FANUC Robotics SYSTEM R-30iA and R-30iB Controller. KAREL Reference Manual - page 5

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

7.1

OVERVIEW

The KAREL language facilities allow you to perform the following serial input/output (I/O)

operations:

• Open data files and serial communication ports using the OPEN FILE Statement

• Close data files and serial communication ports using the CLOSE FILE Statement

• Read from files, communication ports, and user interface devices using the READ Statement

• Write to files, communication ports, and user interface devices using the WRITE Statement

• Cancel read or write operations

File variables are used to indicate the file, communication port, or device on which a serial I/O

operation is to be performed.

Buffers are used to hold data that has not yet been transmitted. The use of data items in READ and

WRITE statements and their format specifiers depend on whether the data is text (ASCII) or binary,

and on the data type.

7.2

FILE VARIABLES

A KAREL program can perform serial I/O operations on the following:

• Data files residing in the KAREL file system

• Serial communication ports associated with connectors on the KAREL controller

• User interface devices including the CRT/KB and teach pendant

A file variable is used to indicate the file, communication port, or device on which you want to

perform a particular serial I/O operation.

Table 7-1 lists the predefined file variables for user interface devices. These file variables are already

opened and can be used in the READ or WRITE statements.

Table 7-1. Predefined File Variables

IDENTIFIER

DEVICE

OPERATIONS

TPFUNC*

Teach pendant function key line

Both

TPDISPLAY*

Teach pendant KAREL display

Both

TPPROMPT*

Teach pendant prompt line

Both

TPERROR

Teach pendant message line

Write

TPSTATUS*

Teach pendant status line

Write

7-3

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-1. Predefined File Variables (Cont’d)

CRTFUNC*

CRT/KB function key line

Both

INPUT

CRT/KB keyboard

Read

OUTPUT*

CRT/KB KAREL screen

Write

CRTPROMPT*

CRT/KB prompt line

Both

CRTERROR

CRT/KB message line

Write

CRTSTATUS*

CRT/KB status line

Write

* Only displayed when teach pendant or CRT is in the user menu.

A file variable can be specified in a KAREL statement as a FILE variable. Using FILE in a KAREL

Program shows an example of declaring a FILE variable and of using FILE in the executable section

of a program.

Using FILE in a KAREL Program

PROGRAM lun_prog

VAR

curnt_file : FILE

ROUTINE input_data(file_spec:FILE) FROM util_prog

BEGIN

OPEN FILE curnt_file (’RW’,’text.dt’)

--variable FILE

input_data(curnt_file)

--file variable argument

WRITE TPERROR (’Error has occurred’)

END lun_prog

Sharing FILE variables between programs is allowed as long as a single task is executing the

programs. Sharing file variables between tasks is not allowed.

7.3

OPEN FILE STATEMENT

The OPEN FILE statement associates the file variable with a particular data file or communication

port.

The association remains in effect until the file is closed, either explicitly by a CLOSE FILE statement

or implicitly when program execution terminates or is aborted.

The OPEN FILE statement specifies how the file is to be used (usage string), and which file or

port (file string) is used.

7-4

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

7.3.1

Setting File and Port Attributes

Attributes specify the details of operation of a serial port, or KAREL FILE variable. The

SET_PORT_ATR and SET_FILE_ATR built-ins are used to set these attributes. SET_FILE_ATR

must be called before the FILE is opened. SET_PORT_ATR can be called before or after the FILE

that is using a serial port, is opened.

Table 7-2 lists each attribute type, its function and whether the attribute is intended for use with

teach pendant and CRT/KB devices, serial ports, data files, or pipes. Refer to Appendix A for more

information.

Table 7-2. Predefined Attribute Types

ATTRIBUTE TYPE

FUNCTION

SET_PORT_ATR OR

TP/ CRT

SERIAL

DATA

PIPES

SOCKET

SET_FILE_ATR

PORTS

FILES

MESSAGING

ATR_BAUD

Baud rate

SET_PORT_ATR

not used

valid

not

not

not used

used

used

ATR_DBITS

Data length

SET_PORT_ATR

not used

valid

not

not

not used

used

used

ATR_EOL

End of line

SET_FILE_ATR

not used

valid

not

valid

valid

used

ATR_FIELD

Field

SET_FILE_ATR

valid

valid

valid

valid

valid

ATR_IA

Interactively

SET_FILE_ATR

valid

valid

valid

valid

valid

write

ATR_MODEM

Modem line

SET_PORT_ATR

not used

valid

not

not

not used

used

used

ATR_PARITY

Parity

SET_PORT_ATR

not used

valid

not

not

not used

used

used

ATR_PASSALL

Passall

SET_FILE_ATR

valid

valid

not

valid

valid

used

ATR_READAHD

Read ahead

SET_PORT_ATR

not used

valid

not

not

not used

buffer

used

used

ATR_REVERSE

Reverse

SET_FILE_ATR

not used

valid

valid

valid

valid

transfer

ATR_SBITS

Stop bits

SET_PORT_ATR

not used

valid

not

not

not used

used

used

ATR_TIMEOUT

Timeout

SET_FILE_ATR

valid

valid

not

valid

valid

used

ATR_UF

Unformatted

SET_FILE_ATR

not used

valid

valid

valid

valid

transfer

7-5

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-2. Predefined Attribute Types (Cont’d)

ATTRIBUTE TYPE

FUNCTION

SET_PORT_ATR OR

TP/ CRT

SERIAL

DATA

PIPES

SOCKET

SET_FILE_ATR

PORTS

FILES

MESSAGING

ATR_XONOFF

XON/XOFF

SET_PORT_ATR

not used

valid

not

not

not used

used

used

ATR_PIPOVADV

Pipe

SET_FILE_ATR

not used

not

not

valid

valid

Overflow

used

used

ATR_PIPWAIT

Wait for data

SET_FILE_ATR

not used

not

not

valid

valid

used

used

Table 7-3 contains detailed explanations of each attribute.

Table 7-3. Attribute Values

Attribute Type

Description

Valid Device

Usage Mode

Valid Values

Default Value

ATR_BAUD

The baud rate of a serial

PORT

Read/ Write

BAUD_9600:

BAUD_9600

Baud rate

port can be changed to

9600 baud

one of the valid attribute

BAUD_4800:

values.

4800 baud

BAUD_2400:

2400 baud

BAUD_1200:

1200 baud

ATR_DBITS

If specified, the data

PORT

Read/ Write

DBITS_5: 5 bits

DBITS_8

Data length

length for a serial port is

DBITS_6: 6 bits

changed to the specified

DBITS_7: 7 bits

attribute values.

DBITS_8: 8 bits

ATR_EOL

If specified, the serial port

PORT

Read/ Write

Any ASCII

13

(carriage return)

End of line

is changed to terminate

character code

read when the specified

attribute value. Refer to

Appendix D , for a listing

of valid attribute values.

ATR_FIELD

If specified, the amount

TP/CRT,

Read only

Ignored

Read data until

Field

of data read depends on

PORT, FILE

terminator character

the format specifier in

(EOL) appears

the READ statement, or

the default value of the

data type being read. If

not specified, the data is

read until the terminator

character (EOL) appears.

7-6

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-3. Attribute Values (Cont’d)

Attribute Type

Description

Valid Device

Usage Mode

Valid Values

Default Value

ATR_IA

If specified, the contents

TP/CRT,

Write only

Ignored

TP/CRT is

Interactively write

of the buffer are output

PORT, FILE

interactive, PORT,

when each write operation

FILE are not

to the buffer is complete.

interactive

(Interactive)

If not specified, the

contents of the buffer

are output only when the

buffer becomes full or

when CR is specified.

The size of the output

buffer is 256 bytes. (Not

interactive)

ATR_MODEM

Refer to "Modem Line"

Modem line

section that follows for

information.

ATR_PARITY

The parity for a serial port

PORT

Read/ Write

PARITY_NONE:

PARITY_NONE

Parity

can be changed to one of

No parity

the valid attribute values.

PARITY_ODD:

Odd parity

PARITY_EVEN:

Even parity

ATR_PASSALL

If specified, input is read

TP/CRT, PORT

Read only

Ignored

Read only the

Passall

without interpretation

displayable keys

or transaction. Since

until enter key is

the terminator character

pressed

(EOL) will not terminate

the read, the field attribute

automatically assumes

the ‘‘field’’ option.

ATR_PIPOVADV

Configures the behavior of

PIPE

Read

The value must

The value parameter

the read when an overflow

be between 0

is either OVF_EOF

occurs. By default the

and the total

(sets the default

behavior is to signal an

number of bytes

behavior) or the

end of file (EOF) when the

in the pipe. The

number of bytes to

overflow occurs.

value will be

advance when an

rounded up

overflow occurs.

to the nearest

binary record.

7-7

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-3. Attribute Values (Cont’d)

Attribute Type

Description

Valid Device

Usage Mode

Valid Values

Default Value

ATR_PIPWAIT

The read operation waits

PIPE

Read

WAIT_USED or

The default is

for data to arrive in the

WAIT_NOTUSED

snapshot which

pipe.

means that the

system returns an

EOF when all the

data in the pipe has

been read.

ATR_READAHD

The attribute value is

PORT

Read/ Write

any positive

1

(128 byte buffer)

Read Ahead Buffer

specified in units of 128

integer

bytes, and allocates a

1=128 bytes

read ahead buffer of the

2=256 bytes

indicated size.

0=disable bytes

ATR_REVERSE

The bytes will be

PORT, FILE

Read/ Write

Ignored

Not reverse transfer

Reverse transfer

swapped.

ATR_SBITS

This specifies the number

PORT

Read/ Write

SBITS_1:1 bit

SBITS_1

Stop bits

of stop bits for the serial

SBITS_15: 1.5

port.

bits

SBITS_2:2 bits

ATR_TIMEOUT

If specified, an error will be

TP/CRT, PORT

Read only

Any integer

0

(external)

Timeout

returned by IO_STATUS

value (units are

if the read takes longer

in msec)

than the specified attribute

value.

ATR_UF

If specified, a binary

PORT, FILE

Read/ Write

Ignored

ASCII transfer

Unformatted

transfer is performed.

transfer

For read operations,

the terminator character

(EOL) will not terminate

the read, and therefore

automatically assumes

the ‘‘field’’ option. If not

specified, ASCII transfer

is performed.

ATR_XONOFF

If specified, the

PORT

Read/ Write

XF_NOT_USED:

XF_USED

XON/XOFF

XON/XOFF for a serial

Not used

port is changed to the

XF_USED: Used

specified attribute value.

7-8

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

See Also: Chapter 9 FILE SYSTEM , for a description of file names and file types.

7.3.3

Usage String

The usage string in an OPEN FILE statement indicates how the file is to be used.

• It is composed of one usage specifier.

• It applies only to the file specified by the OPEN FILE statement and has no effect on other FILEs.

• It must be enclosed in single quotes if it is expressed as a literal.

• It can be expressed as a variable or a constant.

Table 7-4 lists each usage specifier, its function, and the devices or ports for which it is intended.

•

‘‘TP/CRT’’ indicates teach pendant and CRT/KB.

•

‘‘Ports’’ indicates serial ports.

•

‘‘Files’’ indicates data files.

•

‘‘Pipes’’ indicates pipe devices.

•

‘‘Valid’’ indicates a permissible use.

•

‘‘No use’’ indicates a permissible use that might have unpredictable side effects.

Table 7-4.

Usage Specifiers

SPECIFIER

FUNCTION

TP/CRT

PORTS

FILES

PIPES

RO

valid

valid

valid

valid

— Permits only read

operations

— Sets file position to

beginning of file

— File must already exist

7-11

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table

7-4.

Usage Specifiers (Cont’d)

RW

valid

valid

valid

valid

No use on

— Rewrites over existing

FRx:

data in a file, deleting

existing data

— Permits read and

write operations

— Sets file position to

beginning of file

— File will be created if it

does not exist

AP

no use

valid

valid -RAM

valid

disk* no use

— Appends to end of

on FRx:

existing data

— Permits read and

write (First operation

must be a write.)

— Sets file position to

end of file

— File will be created if it

does not exist

UD

no use

valid

valid -RAM

no use

disk* no use

— Updates from

on FRx:

beginning of existing

data.

(Number of

characters to be

written must equal

number of characters

to be replaced.)

— Overwrites the

existing data with

the new data

— Permits read and

write

— Sets file position to

beginning of existing

file

7-12

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Buffers are used by the READ and WRITE statements as follows:

• During the execution of a READ statement, if more data was read from the file than required by

the READ statement, the remaining data is kept in a buffer for subsequent read operations. For

example, if you enter more data in a keyboard input line than is required to satisfy the READ

statement the extra data is kept in a buffer.

• If a WRITE statement is executed to a non-interactive file and the last data item was not a CR, the

data is left in a buffer until a subsequent WRITE either specifies a CR or the buffer is filled.

• The total data that can be processed in a single READ or WRITE statement is limited to 127 bytes.

7.8

FORMATTING TEXT (ASCII) INPUT/OUTPUT

This section explains the format specifiers used to read and write ASCII (formatted) text for each

data type.

The following rules apply to formatting data types:

•

For text files, data items in READ and WRITE statements can be of any of the simple data types

(INTEGER, REAL, BOOLEAN, and STRING).

•

Positional and VECTOR variables cannot be read from text files but can be used in WRITE

statements.

•

ARRAY variables cannot be read or written in unsubscripted form. The elements of an ARRAY

are read or written in the format that corresponds to the data type of the ARRAY.

•

PATH variables cannot be read or written.

•

Some formats and data combinations are not read in the same manner as they were written or

become invalid if read with the same format.

The amount of data that is read or written can be controlled using zero, one, or two format

specifiers for each data item in a READ or WRITE statement. Each format specifier, represented

as an INTEGER literal, is preceded by double colons (::).

Table 7-5 summarizes the input format specifiers that can be used with the data items in a READ

statement. The default format of each data type and the format specifiers that can affect each

data type are explained in Section 7.8.1 , through Section 7.8.6 .

Table

7-5.

Text (ASCII) Input Format Specifiers

DATA TYPE

1ST FORMAT SPECIFIER

2ND FORMAT SPECIFIER

INTEGER

Total number of characters read

Number base in range 2 - 16

REAL

Total number of characters read

Ignored

7-18

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-5. Text (ASCII) Input Format Specifiers (Cont’d)

DATA TYPE

1ST FORMAT SPECIFIER

2ND FORMAT SPECIFIER

BOOLEAN

Total number of characters read

Ignored

STRING

Total number of characters read

0 - unquoted STRING

2 - quoted STRING

Table 7-6 summarizes the output format specifiers that can be used with the data items in a WRITE

statement. The default format of each data type and the format specifiers that can affect each data type

are explained in Section 7.8.1 through Section 7.8.6 .

Table 7-6. Text (ASCII) Output Format Specifiers

DATA TYPE

1ST FORMAT SPECIFIER

2ND FORMAT SPECIFIER

INTEGER

Total number of characters written

Number base in range 2-16

REAL

Total number of characters written

Number of digits to the right of decimal

point to be written

If negative, uses scientific notation

BOOLEAN

Total number of characters written

0 - Left justified

1 - Right justified

STRING

Total number of characters written

0 - Left justified

1 - Right justified

2 - Left justified in quotes (leading blank)

3 - Right justified n quotes (leading blank)

VECTOR

Uses REAL format for each component

Uses REAL format for each component

POSITION

Uses REAL format for each component

Uses REAL format for each component

XYZWPR

Uses REAL format for each component

Uses REAL format for each component

XYZWPREXT

Uses REAL format for each component

Uses REAL format for each component

JOINTPOSn

Uses REAL format for each component

Uses REAL format for each component

7.8.1

Formatting INTEGER Data Items

INTEGER data items in a READ statement are processed as follows:

Default: Read as a decimal (base 10) INTEGER, starting with the next nonblank character on the

input line and continuing until a blank or end of line is encountered. If the characters read do not

form a valid INTEGER, the read operation fails.

7-19

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

First Format Specifier: Indicates the total number of characters to be read. The input field must be

entirely on the current input line and can include leading, but not trailing, blanks.

Second Format Specifier: Indicates the number base used for the input and must be in the range of 2

(binary) to 16 (hexadecimal).

For bases over 10, the letters A, B, C, D, E, and F are used as input for the digits with values 10, 11,

12, 13, 14, and 15, respectively. Lowercase letters are accepted.

Table 7-7 lists examples of INTEGER input data items and their format specifiers. The input data

and the resulting value of the INTEGER data items are included in the table. (The symbol [eol]

indicates end of line.)

Table 7-7. Examples of INTEGER Input Data Items

DATA ITEM

INPUT DATA

RESULT

int_var

-2[eol]

int_var = -2

int_var

20 30 ...

int_var = 20

int_var::3

10000

int_var = 100

int_var::5::2

10101

int_var = 21

(base 2 input)

(base 10 value)

int_var

1.00

format error

(invalid INTEGER)

int_var::5

100[eol]

format error

(too few digits)

INTEGER data items in a WRITE statement are formatted as follows:

Default: Written as a decimal (base 10) INTEGER using the required number of digits and one

leading blank. A minus sign precedes the digits if the INTEGER is a negative value.

First Format Specifier: Indicates the total number of characters to be written, including blanks and

minus sign. If the format specifier is larger than required for the data, leading blanks are added. If it is

smaller than required, the field is extended as required.

The specifier must be in the range of 1 to 127 for a file or 1 to 126 for other output devices.

Second Format Specifier: Indicates the number base used for the output and must be in the range of

2

(binary) to 16 (hexadecimal).

If a number base other than 10 (decimal) is specified, the number of characters specified in the first

format specifier (minus one for the leading blank) is written, with leading zeros added if needed.

For bases over 10, the letters A, B, C, D, E, and F are used as input for the digits with values 10,

11, 12, 13, 14, and 15, respectively.

7-20

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-8 lists examples of INTEGER output data items and their format specifiers. The output

values of the INTEGER data items are also included in the table. Double quotes are used in the table

as delimiters to show leading blanks; however, double quotes are not written by KAREL programs.

Table 7-8. Examples of INTEGER Output Data Items

DATA ITEM

OUTPUT

COMMENT

123

Leading blank

"

123

"

-5

Leading blank

"

-5

"

123::6

Right justified (leading blanks)

"

123

"

-123::2

Expanded as required

"

-123

"

1024::0::16

Hexadecimal output

"

400

"

7-21

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-8. Examples of INTEGER Output Data Items (Cont’d)

DATA ITEM

OUTPUT

COMMENT

5::6::2

Binary output (leading zeros)

"

00101

"

-1::9::16

Hexadecimal output

"

FFFFFFFF

"

7.8.2

Formatting REAL Data Items

REAL data items in a READ statement are processed as follows:

Default: Read starting with the next nonblank character on the input line and continuing until a

blank or end of line is encountered.

Data can be supplied with or without a fractional part. The E used for scientific notation can be in

upper or lower case. If the characters do not form a valid REAL, the read operation fails.

First Format Specifier: Indicates the total number of characters to be read. The input field must be

entirely on the current input line and can include leading, but not trailing, blanks.

Second Format Specifier: Ignored for REAL data items.

Table 7-9 lists examples of REAL input data items and their format specifiers. The input data and the

resulting value of the REAL data items are included in the table. The symbol [eol] indicates end of

line and X indicates extraneous data on the input line.

7-22

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-9. Examples of REAL Input Data Items

DATA ITEM

INPUT DATA

RESULT

real_var

1[eol]

1.0

real_var

1.000[eol]

1.0

real_var

2.5 XX

2.50

real_var

1E5 XX

100000.0

real_var::7

2.5 XX

format error (trailing blank)

real_var

1E

format error (no exponent)

real_var::4

1E 2

format error (embedded blank)

REAL data items in a WRITE statement are formatted as follows:

Default: Written in scientific notation in the following form:

(blank)(msign)(d).(d)(d)(d)(d)(d)E(esign)(d)(d)

where:

(blank) is a single blank

(msign) is a minus sign, if required

(d) is a digit

(esign) is a plus or minus sign

First Format Specifier: Indicates the total number of characters to be written, including all the digits,

blanks, signs, and a decimal point. If the format specifier is larger than required for the data, leading

blanks are added. If it is smaller than required, the field is extended as required.

In the case of scientific notation, character length should be greater than (8 + 2nd format specifier)

to write the data completely.

The specifier must be in the range of 1 to 127 for a file or 1 to 126 for other output devices.

Second Format Specifier: Indicates the number of digits to be output to the right of the decimal

point, whether or not scientific notation is to be used.

The absolute value of the second format specifier indicates the number of digits to be output to the

right of the decimal point.

If the format specifier is positive, the data is displayed in fixed format (that is, without an exponent).

If it is negative, scientific notation is used.

7-23

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-10 lists examples of REAL output data items and their format specifiers. The output values of

the REAL data items are also included in the table. Double quotes are used in the table as delimiters

to show leading blanks; however, double quotes are not written by KAREL programs.

Table 7-10.

Examples of REAL Output Data Items

DATA ITEM

OUTPUT

COMMENT

123.0

Scientific notation (default format)

"

1.23000E+02

"

123.456789

Rounded to 5 digits in fractional part

"

1.23457E+02

"

.00123

Negative exponent

"

1.23000E-03

"

-1.00

Negative value

"

-1.00000E+00

"

-123.456::9

Field expanded

"

-1.234560E+02

"

123.456::12

Leading blank added

"

1.234560E+02

"

7-24

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-10. Examples of REAL Output Data Items (Cont’d)

DATA ITEM

OUTPUT

COMMENT

123.456::9::2

Right justified and rounded

"

123.46

"

123.::12::-3

Scientific notation

"

1.230E+02

"

7.8.3

Formatting BOOLEAN Data Items

BOOLEAN data items in a READ statement are formatted as follows:

Default: Read starting with the next nonblank character on the input line and continuing until a

blank or end of line is encountered.

Valid input values for TRUE include TRUE, TRU, TR, T, and ON. Valid input values for FALSE

include FALSE, FALS, FAL, FA, F, OFF, and OF. If the characters read do not form a valid

BOOLEAN, the read operation fails.

First Format Specifier: Indicates the total number of characters to be read. The input field must be

entirely on the current input line and can include leading, but not trailing, blanks.

Second Format Specifier: Ignored for BOOLEAN data items.

Table 7-11 lists examples of BOOLEAN input data items and their format specifiers. The input data

and the resulting value of the BOOLEAN data items are included in the table. (The symbol [eol]

indicates end of line and X indicates extraneous data on the input line.)

7-25

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-11.

Examples of BOOLEAN Input Data Items

DATA ITEM

INPUT DATA

RESULT

bool_var

FALSE[eol]

FALSE

bool_var

FAL 3...

FALSE

bool_var

T[eol]

TRUE

bool_var::1

FXX

FALSE (only reads ‘‘ F’’)

bool_var

O[eol]

format error (ambiguous)

bool_var

1.2[eol]

format error (not BOOLEAN)

bool_var::3

F [eol]

format error (trailing blanks)

bool_var::6

TRUE[eol]

format error (not enough data)

BOOLEAN data items in a WRITE statement are formatted as follows:

Default: Written as either ‘‘TRUE’’ or ‘‘FALSE". (Double quotes are used in the table as delimiters

to show leading blanks; however, double quotes are not written by KAREL programs.)

First Format Specifier: Indicates the total number of characters to be written, including blanks (a

leading blank is always included). If the format specifier is larger than required for the data, trailing

blanks are added. If it is smaller than required, the field is truncated on the right.

The specifier must be in the range of 1 to 127 for a file or 1 to 126 for other output devices.

Second Format Specifier: Indicates whether the data is left or right justified. If the format specifier

is equal to 0, the output word is left justified in the output field with one leading blank, and trailing

blanks as required. If it is equal to 1, the output word is right justified in the output field, with

leading blanks as required.

Table 7-12 lists examples of BOOLEAN output data items and their format specifiers. The output

values of the BOOLEAN data items are also included in the table. Double quotes are used in the table

as delimiters to show leading blanks; however, double quotes are not written by KAREL programs.

7-26

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-12.

Examples of BOOLEAN Output Data Items

DATA ITEM

OUTPUT

COMMENT

FALSE

Default includes a leading blank

"

FALSE

"

TRUE

TRUE is shorter than FALSE

"

TRUE

"

FALSE::8

Left justified (default)

"

FALSE

"

FALSE::8::1

Right justified

"

FALSE

"

TRUE::2

Truncated

"

T

"

7.8.4

Formatting STRING Data Items

STRING data items in a READ statement are formatted as follows:

Default: Read starting at the current position and continuing to the end of the line. If the length of the

data obtained is longer than the declared length of the STRING, the data is truncated on the right. If it

is shorter, the current length of the STRING is set to the actual length.

7-27

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

First Format Specifier: Indicates the total field length of the input data. If the field length is longer

than the declared length of the STRING, the input data is truncated on the right. If it is shorter, the

current length of the STRING is set to the specified field length.

Second Format Specifier: Indicates whether or not the input STRING is enclosed in single quotes. If

the format specifier is equal to 0, the input is not enclosed in quotes.

If it is equal to 2, the input must be enclosed in quotes. The input is scanned for the next nonblank

character. If the character is not a quote, the STRING is not valid and the read operation fails.

If the character is a quote, the remaining characters are scanned until another quote or the end of line

is found. If another quote is not found, the STRING is not valid and the read operation fails.

If both quotes are found, all of the characters between them are read into the STRING variable, unless

the declared length of the STRING is too short, in which case the data is truncated on the right.

Table 7-13 lists examples of STRING input data items and their format specifiers, where str_var

has been declared as a STRING[5]. The input data and the resulting value of the STRING data

items are included in the table. The symbol [eol] indicates end of line and X indicates extraneous

data on the input line.

Table 7-13.

Examples of STRING Input Data Items

DATA ITEM

INPUT DATA

RESULT

str_var

"

"

ABC[eol]

ABC

"

"

str_var

"

"

ABCDEFG[eol]

ABCDE

"

"

(FG is read but the STRING is truncated to 5

characters)

7-28

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-13.

Examples of STRING Input Data Items (Cont’d)

DATA ITEM

INPUT DATA

RESULT

str_var

"

"

’ABC’XX

’AB

"

"

(blanks and quote are read as data)

str_var::0::2

"

"

’ABC’XX

’ABC’

"

"

(read ends with second quote)

STRING data items in a WRITE statement are formatted as follows:

Default: Content of the STRING is written with no trailing or leading blanks or quotes.

The STRING must not be over 127 bytes in length for files or 126 bytes in length for other output

devices. Otherwise, the program will be aborted with the ‘‘STRING TOO LONG’’ error.

First Format Specifier: Indicates the total number of characters to be written, including blanks. If

the format specifier is larger than required for the data, the data is left justified and trailing blanks are

added. If the format specifier is smaller than required, the STRING is truncated on the right.

The specifier must be in the range of 1 to 127 for a file or 1 to 126 for other output devices.

Second Format Specifier: Indicates whether the output is to be left or right justified and whether the

STRING is to be enclosed in quotes using the following values:

0 left justified, no quotes

1 right justified, no quotes

2 left justified, quotes

3 right justified, quotes

Quoted STRING values, even if left justified, are preceded by a blank. Unquoted STRING values are

not automatically preceded by a blank.

7-29

7. FILE INPUT/OUTPUT OPERATIONS

MARRC75KR07091E Rev D

Table 7-14 lists examples of STRING output data items and their format specifiers. The output values

of the STRING data items are also included in the table. Double quotes are used in the table as

delimiters to show leading blanks; however, double quotes are not written by KAREL programs.

Table 7-14.

Examples of STRING Output Data Items

DATA ITEM

OUTPUT

COMMENT

’ABC’

No leading blanks

"

ABC

"

’ABC’::2

Truncated on right

"

AB

"

’ABC’::8

Left justified

"

ABC

"

’ABC’::8::0

Same as previous

"

ABC

"

’ABC’::8::1

Right justified

"

ABC

"

’ABC’::8::2

Note leading blank

"

’ABC’

"

7-30

MARRC75KR07091E Rev D

7. FILE INPUT/OUTPUT OPERATIONS

Table 7-14. Examples of STRING Output Data Items (Cont’d)

DATA ITEM

OUTPUT

COMMENT

’ABC’::8::3

Right justified

"

’ABC’

"

’ABC’::4::2

Truncated

"

’A’

"

Format specifiers for STRING data items can cause the truncation of the original STRING values

or the addition of trailing blanks when the values are read again.

If STRING values must be successively written and read, the following guidelines will help you

ensure that STRING values of varying lengths can be read back identically:

• The variable into which the STRING is being read must have a declared length at least as long as

the actual STRING that is being read, or truncation will occur.

• Some provision must be made to separate STRING values from preceding variables on the

same data line. One possibility is to write a ’ ’ (blank) between a STRING and the variable

that precedes it.

• If format specifiers are not used in the read operation, write STRING values at the ends of their

respective data lines (that is, followed in the output list by a CR) because STRING variables

without format specifiers are read until the end of the line is reached.

• The most general way to write string values to a file and read them back is to use the format

::0::2 for both the read and write.

7.8.5

Formatting VECTOR Data Items

VECTOR data items cannot be read from text (ASCII) files. However, you can read three REAL

values and assign them to the elements of a VECTOR variable. VECTOR data items in a WRITE

statement are formatted as three REAL values on the same line.

Table 7-15 lists examples of VECTOR output data items and their format specifiers, where vect.x

= 1.0, vect.y= 2.0, vect.z = 3.0. The output values of the VECTOR data items are also included in

7-31

Content      ..     3      4      5      6     ..
