ELECTRICAL

13.33

ECU PLUG #1

PIN

#

COLOR

ITEM

PIN

#

COLOR

ITEM

1

Orange

Regulator Rectifier

18

Orange

Regulator Rectifier

2

--

--

19

Red/Black

Battery Voltage (+)

3

White/Green

Speed Limit Signal

20

Black/Blue

Sensor Ground

4

Yellow/Red

Tachometer Signal

21

Black

Aux Kill Switch

5

Blue/Red

Water Temp Signal

22

Black/Red

Soft Stop

6

Green

PTO Injector

23

Blue

Air Temp Sensor

7

--

--

24

White/Black

Exhaust Temp Sensor

8

Yellow

MAG Injector

25

Green/Blue

Solenoid Ground

9

--

--

26

Red

Voltage Regulator (out) power

10

Orange

Regulator Rectifier

27

--

--

11

White/Blue

Chassis Relay Coil

28

Brown

Ground

12

--

--

29

Black/White

Diagnostic

13

Grey

Reverse Switch

30

Green/Blue

Hot/DET Lamp

14

Red/Blue

Injector Power PTO

31

White

Reverse Lamp

15

--

--

32

Light Green/

Red

Ground Speed Signal

16

Red/Blue

Injector Power MAG

33

Orange/Green

Battery Relay Coil

17

--

--

34

Brown/WHite

Fuel Pump Switch

To Magneto (coil)

To Magneto
Crank Position Sensor

To ECU

EV Solenoid

External Power

Digital Wrench

TPS

Coolant Temp Sensor

PTO Ign Coil

(blue cover)

#1 MAG Coil

(white cover)

DET Sensor

ELECTRICAL

13.34

ECU PLUG CONNECTION #2

ELECTRICAL

13.35

ECU PLUG #2

PIN

#

COLOR

ITEM

PIN

#

COLOR

ITEM

1

White

CPS (2 tooth)

18

--

--

2

White/Red

CPS (2 tooth)

19

Purple

Detonation Sensor

3

Green

CPS (5 tooth)

20

Black/Blue

Detonation Sensor Ground

4

White/Green

CPS (5 tooth)

21

Black/Blue

Coolant Temperature Sensor

Ground / TPS Ground

5

--

--

22

Black/Blue

External Power Ground

6

--

--

23

Brown

MAG Ignition Coil Ground

7

Pink

Digital Wrench

24

Brown

PTO Ignition Coil Ground

8

Orange

External Power (+)

25

Brown

Exciter Coil Ground

9

Black/Yellow

MAG Ignition Coil

26

Red

Voltage Regulator Out

10

--

--

27

White/Yellow

EV Solenoid

11

Yellow

Coolant Temp Sensor

28

--

--

12

Aqua

TPS Signal

29

--

--

13

--

--

30

Red/White

Power Supply (5 Volts)

14

Red/Blue

Digital Wrench

31

Blue/Yellow

Injector Coil

15

Gray

Digital Wrench

32

Blue/Yellow

Injector Coil

16

Black/White

Diagnostic Lamp

33

Green/Red

Exciter Coil (+)

17

Black/Red

PTO Ignition Coil

34

Green/Yellow

Exciter Coil (Center)

ELECTRICAL

13.36

STATOR

G/R

G/Y

BR/W

COILS

G/R -- G/Y=15Ω

G/Y -- BR/W=15Ω

G/R -- BR/W = 30Ω

STATOR (4010727)

COLOR

SYSTEM FUNCTION

VALUE

CHARGE

Yellow

Charge Coil

Resistance between the

coils = 13Ω ±15%

Yellow

Charge Coil

coils =.13Ω ±15%
No continuity between

Yellow

Charge Coil

No continuity between

any Yellow to ground

CPS

(see page 13.28 for gap specification)

GRN/ GRN

WHT

Crank Position Sensor (5 Tooth) Igni-

tion timing. machine will not run

with out.

Resistance between

White/Green and Green

= 190 Ω±15%

Red/ Red

White

Crank Position Sensor (2 Tooth) Lo-

cates TDC and RPM. Machine will

not run with out.

Resistance between

White/Red and White =

190 Ω±15%

COILS

Green/Red

Resistance between

Green/Red and Green/

Yellow = 15Ω

Green/Yellow

Exciter Coil -- Powers the Ignition

Coils

Resistance between

Green/Red and Brown/

White = 30Ω

Brown / White

~ to Grd

INJECTORS

Blue/Yellow

Injector Coil -- Powers Injectors to 16

Volts

Resistance between

Blue/Yellow and Blue/

Yellow -- 2.4Ω

STATOR: Supplies the system with 3 Phase AC current to power the system (300 watts).

COILS: Troubleshooting: If gauge and lights cut out above 3500 RPM charge coil is suspect to failure. Brown/White when dis-
connected will have no continuity to engine ground.
