air conditioning select button one
more time. Then, the third row's A/C
will also turn off.

2. The third row A/C system can be sep

arately controlled by the control but

tons in the third row. When the A/C is
ON or OFF, the third row A/C control
button in the front row will turn ON or
OFF, informing the front passengers
of the situation.

3. The fan speed of the third row air con

ditioning can also be separately con

trolled by turning the fan speed
control knob.

OMQ4040329

OMQ4H040306L

CarManuals2.com

Features of your vehicle

156

Windshield defrosting and defogging

Windshield defrosting and
defogging

When the windshield is covered with
frost or moisture, the front view is
blurred, you should remove the frost
and moisture.

W ARNING

Windshield heating

Do not use the

position

during cooling operation in extremely
humid weather. The difference between
the temperature of the outside air and the
windshield could cause the outer surface
of the windshield to fog up, causing loss
of visibility. In this case, set

the mode selection to the

position

and fan speed control to the lower
speed.

• For maximum defrosting, set the tem

perature control to the extreme right/
hot position and the fan speed control
to the highest speed.

• If warm air to the floor is desired while

defrosting or defogging, set the mode
to the floor-defrost position.

• Before driving, clear all snow and ice

from the windshield, rear window,
outside rear view mirrors, and all side
windows.

• Clear all snow and ice from the hood

and air inlet in the cowl grill to improve
heater and defroster effi

ciency and

to reduce the probability of fogging
up the inside of the wind

shield.

Defogging inside windshield

1. Set the fan speed to the desired posi

tion.

2. Select desired temperature.

3. Press the defroster button (

4. The outside (fresh) air position will be

selected automatically and the air
conditioning will turn on according to
the detected ambient temperature.

If the air conditioning and outside (fresh)
air positions are not selected automati

cally, adjust the corresponding button

manually. If the

position is

selected, lower fan speed is adjusted to
a higher fan speed.

Defrosting outside windshield

OMQ4040342

OMQ4040343

CarManuals2.com

157

Features of your vehicle

Windshield defrosting and defogging

1. Set the fan speed to the highest posi

tion.

2. Set the temperature to the extreme

hot (HI) position.

3. Press the defroster button (

4. The outside (fresh) air position will be

selected automatically and the air
conditioning will turn on according to
the detected ambient temperature.

Auto defogging system (if
equipped)

Auto defogging helps reduce the possi

bility of fogging up the inside of the
windshield by automatically sensing the
moisture on inside the windshield.

The auto defogging system oper

ates when the heater or air condi

tioning is on.

When the Auto Defogging System oper

ates, the indicator will illuminate.

If a high amount of humidity is detected
in the vehicle, the Auto Defogging Sys

tem will be enabled.

The following steps will be performed
automatically:

1. The A/C button will turn ON.
2. The air intake control will change to

Fresh mode under low outside tem

perature.

3. The mode will be changed to defrost

to direct airflow to the windshield.

4. The fan speed will be increased.
To cancel or reset the Auto Defogging
System

Press the front windshield defroster but

ton for 3 seconds when the ignition switch
or ENGINE START/STOP button is in
the ON position.

When the Auto Defogging System is
canceled, defrost button indicator will
blink 3 times.

When the Auto Defogging System is
reset, defrost button indicator will blink 6
times without a signal.

NOTICE

• When the air conditioning is turned on

by Auto defogging system, if you try
to turn off the air conditioning, the
indicator will blink 3 times and the air
conditioning will not be turned off.

• To maintain the effectiveness and

efficiency of the Auto Defogging Sys

tem, do not select Recirculation mode
while the system is operating.

• When the Auto Defogging System is

operating, the fan speed adjustment
knob, the temperature adjustment
knob, and the air intake control button
are all disabled.

NOTICE

Do not remove the sensor cover located
on the upper end of the driver side wind

shield glass.

Damage to system parts could occur
and may not be covered by your vehicle
warranty.

OMQ4040561BR

CarManuals2.com

Features of your vehicle

158

Windshield defrosting and defogging

Defroster

The vehicle is equipped with a defroster
for removing frost or fog from the rear
window.

CAUTION

Conductors
To prevent damage to the conductors
bonded to the inside surface of the rear
window, never use sharp instruments or
window cleaners containing abrasives to
clean the window.

If you want to defrost and defog the
front windshield, refer to "Windshield
defrosting and defogging" on page 4-
156.

Operating rear window defroster

The defroster heats the window to
remove frost, fog and thin ice from the
rear window, while the engine is on.

If there is heavy accumulation of snow
on the rear window, brush it off before
operating the rear defroster.

To activate the rear window defroster:

僅

Press the rear window defroster but

ton located in the heater control
panel.

The indicator on the rear window
defroster button illuminates when the
defroster is ON.

The rear window defroster automati

cally turns off after approximately 20
minutes or when the ENGINE START/
STOP button is turned off.

To turn off the defroster:
• Press the rear window defroster but

ton again.

Outside mirror defroster (if
equipped)

If your vehicle is equipped with the out

side mirror defrosters, they will operate
at the same time you turn on the rear
window defroster.

Defogging logic (if equipped)

To reduce the possibility of fogging up
the inside of the windshield, the air
intake or air conditioning is controlled
automatically according to certain con

ditions such as

position.

To cancel automatic defogging logic or
return to the automatic defogging logic,
do the following.

Canceling/returning automatic
defogging logic

OMQ4040332

OMQ4040345L

CarManuals2.com

159

Features of your vehicle

Storage compartment

1. Turn the ENGINE START/STOP

button to the ON position.

2. Press the defroster button (

3. While pressing the air conditioning (A/

C) button, press the air intake control
button at least 5 times within 3 sec

onds.

The recirculation indicator blinks 3
times in 0.5 second of intervals. It indi

cates that the defogging logic is can

celed or returned to the programed
status.

If the battery has been discharged or
disconnected, it resets to the defog logic
status.

Storage compartment

These compartments can be used to
store small items required by the driver
or passengers.
• To avoid possible theft, do not leave

valuables in the storage compart

ment.

• Always keep the storage compart

ment covers closed while driving. Do
not attempt to place so many items in
the storage compartment that the
storage compartment cover cannot
close securely.

W ARNING

Flammable materials
Do not store, propane cylinders or other
flammable/explosive materials in the
vehicle. These items may catch fire and/
or explode if the vehicle is exposed to hot
temperatures for extended periods.

Center console storage

To open the center console storage:

僅

Pull up the lever.

OMQ4040427

CarManuals2.com

Features of your vehicle

160

Interior features

Glove box

The glove box can be locked and
unlocked with the mechanical key (1).

To open the glove box:
• Pull the handle and the glove box will

automatically open (2).

Close the glove box after use.

W ARNING

Glove box
To reduce the risk of injury in an acci

dent or sudden stop, always keep the
glove box door closed while driving.

CAUTION

Do not keep food in the glove box for a
long time.

NOTICE

If the temperature control switch is in the
warm or hot position, warm or hot air will
flow into the glove box.

Interior features

There are various features inside the
vehicle for the convenience of the occu

pants.

Cup holder

Front

Rear

OMQ4A040430

OMQ4A040073

OMQ4040072

CarManuals2.com

161

Features of your vehicle

Interior features

Rear armrest (7 passenger vehicle)

3rd row seats

Cups or small beverage cans may be
placed in the cup holders.

W ARNING

Hot liquids
Do not place uncovered cups with hot
liquid in the cup holder while the vehicle
is in motion. If the hot liquid spills, you
may burn yourself. Such a burn to the
driver could lead to loss of control of the
vehicle.

W ARNING

Keep cans or bottles out of direct sun
light and do not put them in a vehicle
that is heated up. It may explode.

CAUTION

• Keep your drinks sealed while driving

to prevent spilling your drink. If liquid
spills, it may get into the vehicle's
electrical/electronic system and dam

age electrical/electronic parts.

• When cleaning spilled liquids, do not

use heat to dry the cup holders. This
may damage the cup holder.

Seat warmer (if equipped)

The seat warmer is provided to warm
the front seats during cold weather.

Front seat

Rear seat

With the ignition switch or ENGINE
START/STOP button in the ON
position:

OMQ4A040071

OMQ4040074

OMQ4A040084

OMQ4040083

CarManuals2.com

Features of your vehicle

162

Interior features

• Push either of the levers/switch to

warm the driver's seat or the front
passenger's seat.

During mild weather or under conditions
where the operation of the seat warmer
is not needed, keep the levers/switch in
the "OFF" position.

The seat warmer defaults to the OFF
position whenever the ignition switch or
ENGINE START/STOP button is turned
on.

Temperature control (Manual)

• Each time you press the levers/switch,

the temperature setting of the seat will
change as follows:

- Front seat

- Rear seat

Temperature control (Automatic)

The seat warmer starts to automatically
control the seat temperature in order to
prevent low-temperature burns after
being manually turned ON.

You may manually press the button to
increase the seat temperature. However,
it soon returns to the automatic mode
again.
• When pressing the levers/switch for

more than 1.5 seconds with the seat

warmer operating, the seat warmer
will turn OFF.

NOTICE

With the seat warmer levers/switch in
the ON position, the heating system in
the seat turns off or on automatically
depending on the seat temperature.

CAUTION

• When cleaning the seats, do not use

an organic solvent such as paint thin

ner, benzene, alcohol and gasoline.
Doing so may damage the surface of
the heater or seats.

• To prevent overheating the seat

warmer, do not place anything on the
seats that insulate against heat, such
as blankets, cushions or seat covers
while the seat warmer is in operation.

• Do not place heavy or sharp objects

on seats equipped with seat warmers.
Damage to the seat warming compo

nents could occur.

• Do not change the seat cover. It may

damage the seat warmer or air venti

lation system.

W ARNING

Seat warmer burns
Passengers should use extreme caution
when using seat warmers due to the
possibility of excess heating or burns.
The seat warmer may cause burns even
at low temperatures, especially if used for
long periods of time. In particular, the
driver must exercise extreme care for the
following types of passengers:

1. Infants, children, elderly or handi

capped persons, or hospital outpa

tients

CarManuals2.com

163

Features of your vehicle

Interior features

2. Persons with sensitive skin or those

that burn easily

3. Fatigued individuals

4. Intoxicated individuals
5. Individuals taking medication that can

cause drowsiness or sleepiness
(sleeping pills, cold tablets, etc.)

Air ventilation seat (if equipped)

The temperature setting of the seat
changes according to the levers position.
• To ventilate your seat cushion, push

the levers.

Each time you push the levers, the air

flow will change as follows:

The seat warmer (with air ventilation)
defaults to the OFF position whenever
the ENGINE START/STOP button is
turned on.

NOTICE

This function is designed to automati

cally change the temperature setting of
the seat (High -> Low) to maintain maxi

mum comfort inside in case the engine

is stopped by ISG (Idle Stop and Go) sys

tem (if equipped).

CAUTION

Seat damage
• When cleaning the seats, do not use

an organic solvent such as paint thin

ner, benzene, alcohol and gasoline.
Doing so may damage the air ventila

tion seat.

• Do not place heavy or sharp objects

on the seat. Those things may dam

age the air ventilation seat.

• Be careful not to spill liquid such as

water or beverages on the seat. If you
spill some liquid, wipe the seat with a
dry towel. Before using the air ventila

tion seat, dry the seat completely.

Sun visor

Use the sun visor to shield direct light
through the front or side windows.

• To use the sun visor, pull it downward.

僅

To use the sun visor for the side win

dow, pull it downward, unsnap it from
the bracket (1) and swing it to the side
(2). You can slide the sun visor if nec

essary (3).

OMQ4A040085

OMQ4040075

CarManuals2.com

Features of your vehicle

164

Interior features

• To use the vanity mirror, pull down

the visor and slide the mirror cover
(4).

Press the ON button (

) to turn on

the lamp inside the sun visor when
using a mirror. Before returning the
sun visor to the original position, be
sure to press the OFF button (

) to

turn it off.

The ticket holder (5) is provided for
holding a tollgate ticket.

W ARNING

For your safety, do not block your view
when using the sun visor.

NOTICE

Do not put several tickets in the ticket
holder at one time. This could cause
damage to the ticket holder.

USB charger

The USB car charger allows drivers to
charge their digital devices such as
smartphones, and PC tablets.

Front

Rear (if equipped)

Plug the cable into the USB port, and
charging will begin.

The USB car charger is available with
either the ACC on or the ignition on. We
recommend you connect the USB port
and digital devices with the engine run

ning. See the display screen of the
device to check its charging process
completion. Your smartphone or table PC
could get heated up while charging. This
is no reason to worry, as it doesn't impact
life or functions of the device. For safety,
charging can be stopped if the battery
gets too high where the tem

perature

can negatively affect the device.
Charging some digital devices is not
available or requires special dedi

cated

adapters if their charging methods don't
fit the way the USB car charger works.
Quick Charge 2.0 is available on the
smart phone or the table PC equipped
with fast charging capabilities. The
applicable is as follows: (https://

www.qualcomm.com/documents/quick-

charge-device-list)

The smart phone or PC tablet without
fast charging is charged at a regular
speed.

Rated output:
• Digital devices with fast charging:

OMQ4A040079

OMQ4AH040080

CarManuals2.com

165

Features of your vehicle

Interior features

- 9.0 V, 1.67 A

• Digital devices with normal charging:

- 5.0 V, 2.1 A

CAUTION

• Use the USB car charger with the igni

tion on. Otherwise, Vehicle battery
can be discharged.

• Use the official USB cable of the man

ufacturer of the digital device to be
charged.

• Make sure that any foreign object,

drinks, and water do not come into
contact with the USB car charger.
Water or foreign objects can damage
the USB charger.

• Do not use devices that exceed cur

rent consumption of 2.1 A.

• If the charger is connected incorrectly,

it can cause serious damage to the
device. Please note that damages due
to incorrect usage are not covered by
warranty service.

Power outlet (if equipped)

The power outlet is designed to provide
power for mobile telephones or other
devices designed to operate with vehicle
electrical systems or other devices that
are compatible with the power outlet and
vehicle electrical system.

2nd row

3rd row

The devices should draw less than 15
amps with the vehicle on.

NOTICE

• Use the power outlet only when the

vehicle is on and remove the acces

sory plug after use. Using the acces

sory plug for prolonged periods of
time with the vehicle off could cause
the battery to discharge.

• Only use 12 V electric accessories

which are less than 15 A in electric
capacity.

• Adjust the air-conditioner or heater to

the lowest operating level when using
the power outlet.

• Close the cover when not in use.

OMQ4AH040076

OMQ4A040078

CarManuals2.com

Features of your vehicle

166

Interior features

• Some electronic devices can cause

electronic interference when plugged
into a vehicle's power outlet. These
devices may cause excessive audio
static and malfunctions in other elec

tronic systems or devices used in your
vehicle.

• Push the plug in as far as it will go. If

good contact is not made, the plug
may overheat and the fuse may open.

• Plug in battery equipped electronic

devices with reverse current protec

tion. The current from the battery may
flow into the vehicle's electrical/elec

tronic system and cause system mal

function.

W ARNING

Electric shock
Do not put a finger or a foreign object
(pen, etc.) into a power outlet and do not
touch with a wet hand. You may get an
electric shock.

AC Inverter (if equipped)

The AC inverter supplies 115V/150W
electric power to operate electric acces

sories or equipments.

• Rated Voltage: AC 115V
• Maximum electric power: 150W

• In order to avoid an electrical system

failure, electric shock, etc., be sure to
read owner's manual before use.

• Be sure to close the cover except

during the time of use.

W ARNING

To reduce a risk of serious or fatal inju

ries:
• Do not use a heated electric device

such as a coffee pot, toaster, heater,
iron, etc.

• Do not insert foreign objects into the

outlet and do not touch the outlet as
you may get shocked.

• Do not let children touch the AC

inverter.

NOTICE

• To prevent the battery from being dis

charged, do not use the AC inverter
while the engine is not running.

• When not using the AC inverter, make

sure to close the AC inverter cover.

• After using an electric accessory or

equipment, pull the plug out. Leaving
the accessory or equipment plugged
in for a long time may cause battery
discharge.

• Do not use an electric accessory or

equipment the power consumption of
which is greater than 150W (115V).

• Some electric accessories or equip

ments can cause electronic interfer

ence. It may cause excessive audio
noise and malfunctions in other elec

tric systems or devices in the vehicle.

• Do not use broken electric accessories

or equipments, which may damage
the AC inverter and electrical systems
of the vehicle.

OMQ4AH040077

CarManuals2.com

167

Features of your vehicle

Interior features

• Do not use two or more electric acces

sories or equipments at the same
time. It may cause damage to the
electrical systems of the vehicle.

• When the input voltage is lower, outlet

LED will blink and the AC inverter will
turn off automatically. If the input
voltage goes up to normal, the AC
inverter will turn on again.

Wireless smart phone charging
system (if equipped)

A wireless smart phone charging system
is located in front of the center console.

[A]: Indicator, [B]: Charging pad
Firmly close all doors, and make sure to
turn ON the ignition switch or press the
ENGINE START/STOP button. To start
wireless charging, place the smart
phone equipped with wireless charging
function on the wireless charging pad.

For best wireless charging results, place
the smart phone on the center of the
charging pad.

The wireless charging system is
designed for one smart phone equipped
with QI only. Please refer to the smart
phone accessory cover or the smart
phone manufacturer homepage to check
whether your smart phone sup

ports QI

function.

W ARNING

If any metallic object such as coins is
located between the wireless charging
system and the smart phone, the
charging may be disrupted. Also, the
metallic object may heat up.

Wireless smart phone charging

1. Remove any object on the smart

phone charging pad including the
smart key. If there is any foreign object
on the pad other than a smart phone,
the wireless charging function may not
operate properly.

2. Place the smart phone on the center

of the wireless charging pad.

3. The indicator light will change to

orange once the wireless charging
begins. After the charging is com

plete, the orange light will change to
green.

4. You can choose to turn the wireless

charging function to either ON or OFF
by selecting the USM on the instru

ment cluster. (Please refer to "Instru

ment cluster" on page 4-71 for
details).

If the wireless charging does not work,
gently move your smart phone around
the pad until the charging indicator light
turns yellow. Depending on the smart
phone, the charging indicator light may
not turn green even after the charging is
complete.

If the wireless charging is not function

ing properly, the orange light will blink
and flash for ten seconds then turn off. In
such cases, remove the smart phone
from the pad and replace it on the pad
again, or double check the charging sta

tus.

OMQ4A040082

CarManuals2.com

Features of your vehicle

168

Interior features

If you leave the smart phone on the
charging pad when the vehicle ignition is
in OFF, the vehicle will alert you through
warning messages and sound (applica

ble for vehicles with voice guidance
function) after the 'Good bye' function on
the instrument cluster ends.

For some manufacturers' smart phones,
the system may not warn you even
though the smart phone is left on the
wireless charging unit. This is due to the
particular characteristic of the smart
phone and not a malfunction of the
wireless charging.

W ARNING

Distracted driving
Driving while distracted can result in a
loss of vehicle control that may lead to an
accident, severe bodily injury or death.
The driver's primary responsibility is in the
safe and legal operation of a vehicle. Any
use of handheld devices, other
equipment, or vehicle systems that take
the driver's eyes, attention, and focus
away from the safe operation of a vehicle
are not permissible by law. These should
never be used during the opera

tion of

the vehicle.

CAUTION

Liquid in wireless charging system
To prevent liquid from damaging the
wireless smart phone charging system in
your vehicle, be sure not to spill liquid
over the charging system.

CAUTION

Metal in wireless charging system
If any metallic object such as a coin is
located between the wireless charging
system and the smart phone, the

charging may be disrupted. Also, the
metallic object may heat up and poten

tially damage the charging system. If
there is any metallic object between the
smart phone and the charging pad,
immediately remove the smart phone.
Remove the metallic object after it has
cooled down.

CAUTION

CarManuals2.com

• When the interior temperature of the

wireless charging system rises above
a set temperature, the wireless
charging will cease to function. After
the interior temperature drops below
the threshold, the wireless charging
function will resume.

• The wireless charging may not func

tion properly when there is a heavy
accessory cover on the smart phone.
