OPERATION

Safe Operating Precautions

Fuel Recommendations

The generator engine is certified to operate on regular
unleaded gasoline with a pump octane rating of 87 or
higher.

Never use stale or contaminated gasoline or an oil /
gasoline mixture. Avoid getting dirt or water in the fuel
tank.

The use of regular unleaded gasoline containing no more
than 10% ethanol (E10) by volume is permitted. Do not
use  gasoline  containing  methanol.  If  the  content  of
ethanol or methanol exceeds the specified limits, it may
cause  starting  or  performance  problems.  It  may  also
damage  metal,  rubber,  and  plastic  parts  of  the  fuel
system.  Damage  due  to  ethanol  or  methanol  is  not
covered under warranty.

Refueling

IMPORTANT: Thoroughly read the “Safety” chapter

and all warnings and cautions when handling fuel.

Gasoline is highly flammable and explosive and can
cause serious injury. Stop the engine and keep heat,
sparks, and flame away. Handle fuel only outdoors.
Wipe up spills immediately.

Do not spill fuel when filling the fuel tank. Damage
caused by spilled fuel is not covered under warranty.
Spilled fuel is a fire hazard, caused environmental
damage, and can damage paint and plastic. Wipe up
spills immediately. Don fill above bottom of strainer.

Refuel in a well ventilated area before starting the en-
gine. If the engine has been running, allow it to cool.

Never refuel the engine inside a building where
vapors may reach flames or sparks. Keep fuel vapors
away from electrical appliances.

Remove the fuel tank cap (A).

Fill carefully to avoid spilling fuel or exceeding the
bottom of the fuel tank strainer (B).

Securely tighten the fuel tank cap (A) until it clicks.

Position the fuel tank vent lever OFF for storage or
transport, or ON to operate the generator, if equipped.

Move generator at least 10 feet (3 meters) away from
the fueling source and site before starting the engine.

Loosen

Tighten

OFF

OPERATION

Before Starting the Engine

Read, understand, and follow the Safety Section of this
manual.

Ensure the generator is away from the fueling source.

The generator will vibrate during operation. Place the
generator in a dry location and on a flat, level surface.

Unplug all power cords and extension cords from the
generator.

Starting the Engine

Position the fuel tank cap vent lever to ON, if
equipped.

Position the SMART throttle switch to OFF.

For a cold engine start, position the choke lever to
START. To restart a warm engine, leave the choke
lever in the RUN position.

Position the engine switch to ON.

Lightly pull the starter recoil grip until resistance is felt.
Then, firmly pull straight out.

Do not allow starter grip to snap back against the
generator. Return it gently to prevent damage to the
starter.

If the choke lever was positioned to START to start the
engine, gradually move it to RUN as the engine warms
up.

After a 2 to 3-minute warm up, select ON or OFF on
the SMART throttle switch as desired.

If connecting loads to generator, reference “AC
Operation” or “DC Operation” as outlined later in this
chapter.

DANGER

Using a generator indoors CAN KILL YOU IN MINUTES.

Generator exhaust contains carbon monoxide.
This is a poison you cannot see or smell.

NEVER use inside a home
or garage. EVEN IF doors
and windows are open.

Only use OUTSIDE and
far away from windows,
doors, and vents.

OFF

OPERATION

Stopping the Engine

In case of emergency, position the engine switch to OFF
to stop the engine. Under normal conditions, perform the
following procedure.

Shut off or disconnect all appliances connected to the
generator.

Position the engine switch to OFF.

Allow the engine to cool and position the fuel tank cap
vent lever to OFF.

AC Operation

Before connecting a device or power cord to the
generator, ensure it is in good condition. Faulty
appliances or power cords can create a potential for
electrical shock.

If  an  appliance  begins  to  operate  abnormally,
becomes  sluggish,  or  suddenly  stops,  immediately
shut  it  off.  Disconnect  the  appliance  and  determine
whether  the  problem is the appliance or if the rated
load capacity of the generator has been exceeded.

Ensure the combined electrical rating of the device or
appliance does not exceed the maximum allowed by
the  generator.  Never  exceed  the  maximum  power
rating  of  the  generator.  Power  levels  between  rated
and  maximum  may  be  used  for  no  more  than  30
minutes.

NOTE:  When the  electric motor  starts, the  overload
indicator  (middle  light)  may  illuminate  (RED)  and
extinguish  within  4  seconds.  If  the  overload
indicator remains illuminated, consult the generator
dealer.

NOTE:  In  order  to  insure  the  optimum  output  and
the  maximum  service  life  of  the  generator,  the
generator  should  run  at  a  50%  load  for  the  first  20
hours

Start the engine and ensure that the output indicator
(A) illuminates (GREEN).

Plug the device or extension cord into one of the AC
receptacles (B).

OFF

OPERATION

Turn on the device.

NOTE:  If the generator is overloaded or if there is a
short circuit in a connected appliance, the overload
indicator  (RED)  will  illuminate.  The  overload
indicator  will  remain  illuminated  and,  after  about  4
seconds,  current  to  the  connected  appliance(s)  will
shut off but the engine will stay running. The output
indicator (GREEN) will extinguish.

If overloaded or short circuit in a connected device
occurs, stop the engine and refer to the
“Troubleshooting” chapter. Determine if the cause is
a short circuit in the connected device or an overload.
Correct the problem and restart the generator.

After determining the cause of the overload and when
it is safe to resume using the AC power in order to
correct the overload condition and then press the
overload reset switch on the front panel. AC power will
be restored immediately.

AC Capacity

In case of substantial overloading, the electronic circuit
protector will activate. Slightly overloading the generator
or running at maximum power operation (30 minutes)
may not switch the circuit ON, but will shorten the service
life of the generator.

Maximum power is:

(see “Specifications” page)

For continuous operation, do not exceed rated power:

(see “Specifications” page)

Consider the total power requirements of all connected
devices. Appliance and power-tool manufacturers usually
list the rating information near the model or serial number.
After plugging in a device, allow the generator to stabilize
before plugging in additional items. Always consider the
generator capacity before plugging in any device.

NOTE: Typical wattages are listed in the table below.
Before plugging any device into the generator, verify
the manufacturer-listed wattage on the device.

Wattage Reference Table

DEVICE

RUNNING

(RATED)

WATTS

ADDITIONAL

STARTING

(SURGE)

WATTS

Circular Saw - 7 1/4”

1400

2300

Coffee Maker

1000

Dehumidifier

650

800

Electric Drill -
3/8”, 4 Amps

440

600

Hair Dryer

300 - 1200

Light Bulb (75-Watt)

Microwave Oven
1000-Watt

1000

1400

Paint Sprayer

360

1080

Heat Pump

4700

4500

Personal Computer
with 17” Monitor

800

Radio

300

Refrigerator

400 - 800

2200

Space / Wall Heater

1800

Table Saw / Radial Arm
Saw - 10”

2000

Do not use or only use with the Polaris Parallel Kit,
see page 23 for more information

High-Pressure Washer-
1 HP

1200

3600

Garage Door Opener
1/2 HP

875

2350

Sump Pump - 1/2 HP

1050

2200

Central AC Unit
48,000 BTU

6000

7800

Television (Color) - 27”

500

Air Compressor - 1 HP

1600

4500
