Maserati Grandturismo Sport. Service Manual - part 10

5

152

Decreasing the speed stored

The speed stored can be reduced in
two ways:
-  by deactivating the device, pressing

the brake pedal and then storing
the new speed (turning the
rotating section B to position (+) for
at least three seconds);

or
-  by keeping the rotating section B

turned to position (-) until reaching
the new speed, which will be stored
automatically.

Resetting the speed stored

The speed stored is automatically
reset:
-  by turning the engine off
or
-  by turning switch A to OFF.

When driving with Cruise
Control activated, do not
shift to Neutral. Activate

Cruise Control only when traffic and
road conditions permit safe use of
this device, that is: on straight and
dry roads, expressways or highways,
smooth-flowing traffic and smooth
asphalt. Do not activate this device
when driving in town or in heavy
traffic.

Cruise Control can only
be activated at speeds
exceeding 19 mph (30 km/h).

The device can only be
activated in 4th, 5th or 6th
gear, depending upon the

vehicle speed.

When driving downhill with
the device activated, the
vehicle may pick up speed

slightly exceeding the speed stored,
due to the change in the engine load.

In the event of
malfunctioning or failure
of the device, turn switch A

to OFF and contact your Authorized
Maserati Dealer after having checked
that the relative fuse is in proper
working order.

It is advisable to deactivate
the device when it is not in
use. Turn switch A to OFF

to prevent any speeds from being
unintentionally stored.

5

153

Skyhook suspension

The electronic system controlling
the vehicle suspension uses the
sophisticated on board sensors
and is aimed at optimizing vehicle
performance.
The system is capable of constantly
monitoring suspension damping by
means of the actuator fitted on each
shock absorber. This way, the shock
absorber setting is suited to the
road surface conditions and vehicle
dynamics, thus improving passenger
comfort and road-holding.
By pressing button A the drivers
can choose, even while driving, a
normal or racing-type setting for the
suspension, depending on their own
driving style. This way, the system
operates with a shock absorber
“softer” setting in NORMAL mode,
and a “harder” setting if SPORT mode
is selected.

The system is controlled by an
ECU which is designed to manage
the solenoid valves on each shock
absorber in response to the sensor
signals, thus adjusting suspension
damping and setting.
The sensors which enable the ECU
to calculate the vehicle speed,
vertical and side acceleration, as
well as the instantaneous braking
system pressure, thereby controlling
suspension damping, are the
following:
-  front left-hand vertical acceleration

sensor;

-  front right-hand vertical

acceleration sensor;

-  rear vertical acceleration sensor;
-  front left-hand wheel acceleration

sensor;

-  front right-hand wheel acceleration

sensor;

-  lateral acceleration sensor;
-  driving speed sensor;
-  brake pedal switch.

The strategy used by the system
controlling suspension damping
is aimed at reducing the vertical
oscillations of the vehicle (rolling and
pitching) to a minimum.
The activation of SPORT mode
sets the suspension for sports-style
driving and acts on the ASR and
Automatic Gearbox systems (optional
equipment) as well, modifying their
setting for racing-style driving.

Self-diagnostics

Each time the engine is started, the
system performs a self-diagnostic
cycle, if a malfunction is found,
the relative symbol   is displayed
accompanied by the message “Check
suspension”.

A

5

154

Calibration selection

The driver can select, in relation to
road surface conditions, vehicle speed,
driving style and comfort, one of the
two calibration levels provided by the
system: normal or sports-style.
Normal calibration, active when
SPORT mode is disabled, favors
comfort and higher driving stability
with low and average grip conditions.
Sports-style calibration, active when
SPORT mode is enabled, favors wheel
drive and is designed to permit more
sporty driving with optimal road
holding.
Whenever the engine is started,
the system automatically activates
NORMAL mode, even if SPORT mode
was selected before the engine was
last turned off.
The SPORT mode calibration can
be selected only with the ignition
key in MAR (ON) position and it is
enabled by pressing button A, even
while driving: when SPORT mode is
activated, the word “SPORT” on the
multi-function display and the LED on
the button illuminate.

WARNING: SPORT mode should not
be activated if the road surface is
rough or slippery.

Press button A: to reset the normal
calibration, also while driving. When
the normal calibration is activated,
the “SPORT” warning light on the
multi-function display and the button
LED go off.

The electronic suspension control
system works in combination with
the ESC system (Electronic Stability
Control): when the suspension is set
to normal, stability is increased under
medium and low grip conditions,
while when SPORT mode is enabled,
the ESC system optimizes racing-style
driving.

WARNING: In low- and medium-grip
conditions (e.g., rain, snow, ice, sand,
etc.) it is advisable not to use SPORT
mode, even with the ESC enabled.

5

155

Malfunction indicators

If one or more electric components
in the system prove to be
malfunctioning while driving, the
ECU illuminates the relative warning
light   accompanied by the message
“Check suspension” on the display.
In addition, the ECU calibrates the
shock absorbers to a preset value,
thus helping to ensure a safe vehicle
set up.
Should the malfunction involve
one shock absorber only, this will
no longer be controlled by the ECU
and will therefore remain set as it
was when the fault occurred. It is
therefore possible for one of the four
shock absorbers to work with a fixed
calibration, different from that of the
other ones.

WARNING: In the event of a
malfunction in the suspension control
electronic system, which will be
indicated by the illumination of the
warning light   on the display while
driving, keep a moderate speed and
have the vehicle checked as soon as
possible by your Authorized Maserati
Dealer.

If a malfunction occurs while
driving, and this is signaled by the
illumination of the warning light
on the display, it is advisable to stop
the vehicle as soon as possible, turn
the ignition key to STOP (OFF) and
then restart the engine.

If the malfunction is no longer
present and the warning light   on
the display does not illuminate again,
the electronic suspension system will
resume normal operation. On the
other hand, if the problem persists,
the warning light   on the multi-
function display will turn on again.
In both cases, the system must be
checked by your Authorized Maserati
Dealer.
The fault found is memorized by the
ECU and can be diagnosed by your
Authorized Maserati Dealer even if it
has disappeared from the display.

5

156

Headlights

Bi-xenon headlights

The gas-discharge (Xenon) headlights
work by means of an electric arc
saturated with Xenon gas under
pressure, instead of the incandescent
filament.
The light produced is highly superior
to that of traditional light bulbs, in
terms of quality (brighter light) as
well as in relation to the span and
positioning of the area illuminated.
The advantages offered by improved
lighting are clearly perceivable
by the driver (less eye strain and
increased orientation for the driver,
with consequent enhanced driving
safety). This is particularly perceived
in the case of bad weather, fog and/or
insufficient road indications, thanks to
the broader illumination of the side
zones, which are normally left in the
dark.

The broader illumination of the
side zones helps to increase driving
safety as it allows the driver to better
locate anybody at the sides of the
road (pedestrians, bicycle riders and
motorcycle riders).
The electric arc requires very high
voltage for activation, but afterwards
power is supplied at a lower voltage.
The headlights reach maximum
brightness about 0.5 seconds after
being turned on.

The strong light produced by this type
of headlight requires the use of an
automatic system to keep the position
of the headlights constant and to
avoid dazzling approaching cars, in
the case of braking, acceleration or
load transport.

If bulb replacement is
necessary, contact an
Authorized Maserati Dealer

only: RISK OF ELECTRICAL SHOCK!

In addition, the headlights are
equipped with an ALC system
(Adaptive light control).
This system combines the light beam
with the steering angle and the
vehicle speed to help ensure better
visibility of the road surface when
driving in a curve, steering or in the
event of road deviations.

5

157

Driving conditions

Before a trip

Check the following at regular
intervals and always before long trips:
-  Tire pressure and condition.
-  Levels of fluids and lubricants.
-  Conditions of the windshield wiper

blades.

-  Proper operation of the warning

lights and of the external lights.

WARNING: It is always advisable
to perform these checks at least
every 500 mi (800 km) and to always
follow the maintenance operations
provided for in the “Warranty and
Maintenance Schedule” book.

It is also advisable to:
-  clean the glass on the external light

and all other glass surfaces;

-  properly adjust the mirrors, steering

wheel, seats and seat belts.

Capacities

WARNING: Use unleaded fuel only!
The use of fuel containing lead will
permanently damage the catalytic
converter(s) and oxygen sensor
system.

For fluid and lubricant specifications
and quantities, follow the indications
contained in section 7 “Capacities and
technical specifications”.

Proper driving

Although the vehicle is equipped with
active and passive safety devices, the
driver’s conduct is always a decisive
factor for road safety.
Below are some simple rules to
follow for traveling safely in different
conditions. You will be, no doubt,
familiar with some of them but, in
any case, it would be useful to read
them carefully.

Before you drive

-  Make sure that the lights and

headlights are working properly.

-  Adjust the position of the seat,

steering wheel and rear-view
mirrors so that you have the best
driving position.

-  Check that nothing (e.g., mat

covers, etc.) is blocking the pedals.

-  Carefully arrange any objects in the

luggage compartment, to prevent
sudden braking from jerking them
forward.

-  Avoid heavy meals before a trip.

A light snack helps to keep your
reflexes sharp. In particular, avoid
drinking alcohol.

-  Remember to read, at regular

intervals, the instructions contained
in the paragraph “Before a trip”, in
this chapter.

5

158

In addition to being
prohibited by applicable
legislation, it is extremely

dangerous to travel inside the
luggage compartment or on the
front of the vehicle. In the event of
an accident, persons transported in
this manner are more exposed to
the risk of serious injury. Passengers
must only travel seated in the vehicle
seats, with the seat belts fastened
properly. Always check that you and
your passengers have your seat belts
fastened correctly.

While driving

-  Caution is the first rule for safe

driving. Being careful also means
being able to predict driving
behavior of other drivers that is
wrong or careless.

-  Keep a safe distance from vehicles

in front of you, adjusting this
distance in accordance to the
vehicle speed and traffic conditions.

-  Strictly follow the traffic

regulations and above all, respect
the speed limits.

-  Long trips should be started in

optimal physical condition.

Drunk driving, or driving
under the influence of drugs,
alcohol, or certain medicines

is extremely dangerous for the driver
and for others.

Always fasten your seat
belts, including any child
seats. Traveling without your

seat belt fastened increases the risk
of serious injury and death in the
event of a collision.

-  Make regular stops to loosen up

your limbs and refresh yourself, and
avoid driving for hours on end.

-  Ensure that the air inside the

passenger compartment is changed
constantly.

-  Never coast downhill with the

engine off: the braking action
requires greater effort on the pedal
due to the absence of the engine
brake and of the brake servo.

5

159

Driving at night

The main guidelines to follow when
driving at night are set out below:
-  Drive with caution: at night, driving

conditions are more demanding.

-  Reduce your speed, especially on

roads with no street lights.

-  At the first signs of drowsiness,

stop: to continue driving would
be a risk for you and for others.
Continue only after you have had
proper rest.

-  Keep the vehicle at a greater

distance from vehicles in front of
you than you would during the day:
it is difficult to assess the speed of
other vehicles when you can only
see their lights.

-  Make sure that the headlights are

aimed correctly: if they are too low,
they reduce visibility and strain the
eyes. If they are too high, they may
bother the other drivers.

-  Use the high beams only outside

of urban areas and when you are
sure that they will not disturb other
drivers.

-  When another vehicle is

approaching, switch from the high
beams (if on) to the low beams.

-  Keep the taillights and headlights

clean.

-  Outside of densely-populated areas,

beware of animals crossing the
road.

Driving in the rain

Rain and wet roads can be dangerous.
On a wet road all the maneuvers are
more difficult since wheel grip on
the road is significantly reduced. This
means that the braking distances
increase considerably and road
holding decreases.
Below is some advice for driving in
the rain:
-  Reduce your speed and keep a

greater safety distance from the
vehicles in front of you. High speed
may result in loss of vehicle control
and aquaplaning.

-  Heavy rain also substantially

reduces visibility. In these
circumstances, even during the day,
turn on the low beams, to be more
visible to other drivers.

-  Set the Air Conditioning controls

to demisting, in order to avoid any
visibility problems.

-  Periodically check the conditions of

the windshield wiper blades.

Driving in fog

If the fog is dense, avoid traveling
where possible.
When driving in mist, blanket fog or
when there is the possibility of banks
of fog:
-  Keep a moderate speed.
-  Even during daytime, turn on the

low beams and the rear fog lights.
Do not use the high beams.

-  Remember that fog creates

dampness on the asphalt and thus
any type of maneuver is more
difficult and braking distances are
greater.

-  Keep a safe distance from the

vehicles in front of you.

5

160

-  Avoid sudden changes in speed as

much as possible.

-  Whenever possible, avoid passing

other vehicles.

-  If you are forced to stop the vehicle

(breakdowns, impossibility of
proceeding due to poor visibility,
etc.), first of all, try to stop off of
the travel lane. Then turn on the
hazard lights and, if possible, the
low beams.

Sound the vehicle horn rhythmically
if you hear another vehicle
approaching.
-  If you must get out of the vehicle,

wear a high-visibility vest.

Driving in the mountains

On downhill roads, use the engine
brake, engaging low gears so as not
to overheat the brakes.
-  Never coast downhill with the

engine off or in neutral, and never
with the ignition key removed.

-  Drive at a moderate speed and

avoid “cutting” corners.

-  Remember that overtaking uphill

is slower and requires a longer free
stretch of road. If you are being
overtaken on a hill, slow down and
allow the other vehicle to pass.

Driving on snow or ice

Below is some advice for driving in
these conditions:
-  Keep a very moderate speed.
-  Fit snow chains or specific tires if

the road is covered with snow:
see the paragraphs “Snow chains”
and “Winter tires” in the chapter
“Tires” of this section.

-  Mainly use the engine brake and

avoid sharp braking.

-  We recommend that you activate

“Low grip” mode (see page 141).

-  Avoid sudden acceleration and

sharp changes in direction.

-  During the winter season, even

apparently dry roads can have icy
sections. Be careful when crossing
bridges, viaducts and roads that
have little exposure to the sun and
are bordered by trees and rocks.
They may be icy.

-  Keep a safe distance from the

vehicles in front.

5

161

Emission control devices

Even if the vehicle is equipped
with anti-pollution devices, the
environment deserves the greatest
respect from every one of us.
By following a few simple rules,
the driver can avoid damaging the
environment and can often reduce
fuel consumption as well.
In this regard, some useful
information is listed here below;
please read it carefully.
The correct operation of the anti-
pollution devices not only helps
respect for the environment, but also
has an impact on vehicle efficiency.
Keeping these devices in good
working conditions is the first rule for
driving both ecologically sound and
economically.
The first precaution is to follow the
“Maintenance schedule” carefully.
Always use unleaded fuel.

If starting is difficult, do not make
several attempts.
In particular, avoid push starts,
towing or downhill starts: these are
all maneuvers that can damage the
catalytic converter system.
For any emergency starting, only use
an auxiliary battery.
While driving, if the engine does
not run smoothly, you may continue
driving but reducing engine
performance to a minimum; you
should then contact your Authorized
Maserati Dealer as soon as possible.
Never run the engine, even if only for
testing, with one or more spark plugs
disconnected.

Do not warm up the engine letting it
idle before starting off, except in the
event that the external temperature
is very low and, even then, for no
longer than 30 seconds.

During normal operation
the catalytic converter
produces high temperatures.

Therefore, do not park the vehicle on
flammable materials (e.g., grass, dry
leaves, pine needles, etc.): risk of fire!

Do not install heat guards and do not
remove those already fitted to the
catalytic converter and to the exhaust
manifold.
Do not spray anything on the catalytic
converter, Oxygen sensor and exhaust
manifold.

5

162

In addition to the catalytic converter
system, the vehicles are equipped
with a system for controlling fuel
vapor emissions. This system, called
ORVR, has been designed to help
reduce atmospheric pollution by the
evaporation from the fuel system
during the refueling process. Also,
specific to these vehicles is the fuel
filler neck which comes equipped
with a sealed plug that is grounded
to avoid possible sparking during re-
fueling.


Failure to comply with these
rules can create fire hazards.

Other tips

-  Do not warm up the engine when

the vehicle is stationary: in these
conditions the engine warms up
much more slowly and increases
fuel consumption and emissions.
It is advisable to move off slowly,
avoiding high engine RPM.

-  As soon as traffic conditions and

the route permit it, use a higher
gear.

-  Avoid Depressing the accelerator

repeatedly during stops at traffic
lights or before turning off the
engine.

-  Keep your speed as regular as

possible, avoiding unnecessary
braking and acceleration, which
cause fuel wastage and strongly
increase exhaust emissions.

-  Turn the engine off if the vehicle

remains stationary for a long time.

-  Check the tire pressure regularly:

if the pressure is too low, fuel
consumption increases and the tires
are damaged.

-  Do not transport unnecessary

objects in the luggage
compartment. The weight of the
vehicle affects fuel consumption
considerably.

-  Use the electrical devices

only as long as necessary. The
power required increases fuel
consumption.

California Proposition 65
Warning

THIS MOTOR VEHICLE CONTAINS
CHEMICALS KNOWN TO THE
STATE OF CALIFORNIA TO CAUSE
CANCER, BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM (see page 7)

A

5

163

Parking

Pull the parking brake, straighten the
wheels and turn off the engine.
Never leave the ignition key in
position MAR (ON).
Always remove the key when leaving
the vehicle.


Never leave children
unattended in the vehicle.

Do not park the vehicle on
paper, grass, dry leaves or
other flammable materials.

They could catch fire if they come
into contact with hot parts of the
exhaust system.

Do not leave the engine
running with the vehicle
unattended.

Electric parking brake

The vehicle is equipped with an
electric parking brake (EPB).
It is designed to automatically engage
when the engine is turned off and
to disengage when, with the engine
running, the accelerator pedal is
depressed.

When the electric parking brake is
engaged, with the key turned to
STOP (OFF), the warning light



illuminates on the instrument panel
and the words “EPB ON” appear on
the display.
During engagement and
disengagement, the warning light

 flashes until the maximum

engagement force and full release
have been reached.
In the above conditions, the
automatic activation function can be
deactivated/activated by pressing the
button A on the dashboard.

During engagement or
disengagement of the
electric parking brake,

always hold the brake pedal
depressed.

WARNING: When you need to park
the vehicle on a steep slope, both
with the engine running and off, it
is recommended not only to apply
the electric parking brake but also to
move the gearshift lever to P (PARK)
before leaving the vehicle.

When the EPB button is
activated while driving,
the vehicle slows down

with strong deceleration (Dynamic
Braking). It is therefore advisable to
use this function only in the event
of an emergency. The ESC system,
however is always on, and it will
help to maintain the stability of the
vehicle.

Engagement

The electric parking brake is
automatically applied when the
engine is turned off and the vehicle is
stationary.
It can only be disengaged when the
engine is restarted.
If the key has been removed or is
in position STOP (OFF), it cannot be
disengaged.
The electric parking brake can also be
manually applied when the vehicle
is moving or the key is in MAR (ON)
position by pulling up the lever B.

B

A

5

164

If the engine was turned off with
the automatic engagement device
deactivated, you can reactivated it
simply by pulling lever B upward.
The words “EPB ON” appear on the
display.

Always check that the
vehicle is properly locked
before leaving it.

Disengagement

The parking brake is automatically
disengaged when depressing the
brake pedal and moving the gearshift
lever from position P (a pressure
of at least 72.5 psi (5 bar) must be
generated in the braking system), or
with a gear engaged and pushing the
accelerator pedal.
The parking brake can also be
manually disengaged when the
vehicle is moving or the key is in
position MAR (ON) by manually
pulling up lever B and simultaneously
depressing the service brake pedal.

WARNING: If you attempt to
disengage the parking brake without
having depressed the service brake
pedal, a message will be displayed to
warn you to do so.

WARNING: In certain conditions, it is
however advisable to disengage the
parking brake manually and slightly
apply the service brake for starting
off. This is advisable when there are
obstacles very close to the vehicle in
the direction in which you intend to
move.

Deactivating PARK OFF automatic
operation

To deactivate manual operation of the
parking brake, with the engine on,
press the button A on the dashboard.
The words “PARK OFF” appear on the
display for 5 seconds, after which they
remain displayed but in smaller size.
To reactivate automatic operation,
press the button A once again, the
words “PARK ON” appear on the
display for 5 seconds.

WARNING: In certain conditions
when the battery voltage is low, the
electric parking brake system may
temporarily be deactivated for safety
reasons. Therefore, typically upon
starting the engine, when the battery
voltage drops, the message “PARK
OFF” may temporarily be displayed,
indicating that automatic operation is
temporarily disabled.

5

165

WARNING: In the case of performance
starting, check that the electric
parking brake is disengaged.

Malfunction indication

In the event of electric parking brake
system failures, the warning light



will illuminate.

Depending on the message displayed,
it signals the following failures of the
EPB system:
-  Parking brake fault: go to dealer.
  If the message warning you to go

to the nearest Authorized Maserati
Dealer is displayed, drive slowly and
remember that the electric parking
brake device is not functioning.

-  EPB is overheated.
  If the vehicle has been stationary

(key to STOP (OFF)) for about 15
minutes without using the parking
brake, and the warning light

illuminates again after restarting
the engine, slowly drive to the
nearest Authorized Maserati
Dealer.

-  EPB fault, only manual EPB release

possible: see handbook.

  Follow the manual emergency

deactivation procedure in order to
release the parking brake.

-  Parking brake system revision: go to

dealer.

  The EPB system requires

maintenance, therefore contact
your Authorized Maserati Dealer to
have the system corrected.

In the event of an EPB
failure, take your vehicle
to the nearest Authorized

Maserati Dealer as soon as possible.

Emergency disengagement

In the event that the electric parking
brake locks with a total system failure,
you need to manually release the
parking brake using the special tool
provided in the toolkit.
Proceed as follows:
-  remove the toolkit and covering

panel from the luggage
compartment;

-  remove the covering panel

containing the toolkit and the tire

repair kit;

-  remove the cap on the right-hand

side of the EPB ECU;

-  insert the special tool into place;
-  turn the handle clockwise until it is

released;

-  remove the tool from its seat and

close it with the cap.

After each manual
emergency release
procedure, the electric

parking brake system remains non-
functioning until the situation is
corrected by an Authorized Maserati
Dealer.

5

166

Tires

The Maserati GranTurismo is
a performance automobile,
tire wear must be checked

regularly and worn tires must be
replaced. Tire wear will vary and
depends on driving habits and
conditions.

Glossary of tire terminology

“Tire Information Placard (label)”
is a placard/label, showing the OE
(original equipment) tire sizes,
recommended inflation pressure, and
the maximum weight the vehicle can
carry.

“Tire Identification Number (TIN)”: A
number on the side wall of each tire
providing information about the tire
brand and manufacturing plant, tire
size and date of manufacture.

“Inflation pressure”: A measure of the
amount of air in a tire.

“Standard load”: A class of P-metric
or Metric tires designed to carry a
maximum load at a specified psi
rating.

“Extra load”: A class of P-metric
or metric tires designed to carry a
heavier maximum load at a specified

psi rating.

“kPa”: Kilopascal, a metric unit of air
pressure.

“PSI”: Pounds per square inch, a
standard unit of air pressure.

“B-pillar”: The structural member at
the side of the vehicle behind the
front door.

“Bead area of the tire”: Area of the
tire next to the rim.

“Side wall of the tire”: Area between
the bead area and the tread.

“Tread Area of the tire”: Area of the
perimeter of the tire that contacts the
road when mounted on the vehicle.

“Rim”: The metal support (wheel)
for a tire or a tire and tube assembly
upon which the tire beads are seated.

“Cold tire pressure”: The tires are
considered to be cold when they
have the same temperature as the
surrounding (ambient air) meaning
that the car has been stationary
for a minimum of 3 hours, or has
been driven less than 1 mile. Adjust
pressures only in ambient conditions.

“Maximum inflation pressure”: Is
the greatest amount of air pressure
that should ever be put in the
tire. This rating is established by
th tire manufacturer. Use only the

recommended inflation pressure.

“Recommended inflation pressure”:
Inflation pressure, established by
Maserati which is based on the
type of tires that are mounted on a
vehicle at the factory. This inflation
pressure is affected by the number of
occupants in the vehicle, the amount
of cargo and the speed at which the
vehicle will be driven for a prolonged
period. This information can be found
on the tire inflation placard (label)
located on the driver’s side B-pillar
and in the tire inflation table in this
owner’s manual.

5

167

Tire identification number:

On the left-hand sidewall, as fitted
to the car. Commences with DOT
(Department of Transportation)
followed by a two- digit
manufacturing plant code, a two-
digit tire size code, a three-digit tire
construction code, and a four-digit
date code for the week and year of
production.

Tread wear

The tread wear grade is a comparative
rating based on the wear rate
of the tire when tested under
controlled conditions on a prescribed
government test course.
For example, a tire graded 150 would
wear one and one-half (1-1/2) times
as well on the government course as a
tire graded 100.
The relative performance of tires
depends upon the actual conditions of
their use and may depart significantly
from the norm due to variations in
driving habits, service practices and
differences in road characteristics and
climate.

DOT quality grades

Tires

Tread wear

Traction

Temperature

Michelin Pilot Sport (*)

220.

AA.

A

(*) Example only

Traction

The traction grades, from highest
to lowest, are “AA”, “A”, “B”, and
“C”. Those grades represent the tire
ability to stop on wet pavement as
measured under controlled conditions
on specified government test surfaces
of asphalt and concrete.

The traction grade assigned
to this tire is based on
straight-ahead braking

traction tests, and does not include
acceleration, cornering, hydroplaning,
or peak traction characteristics.
