Operation
145
5
OPERATION 2
Raise the hitch to maximum height.
IMPORTANT: Electronic power lift - Make sure LOAD
CONTROL is in the (0) off position, this will prevent
unwanted hitch movement when the tractor is moving
at more than 0.8 km/h (0.5 mph).
OPERATION 3
Make sure the auto hitch is raised to maximum height.
Unlock the locking latches.
To unlock, pull the lever (1).
OPERATION 5
Lower the pick-up hitch using the power lift controls.
OPERATION 6
- Mechanical hitch - Reverse the tractor until the hook is
aligned under the implement towing eye.
- Hydraulic hitch.
Extend the hook rearwards, by moving the corresponding
hydraulic remote control until the hook is aligned under
the implement towing eye.
OPERATION 7
Raise the auto hitch until the hook is engaged in the
implement towing eye.
OPERATION 8
Fully retract the hook by moving the correct remote lever
rearwards.
IMPORTANT: Always make sure the hook is fully
retracted before raising the hitch.
OPERATION 9
Raise the pick-up hitch to max. height until the hitch stops
upward movement and the locking latches are latched.
Release the lift controls.
