(OFF) to have a further 30 seconds
within which to remove the key.

WARNING: In the event that the key
unlocking system fails or if it is not
possible to shift the gearshift lever
to P, to remove the key you must
turn it to STOP (OFF), then remove
the cap G using a pen or sufficiently
pointed tool, then press the button
just uncovered and at the same time
extract the key. When the operation
has been completed, refit the cap G.

If you turn off the engine with
the gearshift lever A in a position
different from P, an acoustic signal
will sound for a few seconds and a
message will be displayed indicating
to shift the lever to P.

When the driver’s door is opened with
the gearshift lever A in a position
different from P, an acoustic signal
will sound for a few seconds and
a message warning the driver that
the gearshift lever is not in P will be
displayed.

For your safety never shift/
change gears with the doors,
trunk lid or the engine

compartment lid open.

Selecting automatic or sequential
manual operating mode

The gearbox can be used both in fully
automatic mode (position D) and in
sequential manual mode (positions
+ o -).
To select the mode, shift the gearshift
lever A to:
D – automatic gearshifting (AUTO);
MANUAL (+ / -) – sequential manual
gearshifting
The lever can always be shifted from
one position to the other, even when
the vehicle is moving.
The lever can continuously be shifted
from D to MANUAL.
If automatic gearshifting has been
set, the word “AUTO” and the letter
D will be shown on the instrument
panel display, while if sequential
manual mode has been set, the word
“MANUAL” and the gear engaged
will be shown on the same display.

5

137

Automatic operation (AUTO)

For automatic operation, move
the gearshift lever A to one of the
following positions:
P –

 Park

R –  Reverse
N –  Neutral
D  –  Drive, automatic forward gear

 (6 forward gears)

The position of the gearshift lever is
shown on the gear display E by the
illumination of the corresponding
letter. This letter is also displayed on
the instrument panel.

The gearshift lever A can be moved
from D to N, as desired. To engage
or disengage R, you must also press
button B.

Position P is engaged by pressing
the button B and then moving the
gearshift lever; it is disengaged
by pressing the button and the
brake pedal at the same time. It is
advisable to also hold the brake pedal
depressed when moving the gearshift
lever to the other positions.

P – Park

When parking the vehicle, shift the
lever to P. A gearbox device will lock
the driving wheels.

WARNING: Shift the lever to position
P only when the vehicle is stationary.
Therefore, it is advisable to perform
this maneuver with the brake pedal
depressed.

WARNING: To prevent accidental
engagement, the gearshift lever can
only be moved from P to any other
position when the button B and the
brake pedal are depressed.

WARNING: Before getting out of the
vehicle, check that the automatic
parking brake is engaged. Move the
gearshift lever to P even when you
need to get out of the vehicle only for
a few seconds.

If you turn off the engine with
the gearshift lever A in a position
different from P, an acoustic signal
will sound for a few seconds and a
message will be displayed indicating
to shift the lever to P.

When the driver’s door is opened with
the gearshift lever A in a position
different from P, an acoustic signal
will sound for a few seconds and
a message warning the driver that
the gearshift lever is not in P will be
displayed.

WARNING: In the event of a battery
failure, manually release the driving
wheel locking device before you drive
following the procedure on the next
page.

H

5

138

In the event of a battery failure, move
the gearshift lever from P to another
position before moving the vehicle.
To do this, follow the emergency
procedure described below:
-  remove the covering plate H in

front of the gearshift lever;

-  using a small tool, push on the

gearshift lever locking mechanism
through the hole;

-  at the same time slightly move

the gearshift lever towards the N
position, in order to free the lever
locking mechanism;

-  remove the small tool from the

hole, being careful not to move the
gearshift lever;

-  shift the lever fully into N;
-  close the hole using the covering

plate H to prevent foreign bodies
from falling into the gearbox and
damaging it.

The gearshift lever is now released.

While moving the gearshift lever,
remember to press the button B on
the lever.

WARNING: Work extremely carefully
so as not to damage the trim panels.

If the automatic parking brake
engagement system is active, the EPB
will be automatically applied when
the vehicle is stopped, see page 163.

WARNING: In the event of a battery
failure, manually disengage the
parking brake (EPB) before you drive,
see page 165.

5

139

R - Reverse gear

With the vehicle stationary, the
engine idling and the button B
pressed, move the gearshift lever A
to position R. It is advisable to also
depress the brake pedal when shifting
to this position. When the lever is
in position R, the system emits an
acoustic signal for a few seconds.
You can also move the gearshift
lever to R when the vehicle is not
completely stationary, however, this
does not mean that reverse gear is
actually engaged, since there is a
limit speed above which the gear may
not be engaged. When the speed
goes below this limit, reverse gear is
engaged.

WARNING: To avoid engaging any
gears accidentally, moving the lever
from position R to any other position
is only possible when button B is
pressed. It is advisable to depress the
brake pedal also when shifting to
another position.

N – Neutral

With the vehicle stationary and the
brake pedal depressed, move the
gearshift lever A to N.
This function should be used when
you need to tow or push the vehicle.

D – Automatic forward gear

Select this position when you wish
to use all the automatic gearshift
functions.
With the vehicle stationary and the
brake pedal depressed, shift the
gearshift lever A to D; if the lever is
positioned on P also press the button
B.
When the function is set, the letter D
illuminates on the gear display and on
the instrument panel.
When this function is active, the
ECU controls automatic engagement
of the six gears. The gears will be
engaged in relation to the traveling
speed, engine RPM, accelerator
position, speed with which the pedal
is depressed as well as the traveling
conditions (e.g., uphill, downhill,
curves).
The system has been programmed
to classify different driving styles,
in relation to the above mentioned
parameters, and to associate them
with the various vehicle settings,
which go from extremely comfortable
and economic driving to racing-
style driving. The setting is selected
automatically.

+ / - – Sequential manual operation
(MANUAL)

This allows you to manually engage
gears while driving.
With automatic gearshifting selected
(position D), move the gearshift lever
A to position + or -.
When this mode is selected, the
symbol + or - illuminates on the gear
display E, based on the position of
the gearshift lever, the gear engaged
is shown on the instrument panel
display.

When sequential manual
operation is selected,
upshifting or downshifting

must be performed manually.

To engage the gears, shift the
gearshift lever A to one of the
following two positions:
+  UP to engage a higher gear
-   DOWN to engage a lower gear.

5

140

WARNING: Some conditions will
always remain automatically
controlled, for example, when the
engine is overrevving or underrevving,
the system automatically engages a
higher or lower gear.

WARNING: If you request a gearshift
in conditions where the engine is
overrevving or underrevving, the
system will not accept the command.

WARNING: The ECU is programmed
to control one gearshift at a time,
therefore, fast and repeated actions
will not necessarily result in a
gearshift. A higher or lower gear
is engaged only if the previous
procedure requested has been
completed.

When the system refuses to engage a
gear, an acoustic signal will sound for
a few seconds.

Sequential manual operation can
only be selected from the D position,
whatever the function (SPORT,
NORMAL) active at the time of the
request.

The gear selected by the automatic
gearbox will remain engaged when
the lever A is moved.
Moving the lever back to D, automatic
operation will instantly be resumed,
and a gear will be engaged based on
the driving style and mode selected.

In the event of a failure of the
sequential manual gearshift system,
the gearbox ECU will select automatic
operation.

Other system functions

The settings automatically selected by
the system operate in three modes:
-  NORMAL
-  SPORT
-  ICE (Low Grip).
Activate the desired mode by pressing
the relative button.
The active mode is shown on the
instrument panel display.

For each mode there are various
vehicle settings, that are automatically
set by the system in relation to
the traveling speed, engine RPM,
accelerator position, speed with which
the pedal is depressed as well as the
traveling conditions (e.g., uphill,
downhill, curves).

NORMAL

This mode is intended specifically
for comfortable and fuel-economy
driving (low longitudinal and lateral
acceleration); the gears are shifted
with minimum vibration in lowest
noise (gears are shifted at low engine
speeds).

C

D

5

141

SPORT

It is activated by pressing the button
C; on the instrument panel and the
word “SPORT” illuminates on the
display.
To return to NORMAL mode from
SPORT mode, press the button again.
As SPORT mode has a lower priority
than “low-grip” mode, if this is
already active when activating SPORT
mode, the system will ignore the
command.

In addition to providing
faster gearshifts than in
NORMAL mode and to

keeping engine power reduction
by the ASR system to a minimum,
SPORT mode also acts on the exhaust
opening.

Fast gearshifting however, always
depends on the accelerator pedal
travel and on the engine RPM, as in
NORMAL mode.
In MANUAL mode, DOWN-shifts with
the accelerator pedal released, will
have a braking effect approaching the
skidding limit of the driving wheels
on dry asphalt.
Under sports-style driving conditions
with gearshifts at high engine RPM,
double-clutching when up-shifting is
performed automatically.

WARNING: In addition to enhancing
performance, opening of the exhaust
also increases noise levels of the
vehicle.

It is advisable not to use
SPORT mode on roads
with low or medium grip

conditions (e.g. ice, snow, or wet
roads) as the driving wheels could
skid during gearshifts.

If you use MANUAL and SPORT
mode in combination for sports-style
driving, when starting-off or shifting
gears, you may perceive an initial
slipping of the driving wheels even on
dry roads.

“ICE” Low Grip

This mode can be used on particularly
slippery road surfaces (e.g., rain,
snow, ice). To activate/deactivate this
mode, press button D. The word “ICE”
will illuminate on the instrument
panel display.
In “low-grip” mode, the system uses
2

nd

 instead of 1

st

 gear; this means

that 2

nd

 gear will automatically be

engaged (gearshift lever in D) in the
event of standing starts in automatic
mode; on the other hand, when in
sequential manual mode (gearshift
lever in MANUAL), moving the
gearshift lever A from neutral or
reverse or when the vehicle stops, 2

nd



gear will automatically be engaged.
When sequential manual mode is
selected with 2

nd

 gear engaged, a

downshift request will be ignored.

5

142

While driving, the system
automatically switches to the upper
gear if the engine reaches the pre-
established speed (3000 RPM). “Low-
grip” mode has priority over SPORT
mode and assists the ESC system.

A downshift request from
6

th

 to 5

th

 gear will only

be accepted if the engine

speed rate in 5

th

 gear is lower than

3000 RPM. As “low-grip” mode can
be activated at any time and the
system limits the engine speed to
3000 RPM in all gears except for the
6

th

, unrequested gearshifts could take

place.

In any case, it is advisable to
deactivate SPORT mode before
selecting “low-grip” mode.

When sequential manual gearshifting
is active, regardless of the mode
set (NORMAL / SPORT / ICE), the
gearbox will automatically upshift
or downshift when reaching the
minimum and maximum RPM.
This is to prevent engine overrevving
or underrevving.

Strategies for downhill driving

When the accelerator pedal is
released, the gearbox system detects
that the vehicle is moving downhill
and deactivates upshifting. When
the accelerator pedal is depressed,
upshifting is reactivated but will be
delayed.
When the brake pedal is depressed,
the gearbox system downshifts to
provide enhanced engine braking
power.
For instance, when driving downhill,
the gearbox system operates so as
to avoid upshifting and shifting
gears when the accelerator pedal
is released, and delays gear
engagement by a few seconds when
the accelerator pedal is depressed.
In addition, when the brakes are
applied, it engages the lowest gear
in order to provide enhanced engine
braking power.
This strategy is designed to improve
downhill driving safety.

Strategies in curves

The system detects when the vehicle
goes into a curve through the lateral
acceleration and the steering angle.
Detecting this condition, it controls
gearshifting using a specific mode.
This mode is exited when the vehicle
comes out of the curve, at a distance

that varies depending on the vehicle
speed.

Fast-off strategy

When the accelerator pedal is fully
released, the system deactivates
upshifting.
The next time the pedal is depressed,
upshifting will be reactivated only
after a few seconds.
Upshifting is also deactivated when
the accelerator pedal is partially
released; the system waits the time
necessary to evaluate if the release
action is completed.

Hot-mode strategy

In the event that the engine oil or
coolant temperature is too high or
both, the gearbox system reduces the
maximum engine speed to 4000 RPM.
Therefore, upshifting will occur at this
limit.
This strategy does not apply to
downhill driving, so as to always
have the efficiency of engine braking
together with the standard braking
system.

ESC system operations

In order to help prevent unstable
driving conditions, the ESC system
may request the gearbox system to
deactivate gearshifting. The system

5

143

handles this request depending on
the gear engaged and on the RPM,
and decides whether to accept it or
not.

Cruise Control

With the Cruise Control function, the
gearbox system selects shift points
as to provide enhanced comfort and
fuel-economy.

MC Start Strategy (optional
equipment)

With the aim of optimizing standing
starts for performance driving (only
recommended for use in areas closed
to traffic and in accordance with
traffic laws), the automatic gearbox
system is equipped with quick start
strategy.
This strategy is activated when
the following conditions occur
simultaneously:
-  AUTO and SPORT modes active;

-  ESC mode OFF;

-  brake pedal depressed.

In these conditions, the driver has the
possibility to accelerate and, keeping
the brake pedal depressed, keep
the vehicle standing until reaching
an engine speed between 2300 an
2500 RPM and then, upon releasing

the brake pedal, have the optimal
standing start performance.

This strategy must only
be used on vehicles in
areas closed to traffic, in

accordance with traffic laws and only
by skilled drivers.

Malfunction indication

The malfunctions indicated are
attributable to two causes:
- Gearbox

failure

-  Gearbox oil temperature too high
In both cases, the warning light

 comes on. In the first case, it

is accompanied by the following
message on the display: “Check
transmission go to dealer” in the
second case: “High gearbox oil
temperature”.

Gearbox failure

This message indicates a gearbox
system malfunction, therefore, if you
are driving, the ECU that controls the
device sets an emergency program.

WARNING: In these conditions, we
recommended that you stop the
vehicle and turn off the engine for
at least one minute. When restarting
the engine, the autodiagnostic system

may erase the malfunction, which will
in any case be recorded by the ECU.

In failure conditions, the gearshift
lever A can always be moved to R, N
and D.
When shifting to D, only a few gears
will be available, depending on the
malfunction found.

WARNING: If a gearbox failure is
signaled, take your vehicle to the
nearest Authorized Maserati Dealer
as soon as possible to have the
malfunction corrected.

If the failure is signaled when the
engine is started, it means that the
gearbox ECU detected a fault when
the vehicle was last used. Also in this
case, take your vehicle to the nearest
Authorized Maserati Dealer to have
the gearbox checked.

When the gearbox is
malfunctioning, drive very
carefully considering that

vehicle performance is reduced. In
addition, the reverse gear safety lock
may not be active: absolutely do not
shift the lever to R when the vehicle
is moving.

15°

15°

15°

15°

5

144

Gearbox oil temperature too high

This message is displayed when the
gearbox oil has reached the maximum
temperature. In this case, the gearbox
ECU sets an emergency program.

WARNING: It is advisable to stop the
vehicle, shift the lever to P or N and
keep the engine running idle until
the warning light

 goes off and

the message disappears. Resume
driving without demanding high
engine performance. If the warning
light comes on again and the message
reappears, stop once again letting
the engine idle until the light goes
off and the message disappears.
If the interval between the two
indications is less than 15 minutes, it is
advisable to stop the vehicle, turn off
the engine and wait for the engine/
gearbox assembly to fully cool down.

Push start

The engine cannot be push-started. If
the battery is dead, start the engine
using an appropriate emergency
battery following the instructions
given in Section 6 “In an emergency”.

Towing the vehicle

If you need to tow the
vehicle, observe the following
recommendations:
-  if possible, have the vehicle

transported on a vehicle equipped
with loading platform and specific
for roadside assistance and
recovery.

If this is not possible:
-  tow the vehicle for a distance of

less than 62 mi (100 km) at a speed
below 37 mph (60 km/h).

Tow the vehicle using the towing
hook found in the toolkit. Screw the
towing hook down tightly in its seat,
on the lower, right-hand side of the
front bumper.
In order to tow the vehicle, turn the
key to MAR (ON) and engage Neutral
by shifting the gearshift lever A to N.
Should the EPB be applied, you must
disengage it (see page 163).
The maximum angle of the towing
cable, both horizontal and vertical
shall be ±15°.

Do not extract the key, as
the steering wheel will lock
automatically and you will

be unable to steer the wheels.

When towing the vehicle,
make sure that you observe
the road traffic regulations

concerning both the towing device
and driving conduct.

When towing the vehicle
with the engine off,
remember that, without

the assistance of the brake servo,
a stronger effort is required on the
brake pedal for braking and on the
steering wheel for steering.

L

M

5

145

Gearshift paddles on the
steering wheel

In sequential manual operating mode,
upshifting and downshifting can be
controlled not only with the gearshift
lever A but also with the two paddles
positioned behind the steering wheel.
L  - Lower gearshift paddle DOWN
M - Upper gearshift paddle UP
Also in automatic gearbox mode,
when the gearshift lever A is in
position D (DRIVE), you can shift to a
different gear by moving one of the
paddles. This action will temporarily
switch the system to sequential
manual operation.

If you then keep to a constant
driving style (low longitudinal and
lateral acceleration), the gearbox
automatically switches back to
automatic operation.

Screw the towing hook into
its seat (approx. 11 turns).
Clean the threaded seat

completely before tightening the
hook.

WARNING: The maximum angle of
the towing cable, both horizontal and
vertical shall be ±15°.

5

146

Fuel economy

In order to improve fuel economy, we
recommend that you shift gears when
the system prompts you to do so.

This will help you to reduce fuel
consumption without strongly
affecting vehicle performance.

The system will indicate when you
should shift gears by displaying
a small arrow next to the gear
displayed.

This arrow illuminates just before
reaching the speed required for
gearshifting.

When the recommended gear has
been selected, the indicator goes
off. If the recommended gearshift
is delayed or not performed, the
indicator will remain illuminated for
a few seconds and will then go off.
As soon as the conditions requiring
gearshifting are met, the indicator
illuminates again, as described above.

The recommended gearshift indicator
will only work when the gearbox is
set to manual sequential operation.

5

147

Using the brakes

To obtain a good running in of brake
pads and discs, avoid sudden braking
during the first approximately 200 mi
(300 km).

ABS is a component of the braking
system that offers two basic
advantages:
-  It helps avoid locking of the

wheels and thus skidding during
emergency braking, especially
under low grip conditions.

-  It makes it possible to brake and

steer at the same time in order to
avoid unexpected obstacles or to
direct the vehicle where desired
when braking: this is in keeping
with the physical limits of the tire
side grip.

In order to fully exploit the ABS
system features:
-  You will note a light vibration of

the brake pedal during emergency
braking or braking under low grip
conditions: this is a sign that the
ABS is working. Do not release
the pedal but continue to press it
to give continuity to the braking
action.

-  The ABS helps prevent the wheels

from locking, but it does not
increase the physical grip limits
between the tires and the road.
Therefore, even if your vehicle is
equipped with ABS, always keep
a safe distance from the vehicle
in front of yours and reduce your
speed when entering a curve.

The wear limit of the brake pads is
indicated by the warning light



and the message “Check Brake Pads”
that will be displayed for 10 second.
The warning light

 will illuminate

on the instrument cluster and stay on
until the problem has been solved.
Please contact an Authorized
Maserati Dealer.

5

148

Using the engine

Running-in

Today’s most modern methods of
production afford high precision in
the construction and assembly of
components. However, the moving
parts do undergo a settling process,
during the first hours of vehicle
operation.

Engine and transmission

Avoid exceeding 5000 RPM for the
first 620 mi (1000 km).
After starting, do not exceed 4000
RPM until the engine has warmed up
sufficiently (water temperature: 149-
158 °F/65-70 °C).
Do not let the engine run at a
constantly high speed for a prolonged
time.

While driving

Never travel with the tachometer
approaching the peak RPM - not even
downhill.
When the tachometer is approaching
the peak RPM (red sector), take
precautions to avoid exceeding that
limit.

WARNING: Under normal conditions,
all the red light warning lights on
the instrument panel should be off.
When they illuminate, they indicate
a malfunction in the relative system.
The only exception is the engine oil
level warning light, see page 214.

Ensure proper operation of the
various devices by checking the
relevant control gauges.

WARNING: Continuing to drive when
a red warning light is on could cause
serious damage to the vehicle and
affect performance.

Never turn the engine off
while driving downhill as the
vacuum decrease prevents

the brake booster from functioning
correctly. After a few attempts at
braking the system will become
almost completely inefficient. The
power steering will also lose its
efficiency in these condition.

A

5

149

Engine control system (OBDII)

This system is designed to
continuously monitor the vehicle
components associated with
emissions; it also indicates, when
the warning light

 illuminates

on the instrument panel, that the
components in question need to be
checked and if necessary serviced.
The purpose is to:
-  keep the system operating

efficiently

-  indicate when a problem causes

an increase in emissions exceeding
the threshold established by
regulations in force

-  indicate the need for replacement

of deteriorated components.

In addition, the system includes a
diagnostics connector that can be
interfaced with special instruments.
This makes it possible to read the
error codes stored in the control
unit, together with a set of specific
parameters for the engine operation
diagnostics cycle, on compliance with
CARB, EPA OBDII rules.

WARNING: Once the engine is started,
the warning light

 will remain on

for approximately 18 seconds before
turning off. This is a normal condition
and part of the operating strategy.

WARNING: When the ignition key
is turned to position MAR (ON) if
the warning light

 does not

illuminate or if it illuminates while
driving, contact your local Authorized
Maserati Dealer as soon as possible.

WARNING: After the problem has
been corrected, your local Authorized
Maserati Dealer staff are required
to perform tests of the system and if
necessary, also road tests which may
even involve long distances.

Position of the diagnostic
connectors

The diagnostic connector A, positioned
underneath the dashboard, next to
the engine lid opening lever, can be
accessed without removing any cover.

California Proposition 65
Warning

THIS MOTOR VEHICLE CONTAINS
CHEMICALS KNOWN TO THE
STATE OF CALIFORNIA TO CAUSE
CANCER, BIRTH DEFECTS OR OTHER
REPRODUCTIVE HARM (see page 7)

A

B

C

5

150

Cruise Control

General

The Cruise Control function allows the
driver to maintain the desired vehicle
speed constant without pressing
the accelerator pedal. This helps
reduce driving fatigue on highways,
especially long trips, as the set speed
is automatically maintained.

WARNING: The device can only
be activated at speeds exceeding
19 mph (30 km/h) and it turns off
automatically when the brake pedal
is depressed or when a speed of 125
mph (200 km/h) is exceeded.

Cruise Control must only be
activated when traffic and
the route permit a constant

speed to be maintained safely for a
sufficiently long distance.

Controls

Cruise Control is controlled by switch
A, by the rotating section B and by
button C (RCL).
Switch A has two positions:
-  OFF the device is deactivated;
-  ON the device is active. When

the device is activated, the green
warning light

 on the display

illuminates together with the
message “Cruise Control on”.

The rotating section B is used to
store the vehicle speed and to keep
it constant, or to increase or decrease
the speed stored.

Turn the rotating section B to position
(+) to save the speed reached or to
increase the speed stored.
Turn the rotating section B to position
(–) to decrease the speed stored.
Every time the rotating section B
is reset, the speed is increased or
decrease by approx. 0.6 mph (1 km/h).
Keep the rotating section turned
to vary the speed continuously.
When a new speed is reached, it will
automatically remain constant.
Button C (RCL) is used to resume the
speed stored.

WARNING: When the ignition key is
turned to STOP (OFF) or switch A is in
the OFF position, the speed stored is
erased and the system deactivated.

5

151

Storing a speed

Turn switch A to ON reach the desired
speed driving normally. Turn the
rotating section B to (+) for at least
three seconds and then release it.
The vehicle speed is stored and the
accelerator pedal can be released.
The vehicle will proceed at the
constant speed stored until the brake
pedal is pressed.
If necessary, (for example, to pass
another vehicle), you can accelerate
by simply pressing the accelerator
pedal. Afterwards, when you release
the accelerator pedal, the vehicle will
return to the speed previously stored.

Resuming the speed stored

If the device has been deactivated
after braking, the speed previously
stored can be resumed as follows:
-  gradually accelerate until you reach

a speed close to that stored;

-  engage the gear selected when

the speed was stored (4

th

, 5

th

 or 6

th



gear);

- press

button

C (RCL).

Increasing the speed stored

The speed stored can be increased in
two ways:
-  by pressing the accelerator and

then storing the new speed reached
(turn the rotating section B for
more than three seconds)

or
-  by turning the rotating section B to

position (+): each pulse transmitted
by the rotating section will cause a
slight increase in speed (about 0.6
mph / 1 km/h), whereas a constant
pressure on the same rotating
section will cause a continuous
increase in speed. When the
rotating section B is released, the
new speed will be automatically
stored in the memory.
