Toyota Corolla Cross (2024 year). Manual in english

353

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Holding a rag under the end,

pull the dipstick out.

Wipe the dipstick clean.

Reinsert the dipstick fully.

Holding a rag under the end,

pull the dipstick out and

check whether the oil level is

above low level mark.

Low level mark

The shape of the dipstick may differ

depending on the type of vehicle or

engine.

Wipe the dipstick and reinsert

it fully.

■

Engine oil consumption

A certain amount of engine oil will

be consumed while driving. In the

following situations, oil consump-

tion may increase, and engine oil

may need to be refilled in between

oil maintenance intervals.

●

When the engine is new, for

example directly after purchasing

the vehicle or after replacing the

engine

●

If low quality oil or oil of an inap-

propriate viscosity is used

●

When driving at high engine

speeds or with a heavy load,

when towing, or when driving

while accelerating or decelerating

frequently

●

When leaving the engine idling for

a long time, or when driving fre-

quently through heavy traffic

■

Engine oil level rise

If the vehicle is repeatedly driven

without the engine warmed up,

moisture caused by dew condensa-

tion inside the engine or fuel which

did not burn mixes into the engine

oil, resulting in a rise in engine oil

level. However, this is not a mal-

function. For example, the engine

become difficult to be warmed up in

the following situations.

●

When driving a short distance

●

When driving at a low speed

●

When the outside temperature is

low

When checking the engine oil, make

sure that the engine is warmed up. If

the engine oil level exceeds the refill

upper limit mark, contact your Toy-

ota dealer.

NOTICE

■

To prevent serious engine

damage

Check the oil level on a regular

basis.

354

6-3. Do-it-yourself maintenance

■

Checking the oil type and
preparing the item needed

Make sure to check the oil type
and prepare the items needed
before adding oil.



Engine oil selection



P.440



Oil quantity (Low level mark



Refill upper limit mark)

1.6 qt. (1.5 L, 1.3 Imp. qt.)



Item
Clean funnel

■

Adding engine oil

If the oil level is below or near
the low level mark, add engine
oil of the same type as that
already in the engine.

Remove the oil filler cap by
turning it counterclockwise.

Add engine oil slowly, check-
ing the dipstick.

Make sure that the oil level does
not exceed the refill upper limit
mark and is between the low level

mark and refill upper limit mark.

Low level mark

Refill upper limit mark

The shape of the dipstick may differ
depending on the type of vehicle or
engine.

Install the oil filler cap by
turning it clockwise.

■

After changing the engine oil

The engine oil maintenance data
should be reset. Perform the follow-
ing procedures:

Use the meter control switches to
reset. (



P.84, 91)



4.2-inch display

Park the vehicle in a safe place
and then start the engine. The oil
maintenance cannot be reset
while the vehicle is moving.

Select

of the multi-informa-

tion display and then press OK.

Press

select

“Vehi-

cle Settings” and then press and

hold .

Press

select

“Oil

Maintenance” and then press

Press

select

“Yes”

and then press

Adding engine oil

355

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca



7-inch display

Park the vehicle in a safe place

and then start the engine. The oil

maintenance cannot be reset

while the vehicle is moving.

Select

of the multi-informa-

tion display and then press OK.

Press

to select “Vehi-

cle Settings” and then press and
hold .

Press

to select “Oil

Maintenance” and then press

Press

to select “Yes”

and then press

The coolant level is satisfactory

if it is between the “MAX” and

“MIN” lines on the reservoir

when the engine is cold.

Reservoir
“MAX” line
“MIN” line

If the level is on or below the “MIN”

line, add coolant up to the “MAX”

line. (



P.432)

■

Coolant selection

Only use “Toyota Super Long Life

Coolant” or a similar high quality

ethylene glycol based non-silicate,

non-amine, non-nitrite, and

WARNING

■

Used engine oil

●

Used engine oil contains poten-

tially harmful contaminants

which may cause skin disorders

such as inflammation and skin

cancer, so care should be taken

to avoid prolonged and

repeated contact. To remove

used engine oil from your skin,

wash thoroughly with soap and

water.

●

Dispose of used oil and filters

only in a safe and acceptable

manner. Do not dispose of used

oil and filters in household trash,

in sewers or onto the ground.

Call your Toyota dealer, service

station or auto parts store for

information concerning recy-

cling or disposal.

●

Do not leave used engine oil

within the reach of children.

NOTICE

■

When replacing the engine oil

●

Be careful not to spill engine oil

on the vehicle components.

●

Avoid overfilling, or the engine

could be damaged.

●

Check the oil level on the dip-

stick every time you refill the

vehicle.

●

Be sure the engine oil filler cap

is properly tightened.

Checking the engine cool-

ant

356

6-3. Do-it-yourself maintenance

non-borate coolant with long-life

hybrid organic acid technology.
U.S.A.:
“Toyota Super Long Life Coolant” is

a mixture of 50% coolant and 50%

deionized water. (Minimum tem-

perature: -31°F [-35°C])
Canada:
“Toyota Super Long Life Coolant” is

a mixture of 55% coolant and 45%

deionized water. (Minimum tem-

perature: -44°F [-42°C])
For more details about coolant, con-

tact your Toyota dealer.

■

If the coolant level drops within

a short time of replenishing

Visually check the radiator, hoses,

engine coolant reservoir caps, drain

cock and water pump.

If you cannot find a leak, have your

Toyota dealer test the cap and

check for leaks in the cooling sys-

tem.

Check the radiator and con-

denser and clear away any for-

eign objects. If either of the

above parts is extremely dirty or

you are not sure of their condi-

tion, have your vehicle

inspected by your Toyota dealer.

■

Checking fluid level

The brake fluid level should be

between the “MAX” and “MIN”

lines on the tank.

WARNING

■

When the engine is hot

Do not remove the engine coolant

reservoir cap.
The cooling system may be under

pressure and may spray hot cool-

ant if the cap is removed, causing

serious injuries, such as burns.

NOTICE

■

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct

mixture of water and antifreeze

must be used to provide proper

lubrication, corrosion protection

and cooling. Be sure to read the

antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to

prevent it from damaging parts or

paint.

Checking the radiator and

condenser

WARNING

■

When the engine is hot

Do not touch the radiator or con-

denser as they may be hot and

cause serious injuries, such as

burns.

Checking and adding the

brake fluid

357

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

■

Adding fluid

Slide and lift up the rubber

strip to partly remove it as

shown.

Disconnect the claws and

remove the service cover.

Remove the reservoir cap.

Add brake fluid slowly while

checking the fluid level.

Make sure to check the fluid

type and prepare the necessary

item.



Fluid type

FMVSS No.116 DOT 3 or SAE

J1703 brake fluid
FMVSS No.116 DOT 4 or SAE

J1704 brake fluid



Item

Clean funnel

■

Brake fluid can absorb moisture

from the air

Excess moisture in the brake fluid

can cause a dangerous loss of brak-

ing efficiency. Use only newly

opened brake fluid.

Check the battery as follows.

■

Battery exterior

Make sure that the battery termi-

nals are not corroded and that

there are no loose connections,

cracks, or loose clamps.

WARNING

■

When filling the reservoir

Take care as brake fluid can harm

your hands and eyes and damage

painted surfaces.

If fluid gets on your hands or in

your eyes, flush the affected area

with clean water immediately.
If you still experience discomfort,

see a doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level

to go down slightly as the brake

pads wear out or when the fluid

level in the accumulator is high.

If the reservoir needs frequent

refilling, there may be a serious

problem.

Battery

358

6-3. Do-it-yourself maintenance

Terminals
Hold-down clamp

■

Before recharging

When recharging, the battery pro-

duces hydrogen gas which is flam-

mable and explosive. Therefore,

observe the following precautions

before recharging:

●

If recharging with the battery

installed on the vehicle, be sure to

disconnect the ground cable.

●

Make sure the charger is off when

connecting and disconnecting the

charger cables to the battery.

■

After recharging/reconnecting

the battery (vehicles with a

smart key system)

●

Unlocking the doors using the

smart key system may not be pos-

sible immediately after reconnect-

ing the battery. If this happens,

use the wireless remote control or

the mechanical key to lock/unlock

the doors.

●

Start the engine with the engine

switch in ACC. The engine may

not start with the engine switch

turned off. However, the engine

will operate normally from the sec-

ond attempt.

●

The engine switch mode is

recorded by the vehicle. If the bat-

tery is reconnected, the vehicle

will return the engine switch mode

to the status it was in before the

battery was disconnected. Make

sure to turn off the engine before

disconnecting the battery. Take

extra care when connecting the

battery if the engine switch mode

prior to discharge is unknown.

If the system will not start even after

multiple attempts, contact your Toy-

ota dealer.

WARNING

■

Chemicals in the battery

The battery contains poisonous

and corrosive sulfuric acid and

may produce hydrogen gas which

is flammable and explosive. To

reduce the risk of death or serious

injury, take the following precau-

tions while working on or near the

battery:

●

Do not cause sparks by touch-

ing the battery terminals with

tools.

●

Do not smoke or light a match

near the battery.

●

Avoid contact with eyes, skin

and clothes.

●

Never inhale or swallow electro-

lyte.

●

Wear protective safety glasses

when working near the battery.

●

Keep children away from the

battery.

■

Where to safely charge the

battery

Always charge the battery in an

open area. Do not charge the bat-

tery in a garage or closed room

where there is insufficient ventila-

tion.

359

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Add washer fluid in the following

situations:



A washer does not work.



The warning message

appears on the multi-informa-

tion display.

WARNING

■

Emergency measures regard-

ing electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean

water for at least 15 minutes

and get immediate medical

attention. If possible, continue

to apply water with a sponge or

cloth while traveling to the near-

est medical facility.

●

If electrolyte gets on your skin

Wash the affected area thor-

oughly. If you feel pain or burn-

ing, get medical attention

immediately.

●

If electrolyte gets on your

clothes

It can soak through clothing on

to your skin. Immediately take

off the clothing and follow the

procedure above if necessary.

●

If you accidentally swallow elec-

trolyte

Drink a large quantity of water

or milk. Get emergency medical

attention immediately.

■

When disconnecting the bat-

tery

Do not disconnect the negative (-)

terminal on the body side. The

disconnected negative (-) terminal

may touch the positive (+) termi-

nal, which may cause a short and

result in death or serious injury.

NOTICE

■

When recharging the battery

Never recharge the battery while

the engine is running. Also, be

sure all accessories are turned

off.

Adding the washer fluid

WARNING

■

When adding washer fluid

Do not add washer fluid when the

engine is hot or running as

washer fluid contains alcohol and

may catch fire if spilled on the

engine, etc.

NOTICE

■

Do not use any fluid other

than washer fluid

Do not use soapy water or engine

antifreeze instead of washer fluid.

Doing so may cause streaking on

the vehicle’s painted surfaces, as

well as damaging the pump lead-

ing to problems of the washer

fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as

necessary.

Refer to the freezing tempera-

tures listed on the label of the

washer fluid bottle.

360

6-3. Do-it-yourself maintenance

Check if the treadwear indica-
tors are showing on the tires.
Also check the tires for uneven
wear, such as excessive wear
on one side of the tread.

Check the spare tire condition
and pressure if not rotated.

New tread

Worn tread

Treadwear indicator

The location of treadwear indicators

is shown by a “TWI” or “

” mark,

etc., molded into the sidewall of
each tire.
Replace the tires if the treadwear
indicators are showing on a tire.

■

When to replace your vehicle’s
tires

Tires should be replaced if:

●

The treadwear indicators are
showing on a tire

●

You have tire damage such as
cuts, splits, cracks deep enough
to expose the fabric, and bulges
indicating internal damage

●

A tire goes flat repeatedly or can-
not be properly repaired due to the
size or location of a cut or other
damage

If you are not sure, consult with your
Toyota dealer.

■

Tire life

Any tire over 6 years old must be
checked by a qualified technician
even if it has seldom or never been
used or damage is not obvious.

■

Maximum load of tire

Check that the number given by
dividing the maximum load by 1.10
of the replacement tire is greater
than 1/2 of the Gross Axle Weight
Ratings (GAWR) of either the front
axle or the rear axle, whichever is
greater.

For the GAWR, see the Certification
Label.
For the maximum load of the tire,
see the load limit at maximum cold
tire inflation pressure mentioned on
the sidewall of the tire. (



P.448)

Tires

Replace or rotate tires in
accordance with mainte-
nance schedules and tread-
wear.

Checking tires

361

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

■

Tire types

●

Summer tires

Summer tires are high-speed perfor-

mance tires best suited to highway

driving under dry conditions. Since

summer tires do not have the same

traction performance as snow tires,

summer tires are inadequate for

driving on snow-covered or icy

roads. For driving on snow-covered

roads or icy roads, the use of snow

tires is recommended. When install-

ing snow tires, be sure to replace all

four tires.

●

All season tires

All season tires are designed to pro-

vide better traction in snow and to

be adequate for driving in most win-

ter conditions as well as for use

year-round. All season tires, how-

ever, do not have adequate traction

performance compared with snow

tires in heavy or loose snow. Also,

all season tires fall short in accelera-

tion and handling performance com-

pared with summer tires in highway

driving.

●

Snow tires

For driving on snow-covered roads

or icy roads, we recommend using

snow tires. If you need snow tires,

select tires of the same size, con-

struction and load capacity as the

originally installed tires. Since your

vehicle has radial tires as original

equipment, make sure your snow

tires also have radial construction.

Do not install studded tires without

first checking local regulations for

possible restrictions. Snow tires

should be installed on all wheels.

(



P.288)

■

If the tread on snow tires wears

down below 0.16 in. (4 mm)

The effectiveness of the tires as

snow tires is lost.

■

Checking the tire valves

When replacing the tires, check the

tire valves for deformation, cracks,

and other damage.

WARNING

■

When inspecting or replacing

tires

Observe the following precautions

to prevent accidents.

Failure to do so may cause dam-

age to parts of the drive train as

well as dangerous handling char-

acteristics, which may lead to an

accident resulting in death or seri-

ous injury.

●

Do not mix tires of different

makes, models or tread pat-

terns.

Also, do not mix tires of remark-

ably different treadwear.

●

Do not use tire sizes other than

those recommended by Toyota.

●

Do not mix differently con-

structed tires (radial, bias-belted

or bias-ply tires).

●

Do not mix summer, all season

and snow tires.

●

Do not use tires that have been

used on another vehicle.

Do not use tires if you do not

know how they were used previ-

ously.

●

Do not tow if your vehicle has a

compact spare tire installed.

362

6-3. Do-it-yourself maintenance

Rotate the tires in the order

shown.

Front

To equalize tire wear and extend

tire life, Toyota recommends that

tire rotation is carried out at the

same interval as tire inspection.
Do not fail to initialize the tire pres-

sure warning system after tire rota-

tion.

Your vehicle is equipped with a

tire pressure warning system

that uses tire pressure warning

valves and transmitters to detect

low tire inflation pressure before

serious problems arise.
The tire pressure warning sys-

tem of this vehicle adopts a

2-type warning system.



When “Adjust Pressure” is

displayed (Normal Warning)

The tire pressure warning light

comes on and a buzzer sounds

when the tire inflation pressure

becomes low due to natural air

leakage or outside temperature.

(Ways of coping:



P.403, 443)



When “Immediately Check

tire when Safe” is displayed

(Emergency Warning)

The tire pressure warning light

comes on and a buzzer sounds

when the tire inflation pressure

becomes low suddenly due to a

blowout. (Ways of coping:



P.403,

P.414)

However, the system may not be

able to detect sudden tire ruptures

(bursting, etc.).
The tire pressure detected by the

tire pressure warning system can

be displayed on the multi-informa-

tion display.
The unit can be changed.

NOTICE

■

If tire inflation pressure of

each tire becomes low while

driving

Do not continue driving, or your

tires and/or wheels may be

ruined.

■

Driving on rough roads

Take particular care when driving

on roads with loose surfaces or

potholes.

These conditions may cause

losses in tire inflation pressure,

reducing the cushioning ability of

the tires. In addition, driving on

rough roads may cause damage

to the tires themselves, as well as

the vehicle’s wheels and body.

Tire rotation

Tire pressure warning

system

363

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

■

How to change the unit



4.2-inch display

Park the vehicle in a safe
place and turn the engine
switch off.

Changing the unit cannot be per-
formed while the vehicle is moving.

Turn the engine switch to
ON.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Pressure unit setting”.

Press

to select the

desired unit and then press



7-inch display

Park the vehicle in a safe
place and turn the engine
switch off.

Changing the unit cannot be per-
formed while the vehicle is moving.

Turn the engine switch to
ON.

Select

of the multi-infor-

mation display and then

press .

Press

select

“Vehicle Settings” and then

press and hold

Press

select

“TPWS setting” and then

press .

Press

select

“Pressure unit setting”.

Press

to select the

desired unit and then press

■

Routine tire inflation pressure
checks

The tire pressure warning system
does not replace routine tire inflation
pressure checks. Make sure to
check tire inflation pressure as part
of your routine of daily vehicle
checks.

■

Tire inflation pressure

●

It may take a few minutes to dis-
play the tire inflation pressure
after the engine switch is turned to
ON. It may also take a few min-
utes to display the tire inflation

364

6-3. Do-it-yourself maintenance

pressure after inflation pressure
has been adjusted.

●

Tire inflation pressure changes
with temperature.
The displayed values may also be
different from the values mea-
sured using a tire pressure gauge.

■

Situations in which the tire
pressure warning system may
not operate properly

●

In the following cases, the tire
pressure warning system may not
operate properly.

• If non-genuine Toyota wheels are

used.

• A tire has been replaced with a

tire that is not an OE (Original
Equipment) tire.

• A tire has been replaced with a

tire that is not of the specified size.

• Tire chains, etc. are equipped.
• An auxiliary-supported run-flat tire

is equipped.

• If a window tint that affects the

radio wave signals is installed.

• If there is a lot of snow or ice on

the vehicle, particularly around the
wheels or wheel housings.

• If the tire inflation pressure is

extremely higher than the speci-
fied level.

• If wheel without tire pressure

warning valves and transmitters
are used.

• If the ID code on the tire pressure

warning valves and transmitters is
not registered in the tire pressure
warning computer.

●

Performance may be affected in
the following situations.

• Near a TV tower, electric power

plant, gas station, radio station,
large display, airport or other facil-
ity that generates strong radio
waves or electrical noise

• When carrying a portable radio,

cellular phone, cordless phone or
other wireless communication
device

●

If tire position information is not
correctly displayed due to the
radio wave conditions, the display

may be corrected by driving and
changing the radio wave condi-
tions.

●

When the vehicle is parked, the
time taken for the warning to start
or go off could be extended.

●

When tire inflation pressure
declines rapidly for example when
a tire has burst, the warning may
not function.

■

Warning performance of the tire
pressure warning system

The warning of the tire pressure
warning system will change in
accordance with the conditions
under which it was initialized. For
this reason, the system may give a
warning even if the tire pressure
does not reach a low enough level,
or if the pressure is higher than the
pressure that was adjusted to when
the system was initialized.

When replacing tires or wheels,
tire pressure warning valves and
transmitters must also be
installed.

When new tire pressure warning
valves and transmitters are
installed, new ID codes must be
registered in the tire pressure
warning computer and the tire
pressure warning system must
be initialized. (



P.367)

■

When replacing the tires and
wheels

If the ID code of the tire pressure
warning valve and transmitter is not
registered, the tire pressure warning
system will not work properly. After

Installing tire pressure
warning valves and trans-
mitters

365

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

driving for about 20 minutes, the tire

pressure warning light blinks for 1

minute and stays on to indicate a

system malfunction.

■

The tire pressure warning

system must be initialized

in the following circum-

stances:



When rotating the tires.



When changing the tire.



After registering the ID codes.

(



P.367)



When changing between two

registered wheel sets.

When the tire pressure warning

system is initialized, the current

tire inflation pressure is set as

the benchmark pressure.

■

How to initialize the tire

pressure warning system

Park the vehicle in a safe

place and stop the engine for

20 minutes or more.

Initialization cannot be performed

while the vehicle is moving.

Adjust the tire inflation pres-

sure to the specified cold tire

inflation pressure level.

(



P.443)

Make sure to adjust the tire pres-

sure to the specified cold tire infla-

tion pressure level. The tire

pressure warning system will oper-

ate based on this pressure level.

Start the engine.

4.2-inch display meter:
Press

of the meter

control switch to select

NOTICE

■

Repairing or replacing tires,

wheels, tire pressure warn-

ing valves, transmitters and

tire valve caps

●

When removing or fitting the

wheels, tires or the tire pressure

warning valves and transmit-

ters, contact your Toyota dealer

as the tire pressure warning

valves and transmitters may be

damaged if not handled cor-

rectly.

●

Make sure to install the tire

valve caps. If the tire valve caps

are not installed, water could

enter the tire pressure warning

valves and the tire pressure

warning valves could be bound.

●

When replacing tire valve caps,

do not use tire valve caps other

than those specified. The cap

may become stuck.

■

To avoid damage to the tire

pressure warning valves and

transmitters

When a tire is repaired with liquid

sealants, the tire pressure warn-

ing valve and transmitter may not

operate properly. If a liquid seal-

ant is used, contact your Toyota

dealer or other qualified service

shop as soon as possible. Make

sure to replace the tire pressure

warning valve and transmitter

when replacing the tire. (



P.364)

Initializing the tire pres-

sure warning system

366

6-3. Do-it-yourself maintenance

7-inch display meter:

Press

of the meter

control switch to select

4.2-inch display meter:

Press

to select

“Vehicle Settings” and then

press and hold

7-inch display meter:

Press

to select “Vehi-

cle Settings” and then press and

hold .

4.2-inch display meter:

Press

to select

“TPWS setting” and then

press .

7-inch display meter:

Press

to select

“TPWS setting” and then press

4.2-inch display meter:

Press

to select “Set

Pressure”. Then press and

hold .

7-inch display meter:

Press

to select “Set

Pressure”. Then press and hold

After setting the tire inflation pres-
sure, a message indicating that set-
ting has been completed will be
displayed on the multi-information

display.

Also, “--” is displayed for inflation
pressure of each tire on the
multi-information display while the
tire pressure warning system deter-
mines the position.

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When initialization is complete, the
inflation pressure of each tire will be
displayed on the multi-information
display.

Even if the vehicle is not driven at
approximately 25 mph (40 km/h) or
more, initialization can be com-
pleted by driving for a long time.
However, if initialization does not
complete after driving for 1 hour or
more, park the vehicle in a safe
place for approximately 20 minutes
and then drive the vehicle again.

■

When initializing

●

Initialization is performed while
driving at a vehicle speed of
approximately 25 mph (40 km/h)
or more.

●

Make sure to carry out initializa-
tion after adjusting the tire inflation
pressure.
Also, make sure the tires are cold
before carrying out initialization or
tire inflation pressure adjustment.

●

The tire pressure warning system
can be initialized by yourself, but

367

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

depending on the driving condi-

tions and driving environment, ini-

tialization may take some time to

complete.

■

The initialization operation

●

If you have accidentally turned the

engine switch to OFF during ini-

tialization, it is not necessary to

restart the initialization again as

initialization will restart automati-

cally when the engine switch has

been turned to ON for the next

time.

●

If you accidentally perform initial-

ization when initialization is not

necessary, adjust the tire inflation

pressure to the specified level

when the tires are cold, and con-

duct initialization again.

●

While the position of each tire is

being determined and the inflation

pressures are not being displayed

on the multi-information display, if

the inflation pressure of a tire

drops, the tire pressure warning

light will come on.

■

If the tire pressure warning sys-

tem is not initialized properly

●

In the following situations, initial-

ization may take longer than usual

to be completed or may not be

possible. Normally, initialization

completes within approximately

30 minutes.

• Vehicle is not driven at approxi-

mately 25 mph (40 km/h) or more

• Vehicle is driven on unpaved

roads

• Vehicle is driven near other vehi-

cles and system cannot recog-

nize tire pressure warning valve

and transmitters of your vehicle

over those of other vehicles.

• If the vehicle is driven in heavy

traffic or another situation where

other vehicles are driven close by,

it may take time for the system to

recognize the tire pressure warn-

ing valve and transmitters of your

vehicle over those of other vehi-

cles.

●

If initialization does not complete

after driving for 1 hour or more,

park the vehicle in a safe place for

approximately 20 minutes and

then drive the vehicle again.

●

If the vehicle is reversed during

initialization, the data up to that

point is reset, so perform the ini-

tialization procedure again from

the beginning.

●

In the following situations, initial-

ization will not be started or was

not completed properly and the

system will not operate properly.

Perform the initialization proce-

dure again.

• If, when attempting to start initial-

ization, the tire pressure warning

light does not blink 3 times.

• If, when the vehicle has been

driven for about 20 minutes after

performing initialization, the tire

pressure warning light blinks for

approximately 1 minute and then

illuminates.

●

If the inflation pressure of each

tire is still not displayed, have the

vehicle inspected by your Toyota

dealer.

Every tire pressure warning

valve and transmitter has a

unique ID code. When replacing

a tire pressure warning valve

WARNING

■

When initializing the tire pres-

sure warning system

Do not initializing tire inflation

pressure without first adjusting

the tire inflation pressure to the

specified level. Otherwise, the tire

pressure warning light may not

come on even if the tire inflation

pressure is low, or it may come on

when the tire inflation pressure is

actually normal.

Registering ID codes

368

6-3. Do-it-yourself maintenance

and transmitter, it is necessary
to register the ID code.

When registering the ID codes,
perform the following procedure.

Park the vehicle in a safe
place, wait for approximately
20 minutes, and then start
the engine.

Select

of the

multi-information display and

then press

4.2-inch display meter:

Press

to select

“Vehicle Settings” and then

press and hold

7-inch display meter:

Press

to select “Vehi-

cle Settings” and then press and

hold .

4.2-inch display meter:

Press

to select

“TPWS setting” and then

press .

7-inch display meter:

Press

to select

“TPWS setting” and then press

4.2-inch display meter:

Press

to select

“Tyre Set Switching” and then

press .

7-inch display meter:

Press

to select “Tyre

Set Switching” and then press

4.2-inch display meter:

Press

select

“Register New Valve / ID” and

then press

7-inch display meter:

Press

to select “Reg-

ister New Valve / ID” and then

press .

4.2-inch display meter:

Press

select

“Tire Set 1” or “Tire Set 2”.

Then press

7-inch display meter:

Press

to select “Tire

Set 1” or “Tire Set 2”. Then

press .

The change wheel set mode is acti-
vated and registration is started.
Then a message will be displayed
on the multi-information display.

When registration is being per-
formed, the tire pressure warning
light will blink for approximately 1
minute then illuminate and “--” will
be displayed for the inflation pres-

369

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

sure of each tire on the multi-infor-
mation display.

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When registration is completed, the
tire pressure warning light will go off
and the inflation pressure of each
tire will be displayed on the
multi-information display.

Even if the vehicle is not driven at
approximately 25 mph (40 km/h) or
more, registration can be com-
pleted by driving for a long time.
However, if registration does not
complete after driving for 1 hour or
more, perform the procedure again
from the beginning.

Initialize the tire pressure
warning system. (



P.365)

■

When registering ID codes

●

ID code registration is performed
while driving at a vehicle speed of
approximately 25 mph (40 km/h)
or more.

●

Before performing ID code regis-
tration, make sure that no wheels
with tire pressure warning valve
and transmitters installed are near
the vehicle.

●

Make sure to initialize the tire
pressure warning system after
registering the ID codes. If the
system is initialized before regis-
tering the ID codes, the initialized
values will be invalid.

●

ID codes can be registered by
yourself, but depending on the
driving conditions and driving
environment, registration may
take some time to complete.

●

As the tires will be warm when
registration is completed, make
sure to allow the tires to cool
before performing initialization.

■

Canceling ID code registration

●

To cancel ID code registration
after it has been started, select
“Identify Wheel” on the multi-infor-
mation display and press and hold

again.

●

If ID code registration has been
canceled, the tire pressure warn-
ing light will blink for approxi-
mately 1 minute when the engine
switch is turned to ON and then
illuminate. The tire pressure warn-
ing system will be operational
when the tire pressure warning
light turns off.

●

If the warning light does not turn
off even after several minutes
have elapsed, ID code registration
may not have been canceled cor-
rectly. To cancel registration, per-
form the ID code registration start
procedure again and then turn the
engine switch off before driving.

■

If ID codes are not registered
properly

In the following situations, ID code
registration may take longer than
usual to be completed or may not be
possible. Normally, registration com-
pletes within approximately 30 min-
utes.

●

Vehicle is not parked for approxi-
mately 20 minutes or more before
driving

●

Vehicle is not driven at approxi-
mately 25 mph (40 km/h) or more

●

Vehicle is driven on unpaved
roads

●

Vehicle is driven near other vehi-
cles and system cannot recog-
nize tire pressure warning valve
and transmitters of your vehicle
over those of other vehicles

●

Wheel with tire pressure warning
valve and transmitter installed is
inside or near the vehicle

If registration does not complete
after driving for 1 hour or more, per-
form the ID code registration proce-

370

6-3. Do-it-yourself maintenance

dure again from the beginning.

●

If the vehicle is reversed during
registration, the data up to that
point is reset, so perform the reg-
istration procedure again from the
beginning.

●

In the following situations, ID code
registration will not be started or
was not completed properly and
the system will not operate prop-
erly. Perform the ID code registra-
tion procedure again.

• If, when attempting to start ID

code registration, the tire pressure
warning light does not blink slowly
3 times.

• If, when the vehicle has been

driven for about 20 minutes after
performing ID code registration,
the tire pressure warning light
blinks for approximately 1 minute
and then illuminates.

If the ID codes cannot be registered
even when performing the above
procedure, contact your Toyota
dealer.

Your vehicle is equipped with
tire pressure warning system
with the function to have ID
codes registered for a second
wheel set, for example a winter
set. You can register a second
wheel set by yourself or your
Toyota dealer.

After registration of a second
wheel set, either of these two
wheel sets can be selected for
usage with the tire pressure
warning system.

■

Operating conditions for
the function



This function will perform the

change of wheel set only if a
second wheel set has been
registered. If no second wheel
set has been registered, no
change will be made when
selecting this function in the
menu.



Only a change between both
registered wheel set is possi-
ble, mixing between these
wheel sets is not supported.

■

How to change between
wheel sets

Have the vehicle fitted with
the preferred wheel set.

4.2-inch display meter:

Press

of the meter

control switch to select

7-inch display meter:

Press

of the meter

control switch to select

4.2-inch display meter:

Press

select

“Vehicle Settings” and then

press and hold

7-inch display meter:

Press

to select “Vehi-

cle Settings” and then press and

hold .

4.2-inch display meter:

Press

select

“TPWS setting” and then

press .

7-inch display meter:

Selecting wheel set

371

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

Press

to select

“TPWS setting” and then press

4.2-inch display meter:

Press

to select

“Tyre Set Switching” and then

press .

7-inch display meter:

Press

to select “Tyre

Set Switching” and then press

4.2-inch display meter:

Press

to select

“Register New Valve / ID” and

then press

7-inch display meter:

Press

to select “Reg-

ister New Valve / ID” and then

press .

4.2-inch display meter:

Press

to select

“Tire Set 1” or “Tire Set 2”.

Then press

7-inch display meter:

Press

to select “Tire

Set 1” or “Tire Set 2”. Then

press .

Afterward, the tire pressure warning
light turns on after flashing for 1

minute.

After 2 minutes, registration of a
second wheel set is being per-
formed. The tire pressure warning
light will turn off and “--” will be dis-
played for the inflation pressure of
each tire on the multi-information
display.

Initialize the tire pressure
warning system. (



P.365)

If the tire inflation pressure settings
for the installed tires change, initial-
ization operations are required, but
if the tire inflation pressure settings
are the same, initialization is not
required.

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

Registration of a second wheel set
is complete when the tire pressure
warning light turns off and the infla-
tion pressure of each tire is dis-
played on the multi-information
display.

372

6-3. Do-it-yourself maintenance

The recommended cold tire
inflation pressure and tire size
are displayed on the tire and
loading information label.
(



P.443)

Tire valve

Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pres-
sure gauge onto the tire
valve.

Read the pressure using the
gauge gradations.

If the tire inflation pressure is
not at the recommended
level, adjust the pressure.
If you add too much air, press
the center of the valve to
deflate.

After completing the tire infla-
tion pressure measurement
and adjustment, apply soapy
water to the valve and check
for leakage.

Put the tire valve cap back
on.

■

Tire inflation pressure check
interval

You should check tire inflation pres-
sure every two weeks, or at least
once a month. Do not forget to
check the spare.

■

Effects of incorrect tire inflation
pressure

Driving with incorrect tire inflation
pressure may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor
handling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating,
have it checked by your Toyota
dealer.

Tire inflation pressure

Checking the specified
tire inflation pressure

Inspection and adjust-
ment procedure

373

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

■

Instructions for checking tire

inflation pressure

When checking tire inflation pres-

sure, observe the following:

●

Check only when the tires are

cold.

If your vehicle has been parked for

at least 3 hours or has not been

driven for more than 1 mile or 1.5

km, you will get an accurate cold

tire inflation pressure reading.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is

properly inflated based only on its

appearance.

●

It is normal for the tire inflation

pressure to be higher after driving

as heat is generated in the tire. Do

not reduce tire inflation pressure

after driving.

●

Never exceed the vehicle capacity

weight.

Passengers and luggage weight

should be placed so that the vehi-

cle is balanced.

WARNING

■

Proper inflation is critical to

save tire performance

Keep your tires properly inflated.

If the tires are not properly

inflated, the following conditions

may occur which could lead to an

accident resulting in death or seri-

ous injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting

from overheated tires

●

Air leaking from between tire

and wheel

●

Wheel deformation and/or tire

damage

●

Greater possibility of tire dam-

age while driving (due to road

hazards, expansion joints,

sharp edges in the road, etc.)

NOTICE

■

When inspecting and adjust-

ing tire inflation pressure

Be sure to put the tire valve caps

back on.

If a valve cap is not installed, dirt

or moisture may get into the valve

and cause an air leak, resulting in

decreased tire inflation pressure.

374

6-3. Do-it-yourself maintenance

When replacing wheels, care

should be taken to ensure that

they are equivalent to those

removed in load capacity, diam-
eter, rim width and inset

Replacement wheels are avail-

able at your Toyota dealer.

: Conventionally referred to as off-

set.

Toyota does not recommend

using the following:



Wheels of different sizes or

types



Used wheels



Bent wheels that have been

straightened

■

When replacing wheels

The wheels of your vehicle are

equipped with tire pressure warning

valves and transmitters that allow

the tire pressure warning system to

provide advance warning in the

event of a loss in tire inflation pres-

sure. Whenever wheels are

replaced, the tire pressure warning

valves and transmitters must be

installed. (



P.364)

Wheels

If a wheel is bent, cracked or

heavily corroded, it should

be replaced. Otherwise, the

tire may separate from the

wheel or cause a loss of

handling control.

Wheel selection

WARNING

■

When replacing wheels

●

Do not use wheels that are a dif-

ferent size from those recom-

mended in the Owner’s Manual,

as this may result in a loss of

handling control.

●

Never use an inner tube in a

leaking wheel which is designed

for a tubeless tire.

Doing so may result in an acci-

dent, causing death or serious

injury.

■

When installing the wheel

nuts

●

Be sure to install the wheel nuts

with the tapered ends facing

inward. (



P.421) Installing the

nuts with the tapered ends fac-

ing outward can cause the

wheel to break and eventually

cause the wheel to come off

while driving, which could lead

to an accident resulting in death

or serious injury.

●

Never use oil or grease on the

wheel bolts or wheel nuts.

Oil and grease may cause the

wheel nuts to be excessively

tightened, leading to bolt or disc

wheel damage. In addition, the

oil or grease can cause the

wheel nuts to loosen and the

wheel may fall off, causing an

accident and resulting in death

or serious injury. Remove any

oil or grease from the wheel

bolts or wheel nuts.

■

Use of defective wheels pro-

hibited

Do not use cracked or deformed

wheels. Doing so could cause the

tire to leak air during driving, pos-

sibly causing an accident.

375

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca



Use only Toyota wheel nuts

and wheel nut wrenches

designed for use with your

aluminum wheels.



When rotating, repairing or

changing your tires, check

that the wheel nuts are still

tight after driving 1000 miles

(1600 km).



Use only Toyota genuine bal-

ance weights or equivalent

and a plastic or rubber ham-

mer when balancing your

wheels.

Turn the engine switch off.

Open the glove box. Slide off

the damper.

Push in the glove box on the

vehicle’s outer side to discon-

nect the claws. Then pull out

the glove box and disconnect

the lower claws.

Unlock the filter cover ( ),

pull the filter cover out of the

NOTICE

■

Replacing tire pressure warn-

ing valves and transmitters

●

Because tire repair or replace-

ment may affect the tire pres-

sure warning valves and

transmitters, make sure to have

tires serviced by your Toyota

dealer or other qualified service

shop. In addition, make sure to

purchase your tire pressure

warning valves and transmit-

ters at your Toyota dealer.

●

Ensure that only genuine Toyota

wheels are used on your vehi-

cle.

Tire pressure warning valves

and transmitters may not work

properly with non-genuine

wheels.

Aluminum wheel precau-

tions (if equipped)

Air conditioning filter

The air conditioning filter

must be changed regularly

to maintain air conditioning

efficiency.

Removing the air condi-

tioning filter

376

6-3. Do-it-yourself maintenance

claws ( ), and remove the

filter cover.

Remove the filter case.

Remove the air conditioning

filter from the filter case and

replace it with a new one.

The “

UP” marks shown on the

filter and the filter case should be

pointing up.

■

Checking interval

Replace the air conditioning filter

according to the maintenance

schedule. In dusty areas or areas

with heavy traffic flow, early replace-

ment may be required. (For sched-

uled maintenance information,

please refer to the “Scheduled

Maintenance Guide” or “Owner’s

Manual Supplement”.)

■

If air flow from the vents

decreases dramatically

The filter may be clogged. Check

the filter and replace if necessary.

NOTICE

■

When using the air condition-

ing system

Make sure that a filter is always

installed.

Using the air conditioning system

without a filter may cause damage

to the system.

■

To prevent damage to the fil-

ter cover

When moving the filter cover in

the direction of arrow to release

the fitting, pay attention not to

apply excessive force to the

claws. Otherwise, the claws may

be damaged.

377

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

: If equipped

■

If the key battery is depleted

The following symptoms may occur:

●

The smart key system (if
equipped) and wireless remote
control will not function properly.

●

The operational range will be
reduced.



Flathead screwdriver



Small flathead screwdriver



Lithium battery CR2016 (vehi-
cles without a smart key sys-
tem) or CR2450 (vehicles with
a smart key system)

■

Use a CR2016 or CR2450 lith-
ium battery

●

Batteries can be purchased at
your Toyota dealer, local electrical
appliance shops or camera stores.

●

Replace only with the same or
equivalent type recommended by
the manufacturer.

●

Dispose of used batteries accord-

ing to local laws.



Vehicles without a smart key
system

Remove the cover.

To prevent damage to the key,
cover the tip of the flathead screw-
driver with a rag.

Remove the module.

Open the case cover using a
coin protected with tape etc.
and remove the depleted bat-
tery.

Insert a new battery with the “+” ter-

Wireless remote con-

trol/electronic key bat-

tery

Replace the battery with a
new one if it is depleted.
As the key may be damaged
if the following procedure is
not performed properly, it is
recommended that key bat-
tery replacement be per-
formed by your Toyota
dealer.

Items to prepare

Replacing the battery

378

6-3. Do-it-yourself maintenance

minal facing up.

Install the cover.

Align the cover with the key and
then press it straight into the key.

Make sure that the cover is
securely installed without any gaps
between it and the key.

Operate the

switch

and check that the doors can
be locked/unlocked.



Vehicles with a smart key sys-
tem

Release the lock and remove
the mechanical key.

Remove the key cover.

To prevent damage to the key,
cover the tip of the flathead screw-
driver with a rag.

Remove the depleted battery
using a small flathead screw-
driver.

When removing the cover, the elec-
tronic key module may stick to the
cover and the battery may not be
visible. In this case, remove the
electronic key module in order to
remove the battery.

Insert a new battery with the “+” ter-
minal facing up.

When installing the key cover
and mechanical key, install
by conducting step

and

step

with the directions

reversed.

Operate the

switch

and check that the doors can
be locked/unlocked.

379

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

WARNING

■

Battery precautions

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

●

Do not swallow the battery.

Doing so may cause chemical

burns.

●

A coin battery or button battery

is used in the key. If a battery is

swallowed, it may cause severe

chemical burns in as little as 2

hours and may result in death or

serious injury.

●

Keep away new and removed

batteries from children.

●

If the cover cannot be firmly

closed, stop using the key and

stow the key in the place where

children cannot reach, and then

contact your Toyota dealer.

●

If you accidentally swallow a

battery or put a battery into a

part of your body, get emer-

gency medical attention imme-

diately.

■

To prevent battery explosion

or leakage of flammable liq-

uid or gas

●

Replace the battery with a new

battery of the same type. If a

wrong type of battery is used, it

may explode.

●

Do not expose batteries to

extremely low pressure due to

high altitude or extremely high

temperatures.

●

Do not burn, break or cut a bat-

tery.

NOTICE

■

When replacing the battery

Use a flathead screwdriver of

appropriate size. Applying exces-

sive force may deform or damage

the cover.

■

For normal operation after

replacing the battery

Observe the following precautions

to prevent accidents:

●

Always work with dry hands.

Moisture may cause the battery

to rust.

●

Do not touch or move any other

component inside the remote

control.

●

Do not bend either of the battery

terminals.

380

6-3. Do-it-yourself maintenance

Turn the engine switch off.

Open the fuse box cover.



Engine compartment

Push the tabs in and lift the lid off.



Under the driver’s side instru-
ment panel

Remove the lid.

Make sure to push the claw when
removing/installing the lid.

Remove the fuse with the
pullout tool.
Only type A fuse can be
removed using the pullout
tool.

Check if the fuse is blown.

Replace the blown fuse with a new
fuse of an appropriate amperage
rating. The amperage rating can be
found on the fuse box lid.



Type A

Normal fuse

Blown fuse



Type B

Checking and replac-

ing fuses

If any of the electrical com-
ponents do not operate, a
fuse may have blown. If this
happens, check and replace
the fuses as necessary.

Checking and replacing
fuses

381

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Normal fuse
Blown fuse



Type C

Normal fuse
Blown fuse



Type D

Normal fuse
Blown fuse

■

After a fuse is replaced

●

When installing the lid, make sure

that the tab is installed securely.

●

If the lights do not turn on even

after the fuse has been replaced,

a bulb may need replacement.

(



P.383)

●

If the replaced fuse blows again,

have the vehicle inspected by

your Toyota dealer.

■

If there is an overload in a cir-

cuit

The fuses are designed to blow, pro-

tecting the wiring harness from

damage.

WARNING

■

To prevent system break-

downs and vehicle fire

Observe the following precau-

tions.

Failure to do so may cause dam-

age to the vehicle, and possibly a

fire or injury.

●

Never use a fuse of a higher

amperage rating than that indi-

cated, or use any other object in

place of a fuse.

●

Always use a genuine Toyota

fuse or equivalent.

Never replace a fuse with a

wire, even as a temporary fix.

●

Do not modify the fuses or fuse

boxes.

NOTICE

■

Before replacing fuses

Have the cause of electrical over-

load determined and repaired by

your Toyota dealer as soon as

possible.

382

6-3. Do-it-yourself maintenance

Adjustment bolt A

Adjustment bolt B



Make sure the vehicle has a
full tank of gasoline and the
area around the headlight is
not deformed.



Park the vehicle on level
ground.



Make sure the tire inflation
pressure is at the specified
level.



Have someone sit in the
driver’s seat.



Bounce the vehicle several
times.

Using a Phillips-head screw-
driver, turn bolt A in either
direction.

Remember the turning direction
and the number of turns.

Turn bolt B the same number
of turns and in the same
direction as step

If the headlight cannot be adjusted
using this procedure, take the vehi-
cle to your Toyota dealer to adjust
the headlight aim.

Headlight aim

Vertical movement adjust-
ing bolts

Before checking the head-
light aim

Adjusting the headlight
aim

383

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

Check the wattage of the light
bulb to be replaced. (



P.445)



P.118

■

Front

Front side marker lights (bulb
type)

Parking lights (bulb type)

Front turn signal lights (bulb
type)

■

Rear

Tail lights/rear side marker
lights (bulb type)

Back-up lights

License plate lights

■

Lights that need to be
replaced by your Toyota
dealer



Headlights (if equipped)



Headlights/daytime running
lights (if equipped)



Daytime running lights/park-
ing lights (if equipped)



Front turn signal lights (LED
type)



Front side marker lights (LED
type)



Fog lights (if equipped)



Side turn signal lights (if
equipped)



Tail lights (if equipped)



Stop lights



Rear turn signal lights

Light bulbs

You may replace the follow-
ing bulbs yourself. The diffi-
culty level of replacement
varies depending on the
bulb. If necessary bulb
replacement seems difficult
to perform, contact your
Toyota dealer.

For more information about
replacing other light bulbs,
contact your Toyota dealer.

Preparing for light bulb
replacement

Disabling the power back
door system (if equipped)

Bulb locations

384

6-3. Do-it-yourself maintenance



High mounted stoplight

■

LED light bulbs

The lights other than the following
lights each consist of a number of
LEDs. If any of the LEDs burn out,
take your vehicle to your Toyota
dealer to have the light replaced.

●

Front side marker lights (bulb
type)

●

Parking lights (bulb type)

●

Front turn signal lights (bulb type)

●

Tail lights/rear side marker lights
(bulb type)

●

Back-up lights

●

License plate lights

■

Condensation build-up on the
inside of the lens

Temporary condensation build-up
on the inside of the headlight lens
does not indicate a malfunction.
Contact your Toyota dealer for more
information in the following situa-
tions:

●

Large drops of water have built up
on the inside of the lens.

●

Water has built up inside the
headlight.

■

Front side marker lights
(bulb type)

Turn the bulb base counter-
clockwise.

Remove the light bulb.

When installing, reverse the
steps listed.

■

Parking lights (bulb type)

Turn the bulb base counter-
clockwise.

Remove the light bulb.

When installing, reverse the
steps listed.

Replacing light bulbs

Toyota Corolla Cross (2024 year). Manual in english - page 12
