Electrical System 3D-16
1 Roof body
2 Rear interior lamp bracket 3 Rear interior lamp 4 Bolt 5 Rear interior lamp cover Removal/Installation of Rear Interior 1. Remove the negative cable of the battery. 2. After Alice the dome using a flathead screwdriver. 3. Remove the connectors. 4. Replace the rear interior lamps.
1 Roof body
2 Rear interior lamp (High version) Removal/Installation of Rear Interior
Lamp Bulb This interior lamp is of LED source, so please Trunk Lamp Removal/Installation of Trunk Lamp 1. Disconnect the negative cable of the battery. 2. Pry up the trunk lamp and remove it. 3. Remove the connector and remove the trunk lamp. 4. Perform the installation in reverse order of the removal.
1
C-pillar trim trunk
2
Trunk lamp
Removal/Installation of Trunk Lamp This trunk lamp is of LED source, so please Courtesy Lamp Removal/Installation of Courtesy Lamp 1. Remove the negative cable of the battery. 2. Remove the front door trim plate body. 3. Remove the connector. 4. Unscrew the back of the front door trim body lamps. 5. Perform the installation in reverse order of the removal.
1 Courtesy lamp cover 2 Front door trim plate body |
