Volvo S90 Twin Engine (2019 year). Instruction - part 7

Navigating in the center display's views
(p. 111)

•

•

Changing a driver profile's name (p. 133)

•

Linking a remote key to a driver profile
(p. 134)

Changing a driver profile's name

It is possible to change the names of the differ-
ent driver profiles used in the vehicle.

1. Tap

Settings

in the Top view in the center

display.

2. Tap

System

Driver Profiles

3. Select

Edit Profile

> A menu will open in which the driver pro-

file can be changed.

4. Tap the

Profile Name

box.

> A keyboard will be displayed and can be

used to change the name. Tap

close the keyboard.

5. Save the name change by pressing

Back

> The name has now been changed.

Selecting a driver profile (p. 133)

Profile names may not begin with a space. If a
space is entered first, the profile name will not
be saved.

Related information

•

•

Using the center display keyboard (p. 122)

DISPLAYS AND VOICE CONTROL

134

Protecting a driver profile

It may not always be desirable to store settings
made in the vehicle to the active driver profile. In
these instances, the driver profile can be protec-
ted.

Protecting a driver profile is only possible
when the vehicle is stationary.

To protect a driver profile:

1. Tap

Settings

in the Top view in the center

display.

2. Tap

System

Driver Profiles

3. Select

Edit Profile

> A menu will open in which the driver pro-

file can be changed.

4. Tap

Protect Profile

to protect the profile.

5. Confirm your selection to protect the profile

by tapping

Back

> When the profile is protected, settings

made in the vehicle will not be automati-
cally stored to the profile. The changes
must instead be saved manually by tap-
ping

Save current settings to the

profile

. If the profile is not protected, the

settings will be automatically stored to the
profile.

Related information

•

Linking a remote key to a driver

profile

A remote key can be linked to a driver profile.
This driver profile and all of its settings will then
automatically be selected every time the vehicle
is used with that particular remote key.

The first time the remote key is used, it is not
linked to any specific driver profile. The

Guest

profile is automatically activated when the ignition
is switched on.

A driver profile can also be selected manually
without linking it to any key. When the vehicle is
unlocked, the last active driver profile will be acti-
vated. If the key has ever been linked to a driver
profile, it is not necessary to manually select a
driver profile when using that particular key.

Linking a remote key to a specific driver
profile

A remote key can only be connected to a
driver profile when the vehicle is stationary.

First select the profile you would like to link to
the key (if that profile is not already active). The
active profile can then be linked to the key.

1. Tap

Settings

in the Top view in the center

display.

DISPLAYS AND VOICE CONTROL

135

2. Tap

System

Driver Profiles

3. Mark the desired profile. The display will

return to Home view. The

Guest

profile can-

not be linked to a remote key.

4. Pull down Top view again and tap

Settings

System

Driver Profiles

Edit

Profile

5. Select

Connect key

to link the profile with

the key. A driver profile can only be linked to
the key currently being used in the vehicle. If
there are any other keys in the vehicle,

than one key is found, put the key you
want to connect on backup reader

will be

displayed.

Location of the backup reader in the tunnel console.

> When

Profile connected to key

is dis-

played, the key and driver profile have
been linked.

6. Tap

> The key used is now linked to the driver

profile and will remain so as long as the

Connect key

box is not deselected.

Related information

•

Changing a driver profile's name (p. 133)

•

•

Remote key (p. 237)

Resetting driver profile settings

Settings that have been saved for one or more
driver profiles can be reset when the vehicle is
stationary.

Factory Reset

is only possible when the

vehicle is stationary.

1. Tap

Settings

in the Top view.

2. Tap

System

Factory Reset

Reset

Personal Settings

3. Select option

Reset for the active profile

Reset for all profiles

Cancel

Related information

•

Resetting center display settings (p. 130)

•

DISPLAYS AND VOICE CONTROL

136

Messages in the center display

The center display shows messages in certain
circumstances to inform or assist the driver.

Messages in the center display's Top view.

Messages with lower priority for the driver are
shown in the center display.

Most of the messages are shown in the center
display's status bar. The message will disappear
from the status bar after a short period of time or
after the required action has been taken. Mes-
sages that need to be saved are stored in Top
view in the center display.

The message may be shown along with graphics,
symbols or a button to e.g. activate/deactivate a
function connected to the message.

Pop-up messages

Messages are sometimes shown as pop-up win-
dows. Pop-up messages have a higher priority

than messages shown in the status bar and
require acknowledgment/action before they dis-
appear. Messages that need to be saved are
stored in Top view in the center display.

Related information

•

Handling messages in the center display
(p. 136)

•

Handling messages saved from the center
display (p. 137)

•

Messages in the instrument panel (p. 101)

Handling messages in the center

display

Messages in the center display are handled in
the center display's views.

Messages in the center display's Top view.

Some messages in the center display have a but-
ton (or several buttons in a pop-up message) to
e.g. activate/deactivate a function related to the
message.

DISPLAYS AND VOICE CONTROL

137

Handling new messages

For messages with buttons:

–

Tap the button to perform the action or let
the message automatically time-out after a
short period.
> The message will disappear from the sta-

tus bar.

For messages without buttons:

–

Close the message by tapping it or let the
message automatically time-out after a short
period.
> The message will disappear from the sta-

tus bar.

Messages that need to be saved are stored in
Top view in the center display.

Related information

•

Messages in the center display (p. 136)

•

Handling messages saved from the center
display (p. 137)

•

Messages in the instrument panel (p. 101)

Handling messages saved from the

center display

Messages saved from the instrument panel and
center displays are handled in the center display.

Saved messages and possible selections in Top view.

Messages that have been shown in the center
display and that need to be saved are stored in
the center display's Top view.

Reading saved messages

1. Open Top view in the center display.

> A list of saved messages will be displayed.

Messages with an arrow to the right can
be expanded.

2. Tap a message to expand/minimize it.

> More information about the message will

appear in the list and the image to the left
of the app will display information about
the message in graphic form.

Handling saved messages

Some messages have a button to e.g. activate/
deactivate a function related to the message.

–

Tap the button to perform the action.

Saved messages in Top view are automatically
deleted when the ignition is switched off.

Related information

•

Messages in the center display (p. 136)

•

Handling messages in the center display
(p. 136)

•

Messages in the instrument panel (p. 101)

DISPLAYS AND VOICE CONTROL

* Option/accessory.

138

Head-up display*

The head-up display is a complement to the
instrument panel and projects information from
the instrument panel onto the windshield. The
projected images can only be seen from the driv-
er's seat.

Incoming phone calls.

The head-up display projects warnings and infor-
mation related to speed, cruise control functions,
navigation, etc. onto the windshield in the driver's
field of vision. Traffic information and incoming
phone calls can also be shown on the head-up
display.

The driver's ability to see information in the
head-up display may be impeded by:

•

the use of polarizing sunglasses

•

a driving posture in which the driver is not
centered in the seat

•

objects on the display unit's glass cover

•

unfavorable lighting conditions.

CAUTION

The information is projected from a display
unit located in the dashboard. To help prevent
damage to the display unit's glass cover, do
not place any objects on the glass and pre-
vent objects from falling onto it.

Examples of what might be shown on the display.

Speed

Cruise control

Navigation

Road signs

A number of symbols may be projected temporar-
ily onto the head-up display, including:

If the warning symbol appears, read the
warning message in the instrument
panel.

If the information symbol appears, read
the warning message in the instrument
panel.

DISPLAYS AND VOICE CONTROL

* Option/accessory.

139

The snowflake symbol will illuminate if
there is a risk of slippery conditions.

Activating and deactivating the head-up dis-
play* (p. 139)

People with certain types of vision problems
may experience headaches or eye strain
when using the head-up display.

City Safety in head-up-display

If a collision warning is given, the information in
the head-up display will be replaced by a City
Safety graphic. This graphic will illuminate even if
the head-up display is turned off.

A City Safety graphic flashes to attract the driver's atten-
tion.

Related information

•

•

Cleaning the head-up display* (p. 620)

•

Replacing a windshield with head-up display*
(p. 595)

Activating and deactivating the

head-up display*

The head-up display can be activated and deac-
tivated when the vehicle has been started.

Press the

Head-up Display

button in the center display's
Function view. An indicator light
in the button will illuminate
when the function is activated.

Related information

•

Head-up display settings* (p. 140)

•

Head-up display* (p. 138)

DISPLAYS AND VOICE CONTROL

* Option/accessory.

140

Head-up display settings*

Adjusting settings for the head-up display.

Settings can be adjusted when the vehicle is
started and a projected image is displayed on the
windshield.

Selecting display options

Select the functions to be shown in the head-up
display.

1. Tap

Settings

in the center display's Top

view.

2. Tap

My Car

Displays

Head-Up

Display Options

3. Select one or more functions:

•

Show Navigation

•

Show Road Sign Information

•

Show Driver Support

•

Show Phone

This setting is stored as a personal setting in the
driver profile.

Adjusting brightness and height
position

1. Press the

Head-up Display Adjustments

button in the center display's Function view.

2. Adjust the brightness of the projected image

and the height position in the driver's field of
vision using the right-side steering wheel
lever.

Decreasing brightness

Increasing brightness

Raising position

Lowering position

Confirm

The brightness of the graphic is automatically
adapted to the light conditions in its background.
Brightness is also affected by adjustments to the
brightness of the other displays in the vehicle.

The height position can be stored in the front
power seat's* memory function using the keypad
in the driver's door.

DISPLAYS AND VOICE CONTROL

}}

* Option/accessory.

141

Calibrating the horizontal position

If the windshield or display unit has been
replaced, the head-up display's horizontal posi-
tion may need to be calibrated. Calibration means
that the projected image is rotated clockwise or
counterclockwise.

1. Tap

Settings

in the center display's Top

view.

2. Select

My Car

Displays

Head-Up

Display Options

Head-Up Display

Calibration

3. Calibrate the horizontal position of the image

using the right-side steering wheel keypad.

Rotate counterclockwise

Rotate clockwise

Confirm

Related information

•

Head-up display* (p. 138)

•

Activating and deactivating the head-up dis-
play* (p. 139)

•

Storing positions for seats, mirrors and head-
up display* (p. 182)

•

Voice control

The driver can use voice commands to control
certain functions in the media player, a
Bluetooth-connected phone, the climate system
and the Volvo navigation system*.

Voice commands offer extra convenience and
help minimize distractions so drivers can concen-
trate on driving and keep their attention on the
road and traffic situation.

WARNING

The driver is always responsible for ensuring

that the vehicle is operated in a safe manner

and that all applicable traffic regulations are

followed.

Voice control microphone

Voice control is carried out as a dialog, with spo-
ken commands from the user and verbal respon-

DISPLAYS AND VOICE CONTROL

* Option/accessory.

142

ses from the system. The voice control system
uses the same microphone as devices connected
with Bluetooth, and the voice control system
responds through the vehicle's loudspeakers. In
certain cases, text messages will also be dis-
played in the instrument panel. The functions are
controlled using the right-side steering wheel
keypad and settings are made in the center dis-
play.

System updates

The voice control system is continuously
improved. For optimal functionality, always down-
load the latest update at support.volvocars.com.

Related information

•

Using voice commands (p. 142)

•

Voice control for cellular phones (p. 143)

•

Voice control for radio and media (p. 144)

•

•

Voice control for cellular phones (p. 143)

Using voice commands

Press the button for voice con-
trol

on the right-side

steering wheel keypad to acti-
vate the system and initiate a
voice command dialog.

These may include:

•

Wait until after the tone, and then speak in
your normal voice at a normal speed.

•

Do not speak while the system is responding
(the system is unable to process commands
during this time).

•

Avoid background noises in the passenger
compartment by keeping doors, windows and
the panoramic roof* closed.

Voice control can be canceled by:

•

saying "

Cancel

•

pressing and holding the steering wheel key-
pad's voice command button

To speed up the voice command dialog and skip
system responses, press the voice command but-
ton

while the system is responding and give

your next command.

Voice command examples

Press

, say "

Call [First name]

[Last name]

[number category]

" - calls the selected contact

from the phone book. If the contact has several
phone numbers (e.g. home, cell, work), the right
category must also be given.

Press

and say "

Call Robyn

Smith

cellular

Commands/phrases

The following commands can always be used:

•

Repeat

" - repeats the most recent voice

command in the current dialog.

•

Cancel

" - cancels the dialog.

•

Help

" - initiates a help dialog. The system

responds with commands that can be used
in the current situation, an instruction or an
example.

Commands for specific functions, such as phone
and audio, are described in the sections related
to that function.

Certain markets only.

DISPLAYS AND VOICE CONTROL

* Option/accessory.

143

Numbers

Number commands can be given in different
ways depending on the function to be controlled:

•

Phone numbers and zip codes should be
given by stating each number individually, e.g.
zero three one two two four four three
(03122443).

•

Addresses can be given by stating each
number individually or in a group, e.g. two two
or twenty-two (22). For English and Dutch
language settings, groups of numbers can
also be said in sequence, e.g. twenty-two
twenty-two (22 22). For English, double or
triple digits can also be used, e.g. double
zero (00). Numbers in the range 0-2300 can
be used.

•

Frequencies can be given as ninety-eight
point eight (98.8), one hundred four point
two, or hundred four point two (104.2).

Related information

•

Voice control (p. 141)

•

•

Voice control for radio and media (p. 144)

•

•

Using voice commands (p. 142)

Voice control for cellular phones

Call a contact in the phone book, have a text
message read aloud or dictate short messages
using voice commands to a Bluetooth-con-
nected phone.

To access a contact in the phone book, the voice
command must contain the contact information
entered in the phone book. If a contact, e.g.

Robyn Smith

, has several phone numbers listed

in the phone book, a number category such as

home

cellular

can also be specified, i.e. "

Call

Robyn

Smith

cellular

Tap

and say one of the following commands:

•

Call [contact]

" - call the selected contact

from the phone book.

•

Call

[phone number]

" - call a phone num-

ber.

•

Recent calls

" - display the list of recent

calls.

•

Read message

" - read a text message

aloud. If there are several messages, select
the message to read aloud.

•

Message to [contact]

" - the user is

prompted to dictate a short message. The
message will then be read aloud and the
user can choose to send

or re-dictate the

message. The vehicle must be connected to
the Internet to access this function.

Related information

•

Voice control (p. 141)

•

•

Voice control for radio and media (p. 144)

•

•

Internet-connected vehicle* (p. 523)

•

Certain markets only.

Only certain phones can send messages via the vehicle. For additional information on compatibility, see support.volvocars.com.

DISPLAYS AND VOICE CONTROL

* Option/accessory.

144

Voice control for radio and media

Voice commands for the radio and media play-
ers are shown below.

Tap

and say one of the following commands:

•

Media

" - initiates a dialog for media and

radio and displays examples of commands.

•

Play

[artist]

" - plays music by the selected

artist.

•

Play

[song title]

" - plays the selected

song.

•

Play

[song title]

from

[album]

" - plays

the selected song from the selected album.

•

Play

[radio station]

" - starts the selected

radio station.

•

Tune to [frequency]

" - tunes to the

selected radio frequency in the currently
active waveband. If no radio source is active,
the FM band will be started as default.

•

Tune to [frequency]

[waveband]

" - tunes

to the selected radio frequency on the
selected waveband.

•

Radio

" - starts FM radio.

•

Radio FM

" - starts FM radio.

•

SiriusXM

" - starts SiriusXM radio*

•

" - starts playback from CD*.

•

USB

" - starts playback from USB.

•

iPod

" - starts playback from iPod.

•

Bluetooth

" - starts playback from a Blue-

tooth-connected media source.

•

Similar music

" - plays music from a USB-

connected device with music similar to that
currently playing.

Related information

•

Voice control (p. 141)

•

Using voice commands (p. 142)

•

Voice control for cellular phones (p. 143)

•

•

Voice control settings

Settings for the voice control system are made
here.

Settings

System

Voice Control

Settings can be personalized in the following
areas:

•

Repeat Voice Command

•

Gender

•

Speech Rate

Sound settings

Select sound settings under:

Settings

Sound

System Volumes

Voice Control

Language settings

The voice control system is not available for all
languages. The languages available for voice
commands are indicated by the

icon in the

list of languages.

Changing the language here will also change the
language in the menus, messages and help texts.

Settings

System

System Languages

and Units

System Language

Certain markets only.

LIGHTING

* Option/accessory.

148

Lighting panel and controls

The lighting panel and controls can be used to
adjust both exterior and interior lighting. The
lighting ring on the left-side steering wheel lever
can be used to activate and adjust the exterior
lighting. The brightness of the interior lighting
can be adjusted using the thumb wheel on the
dashboard.

Exterior lighting

Lighting ring position.

When the vehicle's ignition is in mode II, the
lighting ring positions have the following func-
tions:

Position

Meaning

US: Daytime running lights and
parking lights are off.

Canada: Daytime running lights and
parking lights are on.

High beam flash can be used.

Parking lights when the vehicle is
parked.

US: Daytime running lights are off.

Canada: Daytime running lights are
on.

High beam flash can be used.

Low beams and parking lights.

High beams can be activated.

High beam flash can be used.

Position

Meaning

Daytime running lights and parking
lights in daylight conditions.

Low beams and parking lights in
weak daylight or dark conditions or
when the front fog lights* and/or
rear fog light are activated.

Active high beam can be activated.

High beams can be activated when
low beams are on.

High beam flash can be used.

Active high beams on/off.

US models only: Daytime running lights and parking lights can

be deactivated in the center display.

Adjusting light functions via the center dis-
play (p. 149)

Volvo recommends use of Daytime Running
Lights in the US. Its use is mandatory in Can-
ada.

Volvo recommends using position

when

the vehicle is in motion.

LIGHTING

* Option/accessory.

149

WARNING

The vehicle lighting system cannot in all situa-

tions determine when the daylight is too weak

or not strong enough, e.g. when there is fog

or rain.
The driver is always responsible for driving the

vehicle with lighting that is safe for the traffic

conditions and as specified by applicable traf-

fic regulations.

Thumbwheel in instrument panel

Thumb wheel (to the left) for adjusting interior bright-
ness.

Related information

•

•

Interior Lighting (p. 158)

•

Parking lights (p. 150)

•

Using turn signals (p. 154)

•

Using high beam (p. 152)

•

Low beams (p. 151)

•

Rear fog light (p. 155)

•

Active Bending Lights* (p. 155)

•

Brake lights (p. 156)

•

Emergency brake lights (p. 156)

•

Hazard warning flashers (p. 157)

Adjusting light functions via the

center display

A number of light functions can be adjusted and
activated via the center display. These include
active high beams, home safe lighting and
approach lighting.

1. Tap

Settings

in the Top view.

2. Tap

My Car

Lights and Lighting

3. Select

Exterior Lights

Interior Lighting

and then the function that you would like to
adjust.

Related information

•

Lighting panel and controls (p. 148)

•

Active high beam (p. 153)

•

Using home safe lighting (p. 157)

•

Welcome Light (p. 157)

•

Using turn signals (p. 154)

•

Changing settings in the center display's Top
view (p. 128)

•

Function view in the center display (p. 118)

LIGHTING

150

Parking lights

The parking lights can be used to help other
road users see the vehicle if it is stopped or
parked. Use the lighting ring on the steering
wheel lever to turn on the parking lights.

Lighting ring in the parking light position.

Turn the lighting ring to the

position to

turn on the parking lights (the license plate light-
ing will also illuminate).

Canadian models: If the ignition is in the II posi-
tion, the daytime running lights will illuminate
instead of the front parking lights. With the light-
ing ring in this position, the parking lights will
remain on regardless of what position the ignition
is in.

US models: When

mode is selected, the

daytime running lights can be deactivated in the
center display. The parking lights will also be

deactivated. In weak daylight or dark conditions,
the parking lights and low beams will be illumi-
nated.

In dark conditions, the rear parking lights also
illuminate when the trunk lid is opened to alert
following traffic. This happens regardless of what
position the lighting ring or ignition is in.

Related information

•

Lighting panel and controls (p. 148)

•

Ignition modes (p. 429)

Daytime running lights

The vehicle has sensors that detect ambient
lighting conditions. With the lighting ring in the

position, the daytime running lights will

always be activated when the ignition is in mode
II. In weak daylight or dark conditions, the head-
lights automatically switch to low beams.

Lighting ring in AUTO position.

LIGHTING

}}

* Option/accessory.

151

With the steering wheel lever's lighting ring in the

position, the daytime running lights (DRL

)

will illuminate when the vehicle is driven in day-
light conditions. The headlights will switch auto-
matically from daytime running lights to low
beams in weak daylight or dark conditions. The
headlights will also switch to low beams if the
front fog lights* and/or rear fog light are acti-
vated.

US models: When

mode is selected, the

daytime running lights can be deactivated in the
center display. The parking lights will also be
deactivated. In weak daylight or dark conditions,
the parking lights and low beams will be illumi-
nated.

US models: With the lighting ring in the
or

position, the daytime running lights will

be off.

Canadian models: With the lighting ring in the

position, the daytime running

lights will be on.
