Storing position for seat, door mirrors and
head-up display

•

Activating and deactivating the heated
rear window and door mirrors (p. 217)

•

Adjusting rearview mirror dimming

Bright light from behind could be reflected in
the rearview mirrors and dazzle the driver.
Use dimming when disturbed by light from
behind.

Manual dimming

The interior rearview mirror can be dimmed
with a control in the mirror's lower edge.

Control for manual dimming.

1. Use dimming by moving the control in

towards the passenger compartment.

2. Return to normal mode by moving the

control towards the windscreen.

The control for manual dimming is not availa-
ble on mirrors with automatic dimming.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

172

Automatic dimming

Bright light from behind is automatically
dimmed by the interior rearview and door mir-
rors. Automatic dimming is always active
while driving, apart from when gearbox
reverse position is selected.

NOTE

When sensitivity is changed there is no
immediately noticeable change in dim-
ming, but the change takes place gradu-
ally.

Dimming sensitivity will affect both the interior
rearview mirror and the door mirrors.

To change dimming sensitivity:

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

My Car

Mirrors and

Convenience

3. Under

Rearview Mirror Auto Dimming

select

Normal

Dark

Light

The interior rearview mirror contains two sen-
sors - one forward facing and one rearward
facing - that work together to identify and
eliminate dazzling light. The forward facing
sensor detects ambient light, while the rear-
ward facing sensor detects the light from vehi-
cle headlights behind.

For the door mirrors to be equipped with auto-
matic dimming, the interior rearview mirror
must also be equipped with automatic dim-
ming.

NOTE

If the sensors are obscured by e.g. parking
permits, transponders, sun visors or
objects in the seats or on the parcel shelf in
such a way that light is prevented from
reaching the sensors, then the dimming
function of the interior rearview and door
mirrors is reduced.

Related information

•

Rearview and door mirrors (p. 171)

•

Rearview and door mirrors (p. 171)

Angling the door mirrors

To ensure better visibility to the rear, the door
mirrors need to be set to the preferences of
the driver. There are a number of automatic
settings that can also be linked to the mem-
ory function buttons for the power seat

Using controls for door mirrors

Controls for door mirrors.

The door mirror positions are adjusted with
the joystick in the driver's door control panel.
Ignition position must be at least

1. Press the

button for the left-hand door

mirror or the

button for the right-hand

door mirror. The light in the button illumi-
nates.

2. Adjust the position with the joystick in the

centre.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

173

3. Press the

button again. The light

should no longer be illuminated.

Folding in rearview mirrors
electrically

The mirrors can be retracted for parking/driv-
ing in narrow spaces.

1. Depress the

and

buttons simultane-

ously.

2. Release them after approximately 1 sec-

ond. The mirrors automatically stop in the
fully retracted position.

Fold out the mirrors by pressing down the

and

buttons simultaneously. The mirrors

automatically stop in the fully extended posi-
tion.

Resetting to neutral

Mirrors that have been moved out of position
by an external force must be reset electrically
to the neutral position for electric retracting/
extending

to work correctly.

1. Fold in the door mirrors by pressing down

the

and

buttons simultaneously.

2. Fold them out again by pressing the

and

buttons simultaneously.

3. Repeat the above procedure as necessary.

The mirrors are now reset in neutral position.

Angling during parking

A door mirror can be angled down for the
driver to view the side of the road when park-
ing, for example.

–

Engage reverse gear and press the

button.

Note that the button may need to be pressed
twice, depending on whether it was already
preselected. The button flashes when the door
mirror is angled down. When reverse gear is
disengaged, the door mirror automatically
starts to return after approx. 3 seconds and
then reaches its original position after approx.
8 seconds.

Automatic angling during parking

With this setting, the door mirror is automati-
cally angled down when reverse gear is
selected. The folded position is preset and
cannot be adjusted.

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

3. Under

Exterior Mirror Tilt at Reverse

select

Off

Driver

Passenger

Both

activate/deactivate and to select which
review mirror should be angled.

You can make the door mirror return to its
original position by pressing the

button

twice.

Automatic retraction when locking

When the car is locked/unlocked with the
remote control key, the door mirrors can be
automatically retracted/extended. However, if
the mirrors have been folded in manually then
they have to be folded out manually as well.

1. Tap on

Settings

in the centre display's

top view.

2. Press

My Car

Mirrors and

Convenience

3. Select

Fold Mirror When Locked

to acti-

vate/deactivate.

Related information

•

•

Adjusting rearview mirror dimming (p. 171)

•

Storing position for seat, door mirrors and
head-up display

Activating and deactivating the heated
rear window and door mirrors (p. 217)

•

Only in combination with power seat with memory buttons

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

174

Sunroof

The sunroof can be opened vertically at the
rear edge (ventilation position) or horizontally
(open position).

The sunroof has a wind deflector. There is
also an inner sunscreen that is closed man-
ually.

The sunroof is operated with a control located
in the roof. The control is activated when the
car's electrical system is in ignition position

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

, and then take the

remote control key with you when leav-
ing the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

•

Do not open the sunroof when load
carriers are fitted.

•

Do not place any heavy objects on the
sunroof.

Pinch protection for windows and sun
blinds (p. 166)

•

Remove ice and snow before opening
the sunroof. Take care not to scratch
surfaces or damage strips.

•

Do not operate the sunroof if it has fro-
zen closed.

Wind deflector

The sunroof has a wind deflector that is folded
up when the sunroof is in the open position.

Related information

•

Operating the sunroof

(p. 175)

•

•

Keyless locking and unlocking

(p. 261)

•

Locking and unlocking with the remote
control key (p. 239)

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

175

Operating the sunroof

When operating with the control that is fitted
in the roof, the sunroof is first opened hori-
zontally to a comfort position.

In ventilation position, the sunroof is raised at
the rear edge.

WARNING

Children, other passengers or objects may

be trapped by the moving parts.

•

Always operate the windows with cau-
tion.

•

Do not allow children to play with the
controls.

•

Never leave children alone in the car.

•

Remember to always switch off the
power supply to the power windows
by setting the car's electrical system in
ignition position

, and then take the

remote control key with you when leav-
ing the car.

•

Never put an object or part of the body
through the windows, even if the car's
electrical system is fully disconnected.

•

Do not open the sunroof when load
carriers are fitted.

•

Do not place any heavy objects on the
sunroof.

•

Remove ice and snow before opening
the sunroof. Take care not to scratch
surfaces or damage strips.

•

Do not operate the sunroof if it has fro-
zen closed.

Opening, manual

Opening, automatic

Closing, manual

Closing, automatic

The movement of the sunroof is stopped if the
control is released during manual operation, or
when the sunroof reaches the comfort posi-
tion or the maximum opening or closing posi-
tion. The movement is also stopped if the con-
trol is operated again while the movement is in
progress.

In order that the sunroof can be operated, the
car's electrical system must be in ignition
position

It can also be operated using a remote control
key or keyless opening

with the door handle.

WARNING

Check that children or other passengers

are not at risk of crushing when all the win-

dows are closed with a remote control key

or keyless opening

with a door handle.

Pinch protection for windows and sun
blinds (p. 166)

Check that the sunroof is properly closed
when closing.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

176

Manual operation

–

To open the sunroof, press the control
rearward to the position for manual open-
ing. The sunroof first reaches comfort
position

. In order to open to maximum

opening position - press the control back-
wards a second time.

Close the sunroof by repeating the preceding
procedure in reverse order - press the control
forward/downward to the manual closing
position instead.

Automatic operation

–

To open the sunroof, press the control
backwards to the position for automatic
opening and release. The sunroof first rea-
ches comfort position

. To open to the

maximum opening position - press the
control a second time backward to the
position for automatic opening and
release.

Close the sunroof by repeating the preceding
procedure in reverse order - press the control
forward/downward to the automatic closing
position instead.

The sunroof does not stop at comfort position
during closing.

NOTE

It may not be possible to operate windows
at low temperatures.

Ventilation position

Ventilation position, vertically at the rear edge.

Open by pressing the control upward.

Close by pressing the control forward/
downward.

When ventilation position is selected, the sun-
roof is raised at the rear edge.

Sunscreen

The sunroof features a manual, sliding interior
sunscreen. The sunscreen slides back auto-
matically when the sunroof is opened. Grip the

handle and slide the sunscreen forward to
close it.

Related information

•

Sunroof

(p. 174)

•

•

Keyless locking and unlocking

(p. 261)

•

Locking and unlocking with the remote
control key (p. 239)

Comfort position is an open position for the sunroof, where wind noise and resonance noise are at a comfortably low level while driving.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

177

Wiper blades and washer fluid

Together with the washer fluid, the wipers
aim to improve visibility as well as headlamp
pattern.

The washer nozzles are heated

automatically

in cold weather to prevent the washer fluid
from freezing.

Information indicating that the washer fluid
needs topping up appears in the driver display
when there is approx. 1 litre (1 qt) of washer
fluid remaining.

Related information

•

•

•

•

•

•

•

Using windscreen wipers

The windscreen wipers are designed to clean
the windscreen. Different settings for the
windscreen wipers are set using the right-
hand stalk switch.

Right-hand stalk switch.

The thumbwheel is used to set rain sensor
sensitivity and wiper swipe frequency.

Single sweep

Lower the stalk switch and release to
make one sweep.

Windscreen wipers off

Move the stalk switch to position

switch off the windscreen wipers.

Intermittent wiping

Move the lever up to switch the wipers
to intermittent wiping. Set the number

of sweeps per time unit with the thumbwheel
when intermittent wiping is selected.

Continuous wiping

Raise the stalk switch for the wipers to
sweep at normal speed.

Raise the stalk switch further for the
wipers to sweep at high speed.

Before activating the wipers - ensure that
the wiper blades are not frozen in, and that
any snow or ice on the windscreen is scra-
ped away.

Use plenty of washer fluid when the wipers
are cleaning the windscreen. The wind-
screen must be wet when the windscreen
wipers are operating.

Related information

•

•

•

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

178

•

•

•

•

Using the rain sensor

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen. Rain sensor sen-
sitivity can be adjusted with the thumbwheel
on the right-hand stalk switch.

Right-hand stalk switch.

Rain sensor button

Thumbwheel sensitivity/frequency

When the rain sensor is activated, the rain
sensor symbol

is shown in the driver

display.

Activating the rain sensor

When activating the rain sensor, the car must
be running or in ignition position

while

the windscreen wiper stalk switch is in posi-
tion

or in the position for a single sweep.

Activate the rain sensor by pressing the rain
sensor button

Move the lever down to make the wipers
move.

Turn the thumbwheel upward for higher sensi-
tivity and downward for lower sensitivity. An
extra sweep is made when the thumbwheel is
turned upward.

Deactivating the rain sensor

Deactivate the rain sensor by pressing the rain
sensor button

or moving the stalk

switch up to another wiper program.

The rain sensor is deactivated automatically in
ignition position

or when the engine is

switched off.

The rain sensor is deactivated automatically
when wiper blades are set in service position.
The rain sensor is reactivated when service
mode has been deactivated.

The windscreen wipers could start and be
damaged in an automatic car wash. Deac-
tivate the rain sensor while the car is run-
ning or when the car's electrical system is
in ignition position

. The symbol in the

driver display extinguishes.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

}}

179

Related information

•

•

•

•

•

•

•

Using the rain sensor's memory

function

The rain sensor automatically starts the wind-
screen wipers based on how much water it
detects on the windscreen.

Activating/deactivating the memory
function

The memory function for the rain sensor can
be activated in such a way that the rain sensor
button does not need to be depressed each
time the car is started:

1. Press

Settings

in the top view in the cen-

tre display.

2. Press

My Car

Wipers

3. Select

Rain Sensor Memory

to activate/

deactivate the memory function.

Related information

•

•

•

•

•

•

•

Using windscreen and headlamp

washers

Windscreen and headlamp washers are
designed to clean the windscreen and head-
lamps. Windscreen and headlamp washers
are started using the right-hand stalk switch.

Starting windscreen and headlamp
washers

Washing function, right-hand stalk switch.

–

Move the right-hand stalk switch toward
the steering wheel to start the windscreen
and headlamp washers.
> The windscreen wipers will make sev-

eral more sweeps once the stalk switch
has been released.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

180

Avoid activating the washer system when
it is frozen or the washer reservoir is
empty, otherwise there is a risk of damag-
ing the pump.

Headlamp washing

To save fluid, the headlamps are washed auto-
matically at a defined interval when the head-
lamps are switched on.

Reduced washing

If only approx. 1 litre (1 qt) of washer fluid
remains in the reservoir and the message

Washer fluid

Level low, refill

, together with

the

symbol, is shown in the driver dis-

play, then the supply of washer fluid to the
headlamps is switched off. This is to prioritise
cleaning the windscreen and the visibility
through it. The headlamps are only washed if
main or dipped beam is switched on.

Related information

•

•

•

•

•

•

•

Storing position for seat, door mirrors and
head-up display

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

182

Manual front seat

The car's front seats have a range of setting
options in order to enhance comfort.

Raise/lower the front edge of the seat
cushion

by pumping up/down.

Change the length

of the seat cushion by

pulling the lever up and moving the seat
cushion forward/backward by hand.
Adjust the seat forward/backward by lift-
ing the handle and adjusting the distance
to the steering wheel and pedals. Check
that the seat is locked after the position
has been adjusted.
Change the lumbar support

by pressing

the button upward/downward/forward/
back

Raise/lower the seat by means of adjust-
ing the control up/down.
Change the backrest inclination by turning
the control knob.

WARNING

Adjust the position of the driver's seat

before setting off, never while driving.

Make sure that the seat is in locked posi-

tion in order to avoid personal injury in the

event of heavy braking or an accident.

Related information

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Only applies to the driver's seat.

Applicable to four-way lumbar support

. Two-way lumbar support

is adjusted forwards/backwards.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

183

Power

front seat

The car's front seats have a range of setting
options in order to enhance comfort. The
power seat can be moved forwards/back-
wards and upwards/downwards. The front
edge of the seat cushion can be raised/
lowered as well as adjusted in length

and the

backrest inclination can be changed. The
lumbar support

can be adjusted upward/

downward/forward/backward.

Seat setup can take place when the engine is
running and within a certain time after unlock-
ing the door without the engine running.
Adjustment can also be performed within a
certain time after the engine has been
switched off.

The power seats have overload protection
that is triggered if any seat is blocked by an
object. If this happens, remove the object
and then move the seat again.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

Adjusting the power

front seat (p. 183)

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Adjusting the power

front seat

Set the preferred seat position using the con-
trol on the front seat's seating section. To set
the various comfort functions, turn the multi-
function control

up/down.

The illustration shows the controls from a car with
four-way lumbar support

. Cars with two-way lumbar

support

do not have the rotatable multifunction con-

trol.

In cars with four-way lumbar support

turn the multifunction control

up/down to

set the different comfort functions. In cars
with two-way lumbar support

, use the

round button to adjust the lumbar support
forward/backward.
Raise/lower the seat cushion front edge
by adjusting the control up/down.

Applicable to four-way lumbar support

. Two-way lumbar support

is adjusted forwards/backwards.

Not available in cars with two-way lumbar support

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

184

Raise/lower the seat by means of adjust-
ing the control up/down.
Move the seat forward/backward by
adjusting the control forward/backward.
Change the backrest inclination by adjust-
ing the control forward/backward.

Only one movement (forward/back/up/down)
can be made at a time.

The backrests of the front seats cannot be
lowered fully forward.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

Power

front seat (p. 183)

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

Storing position for seat, door

mirrors and head-up display

You can store the position for power

seat,

door mirrors and head-up display

in the

memory buttons.

Store two different positions for the power

seat, the door mirrors and the head-up dis-
play

using the memory buttons. The buttons

are located on the inside of one of the front
doors or both

Button

for storing settings.

Memory button.

Storing a position

1. Adjust seat, door mirrors and head-up dis-

play to the desired position.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

185

2. Press and hold the

button depressed.

The light indicator in the button illumi-
nates.

3. Within three seconds, press and hold the

button.

> When the position has been stored in

the selected memory button, an acous-
tic signal can be heard and the light
indicator in the

button extinguishes.

If none of the memory buttons is depressed
within three seconds then the

button extin-

guishes and no storing takes place.

The seat, the door mirrors or the head-up-dis-
play must be readjusted before a new memory
can be set.

Related information

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

•

Settings for head-up display

•

(p. 142)

Using a stored position for seat,

door mirrors and head-up display

If the positions for the power

seat, the door

mirrors and the head-up display

have been

stored, they can be activated by using the
memory buttons.

Using a stored setting

A stored setting can be used with the front
door either open or closed:

Open front door

–

Depress one of the memory buttons

(

)

(

) with a short press. Power seat,

door mirrors and head-up display move
and then stop at the positions stored in
the selected memory button.

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

* Option/accessory.

186

Closed front door

–

Hold one of the memory buttons

(

) or

(

) depressed until seat, door mirrors

and head-up display stop in the positions
that are stored in the selected memory
button.

If the memory button is released, the move-
ment of the seat, door mirrors and head-up
display will be stopped.

WARNING

•

Because the driver's seat can be
adjusted with the ignition off, children
should never be left unattended in the
vehicle.

•

Movement of the seat can be STOP-
PED at any time by pressing any but-
ton on the power seat control panel.

•

Do not adjust the seat while driving.

•

Make sure there is nothing under the
seats when they are being adjusted.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•

•

Settings for head-up display

•

(p. 142)

Massage settings

in the front seat

Both the multi-function control on the side of
the seat and the centre display can be used in
order to change the settings. The range of
settings is shown in the centre display.

Multi-function control, located on the side of the

seat's seating section.

Settings for massage

The following setting options are available for
massage:

•

Off

: Select

Off

in order to switch

on/off the massage function.

•

Programs 1-5

: There are 5 preset mas-

sage programs. Select between

Swell

Tread

Advanced

Lumbar

and

Shoulder

-------------------------------------------------------------------------------------------------------------------------------------------------------------

SEATS AND STEERING WHEEL

}}

* Option/accessory.

187

•

Intensity

: Select between

Low

Normal

and

High

•

Speed

: Select between

Slow

Normal

and

Fast

Restarting massage

The massage function is deactivated automat-
ically after 20 minutes. Reactivation of the
function is performed manually.

–

Tap on

Restart

, which is shown in the

centre display, to restart the selected mas-
sage program.
> The massage program restarts. If no

action is taken, the message remains
shown in the top view.

Related information

•

Storing position for seat, door mirrors and
head-up display

•

•

•

Using a stored position for seat, door mir-
rors and head-up display

•

•

•

•

•

Adjusting the passenger seat from the
driver's seat

•
