Model MA TOW Tractor. Manual - part 81
Chapter 4: Illustrated Parts List
Jan. 1997
Section 4-2
p. 209
60-3
—— ----------------
T6-4014-119
spring
1
Notes 1,2,4,5
—— ----------------
T6-4014-119
spring
2
Note 6
—— ----------------
T6-4044-123
spring
1
Note 3
60-4
—— ----------------
1"
flat washer
1
Notes 1,2
—— ----------------
T6-4044-119
stop ring
1
Note 3
—— ----------------
T6-4014-151-6
lock spacer
1
Note 4
—— ----------------
1-1/16"
flat washer
1
Note 5
—— ----------------
1-1/16"
flat washer
2
Note 6
60-5
—— ----------------
3/8X1-3/4"
roll pin
1
Notes 1,2
—— ----------------
1/4X1-3/4"
roll pin
1
Notes 3,5,6
—— ----------------
1/4X2"
roll pin
1
Note 4
60-
—— ----------------
T6-4014-127
hitch lift cable assembly, e-hitch
1
As Req’d
60-
105 CP-400-CA
T6-4025-103
Hitch, Holland 400
1
“
60-
105 PHT60A0L8
T6-4024-105
hitch, pintle
1
“
60-
105 XA-T-150-AF
MD-Y01-103
hitch, jakes/universal
1
“
60-
105 CP-T-190C
T6-9011-107
hitch, jakes, with lift handle
1
“
60-
174 ZB-98AM
MD-F13-103
hitch, rose
1
“
60-
174 2638
MG-ND-717
mounting bracket, slip-on rose hitch
1
“
60-
174 2639
MG-ND-718
plunger handle, slip-on rose hitch
1
“
60-
174 2640
MG-ND-719
plunger spring, slip-on rose hitch
1
“
60-
174 2641
MG-ND-720
plunger, slip-on rose hitch
1
“
60-
174 367
MG-ND-721
draw bar, slip-on rose hitch
1
“
60-
----- ----------------
T6-4026-101
Martin Marietta Hitch
1
“
60-
----- ----------------
T6-4026-101-4
Martin Marietta Hitch pin
1
“
Fig &
Co Vendor Part
Tug Part Number
Description
Qty
Effective
Ind#
de Number
Quantities given are for one hitch assembly.
1. Used with standard Tug E-hitch T6-4014-103.
2. Used with Federal Express type E-hitch T6-4014-103FE.
3. Used with Eastern Air Lines type E-hitch T6-4044-103.
4. Used with TWA type E-hitch T6-4044-151.
5. Used with UPS domestic type E-hitch T6-4044-200.
6. Used with UPS Germany type E-hitch T6-4044-201.
