Climate controls (p. 209)

It is not possible to activate the air condi-
tioning when the fan control is in

Off

posi-

tion.

Related information

•

Parking climate

Parking climate control is a generic term for
various functions that improve the passenger
compartment climate when the car is parked,
e.g. preconditioning.

Functions belonging to the parking
climate control are controlled from
the

Parking climate

in climate view

in the centre display. Open climate

view by pressing the symbol in the middle of
the climate row.

Related information

•

Climate (p. 198)

•

Climate comfort when parking (p. 227)

•

•

Symbols and messages for parking cli-
mate control (p. 228)

Preconditioning

Preconditioning is a climate function which, if
possible, attempts to reach comfort tempera-
ture in the passenger compartment before
departure.

Preconditioning can use direct start or be set
via the timer.

The function utilises several systems in differ-
ent cases:

•

In a cold climate, the parking heater
warms up the passenger compartment to
a comfortable temperature.

•

The air conditioning, in a hot climate, cools
the passenger compartment to the com-
fort temperature.

•

Activation of heated steering wheel

and

heated seats

for driver and passenger can

be selected.

•

Heated windscreen, rear window and door
mirrors are automatically activated as
required.

During preconditioning in a hot climate, con-
densation from the air conditioning may drip
under the car. This is normal.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

222

Preconditioning is available only when the
car is connected to an electrical socket

. A

charging station which is not always
active, e.g. on account of a timer, may
cause preconditioning to malfunction.

If the car is not connected to an electrical
socket, it is still possible to cool the pas-
senger compartment briefly in a warm cli-
mate by starting preconditioning directly.

During preconditioning of the passenger
compartment, the car works to reach com-
fort temperature and not the temperature
set in the climate control system.

Related information

•

Start and switch off preconditioning
(p. 222)

•

•

Start and switch off

preconditioning

Preconditioning heats or cools the passenger
compartment, if possible, prior to driving. The
function can use direct start from the centre
display or a mobile phone.

Start and switch off from car

1. Open climate view in the centre display by

pressing the symbol in the middle of the
climate row.

2. Select the

Parking climate

tab.

3. Select whether seat heating and steering

wheel heating should be activated during
preconditioning by ticking/unticking the
boxes for the respective function.

4. Press

Preconditioning

> Preconditioning is started/switched off

and the button is illuminated/extin-
guished.

Preconditioning is available only when the
car is connected to an electrical socket

. A

charging station which is not always
active, e.g. on account of a timer, may
cause preconditioning to malfunction.

If the car is not connected to an electrical
socket, it is still possible to cool the pas-
senger compartment briefly in a warm cli-
mate by starting preconditioning directly.

The car's doors and windows should be
closed during the preconditioning of the
passenger compartment.

Applicable to electric heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

* Option/accessory.

223

WARNING

Do not use preconditioning

•

In unventilated spaces indoors.
Exhaust gases are emitted if the heater
starts.

•

In locations with combustible or flam-
mable material nearby. Fuel, gas, long
grass, sawdust, etc. may ignite.

•

When there is a risk that the heater’s
exhaust line may be blocked. For
example, deep snow inside the front
right-hand wheel housing can obstruct
the heater’s ventilation.

Remember that the preconditioning can be

started by a timer that has been set for a

long time in advance.

Starting from the app

Start of preconditioning and information about
the selected settings can be managed from a
device that has the Volvo On Call

app. Pre-

conditioning heats or cools the passenger
compartment (using the car's air conditioning)
to comfort temperature.

The passenger compartment can also be pre-
conditioned with the car remote start function
(Engine Remote Start - ERS)

via the Volvo

On Call

app.

Related information

•

•

•

Preconditioning time setting

The timer can be set so that the precondition-
ing is finished at a predetermined time.

The timer can handle up to 8 different settings
for:

•

A time on a single date

•

A time on one or more days of the week,
with or without repetition.

Preconditioning is available only when the
car is connected to an electrical socket

. A

charging station which is not always
active, e.g. on account of a timer, may
cause preconditioning to malfunction.

If the car is not connected to an electrical
socket, it is still possible to cool the pas-
senger compartment briefly in a warm cli-
mate by starting preconditioning directly.

Related information

•

Adding and editing time setting for pre-
conditioning (p. 224)

•

Applicable to fuel-driven auxiliary heater.

Certain markets.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

224

•

Activating and deactivating time setting
for preconditioning (p. 225)

•

Removing time setting for preconditioning
(p. 226)

Adding and editing time setting for

preconditioning

The timer for preconditioning can manage up
to 8 time settings.

Adding a time setting

The button to add a time setting in the

Parking

climate

tab in the climate view.

1. Open the climate view in the centre dis-

play.

2. Select the

Parking climate

tab.

3. Press

Add timer

> A pop-up window is shown.

It is not possible to add a time setting if
there already are 8 settings entered for the
timer. Delete a time setting in order to be
able to add a new one.

4. Tap on

Date

to set the time for a single

date.

Tap on

Days

to set the time for one or

more days of the week.

With

Days

: Activate/deactivate repetition

by ticking/unticking the box for

Repeat

weekly

5. With

Date

: Select the date for precondi-

tioning by scrolling the date list with the
arrows.

With

Days

: Select the days of the week

for preconditioning by tapping on the but-
tons for the days of the week.

6. Set the time when the preconditioning

should be finished by scrolling with the
arrows.

Applicable to electric heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

225

7. Tap on

Confirm

in order to add the time

setting.
> The time setting is added to the list and

is activated.

WARNING

Do not use preconditioning

•

In unventilated spaces indoors.
Exhaust gases are emitted if the heater
starts.

•

In locations with combustible or flam-
mable material nearby. Fuel, gas, long
grass, sawdust, etc. may ignite.

•

When there is a risk that the heater’s
exhaust line may be blocked. For
example, deep snow inside the front
right-hand wheel housing can obstruct
the heater’s ventilation.

Remember that the preconditioning can be

started by a timer that has been set for a

long time in advance.

Editing a time setting

1. Open the climate view in the centre dis-

play.

2. Select the

Parking climate

tab.

3. Press the time setting that is to be

changed.
> A pop-up window is shown.

4. Edit the time setting in the same way as

described in "Adding a time setting"
above.

Related information

•

•

Activating and deactivating time setting
for preconditioning (p. 225)

•

•

Removing time setting for preconditioning
(p. 226)

Activating and deactivating time

setting for preconditioning

A time setting in the timer for preconditioning
can be activated or deactivated based on
need.

The timer buttons in the

Parking climate

tab in the

climate view.

1. Open the climate view in the centre dis-

play.

2. Select the

Parking climate

tab.

3. Activate/deactivate a time setting by tap-

ping on the timer button to the right of the
setting.
> The time setting is activated/deacti-

vated and the button illuminates/extin-
guishes.

Applicable to fuel-driven auxiliary heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

226

WARNING

Do not use preconditioning

•

In unventilated spaces indoors.
Exhaust gases are emitted if the heater
starts.

•

In locations with combustible or flam-
mable material nearby. Fuel, gas, long
grass, sawdust, etc. may ignite.

•

When there is a risk that the heater’s
exhaust line may be blocked. For
example, deep snow inside the front
right-hand wheel housing can obstruct
the heater’s ventilation.

Remember that the preconditioning can be

started by a timer that has been set for a

long time in advance.

Related information

•

•

Adding and editing time setting for pre-
conditioning (p. 224)

•

•

Removing time setting for preconditioning
(p. 226)

Removing time setting for

preconditioning

A time setting for preconditioning that is no
longer required can be deleted.

The button for editing the list/deleting the time set-

ting in the tab

Parking climate

in the climate view.

1. Open the climate view in the centre dis-

play.

2. Select the

Parking climate

tab.

3. Press

Edit list

4. Press the delete icon to the right in the

list.
> The icon changes to the text

Delete

5. Press

Delete

to confirm.

> The time setting is removed from the

list.

Related information

•

•

Adding and editing time setting for pre-
conditioning (p. 224)

•

•

Activating and deactivating time setting
for preconditioning (p. 225)

Applicable to fuel-driven auxiliary heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

227

Climate comfort when parking

The climate in the car's passenger compart-
ment can be maintained while the car is
parked, e.g. if the engine needs to be
switched off but the driver or passenger(s)
wants to remain in the car and maintain the
level of climate comfort.

Starting climate comfort retention is only pos-
sible via direct start.

The function utilises several systems in differ-
ent cases:

•

Residual heat from the engine, in a cold
climate, heats the passenger compart-
ment to comfort temperature.

•

When it is warm, the ventilation cools the
passenger compartment by blowing in air
from outside the car.

Climate comfort retention is switched off
when the car is locked from the outside to
avoid using residual heat unnecessarily.
Use of the function is intended to maintain
climate comfort when driver or passengers
remain inside the car.

Related information

•

Starting and switching off climate comfort
when parking (p. 227)

•

Starting and switching off climate

comfort when parking

Climate comfort retention maintains the cli-
mate in the passenger compartment after
driving. The function can use direct start from
the centre display.

1. Open climate view in the centre display by

pressing the symbol in the middle of the
climate row.

2. Select the

Parking climate

tab.

3. Press

Keep climate comfort

> Climate comfort retention is started/

switched off and the button illumi-
nates/extinguishes.

It is not possible to start climate comfort
retention if there is not enough residual
heat in the engine to maintain the passen-
ger compartment climate, or if the outside
temperature is above approx. 20°C (68°F).

Climate comfort when parking (p. 227)

Related information

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

* Option/accessory.

228

Symbols and messages for parking

climate control

A number of symbols and messages regar-
ding parking climate control can be shown in
the driver display.

Messages relating to parking climate control
can also be displayed in a device which has
the Volvo On Call

app.

This symbol illuminates in the driver
display

when the parking heater is

active.

Symbol Message

Specification

Parking climate

Service required

Parking climate control is disengaged. Contact a workshop

to check the function as soon as

possible.

Parking climate

Temporarily unavailable

Parking climate control is temporarily disengaged. If the problem persists for some time, con-
tact a workshop

to check the function.

Parking climate

Unavailable Fuel level too low

Parking climate control cannot be activated when the fuel level is too low to start the parking
heater. Fill the vehicle's fuel tank.

Parking climate

Unavailable Charge level too low

Parking climate control cannot be activated if the charge level of the hybrid battery is too low
to start the parking heater. Start the car.

Applies to fuel-driven heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

229

Symbol Message

Specification

Parking climate

Unavailable, not connected to the
mains

The parking climate control cannot be activated if the charging cable is not connected. Con-
nect the charging cable.

Parking climate

Limited Charge level too low

The running time for parking climate control is limited when the state of charge in the hybrid
battery is low. Start the car.

An authorised Volvo workshop is recommended.

Applies to fuel-driven heater.

Applies to electric heater.

Related information

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

230

Heater

The heater has two subfunctions that help to
heat the passenger compartment or engine in
different situations.

The heater has two subfunctions:

•

Parking heater - heats the passenger com-
partment, if necessary, when the parking
climate control's preconditioning is acti-
vated.

•

Additional heater - heats the passenger
compartment and engine, if necessary,
during driving.

Either a fuel-driven heater or an electric heater
is used, depending on the market

The heater is fitted in the front right-hand
wheel housing.

When the heater is running

, smoke may

be emitted from the right-hand front wheel
housing and a low hum may be heard. A
ticking sound from the fuel pump may also
be heard from the rear section of the car.
This is perfectly normal.

Battery and charging

The heater is powered by the car's hybrid bat-
tery. If the charge level of the hybrid battery is
too low, then the heater is switched off auto-
matically and the driver display shows a mes-
sage.

Make sure that there is enough charge in
the battery if the heater needs to be used.

Fuel and refuelling

Warning label on fuel filler flap.

The heater uses fuel from the car's normal fuel
tank.

If the car is parked on a steep hill, the front of
the car should point downhill to ensure that
there is a supply of fuel to the heater.

If the level in the fuel tank is too low then the
heater is switched off automatically and the
driver display shows a message.

Additional heater (p. 232)

Make sure there is enough fuel in the car's
fuel tank if the heater needs to be used.

WARNING

Fuel which spills out could be ignited.

Switch off the fuel-driven heater before

starting to refuel.

Check in the driver display that

the heater is switched off. This

symbol is lit when it is working as

a parking heater.

Related information

•

Climate (p. 198)

•

Parking heater (p. 231)

•

An authorised Volvo dealer has information regarding which markets use which type of heater.

Applicable to fuel-driven auxiliary heater.

Applies to fuel-driven heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

}}

231

Parking heater

The parking heater heats the passenger com-
partment as necessary before driving if the
car's preconditioning is activated.

The parking heater is one of two subfunctions
of the car's heater. The heater is fitted in the
front right-hand wheel housing.

When this symbol illuminates in the
driver display, the parking heater
may be active

When the heater is running

, smoke may

be emitted from the right-hand front wheel
housing and a low hum may be heard. A
ticking sound from the fuel pump may also
be heard from the rear section of the car.
This is perfectly normal.

The parking heater starts automatically if the
parking climate's preconditioning is activated
and the passenger compartment needs to be
heated up.

Depending on factors such as battery level,
passenger compartment temperature and
ambient temperature, the heater has different
running times, but never longer than 40
minutes.

Additional heater (p. 232)

Make sure there is enough fuel in the car's
fuel tank if the parking heater needs to be
used

Make sure that there is enough charge in
the hybrid battery if the parking heater
needs to be used.

WARNING

Do not use preconditioning

•

In unventilated spaces indoors.
Exhaust gases are emitted if the heater
starts.

•

In locations with combustible or flam-
mable material nearby. Fuel, gas, long
grass, sawdust, etc. may ignite.

•

When there is a risk that the heater’s
exhaust line may be blocked. For
example, deep snow inside the front
right-hand wheel housing can obstruct
the heater’s ventilation.

Remember that the preconditioning can be

started by a timer that has been set for a

long time in advance.

WARNING

If there is a smell of fuel, unusual amounts

of smoke, black smoke, or unusual sounds
coming from the parking heater

, switch

off the heater and, if possible, pull out its

fuse. Volvo recommends that an authorised

Volvo workshop should be contacted for

repair.

Applies to fuel-driven heater.

Applicable to fuel-driven auxiliary heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

232

Related information

•

Heater (p. 230)

•

Additional heater

The auxiliary heater helps to heat the passen-
ger compartment and engine while driving.

The additional heater is one of two subfunc-
tions of the car's heater. The heater is fitted in
the front right-hand wheel housing.

When the heater is running

, smoke may

be emitted from the right-hand front wheel
housing and a low hum may be heard. A
ticking sound from the fuel pump may also
be heard from the rear section of the car.
This is perfectly normal.

The additional heater starts and is controlled
automatically when heating is required while
the car is being driven.

It switches off automatically when the car is
switched off.

Activating and deactivating automatic
start of auxiliary heater (p. 233)

Make sure there is enough fuel in the car's
fuel tank if the auxiliary heater needs to be
used

Related information

•

Heater (p. 230)

•

Parking heater (p. 231)

•

Applicable to fuel-driven auxiliary heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CLIMATE

233

Activating and deactivating

automatic start of auxiliary heater

The auxiliary heater helps to heat the passen-
ger compartment and engine while driving.

It is possible to set whether automatic start
for the additional heater should be activated/
deactivated.

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

Climate

3. Select

Additional Heater

to activate/

deactivate automatic start of the addi-
tional heater.

Volvo recommends that the automatic
start for the additional heater should be
switched off for short driving distances

Additional heater (p. 232)

If the auxiliary heater's automatic starting
is deactivated, this may impede comfort in
the passenger compartment as the climate
control system will then have no heat
source during electrical operation.

Related information

•

Applicable to fuel-driven auxiliary heater.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

236

Lock confirmation

The car indicates with hazard warning flash-
ers when the car is locked or unlocked.

Exterior indication

Locking

•

The car's hazard warning flashers indicate
locking by flashing and retracting the door
mirrors

Unlocking

•

The car's hazard warning flashers indicate
unlocking by two flashes and extending
the door mirrors

All doors, the boot lid and the bonnet must be
closed for the car to indicate that it is locked.
If locking takes place with just the driver door
closed

, locking will take place but the lock

indication with hazard warning flashers will
only take place when all doors, the boot lid
and the bonnet have been closed.

Lock and alarm indicator on the
instrument panel

The lock and alarm indicator shows the status
of the locking system:

•

A long flash indicates locking.

•

Short flashes indicate that the car is
locked.

•

Rapid flashes after disarming the alarm

indicate that the alarm has been triggered.

Indication in lock buttons

Front door

Lock buttons with indicator lamp in the front door.

An illuminated indicator lamp in the lock but-
ton of either front door indicates that all doors
are locked. If any door is opened, the lamp will
extinguish in both doors.

Only for cars with retractable power door mirrors.

Not applicable to with cars equipped with keyless locking/unlocking

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

}}

* Option/accessory.

237

Rear door

Lock button with indicator lamp in the rear door.

An illuminated indicator lamp in the lock but-
ton for one of the doors indicates that the door
in question is locked. If any door is unlocked,
its lamp will extinguish while the others will
continue to illuminate.

Other indication

The home safe lighting and approach light
functions can also be activated when locking
and unlocking.

Related information

•

Lock indication setting (p. 237)

•

Approach light duration (p. 160)

•

Using home safe lighting (p. 159)

Lock indication setting

It is possible to select various options for how
the car confirms locking and unlocking in the
settings menu in the centre display.

To change the locking response setting:

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Locking

3. Press

Visible Locking Feedback

select when the car is to give a visible
response:

•

Lock

•

Unlock

•

Both

Or switch off the function by selecting

Off

To change the setting for retractable rearview
mirrors

when locking:

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

3. Select

Fold Mirror When Locked

to acti-

vate or deactivate the function.

Related information

•

Lock confirmation (p. 236)

Remote control key

The remote control key locks and unlocks the
doors and boot lid. The remote control key
needs to be inside the car for it to be started.

Remote control key

or key tag (Key Tag)

The remote control key is not physically used
when starting since the car is equipped with
support for keyless starting (Passive Start) as
standard. You simply need to have the key in
the front part of the passenger compartment.

For cars equipped with keyless locking and
unlocking (Passive Entry)

the key can be any-

where in the car to start the car. In this case, a
slightly smaller, lighter key tag (Key Tag) is
also supplied.

The remote control keys can be linked to dif-
ferent driver profiles to save personal preferen-
ces in the car.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

KEY, LOCKS AND ALARM

* Option/accessory.

238

Remote control key buttons

The remote control key has four buttons - one on the

left-hand side and three on the right-hand side.

Locking

– Pressing the button locks the

doors, boot lid and fuel filler flap and also
arms the alarm

Press and hold to close all of the windows
and the sunroof

simultaneously.

Unlocking

– Pressing the button unlocks

the doors and boot lid and also deacti-
vates the alarm.
A longer press opens all windows simulta-
neously. This total airing function can be
used, for example, to quickly air the car in
hot weather.

Boot lid

– Unlocks and disarms the

alarm for the boot lid only. On cars with
power operated boot lid

, the boot lid is

opened automatically when the button is
held depressed. The boot lid is also closed
with a long press – acoustic warning sig-
nals sound. On cars without power oper-
ated boot lid, the boot lid is opened
mechanically, by spring pressure, using a
long press.

Panic function

– Used to attract atten-

tion in an emergency. Press and hold the
button for at least 3 seconds or press it
twice within 3 seconds to activate the
direction indicators and the horn. The
function can be turned off with the same
button once it has been active for at least
5 seconds. Otherwise the function
switches off automatically after 3 minutes.

WARNING

If anyone is left in the car, make sure the

power windows and sunroof

are de-ener-

gised by always taking the remote control

key with you when you leave the car
