50

THE PERFECT FIT

Suspension Adjustments

Factory settings, combined with user adjustments to the rear track shock
spring (RTSS), should be all that’s necessary to provide the best riding
experience for most riders. The primary adjustment for overall vehicle
balance is RTSS preload. Perform this adjustment first.

Always perform shock spring preload adjustments with the weight of
the vehicle removed from the shock and with the shock at full extension.

NOTICE: Never adjust spring preload to an installed length longer than the

maximum or shorter than the minimum lengths in the following chart.
Damage to the suspension could result. Never exceed one inch (2.54
cm) of preload beyond the factory settings. When decreasing preload,
make sure at least two turns of preload are holding the retainer
against the spring.

Spring Type

Maximum

Installed Length

Minimum Installed

Length

RMK Factory Spring

10 3/4" (27.3 cm)

9 5/8" (24.5 cm)

PRO-RMK Factory Spring

11" (28 cm)

9 3/4" (24.8 cm)

ASSAULT RMK Factory Spring

11" (28 cm)

9 3/8" (23.8 cm)

250# Optional Heavy Spring

10 7/8" (27.6 cm)

9 7/8" (25 cm)

Installed Length

Measurement

51

THE PERFECT FIT

Suspension Adjustments

For riders who weigh 160-220 lbs. (73-100 kg), test ride at factory
settings, then make fine-tuning adjustments. See page 52.

For riders outside the 160-220 lbs. (73-100 kg) weight range, adjust the
factory-set preload to the following installed lengths as a starting point,
then test ride before making fine-tuning adjustments. Do not exceed the
minimum and maximum installed length requirements. See page 50.

TIP: If adjustments to the factory-installed springs are not sufficient for riders

over 300 lbs. (136 kg), optional heavy springs are available. Please see
your POLARIS dealer.

Initial RTSS Preload Settings

(Measure spring length with suspension off the ground)

Rider Weight

Model

Installed Length

For Factory-Installed Springs

Under 160 lbs.

Under 73 kg

RMK/PRO-RMK

10 3/4"

27.3 cm

ASSAULT RMK

10 7/8"

27.6 cm

160-220 lbs

73-100 kg

RMK/ASSAULT

RMK

*10 1/4"

*26 cm

PRO-RMK

*10 3/8"

*26.4 cm

220-280 lbs.

100-127 kg

RMK/PRO-RMK

10 1/8"

25.7 cm

ASSAULT RMK

10"

25.4 cm

280-340 lbs.

127-154 kg

RMK/PRO-RMK

9 3/4"

24.8 cm

ASSAULT RMK

9 1/2"

24.1 cm

*Factory Setting

For Optional 250-Pound Heavy Springs

250-300 lbs.

113-136 kg

ALL

10 1/8"

25.7 cm

300-350 lbs.

136-159 kg

ALL

10"

25.4 cm

52

THE PERFECT FIT

Suspension Adjustments

Fine-Tuning Your Suspension Set-Up

The primary adjustment for overall vehicle balance is RTSS preload.
Adjust the factory-set preload to the recommended setting for your
weight and then test ride. Additional minor adjustments can then be
made to the spring preload to adjust the feel of the vehicle. Do not
exceed the minimum and maximum installed length requirements. See
page 50.

For more ski lift (transfer), reduce spring preload by increasing the
installed length. Rotate the spring 1-2 full turns counter-clockwise
(when viewed from bottom). This will enhance maneuverability, mak-
ing the snowmobile more “flickable” although it may hinder climbing
performance.

For less ski lift (transfer), increase spring preload by reducing the
installed length. Rotate the spring 1-2 full turns clockwise (when viewed
from bottom). This will improve climbing ability and rider control.

To control the overall balance of the vehicle use the following guideline:

• More rear track shock spring preload increases ski pressure. Less pre-

load decreases ski pressure.

• Spring preload can affect bottoming resistance. More preload means

less bottoming. Less preload means a softer ride (and more bottom-
ing). Both adjustments will affect overall balance and ski pressure.

After adjusting RTSS preload to your satisfaction, the front track shock
(FTS) spring preload and independent front suspension (IFS) spring pre-
load can also be adjusted. See page 54.

53

THE PERFECT FIT

Suspension Adjustments

Shock Compression Damping (RMK/ASSAULT RMK)

The primary adjustment for overall vehicle balance is RTSS preload.
Perform this adjustment first. See page 50. After adjusting RTSS pre-
load to your satisfaction, compression damping adjustments can be
made to control ride quality and bottoming resistance.

800 RMK Damping

Make the adjustments in half-turn incre-
ments, then test ride.

To stop bottoming, turn the damping
screw clockwise one half-turn, then test
ride. Repeat the adjustment until bottom-
ing stops and the desired ride quality is
achieved.

ASSAULT RMK Damping

Compression damping can be adjusted at
the front suspension and at the rear track
shock. Make adjustments in 2-click incre-
ments, then test ride. When adjusting the
front suspension, always adjust both
clickers equally.

To stop bottoming of the front or rear sus-
pension (stiffer ride), rotate the clicker(s)
clockwise two clicks (as viewed from the
top of the clicker), then test ride. Repeat
the adjustment until bottoming stops and
the desired ride quality is achieved.

For a more plush ride at the front or rear
suspension, rotate the clicker(s) counter-
clockwise two clicks, then test ride.
Repeat the adjustment until the desired
ride quality is achieved.

Screw

Stiffer

Softer

S

tiff

e

r

S

o

ft

e

r
