Caterpillar. Dealer service tools catalog (2018) - page 14
Hand Tools
PNEUMATIC TOOLS
Air Hammer
Warranty: Manufacturer's
European Union Compliant, CE marked
• Long barrel for easier access to hard to reach
areas
• Aluminum housing reduces weight and
provides durable long life
• Includes Quick-Connect Chuck 536-6465
• Variable speed trigger is easy to use, versatile
REPAIR INFORMATION
• Air directed exhaust
The Tool Repair Center can help with questions about
• Air line fi lter
repair options, calibration details, or general customer
service needs. Call +1(262) 656-4769 worldwide or in North
• Nylon friction plugs
America, toll-free at (855) 351-0926 or send an email to
catwarranty@snapon.com..
Recommended
Air
Sound Level,
Air Inlet
Recom. Hose Size,
Overall
Quick Connect
Part No.
Blows/Minute
Weight
Air Pressure
Consumption
Free Speed
Thread Size
ID min.
Length
Couple
Long Air Hammer with Quick-Connect Chuck 536-6465
620 kPa
18 SCFM
1/4 in - 18
8 mm (5/16 in) I.D.
187 mm
2.1 kg
222-3080
99 DBA
3400
536-6465
(90 PSIG)
(2.5CFM)
NPT
Min
(7.4")
(4.6lb
Air Hammer Accessories
Warranty: Caterpillar ®Six Months
• Used with 222-3080 Air Hammer
• Material: tungsten carbide steel
Part No.
Description
Width
Length
Shank Diameter
Use
223-4352
Sheet Metal Ripper
5/8in
5in
-
-
223-4353
Flat Chisel
3/4in
7in
-
-
Slices bushings, cylinder
223-4354
Panel Cutter
3/4in
6in
-
sleeves, etc.
Cuts exhaust and tail
223-4355
SlittingChisel
1in
6 7/8 in
-
pipes
223-4356
Weld Breaker
5/8in
6 3/4 in
-
-
228.6 mm
226-0102
Punch, 15 Degree
-
10.18mm (0.4in)
-
(9 in)
228.6 mm
226-0124
Straight Punch
-
10.18mm (0.4in)
-
(9 in)
Punch Tool for Pneumatic Hammer, 57 Degree
Model Usage: PM620, PM622, PM-200, PM-201,
• New 57-degree punch tool for pneumatic air
• Used to quickly and easily remove 222-7570
PM-102, PM-820, RM500B
hammers for better access
bits from the tool holder
Warranty: Caterpillar ®Six Months
Part No.
Description
Dimensions
Weight
Punch Tool for Pneumatic Hammer,
Dia 19.3 x 212.2 mm
541-9315
0.19 kg (0.4 lb)
57 Degree
(Dia 0.8 x 8.4in)
Separator Fork
Warranty: Caterpillar ®Six Months
• Used with common air hammers
• Pickle fork design used for ball joints and tie
rod ends
• Multiple applications
Part No.
Description
Dimensions
Weight
Length: 187.32mm (7 3/8in)
541-9329
Separator Fork
0.5 kg (1 lb)
Tip (Opening): 20.63 mm (13/16 in)
17-90 JULY 2018 Hand Tools
Hand Tools
PNEUMATIC TOOLS
Air Ratchet
Model Usage: All Cat® Products
• 200 RPM free speed, 250 in-lbs torque output
- fast and powerful
Warranty: Caterpillar ®18 Months
European Union Compliant, CE marked
• Aluminum housing reduces weight and
REPAIR INFORMATION
provides durable long life
The Tool Repair Center can help with questions about
• Versatile, easy-to-use paddle-style trigger;
repair options, calibration details, or general customer
variable speed trigger
service needs. Call +1(262) 656-4769 worldwide or in North
America, toll-free at (855) 351-0926 or send an email to
• Ball bearing mounted air motor reduces
catwarranty@snapon.com..
vibration and operator fatigue; prolongs motor
life
Part
Recommended
Free Speed
Free
Sound Level,
Torque
Air Inlet
Recommended
Overall
Drive
Weight
Number
Air Pressure
Air
Speed
Free Speed
Range
Thread Size
Hose Size
Length
620 kPa
22 SCFM
7-81 N•m
256 mm
1.09 kg
222-3059
3/8in
200RPM
95.1 dBa
1/4 in - 18 NPT
10mm(3/8in)
(90 PSIG)
(3.0 CFM)
(5-60 ft-lb)
(10.43 in)
(2.4 lb)
Shears
Model Usage: All Cat® Products
European Union Compliant, CE marked
REPAIR INFORMATION
The Tool Repair Center can help with questions about
Warranty: Caterpillar ®18 Months
repair options, calibration details, or general customer
service needs. Call +1(262) 656-4769 worldwide or in North
America, toll-free at (855) 351-0926 or send an email to
catwarranty@snapon.com..
Recom.
Sound
Sound
Recom.
Average Air
Cutting
Cutting
Air Inlet
Overall
Part No.
Air
HP
Level, Free
Level,
Cut Width
Strokes
Hose Size,
Weight
Cons.
Capacity
Speed
Thread Size
Length
Pressure
Speed
Working
ID min.
620 kPa
4 CFM [113.3
1.2 mm
5.6 mm
4.572 m (15
2500 per
1/4 in - 18
8 mm
254 mm
1.3 kg
222-3083
0.6
88.1 dBa
99.6 dBa
(90 PSIG)
I/min.]
(3/64 in)
(7/32 in)
ft) per/min
minute
NPT
(5/16 in)
(10in)
(2.8 lb)
Pneumatic Snap Ring Tool
Warranty: Manufacturer's, One Year
• Light weight
• Ergonomic design
• Easy to use
• Handles snap rings 0.25 - 6 inch (0.6 - 15 cm)
Snap Ring Tool
Replacement Tips (Warranty: Caterpillar Standard Warranty, 6 months)
Straight
430-4392
45-degree Angle
430-4394
90-degree Angle
JULY 2018 Hand Tools
17-91
Hand Tools
PNEUMATIC TOOLS
Air Engraver
Warranty: Caterpillar ®Six Months
European Union Compliant, CE marked
REPAIR INFORMATION
The Tool Repair Center can help with questions about
• Punch 3/16 inch diameter starting hole
repair options, calibration details, or general customer
service needs. Call +1(262) 656-4769 worldwide or in North
• Material: tungston carbide steel
America, toll-free at (855) 351-0926 or send an email to
catwarranty@snapon.com..
Recom-
Overall
Recom-
Average Air
Air Inlet
mended
Length
Part No.
Description
mended Air
Consump-
Free Speed
Sound Level
HoseLength
Weight
Thread Size
Hose Size, ID
Without
Pressure
tion
min.
Hose
620 kPa (90
7 SCFM (1.0
1/4 in - 18
10 mm (3/8
"1,511 mm
"140 mm
223-1154
Air Engraver
14000 RPM
90.0 dBa
.22 kg (.48 lb)
PSIG)
CFM)
NPT
in)
(59.49 in)"
(5.5in)"
Air Engraver Needles
Needle,
223-4357
-
-
-
-
-
-
-
-
-
Coarse
Needle,
223-4358
-
-
-
-
-
-
-
-
-
Medium
223-4359
Needle, Fine
-
-
-
-
-
-
-
-
-
High-Power Extension Air Gun
Warranty: Caterpillar ®Six Months
• Versatile tool ideal for cleaning hard-to-reach
• Includes durable cast aluminum, pistol-style
locations
body, aluminum extension, and zinc alloy
nozzle
• Good for cleaning benchtops, workstations,
machinery, and equipment
• 1/4 inch FNPT inlet
• Venturi tip increases the power and limits
• Meets OSHA standards
static pressure to less than 207 kPa (30 PSI)
when tip is blocked
Part No.
Description
Size
156-0930
Safety Air Gun
61 cm (24.0 in)
156-0931
Safety Air Gun
91 cm (36.0 in)
156-0932
Safety Air Gun
122 cm (48.0in)
Jet Guard Safety Air Gun
Warranty: Manufacturer's One Year
• CE marked, Meets OSHA Standards
• Pinned, tamper proof nozzle
• Safety air shield - patented protective air
• Durable cast aluminum body
cone protects operator from chip fly-back
• 1/4 inch NPT/BSPT inlet
• Delivers high thrust with pinpoint accuracy
• Specs at 100 psi (6.9 bar)
• Adjustable air volume - from a “blast” to a
• - Operating pressure 40-120 psi (2.8 - 8.3 bar)
“whisper”
• - Output thrust: 0.4 lbs (1.8 N)
• Ergonomic, pistol grip handle provides
• - Noise level: 102 dBA
maximum comfort
• - Air usage: 35 cfm (991 l/m)
• Wide comfort trigger
• - Weight: 0.6 lbs (272 g)
• Built in hanger for easy storage
Part No.
Description
441-5255
Jet Guard Safety Air Gun
17-92 JULY 2018 Hand Tools
Hand Tools
PNEUMATIC TOOLS
Jet Guard Safety Air Gun
Warranty: Caterpillar ®Six Months
• Meets OSHA Standards
• Good for cleaning machine tools and other
production equipment
• Patented protective air cone protects operator
from chip fly-back
• Built in hanger for easy storage
• Delivers high thrust with pinpoint accuracy
• Durable cast aluminum body
• Knurled adjusting nut controls air volume
• 1/4inch NPTinlet
• Ergonomic pistol grip and trigger reduce hand
fatigue
Part No.
Description
156-0927
Jet Guard Safety Air Gun
Safety Blow Gun
Warranty: Caterpillar ®Six Months
• Supplies non-aspirating, high velocity, sharply
• For use with inlet pressure up to 150 psig
defined, collimated air stream particularly
• Lightweight all metal construction
suited for cleaning small blind holes and
cavities
• 1/4 inch FNPT inlet
• Complies with OSHA standard 1910.242(b)
for dead-ended nozzle pressure and noise
limitation
Part No.
Description
Test Lab Listing
4C-3302
Air Blow Gun w/Nozzle Assembly
UL/FM
4C-3304
Nozzle w/152 mm (6 in) Extension
-
Gun Vac®
Warranty: Caterpillar ®Six Months
• Rugged aluminum construction
• Reusable collection bag
• Uses standard shop compressed air
• Includes brush and 23 cm (9 in) crevice tool
• No motor, wires, or electrical fields
• Accepts all 1-1/4 inch vac accessories
• Creates twice the vacuum suction of
• 1/4inch NPTinlet
conventional electric shop vacuums
Part No.
Description
4C-6774
Gun Vac, 551 x 1034 kPa (80-150 PSI)
4C-6775
Reusable Bag, 190 mm x 343 mm (7 1/2 in x 13 1/2 in)
4C-6776
Extension, 457.2 mm (18 in)
JULY 2018 Hand Tools
17-93
Hand Tools
PNEUMATIC TOOLS
Superbolt Angle Nut Runner
Model Usage: 797 Mining Truck
• Used to aid in reducing operator fatigue when
REPAIRS
installing Superbolts on 797F front struts
Apex Tool Group, www.apextoolgroup.com
Warranty: Manufacturer’s
• Wrenches can be set to required torque and
1000 Lufkin Road, Apex, NC 27539
stall out when set torque is reached
919-387-0099 p 919-387-2614 f
Part No.
Description
492-5762
Superbolt Angle Nut Runner Tool Assembly
492-5763
Superbolt Angle Nut Runner Controller
Blow Gun with Air Knife and Regulator Group
Model Usage: D6T and D8T Track Type Tractors
• Blow gun with 2” air knife easily cleans
• Regulator with adapter regulates air flow to
D-shaped filter assemblies
the gun
Warranty (Blow Gun with Air Knife):
Manufacturer’s Five Years against defects in
Part No.
Description
Dimensions
Weight
materials orworkmanship
485-3771
Blow Gun with Air Knife
30”long extension (762 mm)
2.7 kg (6 lb)
More at www.exair.com
485-3769
Regulator with Adapter
Regulator 64 mm long, adapter 37 mm long
1.2 kg (2.7 lb)
Warranty (Regulator Group):
Warranty: Caterpillar ®Six Months
17-94 JULY 2018 Hand Tools
Hand Tools
PNEUMATIC TOOLS
Air Comb Filters and Radiator Cleaners
Model Usage: All Models
• Special multi-port nozzle maximizes air
• Accesses hard-to-reach areas
pressure and volume at a 90 degree angle.
Warranty: Manufacturer’s One Year
• Extends filter life; won’t punch holes
• Thoroughly cleans air filters, condensers and
• Available in four sizes
radiators from the inside out
485-7788
Focused high-pressure output
•
WARRANTY INFORMATION
• 5x the air volume
Innovative Products of America, Inc.: 845-679-4500
• Long-reach 90 degree airflow
492-0940
Part No.
Length
Weight
485-7788
406 mm (16 in), 304 mm (12 in) air comb
0.454 kg (1 lb)
492-0940
711 mm (28 in), 610 mm (24 in) air comb
0.454 kg (1 lb)
485-7790
485-7790
1016 mm (40 in), 914 mm (36 in) air comb
0.544 kg (1.2 lb)
485-7791
1321 mm (52 in), 1245 mm (49 in) air comb
0.59 kg (1.3 lb)
485-7791
JULY 2018 Hand Tools
17-95
Hand Tools
PNEUMATIC TOOLS
Pneumatic Syphon Spray Gun
Warranty: Caterpillar ®Six Months
CE marked
• Adjustable trigger and nozzle tip control
volume and spray pattern
• Ideal for oils, solvents, water, and other
liquids
• Brass nozzle tip
• Ergonomic, rugged, cast aluminum pistol grip
• 1/4 inch NPT/BSPT inlet
designed for heavyduty use
Specs at 100 psi (6.9 bar)
• High vacuum syphon delivers up to 45 L (12
• Operating pressure 40-120 psi (2.8 - 8.3 bar)
gal) per hour
• Flow rate: 16 gph (1 l/m)
• 305 mm (12 in) extension for accessing
difficult, hard-to-reach areas
• Air usage: 9 cfm (255 l/m)
• Wide comfort trigger
• Weight: 1.5 lbs (680 g)
Part No.
Description
441-5254
PneumaticSyphon SprayGun
Pneumatic Syphon Spray Gun
Warranty: Caterpillar ®Six Months
• Ergonomic, rugged, die cast aluminum pistol
• Adjustable trigger and nozzle tip control
grip designed for heavy-duty use
volume and spray pattern
• High vacuum syphon delivers up to 45 L (12
• 183 cm (6 ft) 1/4 inch PVC feed
gal) per hour
• Brass nozzle tip
• 304.8 mm (12 in) extension for accessing
• 1/4inch NPTinlet
difficult, hard-to-reach areas
• Meets OSHA standards
Part No.
Description
4C-5746
PneumaticSyphon SprayGun
Spray Gun Canister
Warranty: Caterpillar ®Six Months
• 0.94 L (1 qt) canister attaches to spray gun
• Increased mobility reduces the risks of spills
eliminating feed tubes and buckets
Part No.
Description
4C-6778
Spray Gun Canister
Pneumatic Oil Gun
Warranty: Caterpillar ®Six Months
• Ergonomic, rugged, die cast aluminum
volume and spray pattern
construction pistol grip designed for heavy-
• 0.95 L (1 qt) steel, reusable dispenser
duty use
eliminates feed tubes and buckets
• High vacuum syphon delivers up to 49.2 L (13
• Good for lubricating trucks, automobiles,
gal) per hour
construction equipment, and machinery
• 304.8 mm (12 in) extension for accessing
• 1/4inch NPTinlet
hard-to-reach areas
• Meets OSHA standards
• Adjustable trigger and nozzle tip control
• Conforms to MIL-O-14 559C
Part No.
Description
4C-6779
Pneumatic Oil Gun
17-96 JULY 2018 Hand Tools
Hand Tools
TORQUETOOLS
Torque Wrenches, Cat® Electronic
Warranty: Manufacturer's One Year
CE marked, N.I.S.T. traceable certificate of
• Ergonomically designed molded non-slip
calibration
rubber grip
• Just the set torque and the wrench will beep
• Scales include: foot pounds, inch pounds,
and flash a green light when the desired
kilogram centimeters, or newton meters
torque is reached
• Case included
• Torques clockwise and counterclockwise
• Provides torque angle
REPAIR INFORMATION
• Easy-to-read display shows torque in real time
The Tool Repair Center can help with questions about
repair options, calibration details, or general customer
• 15-Degree Flex Ratcheting Head
service needs. Call +1(262) 656-4769 worldwide or in North
America, toll-free at (855) 351-0926 or send an email to
• Push Button Socket Release
catwarranty@snapon.com.
•
Remembers last unit and torque setting
Part No.
Drive
Accuracy
Head Type
TorqueRange
Length
13.6 N·m - 135.6 N·m
384-6821
3/8in
± 2% CW / ± 3% CCW
Flex Ratchet
17 in (43 cm)
(5 ft-lb - 100 ft-lb)
33.8 N·m - 338 N·m
384-6822
1/2in
± 2% CW / ± 3% CCW
Flex Ratchet
27 in (68 cm)
(25 ft-lb - 250 ft-lb)
Click-Type Torque Wrenches
Warranty: Manufacturer's 90 Days
Style A
Style B
• Work only in the right-hand or clockwise
• Work in both right and left-hand (clockwise
direction, and are guaranteed to be accurate
and counter-clockwise) directions
within 4% of setting of the top 80% of the
• Micrometer handle style adjustment
scale
• These wrenches are labeled in both ft-lbs and
• Easily adjusted by a small calibrated dial
A
N•m
along the wrench arm
• Includes a certificate of calibration
• Eliminates the need to reduce the torque
setting to the low end of the scale for storage
B
in order to retain accuracy
REPAIR INFORMATION
The Tool Repair Center can help with questions about
• The 162-8718 Torque Wrench can be
repair options, calibration details, or general customer
disassembled into three components for
service needs. Call +1(262) 656-4769 worldwide or in North
storage in a tool box
America, toll-free at (855) 351-0926 or send an email to
catwarranty@snapon.com.
• Includes a certificate of calibration
Min. Torque
Max. Torque
Ratchet
Head
Head
Kit Part
Style
Part No.
Drive
Accuracy
Increments
Length
Case
Kit Part No.
Range
Range
Type
Width
Depth
No.
271 N·m
813.5 N·m
13.6 N·m
1219.2 mm
60.32 mm
31.75 mm
160-6390
260-3766
A
162-8718
3/4
±4%
Detach
No
(200 ft-lb)
(600 ft-lb)
(10 ft-lb)
(48in)
(2 3/8in)
(1 1/4in)
(branded)
(non-branded)
27.1 N·m
135.6 N·m
2.71 N·m
447.67 mm
28.57 mm
14.28 mm
4C-5819
260-3764
A
4C-5492
3/8
±4%
Flex
Yes
(20 ft-lb)
(100 ft-lb)
(2 ft-lb)
(17 5/8in)
(1 1/8in)
(9/ 16in)
(branded)
(non-branded)
54.5 N·m
341.67 N·m
6.8 N·m
591.97 mm
41.27 mm
19.05 mm
5P-7429
260-3765
A
8T-9293
1/2
±4%
Flex
Yes
(40 ft-lb)
(252 ft-lb)
(5 ft-lb)
(22 1/8in)
(1 5/8in)
(3/4 in)
(branded)
(non-branded)
1.4 N·m
5.4 N·m
±4% CW,
1.35 N·m
258 mm
B
386-3340
1/4
Fixed
-
-
Yes
-
-
(0.83 ft-lb)
(4.2 ft-lb)
±6% CCW
(1 ft-lb)
(10.2 in)
27.1 N·m
203.6 N·m
1.4 N·m
469.9 mm
B
214-7349
1/2
±6%
Fixed
-
-
Yes
214-7350
-
(20 ft-lb)
(150 ft-lb)
(1 ft-lb)
(18.5 in)
40.7 N·m
339.3 N·m
1.4 N·m
539.6 mm
B
9U-5006
1/2
±6%
Fixed
-
-
Yes
-
-
(30 ft-lb)
(250 ft-lb)
(1 ft-lb)
(21.25 in)
135.7 N·m
814.2 N·m
7.0 N·m
1092.2 mm
B
9U-5007
3/4
±6%
Fixed
-
-
Yes
-
-
(100 ft-lb)
(601 ft-lb)
(5.2 ft-lb)
(45in)
6.8 N·m
101.8 N·m
0.7 N·m
393.7 mm
B
9U-5019
3/8
±6%
Fixed
-
-
Yes
-
-
(5 ft-lb)
(75 ft-lb)
(0.5 ft-lb)
(15.5 in)
13.6 N·m
135.7 N·m
0.7 N·m
393.7 mm
B
9U-5020
3/8
±6%
Fixed
-
-
Yes
-
-
(10 ft-lb)
(100 ft-lb)
(0.5 ft-lb)
(15.5 in)
271.2 N·m
1355.8 N·m
±4% CW,
6.8 N·m
1753 mm
B
386-3348
1
Fixed
-
-
Yes
-
-
(200 ft-lb)
(1000 ft-lb)
±6% CCW
(5 ft-lb)
(69in)
JULY 2018 Hand Tools
17-97
Hand Tools
TORQUE TOOLS
Dial-TypeTorqueWrenches
Warranty: Manufacturer's Lifetime
• Accuracy within 2% of the reading within the
• Work in both right and left-hand (clockwise
upper 80% of the scale
and counter-clockwise) directions
• Wrenches with follow-up needle use two
pointers on the dial which move as one as
REPAIR INFORMATION
long as pressure is applied and one remains
The Tool Repair Center can help with questions about
at the maximum torque reading until reset
repair options, calibration details, or general customer
service needs. Call +1(262) 656-4769 worldwide or in North
• Wrenches with light indicator features a light
America, toll-free at (855) 351-0926 or send an email to
which comes on when the torque setting is
catwarranty@snapon.com.
reached
Torque
Metric
English
Needle
Light Indicator
Part No.
Drive U.S.
Drive
Accuracy
Length
Case
Range
Graduations
Increments
Included
Included
103.9 cm
9S-7351
800 N·m
600 ft-lb
3/4in
±2%
20.0 N·m
10 ft-lb
-
Yes
No
(40.9 in)
75.9 cm
9S-7352
480 N·m
350 ft-lb
3/4in
±2%
10.0 N·m
5 ft-lb
Yes
-
No
(29.9 in)
47.6 cm
9S-7353
230 N·m
175 ft-lb
1/2in
±2%
10.0 N·m
2.5 ft-lb
Yes
-
No
(18.75 in)
25.2 cm
9S-7354
34 N·m
300 in-lb
3/8in
±2%
1.0 N·m
5 in-lb
Yes
-
No
(9.9in)
9U-5017
25.4 cm
(warranty
35 N·m
300 in-lb
3/8in
±4%
1.0 N·m
5 in-lb
Yes
-
Yes
(10.0 in)
90 days)
Heavy-Duty Box Wrenches
Warranty: Manufacturer's Lifetime
• Used for fasteners in inaccessible places,
REPAIR INFORMATION
such as track roller guard bolts, where a
The Tool Repair Center can help with questions about
torque wrench and standard socket cannot
repair options, calibration details, or general customer
service needs. Call +1(262) 656-4769 worldwide or in North
be used
America, toll-free at (855) 351-0926 or send an email to
catwarranty@snapon.com.
Part No.
Hex Size
Straight/Config.
Offset
Torque
262-2758
20 mm
12 pt
straight
650 ft-lb
262-2759
30 mm
12 pt
straight
650 ft-lb
4C-9563
24 mm
12 pt
straight
650 ft-lb
6V-4165
19 mm
12 pt
straight
650 ft-lb
6V-4166
7/8in
12 pt
straight
650 ft-lb
6V-4167
15/16 in
12 pt
straight
650 ft-lb
6V-4168
1 1/8 in
12 pt
straight
650 ft-lb
6V-4169
1 5/16 in
12 pt
straight
650 ft-lb
6V-4171
15/16 in
12 pt
15° offset
-
6V-4154 (shown below)
1 1/2 in
12 pt
straight
650 ft-lb
Torque Wrench Extensions
Warranty: Manufacturer's Lifetime
• Has an effective length of 610 mm (24 in) and
Reference
a capacity up to 884 N•m (650 ft-lb)
• Form SEHS7150 to determine the torque
• Slide rule-type torque computer
wrench dial reading for different extensions
6V-4154
Part Number
Description
6V-3146
Tubular Extension
6V-4154
Heavy-Duty Box Wrench
6V-4170
Adapter, 3/4 inch, Sq. Drive
6V-3146
6V-4170
17-98 JULY 2018 Hand Tools
Hand Tools
TORQUETOOLS
Adapters and Extensions for Torque Wrenches
Warranty: Manufacturer's Lifetime
• 8S-5131 and 1P-2382 Adapters are used with
• 8F-4677 Extension and 8F-4678 Adapter are
the 9S-7353 or 9U-5014 Torque Wrench
used with the 9S-7352 or 9U-5015 Wrench to
increase the capacity of the wrench
Part No.
Description
Use
156-2568
Adapter,3/8inch drive, 10mm, 12 point box end
-
for universal joint bolts on all tractor-scrapers (except 613) and
1P-2382
Adapter (1/2 inch Drive, 3/4 inch 12 Point Box End)
No. 16 Mo- tor Graders
for torquing fuel line nuts on D3 Tractors, 910 Wheel Loaders and
5P-0166
Crowfoot Wrench (3/8 inch Drive, 3/4 inch Hex)
931 Track Loaders
use to double capacity of 8F-4675 and 9S-7352 Torque Wrenches
8F-4677
Extension, 3/4 inch Drive, 26 7/8 inch center to center
for torque applications up to 700 ft.lb.
8F-4678
Adapter Driver (3/4 inch Drive)
for use with 8F-4677 Extension
8T-3196
Offset Box Wrench
3/4 inch Drive, 1 7/8 inch Hex, 12 pt
Crankshaft Main Bearing on 3054 and 3056 Engines.
9U-6282
-
1/2 inch Sq. Drive, 15/16 inch Hex, 12 pt
386-3349
Offset Handle
1/2 inch square drive; 375 mm (14.76 in) offset; 559 mm (22 in) long
317-2806
1/2 in Drive Adapter with 5/8 inch Box End
-
Torque Wrench Adapter, Special 15/16 in
Model Usage: 3500B an 3500C Engines
• Achieves consistent and accurate 120 Nm
torque when used with the 147-2059 torque
Warranty: Manufacturer’s 30 day materials and
wrench
workmanship
262-656-4769 or catwarranty@snapon.com
Part No.
Description
Dimensions (L x W x H)
Weight
523-4602
Special 15/16 in Torque Wrench Adapter
457 x 48 x 23 mm (18 x 1.9 x 0.9 in)
0.5 kg (2.2lb)
Special Torque Wrench Extensions
Warranty: Manufacturer's Lifetime
• Extensions listed below are used with the 6V-
• Torque computer (376-4937), can be used to
9451 Tubular Arm, and the 9S-7352
compute the correct torque wrench reading
for proper torque application at the fastener
4V-9451
• Torque Wrench primarily for applications up to
1000 ft-lb (1360 N·m)
Part No.
Description
Use
6V-9451
Tubular Arm
-
4V-9454
4V-9455
Tighten mounting stud nuts on 55, 56, 57, 58 and 59 Towing
6V-9454
Wrench, 1 7/8 inch
Winches.
6V-9455
Wrench, 1 7/8 inch
Tighten mounting stud nuts on 55 and 56 Towing Winches
4V-9456
6V-9456
Wrench, 1 11/16 inch
Tighten steering cylinder tie rod bolt nut on No. 16G Motor Graders.
435-3382
Wrench, 1 1/4 inch
-
Torque Computer
Warranty: Caterpillar ®Six Months
• Used for calculating proper torque when using
an extension with analog and digital torque
wrenches
Part No.
Description
376-4937
Torque Computer
JULY 2018 Hand Tools
17-99
Hand Tools
TORQUE TOOLS
Degree Wheel
Warranty: Manufacturer's Lifetime
• Used for measuring torque turn angles
• The nut or bolt does not have to be marked in
order to obtain the correct torque
Part No.
Description
Size
8T-3052
Degree Wheel
1/2 in drive; can be used with any standard 1/2 in drive socket
MechanicalTorqueTester
Warranty: Manufacturer's Lifetime
• Torque wrenches can be checked quickly and
• Certified accuracy is ±1% or one scale
easily
division, whichever is greater
• Furnished with 3/8 inch, 1/2 inch and 3/4
inch adapters to accommodate Cat torque
wrenches
Part No.
Description
TorqueRange
1P-7460
Mechanical Torque Tester
680.0 N·m (502 ft-lb)
Electronic Torque Testers
Warranty: Manufacturer's 90 Days
European Union Compliant, CE marked
• Automatic or manual display reset
• Accuracy better than 1% of the indicated
• Unique adjustable head moves for easy
value in ranges between 10% to 100% of
reading
maximum rating
• Rechargeable battery with 110 V AC adapter
• Maximum overtorque of 120% of full rating
included (not available separately)
• Reliable "first-peak" mode for tests of click
NOTE: Use 9U-5101 mounting bracket to
type torque wrenches without the need for
mount the testers to a bench top. No bracket is
manual sensitivity adjustment-a red light
required to mount testers to a vertical surfaces.
and buzzer indicate capture of first torque
peak. Other modes include "peak hold" which
REPAIR INFORMATION
records the highest reading during a test and
The Tool Repair Center can help with questions about
"track" which displays continuously during
repair options, calibration details, or general customer
use.
service needs. Call +1(262) 656-4769 worldwide or in North
America, toll-free at (855) 351-0926 or send an email to
• Equally accurate in clockwise and counter-
catwarranty@snapon.com.
clockwise directions
Part No.
TorqueRange
Drive U.S.
Size
9U-5009
12to 57 dN·m
10 to 50in-lb
1/4
9U-5010
57 to 282 dN·m
50 to 250 in-lb
3/8
9U-5011
226 to 1130 dN·m
200 to 1000 in-lb
3/8
9U-5012
68 to 339 N·m
50 to 250 ft-lb
1/2
17-100 JULY 2018 Hand Tools
Hand Tools
GREASE GUNS
Grease Fitting Relief Valve
Warranty: Caterpillar ®Six Months
• This thumb-operated relief valve is installed
• Improves efficiency during greasing and
between a grease gun and a grease gun hose.
reduces grease zerk breakage
• When a pressure lock situation is created
• For use on any grease gun
during greasing, the valve expells grease,
lowering the pressure, and allows the gun to
be safely removed from a grease zerk, without
damage to the zerk.
Part No.
Description
Dimensions
Weight
493-6894
Grease Fitting Relief Valve
88 x 30 x 15 mm (3.5 x 1.2 x 0.6 in)
0.034 kg (0.08lb)
JULY 2018 Hand Tools
17-101
Hand Tools
GREASE GUNS
Lever Grease Gun, Model Pro "L"
Warranty: Caterpillar ®Six Months
• Heavy-duty construction
• Lever gun will operate with partial lever
strokes for use in close quarters
• Cast iron head equipped with a check valve
and an air-bleed valve
• Zinc plated
• Spring primed
• Cat branded
• Two way loading
• Maximum operating pressure of assembly:
68,948 kPa (10,000 PSI)
• Uses standard Cat Grease cartridges (14.5 oz)
Part Number
Description
8F-9866
Cat Pro "L" Grease Gun
8F-9866 Consists of:
190-1668
Coupler
190-1669
Hose Assembly, 12 in long
Optional:
190-5623
Hose Assembly, 18 in long
Service Parts for Noncurrent 8F-9866 (This model is not marked Pro L and uses the 2M-
2689 or 190-1670 Coupler with a check valve)
190-1670
Coupler (valve with steel insert)
2M-2689
Coupler (valve with rubber insert)
9F-2636
Nozzle Assembly (Manufacturer's Warranty 30 Days)
9F-2637
Nipple (part of 9F-2636)
Pistol Grip Grease Gun
Warranty: Manufacturer's One Year
• Heavy-duty construction
• Lever gun will operate with partial lever
strokes for use in close quarters
• Cast iron head equipped with a check valve
and an air-bleed valve
• Zinc plated
• Spring primed
• Cat branded
• Two-way loading
• Maximum operating pressure of assembly:
31,026 kPa (4,500 PSI)
• Uses standard Cat Grease cartridges (14.5 oz)
Part No.
Description
190-5622
Pistol Grip Grease Gun
Grease Gun Consists of:
190-1668
Coupler
190-5623
Hose Assembly, 18 in long
Optional:
190-1669
Hose Assembly, 12 in long
Electric Grease Gun
Warranty: Manufacturer's One Year Contact
• 20v, 1.5 Ah lithium-ion grease gun
• LCD displays:
JERRY.MEEHAN@SKF.COM OR 815-341-1321
• 10,000 psi maximum
- Grease meter in ounces or grams
• Two-flow rates: High - 6oz (170g) per minute
- Grease level gauge
and Low - 3.2oz (90.7oz) per minute
- Battery level gauge
• Delivers up to 15 cartridges per hour on a
- Troubleshooting information
single charge
• Built-in LED flashlight
• 70-min battery recharge
• Carrying case
Part Number
Description
Charger Voltage
463-3105
20v, 1.5 Ah lithium-ion grease gun
110v, 60hz
463-3106
20v, 1.5 Ah lithium-ion grease gun
220v, 50hz
17-102 JULY 2018 Hand Tools
Hand Tools
SCREWDRIVERS
Screwdriver Set, 5-Piece
Warranty: Caterpillar ®Lifetime
• Exclusive high-tech handle for a more
comfortable grip and more powerful
performance
Part No.
Size
Description
233-1640
-
Screwdriver Set
Set Consists of:
6V-7933
5/16 in tip, 277.11 mm (10.91 in) long
Standard Screwdriver
6V-7934
No. 2 Phillips tip, 213.6 mm (8.41 in) long
Phillips Screwdriver
6V-7935
1/4" tip 213.6mm (8.41 in)long
Standard Screwdriver
6V-7936
No. 1 Phillips tip, 162.9 mm (6.66 in) long
Phillips Screwdriver
525-8019
3/16 in tip, 260 mm (9.44 in) long
Standard Screwdriver
Screwdriver Set, 2-Piece
Warranty: Caterpillar ®Lifetime
• Exclusive high-tech handle for a more
comfortable grip and more powerful
performance
Part No.
Size
Description
9U-7290
Includes a flat 1/4 in tip and #1 Phillips
Screwdriver Set
Set consists of:
Part No.
Size
Description
6V-7936
163 mm (6.6") long
No. 1 Phillips Tip
525-8019
3/16" Flat tip, 163 mm (6.6")long
Flat Tip
JULY 2018 Hand Tools
17-103
Hand Tools
SCREWDRIVERS
Black Plastic Handle Screwdriver Set, 6-Piece
Warranty: Caterpillar ®Lifetime
• Includes vinyl pouch
Part No.
Tip Size
Description
162-7804
-
Complete Screwdriver Set
Complete Set Consists of:
6V-7937
3/16 in
Standard Screwdriver
6V-7935
1/4in
Standard Screwdriver
6V-7933
5/16 in
Standard Screwdriver
6V-7932
3/8in
Standard Screwdriver
6V-7936
No. 1
Phillips Screwdriver
6V-7934
No. 2
Phillips Screwdriver
Black Plastic Handle Screwdrivers
Warranty: Caterpillar ®Lifetime
• Nickel/chrome-plated blades with vapor-
• Heavy-duty, high impact handle
blasted tips for best possible grip on screws
Part No.
Tip Size
Length
Standard Tip, Round Shank Screwdrivers
277-8790
1/2in
469.0 (18.47 in)
6V-7932
3/8in
342.1 mm (13.50 in)
6V-7933
5/16 in
277.1 mm (10.91 in)
6V-7935
1/4in
212.8 mm (8.38 in)
6V-7937
3/16 in
239.8 mm (9.44 in)
6V-7938
1/4in
100.1 mm (3.94 in)
6V-9124
1/8in
120.7 mm (4.75 in)
Phillips Tip, Round Shank Screwdrivers
214-7342
No. 3
276.4 mm (10.88 in)
6V-7934
No. 2
213.6 mm (8.41 in)
6V-7936
No. 1
169.2 mm (6.66 in)
Ratcheting Screwdriver, 5 Bits
Warranty: Caterpillar ®Lifetime
• Nickel/chrome-plated blades with vapor-
• Heavy-duty, high impact handle
blasted tips for best possible grip on screws
Part No.
Description
Size
Length
3/16in and 9/32 in flat tips, #1 and
"22.25 mm (8 3/4in)long overall;
Ratcheting
9U-7291
#2 Phillips, and #10 Torx stored in
96.04 mm (3 25/32 in) stainless steel
Screwdriver
hollow handle
shanklength
Screwdriver
Warranty: Caterpillar ®Six Months
• Wide tri-lobe design in the center of the
• Soft-grip handle provides increased
handle and Snap-on® bolstered, special
comfort and control while resisting most
alloy steel blade supply turning power when
shop solvents.
needed
• Nickel-chrome plating helps protect against
• Six specially designed curves and flutes with
corrosion and promotes easy clean up.
a round neck provides fingertip control, aids in
• Tip identifier on the crown helps to quickly
spinning and prevents the tool from rolling on
identify the needed tool.
flat surfaces.
Part No.
Description
Length
Weight
Snap-on Flat Tip 1/8 in Instinct® Mini-Tip
460-9913
149mm(5-7/8in)
0.23 kg (8 oz)
Soft-Grip Red Screwdriver
17-104 JULY 2018 Hand Tools
Hand Tools
SCREWDRIVERS
Screwdriver Bit Set, 32-Piece
Warranty: Caterpillar ®Six Months
• Cushion grip handle
• Blast finished tip for added grip
• Strong magnetic grip holds bit securely
Part No.
Adapter
Hex
Tamper
Torq
Torx
Tri-wing
3/32, 7/64, 1/8, 9/64, 5/32,
T7, T8, T10,
1/4 in square to
386-3366
3/16 in and 2, 2.5, 3, 4,
4, 6, 8, 10
6, 8, 10
T15, T20, T25,
1, 2, 3, 4
1/4 in hex
5 mm
T27, T30, T40
Insulated Screwdriver
Warranty: Caterpillar ®Lifetime
• Insulated design with no conductive path to
• Individually tested to protect up to 1,000 volts
user
AC and 1,500 volts DC
• Durable construction with nothing to tear,
puncture, or wear away
Part No.
Description
Sizes
386-3369
Insulated Screwdriver
3 mm Flat
386-3370
Insulated Screwdriver
3 mm Flat
Nutdrivers
Warranty: Caterpillar ®Lifetime
• Insulated design with no conductive path to
• Individually tested to protect up to 1,000 volts
user
AC and 1,500 volts DC
• Durable construction with nothing to tear,
puncture, or wear away
Part No.
Description
Sizes
386-3371
Nutdriver (Warranty Six Months)
7/32 in (5.5 mm)
386-3372
Nutdriver
7 mm(0.28 in)
Torx Driver Set
Warranty: Caterpillar ®Lifetime
• Ergonomic, durable handles
• Nut-shaped bolster for hard-to-turn fasteners
• Vapor-blasted tips for better grip
• Available as a set or individually
Part
Description
Size
Number
431-1522
9-piece Torx Driver Set
-
Individual Drivers
431-1520
Torx Driver
T8
431-1524
Torx Driver
T10
431-1515
Torx Driver
T15
431-1521
Torx Driver
T20
431-1518
Torx Driver
T25
431-1516
Torx Driver
T27
431-1514
Torx Driver
T30
431-1519
Torx Driver
T40
431-1517
Torx Driver
T45
JULY 2018 Hand Tools
17-105
Hand Tools
SCREWDRIVERS
Torx Driver
Warranty: Caterpillar ®Lifetime
• Wide tri-lobe design
• Durable nickel chrome plating
• Comfortable handle
Part No.
Description
Sizes
386-3373
Torx Driver
T10
Off-Set Slotted Screwdriver
Warranty: Caterpillar ®Lifetime
• Handy for removing slotted screws in areas
with limited access
Part No.
Description
5P-0302
Off-Set Slotted Screwdriver
Yellow Grip Pliers Set, 3-Piece
Warranty: Caterpillar ®Lifetime
• Hardened cutting edges stay sharper longer
• Machined cutter heads for matched blades
and cut with less effort
• Vinyl grip
Part Number
Description
Length
233-1639
Pliers Set
-
6V-6192
Slip Joint Pliers
208 mm (8 in)
Diagonal Cutting Pliers, 44.45 cm (17 1/2 in)
185.7 mm (7.30 in)
Pliers6V-6193sists of:
6V-6194
NeedleNose Pliers
181.1 mm (7.13 in)
Pliers Set, Cat® Locking 5-Piece
Warranty: Caterpillar ®Lifetime
• Heavy Duty Locking pliers
• Cat branded
• Reinforced teeth
Part No.
Description
Length
316-0707
LockingPliers Set with rollup pouch
-
Set Components:
316-0702
Straight jaws - 1 5/32 in (3 cm)
5 in (13 cm)
316-0703
Curved jaws 1 5/8 in (4 cm)
7 in (17 cm)
Hose clamping jaws with curved, straight, and clamp sections -
316-0704
10 in (25 cm)
1 5/32 in (3 cm)
316-0705
Curved jaws with cutter 2 7/16 in (6 cm)
10 in (25 cm)
316-0706
Straight jaws 2-7/16 in (6 cm)
10 in (25 cm)
17-106 JULY 2018 Hand Tools
Hand Tools
SCREWDRIVERS
Pliers
Warranty: Caterpillar ®Six Months
• Swivel pads and narrow jaw profile firmly grip
tapered surfaces in areas where c-clamps
cannot fit.
Part No.
Description
Specifications
Weight
Blue Point Locking Clamp,
Max. Jaw Capacity: 100 mm (3 15-16in)
0.81 kg
460-9920
Self-Leveling Jaw Pliers
Length: 381 mm (15in)
(1 lb-13 oz)
Combination and Multiple Position Pliers
Warranty: Caterpillar ®Lifetime
Type
Part No.
Description
Length
Finish
Vinyl Grip
A
213-1983
Combination Pliers
159.3 mm (6.30 in)
Chrome
Yes
A
6V-6192
Slip Joint Pliers
190.5 mm (7.50 in)
Black Oxide
Yes
B
214-7347
Multiple Position Pliers
304.8 mm (12.00 in)
Chrome
Yes
Multiple Position Pliers
B
236-1169
400.0 mm (16.00 in)
Chrome
Yes
(Six Month Warranty)
B
6V-6195
Interlocking Joint Pliers
235.0 mm (9.30 in)
Black Oxide
Yes
C
6V-6194
NeedleNose Pliers
181.1 mm (7.13 in)
Black Oxide
Yes
Diagonal Cutting Pliers,
D
6V-6193
185.7 mm (7.30 in)
Black Oxide
Yes
44.45 cm (171/2in)
Soft Jaw Pliers
Warranty: Caterpillar ®Six Months
• Soft Jaw Pliers with Urethane Jaw Inserts
• High carbon steel with vinyl grips
• Four pivot positions from 3/4 inch to 2 1/4
• Non marring
inch
Part Number
Description
Length
6V-0006
Soft Jaw Pliers
10in (254 mm)
Retaining Ring Pliers
Warranty: Caterpillar ®Six Months
• Soft Jaw Pliers with Urethane Jaw Inserts
• High carbon steel with vinyl grips
• Four pivot positions from 3/4 inch to 2 1/4
• Non marring
inch
Item
Part Number
No.
Tip Size
Type
Straight Tips
1
1P-1863
No. 26
0.12 in
External
2
1P-1861
No. 25
0.09 in
Internal
3
1P-1857
No. 23
0.07 in
Internal
4
1P-1855
No. 22
0.04 in
External
5
1P-1859
No. 24
0.07 in
External
6
1P-1853
No. 21
0.04 in
Internal
Right Angle Tips
7
1P-1864
No. 26-90
0.12 in
External
8
1P-1862
No. 25-90
0.09 in
Internal
9
1P-1858
No. 23-90
0.07 in
Internal
10
1P-1856
No. 22-90
0.04 in
External
11
1P-1860
No. 24-90
0.07 in
External
12
1P-1854
No. 21-90
0.04 in
Internal
JULY 2018 Hand Tools
17-107
Hand Tools
SCREWDRIVERS
External Pliers
Warranty: Caterpillar ®Six Months
• Use to compress or expand large retaining
• Gap between the plier tips ranges from 12.7
rings
mm(.50 in) fully closed to 76.0 mm (3.00 in)
fully open
• A double ratchet locks to hold the handles at
any given point without hand pressure
Item
Part No.
Description
1
5P-5197
External Pliers
2
136-1452
Internal Pliers Assembly
3 and4
1U-6728
Tip Set
Not Shown
6V-2062
Tip Set, 90 Degrees
Internal Retaining Ring Pliers
Warranty: Caterpillar ®Six Months
• Used to remove and install the large internal
• Pliers include 0.15 in (3.8 mm) diameter tips
retaining rings in power shift transmissions
• Service Part: 1U-8759 Replacement Tips (2 per
package)
• Double ratchet lock
Part No.
Description
Length
1U-8758
Internal Retaining Ring Pliers
29.00 in (737.0 mm)
Pliers
• The tips of the pliers precisely fit the gripping
Warranty: Caterpillar ®Six Months
• The hand-held pliers allow accurate assembly
points on the clamp the integrated spring
and disassembly operations
element keeps the pliers open, thus permitting
comfortable and fast working
Part No.
Description
444-6561
Pliers
External Retaining Ring Pliers
• Right angle tips to provide the necessary
Warranty: Caterpillar ®Lifetime
• Used to remove and install tempered steel
clearancewhere the lock ring is accessible
retaining rings used in many applications
only from a perpendicular position
Part No.
Description
2P-8312
External Retaining Ring Pliers
Reversible Wire Twisters
Warranty: Manufacturer’s Lifetime,
• Simple operation with a one-handed locking
• Automatic spring opening
262-656-4769 or catwarranty@snapon.com
function
• Commonly used on surface drill and longwall
• Jaw tip designed to hold clipped wire for
products
precision work and hard-to-reach areas
• Simplifies lock wire installation
• Ergonomic handle reduces user fatigue.
• For use with Ø 0.6 mm to Ø 1.2 mm (0.024 to
• Reversible trigger makes it easy to switch
.047 in) wire
between right and left applications with one
hand.
Part No.
Description
Dimensions
Weight
521-0962
Reversible Wire Twisters
OAL254 mm (10in)
0.53 kg (1.2 lb)
17-108 JULY 2018 Hand Tools
Hand Tools
HAMMERS AND SLIDE SLEDGES
Slide Sledge® Heavy Equipment Hammers
Warranty: Caterpillar ®One Year
• Safe, easy operation by one person to execute
• Varied sizes and weights available for greater
specific jobs with greater accuracy than two
force or accessibility
people with a hammer and chisel
Part No.
Weight
Length
Description
272-1208
9.00lb
30.00 in
Slide Sledge w/ 2 in diameter pin driver (272-1237)
272-1212
13.00 lb
46.00 in
Slide Sledge w/ 2 in diameter pin driver (272-1237)
272-1215
14.00 lb
30.00 in
Slide Sledge w/ 2 in diameter pin driver (272-1237)
272-1218
21.00 lb
46.00 in
Slide Sledge w/ 2 in diameter pin driver (272-1237)
Slide Sledge® Heavy Equipment Hammer Tips
Warranty: Caterpillar ®90 Days
Part No.
Description
Use
Picture No.
272-1228
Pin Driver, 1/2 in diameter
Recommendedfor pins and bolts 1/2in - 7/8in diameter
1
272-1230
Pin Driver, 7/8 in diameter
Recommendedfor pins and bolts 7/8in - 1-1/4 in diameter
2
272-1233
Pin Driver, 1 1/4 in diameter
Recommended for pins and bolts 1 1/4 in - 2 in diameter
3
272-1237
Pin Driver, 2in diameter
Recommended for pins and bolts 2 in - 2 1/2 in diameter
4
272-1239
Pin Driver, 2 1/2 in diameter
Recommended for pins and bolts 2 1/2 in - 3 in diameter
5
272-1240
Pin Driver, 3in diameter
Recommended for pins and bolts 3 in - 4 in diameter
6
272-1224
Tie Rod/Ball Joint Separator Fork, 11/16 in
Used to separate tie rod ends and ball joints
7
272-1225
Tie Rod/Ball Joint Separator Fork, 15/16 in
Used to separate tie rod ends and ball joints
7
272-1227
Tie Rod/Ball Joint Separator Fork, 1- 7/16in
Used to separate tie rod ends and ball joints
7
272-1223
Tie Rod/Ball Joint Splitter Adapter
Attach all Slide Sledge separator fork and most common forks available
8
272-1222
Tie Rod/Ball Joint Separator 3 Tip Set
Includes a Slide Sledge separator adapter and 11/16 in, 15/16 in and 1-1/8 in forks
9
272-1242
Ripper Tooth Pin Inserter, 3/4 in diameter
For pins as small as 3/4 in up to 1 in with minimum tooth spacing of 4 1/2 in
10
272-1244
Ripper Tooth Pin Inserter, 1/2 in diameter
Use on pins as small as 1/2in up to 3/4in with minimum tooth spacing of 3 1/2in
10
272-1247
Ripper Tooth Pin Inserter, 3/8 in diameter
Use on pins as small as 3/8in up to 1/2in with minimum tooth spacing of 2 3/4in
10
272-1243
Ripper Tooth Pin Remover, 3/4 in diameter
Use on pins as small as 3/4 in up to 1 in with minimum tooth spacing of 4 1/2 in
11
272-1245
Ripper Tooth Remover, 1/2 in diameter
Use on pins as small as 1/2in up to 3/4in with minimum tooth spacing of 3 1/2in
11
272-1246
Ripper Tooth Pin Remover, 3/8 in diameter
Use on pins as small as 3/8in up to 1/2in with minimum tooth spacing of 2 3/4in
11
For chopping away hardened debris and shearing metal bolts, pins, and rivets up
272-1241
Curved Chisel Tip, 1 3/8 in
12
to 3/8in, grade 8
Removes scarifier teeth on most motor graders. The fork design allows the techni-
272-1251
Scarifier Tooth Tip
13
cian to split the trenching arm where the scarifier tooth is forced to fit.
All-purpose impact tool designed to separate parts and straighten steel with
272-1252
UtilityWedge Tip
14
maxi-mum force.
Adapter driver tip to install races, bearings, and seals. Add drive plates to the end
272-1249
Race/Bearing/Seal Adapter
in various combinations. Fits plates with a common 9/16 in center hole, up to 3/4 in
15
high (plates not included)
Adapter driver tip to properly install bushings easily and quickly. Fits drivers with a
272-1250
Bushing Driver Adapter
16
common3/4 in center hole, up to 7/8 in high (drivers not included)
Adapter driver toinstall bearings, bushings, and seals. Fits drivers or plates with a
272-1248
Bushing/Bearing/Seal Plate Driver Adapter
17
1/ 4 in center hole. (drivers and plates not included)
287-2075
Small Tire Bead Breaker, 2 1/4in head width
Most standard applications
18
287-2076
Large Tire Bead Breaker, 2 7/8 in head width
Ideal for tractor trailers, backhoes, motor graders, and otherlarge equipment
19
JULY 2018 Hand Tools
17-109
Hand Tools
HAMMERS AND SLIDE SLEDGES
Slide Sledge® Heavy Equipment Hammer Accessories
Warranty: Manufacturer's, 90 Days
Part No.
Description
Use
Picture No.
Increases the Slide Sledge striking force by 5 lbs;
272-1253
5 Pound Handle Weight
works with any of the four tools by threading onto
1
tool handle
38 in long; For use with the shorter Slide Sledges
273-3527
Heavy Nylon Tool Bag
2
(272-1208 & 272-1215)
52 in long; For use with the longer Slide Sledges
273-3528
Heavy Nylon Tool Bag
3
(272-1212 & 272-1218)
Display Case for Slide
331-1264
-
-
Sledge Tools (Dealer Use)
Slide Sledge® Heavy Equipment Hammer Repair Parts
Warranty: Manufacturer's, 90 Days
• Various individual repair parts for the Slide
• Most repair parts are specific to certain sized
Sledge Heavy Equipment Hammer
Slide Sledges (specified in table below)
Part No.
Description
Use
Picture No.
312-0985
Drive Bar
Internal drive bar replacement for 272-1212 Slide Sledge
1
312-0988
Drive Bar
Internal drive bar replacement for 272-1218 Slide Sledge
1
312-0999
Drive Bar Tube
External main body of 272-1208 Slide Sledge
2
312-1002
Drive Bar Tube
External main body of 272-1215 Slide Sledge
2
Connection point of body and handle for 272-1208 & 272-
312-0992
Hand Guard
3
1212 Slide Sledge
312-0996
Slide Lock Pin
Pin forlocking the handle on all sized Slide Sledges
4
Plunger on endof Drive Barwhere tipsare secured for
312-1009
Plunger
6
272-1208 & 272-1212
Plunger on endof Drive Barwhere tipsare secured for
312-1010
Plunger
6
272-1215 & 272-1218
Housing and spring that go around the Plunger for 272-
312-7677
Plunger Parts Kit
7
1208&272-1212
Housing and spring that go around the Plunger for 272-
312-7678
Plunger Parts Kit
7
1215&272-1218
Hammers
Warranty: Caterpillar ®Lifetime unless otherwise
noted
Item
Part No.
Size
Height
Length
Weight
Material
Ball Peen Hammers
1
1S-0257
1 1/8 in
-
298.5 mm (11.75 in)
340 g (12 oz)
-
2
1B-7810
1 5/32 in
113.5 mm (4.47 in)
406.4mm (16in)
680 g ( 1 1/2 lb)
-
3
8H-8577
1 1/4 in
128.6 mm (5.06 in)
406.4mm (16in)
900 g (2 lb)
-
–
386-3351
1 7/8 in
76 mm (3 in)
362mm(14.25in)
454 g (1.0lb)
-
–
386-3363
7/8in
64 mm (2.5 in)
311mm(12.25in)
227 g (0.5lb)
-
Soft Face Hammers
4
1S-0258
1 11/16 in
117.5 mm (4.63 in)
330.2mm (13in)
900 g (2 lb)
-
Replacement Tips for 1S-0258 (Warranty: Six Months)
5
3S-0460
-
-
-
-
Medium tip
6
3S-0459
-
-
-
-
Hard tip
Hammer Handles (Warranty: Manufacturer: 120 Day)
-
263-3817
305 mm (12in)
-
-
-
Hickory
–
263-3819
407 mm (16 in)(2)
-
-
-
Hickory
–
263-3820
458 mm (18in)
-
-
-
Hickory
17-110 JULY 2018 Hand Tools
Hand Tools
HAMMERS AND SLIDE SLEDGES
Hammer
Warranty: Caterpillar ®Six Months
• For bumping when filing or where metal is
covered with sound-proofing material
Part No.
Description
Dimensions
Weight
Round Head Size: 1-19/32 in
460-9915
Snap-on Long Spot Pick Hammer
Height: 155.6mm (6-1/8in)
0.42 kg (15 oz)
Length: 330 mm (13 in)
Hammers, Multiple Use
Warranty: Caterpillar ®Lifetime unless otherwise
noted
Item
Part No.
Description
Face Diameter
Overall Length
Weight
Size
Material
1
223-1697
Double Face Sledge
47.8
889 mm (35in)
4.4 kg (9.61 lb)
-
2
223-1694
Dead Blow Sledge(Warranty: Six Months)
69.8
508 mm (20in)
2.5 kg (5.51 lb)
-
-
Hand Drilling (Short Handle)
3
223-1693
38.1
273mm(10.75in)
1.8 kg (4.01 lb)
-
(Warranty: Six Months)
–
223-1695
Dead Blow Sledge
82.6
914.4mm (36in)
5.4 kg (12.02lb)
-
-
–
223-1698
Double Face Sledge
54
905mm(35.63in)
5 kg (10.91 lb)
-
Double Face Sledge(Warranty: Manufacturer,
–
245-9823
73
914mm(35.98in)
7.2 kg (15.98lb)
-
120 Day)
Hammer Handles
-
263-3821
-
-
-
-
762 mm (30 in)(3)
Hickory
–
263-3822
Warranty: Manufacturer, 120 Day
-
-
-
915mm(36.02in)
Hickory
Rubber Mallet
Warranty: Caterpillar ®Six Months
• Solid rubber head
Part No.
Description
Specifications
Weight
Length: 95mm (3-3/4in)
460-9914
Blue Point Rubber Head Mallet
Diameter Head: 57 mm (2-1/4 in)
0.63 kg (1 lb-6 oz)
HandleLength:279 mm (11in)
Handled Tooth Pin Removers
Warranty: Caterpillar ®Six Months
• Removes/installs bucket teeth retaining pins
• Quicker, safer, and easier than a conventional
punch
• Small enough to store in toolbox
Part No.
Use
196-1168
Replacement Handle for 196-1331 and 203-4290
196-1331
J350, J400, J450, and J460 GET Tips
203-4290
J550 GET tip
JULY 2018 Hand Tools
17-111
Hand Tools
CHISELS AND PUNCHES
Handled Tooth Pin Removers
Warranty: Caterpillar ®Six Months
• Removes and installs solid or flex pins from
• Quicker, safer, and easier than a conventional
bucket teeth
punch
• Small enough to store in toolbox
Part No.
Use
143-2459
J200 and J225 GET Tips
143-2460
J250, J300, and J350 GET Tips
207-0631
23 Series Teeth and Diagonal Retention System (DRS)
Pin Punch Set, 7 Piece
Warranty: Caterpillar ®Six Months
• Replaces discontinued 1U-7250 Pin Punch Set,
• Individually heat treated for uniform hardness
7 Piece
• Includes pouch
Part No.
Point Size
Length
Description
226-1900
-
-
Pin Punch Set
Pin Punch Set Consists of:
226-1901
1/16 in
102mm (4.0in)
Drive Pin Punch (3/32 in)
226-1902
3/32 in
114mm (4.5in)
Punch
226-1903
1/8in
121mm(4.75in)
Punch
226-1904
5/32 in
152 mm (6 in)
Punch
226-1905
3/16 in
127 mm (5 in)
Punch
226-1906
7/32 in
146mm(5.75in)
Punch
226-1907
1/4in
146mm(5.75in)
Punch
Drift Punch Set, 5 Piece
Warranty: Caterpillar ®Six Months
• Replaces discontinued 1U-7260 Drift Punch
• Individually heat treated for uniform hardness
Set, 5 Piece
• Includes pouch
• Material: high carbon steel
Part Number
Point Size
Length
Description
227-3129
-
-
Drift Punch Set
Drift Punch Set Consists of:
227-3130
1/8in
203 mm (8 in)
Punch
227-3131
3/16 in
254 mm (10in)
Punch
227-3132
7/32 in
305mm(12.0in)
Punch
227-3133
1/4in
305mm(12.0in)
Punch
227-3134
5/16 in
305mm(12.0in)
Punch
Chisel Group, 5 Piece
Warranty: Caterpillar ®Six Months
• Individually heat-treated for uniform hardness
• Resharpened and polished after blasting for a
sharper cutting edge
• Includes pouch
Part Number
Punch Size
Length
Description
227-3795
-
-
Chisel Group
Chisel Group Consists of:
227-3796
5/16 in
127 mm (5 in)
Chisel
227-3797
3/8in
140mm (5.5in)
Chisel
227-3798
7/16 in
152 mm (6 in)
Chisel
227-3799
1/2in
152 mm (6 in)
Chisel
227-3800
5/8in
165mm (6.5in)
Chisel
17-112 JULY 2018 Hand Tools
Hand Tools
CHISELS AND PUNCHES
Chisels and Punch Pieces
Warranty: Caterpillar ®Lifetime unless otherwise
• Hot-formed from fine alloy steel and heat
noted
treated for maximum hardness - they hold
their edges and points
Item
Part No.
Punch Size
Length
Type
–
165-3977
4.95 mm (Warranty: Six Months)
154mm(6.06in)
Radius Punch
–
452-9936
13/32 in
139.7 mm (5.50 in)
Cold Chisel
–
1U-7296
3/16in (Warranty: SixMonths)
158.8 mm (6.25 in)
Center Punch
–
452-9937
5/32 in
203.2 mm (8.00 in)
Punch
–
8T-0832
1/4in
142.7 mm (5.63 in)
Cape Chisel
1
8H-8578
3/8in
241.3 mm (9.50 in)
Punch
2
452-9933
3/4in
177.8 mm (7.00 in)
Cold Chisel
3
452-9934
3/16 in
152.4 mm (6.00 in)
Center Punch
JULY 2018 Hand Tools
17-113
Hand Tools
PRY BARS
Handled Pry Bars
Warranty: Caterpillar ®Six Months
• Black chrome striking cap-hit bar without
• Ergonomic handle made from a dual
damage to handle
durometer composite for user comfort;
reduces hand fatigue
• Available in bar shank lengths of 30, 46, 61
and 91 cm (12, 18, 24 and 36 in)
• Long-life finish resists rust and wear during
use
• Polished tip with black oxide finish
Part No.
Description
Size
Handled Pry Bar Kit includes:
239-4140
-
239-4141, 239-4142 and 239-4143
239-4141
Handled Pry Bar
12 inch Handled Pry Bar, 30 cm (12 in)
239-4142
Handled Pry Bar
18 inch Handled Pry Bar, 46 cm (18 in)
239-4143
Handled Pry Bar
24 inch Handled Pry Bar, 61 cm (24 in)
239-4255
Handled Pry Bar
36 inch Handled Pry Bar, 91 cm (36 in)
Handled Pry Bar
Warranty: Caterpillar ®Six Months
• 12" handled pry bar
• Heated treated and precision forged steel
• Blade extends through handle to deliver
• Square blade
hammering force to the blade tip
• 5/8" wide tip
• A metal end cap prevents damage to the
handle
Part No.
Description
160-5119
Handles Pry Bar
Pry Bar Display
Warranty: Caterpillar ®Six Months
• Eye-catching addition to the sales floor area
• Display holds two 1U-7593, two 4C-5742, and
one 4C-5647 pry bars.
• Sturdy display measures only 406.4 mm x
457.2 mm (16 in x 18 in) at the base but its
• Pry bars purchased separately
1625.6 mm (64 in) high for extra visual impact
Part No.
Description
Size
244-0910
Pry Bar Display
406.4 mm x 457.2 mm (16 in x 18 in) at the base; 1625.6 mm (64 in) high
Pry Bars
Warranty: See Individual Parts
Part No.
Description
Size
194-3553
Rolling Head Pry Bar
304.8 mm (12.00 in)
194-3556
Rolling Head Pry Bar
533.4 mm (21.00 in)
1U-7587
Pry Bar, 6 in long (Warranty: Lifetime)
152.4 mm (6.00 in)
1U-7591
Pry Bar
457.2 mm (18.00 in)
1U-7592
Pry Bar
609.6 mm (24.00 in)
1U-7593
Pry Bar
762.0 mm (30.00 in)
4C-5647
Long Pry Bar
1371.6 mm (54.00 in)
4C-5742
Pry Bar
1168.4 mm (46.00 in)
5F-4764
Rolling Head Pry Bar, 40.64 cm (16 in)
406.4 mm (16.00 in)
9U-7968
Angled Push Bar
300mm(11.8in)
386-3305
Extra long (6 ft) pry bar (Fiberglass and Iron)
1842mm(72.5in)
342-9517
Indexable, Industrial Finish Pry Bar
203 mm (8in) length
268-1968
Indexable, Industrial Finish Pry Bar
305 mm (12in)length
17-114 JULY 2018 Hand Tools
Hand Tools
PRY BARS
Bead Braker Bar
Warranty: Caterpillar ®Six Months
• Used to break frozen or rusted beads
• 30 inches (762 mm)
• Lightweight and portable
• 7/8 inch stock
Part No.
Description
4F-5166
Bead Braker Bar
JULY 2018 Hand Tools
17-115
Hand Tools
CUTTING TOOLS
Utility Knife, Cat® Branded
Warranty: Caterpillar ® Materials and
• Lightweight aluminum handle with durable
• Sturdy locking liner ensures blade stays open
Workmanship for First Owner
anodized finish
during use
• Strong and, stiff stainless steel frame
• Pocket clip for convenient storage
Part No.
Description
Size
Quantity
542-5383
Utility Knife
-
1
4C-4871
Utility Knife Blades
0.635 mm (0.025 in)
100 blades per box
Utility Knife Blades
Warranty: Caterpillar ®Six Months
Part No.
Description
Size
Quantity
4C-4871
Utility Knife Blades
0.635 mm (0.025 in)
100 blades per box
Single Edge Razor Blades
• Industrial quality
• Fits all standard razor blade tools
• Ideal for scraping paint and glass, cutting, and
• Gauge: 0.009
trimming
Part No.
Description
Quantity
264-4353
Single Edge Razor Blades
100 blades per box
Hacksaws
Warranty: Caterpillar ®Lifetime unless otherwise
• 2 1/2-inch 420 high carbon stainless steel
• Nail mark
noted
spear blade
• Shackle
• 2 3/8-inch 1095 carbon steel screwdriver/
• Made in the USA
insulation cutter/wirescraper blade
Specifications
• Delrin handle
• 4.1 oz (116 g), 6-1/2 inch (16.5 cm)
Part No.
Description
Length
Use
Teeth
Material
Qty.
208-6183
Hacksaw
419.1 mm (16.50 in)
for use with 12 inch blade
-
-
-
Replacement Hacksaw Blade Sets
1U-9234
Replacement Hacksaw Blade Sets
305.0mm (12in)
-
457 mm (18in)
Bi-Metal
5
1U-9236
Replacement Hacksaw Blade Sets
305.0mm (12in)
-
610 mm (24in)
Bi-Metal
10
1U-9238
Replacement Hacksaw Blade Sets
305.0mm (12in)
-
813 mm (32in)
Bi-Metal
5
17-116 JULY 2018 Hand Tools
Hand Tools
CUTTINGTOOLS
Snips
Warranty: Caterpillar ®Six Months
• Maneuverable for angle cutting or pattern
• 1-1/8 in cutting edge
configurations
• Yellow handle
• Cuts up to 18 gage mild steel
• Straight cut
• Black oxide finish
Part No.
Description
Length
Weight
460-9919
Snap-on Aviation Snips
241mm (9.5in)
0.4 kg (14 oz)
File Set, 8 piece
Warranty: Manufacturer, 120 Day
• Files meet Federal Specification #GGG-F-325B
• Files and wood file handles can be ordered
separately
• Manufactured under ISO 9002 Certification
• Material: high carbon steel
Part No.
Description
264-0414
8 piece File Set
264-0414 consists of
263-9067
Aluminum File, 254 mm (10 in)
263-9069
Half Round Bastard File, 254 mm (10 in)
263-9070
Mill Bastard File, 203.2 mm (8 in)
263-9071
Round File, 4.8 mm (3/16) diameter x 203.2 mm (8 in)long
263-9072
Slim Taper File, 152.4 mm (6 in)
263-9074
Mill Bastard File, 152.4 mm (6 in)
Wood File Handle for file lengths between
263-9075
152.4 mm (6 in) to 203.2 mm (8 in)
Wood File Handle for file lengths between
263-9076
203.2 mm (8 in) to 254 mm (10 in)
Filter Cutter
Warranty: Caterpillar ®Six Months
• Used to cut open spin-on filters to inspect
• Heavy-duty double roller and cutting wheel
filter media for contaminants, a common
design eliminates binding of filters
practice when diagnosing potential machine
• All wear parts are heat-treated steel for
problems and internal contaminants.
added durability
• Aluminum frame construction
• Cutting wheels are ground with a double-
• Designed to cut all types of filters, including
taper edge for easier cutting
aircraft-style filters, without repositioning
cutting wheels
Item
Part Number
Description
Required
–
175-7546
Oil Filter Cutter Group
-
Replacement Parts
1
177-0364
Roller
2
2
177-0365
Cutting Wheel
2
3
177-0367
Pin
4
Not shown
177-0366
Spacer
2
Wire and Terminal Removal Tool
Model Usage: All
• Used to remove wire and terminal from
• Used to service Cat® fuse blocks using mini-
Rear Terminal ATC® Fuse Block (RTA), if
fuses (GM style)
Warranty: Manufacturer’s
replacement is necessary
• Replaces 197-7876
Part No.
Description
Dimensions
Weight
496-8187
Wire and Terminal Removal Tool
101.6 x 12.7 mm(4 x0.5in)
0.130 kg (0.286lb)
JULY 2018 Hand Tools
17-117
Hand Tools
CUTTING TOOLS
Tubing Cutters, Quick Release
Warranty: Caterpillar ®Lifetime except part
• Offer the best tracking and easiest cutting
• With a quick wheel change, they also cut a
4C-6979
available anywhere
wide variety of plastic pipe and tubing
• Cut copper, aluminum and steel tubing (not
steel pipe)
Wheelfor Copper,
Wheel for
Item
Part No.
O.D. Capacity
Length
Weight
Aluminum, Brass, Steel
Stainless Steel
3.0 mm - 33.0 mm
152 mm
0.2 kg
1
4C-6977
4C-6980
4C-6981
(.13 in - 1.31 in)
(5.98 in)
(0.44 lb)
6.0 mm - 60.0 mm
203 mm
0.5 kg
2
4C-6978
4C-6980
4C-6981
(.25 in - 2.63 in)
(7.99 in)
(1.10 lb)
10.0 mm - 90.0 mm
(.38 in - 3.50 in)
279 mm
1.1 kg
3
4C-6979
4C-6982
-
(Warranty: Six
(10.98 in)
(2.43 lb)
Months)
Level, Universal
Warranty: Caterpillar ®Six Months
• Made of high-impact ABS
• Has two easy-to-read Plexiglas vials, one a
vertical angle dial adjustable from 0° to 180°
Part No.
Description
9U-7329
Level, Universal
Protractor
Warranty: Caterpillar ®Six Months
• Quickly find angles
• 6 inches (15 cm) long
• Determine miter angle layout
• High-strength plastic with brass hardware
• Measure and transfer inside/outside sloped
angles
Part No.
Description
441-3703
Protractor
Angle Finder and Level
Warranty: Caterpillar ®Six Months
• Quickly identifies angles without interference
• Demarked 0 to 90 degrees in five quadrants
from cold, heat, or magnetic fields
• Ceramic magnetic base
Part No.
Description
437-4620
Angle Finder and Level
17-118 JULY 2018 Hand Tools
Hand Tools
LEVELS, MEASURING TOOLS AND GAUGES
Tape Measures
Warranty: Caterpillar ®Six Months
• Ergonomically designed
• Yellow and black plastic
• Magnetic tip holds tape in place and makes
• Auto retract
long distance measuring much easier
• Tape lock lever
Part No.
Blade Width
Blade Length
EnglishGraduations
Metric Graduations
1U-9366
19.0 mm (3/4 in)
16ft (5m)
1in, 1/16in
1.0 cm, 1.0 mm
1U-9367
25.4 mm (1 in)
26ft (8m)
1in, 1/16in
1.0 cm, 1.0 mm
1U-9368
25.4 mm (1 in)
30ft (9m)
1 ft, 1 in, 1/16 in
-
5P-3277
12.7 mm (1/2 in)
10ft (3m)
1in, 1/10in
1.0 cm, 1.0 mm
Tape Measure, Steel
Warranty: Caterpillar ®Six Months
• Heavy-duty vinyl covered welded steel case
• Graduation - inches in black, feet and
16 inch centers in red; meters in black,
• Yellow coated 3/8 inch wide blade, 2-color
centimeters and millimeters in red
markings, folded steel hook, folding handle
• English on one side, metric on the other side
Part No.
Blade Width
Blade Length
EnglishGraduations
Metric Graduations
1U-9369
3/8in
50
1 ft 1 in, 1/16 in
1.0 m, 1.0 cm, 1.0 mm
Straight Edge, 1000 mm
Warranty: Caterpillar ®Six Months
• 1000 mm dual scale: ½ mm and 1 mm
• Graduation type 36
increments
• Satin chrome finish with black markings
• 40 inch dual scale: 1/32 and 1/64
Part No.
Description
386-3364
Straight Edge,1000mm
JULY 2018 Hand Tools
17-119
Hand Tools
LEVELS, MEASURING TOOLS AND GAUGES
Taper Gauge
Warranty: Caterpillar ®Six Months
• Used to quickly and conveniently measure
• Made of quality tool steel
openings for shim packs or spacers
• One side graduated in inches, other side in
• Used in place of thickness gauges
millimeters
Part No.
Description
Size
4C-8733
Taper Gauge
6.20in x 0.40in (160 x 11.0 mm)
Block Magnet
Warranty: Caterpillar ®Six Months
• Used to quickly and conveniently measure
• Made of quality tool steel
openings for shim packs or spacers
• One side graduated in inches, other side in
• Used in place of thickness gauges
millimeters
Part No.
Description
Weight
Size
Block
4C-9798
0.166 kg (0.366 lbs)
25.0 mm x 25.0 mm x 50.0 mm (1.00in x1.00in x 2.00in)
Magnet
O-Ring Measuring Cone
Warranty: Manufacturer's 30 Days
• Find the correct O-ring replacement faster and
• Material: high-impact, yellow plastic
easier.
• Round base with five industry standard O-ring
• Designed to measure SAE industry standard
cross section diameters (widths) cut into the
O-ring dimensions (cross section and dash
edge
size). These dimensions are published by the
• Cone has 65 steps indicating varying inside
Society of Automotive Engineers (SAE).
diameters
• 457.2 mm (18 in) tall, cone shaped
Part No.
Description
9U-5155
O-Ring Measuring Cone
Check-A-Thread
Warranty: Caterpillar ®Six Months
• Quickly identify the most common size nuts
• Male threaded studs to identify nut sizes.
and bolts
• Mounts to the wall or sits on its built in stand
• Female
threaded holes to identify common
bolt sizes
Measure
Check-A-Thread Part Number
Inch
250-6865
Metric
250-6866
17-120 JULY 2018 Hand Tools
Hand Tools
LEVELS, MEASURING TOOLS AND GAUGES
Feeler Gauges
Warranty: Caterpillar ®Lifetime
Part No.
Description
Size
1U-7234
Feeler Gauge (Warranty: Six Months)
25 Blade, .0015 in - .040 in
386-3236
Feeler Stock Assortment
32 Blade, .0005 in - .030 in
8H-8581
Feeler Gauge
25 Blade, .0015 in - .025 in
Feeler Gauge Set, Dual Scale, 13-Blade
Warranty: Caterpillar ®Lifetime
• Stamped with both Metric and English sizes
• Metric sizes: 0.0254, 0.0381, 0.0508, 0.0762,
0.1016, 0.127, 0.1524, 0.1778, 0.2032, 0.254,
• English sizes: 0.001, 0.0015, 0.002, 0.003,
0.3048, 0.3302, 0.0381 mm
0.004, 0.005, 0.006, 0.007, 0.008, 0.010,
0.012, 0.013, 0.015 inch
Part No.
Description
383-8887
Dual Scale Feeler Gauge Set
Gauges for Checking Clearance
SMCS Code: 1000-082, 0700, 0701, 0714
• Used to quickly and easily check clearance
• Clearance thickness is determined by holding
between mating parts (main rod and bearing
crushed indicator material against paper
Models: All Engines or Clearance Between Any
clearance, component side clearance, oil
packaging (refer to illustration)
Mating Parts
pump cover to gear clearance, etc.)
• Any plastic residue on parts can be quickly
Warranty: Caterpillar ®Six Months
• Plastigage clearance indicator is an extruded
removed with component cleaner
plastic thread that crushes when clamped
• One indicator per package
between two mating parts
• Overall length: 30.0 cm (12.00 in)
• Available in four color-coded sizes for easy
• Plastic Material
identification
Part No.
Color
Clearance Range
198-9142
Green
0.025 to 0.076 mm (.001 to .003in)
198-9143
Red
0.051 to 0.152 mm (.002 to .006in)
198-9144
Blue
0.102 to 0.229 mm (.004 to .009in)
198-9145
Yellow
0.230 to 0.510 mm (.009 to .020in)
Hardness Tester
Warranty: Caterpillar ®Six Months
• Check crankshaft journal hardness
• Height of bounce read as Shore scleroscope
reading
• Hardened steel ball strikes tested surface
without damage
Reference
• 15 to 65 Rockwell C Scale
• SEBF8041 Guideline for Reusable Parts
Part No.
Description
6V-6035
Hardness Tester
JULY 2018 Hand Tools
17-121
Hand Tools
SEAL PICKS
Thread Pitch Gauges
Warranty: Caterpillar ®Six Months
• Quickly measure the pitch or lead of a bolt
thread
Part No.
Description
Size
386-3235
Metric
18 Leaves, 0.4 mm - 7.0 mm
386-3237
English
30 Leaves, 4 - 42 TPI (Threads Per Inch)
Seal Pick
Warranty: Caterpillar ®Six Months
• Used to remove and install all types of oil
• Blunt, hook end is used to align seals for
seals
installation and to eliminate the twist that
occurs when installing O-ring or quad-ring
• One end of pick is pointed for prying out
seals
flexible seals
• Both ends of the pick are hardened and
provide much greater strength than would
normally be expected from a tool this size
Part No.
Description
5P-1720
Seal Pick
Seal Pick Kit
Warranty: Caterpillar ®Lifetime
Part No.
Description
5P-7414
Seal Pick Kit
Seal Pick
Model Usage: All Hydraulic Cylinders
• Used to remove cylinder rod seals
• Large size allows faster and easier removal of
seals from large hydraulic cylinders
Warranty: Caterpillar ®Six Months
• Heavy-dutydesign
• Length: 262 mm (10 in)
Part No.
Description
195-4609
Seal Pick
17-122 JULY 2018 Hand Tools
Hand Tools
BRUSHES
Brushes, Scratch
Warranty: Caterpillar ®Six Months
• Hand scratch brushes are excellent for
• Provide long, effective service at extremely
removing rust, scale, old paint, chips and dirt,
low cost
and for cleaning castings and metal parts
Part No.
Description
Size
1U-9915
Curved Handle Brush
.014 in (3 x 19 Row)
1U-9916
Curved Handle Brush
.012 in (4 x 19 Row)
1U-9917
Shoe Handle Brush
.014 in (4 x 16 Row)
1U-9918
Inspection Stainless Brush
.006 in (3 x 7 Row)
Brushes, Corner Cleaner Wire
Warranty: Caterpillar ®Six Months
• Quickly removes flaking paint, rust, and scale
• Full size handle with finger grips and thumb
rest provides added control and comfort
• Handy small size with pointed end works well
in hard to reach areas
• Made of tough polypropylene
Part No.
Description
Length
160-0774
Brushes, Corner Cleaner Wire
254.0 mm (10.00 in)
Brushes, Longneck Wire
Warranty: Caterpillar ®Six Months
• Quickly removes flaking paint, rust, and scale
• Full size handle with finger grips and thumb
rest provides added control and comfort
• Handy small size with pointed end works well
in hard to reach areas
• Made of tough polypropylene
Part No.
Description
Dimensions
160-0772
Brushes, Longneck Wire
76.2 x 330.2 mm (3 x 13in)
Scrubber, Industrial Wire
Warranty: Caterpillar ®Six Months
• Quickly removes flaking paint, rust, and scale
• Dual grip design reduces fatigue - grasp
either the handle or specially molded block
• Made of tough polypropylene
Part No.
Description
Length
160-0775
Industrial Wire Scrubber
177.8 mm (7.00 in)
Brushes, Parts Cleaning
Warranty: Caterpillar ®Six Months
Item
Part No.
Description
Wire Size
Wire Row
1
1U-9920
11 in O.A.L.
Size #10
Black Polypropylene
2
1U-9919
11 in O.A.L.
Size #10
Tampico
3
2B-4317
10 3/4 in O.A.L.
Paint Style 1 1/2 in
Nylon
3
JULY 2018 Hand Tools
17-123
Hand Tools
BRUSHES
Brushes, Paint
Warranty: Manufacturer, 120 Day
• Use with interior or exterior paints, stains,
• 262-9752 not available in Australia, New
varnishes, and urethanes
Zealand, Republic of Fiji or Papua New Guinea
Part No.
Width x Length
Material
262-9749
25 mm x 178 mm (1 in x 7 in)
Nylon Brush, Metal Ferrule, Plastic Handle
262-9750
51 mm x 203 mm (2 in x 8 in)
Nylon Brush, Metal Ferrule, Plastic Handle
2• Quantity76 mm x 203 mm (3 in x 8 in)
HogBristle Brush, Metal Ferrule,Wood Handle
brushes
• Chemical resistant handle
Brushes, Acid
Warranty: Caterpillar ®Six Months
• Genuine horsehair bristles, crimped with flat
tin handle
Part No.
Description
Size
1U-9977
Acid Brush
3/8in
1U-9978
Acid Brush
1/2in
Brush, Battery Post
Warranty: Caterpillar ®Six Months
• Stiff wire bristles thoroughly clean posts
Part No.
Description
1U-9921
Battery Post Brush
17-124 JULY 2018 Hand Tools
Hand Tools
MISCELLANEOUSTOOLS
Rivet Sets
Warranty: Caterpillar ®Six Months
• Available for either "Star" set rivets or "Roll"
• "Roll" set rivets, marked with a circle on the
set rivets
head, should be used when clinching is done
against metal. To form a good clinch, there
• "Star" set rivets, identified by a star stamped
should be approximately 1/8 inch of rivet
in the head, should be used only where the
extension before the rivet is set.
clinching is done against a non-metallic
surface. To form a good clinch, there should
be approximately 3/16 inch of rivet extension
before the rivet is set.
Item
Part No.
Description
–
6V-7013
Roll Set (for 5/32 in rivets)
1
1P-2874
Roll Set (for 1/4 in rivets)
2
6F-6947
Star Set
3
6F-6946
Roll Set (for 3/16 in rivets)
Riveter Kit
SMCSCode: 4054
• Used for miscellaneous repairs requiring
• Comes with three different nose pieces
rivets
Model Usage: M312 Wheeled Excavators
Part No.
Description
Length
Warranty: Caterpillar ®Lifetime
129-1063
Riveter Kit
53.0 cm (21.0in)
Shovels and Spades, Nupla Ergo-Power
Warranty: Manufacturer's Limited Lifetime:
• Stronger than wood, built to last
• Mold injected protective covering over a
wendy@jmindsupply.com or 309-546-3323
Classic Nuplaglas handle
• Industrial grade steel blades
• Made in USA
Item
Part No.
Description
1
555-7125
Shovel, Round Point with 122 cm (48 in) long handle
2
555-7126
Spade, Drain with 122 cm (48 in) long handle
3
555-7127
Shovel, Square with 122 cm (48 in) long handle
4
555-7128
Scoop, # 12 Aluminum
5
555-7129
Spade, Drain with 69 cm (27 in) D handle
6
555-7130
Shovel, Square Point with 69 cm (27 in) D handle
7
555-7131
Shovel, Round Point with 69 cm (27 in) D handle
1
2
3
4
5
6
7
Pickup Tools
Warranty: Caterpillar ®Lifetime
Item
Part Number
Description
1
1U-7262
Magnet
2
146-2728
Flex Pickup Tool
JULY 2018 Hand Tools
17-125
Hand Tools
MISCELLANEOUS TOOLS
Inspection Mirror
Warranty: Caterpillar ®Six Months
• The mirror extends to 15 1/4 in long
• The mirror swivels 360 degrees
Part No.
Description
9U-6182
Inspection Mirror
Scraper
Warranty: Caterpillar ®Six Months
Part No.
Description
8H-8580
Scraper
Filter and Plug Removal and Installation Tools
Warranty: Caterpillar ®Lifetime unless otherwise
• Used to remove and install drain and fill plugs
• Most hexagonal plugs can also be removed
noted
and installed using the 213-1985 Sliding
T-Handle and 8H-8561 Socket
Item
Part No.
Description
1
1S-2475
Wrench, 3/4 in square (Warranty: Six Months)
2
8H-8559
Socket Extension
3
213-1985
Sliding T-Handle
4
212-8145
Drain Plug Socket (Warranty: SixMonths)
5
212-8146
Drain Plug Socket, 1/2in Female, 1in and 1 1/2in Hex (Warranty: Six Months)
6
185-3630
Filter Strap Wrench Assm. (Warranty: Six Months)
Cab Glass Installation Tools
Warranty: Caterpillar ®Six Months
• For installing the filler strips around the glass
in cabs
Part No.
Description
4C-9946
Filler Strip Tool Assembly
5H-4845
Seal Installation Tool Assembly
Caulker, Superior E-Z Thrust
Warranty: Caterpillar ®Six Months
• Holds any 12 oz. tube designed for use with a
• Recommended for all grades of caulks,
caulking gun
sealants and adhesives from heavy to light
consistencies
Part No.
Description
Cartridge Size
4C-6922
E-Z Thrust Caulker
0.01 gal
17-126 JULY 2018 Hand Tools
Hand Tools
MISCELLANEOUSTOOLS
Caulker, Super Ratchet-Type
Warranty: Caterpillar ®Six Months
• Designed for the professionals who prefer
• Engineered to withstand heavy use
ratchet guns
• Equipped with ladder hook, built-in spout
cutter, seal puncture tool, and convenient "D"
ring and wrist strap
• Will outlast,
Part No.
Description
Cartridge Size
4C-6923
Super Ratchet-Type Caulker
1/10 gal
outperform all other ratchet guns
Saw Blades (BIM)
Warranty: Manufacturer, 120 Day
Part No.
Length
Teeth
Package Qty
Teeth Specs
Raker BIM(All purpose blade, highly
1U-9234
305.0mm (12in)
457 mm (18in)
5
flexible, for the most difficult materials)
1U-9236
305.0mm (12in)
610 mm (24in)
10
Wavy BIM
1U-9238
305.0mm (12in)
813 mm (32in)
5
Wavy BIM
Saw Blades, Bi-Metal All-Purpose Tiger
Warranty: Caterpillar ®Six Months
Part No.
Length
Teeth/Inch
Package Qty
Recommended Use
152 mm (6in),
Heavy gauge (non-ferrous metals)— bar and angle
4C-9942
18
5
flexible
stock-stainless- galvanized pipe-tubing (over 18 ga.)
152 mm (6in),
Heavy gauge (non-ferrous metals)— bar and angle
4C-9943
14
5
flexible
stock-cast alumi- num-copper-brass-galvanized
4C-9944
229 mm (9 in)
5/7
5
General roughing-in wood
4C-9945
305mm(12in)
6
5
General roughing-in wood
Zip-Tie Gun
Model Usage: All Cat® Products
• Used to tighten the 204-2281 plastic tie strap
• Replaceable blade available (490-6593)
tensions cable ties (0.10” to 0.50” wide)
Warranty: Manufacturer’s
• For plastic zip ties only
• Padded foam-grip handle
Reference
• Handles cable ties up to 250 lb tensile
• NEHS1243-00 Tool Operating Manual
strength
Part No.
Description
326-8203
Zip-Tie Gun
Trim Pad Removal Tool
Warranty: Manufacturer’s Lifetime
• Used to remove the plastic clips that hold
WARRANTY INFORMATION
interior cab panels in place
1-262-656-6168 OR TFR@SNAPON.COM
• This tool allows technicians to easily remove
clips and interior panels during service work
without damaging clips or panels.
Part No.
Description
Dimensions
Weight
493-6875
Trim Pad Removal Tool
190 mm (7.5 in) OAL
0.1 kg (3.4 oz)
JULY 2018 Hand Tools
17-127
Hand Tools
TOOL BOXES AND CASES
Terminal Tool Group
Warranty: Caterpillar ®Six Months
• Tools set for most domestic computer
• Individual handles for easy access in tight
connectors and terminals
spaces
• Designed for weather pack and pack-con
• Storage case
terminals with flat blade to open connectors
and fork for ALDL connectors to access
trouble codes
Part Number
Description
435-5074
Terminal Tool Group
Kit Includes:
GM C3 System Terminal Tools (red handle)
Spring Loaded Tube
1/8 x 1in (3.3mm x 28mm)
Square Blade
1/16 x 3/4 in (1.4 x 19 mm)
Flat Blade
1/16 x 1 in (1.5 x 24.75 mm)
Flat Blade
5/64 x 1 in (2 x 23 mm)
Fork Blade
5/16 x 1 in (8 x 24 mm)
Flat Blade Screwdriver
3/16 x 1in (4.75 x 24mm)
Wire Terminal Tools (green handle)
Tube
1/8 x 1 in (3.3 x 28 mm)
Tube
11/64 x 1/2 in (4.3 x 13 mm)
Tube
5/32 x 1/2 in (3.75 x 13 mm)
Tube
1/8 x 1/2in (3 x 13mm)
Flat Twin Blade
1/8in (3 mm)
Twin Blade
1/16 in (1.6 mm)
Steering Wheel Puller and Lock Plate Depressor Set
Warranty: Caterpillar ®Lifetime
• Includes a selection of bolts and handle in a
• Detachable handle helps hold puller when
plastic storage case
turning force is applied to pressure screw
• Adaptors are included for servicing lock plates
• Industrial finish
onvehicles with tilt wheels
Part Number
Description
145-5242
Steering Wheel Puller and Lock Plate Depressor Set
17-128 JULY 2018 Hand Tools
Hand Tools
TOOL BOXES AND CASES
Tool Chest, Cat® Heavy-Duty Road Chest and Cover
Warranty: Tool Chest- Manufacturer’s Lifetime;
Cat® Heavy-Duty Road Tool Chest
• Deep, narrow drawers and top compartment
Tool Chest Cover- Manufacturer’s Free From
provide ample storage for power tools and
• Durable black finish
Defects in Material and Workmanship at the
deep sockets.
• 10 Drawers
Time of Sale to First User
• Full-width double-wall construction supports
• Load capacity: 204 kg (450 lb)
Contact catwarranty@snapon.com
loaded drawers.
or 855-351-0926.
• Cubic Inches: 8,187 in (134,160 cm)
• Full length, two-point lock rod for added
• Constructed of Class-1 heavy-gauge steel for
security
extra durability
Cat® Heavy-Duty Road Tool Chest Cover
• Wide side walls have additional corner
• Protects the Cat® heavy-duty road chest from
gussets for added strength.
the elements
• Heavy-duty hinged front cover provides easy
• Constructed of black, 600D PVC-coated
access to tools.
polyester
• Water- and UV-resistant
Part No.
Description
Dimensions (W x D x H)
Weight
483-0652
Cat® Heavy-DutyRoad ToolChest
791 x 548 x 516 (31 x 21 x 20 in)
81 kg (178 lb)
521-7664
Cat® Heavy-Duty Road Tool Chest Cover
838 x 533 x 533 (33 x 21 x 21 in)
0.249 kg (0.55lb)
Tool Boxes, Cat® Branded
Warranty: Caterpillar ®Lifetime
• Ready to work and stand up to every day use.
• Aluminum protective corners
• High- quality boxes with a lifetime warranty
• Heavy-duty casters
on manufacturing defects
• All drawers have ball bearing slides with the
• Double-wall construction
two bottom 6-inch drawers having double
slides.
• High security locks
• 12-drawer design with drawer mats
• Full extension slides
• Reinforced bottom channels
Specifications
• Integrated latch security system on all
• 53 inches long, 43 inches high, and 18 inches
drawers
deep
Part Number
Description
482-9899
Cat® Tool Box, Red
482-9900
Cat® Tool Box, Black
JULY 2018 Hand Tools
17-129
Hand Tools
TOOL BOXES AND CASES
Cat® 55-Inch Tool Box
Warranty: Caterpillar ®Lifetime
• Heavy-duty welded construction
• Top drawer of the roller cabinet is a full width
drawer with two slides and four welded
• Full-length double walls
drawer supports to hold up to 250 pounds
• Steel gusset reinforced corners
Bottom drawer of the roller cabinet has two
•
• Multiple applications of powder coat paint
slides to hold up to 250 pounds
• Soft, durable wheels reduce vibration and last
• Upgraded drawer pads
a lifetime
55-Inch Roller Cabinets
• Two banks of drawers - 70/30 split
• 11 Drawers
• Long-lasting ball bearing drawer slides
• Dimensions: 55" W x 24" D x 39" H (140 cm W
• Lock 'n Roll drawers keeps them secure during
x 61 cm D x 99 cm H)
movement
• Volume: 25,000 cubic inches (409,675 cm³)
• Each drawer holds up to 125 pounds
• Surface Area: 6,300 square inches (40,645
• Doubled over drawer edges make them
cm²)
smooth and rigid
• Capacity: 2,400 lbs (1,089 kg)
• Deep, comfortable drawer pulls
Part No.
Description
385-1731
Cat®55-Inch Tool Box, Black
Tool Boxes, Cat® 40-Inch
Warranty: Caterpillar ®Lifetime
• Heavy-duty welded construction
40-Inch Top Chests
• Full-length double walls
• 4 Drawers
• 1 Top Storage Compartment
• Steel gusset reinforced corners
• Dimensions: 40" W x 20" D x 19" H (101 cm W
• Multiple applications of powder coat paint
x 51 cm D x 50 cm H)
• Long-lasting ball bearing drawer slides
• Volume: 9,800 cubic inches (160,593 cm³)
• Surface Area: 3,200 square inches (20,645
• Lock 'n Roll drawers keeps them secure during
cm²)
movement
• Capacity: 1,400 lbs (635 kg)
• Each drawer holds up to 100 pounds
40-Inch Roller Cabinets
• Doubled over drawer edges make them
• 7 Drawers
smooth and rigid
• Dimensions: 40" W x 20" D x 38" H (101 cm W
• Deep, comfortable drawer pulls
x 51 cm D x 98 cm H)
• Volume: 15,000 cubic inches (245,805 cm³)
• Upgraded drawer pads
• Surface Area: 4,250 square inches (27,419
• Cat branded
cm²)
• Capacity: 2,400 lbs (1,089 kg)
Part No.
Description
385-1726
40-Inch Top Chest, Black
385-1727
40-Inch Roller Cabinet, Black
385-1728
40-Inch Top Chest, Red
385-1729
40-Inch Roller Cabinet, Red
17-130 JULY 2018 Hand Tools
JULY 2018 Hand Tools
17-130
