Caterpillar. Dealer service tools catalog (2018) - page 16
Hydraulic/Mechanical Pullers/Drivers
BEARING PULLERS
Bearing Cup Pulling Attachment Dimensions
• Used in conjunction with push-pullers to
provide easy removal of bearing cups, oil
seals, and bushings from blind holes without
damage
Part No. a
for 1S-5188,
A
B
C
D (Min.)
D(Max.)
E
F
G
H
J
K
7S-7786 and
1P-7461
1H-3112 Puller b
25.4 mm
6.35 mm
6.35 mm
76.2 mm
228.6 mm
19.05 mm
19.05 mm
50.8 mm
152.4 mm
180.85 mm
63.5 mm
6V-7888 b
(1.00 in)
(0.25 in)
(0.25 in)
(3.00 in)
(9.00 in)
(0.75 in)
(0.75 in)
(2.00 in)
(6.00 in)
(7.12 in)
(2.50 in)
8B-7554 Puller b
12.7 mm
2.79 mm
2.79 mm
38.1 mm
127.0 mm
12.7 mm
12.7 mm
20.57 mm
74.68 mm
93.22 mm
33.27 mm
1P-7461 a
(0.50 in)
(0.11 in)
(0.11 in)
(1.50 in)
(5.00 in)
(0.50 in)
(0.50 in)
(0.81 in)
(2.94 in)
(3.67 in)
(1.31 in)
14.22 mm
4.57 mm
4.57 mm
38.1 mm
127.0 mm
12.7 mm
12.7 mm
20.57 mm
74.68 mm
95.25 mm
25.4 mm
1S-5188 a
(0.56 in)
(0.18 in)
(0.18 in)
(1.50 in)
(5.00 in)
(0.50 in)
(0.50 in)
(0.81 in)
(2.94 in)
(3.75 in)
(1.00 in)
15.75 mm
3.05 mm
6.35 mm
38.1 mm
152.4 mm
12.7 mm
12.7 mm
28.45 mm
127.0 mm
146.05 mm
38.1 mm
6V-7887 b
(0.62 in)
(0.12 in)
(0.25 in)
(1.50 in)
(6.00 in)
(0.50 in)
(0.50 in)
(1.12 in)
(5.00 in)
(5.75 in)
(1.50 in)
11.18 mm
4.57 mm
4.57 mm
38.1 mm
177.8 mm
12.7 mm
12.7 mm
20.57 mm
155.45 mm
176.28 mm
25.4 mm
7S-7786 a
(0.44 in)
(0.18 in)
(0.18 in)
(1.50 in)
(7.00 in)
(0.50 in)
(0.50 in)
(0.81 in)
(6.12 in)
(6.94 in)
(1.00 in)
a. Optional legs (sold separately)
b. Standard legs
Swivel Nuts
Warranty: Caterpillar ®Six Months
• Used on 8B-7554 Bearing Cup Puller
Attachment
• Service replacement nuts for 5P-4750
Adjustment Screw Assembly
• Replace worn or damaged parts to extend
tool life
Item
Part Number
Description
Use
1
357-2991
Swivel Nut
fits on adjustment end of adjustment screw
2
357-2992
Swivel Nut
fits on stationary end of adjustment screw
10-18 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
BEARING PULLERS
Puller Kit
Model Usage: HH44DE Harvester Head
• 380-5712 used to easily remove and install
the drive sprocket on the saw motor
Warranty: Caterpillar ®Six Months
• 380-5713 used to replace piston seals on the
feed out cylinder
• 380-5717 used to replace the check valve on
the tensioning system
• 380-5718 used to replace the check valve on
the chain lubricator
Part No.
Dimensions
Weight
431.8 x 76.2 mm (17 x 3 in) - Includes (1) grinder/plate, (2) hex
380-5712
1.93 kg (4.25 lb)
headbolts, (1) nut and (1) puller bolt
380-5713
75x 50 mm (2.95 x 1.97in)
.29 kg (.64 lb)
380-5717
57x 44 mm (2.24 x 1.73in)
.045 kg (.10 lb)
380-5718
70x 30 mm (2.75 x 1.18in)
.004 kg (.009 lb)
Bearing Puller Assembly
Model Usage: 795F AC Large Mining Trucks
• Used to remove the bearing retainer 385-9873
• Use with two M30 studs, spaced at 380mm
and ball bearing 164-9923 on the electric
(15”) distance
Warranty: Caterpillar ®Six Months
generator group
• M8-tapped hole provided for installing lifting
• Tool fits around the bearing retainer,
eyebolt at the top of the tool
protecting the sealing ring 385-9189 from
damage
Part No.
Description
Capacity
Diameter
Weight
455-0124
Bearing Puller Assembly
20 T (196 kN)
520mm(20.5in)
27 kg (59.52lb)
Bearing Puller Adapter
Model Usage: 795F AC
• Used to remove the bearing 286-8083 from
795F AC rear frame and axle housing
Warranty: Caterpillar ®Six Months
Part No.
Description
Dimensions
Weight
520-1526
Bearing Puller Adapter
Dia 166 X 25 mm (6.5 X 1 in)
4 kg (8.8 lb)
Bearing Adapter
Model Usage: 797F
• Used to remove the sleeve bearing 332-7425
of center arm (Tri-link)
Warranty: Caterpillar ®Six Months
Part No.
Description
Dimensions
Weight
525-5122
Bearing Adapter
Dia 132 x 25 mm (Dia 5.2 x 1 in)
2.1 kg (4.6 lb)
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-19
Hydraulic/Mechanical Pullers/Drivers
BEARING PULLERS
Bearing Puller
Model Usage: 994K
• 526-5522 used to remove the bearing
• Use with M64 threaded rod
420-5758 (K-pin) in the tilt link of lift arm
Warranty: Caterpillar ®Six Months
assembly
• 526-5523 used to remove the bearing
526-5522
420-5759 (A-pin) in the rear of the lift arm
assembly
Part No.
Dimensions
Weight
526-5522
Dia. 279 x 38.1 mm (11 x1.5 in)
12 kg (26.5 lb)
526-5523
Dia. 259 x 38.1 mm (10.2 x 1.5 in)
13 kg (28 lb)
526-5523
Bearing Puller Assembly
Warranty: Caterpillar ®Six Months
• Used for numerous operations where space
• Knife-like edges can be forced behind gears or
does not permit attaching other types of
bearings and used in conjunction with push-
pullers directly on the part to be pulled
pullers, or the forcing screws illustrated
Item
Part No.
Description
Qty.
Capacity
Spread
Length
Width
Thread Size
Bearing
-
446-9413
Puller
-
50
0.67 - 9.65 in
-
11.5
1 1/4 in - 12
Assembly
Bearing
-
446-9412
Puller
-
30
0.67 - 9.65 in
-
11.5
1 in - 14
Assembly
Bearing
-
1H-3110
Puller
-
20
0.75 - 13.38in
20.5
10.25
1 in - 14
Assembly
—
5F-7343
Puller
-
20
0.625 - 8.00in
14.38
7.12
1 in - 14
Bearing
-
8B-7551
Puller
-
15
0.50 - 5.25 in
10.5
6.00
5/8 in - 18
Assembly
Bearing
-
8H-0663
Puller
-
9
0.38 - 4.62 in
8.5
4.25
5/8 in - 18
Assembly
Bearing
-
9S-9152
Puller
-
4
0.12 - 2.00 in
4.19
2.44
3/8 in - 16
Assembly
9S-9152 Service/Repair Parts
2
1B-4204
Nut
2
-
-
-
-
-
3
1P-1430
Bolt
2
-
-
-
-
-
8H-0663 Service/Repair Parts
2
1B-4206
Nut
4
-
-
-
-
-
3
8B-7552
Stud
2
-
-
-
-
-
8B-7551 Service/Repair Parts
2
1B-4207
Nut
4
-
-
-
-
-
3
3H-0459
Stud
2
-
-
-
-
-
5F-7343 Service/Repair Parts
2
1B-4208
Nut
4
-
-
-
-
-
3
3H-0460
Stud
2
-
-
-
-
-
1H-3110 Service/Repair Parts
2
3S-1356
Nut
4
-
-
-
-
-
3
1U-7758
Stud
2
-
-
-
-
-
10-20 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
BEARING PULLERS
Bearing and Seal Driver Group
Warranty: Caterpillar ®Six Months
• Contains plate sizes from 7/16 inch to 1 inch
• Drive plates can be used in various
diameter (in 1/16 inch increments)
combinations to install parts flush with a
housing or some distance below a housing
• Particularly useful for work on small
surface
components such as oil and water pumps
• Instructions included
• Plates in this group are also contained in the
1P-0510 Group
• All bolts have 1/4 inch-20 threads
• Proper installation of bearings, races and
seals can be accomplished quickly and easily
with these driver tools
Part Number
Description
1P-0500
Bearing and Seal Driver Group
GroupConsists of:
1P-0454
Plate, 0.438 in Diameter
1P-0455
Plate, 0.500 in Diameter
1P-0456
Drive Plate
1P-0457
Plate, 0.625 in Diameter
1P-0458
Plate, 0.687 in Diameter
1P-0459
Plate, 0.750 in Diameter
1P-0460
Plate, 0.812 in Diameter
1P-0461
Plate, 0.875 in Diameter
1P-0462
Plate, 0.937 in Diameter
1P-0463
Plate
1P-0528
Extension Tube
1P-0529
Handle
4L-7124 a
Bolt - Hex Socket Head
5L-9018
Bolt, 1 3/4in long
6B-7225
Wrench, 3/16 in Hex
6J-2819
Bolt, 2 3/4in long
6L-5551
Bolt
6L-5897
Bolt, 7/8 in long
9S-1725 b
Case
9S-9155
Spacer
a. Part of 1P-0520 Driver Group
b. Warranty: Manufacturer, 90 Day
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-21
Hydraulic/Mechanical Pullers/Drivers
BEARING PULLERS
Bearing and Seal Driver Group
Warranty: Caterpillar ®Six Months
• Contains plate sizes from 7/16 inch to 3.00
• Drive plates can be used in various
inch diameter (in 1/16 inch increments)
combinations to install parts flush with a
housing or some distance below a housing
• All bolts have 1/4 inch-20 threads
surface
• Proper installation of bearings, races and
• Instructions included
seals can be accomplished quickly and easily
Part Number
Description
1P-0510
Bearing and Seal Driver Group
Consist:
1P-0454
Plate, 0.438 in Diameter
1P-0455
Plate, 0.500 in Diameter
1P-0456
Drive Plate
1P-0457
Plate, 0.625 in Diameter
1P-0458
Plate, 0.687 in Diameter
1P-0459
Plate, 0.750 in Diameter
1P-0460
Plate, 0.812 in Diameter
1P-0461
Plate, 0.875 in Diameter
1P-0462
Plate, 0.937 in Diameter
1P-0463
Plate
1P-0464
Plate, 1.062 in Diameter
1P-0465
Plate, 1.125 in Diameter
1P-0466
Plate, 1.187 in Diameter
1P-0467
Plate, 1.250 in Diameter
1P-0468
Plate, 1.312 in Diameter
1P-0469
Plate, 1.375 in Diameter
1P-0470
Plate, 1.437 in Diameter
1P-0471
Plate, 1.500 in Diameter
1P-0472
Plate, 1.563 in Diameter
1P-0473
Plate, 1.625 in Diameter
1P-0474
Plate, 1.687 in Diameter
1P-0475
Plate, 1.750 in Diameter
1P-0476
Plate, 1.812 in Diameter
1P-0477
Plate, 1.870 in Diameter
1P-0478
Plate, 1.937 in Diameter
1P-0479
Plate, 2.000 in Diameter
1P-0480
Plate, 2.062 in Diameter
1P-0481
Plate, 2.125 in Diameter
1P-0482
Plate, 2.187 in Diameter
1P-0483
Plate, 2.250 in Diameter
1P-0484
Plate, 2.312 in Diameter
1P-0485
Plate, 2.375 in Diameter
1P-0486
Plate, 2.437 in Diameter
1P-0487
Plate, 2.500 in Diameter
1P-0488
Plate, 2.562 in Diameter
1P-0489
Plate, 2.625 in Diameter
1P-0490
Plate, 2.687 in Diameter
1P-0491
Plate, 2.750 in Diameter
1P-0492
Plate
1P-0493
Plate, 2.875 in Diameter
1P-0494
Plate, 2.937 in Diameter
1P-0495
Plate, 3.000 in Diameter
1P-0528
Extension Tube
1P-0529
Handle
1P-0531 a
Handle
4L-7124 a
Bolt - Hex Socket Head
5L-9018
Bolt, 1 3/4in long
6B-7225
Wrench, 3/16 in Hex
6J-2819
Bolt, 2 3/4in long
6L-5551
Bolt
6L-5897
Bolt, 7/8 in long
9S-9155
Spacer
a. Part of 1P-0520 Driver Group
10-22 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
BEARING PULLERS
Bearing and Seal Driver Group
Warranty: Caterpillar ®Six Months
• Contains plate sizes from 3 1/16 inch to 6 1/4
• Drive plates can be used in various
inch diameter (in 1/16 inch increments)
combinations to install parts flush with a
housing or some distance below a housing
• All bolts have 1/4 inch-20 threads
surface
• Proper installation of bearings, races and
• Instructions included
seals can be accomplished quickly and easily
with these driver tools
• Includes: Box Bearing Driver
Part Number
Description
1P-0520
Bearing and Seal Driver Group
Parts in Group
1P-0496
Plate, 3.062 in Diameter
1P-0497
Plate, 3.125 in Diameter
1P-0498
Plate, 3.187 in Diameter
1P-0499
Plate, 3.250 in Diameter
1P-0501
Plate, 3.312 in Diameter
1P-0502
Plate, 3.375 in Diameter
1P-0503
Plate, 3.437 in Diameter
1P-0504
Plate, 3.500 in Diameter
1P-0505
Plate, 3.562 in Diameter
1P-0506
Plate, 3.625 in Diameter
1P-0507
Plate, 3.687 in Diameter
1P-0508
Plate, 3.750 in Diameter
1P-0509
Plate, 3.812 in Diameter
1P-0511
Plate, 3.875 in Diameter
1P-0512
Plate, 3.937 in Diameter
1P-0513
Plate, 4.000 in Diameter
1P-0514
Plate, 4.062 in Diameter
1P-0515
Plate, 4.125 in Diameter
1P-0516
Plate, 4.187 in Diameter
1P-0517
Plate, 4.250 in Diameter
1P-0518
Plate, 4.312 in Diameter
1P-0519
Plate, 4.375 in Diameter
1P-0521
Plate, 4.437 in Diameter
1P-0522
Plate, 4.500 in Diameter
1P-0523
Plate, 4.750 in Diameter
1P-0524
Plate, 5.000 in Diameter
1P-0525
Plate, 5.500 in Diameter
1P-0526
Plate, 6.000 in Diameter
1P-0527
Plate, 6.250 in Diameter
1P-0531 a
Handle
1P-0532 a
Handle
4L-7124 a
Bolt - Hex Socket Head
5L-9018
Bolt, 1 3/4in long
6B-7225
Wrench, 3/16 in Hex
6J-2819
Bolt, 2 3/4in long
6L-5551
Bolt
6L-5897
Bolt, 7/8 in long
9S-9155
Spacer
a. Part of 1P-0520 Driver Group
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-23
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Single and Double Acting Puller Cylinder Groups Summary
Warranty: Manufacturer's
Maximum
Maximum
Overall Cylinder
Center Hole
Part No.
Stroke
Weight
Overall Length
Operating
Seal Kits
Capacity
Diameter
Diameter
Pressure
Double Acting Cylinder Groups
68,950 kPa
1U-5197
80
10.16 cm (4 in)
30.07 kg (66.3lb)
241.3 mm (9.50 in)
165.1mm (6.5in)
38.6mm (1.52in)
6V-0008
(10,000 PSI)
68,950 kPa
316-1489
60
165.1mm (6.5in)
35.38 kg (78lb)
323.8 mm (12.75 in)
158.6 mm (6.25 in)
54.1mm (2.13in)
316-1500
(10,000 PSI)
68,950 kPa
465-6061
100
152.4mm (6in)
52.16 kg (115lb)
330 mm (13in)
185mm (7.2in)
52mm (2.05in)
465-6064
(10,000 PSI)
68,950 kPa
465-6062
150
127mm (4.5in)
66 kg (145.5lb)
283mm(11.1in)
216mm (8.5in)
63.5mm (2.5in)
316-1501
(10,000 PSI)
68,950 kPa
6V-3160
31
50.8 mm (2 in)
6.80 kg (15 lb)
12.7mm (0.50in)
10.16 cm (4 in)
29.4mm (1.16in)
-
(10,000 PSI)
68,950 kPa
6V-3170
55
12.7mm (0.5in)
9.53 kg (21 lb)
88.9mm (3.50in)
137.2mm (5.4in)
33.2mm (1.31in)
6V-3168
(10,000 PSI)
68,950 kPa
6V-3175
55
50.8 mm (2 in)
13.15 kg (29lb)
132.1 mm (5.20 in)
137.2mm (5.4in)
33.2mm (1.31in)
6V-3168
(10,000 PSI)
68,950 kPa
8S-7172
103
355.6mm (14in)
71.67 kg (158lb)
657.9 mm ( 25.90in)
160mm (6.3in)
-
9S-4527
(10,000 PSI)
68,950 kPa
9S-8900
71
177.8mm (7in)
49.47 kg ( 109.1 lb)
454.7 mm (17.90 in)
134.6mm (5.3in)
-
9S-9080
(10,000 PSI)
68,950 kPa
9S-8901
103
165.1mm (6.5in)
72.57 kg (160lb)
472.4 mm (18.60 in)
160mm (6.3in)
50.8 mm (2 in)
9S-4527
(10,000 PSI)
Single Acting Cylinder Groups
68,950 kPa
150-3624
75
155.7 mm (6.13 in)
33.34 kg (73.5lb)
311.1 mm (12.25 in)
146mm(5.75in)
-
163-5469
(10,000 PSI)
68,950 kPa
196-0222
100
168.4 mm (6.63 in)
41.28 kg (91lb)
504.9 mm (19.88 in)
158.7 mm (6.25 in)
-
-
(10,000 PSI)
68,950 kPa
316-1493
12
76.2 mm (3 in)
4.44 kg (9.8 lb)
184.2 mm (7.25 in)
69.85 mm (2.75 in)
19.6mm (0.77in)
316-1504
(10,000 PSI)
68,950 kPa
316-1494
30
155.7 mm (6.13 in)
21.77 kg (48lb)
330.2mm (13in)
114.3mm (4.5in)
33.3mm (1.31in)
316-1505
(10,000 PSI)
68,950 kPa
316-1495
30
63.5mm (2.5in)
10.88 kg (24lb)
178.6 mm (7.03 in)
114.3mm (4.5in)
33.3mm (1.31in)
316-1504
(10,000 PSI)
68,950 kPa
316-1496
20
50.8 mm (2 in)
7.71 kg (17 lb)
162mm(6.38in)
98.6mm (3.88in)
26.9mm (1.06in)
316-1507
(10,000 PSI)
68,950 kPa
360-6970
25
50.8mm (2.0in)
6.35 kg (14 lb)
165.1 mm (6.50 in)
85.5mm (3.38in)
-
361-4315
(10,000 PSI)
68,950 kPa
5P-9725
10
257mm(10.12in)
0.45 kg (1 lb)
660.4mm (26in)
57.2mm (2.25in)
-
-
(10,000 PSI)
Hydraulic Puller Group
68,950 kPa
1P-0820
17.5
50.8 mm (2 in)
6.62 kg (14.6 lb)
155.6 mm (6.13 in)
5.75 x 3.75 in
27mm (1.06in)
-
(10,000 PSI)
10-24 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Single Acting Hydraulic Pusher Cylinders Summary
Model Usage: All Models
European Union compliant, CE marked
Warranty: Manufacturer’s Limited Lifetime
360-6954
360-6962
360-6964
SummaryofSingleActingHydraulic PusherCylinders
Maximum
Retracted
Outside
Part Number
Capacity (Ton)
Stroke
Weight
Extended
Operating
Seal Kits
Height
Diameter
Pressure
Single Acting Pusher Rams
165.1 mm
241.3 mm
68,950 kPa
360-6953
5
76.2mm (3.00in)
1.49 kg (3.3 lb)
38.1mm (1.50in)
361-4312
(6.50 in)
(9.50 in)
(10,000 PSI)
215.9 mm
342.9 mm
68,950 kPa
360-6354
5
127mm(5.00in)
1.86 kg (4.1 lb)
38.1mm (1.50in)
361-4312
(8.50 in)
(13.50 in)
(10,000 PSI)
68,950 kPa
360-6955
5
16.0mm (0.63in)
.99 kg (2.2 lb)
41.4mm (1.63in)
57.2mm (2.25in)
58.6mm (2.31in)
361-4313
(10,000 PSI)
121.4 mm
175.5 mm
68,950 kPa
360-6956
10
54.1mm (2.13in)
2.31 kg (5.1 lb)
57.2mm (2.25in)
361-4314
(4.78 in)
(6.91 in)
(10,000 PSI)
155.7 mm
247.7 mm
403.4 mm
68,950 kPa
360-6957
10
4.45 kg (9.8 lb)
57.2mm (2.25in)
361-4314
(6.13 in)
(9.75 in)
(15.88 in)
(10,000 PSI)
257.3 mm
349.3 mm
606.6 mm
68,950 kPa
360-6958
10
6.35 kg (14.0 lb)
57.2mm (2.25in)
361-4314
(10.13 in)
(13.75 in)
(23.88 in)
(10,000 PSI)
158.8 mm
273.1 mm
431.5 mm
68,950 kPa
360-6959
25
9.98 kg (22.0 lb)
85.9mm (3.38in)
361-4315
(6.25 in)
(10.75 in)
(17.00 in)
(10,000 PSI)
158.8 mm
282.7 mm
441.5 mm
127.0 mm
68,950 kPa
360-6960
50
23.13 kg (51.0lb)
361-4316
(6.25 in)
(11.13 in)
(17.38 in)
(5.00 in)
(10,000 PSI)
168.4 mm
58.97 kg
357.1 mm
525.3 mm
177.8 mm
68,950 kPa
360-6961
100
361-4317
(6.63 in)
(130.0 lb)
(14.06 in)
(20.69 in)
(7.00 in)
(10,000 PSI)
Aluminum, Single Acting Pusher Rams
152.4 mm
281.9 mm
441.7 mm
149.4 mm
68,950 kPa
360-6962
50
14.29 kg (31.5lb)
361-4318
(6.00 in)
(11.1 in)
(17.39 in)
(5.88 in)
(10,000 PSI)
150.1 mm
321.1 mm
470.9 mm
180.1 mm
68,950 kPa
360-6963
100
21.91 kg (48.3lb)
361-4319
(5.91 in)
(12.64 in)
(18.54 in)
(7.09 in)
(10,000 PSI)
150.1 mm
336.0 mm
485.9 mm
130.0 mm
68,950 kPa
360-6969
50 (Locking)
11.88 kg (26.2lb)
361-4325
(5.91 in)
(13.23 in)
(19.13 in)
(5.12 in)
(10,000 PSI)
Shorty, Spring Return Pusher Rams
126.2 mm
68,950 kPa
360-6964
10
38.1mm (1.50in)
4.08 kg (9.0 lb)
88.1mm (3.47in)
69.9mm (2.75in)
361-4320
(4.97 in)
(10,000 PSI)
143.0 mm
68,950 kPa
360-6965
20
44.5mm (1.75in)
4.99 kg (11.0 lb)
98.6mm (3.88in)
92.2mm (3.63in)
361-4321
(5.63 in)
(10,000 PSI)
117.6 mm
179.3 mm
101.6 mm
68,950 kPa
360-6966
30
61.9mm (2.44in)
6.80 kg (15.0 lb)
361-4322
(4.63 in)
(7.06 in)
(4.00 in)
(10,000 PSI)
122.2 mm
182.6 mm
123.9 mm
68,950 kPa
360-6967
50
60.5mm (2.38in)
10.87 kg (24.0lb)
361-4323
(4.81 in)
(7.19 in)
(4.88 in)
(10,000 PSI)
141.2 mm
198.3 mm
165.1 mm
68,950 kPa
360-6968
100
57.2mm (2.25in)
22.68 kg (50.0lb)
361-4324
(5.56 in)
(7.81 in)
(6.50 in)
(10,000 PSI)
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-25
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Single Acting Hydraulic Lifting Cylinders Summary
Retracted
Outside
Part Number
Capacity (Ton)
Extended
Seal Kit
Height
Diameter
Spring Return Lifting Rams
86.36 mm
396-9840
25
12.0
20.0
419-5743
(3.4in)
Double Acting Cylinder Group
Warranty: Caterpillar ®Six Months
• Provides a special crosshead which allows the
Specifications
puller to be converted to either a 2- or 3-jaw
• Overall length : 467 mm (18.6 in)
operation
Cylinder diameter: 160 mm (6.3 in)
•
• Especially well suited for removing final drive
• Stroke: 165 mm (6.5 in)
sprockets
• Weight: 72.5 kg (160 lb)
• Includes 9S-9068 Handle
• Capacity: 78.9 t (87 tons) rod in, 93.4 t
(103 tons) rod out
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
• Includes: NEEG2098 Decal
Part No.
Description
9S-8901
Cylinder Group
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
2N-1746
Hex Bolt
3B-4506
Lock Washer
6H-4158
Pin
7B-2499
Ring
9S-4522
Piston
9S-4527
Cylinder Repair Kit
9S-9067
Cylinder Rod
9S-9068
Handle
10-26 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Double Acting Cylinder Group
Warranty: Caterpillar ®Six Months
• Provides a special crosshead which allows the
Specifications
puller to be converted to either a 2- or 3-jaw
• Overall length: 455 mm (17.9 in)
operation
Cylinder diameter: 134 mm (5.3 in)
•
• Especially well suited for removing final drive
• Stroke: 180 mm (7.1 in)
sprockets
• Weight: 49.4 kg (109 lb)
• Capacity: 50 t (55 tons) rod in, 64.4 t (71 tons)
rod out
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
• Includes: NEEG2109 Decal
Part No.
Description
9S-8900
Cylinder Group
Service/Repair Parts
1B-4330
Nut
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
3B-4504
Lock Washer
6H-4158
Pin
7B-2499
Ring
7B-2742
Bolt
8H-3128
Bolt - Hex Socket Head
9S-4528
Bearing
9S-9067
Cylinder Rod
9S-9078
Bolt
9S-9080
Repair Kit
Double Acting Cylinder Group
Warranty: Caterpillar ®Six Months
• Used with the 1P-3490 Master Pin
Specifications
Arrangement to remove and install track
• Overall length: 65.78 cm (25.9 in)
master pins
Cylinder diameter: 16 cm (6.3 in)
•
• Allows the operation to be accomplished in
• Stroke: 35.56 cm (14.0 in)
1 stroke
• Weight: 71.66 kg (158 lb)
• Capacity: 78.9 t (87 tons) rod in 93.4 t
(103 tons) rod out
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
• Includes: NEEG2107 Decal
Part Number
Description
8S-7172
Cylinder Group
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
9S-4521
Rod
9S-4522
Piston
9S-4527
Cylinder Repair Kit
9S-4528
Bearing
9S-4920
Bolt
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-27
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Double Acting Cylinder Group
Warranty: Manufacturer’s Limited Lifetime
• Has a large center hole through which forcing
• Weight : 35.38 kg (78 lb)
screws or other accessories may be extended
• Capacity: 60 tons
for lifting and pulling applications
• Center hole diameter: 54.10 mm (2.13 in)
Specifications
• Maximum operating pressure: 68,950 kPa
• Overall length: 32.38 cm (12.75 in)
(10,000 PSI)
• Cylinder diameter: 15.87 cm (6.25 in)
• Includes: NEEG2111 Decal
• Stroke: 16.51 cm (6.5 in)
Part Number
Description
316-1489
CylinderGroup (60 Ton)
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
316-1500
Seal Kit
Cylinder Group - 100 Ton
Warranty: Caterpillar ®Six Months
• Single-acting, spring-return cylinder
• Extended height: 505.0 mm (19.88 in)
• Equipped with a quick disconnect fitting
• Outside diameter: 160.0 mm (6.25 in)
• Collar thread: 6 1/4-12
Specifications
• Capacity: 100 Ton
• Collar thread length: 56.0 mm (2.25 in)
• Stroke: 168.3 mm (6.63 in)
• Working pressure: up to 68,950 kPa
(10,000 PSI)
• Retracted height: 337.0 mm (13.25 in)
Part Number
Description
196-0222
Cylinder Group
10-28 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Service Cylinder Attachments
Model Usage: All
• Cylinder attachments for 5 thru 25 ton
cylinders allows more options using standard
Warranty: Manufacturer’s
cylinders for various job applications.
Part No.
Description
Dimensions
Weight
64 x 57 mm
465-4079
Adapter As.-Base (9.07 Metric Ton)
1kg (2lb)
(2.5 x 2.2in)
45 x 51 mm
465-4080
Adapter As.-Base (4.54 Metric Ton)
0.4 kg (1 lb)
(1.8 x 2 in)
99 x 73 mm
465-4081
Adapter As.-Base (22.68 Metric Ton)
2.4 kg (5.3 lb)
(3.9 x 2.9in)
27 x 127 mm
465-4082
Tube-Extension (4.54 Metric Ton)
0.3 kg (1 lb)
(1.1 x 5 in)
25.4 x 19 mm
465-4083
Tool-Saddle (4.54 Metric Ton)
0.04 kg (0.1 lb)
(1 x 0.7 in)
42 x 54 mm
465-4084
Adapter-Saddle (9.07 Metric Ton)
0.4 kg (1 lb)
(1.7 x 2.1in)
27 x 40 mm
465-4085
Adapter-Threaded (4.54Metric Ton)
0.14 kg (0.3 lb)
(1.1 x 1.6in)
60 x 254 mm
465-4086
Tube-Extension (22.68 Metric Ton)
4 kg ( 9 lb)
( 2.4 x 10 in)
61 x 457 mm
465-4087
Tube-Extension (22.68 Metric Ton)
6 kg (13.2 lb)
(2.4 x 18 in)
42 x 127 mm
465-4088
Tube-Extension (9.07 Metric Ton)
1kg (2lb)
(1.7 x 5 in)
42 x 457 mm
465-4089
Tube-Extension (9.07 Metric Ton)
2 kg (4.4 lb)
(1.7 x 18 in)
42 x 762 mm
465-4090
Tube-Extension (9.07 Metric Ton)
3.2 kg (7 lb)
(1.7 x 30 in)
27 x 457 mm
465-4091
Tube-Extension (4.54 Metric Ton)
1kg (2lb)
(1.1 x 18 in)
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-29
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Double Acting Hydraulic Cylinders
Warranty: Caterpillar ®Six Months
• Designed with an external relief valve for the
• When there is too much pressure a small
rod end of the cylinder
amount of oil is released through the relief
valve
• Valve prevents an increase in pressure at the
rod end if there is a restriction of the return oil
• 6V-3170 includes piston
to the pump
• 6V-3175 includes 6V-3173 Piston
• Relief valve setting is 72,394 kPa (10,500 PSI)
Part Number
6V-3170
6V-3160
6V-3175
Overall length
88.9mm (3.5in)
12.7 cm (5.0 in)
13.18 cm (5.19in)
Cylinder diameter
13.81 cm (5.44in)
10.16 cm (4.0in)
13.81 cm (5.44in)
Stroke
12.7mm (0.5in)
50.8mm (2.0in)
50.8mm (2.0in)
Weight
9.52 kg (21 lb)
6.80 kg (15 lb)
6.80 kg (15 lb)
Capacity
50 t (55 tons)
28 t (31 tons)
50 t (55 tons)
Hole diameter
33.27 mm (1.31 in)
29.46 mm (1.16 in)
33.27 mm (1.31 in)
Maximum operating
68,950 kPa (10,000 PSI)
68,950 kPa (10,000 PSI)
68,950 kPa (10,000 PSI)
pressure
Decal
NEEG2113
NEEG2112
NEEG2113
Repair Kit
6V-3168
6V-3159
6V-3168
Part Number
Description
6V-3160
Cylinder Group
6V-3170
55tonCylinder
6V-3175
Hydraulic Cylinder
6V-3160 Service/Repair Parts a
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
6V-3159
Repair Kit
9L-2336
Ring
6V-3170 Service/Repair Parts a
191-6624
Valve, Relief
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
6V-3168
Repair Kit
6V-3172
Head
6V-3175 Service/Repair Parts a
191-6624
Valve, Relief
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
6V-3168
Repair Kit
6V-3172
Head
6V-3173
Piston
a. Includes: NEEG2112 Decal
10-30 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Service Cylinder Attachments
Model Usage: All
• Cylinder attachments for 5- thru 25-ton
• Allows more options using standard cylinders
cylinders
for various job applications
Warranty: Manufacturer’s
Part No.
Description
Diameter
Weight
465-4079
Adapter Assembly -Base (9.07 metric ton)
64 x 57 mm (2.5 x 2.2 in)
1kg (2lb)
465-4080
Adapter Assembly-Base (4.54 metric ton)
45 x 51 mm (2 x 2 in)
0.4 kg (1 lb)
465-4079
465-4081
AdapterAssembly-Base (22.68metric ton)
99 x 73 mm (4 x 3 in)
2.4 kg (5.3 lb)
465-4082
Tube-Extension (4.54 metric ton)
27 x 127 mm (1 x 5 in)
0.3 kg (1 lb)
465-4083
Tool-Saddle (4.54 metric ton)
5.4 x 19 mm (1 x 1 in)
0.04 kg (0.1 lb)
465-4084
Adapter-Saddle (9.07 metric ton)
42 x 54 mm (2 x 2 in)
0.4 kg (1 lb)
465-4085
Adapter-Threaded (4.54 metric ton)
27 x 40 mm (1 x 2 in)
0.14 kg (0.3 lb)
465-4086
Tube-Extension (22.68 metric ton)
60 x 254 mm (2.4 x 10 in)
4 kg ( 9 lb)
465-4087
Tube-Extension (22.68 metric ton)
61 x 457 mm (2.4 x 18 in)
6 kg (13.2 lb)
465-4080
465-4088
Tube-Extension (9.07 metric ton)
42 x 127 mm (2 x 5 in)
1kg (2lb)
465-4089
Tube-Extension (9.07 metric ton)
42 x 457 mm (2 x 18 in)
2 kg (4.4 lb)
465-4090
Tube-Extension (9.07 metric ton)
42 x 762 mm (2 x 30 in)
3.2 kg (7 lb)
465-4091
Tube-Extension (4.54 metric ton)
27 x 457 mm (1 x 18 in)
1kg (2lb)
465-4081
465-4085
465-4089
465-4086
465-4082
465-4090
465-4083
465-4087
465-4091
465-4088
465-4084
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-31
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Hydraulic Coupler Bleed Tool Group
Warranty: Manufacturer's
• Used on hydraulic cylinders utilized on service
• Fluid will drain into a suitable container (not
tools
provided)
• Allows the technician to relieve trapped
• Aluminum
hydraulic pressure in couplings designed
Specifications
for 10,000 psi (700 bar) or less with 1-3/16”
threads
Dimensions 204 X 102 X 21 mm (8 X 4 X 2 in)
• Couplers can be either male or female and
Weight 1.2 kg (2.5 lb)
have either ball or cone check designs
• Following attachment, the cap bolt assembly
is turned slowly until contact with check (ball
or cone) which then opens and hydraulic
pressure is relieved
Part Number
Description
466-5302
Hydraulic Coupler Bleed Tool Group
Relief Valve
Warranty: Caterpillar ®Six Months
• Used on cylinders without a relief valve
• Prevents an increase in pressure caused by a
restriction (blockage) of the return oil to the
• Can be added to the rod end of any center
pump
hole 2-way (double-acting) cylinder, which is
rated for 68,950 kPa (10,000 PSI) operation
• Beyond the relief valve setting of 10,500 PSI,
the operator will see small amounts of oil
• Gives extra protection to the service tool
released through the valve
Part Number
Description
6V-3176
ValveAssembly
Replacement Parts
191-6624
Valve, Relief
Inline Hydraulic Components
Warranty: Manufacturer’s
Valve Assembly
Adapter
• Torque to 115-128 Nm (85-95 ft.lb)
• Max. operating pressure 700 bar (10,000 psi)
• Use loctite no. 242
• Connection 1-3/8 inch nptf male, connection
2 - cr-400 coupler
515-8204
• Set safety relief valve to 793-862 bar (11,500-
12,500 psi)
• 45 degree angled gauge improves visibility.
• Maximize controlled load movement
Gauge
• 1/4 inch npt, max. operating pressure
• Glycerin-dampened gauge with dual scale
700 bar (10,000 psi)
• High-flow female coupler
515-8205
Part No.
Description
Dimensions
Weight
515-8204
Valve Assembly (Control Check)
115 x 97 mm (4.5 x 4 in)
1.6 kg (3.5 lb)
515-8205
Gauge
84 x 36 mm (3.3 x 1.4 in)
1.4 kg (3 lb)
515-8206
515-8206
Adapter Assembly (45 Degree Angled Gauge)
154 x 111 x 62 mm (6 x 4.3 x 2.4 in)
1.4 kg (3 lb)
10-32 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Hydraulic Cylinder, Single Acting
Warranty: Caterpillar ®Six Months
• Primary use for this hydraulic cylinder is with
Specifications
the 5P-8639 Press Group
• Overall length: 40.33 cm (15.88 in)
• Rod is extended by hydraulic pressure and
• Cylinder diameter: 57.15 mm (2.25 in)
returned by spring pressure
• Stroke: 25.70 cm (10.12 in)
• Weight: 6.35 kg (14 lb)
• Capacity: 10 tons
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
• Threaded cylinder: 2 1/4 in-14 thd
• Includes: SEES5625 Decal
Part Number
Description
5P-9725
Cylinder Group
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
5P-9724
Repair Kit
Single Acting Hydraulic Cylinder
Warranty: Manufacturer’s Limited Lifetime
• Has center hole large enough for 25.4 mm
Specifications
(1 in) puller stud
• Overall length: 16.20 cm (6.38 in)
• Piston is extended by hydraulic pressure and
• Cylinder diameter: 98.55 cm (3.88 in)
retracted by spring pressure
• Stroke: 50.8 mm (2 in)
• Weight: 7.71 kg (17 lb)
• Capacity: 20 tons
• Center hole diameter: 26.92 mm (1.06 in)
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
Part Number
Description
316-1496
Cylinder
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
316-1507
Repair Kit
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-33
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Hydraulic Puller Group
Warranty: Caterpillar ®Six Months
• Lightweight and compact
Specifications
• Can be used to pull or push bearings, gears,
• Stroke: 50.8 mm (2.0 in)
shafts, or other press-fitted parts
• Usable reach: 11 5/8 in
• Has a 17.5 ton capacity and generally can be
• Capacity: 17.5 tons
used in place of the 8B-7548 Bearing Puller
• Threaded insert: 1 in-8
Assembly
• Maximum operating pressure: 68,950 kPa
• Uses accessories found in 8B-7548
(10,000 PSI)
Item
Description
1
Adjusting Crank
Service/Repair Parts
SEES5617
Decal Pressure
NEEG2101
Decal
Item
Part Number
Description
—
1P-0820
Puller Group— Hyd
1P-0820 Consists of:
2
9S-6074
Adjusting Screw
3
9S-7338
Cross Block Group b
4 a
1P-2329
Threaded Insert
4 a
1P-7361
Plain Insert (not part of 1P-0820)
a. Can use either 1P-2329 or 1P-7361
b. Includes plate
Hydraulic Puller
Warranty: Manufacturer’s Limited Lifetime
• Especially useful for pulling pins that have up
Specifications
to a 19.56 mm (0.77 in) center tapped hole
• Overall length: 7.25 in
• Provides 12 tons pulling force
• Cylinder diameter: 2.75 in
• Puller ram is extended by hydraulic pressure
• Stroke: 3.00 in
and returned by spring pressure
• Weight : 9.8 lb
• Capacity: 12 tons
• Center hole diameter: 0.77 in
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
• Includes: NEEG2106: Decal
Part Number
Description
316-1493
Hydraulic Puller Group
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
316-1504
Seal Kit
10-34 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Cylinder Group
Warranty: Manufacturer’s Limited Lifetime
• Single-acting, spring-return 30 Ton cylinder
Specifications
• Center hole design allows screws, cables, etc.
• Capacity: 30 ton
to go straight through ram
• Center hole diameter: 33.27 mm (1.31 in)
• Long stroke design
• Retracted height: 33.02 cm (13 in)
• Extended height: 48.59 cm (19.13 in)
• Collar thread: 4 1/2-12
Part Number
Description
316-1494
Cylinder Group
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
316-1505
Seal Repair Kit
Single Acting Hydraulic Cylinder
Warranty: Manufacturer’s Limited Lifetime
• Center hole design
Specifications
• Piston is extended by hydraulic pressure and
• Overall length: 17.85 cm (7.03 in)
retracted by spring pressure
• Cylinder diameter: 11.43 cm (4.5 in)
• Stroke: 63.5 mm (2.5 in)
• Weight: 10.88 kg (24 lb)
• Capacity: 30 ton
• Maximum operating pressure: 68,950 kPa
(10,000 PSI)
Part Number
Description
316-1495
Single Acting Hydraulic Cylinder
Service/Repair Parts
1P-2375
Coupler Assembly Quick Connective (Male)
1P-7437
Protective Cap
316-1505
Seal Repair Kit
Hydraulic Multi-stage Cylinder
Model Usage: AD55B & AD45B
European Union Compliant, CE marked
Specifications
Warranty: Manufacturer’s Limited Lifetime
• Low profile, high lift jack used to raise low
• Outside Diameter: 368.3 mm (14.50 in)
profile machines
• Weight: 204 kg (450 lb)
• Double acting cylinder used to reduce cycle
• Lifting Capacity: 75 ton
time and improve efficiency
Collapsed Height: 254.1 mm (10 in)
•
• Allows for smaller collapsed weight and
• Stroke: 368.3 mm (12.85 in)
greater stroke
• Spacers: 25, 50, 75 mm (.98, 1.97, 2.95 in):
• Pilot operated check valve maintains pressure
Qty. 3
if hoses are disconnected
• Hoses: 6 m (20 ft) quick disconnects attached:
Qty. 2
Part Number
Description
417-9063
Hydraulic Multi-stage Cylinder
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-35
Hydraulic/Mechanical Pullers/Drivers
SINGLE AND DOUBLE ACTING PULLER CYLINDERS
Hydraulic Pump
Model Usage: AD55B & AD45B
• Two speed operation and high by-pass
Specifications
pressure reduces cycle time for improved
Warranty: Manufacturer’s Limited Lifetime
• Dimensions: 446 x 467 x 330 mm
productivity
(17.55 x 18.4 x 13.0 in)
• Used with 20,000 PSI double acting cylinders
• Motor: 60-100 PSI Dynamic Air Pressure
• ATEX Certified (Ex II 2 GD ck T4)
20-100 scfm Air Consumption
94-97 dBA Sound Level
• Display: None
• Valve: Manual 4 way - 3 pos
• Flow Rate: 850 in 3/min @ 100 PSI
80 in 3/min @ 10,000 PSI
• Reservoir Capacity: 20 L (5 gal)
• Max Operating Pressure: 10,000 PSI (700 bar)
Part Number
Description
417-9064
Hydraulic Pump
10-36 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
All pumps are equipped with an adjustable external relief valve.
Electric Hydraulic Pumps Specifications
Oil Delivery
Reservoir
Maximum
Control
Part No.
Voltage
Hz
Motor HP
(cu in/min)
Electronic Control
For Use With
Capacity
Pressure
Valve
10,000 psi
7.57 L
68,947 kPa
Toggle Switch run/off/jog and
Double Acting
350-7768
115
50-60
1.7
55
Manual
(2.0 gal)
(10,000 PSI)
Remote Switch on 6 ft Cord
Cylinders
7.57 L
68,947 kPa
Toggle Switch run/off/jog and
Double Acting
350-7769
220
50-60
1.7
55
Manual
(2.0 gal)
(10,000 PSI)
Remote Switch on 6 ft Cord
Cylinders
2.0 gal
68,947 kPa
Advance/
Double Acting
439-5247
115
50-60
1.0
40
4-way/ 3-position footswitch
(7.6 L)
(10,000 PSI)
Return
Cylinders
2.0 gal
68,947 kPa
Advance/
Double Acting
439-5248
220
50-60
1.0
40
4-way/ 3-position footswitch
(7.6 L)
(10,000 PSI)
Return
Cylinders
68,947 kPa
Double Acting
439-5249
115
50-60
1.0 gal (3.8 L)
0.73
20
Manual
4 -way/3-position valve
(10,000 PSI)
Cylinders
68,947 kPa
Double Acting
439-5250
220
50-60
1.0 gal (3.8 L)
0.73
20
Manual
4 -way/3-position valve
(10,000 PSI)
Cylinders
68,947 kPa
Single Acting
450-9134
115
50-60
0.5 gal (2L)
0.5
15
Manual
3-way/ 2-position
(10,000 PSI)
Cylinders
68,947 kPa
Single Acting
451-8702
115
50-60
1.0 gal (3.8 L)
0.73
20
Manual
3-Way/ 2-Position
(10,000 PSI)
Cylinders
68,947 kPa
Single Acting
452-1079
220
50-60
1.0 gal (3.8 L)
0.73
20
Manual
3-Way/ 2-Position
(10,000 PSI)
Cylinders
68,947 kPa
Single Acting
461-4388
220
50-60
0.5 gal (2L)
0.5
15
Manual
3-way/ 2-position
(10,000 PSI)
Cylinders
Air Hydraulic Pumps Specifications
Max Operating
Usable Oil
Dynamic Air
Flow Rate
Part No.
Air Consumption
Pressure
Capacity
Pressure
700 psi
10,000 psi
Control Valve
For Use With
689 bar
4.13 - 6.89 bar
0.57 - 2.83m3/min
11,061 cm3/min
1,311 cm3/min
Manual
439-5242
6.62 L (1.75 gal)
D/A Cylinders
(10,000 psi)
(60 - 100 psi)
(20 - 100 scfm)
(675 in3/min)
(80 in3/min)
(ADV/HOLD/RET)
689 bar
2.75 - 8.62 bar
0.34 m3/min
983 cm3/min
164 cm3/min
Manual
439-5243
2.08 L (0.55 gal)
S/A Cylinders
(10,000 psi)
(40 - 125 psi)
(12 scfm)
(60 in3/min)
(10 in3/min)
(ADV/HOLD/RET)
689 bar
4.13 - 6.89 bar
0.57 - 2.83m3/min
8,193 cm3/min
983 cm3/min
Pendant-Controlled
Hydraulic Torque
451-7991
6.62L (1.75 gal)
(10,000 psi)
(60-100 psi)
(20 - 100 scfm)
(500 in 3/min)
(60in 3/min)
Torque Wrench Valve
Wrenches
689 bar
2.75 - 8.62 bar
0.34 m3/min
836 cm3/min
98 cm3/min
Pendant
451-7995
2.08 L (0.55 gal)
S/A Cylinders
(10,000 psi)
(40 - 125 psi)
(12 scfm)
(51 in3/min)
(6 in3/min)
(ADV/HOLD/RET)
207 bar
2.75 - 8.62 bar
0.34 m3/min
983 cm3/min
164 cm3/min
Manual
455-6557
2.08 L (0.55 gal)
D/A Cylinders
(3,000 psi)
(40 - 125 psi)
(12 scfm)
(60 in3/min)
(10 in3/min)
(ADV/HOLD/RET)
Manual Hydraulic Pumps Specifications
Part No.
Reservoir Capacity
Maximum Operating Pressure
Volume Per Stroke
Control Value
For UseWith:
1 in3 (16.4 cm3) @ 500 psi,
Single Acting
439-5245
0.58 gal (2.2L)
689 bar (10,000 psi)
-
0.15 in3 (2.46 cm3) @ 10,000 psi
Cylinders
1.00 in3 (16.4 cm3) @ 500 psi,
Single Acting
439-5246
0.2 gal (0.77L)
689 bar (10,000 psi)
-
0.15 in3 (2.46 cm3) @ 10,000 psi
Cylinders
0.91 in3 (14.91 cm3) @ 200 psi,
Single Acting
451-7994
0.3 gal (1.15L)
689 bar (10,000 psi)
-
0.19 in3 (3.11 cm3) @ 10,000 psi
Cylinders
1st Stage, 1379 kPa (200 PSI) -
3-Position -
Double Acting
9U-6600
7.57 kg (2.0 gal)
119.46 cc (7.29 cu in) - 4.75 cc (0.290 cu in)
2nd Stage, 68,950 kPa (10,000 PSI)
4-Manual
Cylinders
NOTE: Hoses sold separately
10-37
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-37
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Electric Hydraulic Pump Group
Model Usage: All
European Union Compliant, CE marked
• High strength, molded composite shroud
protects motor and electronics, while
Warranty: Manufacturer's Limited Lifetime
• Features high-efficiency pump design with
providing an ergonomic non-conductive
higher oil flow and bypass pressure and
handle
1.7 HP universal electric motor with high
power-to-weight ratio and low voltage
• Shares common components with the newly
operation
released hydraulic tensioner pumps for ease
of repair and maintenance
• Low voltage pendant provides additional
safety for the operator
Part No.
350-7768
350-7769
208-240 VAC, Single Phase,
Motor
115 VAC, Single Phase, 50/60 Hz
50/60 Hz
Display
No Gauge or LCD
Power
1.26 kW (1.7 HP)
Flow Rate
700 in³/min @ 100 PSI and 60 in³/min @ 10,000 PSI
Reservoir Capacity
8 L (2 gal)
Valve
4 way/ 3 position manual
Maximum Operating Pressure
10,000 PSI (700 bar)
Dimensions
483 x 266 x 520 mm (19.0 x 10.5 x 17.0 in)
Comes with skid bar, no oil
Service Parts
Breather Plug
346-6159
Brush Replacement Kit
346-6160
External Relief Valve
346-6161
Valve Repair Kit
346-6162
Pendant
346-6163
Skid Plate
346-6164
Accessories
Roll Cage
346-6163
Pressure Gauge
186-2613
Hose - 11 ft - no couplers
6D-7726
Coupler Assembly & Plug
1P-2376 & 1P-2377
Attachments
• Higher capacity motors in the 350-7768 and
• Remote switch permits operator to move
• Several additional items are required to
350-7769 Pumps provide faster ram operation
to the most advantageous position when
attach these pumps to a hydraulic cylinder or
applying pressure to the tool setup
puller.
• Motor operation can be controlled from a
switch mounted on pump body or by remote
switch attached to a 1.83 m (6 ft) cord.
Part No.
Description
Quantity
Size
8T-0820
Standard Pressure Gauge (Can use either 8T-5343 or 8T-0820 gauge)
1
-
8T-5343
Pressure Gauge
-
-
135-2532
Bushing
2
-
Street Elbow
135-2533
(This fitting may be eliminated. It is used to make both hoses come out in the same direction from the
1
-
valve on top of the pump assembly. This provides a neaterappearance and more usable hoselength.)
1P-2376
Coupler Assembly Quick Connective (Female) (2)
2
-
1P-2377
Plug As - Dust
2
6D-7726
Hydraulic Hose
2
351 cm (138in)
8F-0024
Hose Assembly
2
183 cm (72 in)
1U-9903
Valve Repair Kit
-
-
2P-2287
Valve Kit
-
-
10-38 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Electric Hydraulic Pump
Model Usage: For General Purpose Hydraulic
• Quiet, fully enclosed motor for indoor and
• 4-way/3-position valve for use with double-
Cylinders
outdoor use
acting tools operated via foot control
Warranty: Manufacturer’s Limited Lifetime
• Heavy duty, IP54 rating delivers performance
• Ships with no oil
with superior dust and water protection.
Part No.
439-5247*
439-5248**
Motor
115V, Single-Phase 50/60 Hz
230V, Single-Phase 50/60 Hz
Display
No Gage
Power
1.0 hp (0.74 kW)
Flow Rate
450 in3/min @ 100 psi, 40 in3/min @ 10,000 psi
Usable Oil Capacity
2.0 gal (7.6 L)
Valve
4-way/3-position footswitch
Max Operating Pressure
10,000 psi (689 bar)
Dimensions
241.3 x 513.9 x 512.3 mm (9.5 x 20.2 x 20.2 in)
Weight
66 kg (145 lb)
Service Repair Items
Footswitch Kit
455-6556
Pendant Kit
346-6165
Repair Kit
447-0917
Seal Kit
447-2218
Breather Plug
346-6159
Accessories
346-6164
Skid Plate Assembly
*Replaces 1U-5555 **Replaces 1U-5565 and 171-5397
Electric Hydraulic Pump - 10,000 psi
Model Usage: For General Purpose Hydraulic
CE Compliant
Specifications
Cylinders
• 4 -way/3-position valve for double-acting
• Power: 0.73 hp (0.54 kW)
Warranty: Manufacturer’s Limited Lifetime
tools, controlledmanually
• Flow Rate: 200 in3/min@ 250 psi,
• Motor-controlled via pendant
20 in3/min @ 10,000 psi
• Large easy-carry handle for max. portability
• Usable Oil Capacity: 1.0 gal (3.8 L), ships with
no oil
• Hydraulic power supply should be used
with 10,000 psi (700 bar) gauges, couplers,
• Max Operating Pressure: 10,000 psi (689 bar)
adapters, and hoses.
• Dimensions: 309.4 x 368.3 x 371.6 mm (12.2 x
• No gauge or LCD
14.5 x 14.6 in)
• Weight: 14.5 kg (32 lbs)
Part No.
Description
439-5249*
Pump Assembly, 115 V Single Phase 50/60 Hz
439-5250**
Pump Assembly, 220 V Single Phase 50/60 Hz
Service Parts
459-2622
Pump Repair Kit
459-2623
Motor Brush Kit for 115 V
459-2624
Motor Brush Kit for 220 V
459-2625
Shroud Assembly for 115 V
459-2626
Shroud Assembly for 220 V
459-2627
Pendant Kit
*Replaces 2P-5550 **Replaces 2P-5500
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-39
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Electric Hydraulic Pump
Model Usage: For General Purpose Hydraulic
• Durable, lightweight pump delivers powerful
• 3-way/2-position valve for single-acting tools,
Cylinders
performance in a basic package.
controlled manually
Warranty: Manufacturer’s Limited Lifetime
• Small motor performs, even with poor quality
• Large easy-carry handle for maximum
power.
portability
• Motor controlledvia pendant
• Ships with no oil
Part No.
451-8702
452-1079
Motor
115V, Single-Phase 50/60 Hz
220V, Single-Phase 50/60 Hz
Display
No Gage or LCD
Power
0.73 hp (0.54 kW)
Flow Rate
200 in3/min @ 250 psi, 20 in3/min @ 10,000 psi
Usable Oil Capacity
1.0 gal (3.8 L)
Valve
3-Way/2-Position Manual
Max Operating Pressure
10,000 psi (689 bar)
Dimensions
309.4 x 368.3 x 373.9 mm (12.2 x 14.5 x 14.7 in)
Weight
14 kg (30 lb)
Service Repair Items
Shroud Assembly
459-2625
459-2626
MotorBrushKit
459-2623
459-2624
Pump Repair Kit
459-2628
Pendant Kit
459-2629
10-40 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Cordless Electric Hydraulic Pump
Model Usage: For General Purpose Hydraulic
European Union Compliant, CE marked
• Perfect for use in the field or hard-to-reach
Cylinders
jobs: no power chords or tripping hazards
• Delivers the power and speed of an electric
Warranty: Manufacturer’s Limited Lifetime
pump, with the portability of a hand pump
• Composite shroud includes carrying handle
and shoulder strap for the ultimate in
• Powered by a 28V Li-ion battery providing
portability
steady, reliable power (two batteries and one
charger included)
•
Part No.
450-9134
461-4388
533-1186
533-1185
28V Permanent
28 V Permanent
28V Permanent
28 V Permanent
Motor
Magnet DC
Magnet DC
Magnet DC
Magnet DC
Charger (included)
115V
220V
115V
220V
For Use With
Single-Acting Cylinders
Double-Acting Cylinders
Display
No Gage or LCD
Power
0.5 hp (0.375 kW)
Battery
28 VDC Li-lon
Flow Rate
125 in3/min @ 250 psi
15 in3/min @ 10,000 psi
4-way/3-position footswitch
Usable Oil Capacity
0.5 gal (2L) Bladder
Valve
3-way/2-position -Manual
ValveType
Advance/Return
Max Operating Pressure
10,000 psi (689 bar)
Dimensions
208.7 x 421.6 x 294.7 mm (8.2 x 16.6 x 11.6 in)
Weight
11 kg (24 lb)
Service Repair Items
115V Charger for 28V
461-4390
230V Charger for 28V
461-4391
PumpAssembly (no battery incl)
453-7292 Single-Acting
533-1178 Double-Acting
28V Battery Pack
461-4389
Seal Kit
455-6551
MotorBrushKit
455-6552
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-41
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Air Hydraulic Pumps
Model Usage: For General Purpose Hydraulic
European Union Compliant, CE marked
• The different valve interfaces allow the
Cylinders
operators several options to actuate the
• This line of pumps offer versatility and
pump; be it manual, foot, or pendant.
Warranty: Manufacturer’s
portability wherever air-powered tools are
preferred.
• 439-5243 and 451-7995 have an accessory
available that allows for a 3.75L (1 gal)
• High capacity, high flow for larger cylinders
capacity.
to smaller capacity, high flow for smaller
439-5242
cylinders
Part No.
439-5242
439-5243
451-7995
455-6557*
Max Operating
689 bar (10,000 psi)
689 bar (10,000 psi)
689 bar (10,000 psi)
207 bar (3,000 psi)
Pressure
Usable Oil Capacity
6.62 L (1.75 gal)
2.08 L (0.55 gal)
2.08 L (0.55 gal)
2.08 L (0.55 gal)
Flow Rate @ 48 bar
11,061 cm3/min
983 cm3/min
836 cm3/min
983 cm3/min
(700 psi)
(675 in3/min)
(60 in3/min)
(51 in3/min)
(60 in3/min)
Flow Rate @ 689 bar
1,311 cm3/min
164 cm3/min
98 cm3/min
164 cm3/min
(10,000 psi)
(80 in3/min)
(10 in3/min)
(6 in3/min)
(10 in3/min)
439-5243
Dynamic Air
4.13 - 6.89 bar
2.75 - 8.62 bar
2.75 - 8.62 bar
2.75 - 8.62 bar
Pressure
(60 - 100 psi)
(40 - 125 psi)
(40 - 125 psi)
(40 - 125 psi)
0.57 - 2.83m3/min
0.34 m3/min
0.34 m3/min
0.34 m3/min
Air Consumption
(20 - 100 scfm)
(12 scfm)
(12 scfm)
(12 scfm)
Manual
Manual / Foot
Pendant
Manual
Control Valve
(ADV/HOLD/RET)
(ADV/HOLD/RET)
(ADV/HOLD/RET)
(ADV/HOLD/RET)
Used With
D/A Cylinders
S/A Cylinders
S/A Cylinders
D/A Cylinders
Dimensions
414 x 267 x 381 mm
350 x 165 x 216 mm
318 x 165 x 203 mm
324 x 165 x 267 mm
(L x W x H)
(16.3 x 10.5 x 15 in)
(13.75 x 6.5 x 8.5 in)
(12.5 x 6.5 x 8 in)
(12.75 x 6.5 x 10.5in)
Weight with Oil
35 kg (77 lb)
8.17 kg (18 lb)
10 kg (22 lb)
10.9 kg (24 lb)
Service Repair Items
Part No.
Description
439-5242
439-5243
451-7995
455-6557*
447-0917
Pump Seal Kit
X
451-7995
455-6558
Air Motor Replacement
X
455-6562
Pump Repair Kit
X
X
455-6563
Pump Repair Kit
X
455-6564
Air Motor Replacement
X
X
X
455-6557
455-6565
Air Hose Replacement
X
455-6566
Air Pendant Kit
X
Accessories
455-6567
3.75L Reservoir Kit, Black (Only for 439-5243, 451-7995)
6D-7726
Hose- 689bar -3.6 m(12 ft)WithoutCouplers
1P-2376
QuickDisconnect- Female
1P-2375
Quick Disconnect - Male
*Replaces 9U-5774
10-42 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Manual Hydraulic Pump
Model Usage: For General Purpose Hydraulic
• Reduced handle effort and ergonomic grip for
• Quick-grip handle allows for easy
Cylinders
less operator fatigue
transportation.
Warranty: Manufacturer’s Limited Lifetime
• Vent-free reservoir eliminates spills.
• Durable, all-steel construction and chrome-
plated plunger for superior durability
• Ships with no oil
Part No.
439-5245
Oil Displacement per Stroke
1 in3 (16.4 cm3) @ 500 psi, 0.15 in3 (2.46 cm3) @ 10,000 psi
Max Operating Pressure
10,000 psi (689 bar)
Usable Oil Capacity
0.58 gal (2.2L)
Max Handle Effort
28.7 kg (77 lb)
Dimensions
597.2 x 150 x 194.4 mm (23.5 x 5.9 x 7.65in)
Weight
8.8 kg (23.6 lb)
Manual Hydraulic Pump
Model Usage: For General Purpose Hydraulic
• Ergonomic grip and reduced handle effort for
• Quick-grip handle allows for easy
Cylinders
less operator fatigue
transportation.
Warranty: Manufacturer’s Limited Lifetime
• Vent-free reservoir eliminates spills.
• Durable, all-steel construction and chrome-
plated plunger for superior durability
• Ships with no oil
Part No.
439-5246
Oil Displacement per Stroke
1.00 in3 (16.4 cm3) @ 500 psi, 0.15 in3 (2.46 cm3) @ 10,000 psi
Max Operating Pressure
10,000 psi (689 bar)
Usable Oil Capacity
0.2 gal (0.77L)
Max Handle Effort
40 kg (88 lb)
Dimensions
549.4 x 140 x 162.5 mm (21.63 x 5.51 x 6.40 in)
Weight
7.1 kg (15.6 lb)
Service Repair Items
Pump Seals Kit
455-6568
Two-Stage Plunger Kit
455-6569
Release Valve Kit
455-6570
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-43
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Manual Hydraulic Pump
Model Usage: For General Purpose Hydraulic
• All-aluminum construction makes these
• Fine-pitched threads on release valve allow
Cylinders
pumps ideal for portability, high heat or
for precise load lowering.
welding applications.
Warranty: Manufacturer’s Limited Lifetime
• Ships with no oil
• Integrated spring latch provides quick
carrying mobility.
Part No.
451-7994
Oil Displacement per Stroke
0.91 in3 (14.91 cm3) @ 200 psi, 0.19 in3 (3.11 cm3) @ 10,000 psi
Max Operating Pressure
10,000 psi (689 bar)
Usable Oil Capacity
0.3 gal (1.15L)
Dimensions
606.4 x 140 x 131.1 mm (28.87 x 5.51 x 5.16 in)
Weight
5 kg (11 lb)
Hand Pump Group
Warranty: Caterpillar ®Six Months
• Replaced discontinued 4C-4865 Hydraulic
Specifications
Hand Pump
• Reservoir (tank) capacity: 7.9 L (2.1 gal)
• Portable power source for Hydraulic Service
• Usablecapacity: 7.6 L (2.0 gal)
Tools
Fluid: SAE 10 non-detergent petroleum oil
•
• Square reservoir configuration and slightly
• Weight (with oil): 26 kg (58 lb)
larger pumping capacity
• Valve port size: 3/8 in NPT
• Pump repair parts are explained in the Special
Instruction Form SEHS9061 which is supplied
• Approximate size: 308 x 321 x 766 mm
with each unit
(12.12 x 12.64 x 30.16 in)
Specifications
Volume Per Stroke
Pressure
FirstPressure Level
119 cc (7.29 cu in)
1380, ± 345 kPa (200, ± 50 PSI)
Second Pressure Level
4.75 cc (0.290 cu in)
69,000, ± 3,450 kPa (10,000, ± 500 PSI)
Part Number
Description
9U-6600
HandPump Group (Hoses sold separately)
Service/Repair Parts
4C-4866
Service Kit
9U-6588
PumpHousing
9U-6589
Pump Link
9U-6590
O-ring Seal
9U-6591
Pivot Disc
9U-6592
Piston
9U-6593
Plunger
9U-6596
Filter
9U-6602
Filter
9U-6603
Tube Assembly
9U-6604
Tube Assembly
9U-6606
Four-way Valve
9U-6607
Service Kit
Service Repair Items
Pump Seals Kit
455-6571
Release Knob
455-6572
Release Knob Screw
455-6573
Service Repair Items
Pump Seals Kit
455-6574
Two-Stage Plunger Kit
455-6569
Release Valve Kit
455-6570
10-44 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Hydraulic Shop Presses
Warranty: Caterpillar ®Lifetime
A
B
G
E
Optional
Part No.
OTC No.
Force
Weight
Max. Working
Pump
Hydraulic
Height
Outside Width
InsideWidth
Height
Group
179.71 cm
120.65 cm
88.9 cm
104.46 cm
1U-7459
1850
55 ton
317.1 kg (699lb)
Manual
1U-7466
(70 3/4in)
(47 1/2in)
(35in)
(41 1/8in)
179.71 cm
120.65 cm
88.9 cm
104.46 cm
1U-7461
1851
55 ton
313.9 kg (692lb)
Air
1U-7466
(70 3/4in)
(47 1/2in)
35 in)
(41 1/8in)
182.88 cm
123.19 cm
91.44 cm
83.19 cm
1U-7463
1845
55 ton
420 kg (926lb)
Electric
1U-7466
(72in)
(48 1/2in)
(36in)
(32 3/4in)
182.88 cm
123.19 cm
91.44 cm
83.19 cm
1U-7464
1846
55 ton
417.3 kg (920lb)
Manual
1U-7466
(72in)
(48 1/2in)
(36in)
(32 3/4in)
182.88 cm
123.19 cm
91.44 cm
83.19 cm
1U-7465
1847
55 ton
415.9 kg (917lb)
Air
1U-7466
(72in)
(48 1/2in)
(36in)
(32 3/4in)
220.03 cm
120.65 cm
88.90 cm
115.57 cm
1U-7468
1854
100 ton
534.8 kg (1,179lb)
Electric
-
(86 5/8in)
(47 1/2in)
(35in)
(45 1/2in)
196.22 cm
162.56 cm
127.00 cm
106.68 cm
1U-7471
1858
100 ton
746.2 kg (1,645lb)
Electric
-
(77 1/4in)
(64in)
(50in)
(42in)
313.06 cm
160.66 cm
130.18 cm
162.56 cm
4C-5639
1867
200 ton
2,020.8 kg (4,455 lb)
Electric
-
(1231/4in)
(63 1/4in)
(51 1/4in)
(64in)
Arbor Press (10 Ton)
Model Usage: General Shop Use
• Used with 10-ton single-acting hydraulic
• Holes for horizontal or vertical mounting
cylinder and any single-acting hydraulic pump
Warranty: Manufacturer’s
• Back is slotted for loading of longer parts.
(sold separately)
Part No.
Description
Throat Depth
Dimensions (L x W x H)
Weight
291 x 151 x 426 mm
27 kg
526-5512
Arbor Press (10 Ton)
150 mm from center of cylinder
(11.5 x 6 x 16.8 in)
(78 lb)
Economy Shop Presses, 55 Ton
Warranty: Caterpillar ®Six Months
• Durable steel frame resists buckling or
1U-7461
bending and hand operated winch and cable
• Same as 1U-7459 except with 1U-7545 Air/
mechanism adjusts lower press bolster
Hydraulic Pump (1U-7545 requires 9 cfm at
689.5 kPa [100 PSI] at the pump)
Part Number
Description
Weight
1U-7459
EconomyShopPresses,55 Ton
317.06 kg (699lb)
1U-7461
EconomyShopPresses,55 Ton
313.89 kg (692lb)
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-45
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Heavy-Duty Shop Presses, 55 Ton
Warranty: Caterpillar ®Six Months
• Larger versions of the 25 ton presses
1U-7463
• Side to side positioning of ram allows full
• Includes electric/hydraulic pump, 1U-7547
capacity pressing along entire bolster length
Hose Gauge (9.53 mm ID x 2.44 m [ 3/8 in ID
without buckling or bending
x 8 ft]), and pump mounting bracket (Pump:
1/2 HP, single-phase, 115 V/60 Hz)
• Single-acting ram has a 33.02 cm (13 in)
stroke
1U-7465
• Choice of pumps is available to suit individual
• Same as 1U-7463 except has an air/hydraulic
needs
pump (requires 9 cfm at 689.5 kPa [100 PSI]
at the pump) and hose (9.53 mm ID x 3.05 m
[3/8 in ID x 10 ft])
Part Number
Description
Weight
1U-7463
Heavy-DutyShop Press,55 Ton
420.03 kg (926lb)
1U-7464
Heavy-DutyShop Press,55 Ton
417.31 kg (920lb)
1U-7465
Heavy-DutyShop Press,55 Ton
415.90 kg (917lb)
Press Accessory Set for 55 Ton Shop Presses
• Use with 55 ton presses
• Weight: 85 lb
Item
Description
1U-7466
Press Accessory Set
Set Includes:
1
Bearing pulling attachment
2
Rampush adapter with 25.4 mm (1in) diameter shank
3
Rampushingadapterwith31.75 mm (11/4in) diameter shank
4
V-push adapter
5
Pair or V-blocks
6
Ram forcing cap
7
Threaded adapter
Economy Shop Press, 100 Ton
Warranty: Caterpillar ®Lifetime
• Ready to tackle the tough pressing tasks
1U-7468
encountered daily in construction, trucking
• Includes ram with 10 inch stroke, electric/
and agricultural maintenance shops
hydraulic pump, 1U-7547 Hose Gauge
• Large 88.9 cm (35 in) opening between press
(6.35 mm ID x 2.44 m [ 1/4 in ID x 8 ft]), and
uprights allows you to easily handle large
pump mounting bracket (Pump: 1/2 HP, single-
gears, shafts, sprockets, etc.
phase, 60 Hz, 115 Volt)
• Hand operated winch and cable mechanism
gives operator positive control in adjustment
of lower press bolster to any height
Part Number
Description
Weight
1U-7468
Economy Shop Press, 100 Ton
534.8 kg (1,179lb)
10-46 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Heavy-Duty Shop Press, 100 Ton
Warranty: Caterpillar ®Lifetime
• Handles all your really tough pressing jobs
• Ram head glides smoothly along upper bolster
on rollers, allowing fast and easy horizontal
• Rugged construction assures that the frame
adjustments
will withstand loads of full-rated capacity
across the upper bolster without structural
• Upper bolster can be lowered 8 inches for
damage
convenient positioning during repetitive jobs
• Wide open uprights (over 30.5 cm [12 in])
• Double-acting ram with 33.02 cm (13 in)
allow easy side loading of bars and shafts for
stroke and electric/hydraulic pump and 2
bending or straightening
hoses (6.35 mm ID x 3.05 m [ 1/4 in ID x 10 ft])
(Pump: 3 HP, 3-phase, 230V/460V, 60 Hz, 3450
RPM, 24V controls)
Part Number
Description
Weight
1U-7471
Heavy-Duty Shop Press, 100 Ton
746.2 kg (1,645lb)
Roll Bed® Shop Presses, 100, 150 and 200 Ton
Warranty: Caterpillar ®Lifetime
• Patented Roll Bed feature allows you to roll
• Width adjusts from 10.16 to over 68.58 cm
out press bed to load and unload heavy work
(4 in to over 27 in) and is secured with locking
with overhead crane
bolts
• Choice of hydraulics makes these presses
• Workhead moves on bearings across the
as functional as you need for the biggest
upper bolster for off-center pressing jobs
pressing jobs
• Has off-center load capacity
• Movable ram head and 3.05 m (10 ft) remote
• To raise or lower the upper bolster, simply turn
control combined with large, open working
a crank handle
area allows operator to easily view work from
• Hydraulic rams meet ANSI B30.1 Standards
all sides
• Heavy-duty, cold-rolled steel construction
4C-5639
assures plenty of staying power to withstand
• 33.02 cm (13 in) stroke
full rated capacity loads
• 200 ton capacity
• Bearings make bed positioning smooth and
easy
Part Number
Description
Weight
4C-5639
Roll Bed Shop Press, 200 Ton
2,020.8 kg (4,455 lb)
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-47
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Smart Hydraulic Tensioning Pump
ModelUsage:G3600 / 3600/ C280
European Union Compliant, CE marked
• Go/No-Go feedback in Program mode to
ensure joint quality
Warranty: Manufacturer's
• Smart Hydraulic Tensioning Pumps (498-6540
and 498-6541) require use of 498-6542 Smart
• Automatic execution helps ensure joint quality
Tensioning Group.
while significantly decreasing time needed to
create the bolted joint
• Electronically controlled hydraulic pump for
bolt tensioning
• Manual mode allows for the use of non-smart
tensioners with the pump
• Touchscreen user interface (HMI) with pre-
loaded programs for specific tensioning jobs
• Pumps includes touchscreen (HMI), HMI case,
HMI cable, and HMI mounting group.
• Independent hydraulic control interface for
safety
Reference
• Quality Record creation for job traceability
• NEHS1280 Tool Operating Manual
Part No.
Voltage
Freq.
Plug
Max Pressure
Oil Cap.
Weight
NEMA 5-15P
498-6540
115v
60 Hz
1500 BAR
7.5 L
55 kg
(USA Style)
Schuko
498-6541
230v
50/60 Hz
1500 BAR
7.5 L
55 kg
(Euro Style)
Operating Temperatures
Temperature Range
Hydraulic Oil Required
15 to 60 C (60 to 140 F) ADV Hydo 10 309-6932 (3.8 L) - 2 gallon required to fill pump (or equivalent)
Service Repair Items
Part No.
Description
466-1821
HMI Mounting Group
466-1822
HMI Travel Case
498-6561
Pump Pressure Relief Valve
498-6562
Hydraulic Pendant Kit
498-6563
HMI (touchscreen)
498-6564
Manifold Valve Filter Kit
498-6565
Mechanical Pressure Gauge Kit (0-200bar)
498-6566
Valve Seal Kit
498-6567
HMICable
Product Dimensions
Item
MM
IN
A
520
20.50
B
317
12.50
C
654
25.75
D
246
9.69
E
270
10.63
F
109
4.29
10-48 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Smart Hydraulic Tensioning Group
ModelUsage:G3600 / 3600/ C280
European Union Compliant, CE marked
• Tensioners feature a hydraulic cycle counter to
help ensure proper maintenance is followed
Warranty: Manufacturer's
• 498-6542 Smart Tensioning Group requires
to maintain safe operation of the tools
use of either 498-6540 Pump Group (115v) or
498-6541 Pump Group (230v).
• Integrated hose assembly features the
necessary electrical cables for communication
• Twin stud design allows tensioning two bolts
from the tensioner to the pump
at one time
• All hydraulic components rated for 1500 bar
• Tensioner design features for improved
max pressure
technician efficiency include nut rotating
gearbox, puller sleeve free float and spring
• Group includes everything except smart pump.
loaded nut rotating sockets for inverted
Reference
operation
• NEHS1281 Tool Operating Manual
• Travel case includes pockets for rod guides for
both the Inline and Vee engines
Part No.
Engine
Application
Weight
498-6542
3600 Series
Connecting Rods
41 kg
Tool Group Contents
Part No.
Description
Qty.
466-1810
Tool Group Travel Case
1
498-6545
3600 ConRod Hose Group
1
498-6547
3600 ConRod Smart Tensioner
2
498-6551
High Force Socket Group
1
498-6572
Thumbwheel Assm
2
498-6573
Rod Guide Retaining Nut
4
Service Repair Items
Part No.
Description
466-1812
Hose - Pump - 3M Length
498-6546
Cable Junction Box
498-6550
Flow Divider
498-6552
Tensioner Return Spring Kit
498-6553
Tensioner Cover Kit
498-6554
Tensioner Fasteners Kit
498-6555
Tensioner Socket Spring Kit
498-6556
Tensioner Seal Kit
498-6557
Tensioner Relief Valve Kit
498-6558
Tensioner Transducer Kit
498-6559
Tensioner Puller Sleeve Assm Kit
498-6560
Swivel Manifold Assm Kit
498-6568
Transducer Cable - Pump
498-6569
Transducer Cable - Tensioner
498-6570
Chafe Gear - 3M Section
498-6571
Hose - Tensioner - 3M Length
498-6574
Quick Disconnect Group - 90°
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-49
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Smart Hydraulic Tensioner
• Integrated electronics provide automatic
• 360° rotation of quick disconnect allows for
feedback to ensure joint quality
convenient hose installation
• Robust top cap design for puller sleeve
• High pressure design allows for compact tool
retention
reducing technician fatigue
• Over stroke protection includes a visual
indicator and internal relief valve
Part No. Max Pressure
Max Load
Max Stroke
Weight
498-6547
1500 BAR
264 kN
8 mm
7.9 kg
Swing Rack Thrust Bolts Torque Wrench Tools
Model Usage: 7495
• Specialized torque tools are required to
• These tools attach to hydraulic torque wrench
tighten the swing rack thrust rail bolts.
478-3990 to ensure accuracy in bolt torque
Warranty: Manufacturer’s
requirements.
• Allows access to the bolt heads without
disassembly of 440-3994 plate
525-7955
Part No.
Description
Dimensions
Weight
525-7955
S1500 Reaction Roller Assembly
130 x 46 x 107 mm (5.12 x 1.9 x 4.3 in)
1.5 kg (3.3 lb)
Torque Link Assembly
525-7956
117 x 18 x 42 mm (4.6 x 0.7 x 1.7 in)
0.5 kg (1.1 lb)
(3/4in sq dr x 1inA/F 12pt)
525-7956
478-3990
10-50 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Cat® Ball Stud Breaker Group
Hammer Group 524-5362
Safety & Regulations
• Inverted Cat® hydraulic breaker includes
• Globally compliant and CE certified
custom-engineered hammer which mounts
• Safety guard encloses work tools, extensions
to upper plate. (Other hammers are not
and adapters
compatible.)
• Receiving provisions capture impacted
• Hydraulic cylinder and manual hand pump to
surfaces of work tools, extensions and
raise/lower upper platform
adapters
• Hand pump bypass feature to prevent
• Optional hydraulic power unit allows for
excessive force on steering components
remote hammer group operation
• Load-lock mechanism provides positive
Hydraulic Power Units (HPU)
locking of upper platform with hydraulic
cylinder disengaged
Part No.
Hydraulic Power Unit
• Spring-loaded wheels collapse to allow
524-5342
460 Volt / 60 Hz / 3 Phase
lower plate to rest solidly on ground (when
524-5343
230 Volt / 60 Hz / 3 Phase
load is applied)
524-5344
415 Volt / 50 Hz / 3 Phase
• Work tool, extensions, adapter configurations
524-5345
380 Volt / 50 Hz / 3 Phase
accommodate varying under-chassis heights
of listed models
524-5346
600 Volt / 60 Hz / 3 Phase
• Forklift provision for transport and storage
• Optimized for maximum hydraulic flow
and pressure
• Robust tool chest for storing work tools,
extensions and adapters
• 162 bar (2,350 psi), 32.2 lpm (8.5 gpm) max
flow rate
• Interchangeable orifice kit for use with
optional Cat 50 hz hydraulic power unit
• Supply and return hydraulic hose
• Remote pendant operation
Specifications
• Custom-designed mobile cart with forklift
• Dimensions: 400 x 800 x 1,000 mm
provision for transport and storage
(16 x 31.5 x 39 in)
• 75.7 L (20 gal) Cat® HYDOTM Advanced 10 or
• Weight: 454 kg (1,000 lb)
iSO46 Hydraulic Oil
(CONTINUED ON NEXT PAGE...)
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-51
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Cat® Ball Stud Breaker Group (CONTINUED)
524-5362 Hammer Group Accessories
Ball Stud Thread on Adapters
524-5368
2¼-12 Thread
524-5369
3¼-12 Thread
524-5374
2¼-12 Thread with Direct Coupler
Extensions
524-5376
110 mm
524-5370
170 mm
524-5371
260 mm
524-5372
350 mm
Work Tools
524-5364
303 mm
524-5373
254 mm
524-5362 Hammer Group Serviceable Parts
Hydraulics
524-5356
Quick Disconnect Kit - 1/2 and 3/4 in
360-6957
Lift Cylinder
524-5378
Lift Cylinder Hose
524-5331
Hand Pump
524-9168
Hand Pump Service Kit
524-5379
Hammer
Additional Parts
524-5377
Push/Pull Tool Handle
524-5365
Locking Ring with Handle Assembly
524-5366
HammerGroupSwivelCaster
524-5367
Hammer Group Rigid Caster
524-5375
Guard
524-5381
50 Hz Orifice and Dowty Washer Kit
524-5382
60 Hz Orifice and Dowty Washer Kit
524-5380
Tool Chest
524-5383
Tool Chest-Swivel Caster
524-5384
Tool Chest-Rigid Caster
(CONTINUED ON NEXT PAGE...)
10-52 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC PUMPS & PRESSES
Cat® Ball Stud Breaker Group (CONTINUED)
Hydraulic Pump Group
Reference
Dimensions
• Hammer Group Tool Operating Manual
• 635 x 737 x 1,359 mm (25 x 29 x 53.5 in)
M0080743
• Weight (empty): 408 kg (900 lb)
• PumpGroup (HPU) Tool Operating Manual
M0083627
• Video on Channel 1 (CATU1570)
Hydraulic Power Unit Serviceable Parts
•
Pump Group Motor Starters
524-5358
460 V
524-5359
230 V
524-5360
415 V
524-5361
380 V
Universal Pump Group Parts (Regardless of Voltage)
524-5348
Service Kit
524-5349
Pendant (corded)
524-5355
Quick Disconnect Kit - 1/2 and 3/4 in
524-5350
ValveAssembly
524-5351
Valve-Coil
524-5352
Pump-Gear
524-5353
Pump Group - Rigid Caster
524-5354
Pump Group - Swivel Caster
524-5357
Hose Assembly
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-53
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC WORK TOOLS
Hydraulic Torque Wrench, Square Drive
Model Usage: All
European Union compliant, CE marked
• Traceability: Tools are shipped with a
calibration certificate from the factory.
Warranty: Manufacturer’s Limited Lifetime
• Robust new handles provide safe and easy
operation.
• Compact, high-strength uni-body construction
provides a small operating radius without
• Wrench now comes standard with double-
sacrificing endurance.
swivel manifold for better maneuverability.
• Includes interchangeable handle to provide
• More durable manifold design with recessed
additional maneuverability.
sealing face
• Includes double swivel manifold to allow
• Reaction arm now features a larger lever for
correct hose alignment in tight quarters.
easier operation.
• 35° rotation angle and rapid return stroke for
• Multiple locations for mounting handle
fast operation
around tool
• Optional angle-of-turn indicator for tracking
• Easy push button release for quick direction
rotation movement
changes
• Newetching tobe used with option angle of
turn indicator
Part No.
Max. Operating Pressure
Max.Torque Output
Square Drive Size
Weight
478-3990
689 bar (10,000 psi)
1952 Nm (1,440 ft-lb)
3/4in
3.3 kg (7.25 lb)
478-3993
689 bar (10,000 psi)
4,373 Nm (3,225 ft-lb)
1in
5.67 kg (12.5 lb)
478-3996
689 bar (10,000 psi)
8,338 Nm (6,150 ft-lb)
1-1/2in
9.3 kg (20.5 lb)
478-4000
689 bar (10,000 psi)
15,151Nm (11,175ft-lb)
1-1/2in
15.9 kg (35 lb)
478-4003*
689 bar (10,000 psi)
35,455Nm (26,150ft-lb)
2-1/2in
32.3 kg (71.2 lb)
Part No.
Dimensions
A
B
C
D
E
F
G
H
39 mm
65 mm
108 mm
97 mm
136 mm
25 mm
70 mm
129 mm
478-3990
(1.54 in)
(2.56 in)
(4.25 in)
(3.82 in)
(5.35 in)
(0.98 in)
(2.76 in)
(5.08 in)
48 mm
80 mm
135 mm
128 mm
173 mm
33 mm
90 mm
161 mm
478-3993
(1.89 in)
(3.15 in)
(5.31 in)
(5.04 in)
(6.81 in)
(1.3in)
(3.54 in)
(6.34 in)
55 mm
92 mm
169 mm
157 mm
192 mm
40 mm
110 mm
188 mm
478-3996
(2.17 in)
(3.62 in)
(6.65 in)
(6.18 in)
(7.56 in)
(1.57 in)
(4.33 in)
(7.4in)
72 mm
114 mm
197 mm
190 mm
228 mm
50 mm
133 mm
229 mm
478-4000
(2.83 in)
(4.49 in)
(7.76 in)
(7.48 in)
(8.98 in)
(1.95 in)
(5.24 in)
(9.02 in)
89 mm
143 mm
246 mm
244 mm
287 mm
64 mm
182 mm
295 mm
478-4003*
(3.5in)
(5.63 in)
(9.69 in)
(9.61 in)
(11.3 in)
(2.52 in)
(7.17 in)
(11.61 in)
*Replaces 384-7264
See Accessories On Next Page...
10-54 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC WORK TOOLS
Hydraulic Torque Wrench, Square Drive
Accessories
Square Drive Service Repair Items
478-3990
478-3993
478-3996
478-4000
478-4003
Description
(Hyd. Wrench)
(Hyd. Wrench)
(Hyd. Wrench)
(Hyd. Wrench)
(Hyd. Wrench)
Drive Unit Seal Kit
478-3991
478-3994
478-3997
478-4001
478-4004
Drive Unit Rebuild Kit
384-8913
384-7877
385-8581
385-9416
384-7267
Ratchet Kit
384-8914
385-7912
385-8582
385-9417
384-7268
Drive Shoe Spring Kit
384-8915
384-8915
385-8583
385-8583
385-7913
Square Drive and Retainer Kit
384-8917
385-7915
385-8585
385-9420
384-7271
Ratchet Lever and Pin
384-8918
385-7916
385-8586
385-9421
384-7272
Swivel Manifold Kit
478-4030
478-4030
478-4031
478-4031
478-4032
Double-Swivel Manifold Replacement
478-4028
478-4028
478-4028
478-4028
478-4028
Swivel Manifold Seal Kit
478-4029
478-4029
478-4029
478-4029
478-4029
Standard Reaction Arm
478-3992
478-3995
478-3998
478-4002
478-4005
Male Quick Disconnect
7X-0487
7X-0487
7X-0487
7X-0487
7X-0487
Male QD Adapter
447-4935
447-4935
447-4935
447-4935
447-4935
Female Quick Disconnect
7X-0486
7X-0486
7X-0486
7X-0486
7X-0486
478-3990
478-3993
478-3996
478-4000
478-4003
Description
Reaction Arm Style
(Hyd. Wrench)
(Hyd. Wrench)
(Hyd. Wrench)
(Hyd. Wrench)
(Hyd. Wrench)
Angle-of-Turn Indicator
-
458-9475
458-9476
458-9477
458-9478
458-9479
Reaction Arm - Short
1
466-1796
-
-
-
-
Reaction Arm - 1”
2
466-1797
-
-
-
-
Reaction Arm - 2”
2
466-1798
-
-
-
-
Reaction Arm - 3”
2
466-1799
-
-
-
-
Reaction Arm - 6”
2
-
-
478-3999
-
-
Reaction Arm - Tube Extension
3
-
478-4033
-
-
-
ReactionArm - 390D Custom
3
-
458-9480
-
-
-
Twin Line Hose - 6m
-
417-9067
417-9067
417-9067
417-9067
417-9067
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-55
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC WORK TOOLS
Low Profile Cassette Wrench Drive Unit
Model Usage: All
European Union compliant, CE marked
• Traceability: Tools are shipped with a
calibration certificate from the factory.
Warranty: Manufacturer’s Limited Lifetime
• Robust new handles provide safe and easy
operation.
• Superior strength to-size ratio provides easy
access to difficult reach applications without
• Wrench now comes standard with double-
sacrificing tool life.
swivel manifold for better maneuverability.
• Includes interchangeable handle to provide
• More durable manifold design with recessed
additional maneuverability.
sealing face
• Includes double-swivel manifold to allow
• Fast-release drive unit enables rapid exchange
correct hose alignment in tight quarters
of cassettes; no tools required.
• 30° rotation angle and rapid return stroke for
• Multiple locations for mounting handle
fast operation
around tool
478-4006*
478-4014**
478-4024
Max. Operating Pressure
689 bar (10,000 psi)
689 bar (10,000 psi)
689 bar (10,000 psi)
2,766 Nm
Max.Torque Output
5,661 Nm (4,175 ft-lb)
11,484 Nm (8,470 ft-lb)
(2,040 ft-lb)
30 : 60 mm
36 : 85 mm
50 : 105 mm
Cassette A/F Range
(1-1/16 in : 2-3/8 in)
(1-5/16 in : 3-3/8 in)
(1-7/8 in : 4-1/8 in)
Weight
1.4 kg (3.09 lb)
2 kg (4.41 lb)
3 kg (6.61 lb)
Dimensions
Drive Unit
A
B
C
D
E
478-4006*
109mm(4.29in)
141mm(5.55in)
148mm(5.83in)
32mm (1.26in)
20mm (0.79in)
478-4014
136mm(5.35in)
167mm(6.57in)
178mm(7.01in)
41mm (1.61in)
20mm (0.79in)
478-4024
172mm(6.77in)
205mm(8.07in)
208mm(8.19in)
53mm (2.07in)
25mm (0.98in)
Cassette
(on next page)
Drive Unit Service Repair Items:
Description
478-4006
478-4014**
478-4024
Drive Unit Seal Kit
478-4007
478-4015
478-4025
Drive Unit Rebuild Kit w/ Retract Link
385-3990
385-8469
385-8735
Swivel Manifold Kit
478-4030
478-4030
478-4031
Double Swivel Manifold Replacement
478-4028
478-4028
478-4028
Swivel Manifold Seal Kit
478-4029
478-4029
478-4029
Male Quick Disconnect
7X-0487
7X-0487
7X-0487
Male QD Adapter
447-4935
447-4935
447-4935
Female Quick Disconnect
7X-0486
7X-0486
7X-0486
*Replaces 385-3988 **Replaces 385-8467
10-56 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC WORK TOOLS
Low Profile Wrench Cassettes
• Cassettes are used in conjunction with
• It is common to have one drive unit and
the appropriate sized drive unit to create a
multiple cassettes; based on nut sizes being
functioning tool.
maintained.
Drive Unit
(on previous page)
Cassette
Description
478-4008
417-9068*
478-4010
478-4012
478-4016*
478-4018**
478-4020***
478-4022
478-4026
36 mm
38 mm
41 mm
46 mm
36 mm
46 mm
55 mm
70 mm
65 mm
Cassette A/F Size
(1-7/16 in)
(1-1/2 in)
(1-5/8 in)
(1-13/16 in)
(1-7/16 in)
(1-13/16 in)
(2-3/16 in)
(2-3/4 in)
(2-9/16 in)
Used with Drive Unit
478-4006
478-4006
478-4006
478-4006
478-4014
478-4014
478-4014
478-4014
478-4024
Cassette Service Repair Items:
Ratchet Lever Assm
478-4009
478-4009
478-4011
478-4013
478-4014
478-4019
478-4021
478-4023
478-4027
Ratchet Kit
385-3993
424-3607
385-3998
385-4003
385-8472
385-8477
385-8482
460-7303
385-8738
Drive Shoe Spring Kit
384-8915
384-8915
384-8915
384-8915
384-8915
384-8915
384-8915
384-8915
385-8738
Cassette Spares Kit
385-4010
385-4010
385-4010
385-4010
385-8489
385-8489
385-8489
385-8489
385-8745
*Custom Cassette, only to be used with specific SIS application
*Replaces 385-8471 **Replaces 385-8476 ***Replaces 385-8481
Description
478-4006
478-4014
478-4024
Reaction Paddle*
385-4011
385-8490
-
Twin Line Hose - 6m
417-9067
417-9067
417-9067
* Reaction paddle used for offset reaction points while using cassettes
JULY 2018 Hydraulic and Mechanical Pullers and Drivers
10-57
Hydraulic/Mechanical Pullers/Drivers
HYDRAULIC WORK TOOLS
Electric Hydraulic Torque Wrench Pump
European Union Compliant, CE marked
These features only apply to 385-3995 and
385-3996 Pumps
• Features high efficiency pump design with
higher oil flow and bypass pressure 1.7 HP
• Digital display with built-in hour meter,
universal electric motor with high power to
pressure and torque display and shows
weight ratio and low voltage operation
self-diagnostics, cycle count and low voltage
warning information
• High strength, molded composite shroud
protects motor and electrical components
• Equipped with auto cycle operation when
with an ergonomic, non-conductive handle
advance button is pressed continuously (pump
operable with or without auto cycle feature)
• Low voltage pendant for additional operator
safety
• Valve technology reduces oil operating
temperatures and withstands contaminants to
increase pump reliability
Pump with LCD Display, Auto-
Pump with LCD Display, Auto-
Pumpwith standard analog
Pumpwith standard analog
cycle and readings in
cycle and readings in
Part Number
pressure gauge
pressure gauge
Torque Values
Torque Values
384-8916
385-3995
385-3996
385-8479
208-240 VAC, Single Phase,
115 VAC, Single Phase,
208-240 VAC, Single Phase,
115 VAC, Single Phase,
Motor
50/60 Hz
50/60 Hz
50/60 Hz
50/60 Hz
Display
Analog Gauge
LCD
LCD
Analog Gauge
Valve
Standard
Auto Cycle
Auto Cycle
Standard
Power
1.26 kW (1.7 HP)
1.26 kW (1.7 HP)
1.26 kW (1.7 HP)
1.26 kW (1.7 HP)
Flow Rate
60 CUin./min @ 10,000 PSI
60 CUin./min @ 10,000 PSI
60 CUin./min @ 10,000 PSI
60 CUin./min @ 10,000 PSI
Reservoir Capacity
6.62 L (1.75 gal)
6.62 L (1.75 gal)
6.62 L (1.75 gal)
6.62 L (1.75 gal)
Maximum Operating Pressure
10,000 PSI
10,000 PSI
10,000 PSI
10,000 PSI
10.49 x 17.71 x 18.99 in
10.49 x 17.71 x 18.99 in
10.49 x 17.71 x 18.99 in
10.49 x 17.71 x 18.99 in
Dimensions
(266.7 x 450 x 482.6 mm)
(266.7 x 450 x 482.6 mm)
(266.7 x 450 x 482.6 mm)
(266.7 x 450 x 482.6 mm)
Comes with fittings and skid bar
Service Parts
385-3995
385-3996
385-8479
384-8916
115VACValveAssembly
384-8480
-
-
-
230VACValveAssembly
-
384-8919
-
384-8919
Pendant
385-4001
385-4001
385-7917
385-7917
Analog Pressure Gauge Assembly
-
-
385-7914
385-7914
Brush Replacement Kit
346-6160
346-6160
346-6160
346-6160
Breather Plug
346-6159
346-6159
346-6159
346-6159
Roll Cage
346-6163
346-6163
346-6163
346-6163
Skid Plate
346-6164
346-6164
346-6164
346-6164
Relief Valve Repair Kit
385-8584
385-8584
385-8584
385-8584
Valve Repair Kit
385-8587
385-8587
385-8587
385-8587
Repair Kit
385-3991
385-3991
385-3991
385-3991
Accessories
Description
Part No.
Twin Torque Hose Assembly - 19 ft with couplers
417-9067
10-58 JULY 2018 Hydraulic and Mechanical Pullers and Drivers
