Snowmobile Polaris 600 RMK / 600 PRO RMK / 800 RMK / 800 PRO RMK / 800 RMK Assault. Manual - part 10

42

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

First Time Use of Your Security System

Perform all tasks in the order shown if you wish to

activate and use the optional security system.

TASK 1: Activate the security system
See your authorized POLARIS dealer to have the optional security system
feature activated in the electronic control unit (ECU).

TASK 2: Lock the System the First Time
1. Start the engine and lock the parking brake.
2. Press and hold the MODE and SEL buttons for 3

seconds, then release. SECURE OFF should be
displayed. If not, repeat this step.

3. Wait until ENTER CODE displays, then press

and release SEL to advance the digit. When “0”
is displayed, press and release MODE to accept
the digit. TIP: If the ENTER CODE screen exits
due to inactivity, repeat step 2.

4. Press and release SEL to advance the second

digit. When “0” is displayed, press and release
MODE to accept the digit.

5. Press and release SEL to advance the third digit.

When “0” is displayed, press and release MODE
to accept the digit.

6. After accepting the third digit, view the display

screen. SECURE ON displays if the system locks.

NOTE:

The system is now locked.

7. You must now unlock the system. Proceed imme-

diately to TASK 3.

43

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

First Time Use of Your Security System

TASK 3: Unlock the System

1. When the engine is running, the display will

alternate between SECURE ON and
ENTER CODE. Wait until ENTER CODE
displays, then press and release SEL to
advance the digit. When “0” is displayed,
press and release MODE to accept the
digit.

2. Press and release SEL to advance the second

digit. When “0” is displayed, press and release
MODE to accept the digit.

3. Press and release SEL to advance the third digit.

When “0” is displayed, press and release MODE
to accept the digit.

4. After accepting the third digit, view the display

screen. SECURE OFF displays if the system
unlocks.

NOTE:

The system is now unlocked.

5. You must now enter a new security code. Proceed immediately to TASK 4.

TASK 4: Enter Your New Security Code

1. Immediately after locking and unlocking the system, and while SECURE

OFF is displayed, press and release the MODE button to bring up the
ENTER CODE screen.

2. When ENTER CODE displays, use the SEL and MODE buttons to select

and accept each digit of a new personal security code.

3. After accepting the third digit, view the display

screen. The new code and CODE SET will dis-
play if the system accepted your new code. You
will not see this display again.

NOTE:

Your new code is now set. The system is

NOT locked.

4. Record your new security code in a safe place for future reference.

Record your new personal security code here: __________________

TIP: If you lose your personal security code, see your dealer to have the code

reset to “000”. Then perform TASK 2 through TASK 4 to change the code
to one of your own choosing.

888

44

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

Locking the System With Your Personal Security Code

1. Start the engine and lock the parking brake.

2. Press and hold the MODE and SEL buttons

for 3 seconds, then release. SECURE OFF
should be displayed. If not, repeat this step.

3. Wait until ENTER CODE displays, then

press and release SEL to advance the digit.
When the first digit of your security code is
displayed, press and release MODE to
accept the digit.

TIP: If the ENTER CODE screen exits due to inactivity,

repeat step 2.

4. Continue to use SEL and MODE to select

and accept the remaining two digits of the
code.

5. After accepting the third digit, view the dis-

play screen. SECURE ON displays if the
system locks. Engine speed is now limited
and the snowmobile cannot be driven.

TIP: When the engine is running, the display will alter-

nate between SECURE ON and ENTER CODE.

6. If BAD CODE displays, the screen will then

return to the ENTER CODE screen. Repeat
steps 3-5 to re-enter the security code.

45

FEATURES

Instrument Cluster

Rider Information Center

Security System (Ignition Lock System)

Unlocking the System With Your Personal Security Code

1. When the engine is running, the display

will alternate between SECURE ON and
ENTER CODE. Wait until ENTER
CODE displays, then press and release
SEL to advance the digit. When the first
digit of your security code is displayed,
press and release MODE to accept the digit.

TIP: When the system is locked and engine temperature is above 120° F (49°

C), the correct password must be entered within 60 seconds or the engine
will shut down.

2. Continue to use SEL and MODE to select

and accept the remaining two digits of the
code.

3. After accepting the third digit, view the

display screen. SECURE OFF displays if
the system unlocks.

4. Re-enter your code if BAD CODE

displays.

NOTE: The system is now unlocked.
