Toyota Corolla Cross (2024 year). Manual in english

385

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

■

Front turn signal lights
(bulb type)

Turn the bulb base counter-
clockwise.

Remove the light bulb.

When installing, reverse the
steps listed.

■

Tail lights/rear side marker
lights (bulb type)

Open the back door.

Remove the 2 screws and
then remove the light unit by
pulling it straight back.

Turn the bulb base counter-
clockwise.

Remove the light bulb.

When installing the light bulb,
install it by conducting steps

and

with the directions

reversed.

Install the light unit.

Align the 2 guides and push the
light unit toward the front of the
vehicle to install it.

386

6-3. Do-it-yourself maintenance

Install the 2 screws.

■

Back-up lights

Open the back door and
remove the cover.

Using a flathead screwdriver,
remove the cover.

To prevent damage to the vehicle,
wrap the tip of the flathead screw-
driver with tape, etc.

Turn the bulb base counter-
clockwise and remove it.

Remove the light bulb.

When installing the light bulb,
install it by conducting steps

and

with the directions

reversed.

Install the cover.

Align the tabs of the cover with the
grooves and install the cover.

387

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

■

License plate lights

Remove the lens.

Lens

Hook

Insert a small flathead screw-
driver, etc. into either the
right or left hole of the lens.

Push the screwdriver side-
ways in the direction of the
arrow shown in the illustra-
tion, disengage the hook, and
then remove the lens.

To prevent damage to the vehicle,
wrap the tip of the screwdriver with
tape, etc.

Remove the light bulb.

Install a new light bulb.

Install the lens.

Hooks

Fit the lens into either the

388

6-3. Do-it-yourself maintenance

right or left hooks.

Push the lens into place.

After installation, confirm that the

lens is properly installed by gently

pulling it.

WARNING

■

To prevent injury

Before performing any light bulb

replacement procedure, be sure

to turn the engine switch off. Fail-

ure to do so may result in burns

from hot components or a part of

your body may get caught on an

operating component, possibly

causing serious injury.

■

Replacing light bulbs

●

Turn off the lights. Do not

attempt to replace the bulb

immediately after turning off the

lights. The bulbs become very

hot and may cause burns.

●

Do not touch the glass portion

of the light bulb with bare

hands. When it is unavoidable

to hold the glass portion, use

and hold with a clean dry cloth

to avoid getting moisture and

oils on the bulb. Also, if the bulb

is scratched or dropped, it may

blow out or crack.

●

Fully install light bulbs and any

parts used to secure them. Fail-

ure to do so may result in heat

damage, fire, or water entering

the light unit. This may damage

the lights or cause condensa-

tion to build up on the lens.

■

To prevent damage or fire

●

Make sure bulbs are fully

seated and locked.

●

Check the wattage of the bulb

before installing to prevent heat

damage.

389

Whe

n tr

ouble

ises

When trouble arises

7-1. Essential information

Emergency flashers ....

390

If your vehicle has to be

stopped in an emergency

..................................

390

If the vehicle is submerged

or water on the road is ris-
ing .............................

392

7-2. Steps to take in an emer-

gency

If your vehicle needs to be

towed.........................

393

If you think something is

wrong ........................

397

Fuel pump shut off system

..................................

398

If a warning light turns on or

a warning buzzer sounds

..................................

399

If a warning message is dis-

played........................

409

If you have a flat tire....

414

If the engine will not start

..................................

424

If you lose your keys ...

426

If the electronic key does

not operate properly ..

426

If the vehicle battery is dis-

charged .....................

428

If your vehicle overheats

..................................

432

If the vehicle becomes stuck

..................................

434

390

7-1. Essential information

7-1.Essential information

Press the switch.

All the turn signal lights will flash.

To turn them off, press the switch
once again.

■

Emergency flashers

●

If the emergency flashers are
used for a long time while the
engine is not operating, the bat-
tery may discharge.

●

If any of the SRS airbags deploy
(inflate) or in the event of a strong
rear impact, the emergency flash-
ers will turn on automatically.
The emergency flashers will turn
off automatically after operating
for approximately 20 minutes. To
manually turn the emergency
flashers off, press the switch
twice.
(The emergency flashers may not
turn on automatically depending
on the force of the impact and
conditions of the collision.)

Steadily step on the brake
pedal with both feet and
firmly depress it.

Do not pump the brake pedal
repeatedly as this will increase the
effort required to slow the vehicle.

Shift the shift lever to N.



If the shift lever is shifted to N

After slowing down, stop the
vehicle in a safe place by the
road.

Stop the engine.



If the shift lever cannot be
shifted to N

Keep depressing the brake
pedal with both feet to reduce
vehicle speed as much as
possible.

Vehicles without a smart key
system: Stop the engine by

Emergency flashers

The emergency flashers are
used to warn other drivers
when the vehicle has to be
stopped on the road due to
a breakdown, etc.

Operating instructions

If your vehicle has to

be stopped in an emer-

gency

Only in an emergency, such
as if it becomes impossible
to stop the vehicle in the
normal way, stop the vehicle
using the following proce-
dure:

Stopping the vehicle

391

7-1. Essential information

Whe

trouble

ises

turning the engine switch to

ACC.

Vehicles with a smart key

system: To stop the engine,

press and hold the engine

switch for 2 consecutive sec-

onds or more, or press it

briefly 3 times or more in suc-

cession.

Stop the vehicle in a safe

place by the road.

WARNING

■

If the engine has to be turned

off while driving

●

Power assist for the brakes and

steering wheel will be lost, mak-

ing the brake pedal harder to

depress and the steering wheel

heavier to turn. Decelerate as

much as possible before turning

off the engine.

●

Vehicles without a smart key

system: Never attempt to

remove the key.

392

7-1. Essential information



If the door can be opened,

open the door and exit the

vehicle.



If the door cannot be opened,

open the window using the

power window switch and

ensure an escape route.



If the window can be opened,

exit the vehicle through the

window.



If the door and window cannot

be opened due to the rising

water, remain calm, wait until

the water level inside the

vehicle rises to the point that

the water pressure inside of

the vehicle equals the water

pressure outside of the vehi-

cle and then open the door

after waiting for the rising

water to enter the vehicle, and

exit the vehicle. When the

outside water level exceeds

half the height of the door, the

door cannot be opened from

the inside due to water pres-

sure.

When the outside water level

exceeds half the height of the door,

the door cannot be opened from the

inside due to water pressure.

■

Water level exceeds the floor

When the water level exceeds the

floor and time has passed, the elec-

trical equipment will get damaged,

the power windows will not operate,

the engine stop, and the vehicle

may not be able to get moving.

■

Using an emergency escape

hammer

Laminated glass is used in the wind-

shield on this vehicle.

Laminated glass cannot be shat-

tered with an emergency hammer

Tempered glass is used in the win-

dows on this vehicle.

: Contact your Toyota dealer or

aftermarket accessory manufac-

turer for further information about

an emergency hammer.

If the vehicle is sub-

merged or water on

the road is rising

This vehicle is not designed

to be able to drive on roads

that are deeply flooded with

water. Do not drive on roads

where the roads may be

submerged or the water

may be rising. It is danger-

ous to remain in the vehicle,

if it is anticipated that the

vehicle will be flooded or

set adrift. Remain calm and

follow the following.

WARNING

■

Caution while driving

Do not drive on roads where the

roads may be submerged or the

water may be rising. Otherwise

the vehicle may be damaged and

cannot move, as well as become

flooded and set adrift, which may

lead to death.

393

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

7-2.Steps to take in an emergency

The following may indicate a
problem with your transmission.
Contact your Toyota dealer or
commercial towing service
before towing.



The engine is running but the
vehicle does not move.



The vehicle makes an abnor-
mal sound.



From the front (2WD models)

Release the parking brake.

Turn automatic mode off. (



P.175)



From the front (AWD models)

Use a towing dolly under the
rear wheels.



From the rear

Use a towing dolly under the
front wheels.

If your vehicle needs

to be towed

If towing is necessary, we
recommend having your
vehicle towed by your Toy-
ota dealer or commercial
towing service, using a
wheel-lift type truck or flat-
bed truck.

Use a safety chain system
for all towing, and abide by
all state/provincial and local
laws.

Situations when it is nec-
essary to contact dealers
before towing

Towing with a wheel-lift
type truck

394

7-2. Steps to take in an emergency

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

When towing the vehicle



2WD models

Be sure to transport the vehicle

with the front wheels raised or

with all four wheels raised off the

ground. If the vehicle is towed

with the front wheels contacting

the ground, the drivetrain and

related parts may be damaged.



AWD models

Be sure to transport the vehicle

with all four wheels raised off the

ground. If the vehicle is towed

with the tires contacting the

ground, the drivetrain or related

parts may be damaged, the vehi-

cle may fly off the truck.

NOTICE

■

To prevent damage to the

vehicle when towing using a

wheel-lift type truck

●

Vehicles without a smart key

system: Do not tow the vehicle

from the rear when the engine

switch is in the “LOCK” position

or the key is removed. The

steering lock mechanism is not

strong enough to hold the front

wheels straight.

●

Vehicles with a smart key sys-

tem: Do not tow the vehicle from

the rear when the engine switch

is off.

●

When raising the vehicle,

ensure adequate ground clear-

ance for towing at the opposite

end of the raised vehicle. With-

out adequate clearance, the

vehicle could be damaged while

being towed.

■

Towing with a sling-type truck

Do not tow with a sling-type truck

to prevent body damage.

■

When towing a vehicle

equipped with a Stop & Start

system

If it is necessary to tow the vehicle

with all 4 wheels on the ground,

perform the following procedure

before towing the vehicle, in order

to protect the system.Turn the

engine switch off and then start

the engine or turn the engine

switch to ON.

395

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

When using a flat-bed truck to
transport the vehicle, use tire
strapping belts. Refer to the
owner's manual of the flat-bed
truck for the tire strapping
method.

In order to suppress vehicle
movement during transporta-
tion, set the parking brake and
turn the engine switch off.

If a tow truck is not available in
an emergency, your vehicle may
be temporarily towed using
cables or chains secured to the
emergency towing eyelet. This
should only be attempted on
hard surfaced roads for at most
50 miles (80 km) at under 18
mph (30 km/h).

A driver must be in the vehicle to
steer and operate the brakes.
The vehicle’s wheels, drive train,
axles, steering and brakes must
be in good condition.

To have your vehicle towed by
another vehicle, the towing eye-
let must be installed to your
vehicle. Install the towing eyelet

using the following procedure.

Take out the wheel nut
wrench and towing eyelet.
(



P.415)

Remove the eyelet cover
using a flathead screwdriver.

To protect the bodywork, place a
rag between the screwdriver and
the vehicle body as shown in the
illustration.

Insert the towing eyelet into
the hole and tighten partially
by hand.

Using a flatbed truck

Emergency towing (vehi-
cles with a towing eyelet)

Emergency towing proce-
dure (vehicles with a tow-
ing eyelet)

396

7-2. Steps to take in an emergency

Tighten down the towing eye-

let securely using a wheel nut

wrench or hard metal bar.

Securely attach cables or

chains to the towing eyelet.

Take care not to damage the vehi-

cle body.

Enter the vehicle being towed

and start the engine.

If the engine does not start, turn the

engine switch to ON.

Shift the shift lever to N and

release the parking brake.

Turn automatic mode off. (



P.175)

When the shift lever cannot be

shifted:



P.171

■

While towing

If the engine is not running, the

power assist for the brakes and

steering will not function, making

steering and braking more difficult.

■

Wheel nut wrench

Wheel nut wrench is installed in lug-

gage compartment. (



P.415)

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

While towing

●

When towing using cables or

chains, avoid sudden starts, etc.

which place excessive stress on

the towing eyelet, cables or

chains. The towing eyelet,

cables or chains may become

damaged, broken debris may hit

people, and cause serious dam-

age.

●

Do not turn the engine switch

off.

There is a possibility that the

steering wheel is locked and

cannot be operated.

■

Installing towing eyelets to

the vehicle

Make sure that towing eyelets are

installed securely.

If not securely installed, towing

eyelets may come loose during

towing.

NOTICE

■

To prevent damage to the

vehicle during emergency

towing

Do not secure cables or chains to

the suspension components.

397

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises



Fluid leaks under the vehicle.
(Water dripping from the air
conditioning after use is nor-
mal.)



Flat-looking tires or uneven
tire wear



Engine coolant temperature
gauge needle continually
points higher than normal.



Changes in exhaust sound



Excessive tire squeal when
cornering



Strange noises related to the
suspension system



Pinging or other noises
related to the engine



Engine missing, stumbling or
running roughly



Appreciable loss of power



Vehicle pulls heavily to one

side when braking



Vehicle pulls heavily to one
side when driving on a level
road



Loss of brake effectiveness,
spongy feeling, pedal almost
touches the floor

If you think something

is wrong

If you notice any of the fol-
lowing symptoms, your
vehicle probably needs
adjustment or repair. Con-
tact your Toyota dealer as
soon as possible.

Visible symptoms

Audible symptoms

Operational symptoms

398

7-2. Steps to take in an emergency

Follow the procedure below to

restart the engine after the sys-

tem is activated.

Turn the engine switch to

ACC or OFF.

Restart the engine.

Fuel pump shut off

system

To minimize the risk of fuel

leakage when the engine

stalls or when an airbag

inflates upon collision, the

fuel pump shut off system

stops the supply of fuel to

the engine.

Restarting the engine

NOTICE

■

Before starting the engine

Inspect the ground under the

vehicle.

If you find that fuel has leaked

onto the ground, the fuel system

has been damaged and is in need

of repair. Do not restart the

engine.

399

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Brake system warning light (warning buzzer)

■

Brake system warning light

■

High coolant temperature warning light

(warning buzzer)

: This light illuminates on the multi-information display.

If a warning light turns on or a warning buzzer

sounds

Calmly perform the following actions if any of the warning
lights comes on or flashes. If a light comes on or flashes, but
then goes off, this does not necessarily indicate a malfunction
in the system. However, if this continues to occur, have the
vehicle inspected by your Toyota dealer.

Actions to the warning lights or warning buzzers

Warning light

Details/Actions

(U.S.A.)

(Red)

(Canada)

Indicates that:



The brake fluid level is low; or



The brake system is malfunctioning



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer. Continuing to drive the vehi-
cle may be dangerous.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in:



The regenerative braking system;



The electronically controlled brake system; or



The parking brake system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

Indicates that the engine coolant temperature is exces-
sively high



Immediately stop the vehicle in a safe place.
Handling method (



P.432)

400

7-2. Steps to take in an emergency

■

Charging system warning light (warning buzzer)

■

Low engine oil pressure warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Malfunction indicator lamp (warning buzzer)

■

SRS warning light

Warning light

Details/Actions

Indicates a malfunction in the vehicle’s charging system



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

Warning light

Details/Actions

Indicates that the engine oil pressure is excessively low



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The electronic engine control system;



The electronic throttle control system;



The electronic continuously variable transmission control
system; or



The Stop & Start system



Immediately stop the vehicle in a safe place and con-
tact your Toyota dealer.

Warning light

Details/Actions

Indicates a malfunction in:



The SRS airbag system; or



The seat belt pretensioner system



Have the vehicle inspected by your Toyota dealer
immediately.

401

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

ABS warning light

■

Inappropriate pedal operation warning light

(warning buzzer)

: This light illuminates on the multi-information display.

■

Electric power steering system warning light (warning
buzzer)

Warning light

Details/Actions

(U.S.A.)

(Canada)

Indicates a malfunction in:



The ABS; or



The brake assist system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

When a buzzer sounds:



Brake Override System is malfunctioning



Drive-Start Control is malfunctioning



Drive-Start Control is operating



Follow the instructions displayed on the multi-infor-
mation display. (



P.409)

When a buzzer does not sound:

Brake Override System is operating.



Release the accelerator pedal and depress the brake
pedal.

Warning light

Details/Actions

(Red/yellow)

Indicates a malfunction in the EPS (Electric Power Steer-
ing) system



Have the vehicle inspected by your Toyota dealer
immediately.

402

7-2. Steps to take in an emergency

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warn-
ing buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or
her seat belt is not fastened. Once the engine switch is turned to ON, the
buzzer sounds. If the seat belt is still unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain
speed.

Front passenger’s seat belt warning buzzer:

The front passenger’s seat belt warning buzzer sounds to alert the front
passenger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.

Warning light

Details/Actions

2WD models: Indicates that remaining fuel is approximately
1.8 gal. (7.0 L, 1.5 Imp. gal.) or less

AWD models: Indicates that remaining fuel is approximately
2.0 gal. (7.5 L, 1.6 Imp. gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat
belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

403

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Rear passengers’ seat belt reminder lights (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear pas-
senger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time, after the
seat belt is fastened and unfastened and the vehicle reaches a certain
speed.

■

Tire pressure warning light (warning buzzer)

■

LTA indicator (warning buzzer)

Warning light

Details/Actions

(4.2-inch dis-

play)

(7-inch dis-

play)

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

Warning light

Details/Actions

When the light comes on after blinking for approximately 1
minute:

Malfunction in the tire pressure warning system



Have the system checked by your Toyota dealer.

When the light comes on:

Low tire inflation pressure such as



Natural causes



Flat tire



Immediately stop the vehicle in a safe place.
Handling method (



P.407)

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in the LTA (Lane Tracing Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.210)

404

7-2. Steps to take in an emergency

■

PDA indicator (warning buzzer)

■

LDA indicator (warning buzzer)

■

Stop & Start cancel indicator (warning buzzer)

■

Intuitive parking assist OFF indicator (warning buzzer)

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in the PDA (Proactive Driving
Assist).



Follow the instructions displayed on the multi-infor-
mation display.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in the LDA (Lane Departure Alert).



Follow the instructions displayed on the multi-infor-
mation display. (



P.409)

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the Stop & Start system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

(if equipped)

Indicates a malfunction in the intuitive parking assist func-
tion



Have the vehicle inspected by your Toyota dealer
immediately.

Indicates that the system is temporarily unavailable, possi-
bly due to a sensor being dirty or covered with ice, etc.



Follow the instructions displayed on the multi-infor-
mation display. (



P.268)

405

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

PCS warning light (warning buzzer)

■

Dynamic radar cruise control indicator (warning buzzer)

■

Cruise control indicator (warning buzzer)

■

Driving assist information indicator

Warning light

Details/Actions

Indicates a malfunction in the PCS (Pre-Collision System).

Follow the instructions displayed on the multi-information
display.

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in the dynamic radar cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.229)

Warning light

Details/Actions

(Yellow)

Indicates a malfunction in the cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.229)

Warning light

Details/Actions

Indicates either of the following systems may be malfunc-
tioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



Follow the instructions displayed on the multi-infor-
mation display. (



P.409)

Indicates one of the following systems is malfunctioning or
disabled.



PKSB (Parking Support Brake)



BSM (Blind Spot Monitor)



RCTA(Rear cross traffic alert)



Safe Exit Assist



Follow the instructions displayed on the multi-infor-
mation display. (



P.409)

406

7-2. Steps to take in an emergency

: If equipped

■

Slip indicator

■

Parking brake indicator

■

Brake hold operated indicator (warning buzzer)

■

Warning buzzer

In some cases, the buzzer may not
be heard due to being in a noisy
location or audio sound.

■

Front passenger detection sen-
sor, seat belt reminder and
warning buzzer

●

If luggage is placed on the front
passenger seat, the front passen-
ger detection sensor may cause
the warning light to flash and the
warning buzzer to sound even if a
passenger is not sitting in the

seat.

●

If a cushion is placed on the seat,
the sensor may not detect a pas-
senger, and the warning light may
not operate properly.

■

SRS warning light

This warning light indicates prob-
lems with the following:

●

Airbag sensor assembly

●

Front impact sensors

●

Side impact sensors (front door)

●

Side impact sensors (front)

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRAC system; or



The hill-start assist control system



Have the vehicle inspected by your Toyota dealer
immediately.

Warning light

Details/Actions

(Flashes)

(U.S.A.)

(Flashes)
(Canada)

It is possible that the parking brake is not fully engaged or
released



Operate the parking brake switch once again.

This light comes on when the parking brake is not released.
If the light turns off after the parking brake is fully released,
the system is operating normally.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Toyota dealer
immediately.

407

7-2. Steps to take in an emergency

Whe

trouble

ises

●

Front passenger occupant classifi-

cation sensors

●

Front passenger’s seat belt buckle

switch

●

“AIR BAG ON” indicator light

●

“AIR BAG OFF” indicator light

●

SRS airbags

●

SRS system related wiring har-

nesses and power sources

■

Electric power steering system

warning light (warning buzzer)

When the battery charge becomes

insufficient or the voltage temporar-

ily drops, the electric power steering

system warning light may come on

and the warning buzzer may sound.

■

When the tire pressure warning

light comes on

Inspect the tires to check if a tire is

punctured.
If a tire is punctured:



P.414

If none of the tires are punctured:

Turn the engine switch off then turn

it to ON. Check if the tire pressure

warning light comes on or blinks.



If the tire pressure warning light

blinks for approximately 1 minute

then stays on

There may be a malfunction in the

tire pressure warning system. Have

the vehicle inspected by your Toyota

dealer immediately.



If the tire pressure warning light

comes on

After the temperature of the tires

has lowered sufficiently, check

the inflation pressure of each tire

and adjust them to the specified

level.

If the warning light does not turn

off even after several minutes

have elapsed, check that the

inflation pressure of each tire is

at the specified level and perform

initialization. (



P.365)

■

The tire pressure warning light

may come on due to natural

causes

The tire pressure warning light may

come on due to natural causes such

as natural air leaks and tire inflation

pressure changes caused by tem-

perature. In this case, adjusting the

tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a

spare tire

The compact spare tire is not

equipped with a tire pressure warn-

ing valve and transmitter. If a tire

goes flat, the tire pressure warning

light will not turn off even though the

flat tire has been replaced with the

spare tire. Replace the spare tire

with the repaired tire and adjust the

tire inflation pressure. The tire pres-

sure warning light will go off after a

few minutes.

■

Conditions that the tire pres-

sure warning system may not

function properly



P.364

WARNING

■

If both the ABS and the brake

system warning lights remain

Stop your vehicle in a safe place

immediately and contact your Toy-

ota dealer.

The vehicle will become

extremely unstable during brak-

ing, and the ABS system may fail,

which could cause an accident

resulting in death or serious injury.

408

7-2. Steps to take in an emergency

WARNING

■

When the electric power

steering system warning light

comes on

When the light comes on yellow,

the assist to the power steering is

restricted. When the light comes

on red, the assist to the power

steering is lost and handling oper-

ations of the steering wheel

become extremely heavy.

When steering wheel operations

are heavier than usual, grip the

steering wheel firmly and operate

it using more force than usual.

■

If the tire pressure warning

light comes on

Be sure to observe the following

precautions.

Failure to do so could cause a

loss of vehicle control and result

in death or serious injury.

●

Stop your vehicle in a safe place

as soon as possible. Adjust the

tire inflation pressure immedi-

ately.

●

If the tire pressure warning light

comes on even after tire infla-

tion pressure adjustment, it is

probable that you have a flat

tire. Check the tires. If a tire is

flat, change it with the spare tire

and have the flat tire repaired by

the nearest Toyota dealer.

●

Avoid abrupt maneuvering and

braking.

If the vehicle tires deteriorate,

you could lose control of the

steering wheel or the brakes.

■

If a blowout or sudden air

leakage should occur

The tire pressure warning system

may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if

provided), should be checked

monthly when cold and inflated to

the inflation pressure recom-

mended by the vehicle manufac-

turer on the vehicle placard or tire

inflation pressure label (tire and

load information label). (If your

vehicle has tires of a different size

than the size indicated on the

vehicle placard or tire inflation

pressure label [tire and load infor-

mation label], you should deter-

mine the proper tire inflation

pressure for those tires.)
As an added safety feature, your

vehicle has been equipped with a

tire pressure monitoring system

(TPMS-tire pressure warning sys-

tem) that illuminates a low tire

pressure telltale (tire pressure

warning light) when one or more

of your tires is significantly

under-inflated. Accordingly, when

the low tire pressure telltale (tire

pressure warning light) illumi-

nates, you should stop and check

your tires as soon as possible,

and inflate them to the proper

pressure. Driving on a signifi-

cantly under-inflated tire causes

the tire to overheat and can lead

to tire failure. Under-inflation also

reduces fuel efficiency and tire

tread life, and may affect the vehi-

cle’s handling and stopping ability.
Please note that the TPMS (tire

pressure warning system) is not a

substitute for proper tire mainte-

nance, and it is the driver’s

responsibility to maintain correct

tire pressure, even if under-infla-

tion has not reached the level to

trigger illumination of the TPMS

low tire pressure telltale (tire pres-

sure warning light).

409

7-2. Steps to take in an emergency

Whe

trouble

ises

■

Warning messages

The warning messages explained

below may differ from the actual

messages according to operation

conditions and vehicle specifica-

tions.

■

Warning buzzer

A buzzer may sound when a mes-

sage is displayed.

The buzzer may not be audible if the

vehicle is in a noisy location or if the

audio system volume is high.

■

If “Engine Oil Level Low Add or

Replace” is displayed

The engine oil level is low. Check

WARNING

Your vehicle has also been

equipped with a TPMS (tire pres-

sure warning system) malfunc-

tion indicator to indicate when the

system is not operating properly.

The TPMS (tire pressure warning

system) malfunction indicator is

combined with the low tire pres-

sure telltale (tire pressure warning

light). When the system detects a

malfunction, the telltale will flash

for approximately one minute and

then remain continuously illumi-

nated. This sequence will con-

tinue upon subsequent vehicle

start-ups as long as the malfunc-

tion exists. When the malfunction

indicator is illuminated, the sys-

tem may not be able to detect or

signal low tire pressure as

intended.
TPMS (tire pressure warning sys-

tem) malfunctions may occur for a

variety of reasons, including the

installation of replacement or

alternate tires or wheels on the

vehicle that prevent the TPMS

(tire pressure warning system)

from functioning properly. Always

check the TPMS (tire pressure

warning system) malfunction tell-

tale after replacing one or more

tires or wheels on your vehicle to

ensure that the replacement or

alternate tires and wheels allow

the TPMS (tire pressure warning

system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure

warning system operates

properly

Do not install tires with different

specifications or makers, as the

tire pressure warning system may

not operate properly.

If a warning message

is displayed

The multi-information dis-

play shows warnings for

system malfunctions and

incorrectly performed oper-

ations, and messages that

indicate a need for mainte-

nance. When a message is

displayed, perform the

appropriate corrective

action for the message.
If a warning message is dis-

played again after the

appropriate actions have

been performed, contact

your Toyota dealer.
Additionally, if a warning

light comes on or flashes at

the same time that a warn-

ing message is displayed,

take the appropriate correc-

tive action for the warning

light. (



P.399)

410

7-2. Steps to take in an emergency

the level of the engine oil, and add if
necessary.(



P.354)

This message may appear if the
vehicle is stopped on a slope. Move
the vehicle to a level surface and
check to see if the message disap-
pears.

■

If “Engine Stopped Steering
Power Low” is displayed

This message is displayed if the
engine is stopped while driving.

When steering wheel operations are
heavier than usual, grip the steering
wheel firmly and operate it using
more force than usual.

■

If “Auto power off to conserve
battery” is displayed

Power was cut off due to the auto-
matic power off function. Next time
when starting the engine, increase
the engine speed slightly and main-
tain that level for approximately 5
minutes to recharge the battery.

■

If “Headlight System Malfunc-
tion Visit Your Dealer” is dis-
played

The following systems may be mal-
functioning. Have the vehicle
inspected by your Toyota dealer
immediately.

●

The LED headlight system

●

AFS (Adaptive Front-lighting Sys-
tem) (if equipped)

●

The automatic headlight leveling
system (if equipped)

●

Automatic High Beam

■

If “AWD System Malfunction
2WD Mode Engaged Visit Your
Dealer” or “AWD System Over-
heated Switching to 2WD
Mode” is displayed

This message may be displayed
when driving under extremely high
load conditions.

Drive the vehicle at low speeds and
stop the vehicle in a safe place with
the engine operating until the mes-
sage is cleared.

If the message is not cleared, have
the vehicle inspected by your Toyota
dealer.

■

If “System Malfunction Visit
Your Dealer” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

PDA (Proactive Driving Assist)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

Safe Exit Assist (if equipped)

●

Intuitive Parking Assist (if
equipped)

●

PKSB (Parking Support Brake)

(if equipped)

Have the vehicle inspected by your
Toyota dealer immediately.

■

If a message that indicates the
need for visiting your Toyota
dealer is displayed

The system or part shown on the
multi-information display is malfunc-
tioning. Have the vehicle inspected
by your Toyota dealer immediately.

■

If “System Stopped See
Owner's Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

411

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

●

RSA (Road Sign Assist) (if

equipped)

●

PDA (Proactive Driving Assist)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

Safe Exit Assist (if equipped)

●

Intuitive Parking Assist (if
equipped)

●

PKSB (Parking Support

Brake) (if equipped)

Follow the following correction
methods.

• Check the voltage of the battery

• Check the sensors that the Toyota

Safety System 3.0 uses for foreign
matter covering them. Remove
them if any. (



P.194)

• Close the back door

Indicates the sensors may not be
operating properly. (



P.198, 256,

260, 267, 281, 282)

●

Check the rear bumper around the
sensors used by the BSM, RCTA,
or Safe Exit Assist for foreign mat-
ter covering them. Remove them if
any. (



P.253, 264)

●

Check the sensors including cam-
era sensors used by the intuitive
parking assist and PKSB for for-
eign matter covering them.
Remove them if any. (



P.268)

●

When problems are solved and
the sensors are operational, this
indication may disappear by itself.

■

If “System Stopped Front Cam-
era Low Visibility See Owner’s
Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

PDA (Proactive Driving Assist)

Follow the following correction
methods.

• Using the windshield wipers,

remove the dirt or foreign matter
from the windshield.

• Using the air conditioning system,

defog the windshield.

• Close the hood, remove any stick-

ers, etc. to clear the obstruction in
front of the front camera.

■

If “System Stopped Front Cam-
era Out of Temperature Range
Wait until Normal Temperature”
is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

PDA (Proactive Driving Assist)

Follow the following correction
methods.

• If the front camera is hot, such as

after the vehicle is parked in the
sun, use the air conditioning sys-
tem to decrease the temperature
around the front camera

• If a sunshade was used when the

vehicle was parked, depending on
its type, the sunlight reflected from
the surface of the sunshade may
cause the temperature of the front
camera to become excessively
high

• If the front camera is cold, such

after the vehicle is parked in an

412

7-2. Steps to take in an emergency

extremely cold environment, use
the air conditioning system to
increase the temperature around
the front camera

■

If “System Stopped Front Radar
Sensor Blocked Clean Radar
Sensor” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

PDA (Proactive Driving Assist)

Follow the following correction
methods.

• Check if there is any foreign mat-

ter attached to the radar sensor or
radar sensor cover and clean
them if necessary (



P.194)

• This message may be displayed

when driving in an open area with
few nearby vehicles or structures,
such as a desert, grasslands, sub-
urbs, etc.

The message may be cleared by
driving the vehicle in an area with
structures, vehicles, etc., nearby.

■

If “System Stopped Front Radar
Sensor Out of Temperature
Range Wait until Normal Tem-
perature” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

PDA (Proactive Driving Assist)

The temperature of the radar sensor
is outside of the operating range.
Wait for the temperature to become
appropriate.

■

If “System Stopped Front Radar
In Self Calibration See Owner’s
Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LTA (Lane Tracing Assist)

●

LDA (Lane Departure Alert)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

PDA (Proactive Driving Assist)

Follow the following correction
methods.

• Check if there is any foreign mat-

ter attached to the radar sensor or
radar sensor cover and clean
them if necessary (



P.194)

• The radar sensor may be mis-

aligned and will be adjusted auto-
matically while driving. Continue
driving for a while.

■

If “Cruise Control Unavailable
See Owner's Manual” is dis-
played

Indicates one of the following sys-
tems is disabled.

●

Dynamic radar cruise control

●

Cruise control

A message is displayed when the
driving assist switch is pushed
repeatedly.

Press the driving assist switch
quickly and firmly.

■

If “Maintenance Required
Soon” is displayed

Indicates that all maintenance
according to the driven distance on
the maintenance schedule

should

be performed soon.

Comes on approximately 4500
miles (7200 km) after the message
has been reset. If necessary, per-
form maintenance. Please reset the
message after the maintenance is
performed. (



P.438)

413

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-
ual Supplement” for the mainte-
nance interval applicable to your
vehicle.

■

If “Maintenance Required Visit
Your Dealer” is displayed

Indicates that all maintenance is
required to correspond to the driven
distance on the maintenance sched-
ule

Comes on approximately 5000
miles (8000 km) after the message
has been reset. (The indicator will
not work properly unless the mes-
sage has been reset.) Perform the
necessary maintenance. Please
reset the message after the mainte-
nance is performed. (



P.438)

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-
ual Supplement” for the mainte-
nance interval applicable to your
vehicle.

■

If “Engine Maintenance
Required Visit Your Dealer” is
displayed

The engine or an engine component
is malfunctioning. Have the vehicle
inspected by your Toyota dealer
immediately.

■

If “Oil Maintenance Required
Soon” is displayed

Indicates that the engine oil should
be scheduled to be changed.

Check the engine oil and change it if
necessary. After changing the
engine oil, make sure to reset the
message. (



P.354)

■

If “Oil Maintenance Required” is
displayed

Indicates that the engine oil should
be changed.

Check and change the engine oil,
and oil filter by your Toyota dealer.
After changing the engine oil, make

sure to reset the message.
(



P.354)

■

If a message that indicates the
need for referring to Owner’s
Manual is displayed

●

If “Engine Coolant Temp High” is
displayed, follow the instructions
accordingly. (



P.432)

●

If the following message is dis-
played on the multi-information
display, it may indicate a malfunc-
tion. Have the vehicle inspected
by your Toyota dealer immedi-
ately.

• “Smart Key System malfunction”

●

If any of the following messages
are displayed on the multi-infor-
mation display, it may indicate a
malfunction. Immediately stop the
vehicle and contact your Toyota
dealer.

• “Braking Power Low”
• “Oil Pressure Low”

414

7-2. Steps to take in an emergency



Stop the vehicle in a safe

place on a hard, flat surface.



Set the parking brake.



Shift the shift lever to P.



Stop the engine.



Turn on the emergency flash-

ers.

If you have a flat tire

Your vehicle is equipped

with a spare tire. The flat tire

can be replaced with the

spare tire.
For details about tires:



P.360

WARNING

■

If you have a flat tire

Do not continue driving with a flat

tire. Driving even a short distance

with a flat tire can damage the tire

and the wheel beyond repair,

which could result in an accident.

Before jacking up the

vehicle

416

7-2. Steps to take in an emergency



AWD models

Jack
Wheel nut wrench
Wheel lock key (if equipped)
Jack handle
Spare tire

WARNING

■

Using the tire jack

Observe the following precau-

tions. Improper use of the tire jack

may cause the vehicle to sud-

denly fall off the jack, leading to

death or serious injury.

●

Do not use the tire jack for any

purpose other than replacing

tires or installing and removing

tire chains.

●

Only use the tire jack that

comes with this vehicle for

replacing a flat tire. Do not use it

on other vehicles, and do not

use other tire jacks for replacing

tires on this vehicle.

●

Put the jack properly in its jack

point.

●

Do not put any part of your body

under the vehicle while it is sup-

ported by the jack.

●

Do not start the engine or drive

the vehicle while the vehicle is

supported by the jack.

Toyota Corolla Cross (2024 year). Manual in english - page 13
