Geely Emgrand X7. Manual part - 464
Shoulder guide ring fixing nut of front row
safety belt
Inch 7/16
40-50
30-37
Upper fixing support of safety belt retractor
M6×15
8-10
6-8
9.3.2 Description and Operation
9.3.2.1 Description and operation
Seat belt
The front-row seats and the rear-row seats are both equipped with safety belts and these are the main means to
protect the passengers. The passenger can be kept in the passenger compartment via the safety belt with the
following conditions, and the impact force can be gradually reduced.
Face impact type
-
Rear impact type collision
-
Side impact type collision
-
Turnover type collision
All vehicles are equipped with an emergency locking retractor. Safety belt with self-lock function The locking
function is activated when quickly pulling the safety belt from the retractor completely. The locking function can
prevent the pull-out amplitude of the safety belt from exceeding the allowable rolling position.
Recommend to fix the child seat with the self-locking function. When the safety belt is completely rolled into the
emergency locking retractor, the function can be canceled. After the locking function is canceled, the safety belt is
unlocked. After the locking function is canceled, the safety belt can be pulled out from the retractor. This vehicle
is also equipped with an airbag system. See 9.2.2.1 Description and Operations in "Airbag System".
Seat safety belt warning lamp
The driver seat safety belt warning lamp and the passenger seat safety belt warning lamp are located on the
combination instrument and the multifunctional instrument displayer respectively to remind the client of wearing
the safety belt.
Child Seat Protection System
Warning: Do not use backward protective device for children on the passenger sear. When inflating the
passenger-side SRS, the child sitting in the backward protective device for children on the passenger seat
will be suffered fro severe injuries. If the forward protective device for children is applicable to your child,
make sure the front row of passenger chair moves backward as far as possible, and then install the
protective device for children. Ensure the position of the protective device for children does not conflict
with any additional requirements of the manufacturer. See the user manual of the automobile as well as the
user guide attached in the protective device for children for details.
Child seat can only be used for the forward seating position. The child seat should be installed and fixed according
to the guidance of the manufacturer. If the child seat is equipped with an upper strap, need to fix the seat. If the
safety belt on the seat is used for fixing the child seat, the seat shall not be allowed to sit.
1855
