54

THE PERFECT FIT

Suspension Adjustments

Independent Front Suspension and Front Track Shock
Spring Preload (RMK/PRO-RMK)

Factory settings, combined with user adjustments to the rear track shock
spring, should be all that’s necessary to provide the best riding experi-
ence for most riders. The primary adjustment for overall vehicle balance
is RTSS preload. Perform this adjustment first. See page 50.

After adjusting the preload, and if desired, additional adjustments can be
made to the independent front suspension and front track shock preload.



When adjusting the front suspension, be sure the springs on both sides
of the vehicle are at the same adjustment.

Always perform shock spring preload adjustments with the weight of
the vehicle removed from the shock and with the shock at full extension.

NOTICE: Never exceed one inch (2.54 cm) of preload beyond the factory set-

tings. When decreasing preload, make sure at least two turns of pre-
load are holding the retainer against the spring.

For a softer ride on rough, washboard surfaces, reduce front track shock
(FTS) spring preload by 1-2 turns.

To improve corner stability, increase front suspension (IFS) spring pre-
load by 1-2 turns on both sides of the vehicle.

NOTICE: IFS spring installed length must always be set at least 1/4 inch (6 mm)

less than the free length.

55

THE PERFECT FIT

Handlebar Adjustments

Handlebar Position (if equipped)

1. Loosen the four bolts on the bottom of the adjuster block. If neces-

sary, pry the blocks apart with a screwdriver.

2. Adjust the handlebar forward or rearward to the desired position.

3. Tighten the bolts.

Handlebar Angle

1. Loosen the four bolts on the top of the adjuster block. If necessary,

pry the blocks apart with a screwdriver.

2. Adjust the handlebar forward or rearward to the desired angle.

3. Tighten the bolts.

Loosen top bolts to adjust

handlebar angle

Loosen bottom bolts to

adjust handlebar position

(if equipped)

56

PRE-RIDE INSPECTIONS

Pre-Ride Checklist

Inspect all items on the checklist for proper operation or condition
before each use of the snowmobile. Procedures are outlined on the refer-
enced pages.

Item

See Page

Drive Belt or QUICKDRIVE Belt

99

Steering System

61

Recoil Rope

61

Coolant Level

89

Chaincase Oil Level

83

Injection Oil Level

69

Parking Brake Lock/Brake Lever/Brake System

59, 60, 94

Auxiliary Shut-Off Switch (Engine Stop Switch)

62

Ignition Switch

62

Headlight/Taillight/Brakelight

62

Suspension Mounting Bolts

57

Skags (Wear Bars)

109

Ski Saddle and Spindle Bolts

57

Hood and Side Panel Fasteners

81

Throttle Lever/Safety Switch

70, 71

Rear Wheel Idler Bolts

105

Tether Switch/Strap (if equipped)

62

Track Alignment/Condition

61, 106

Rail Slide Condition

109

57

PRE-RIDE INSPECTIONS

Pre-Ride Suspension Inspection

Loose nuts and bolts can reduce your snowmobile's reliability and cause
needless repairs and down time. Before beginning any snowmobile trip,
a visual inspection will uncover potential problems. Check the follow-
ing items on a weekly basis or before any long trip.

Item

See Page

Check suspension mounting bolts for tightness.

--

Check rear idler wheel bolts for tightness.

105

Check rear idler adjusting bolt locknuts for tightness.

--

Check front torque arm limiter strap condition.

--

Check rail slide condition.

109

Check track tension.

104

Check ski runner/skag condition.

109

Check ski spindle bolts for tightness.

--

Check tie rod end nuts for tightness.

--
