Daytime running lights (p. 150)

•

Using high beam

High beam is operated via the left-hand steering
wheel lever. High beam is the vehicle's strongest
lighting and should be used when driving in dark
conditions, provided it does not blind other road
users, to improve visibility.

Steering wheel lever with lighting ring.

High beam flash

Move the steering wheel lever slightly back-
ward to the high beam flash mode. The high
beams will illuminate until the lever is
released.

High beams

The high beams can be activated when the
lighting ring is in mode

Activate high beams by moving the steering

wheel lever forward. Deactivate by moving
the steering wheel lever backward.

When the high beams are activated, the
symbol will be illuminated in the instrument panel.

Related information

•

Active high beam (p. 153)

•

When the low beams are on.

LIGHTING

}}

* Option/accessory.

153

Active high beam

Active high beams is a function that uses cam-
era sensors in the upper edge of the windshield
to detect the headlights of approaching vehicles
or the taillights of the vehicle directly ahead.
When either of these is detected, the vehicle's
headlights will automatically switch from high
beams to low beams.

Active high beam is enabled by moving the lighting ring
on the steering wheel lever to

The function can also detect street lighting.
When the camera sensor no longer detects an
approaching vehicle or a vehicle ahead, the head-
lights will return to high beams.

This function can be used in dark conditions
when the vehicle's speed is approx. 20 km/h
(approx. 12 mph) or higher.

If active high beams are deactivated when the
high beams are on, the headlights will automati-
cally switch to low beams.

When active high beams are activated, a white

symbol will be displayed in the instrument

panel.

When high beams are on, the symbol will be blue.
For LED headlights, this applies even if the high
beams are partially dimmed, i.e. if the headlights
are illuminated with slightly more than low beams.

Vehicles with LED

headlights*

If the active high beams are equipped with the
auto on/off function

, the headlights will return to

high beams a second or so after the camera sen-
sor no longer detects the headlights of approach-
ing vehicles or the taillights of a vehicle ahead.

Limitations for active high beams

The camera sensor on which the function is
based has limitations.

If this symbol and the message

Active

High Beam

Temporarily

unavailable

is displayed in the instru-

ment panel, switching between high

and low beams must be done manually. The light-
ing ring on the steering wheel lever can remain in
the

position. The

symbol will go out

when the message is displayed.

The same applies if this symbol along
with the message

Windscreen

sensor

Sensor blocked, see

Owner's manual

is displayed.

Active high beams may be temporarily unavailable
in certain situations, e.g. heavy fog or rain. When
active high beams become available again, or the
windshield sensors are no longer blocked, the
message will disappear and the

symbol will

be displayed.

WARNING

Automatic high beam is an aid in using the

best possible light based on prevailing condi-

tions.
The driver is always responsible for manually

switching between high and low beam when

traffic situations or weather conditions require

this.

LED (Light Emitting Diode)

Depends on the vehicle's equipment level.

LIGHTING

154

Related information

•

Camera limitations (p. 330)

•

Using high beam (p. 152)

•

Using turn signals

The vehicle's turn signals are controlled using
the left-side steering wheel lever. The turn sig-
nals flash three times or continuously, depend-
ing on how far up or down the lever is moved.

Turn signals.

Triple flash indicator

Move the steering wheel lever up or down to
the first position and release. The turn sig-
nals will flash three times. If the function is
deactivated via the center display, the signals
will flash once.

Hazard warning flashers (p. 157)

•

This automatic flashing sequence can be
interrupted by immediately moving the
lever in the opposite direction.

•

If the turn signal indicator flashes more
quickly than normal, refer to the message
in the instrument panel.

Continuous flashing sequence

Move the lever up or down as far as possible.

The lever will stop in its end position and can be
moved back manually or automatically by moving
the steering wheel.

Related information

•

•

Adjusting light functions via the center dis-
play (p. 149)

LIGHTING

}}

* Option/accessory.

155

Active Bending Lights*

Active Bending Lights (ABL) are designed to
help provide maximum illumination in curves and
intersections. Depending on equipment level,
vehicles with LED

headlights* may be equipped

with Active Bending Lights.

Headlight pattern with function deactivated (left) and
activated (right).

Active Bending Lights follow the movement of
the steering wheel to help provide maximum illu-
mination in curves and intersections, helping to
improve visibility for the driver.

The function is automatically activated when the
engine is started. If a fault is detected in the sys-
tem, the

symbol will illuminate in the

instrument panel and a message will be dis-
played.

The function is only active in weak daylight or
dark conditions and only when the vehicle is mov-
ing and the low beams are on.

Deactivating/activating the function

The function is activated as the default factory
setting and can be activated and deactivated in
the center display's Function view:

Tap the

Active Bending

Lights

button.

Related information

•

Adjusting light functions via the center dis-
play (p. 149)

Rear fog light

The rear fog light is considerably brighter than
ordinary taillights and should only be used to
help other road users see the vehicle when visi-
bility is reduced by conditions such as fog,
snow, smoke or dust.

Rear fog light button.

The rear fog light consists of a light on the rear
of the vehicle on the driver's side.

The rear fog light can only be switched on when
the ignition is in II mode and the lighting ring is in
position

Press the button for On/Off. The

symbol in

the instrument panel illuminates when the rear
fog light is on.

LED (Light Emitting Diode)

LIGHTING

156

The rear fog light turns off automatically when
the ignition is switched off or when the steering
wheel lever lighting ring is in position

Regulations concerning rear fog light use vary
from country to country.

Related information

•

•

Emergency brake lights (p. 156)

Brake lights

The brake lights are automatically illuminated
when braking.

The brake lights illuminate when the brake pedal
is depressed. They also illuminate when the
brakes are automatically applied by one of the
driver support systems.

Related information

•

•

Brake functions (p. 430)

Emergency brake lights

The emergency brake lights are activated to
warn following vehicles of hard braking.

This function causes an additional taillight on
each side of the vehicle to illuminate.

The emergency brake lights are activated in the
event of hard braking or if the ABS system is
activated and the vehicle is traveling at a high
speed.

After the driver decelerates to a low speed and
then releases the brake, the brake lights resume
their normal brightness.

Related information

•

Brake lights (p. 156)

•

Brakes (p. 431)

•

Hazard warning flashers (p. 157)

LIGHTING

* Option/accessory.

157

Hazard warning flashers

Hazard warning flashers warn other road users
by all of the vehicle's turn signals being activated
at the same time. The function can be used to
warn about a traffic hazard.

Hazard warning flashers button.

Press the button to activate the hazard warning
flashers.

Emergency brake lights (p. 156)

Regulations concerning the use of hazard
warning flashers may vary from country to
country.

Related information

•

•

Using turn signals (p. 154)

Using home safe lighting

Some of the exterior lights remain on to illumi-
nate the area around the vehicle. This is called
home safe lighting.

To activate home safe lighting:

1. Switch off the ignition.

2. Push the left-side steering wheel lever

toward the dashboard and release.

3. Exit the vehicle and lock the doors.

When the function is activated, a symbol will be
shown in the instrument panel and the parking
lights, outer door handle lights* and the license
plate lights will be illuminated.

The length of time home safe lighting remains
illuminated can be set in the center display.

Related information

•

Adjusting light functions via the center dis-
play (p. 149)

•

Welcome Light (p. 157)

Welcome Light

Approach lighting is activated when the vehicle
is unlocked and can be used to provide light as
you walk toward the vehicle.

The function is activated when the remote key is
used for unlocking. The parking lights, outer door
handle lights*, license plate lights, interior ceiling
lights, footwell lighting and trunk/cargo compart-
ment lighting will be illuminated. If a door is
opened while the function is activated, the light-
ing in the outer door handle* and the interior
lighting will remain illuminated for a longer period
of time.

This function can be activated and deactivated in
the center display.

Related information

•

Adjusting light functions via the center dis-
play (p. 149)

•

Using home safe lighting (p. 157)

•

Remote key (p. 237)

LIGHTING

* Option/accessory.

158

Interior Lighting

The interior is equipped with several different
types of lighting to improve the experience. This
includes reading lamps, glove box lighting and
ground lighting.

All lighting in the passenger compartment can be
turned on and off manually within 5 minutes
after:

•

the engine has been switched off and the
ignition is in mode 0.

•

the vehicle is unlocked but the engine has
not been started.

Front ceiling lighting

The controls in the ceiling console for the front reading
lights and courtesy lighting.

Reading light left side

Passenger compartment lighting

Courtesy lighting auto switch

Reading light right side

Reading lights

The reading lights on the right and left sides are
switched on and off by briefly pressing the but-
tons in the ceiling console. To adjust the bright-
ness, press and hold the button.

Passenger compartment lighting

Briefly press the button in the ceiling console to
switch on or off the footwell lighting and ceiling
lighting.

Courtesy lighting auto switch

Activate the auto switch by briefly pressing the
AUTO button in the ceiling console. With Auto
activated, the indicator light in the button and the
courtesy lighting come on and are turned off as
follows.

The courtesy lighting:

•

comes on when the vehicle is unlocked and
when the ignition is switched off

•

goes off when the engine is started and
when the vehicle is locked

•

comes on or goes off when a side door is
opened or closed

•

remains on for 2 minutes if any of the side
doors are open.

Rear roof lighting

Reading lights are located in the rear section of
the vehicle and can also be used as passenger
compartment lighting.

In vehicles with panoramic roofs*, there are two lamp
units, one on each side of the ceiling.

Briefly press the button on the light to turn on or
off the reading lights. To adjust the brightness,
press and hold the button.

Glove compartment lighting

The glove compartment lighting comes on or
goes off when the glove compartment is opened
or closed.

Vanity mirror lighting*

The vanity mirror lighting comes on or goes off
when the cover over the mirror is opened or
closed.

LIGHTING

}}

* Option/accessory.

159

Ground lighting*

The ground lighting comes on or goes off when a
door is opened or closed.

Doorsill lighting

The doorsill lighting comes on or goes off when a
door is opened or closed.

Trunk lighting

The trunk lighting comes on or goes off when the
trunk lid is opened or closed.

Ambient Lighting

The ambient lighting comes on when the doors
are opened and goes out when the vehicle is
locked. Ambient lighting brightness can be
adjusted in the center display and also fine-tuned
using the thumb wheel in the dashboard.

Mood lighting*

The vehicle is equipped with LEDs that provide
faint lighting in various colors. This lighting is on
when the engine is running. Mood lighting can be
adjusted in the center display and also fine-tuned
using the thumb wheel in the dashboard.

Lighting in the door storage
compartments

Lighting in the door storage compartments
comes on when the doors are opened and goes
out when the vehicle is locked. The brightness
can be adjusted using the thumb wheel in the
dashboard.

Lighting in the tunnel console's front
cup holder

The lighting in front console cup holders
switches on when the vehicle is unlocked and off
when the vehicle is locked. The brightness can
be adjusted using the thumb wheel in the dash-
board.

Related information

•

Adjusting interior lighting (p. 159)

•

•

Passenger compartment interior (p. 574)

•

Adjusting interior lighting

Illumination in the vehicle varies depending on
ignition mode. The interior lighting can be
adjusted with a thumb wheel in the dashboard
and certain light functions can also be adjusted
via the center display.

The thumb wheel on the dash-
board to the left of the steering
wheel can be used to adjust
the brightness of the display
lighting, instrument lights,
ambient lighting and mood
lighting*.

Adjust ambient decor lighting

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

3. Choose from among the following settings:

•

Under

Ambient Light Intensity

, select

Off

Low

High

•

Under

Ambient Light Level

, select

Reduced

Full

Adjusting mood lighting*

The vehicle is equipped with several LEDs that
provide faint lighting in various colors. This light-
ing is on when the engine is running.

LIGHTING

160

Changing the brightness

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

Interior Mood Lighting

3. Under

Interior Mood Light Intensity

, select

Off

Low

High

Changing the color of the light

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Lights and Lighting

Interior Lighting

Interior Mood Lighting

3. Choose

By Temperature

By Color

change the color of the light.

By Temperature

is selected, the light will

change according to the temperature set for
the passenger compartment.

By Color

is selected, the subcategory

Theme Colors

can be used to make further

adjustments.

Related information

•

Interior Lighting (p. 158)

•

Adjusting light functions via the center dis-
play (p. 149)

•

Pinch protection for windows and sun cur-
tains (p. 162)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

162

Windows, glass and mirrors

The vehicle is equipped with controls for win-
dows, glass and mirrors. Some of the windows
in the car are laminated.

Laminated glass

The windshield has laminated glass. Laminated
glass is also available as on option for some
other glass surfaces. Laminated glass is rein-
forced, which provides better protection against
break-ins and improved soundproofing in the
passenger compartment.

The panoramic roof* also has laminated glass.

The symbol shows the windows containing laminated
glass

Related information

•

•

Panoramic roof (p. 170)

•

Power windows (p. 164)

•

Rearview/door mirrors (p. 167)

•

Using sun curtains* (p. 166)

•

Head-up display* (p. 138)

•

Using the windshield wipers (p. 176)

•

Using the windshield and headlight washers
(p. 178)

•

Activating and deactivating the heated wind-
shield* (p. 217)

•

Activating and deactivating the heated rear
window and door mirrors (p. 218)

Pinch protection for windows and

sun curtains

All power windows and sun curtains* have a
pinch protection function that is triggered if any-
thing blocks them while they are opening or
closing.

If pinch protection is activated, movement will
stop and then retract automatically to approx.
50 mm (2 inches) from the point at which it was
blocked (or to full ventilation position).

It is still possible to override pinch protection
when closing is interrupted (e.g. due to ice) by
pressing and holding down the control in the
same direction.

If there is any problem with the pinch protection,
a rest procedure can be tested.

WARNING

If the starter battery is disconnected, the func-

tion for automatic opening and closing must

be reset to function correctly. A reset is

required in order for the pinch protection to

work.

Related information

•

Operating the power windows (p. 165)

•

Does not apply to windshield and panoramic roof*, which are always laminated and therefore do not have this symbol.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

163

•

Using sun curtains* (p. 166)

•

Panoramic roof (p. 170)

Reset procedure for pinch

protection

If you experience any problems with the electri-
cal functions for the power windows, you can try
to perform a reset.

The power sun curtains* also have a reset pro-
cedure that can be tested as needed.

WARNING

If the starter battery is disconnected, the func-

tion for automatic opening and closing must

be reset to function correctly. A reset is

required in order for the pinch protection to

work.

If the problem persists or if it affects the panor-
amic roof or sunroof, contact a workshop

Resetting a power window

1. Start with the window in the closed position.

2. Then operate the window in manual mode

three times upward toward the closed posi-
tion.
> The system will be automatically initiated.

Resetting a sun curtain*

1. Begin with the sun curtain in the lowered

position.

2. Press and hold the lowering control for

approx. 15 seconds.
> The system will be automatically activated.

Related information

•

Pinch protection for windows and sun cur-
tains (p. 162)

•

Operating the power windows (p. 165)

•

Using sun curtains* (p. 166)

An authorized Volvo workshop is recommended.

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

164

Power windows

The power windows are operated using the con-
trol panels found in the doors. The driver's door
has controls for operating all windows and for
activating the child safety locks.

The power window in left rear door can also be
operated with the control panel in the right rear
door.

Driver's door control panel.

Electric child safety locks* that deactivate the
controls in the rear doors to prevent the
doors or windows from being opened from
the inside.
Rear window controls.

Front window controls.

Right-hand rear door controls.

Rear window controls.

The power windows have pinch protection. If
there is any problem with the pinch protection, a
rest procedure can be tested.

WARNING

Children, other passengers or objects can be

trapped by the moving parts.

•

Always operate the windows with caution.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the vehi-
cle's electrical system to ignition mode 0
and then taking the remote key with you
when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehicle
electrical system is completely turned off.

Related information

•

Operating the power windows (p. 165)

•

Pinch protection for windows and sun cur-
tains (p. 162)

•

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

165

Operating the power windows

All power windows can be operated using the
control panel in the driver's door. The control
panels in the other doors can be used to oper-
ate that particular door.

The power window in left rear door can also be
operated with the control panel in the right rear
door.

The power windows have pinch protection. If
there is any problem with the pinch protection, a
rest procedure can be tested.

WARNING

Children, other passengers or objects can be

trapped by the moving parts.

•

Always operate the windows with caution.

•

Do not allow children to play with the
operating controls.

•

Never leave a child alone in the vehicle.

•

Remember to always cut the current to
the power windows by setting the vehi-
cle's electrical system to ignition mode 0
and then taking the remote key with you
when leaving the vehicle.

•

Never stick objects or body parts out
through the windows, even if the vehicle
electrical system is completely turned off.

Operating the power windows.

Operating manually. Move one of the controls
slightly up or down. The power windows go
up or down while the control is held in posi-
tion.
Operating with automatic controls. Move one
of the controls up or down to its end position
and release it. The window moves automati-
cally to its fully closed/open position.

To use the power windows, the ignition must be
in at least mode I or II. After the ignition has
been switched off, the power windows can be
operated for several minutes or until a door is
opened. Only one control panel can be operated
at a time.

It can also be operated using keyless opening*
with the door handle.

WARNING

Make sure that no child or other passenger

comes into contact with the windows as they

are closing with keyless closing*.

One way to reduce the pulsating wind noise
heard when the rear windows are open is to
also open the front windows slightly.

Pinch protection for windows and sun cur-
tains (p. 162)

The windows cannot be opened at speeds
over approx. 180 km/h (ca112 mph), but they
can be closed.

The driver is always responsible for following
applicable traffic regulations.

Related information

•

Power windows (p. 164)

•

•

Keyless locking and unlocking* (p. 253)

•

•

Locking and unlocking using the remote key
(p. 240)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

166

Using sun curtains*

There are integrated sun curtains in each rear
door and in the parcel shelf in the rear window.

Rear door – electrically operated

Each of the sun shades can be fully retracted or
fully extended.

The sun curtains are equipped with pinch protec-
tion. If you experience any problems operating in
the sun curtains, a reset sequence can be tested.

Control for power sun curtain

Control:

Controls:

Driver's door

Right and left rear door

Passenger door

None

Control:

Controls:

Left rear door

Right rear door

Right and left rear door

To operate the power windows and sun curtains,
the ignition must be in at least mode I or II.

If multiple controls are used at the same time, the
operation initiated by the first control used will be
activated. Once that operation has been comple-
ted, the other controls can be used again.

Right-hand rear door controls.

Raising of sun curtain

Lowering of sun curtain

Close the window and raise the sun curtain

The window must be fully closed before the sun
curtain can be raised.

1. Move the button upward and release.

> The window moves automatically to its

upper end position.

2. Move the button upward again and release.

> The sun curtain moves automatically to its

upper end position.

Lowering the sun curtain and opening the
window

The sun curtain must be fully retracted (lowered)
before the window can be opened.

1. Move the button downward and release.

> The sun curtain moves automatically to its

lower end position.

2. Move the button downward again to open

the window.
> The window moves automatically to its

lower end position.

Automatic operation - rapid opening/closing

The window and sun curtain can be opened/
closed simultaneously:

–

Open - press the control backward twice to
the automatic operation position and release.

–

Close - press the control forward/down twice
to the automatic operation position and
release.

WINDOWS, GLASS AND MIRRORS

}}

* Option/accessory.

167

Rear window shelf

An electrically operated sun curtain is integrated
in the rear window shelf.

To operate the sun curtain, the ignition must be
in mode II.

Pinch protection for windows and sun cur-
tains (p. 162)

It may not be possible to operate the sun
shade if the temperature in the passenger
compartment is low.

Operating using the center display

Tap

Rear Sun Curtain

in Func-

tion view in the center display -
the sun curtain will automati-
cally move to its end position,
up or down.

Operating with right-side rear door controls

Briefly press the button - the sun curtain will
automatically move to its end position, up or
down.

Related information

•

•

Adjusting the rearview mirror dimming func-
tion (p. 168)

•

Power windows (p. 164)

Rearview/door mirrors

The rearview mirror and door mirrors can be
used to improve the driver's visibility behind the
vehicle.

Rearview mirror

The rearview mirror can be easily adjusted man-
ually. The rearview mirror can be equipped with
HomeLink*, auto-dim* and compass*.

Door mirrors

WARNING

The door mirror on the passenger side is

curved to improve visibility. Objects in the mir-

ror may appear farther away than they actually

are.

The joystick in the drivers' door control panel is
used to adjust the position of the door mirrors.
There are also several automatic settings that
can also be connected to the memory function
buttons for the power seat*.

Related information

•

HomeLink

(p. 471)

•

Compass* (p. 474)

•

•

Adjusting the door mirrors (p. 169)

WINDOWS, GLASS AND MIRRORS

* Option/accessory.

168

•

Storing positions for seats, mirrors and head-
up display* (p. 182)

•

Activating and deactivating the heated rear
window and door mirrors (p. 218)

Adjusting the rearview mirror

dimming function

Bright light entering the vehicle from behind, e.g.
from the headlights of following vehicles, could
reflect in the rearview mirror and door mirrors
and cause a glare. Use the dimming function
when light from behind is distracting.

Auto-dim

If bright light enters the vehicle from behind, the
door mirrors will automatically dim. Auto-dim is
always active when the engine is running, except
when reverse gear is engaged.

Adjustments to the sensitivity level will not be
noticeable immediately but will instead take
effect after a short period of time.

The sensitivity level for dimming will affect both
the rearview mirror and door mirrors.

To change the dimming sensitivity level:

1. Tap

Settings

in the Top view in the center

display.

2. Tap

My Car

Mirrors and Convenience

3. Under

Rearview Mirror Auto Dimming

select

Normal

Dark

Light

The rearview mirror instead has two sensors -
one pointing forward and one pointing rearward -

which work together to identify and eliminate
glare. The forward-pointing sensor monitors
ambient light, while the rearward-pointing sensor
monitors light from the headlights of following
vehicles.

For the door mirrors to be equipped with auto-
dim, the rearview mirror must also be equipped
with auto-dim.
