Using the windshield and headlight wash-
ers (p. 177)

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 177)

•

Putting the wiper blades in service posi-
tion (p. 630)

•

•

•

Using the windshield wipers

The windshield wipers are designed to clean
the windshield. The right-side steering wheel
lever is used to adjust windshield wiper set-
tings.

Right-hand steering wheel lever.

The thumb wheel is used to set rain sen-
sor sensitivity and interval wiper speed.

Single sweep

Move the lever down and release for a
single sweep.

Wipers off

Move the lever to position

to turn off

the windshield wipers.

Interval wipers

Move the lever upward to put the wip-
ers in interval wiping mode. Set the

number of sweeps per time unit with the
thumb wheel when interval wipers are
selected.

Continuous wipers

Move the lever upward for the wipers
to operate at normal speed.

Move the lever upward again for the
wipers to operate at high speed.

Before activating the wipers, make sure
that the wiper blades are not frozen in
place and that any snow or ice on the
windshield has been scraped away.

Use plenty of washer fluid when the wipers
clean the windshield. The windshield must
be wet when the windshield wipers are
working.

Related information

•

Using the windshield and headlight wash-
ers (p. 177)

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 177)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

176

•

•

Putting the wiper blades in service posi-
tion (p. 630)

•

•

Using the rain sensor

The rain sensor monitors the amount of water
on the windshield and automatically starts
the windshield wipers. Rain sensor sensitivity
can be adjusted using the thumb wheel on
the right-hand steering wheel lever.

Right-hand steering wheel lever.

Rain sensor button

Thumb wheel, sensitivity/interval wiper
speed

When the rain sensor is activated, the
rain sensor symbol will be displayed in the
instrument panel.

Activating the rain sensor

When the rain sensor is activated, the engine
must be running or the ignition in mode

while the windshield wiper lever is in position

or in the single sweep position.

Activate the rain sensor by pressing the rain
sensor button

Move the lever downward for an extra wiper
sweep.

Turn the thumb wheel upward for increased
sensitivity and downward for decreased sensi-
tivity. The wipers will make one extra sweep
when the thumb wheel is turned upward.

Deactivate the rain sensor

Deactivate the rain sensor by pressing the

rain sensor button or moving the lever

upward to another wiper mode.

The rain sensor is automatically deactivated in
ignition mode

or when the engine is

switched off.

The rain sensor is also automatically deacti-
vated when the wiper blades are put in the
service position. The rain sensor will reactivate
when service mode is switched off.

Using the windshield and headlight wash-
ers (p. 177)

The windshield wipers may start inadver-
tently and be damaged in automatic car
washes. Deactivate the rain sensor when
the engine is running or when the ignition
is in mode

. The symbol in the instru-

ment panel will go out.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

177

Related information

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 177)

•

•

Putting the wiper blades in service posi-
tion (p. 630)

•

•

•

Activating and deactivating the

rain sensor's memory function

The rain sensor monitors the amount of water
on the windshield and automatically starts
the windshield wipers.

When the memory function is activated, the
rain sensor button does not need to be
pressed every time the vehicle is started:

1. Tap

Settings

in the center display's Top

view.

2. Tap

My Car

Wipers

3. Select

Rain Sensor Memory

to activate/

deactivate the memory function.

Related information

•

Using the windshield and headlight wash-
ers (p. 177)

•

•

•

Putting the wiper blades in service posi-
tion (p. 630)

•

•

•

Using the windshield and

headlight washers

The windshield and headlight washers are
designed to clean the windshield and head-
lights. Use the right-side steering wheel lever
to start the windshield and headlight wash-
ers.

Starting the windshield and headlight
washers

Washing function, right-hand steering wheel lever.

–

Move the right-hand steering wheel lever
toward the steering wheel to start the
windshield and headlight washers.
> After the lever is released, the wipers

make several extra sweeps.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

178

Avoid activating the washer system when
it is frozen or the fluid reservoir is empty.
Otherwise, there is a risk of damaging the
pump.

Headlight washer

To save washer fluid, the headlights are
washed automatically according to a defined
interval when the headlights are on.

Reduced washing

When there is about 1 liter (1 qt) of washer
fluid left in the reservoir and the

Washer fluid

Level low, refill

message is displayed in the

instrument panel together with the

sym-

bol, the washer fluid supply to the headlights
is cut off. This is to prioritize windshield clean-
ing and visibility through it. The headlights are
only washed if high or low beam is on.

Related information

•

•

Activating and deactivating the rain sen-
sor's memory function (p. 177)

•

•

Putting the wiper blades in service posi-
tion (p. 630)

•

•

•

Storing positions for seats, mirrors and
head-up display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

180

Manual front seats

The front seats can be adjusted in a number
of different ways to help enhance your seat-
ing comfort.

Raise/lower the front edge of the seat
cushion

by moving the control up/down.

Change the length of the seat cushion

pulling up the lever and moving the cush-
ion forward/backward.
Move the seat forward/backing by lifting
the handle and moving the seat to a suita-
ble distance from the steering wheel and
pedals. Check to make sure the seat is
securely locked into place after its setting
has been changed.
Adjust lumbar support

by pressing the

button up/down/forward/rearward.

Raise/lower the seat by moving the con-
trol up/down.
Change the backrest tilt by turning the
knob on the backrest.

WARNING

•

Do not adjust the seat while driving.
The seat should be adjusted so that the
brake pedal can be depressed fully. In
addition, position the seat as far rear-
ward as comfort and control allow.

•

Check that the seat is securely locked
into position after adjusting.

Related information

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Only applies to the driver's seat.

Applies for four-way lumbar support

. Two-way lumbar support

is adjusted forward/rearward.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

181

Power

front seats

The front seats can be adjusted in a number
of different ways to help enhance your seat-
ing comfort. The power seat can be moved
forward/backward and up/down. The height
and length

of the seat cushion and the tilt of

the backrest can be adjusted. Lumbar sup-
port

can be adjusted up, down, forward and

backward.

The seats can be adjusted when the engine is
running and for a certain period of time after
the door has been unlocked without the
engine running. They can also be adjusted for
a short period after the engine is turned off.

The power seats have an overload protec-
tor that is triggered if a seat is blocked by
any object. If this occurs, remove the
object and attempt to adjust the seat
again.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

Adjusting the power

front seats (p. 181)

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the power

front seats

Set the desired seating position using the
controls on the front seat cushion. To set the
convenience functions, turn the multifunction
control

upward/downward.

The illustration shows the controls in a vehicle with
four-way lumbar support

. Vehicles with two-way

lumbar support

do not have the rotary multifunction

control.

In vehicles with four-way lumbar support

turn the multifunction control

up/down to

set the convenience functions. In vehicles
with two-way lumbar support

, use the

round button to adjust the lumbar support
forward/rearward.
Raise/lower the front edge of the seat
cushion by moving the control up/down.

Applies for four-way lumbar support

. Two-way lumbar support

is adjusted forward/rearward.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

182

Raise/lower the seat by moving the con-
trol up/down.
Move the seat forward/rearward by mov-
ing the control forward/rearward.
Change the backrest tilt by moving the
control forward/backward.

Only one movement (forward/rearward/up/
down) can be performed at a time.

The front seat backrests cannot be folded
down completely.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

Power

front seats (p. 181)

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Storing positions for seats, mirrors

and head-up display

Adjustment settings for the power

seat, door

mirrors and head-up display

can be stored in

the memory buttons.

Two different positions for the power

seat,

door mirrors and head-up display

can be

stored using the memory buttons. The buttons
are located on the inside of either one or both

front doors.

Button

for storing a setting.

Memory button.

Not available in vehicles with two-way lumbar support

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

183

Storing positions

1. Adjust the seat, door mirrors and head-up

display to the desired position.

2. Press and hold the

button. The indica-

tor light in the button will illuminate.

3. Within three seconds, press and hold the

button.

> When the position has been stored in

the memory button, an audio signal will
sound and the indicator light in the

button will go out.

If none of the memory buttons are pressed
within three seconds, the

button will go out

and no position will be stored.

The seats, door mirrors or head-up display
must be readjusted before a new memory
position can be set.

For the stored positions to work, all driver
profiles need to be in

Protect Profile

mode.

Related information

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the door mirrors (p. 169)

•

•

Head-up display settings

(p. 142)

•

Protecting a driver profile (p. 136)

Using stored positions for seats,

mirrors and head-up display

If the positions for the power

seat, door mir-

rors and head-up display

have been stored,

they can be activated using the memory but-
tons.

Using a stored position

A stored position can be used with the front
door open or closed:

Front door open

–

Briefly press one of the memory buttons

(

) or

(

). The power seats, door mir-

rors and head-up display will move and
stop at the positions stored in that button.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

184

Front door closed

–

Press and hold one of the memory buttons

(

) or

(

) until the seat, door mirrors

and head-up display stop in the positions
stored in that memory button.

If the memory button is released, the seat,
door mirrors and head-up display will stop
moving.

WARNING

•

This list point needs to be translated
exactly to: "Because the driver's seat
can be adjusted with the ignition off,
children should never be left unatten-
ded in the vehicle.

•

Movement of the seat can be STOP-
PED at any time by pressing any but-
ton on the power seat control panel.

•

Do not adjust the seat while driving.

•

The seat should be adjusted so that the
brake pedal can be depressed fully. In
addition, position the seat as far rear-
ward as comfort and control allow.

•

The seat rails on the floor must not be
obstructed in any way when the seat is
in motion.

For the stored positions to work, all driver
profiles need to be in

Protect Profile

mode.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the door mirrors (p. 169)

•

•

Head-up display settings

(p. 142)

Front seat massage

settings

The settings for the multifunctional seats can
be adjusted using either the mutifunction
control on the side of the seat or the center
display. The adjustment settings are shown in
the center display.

Multifunction control, located on the side of the seat

cushion.

Massage settings

The following massage settings are available:

•

Off

: Select

Off

to turn on/off the

massage function.

•

Programs 1-5

: There are 5 preset mas-

sage programs. Select

Swell

Tread

Advanced

Lumbar

Shoulder

•

Intensity

: Select

Low

Normal

High

•

Speed

: Select

Slow

Normal

Fast

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

185

Restarting the massage function

The massage function turns off automatically
after 20 minutes. The function is reactivated
manually.

–

Tap

Restart

, which is displayed in the

center display, to restart the selected mas-
sage program.
> The massage program will restart. If no

selection is made, the message will be
stored in Top view.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting front seat massage

settings

The settings for the multifunctional seats can
be adjusted using either the mutifunction
control on the seat or the center display. The
adjustment settings are shown in the center
display.

Adjusting front seat massage settings

The front seat backrests have a massage func-
tion. Air-filled cushions provide the massaging
action and a number of settings are available.

The massage function can only be activated
when the engine is running.

1. Activate the multifunction control by turn-

ing the control

upward/downward. The

seat settings view will appear in the center
display.

2. Select

Massage

in the seat settings view.

3. Select massage settings by tapping the

center display or by moving the cursor up/
down using the multifunction control's
upper

/lower

buttons. Change a set-

ting in the selected function by tapping
the arrows on the center display or by
using the multifunction control's front

rear

buttons.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

186

Adjusting

front seat cushion

length

Depending on the selected equipment level,
the length of the seat cushion can either be
adjusted using the multifunction control

the side of the seat cushion, or manually
adjusted using the control on the front of the
seat cushion.

Adjusting seat cushion length using
the multifunction control

The multifunction control, located on the side of the

seat cushion.

1. Activate the multifunction control by turn-

ing the control

upward/downward. The

seat settings view will appear in the center
display.

2. Select

Cushion extension

in the seat set-

tings view.

•

Push in the front part of the four-way
button

to extend the seat cushion.

•

Press the rear part of the four-way but-
ton

to shorten the seat cushion.

Manually adjusting seat cushion
length

Control for adjusting seat cushion.

1. Grasp the

handle on the front of the

seat and pull upward.

2. Adjust the length of the seat cushion.

3. Release the handle and make sure the

seat cushion locks into position.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

187

Adjusting front seat side bolster

settings

Enhance comfort in the front seat by adjust-
ing the sides of the backrest.

The multifunction control is located on the side of the

seat cushion.

The side bolsters in the front seat backrests
can be inflated/deflated to adjust the amount
of support provided. The settings for the multi-
functional seats can be adjusted using either
the mutifunction control on the seat or the
center display. The adjustment settings are
shown in the center display.

To adjust the side bolsters:

1. Activate the multifunction control by turn-

ing it upward/downward

. The seat set-

tings view will appear in the center dis-
play.

2. Select

Side bolsters

in the seat settings

view.

•

Press the front part of the four-way but-
ton to increase side bolster support

•

Press the rear part of the four-way but-
ton to decrease side bolster support

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting front seat lumbar

support

Use the control on the side of the seat cush-
ion to adjust the lumbar support.

Multifunction control, in vehicles with four-way lum-
bar support

Control in vehicles with two-way lumbar support

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

188

Lumbar support is adjusted using the multi-
function control in vehicles with four-way lum-
bar support

, or the round button in vehicles

with two-way lumbar support

. The control is

located on the side of the seat cushion.
Depending on the selected equipment level,
the lumbar support can be adjusted forward/
rearward and up/down (four-way lumbar sup-
port) or forward/backward (two-way lumbar
support).

Adjusting lumbar support in vehicles
with four-way lumbar support

1. Activate the multifunction control by turn-

ing the control

upward/downward. The

seat settings view will appear in the center
display.

2. Select

Lumbar

in the seat settings view.

•

Press the round button up

/down

to move the lumbar support upward/
downward.

•

Press the front part

of the button to

increase lumbar support.

•

Press the rear part

of the button to

decrease lumbar support.

Adjusting lumbar support in vehicles
with two-way lumbar support

1. Press the front part

of the round button

to increase lumbar support.

2. Press the rear part

of the round button

to decrease lumbar support.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

189

Adjusting the passenger seat from

the driver's seat

The front passenger seat can be adjusted
from the driver's seat.

Activating the function

The function is activated via the function view
in the center display:

Tap the

Adjust Passenger

Seat

button to activate.

Adjust passenger seat

The driver must adjust the passenger seat
within 10 seconds of activating the function. If
no adjustment is made within this time, the
function will be deactivated.

The driver adjusts the passenger seat using
the controls on the driver's seat:

Move the passenger seat forward/rear-
ward by moving the control forward/rear-
ward.
Change the backrest tilt of the passenger
seat by moving the control forward/back-
ward.

Related information

•

Storing positions for seats, mirrors and
head-up display

•

•

•

Using stored positions for seats, mirrors
and head-up display

•

•

•

•

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

190

Folding down the rear seat

backrests

The rear seat backrest is split into two sec-
tions. The two sections can be folded forward
individually.

WARNING

•

Adjust the seat and ensure it locks into
position before driving. Use caution
when adjusting the seat. Uncontrolled
or careless adjustments could lead to
injury.

•

Long objects must always be securely
tied down to help prevent injury or
damage in the event of sudden brak-
ing.

•

Always turn off the engine and apply
the parking brake when loading or
unloading the vehicle.

•

Put the gear selector in

to help pre-

vent the gear selector from being inad-
vertently moved.

When the backrest is folded down, make
sure there are no objects in the rear seat,
and the seat belts are not buckled. Other-
wise there is a risk of damage to the
upholstery.

The armrest

in the center seat must be

raised before the seat backrest is folded
down.

The ski hatch

must be closed before the

seat backrest is folded down.

The rear seat must be in the upright posi-
tion when private locking is activated in
order for the seats to lock. Seats in the
folded-down position will not lock.
