LIGHTING

* Option/accessory.

158

•

Active Bending Lights

*

 (p. 156)

•

Adjusting light functions via the center
display (p. 151)

Rear fog light

The rear fog light is considerably brighter
than ordinary taillights and should only be
used to help other road users see the vehicle
when visibility is reduced by conditions such
as fog, snow, smoke or dust.

Rear fog light button.

The fog lights are located on the right and left
sides of the rear of the vehicle.

The rear fog light can only be switched on
when the ignition is in

II

 mode and the lighting

ring is in position

 or

.

Press the button to switch on/off. The
symbol in the instrument panel illuminates
when the rear fog light is on.

The rear fog light turns off automatically when
the ignition is switched off or when the steer-

ing wheel lever lighting ring is in position

 or

.

NOTE

Regulations concerning rear fog light use
vary from country to country.

Related information

•

Lighting control and panel (p. 150)

•

Front fog lights/corner illumination

*

(p. 157)

•

Ignition modes (p. 411)

LIGHTING

159

Brake lights

The brake lights are automatically illuminated
when braking.

The brake lights are illuminated when the
brake pedal is depressed and when the brakes
are automatically applied by a driver support
system.

Related information

•

Emergency brake lights (p. 159)

•

Brake functions (p. 413)

•

Driver support systems (p. 264)

Emergency brake lights

The emergency brake lights are activated to
warn following vehicles of hard braking.

This function causes an additional taillight on
each side of the vehicle to illuminate.

The emergency brake lights are activated in
the event of hard braking or if the ABS system
is activated and the vehicle is traveling at a
high speed.

After the driver decelerates to a low speed and
then releases the brake, the brake lights
resume their normal brightness.

Related information

•

Brake lights (p. 159)

•

Brakes (p. 413)

•

Hazard warning flashers (p. 159)

Hazard warning flashers

Hazard warning flashers warn other road
users by all of the vehicle's turn signals being
activated at the same time. The function can
be used to warn about a traffic hazard.

Hazard warning flashers button.

Press the button to activate the hazard warn-
ing flashers.

NOTE

Regulations concerning the use of hazard
warning flashers may vary from country to
country.

Related information

•

Emergency brake lights (p. 159)

•

Using turn signals (p. 156)

LIGHTING

* Option/accessory.

160

Using home safe lighting

Some of the exterior lights remain on to illu-
minate the area around the vehicle. This is
called home safe lighting.

To activate home safe lighting:

1. Switch off the ignition.

2. Push the left-side steering wheel lever

toward the dashboard and release.

3. Exit the vehicle and lock the doors.

> A symbol in the instrument panel illumi-

nates to indicate that the function is
activated and exterior lighting switches
on: Parking lights, headlights, license
plate lighting and outer door handle
lighting

*

.

The length of time home safe lighting remains
illuminated can be set in the center display.

Related information

•

Adjusting light functions via the center
display (p. 151)

•

Welcome Light (p. 160)

Welcome Light

Approach lighting is activated when the vehi-
cle is unlocked and can be used to provide
light as you walk toward the vehicle.

The function is activated when the remote key
is used for unlocking. The parking lights, ceil-
ing lights, footwell lights and trunk/cargo
compartment lights are activated in daylight
conditions. In weak daylight or dark condi-
tions, the license plate lighting and outer door
handle lighting

*

 will also be activated, with the

light directed toward the ground.

If no door is opened, the lights will remain illu-
minated for approx. 2 minutes. If a door is
opened while the function is activated, the
interior lighting and outer door handle lighting

*

will remain on for a longer period of time.

This function can be activated and deactivated
in the center display.

Related information

•

Adjusting light functions via the center
display (p. 151)

•

Using home safe lighting (p. 160)

•

Remote key (p. 234)

Interior Lighting

The passenger compartment is equipped
with several different types of lighting, e.g.
general lighting, adjustable ambient lighting
and reading lights.

All lighting in the passenger compartment can
be turned on and off manually within
5 minutes after:

•

the engine has been switched off and the
ignition is in mode

0

.

•

the vehicle is unlocked but has not been
started.

Front ceiling lighting

The controls in the ceiling console for the front read-

ing lights and courtesy lighting.

Reading light left side

Passenger compartment lighting

LIGHTING

}}

* Option/accessory.

161

Courtesy lighting auto switch

Reading light right side

Reading lights

The reading lights on the right and left sides
are switched on and off by briefly pressing the
buttons in the ceiling console. To adjust the
brightness, press and hold the button.

Passenger compartment lighting

Briefly press the button in the ceiling console
to switch on or off the footwell lighting and
ceiling lighting.

Courtesy lighting auto switch

Activate the auto switch by briefly pressing
the

AUTO

 button in the ceiling console. With

Auto activated, the indicator light in the button
and the courtesy lighting come on and are
turned off as follows.

Courtesy lighting is switched on when:

•

The vehicle is unlocked

•

The vehicle is switched off

•

A side door is opened.

Courtesy lighting is switched off when:

•

The vehicle is locked

•

The engine is started

•

A side door is closed

•

A side door has been open for approx.
2 minutes.

Rear roof lighting

Reading lights are located in the rear section
of the vehicle and can also be used as passen-
ger compartment lighting.

Reading lights over the rear seat.

In vehicles with panoramic roofs

*

, there are two lamp

units, one on each side of the ceiling.

Briefly press the button on the light to turn on
or off the reading lights. To adjust the bright-
ness, press and hold the button.

Glove compartment lighting

The glove compartment lighting comes on or
goes off when the glove compartment is
opened or closed.

Vanity mirror lighting

*

The vanity mirror lighting comes on or goes off
when the cover over the mirror is opened or
closed.

Ground lighting

*

The ground lighting comes on or goes off
when a door is opened or closed.

Doorsill lighting

The doorsill lighting comes on or goes off
when a door is opened or closed.

Trunk lighting

The trunk lighting comes on or goes off when
the trunk lid is opened or closed.

Ambient Lighting

The ambient lighting comes on when the
doors are opened and goes out when the vehi-
cle is locked. Ambient lighting brightness can
be adjusted in the center display and also fine-
tuned using the thumb wheel in the dash-
board.

||

LIGHTING

* Option/accessory.

162

Mood lighting

*

The vehicle is equipped with LEDs that pro-
vide faint lighting in various colors. This light-
ing is on when the engine is running. Mood
lighting can be adjusted in the center display
and also fine-tuned using the thumb wheel in
the dashboard.

Lighting in the door storage
compartments

Lighting in the door storage compartments
comes on when the doors are opened and
goes out when the vehicle is locked. The
brightness can be adjusted using the thumb
wheel in the dashboard.

Lighting in the tunnel console's front
cup holder

The lighting in front console cup holders
switches on when the vehicle is unlocked and
off when the vehicle is locked. The brightness
can be adjusted using the thumb wheel in the
dashboard.

Related information

•

Adjusting interior lighting (p. 162)

•

Lighting control and panel (p. 150)

•

Ignition modes (p. 411)

•

Passenger compartment interior (p. 562)

Adjusting interior lighting

Illumination in the vehicle varies depending
on ignition mode. The interior lighting can be
adjusted with a thumb wheel in the dash-
board and certain light functions can also be
adjusted via the center display.

The thumb wheel on the
dashboard to the left of the
steering wheel can be used
to adjust the brightness of
the display lighting, instru-
ment lighting, ambient light-
ing and mood lighting

*

.

Adjust ambient decor lighting

1. Tap

Settings

 in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

.

3. Choose from among the following set-

tings:

•

Under

Ambient Light Intensity

, select

Off

,

Low

 or

High

.

•

Under

Ambient Light Level

, select

Reduced

 or

Full

.

Adjusting mood lighting

*

The vehicle is equipped with several LEDs that
provide faint lighting in various colors. This
lighting is on when the engine is running.

Changing the brightness

1. Tap

Settings

 in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

Interior Mood

Lighting

.

3. Under

Interior Mood Light Intensity

,

select

Off

,

Low

 or

High

.

Changing the color of the light

1. Tap

Settings

 in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

Interior Mood

Lighting

.

3. Choose

By Temperature

 or

By Color

 to

change the color of the light.

If

By Temperature

 is selected, the light

will change according to the temperature
set for the passenger compartment.

If

By Color

 is selected, the subcategory

Theme Colors

 can be used to make fur-

ther adjustments.

Related information

•

Interior Lighting (p. 160)

•

Adjusting light functions via the center
display (p. 151)

•

Ignition modes (p. 411)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

164

Windows, glass and mirrors

The vehicle is equipped with several different
types of windows, glass and mirrors. Some of
the windows in the car are laminated.

The windshield has laminated glass. Lamina-
ted glass is also available as on option for
some other glass surfaces. Laminated glass is
reinforced, which provides better protection
against break-ins and improved soundproofing
in the passenger compartment.

The panoramic roof

*

 also has laminated glass.

The symbol shows the windows containing lamina-
ted glass.

1

Related information

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Panoramic roof

*

 (p. 171)

•

Power windows (p. 166)

•

Rearview/door mirrors (p. 168)

•

Using sun curtains

*

 (p. 168)

•

Head-up display

*

 (p. 140)

•

Using the windshield wipers (p. 175)

•

Using the windshield and headlight wash-
ers (p. 177)

•

Activating and deactivating the heated
rear window and door mirrors (p. 215)

Pinch protection for windows and

sun curtains

All power windows and sun curtains

*

 have a

pinch protection function that is triggered if
anything blocks them while they are opening
or closing.

If pinch protection is activated, movement will
stop and then retract automatically to approx.
50 mm (2 inches) from the point at which it
was blocked (or to full ventilation position).

It is still possible to override pinch protection
when closing is interrupted (e.g. due to ice) by
pressing and holding down the control in the
same direction.

If there is any problem with the pinch protec-
tion, a rest procedure can be tested.

WARNING

If the starter battery is disconnected, the

function for automatic opening and closing

must be reset to function correctly. A reset

is required in order for the pinch protection

to work.

Related information

•

Reset procedure for pinch protection
(p. 165)

•

Operating the power windows (p. 166)

1

Does not apply to windshield and panoramic roof

*

, which are always laminated and therefore do not have this symbol.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

165

•

Using sun curtains

*

 (p. 168)

•

Operating the panoramic roof

*

 (p. 172)

Reset procedure for pinch

protection

If you experience any problems with the elec-
trical functions for the power windows, you
can try to perform a reset.

WARNING

If the starter battery is disconnected, the

function for automatic opening and closing

must be reset to function correctly. A reset

is required in order for the pinch protection

to work.

Consult a workshop if you experience any
problems with the panoramic roof.

2

Resetting a power window

1. Start with the window in the closed posi-

tion.

2. Then move the control in manual mode

three times upward toward the closed
position.
> The system will be automatically acti-

vated.

If the problem persists, contact a workshop.

Related information

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Operating the power windows (p. 166)

•

Using sun curtains

*

 (p. 168)

2

An authorized Volvo workshop is recommended.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

166

Power windows

Every door has a control panel for the power
windows. The driver's door has controls for
operating all windows and for activating the
child safety locks.

Driver's door control panel.

Electric child safety locks

*

 that deactivate

the controls in the rear doors to prevent
the doors or windows from being opened
from the inside.
Rear window controls.

Front window controls.

WARNING

Children, other passengers or objects can

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the
vehicle's electrical system to ignition
mode

0

 and then taking the key with

you when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehi-
cle electrical system is completely
turned off.

Related information

•

Operating the power windows (p. 166)

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Reset procedure for pinch protection
(p. 165)

Operating the power windows

All power windows can be operated using the
control panel in the driver's door. The control
panels in the other doors can be used to
operate that particular door.

The power windows have pinch protection. If
there is any problem with the pinch protection,
a rest procedure can be tested.

WARNING

Children, other passengers or objects can

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the
vehicle's electrical system to ignition
mode

0

 and then taking the key with

you when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehi-
cle electrical system is completely
turned off.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

167

Operating the power windows.

Operating manually. Move one of the con-
trols slightly up or down. The power win-
dows go up or down while the control is
held in position.
Operating with automatic controls. Move
one of the controls up or down to its end
position and release it. The window moves
automatically to its fully closed/open posi-
tion.

To use the power windows, the ignition must
be in at least mode

I

 or

II

. After the ignition

has been switched off, the power windows
can be operated for several minutes or until a
door is opened. Only one control can be oper-
ated at a time.

It can also be operated using keyless opening

*

with the door handle.

WARNING

Make sure that no child or other passenger

comes into contact with the windows as

they are closing with keyless closing

*

.

NOTE

One way to reduce the pulsating wind
noise heard when the rear windows are
open is to also open the front windows
slightly.

NOTE

The windows cannot be opened at speeds
over approx. 180 km/h (ca 112 mph), but
they can be closed.

The driver is always responsible for follow-
ing applicable traffic regulations.

NOTE

It may not be possible to operate the win-
dows in low temperatures.

Related information

•

Power windows (p. 166)

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Reset procedure for pinch protection
(p. 165)

•

Keyless locking and unlocking

*

 (p. 251)

•

Locking and unlocking using the remote
key (p. 237)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

168

Using sun curtains

*

There is a sun curtain in the parcel shelf in the
rear window.

–

Pull up the sun curtain and hook it into the
ceiling bracket using the two hooks on the
sun curtain.
> The spring force in the curtain keeps

the hooks hanging in place.

When the sun curtain is not being used, grasp
and unhook it and let the curtain slowly retract
while still holding it.

Related information

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Reset procedure for pinch protection
(p. 165)

•

Power windows (p. 166)

Rearview/door mirrors

The rearview mirror and door mirrors can be
used to improve the driver's visibility behind
the vehicle.

Rearview mirror

The rearview mirror is equipped with Home-
Link

*

, auto-dim

*

 and compass

*

.

The rearview mirror can be adjusted manually.

Door mirrors

WARNING

The door mirror on the passenger side is

curved to improve visibility. Objects in the

mirror may appear farther away than they

actually are.

The joystick in the drivers' door control panel
is used to adjust the position of the door mir-
rors.

There are also several automatic settings that
can also be connected to the memory function
buttons for the power seat

*

.

Related information

•

HomeLink

®

*

 (p. 459)

•

Compass

*

 (p. 462)

•

Adjusting the rearview mirror dimming
function (p. 169)

•

Adjusting the door mirrors (p. 169)

•

Storing positions for seats, mirrors and
head-up display

*

 (p. 182)

•

Activating and deactivating the heated
rear window and door mirrors (p. 215)

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

169

Adjusting the rearview mirror

dimming function

Bright light entering the vehicle from behind,
e.g. from the headlights of following vehicles,
could reflect in the rearview mirror and door
mirrors and cause a glare. Use the dimming
function when light from behind is distract-
ing.

Auto-dim

If bright light enters the vehicle from behind,
the door mirrors will automatically dim when it
is dark outside or when lighting conditions are
low, for example when driving in tunnels.
Auto-dim is always active when the engine is
running, except when reverse gear is engaged.

NOTE

Adjustments to the sensitivity level will not
be noticeable immediately but will instead
take effect after a short period of time.

The sensitivity level for dimming will affect
both the rearview mirror and door mirrors.

To change the dimming sensitivity level:

1. Tap

Settings

 in the Top view in the center

display.

2. Tap

My Car

Mirrors and Convenience

.

3. Under

Rearview Mirror Auto Dimming

,

select

Normal

,

Dark

 or

Light

.

The rearview mirror has two sensors - one
pointing forward and one pointing rearward -
which work together to identify and eliminate
glare. The forward-pointing sensor monitors
ambient light, while the rearward-pointing
sensor monitors light from the headlights of
following vehicles.

For the door mirrors to be equipped with auto-
dim, the rearview mirror must also be equip-
ped with auto-dim.

NOTE

If the sensors are obstructed by e.g. a
parking permit, transponder, sunshade or
objects on the seats or parcel shelf in a
way that prevents light from reaching the
sensors, the auto-dim function in the rear-
view and door mirrors will be reduced.

Related information

•

Rearview/door mirrors (p. 168)

•

Adjusting the door mirrors (p. 169)

Adjusting the door mirrors

To improve visibility to the rear, the door mir-
rors need to be adjusted to the driver's height
and seating position.

There are several automatic settings that can
also be connected to the memory function
buttons for the power seat

*

.

Controls used for door mirrors

Door mirror controls.

The joystick in the drivers' door control panel
is used to adjust the position of the door mir-
rors. The ignition must be in at least mode

I

.

1. Press the

L

 button for the left door mirror

or

R

 for the right door mirror. The button

will light up.

2. Adjust the position using the joystick

located between the buttons.

||

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

170

3. Press the

L

 or

R

 button again. The light in

the button will go out.

Automatically folding door mirrors

*

The door mirrors can be automatically folded
when driving or parking in tight spaces.

1. Press the

L

 and

R

 buttons at the same

time.

2. Release the buttons after about 1 second.

The mirrors will automatically stop when
they are completely folded in.

Open the mirrors by pressing

L

 and

R

 at the

same time. The mirrors will automatically stop
when they reach the last-used setting.

Resetting the mirrors' position

A mirror that has been moved out of position
manually (e.g. hit or bumped into) must be
electrically returned to its original position for
automatic folding

*

 to function properly.

1. Fold in the mirrors by pressing the

L

 and

R

buttons at the same time.

2. Open them again by pressing the

L

 and

R

buttons at the same time.

3. Repeat the above procedure as needed.

The mirrors return to their original positions.

Tilting when parking

3

The door mirrors can be tilted down to help
give the driver a better view along the sides of
the vehicle, e.g. of the curb when parking.

–

Select reverse gear and press the

L

 or

R

mirror button.

Please note that the button may need to be
pressed twice depending on settings. When
the door mirror is tilted down, the light in the
button will flash. When reverse gear is
engaged, the door mirrors will automatically
start to move after 3 seconds and will reach
their original position after about 8 seconds.

Automatically tilting when parking

3

With this setting, the door mirrors will auto-
matically tilt down when reverse gear is
engaged. The folded position is preset and
cannot be adjusted.

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Mirrors and Convenience

.

3. Under

Exterior Mirror Tilt at Reverse

,

select

Off

,

Driver

,

Passenger

 or

Both

 to

activate/deactivate and to select which
mirror to tilt.

To immediately return the door mirrors to their
original position, press the

L

 or

R

 button

twice.

Automatic folding when the vehicle is
locked

*

In the center display, you can set the door mir-
rors to retract/extend automatically when the
vehicle is locked/unlocked with the key.

1. Tap

Settings

 in the center display's Top

view.

2. Tap

My Car

Mirrors and Convenience

.

3. Select

Fold Mirror When Locked

 to acti-

vate/deactivate.

NOTE

If the door mirrors are folded in manually
using the

L

 and

R

 buttons and then the

vehicle is locked, the mirrors will not auto-
matically fold out when the vehicle is
unlocked, even if this preference has been
set. In this case, the mirrors must be folded
out manually.

Related information

•

Rearview/door mirrors (p. 168)

•

Adjusting the rearview mirror dimming
function (p. 169)

•

Storing positions for seats, mirrors and
head-up display

*

 (p. 182)

•

Activating and deactivating the heated
rear window and door mirrors (p. 215)

3

Only on models equipped with a power driver's seat with memory buttons

*

.

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

171

Panoramic roof

*

The panoramic roof is divided into two glass
sections. The front section can be opened
vertically at the rear edge (ventilation posi-
tion) or horizontally (open position). The rear
section cannot be moved.

The panoramic roof has a wind deflector and
sun curtain made of perforated fabric (located
beneath the glass sections) for extra protec-
tion in e.g. bright sunlight.

The panoramic roof and sun curtain are oper-
ated using the controls in the ceiling.

To operate the panoramic roof and sun cur-
tain, the ignition must be in mode

I

 or

II

.

WARNING

Children, other passengers or objects can

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the
vehicle's electrical system to ignition
mode

0

 and then taking the key with

you when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehi-
cle electrical system is completely
turned off.

CAUTION

•

Do not open the panoramic roof when
load carriers are installed.

•

Never place heavy objects on the pan-
oramic roof.

CAUTION

•

Remove ice and snow before opening
the panoramic roof. Be careful not to
scratch any surfaces or damage the
trim.

•

Do not operate the panoramic roof if it
is frozen in place.

Wind blocker

The panoramic roof is equipped with a wind
blocker that folds up when the roof is open.

Related information

•

Operating the panoramic roof

*

 (p. 172)

•

Auto closing the panoramic roof

*

 sun cur-

tain (p. 174)

•

Pinch protection for windows and sun cur-
tains (p. 164)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

172

•

Keyless locking and unlocking

*

 (p. 251)

•

Locking and unlocking using the remote
key (p. 237)

Operating the panoramic roof

*

The panoramic roof and sun curtain are oper-
ated using a control in the ceiling panel, and
both are equipped with pinch protection.

WARNING

Children, other passengers or objects can

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the
vehicle's electrical system to ignition
mode

0

 and then taking the key with

you when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehi-
cle electrical system is completely
turned off.

CAUTION

•

Do not open the panoramic roof when
load carriers are installed.

•

Never place heavy objects on the pan-
oramic roof.

CAUTION

•

Remove ice and snow before opening
the panoramic roof. Be careful not to
scratch any surfaces or damage the
trim.

•

Do not operate the panoramic roof if it
is frozen in place.

To operate the panoramic roof and sun cur-
tain, the ignition must be in mode

I

 or

II

.

It can also be operated using keyless opening

*

with the door handle.

WARNING

Make sure that no child or other passenger

comes into contact with the windows as

they are closing with keyless closing

*

.

CAUTION

Check that the panoramic roof is properly
closed when closing.

The movement of the roof will stop if the con-
trol is released during manual operation or
when the glass has reached the fully open/
closed position. The movement of both the
panoramic roof and the sun curtain is also
stopped if the control in the ceiling is operated
again in the direction opposite that of the cur-

WINDOWS, GLASS AND MIRRORS

}}

173

rent direction of movement. Movement will
also stop if the control in the right rear door is
moved again in any direction.

The panoramic roof and sun curtain are also
equipped with pinch protection. If there is any
problem with the pinch protection, a rest pro-
cedure can be tested.

NOTE

For manual opening, the sun curtain must
be completely open before the panoramic
roof can be opened. For the reverse proce-
dure, the panoramic roof must be com-
pletely closed before the sun curtain can
be completely closed.

NOTE

It may not be possible to operate the win-
dows in low temperatures.

Opening and closing ventilation
position

Ventilation position, rear edge raised.

Open by pushing the control upward
once.
Close by pushing the control downward
once.

When ventilation mode is selected, the rear
edge of the front section of the roof is raised.
If the sun curtain is fully closed when ventila-
tion position is selected, it will automatically
open approx. 50 mm (approx. 2 inches).

If the panoramic roof is closed from the venti-
lation position, the sun curtain will also auto-
matically close.

Fully opening and closing the
panoramic roof with the control in the
ceiling

Operation, manual mode

Operation, automatic mode

Manual operation

1. To open the sun curtain, pull the control

backward to the manual open mode.

2. To open the panoramic roof, pull the con-

trol backward a second time to the man-
ual opening position.

Close by repeating the above procedure in
reverse - push the control forward/down to
the manual closing position.

||

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

174

Auto operation

1. To open the sun curtain to the fully open

position, pull the control backward to the
auto open mode and release.

2. To open the panoramic roof, pull the con-

trol backward a second time to the auto-
matic opening position and release.

Close by repeating the above procedure in
reverse - push the control forward/down to
the auto close position.

Automatic operation - rapid opening or
closing

The panoramic roof and sun curtain can be
opened or closed simultaneously:

–

Open - press the control backward twice
to the automatic operation position and
release.

–

Close - press the control forward/down
twice to the automatic operation position
and release.

Related information

•

Panoramic roof

*

 (p. 171)

•

Auto closing the panoramic roof

*

 sun cur-

tain (p. 174)

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Keyless locking and unlocking

*

 (p. 251)

•

Locking and unlocking using the remote
key (p. 237)

Auto closing the panoramic roof

*

sun curtain

With this function, the sun curtain closes
automatically 15 minutes after the vehicle has
been locked if it is parked in hot weather. This
is done to lower the passenger compartment
temperature and protect the upholstery
against being bleached by the sun.

The function is deactivated as the default fac-
tory setting and can be activated or deacti-
vated using the center display.

1. Tap

Settings

 in the Top view in the center

display.

2. Tap

My Car

Locking

.

Select

Auto Close Sunroof Curtain

 to

activate/deactivate.

NOTE

The sun curtain also closes when all win-
dows are closed with keyless closing

*

.

Related information

•

Panoramic roof

*

 (p. 171)

•

Operating the panoramic roof

*

 (p. 172)

•

Pinch protection for windows and sun cur-
tains (p. 164)

•

Keyless locking and unlocking

*

 (p. 251)

•

Locking and unlocking using the remote
key (p. 237)
