Toyota Prius (2024 year). Manual in english

321

4-5. Using the driving support systems

Dr
iv

ing

■

Precautions for use

For details on the following, refer to
“Panoramic view monitor” of “Park-
ing assist system” in the “MULTIME-
DIA OWNER’S MANUAL”.

●

Displayable range of the screens

●

Cameras

●

Differences between displayed
images and the actual road

●

Differences between displayed
images and the actual objects

■

Detection range of the cameras
and sensors

●

If a parked vehicle is behind the
target parking space and the dis-
tance between it and the vehicle
becomes far, it may no longer be
able to be detected. Depending on
shape or condition of a parked
vehicle, the detection range may
become short or the vehicle may
not be detected.

●

Objects other than parked vehi-
cles, such as columns, walls, etc.,
may not be detected. Also, if they
are detected, they may cause the
target parking space to be mis-
aligned.

■

Situations in which parking
space lines may not be recog-
nized properly

●

In situations such as the following,
parking space lines on the road
surface may not be detected:

• When the parking space does not

use lines (parking space boundar-
ies are marked with rope, blocks,
etc.)

• When the parking space lines are

faded or dirty, making them
unclear

• When the road surface is bright,

such as concrete, and the contrast
between it and the white parking
space lines is small

• When the parking space lines are

any color other than yellow or
white

• When the area surrounding the

parking space is dark, such as at

night, in an underground parking
lot, parking garage, etc.

• When it is raining or has rained

and the road surface is wet and
reflective or there are puddles

• When the sun is shining directly

into a camera, such as in the early
morning or evening

• When the parking space is cov-

ered with snow or de-icing agent

• When there marks from repairs or

other marks on the road surface,
or there is a traffic bollard, or other
object on the road surface

• When the color or brightness of

the road surface is uneven

• When a camera has been

splashed by hot or cold water and
the lens has fogged up

• When the appearance of the park-

ing space is affected by the
shadow of the vehicle or trees

• When a camera lens is dirty or

covered with water droplets

●

In situations such as the following,
the target parking space may not
be recognized correctly:

• When there marks from repairs or

other marks on the road surface,
or there is a parking block, traffic
bollard, or other object on the road
surface

• When it is raining or has rained

and the road surface is wet and
reflective or there are puddles

• When the area around the vehicle

is dark or backlit

• When the color or brightness of

the road surface is uneven

• When the parking space is on a

slope

• When there are diagonal lines

(access aisle) near the parking
space

• When the appearance of the park-

ing space is affected by the
shadow of a parked vehicle (such
as shadows from the grille, side
step, etc.)

• When accessories which obstruct

the view of the camera are
installed

• When the parking space lines are

faded or dirty, making them

322

4-5. Using the driving support systems

unclear

• When the appearance of the park-

ing space is affected by the

shadow of the vehicle or trees

■

Sensor detection information



P.286

■

Objects which the sensor may

not be properly detected



P.287

■

Situations in which the sensor

may not operate properly



P.287

■

Situations in which parking

assistance may not operate

even if there is no possibility of

a collision



P.288

Press the Advanced Park main

switch.

If the switch is pressed while assis-

tance is being performed, the assis-

tance will be canceled.

■

Operating conditions of the

Advanced Park

Assistance will begin when all of the

following conditions are met:

●

The brake pedal is depressed

●

The vehicle is stopped

●

The driver’s seat belt is fastened

●

The steering wheel is not being

operated

●

The accelerator pedal is not

depressed

●

All of the doors and the back door

are closed

●

The outside rear view mirrors are

not folded

●

The parking brake is not engaged

●

The dynamic radar cruise control

are not operating

●

ABS, VSC, TRAC, PCS and

PKSB are not operating

●

The vehicle is not on a steep

WARNING

■

Precautions for the cameras

and sensors

●

Due to the characteristics of the

camera lens, the position of and

distance to people and objects

displayed on the screen may

differ from the actual situation.

For details, refer to “MULTIME-

DIA OWNER’S MANUAL”.

●

Make sure to observe the pre-

cautions for using the intuitive

parking assist, otherwise a sen-

sor may not operate correctly,

possibly leading to an accident.

(



P.285)

●

In situations such as the follow-

ing, the sensors may not oper-

ate correctly, possibly leading to

an accident. Proceed carefully.

• When there is a parked vehicle

next to the target parking space,

if the displayed target parking

space is far from the actual tar-

get parking space, a sensor

may be misaligned. Have the

vehicle inspected by your

Toyota dealer.

• Do not install any accessories

near the detection area of the

sensors.

Turning the Advanced

Park system on/off

323

4-5. Using the driving support systems

Dr
iv

ing

slope

●

The VSC and TRAC are not
turned off

If assistance cannot be started,
check the message displayed on
the Multimedia Display (



P.342).

Guidance screens are displayed
on the Multimedia Display.



Guidance screen (When
assistance starts)

Target parking space box
(blue)

Advice display

Parking type change button

If multiple buttons are displayed,
depending on the condition of the
button its function differs as follows.

: Change the target to

another parking space.

: Select the current target

parking space.

: Select to change to the parallel

parking function

: Change the perpendicular

parking (forward/reverse) function

“MODE” button

Select to change between the
memory function and the perpen-
dicular parking (forward/reverse)
function and parallel parking func-
tion. (



P.337)

“Start” button

Select to start parking assistance.

Perpendicular parking direc-
tion change button

Select to change between the park-
ing (forward) function and parking
(reverse) function

: Change the perpendicular

parking (forward) function

: Change the perpendicular

parking (reverse) function

Customize setting button

Select to display the Advanced
Park setting screen. (



P.341)

Registration button

Select to begin registering a park-
ing space.



Guidance screen (When
reversing)

Operation icon

Displayed when the Advanced Park
is operating.

Guide lines (yellow and red)

Display points from the center of

Advanced Park guidance
screens

324

4-5. Using the driving support systems

the edge of the front or rear bumper
to the target stopping position (yel-

low)

and approximately 1 ft. (0.3

m) (red) from the vehicle.

Moving object warning icon

Emergency support brake
control operation display

“BRAKE!” is displayed.

Intuitive parking assist dis-
play



P.284

Rear camera washer switch

(if equipped)

Press shortly:

The rear camera washer operates
for a certain period of time.

Press and hold:

The rear camera washer operates
while the rear camera washer
switch remains pressed.

: The yellow lateral line is not dis-

played when the target stopping
position is approximately 8.2 ft.
(2.5 m) or more away from the
vehicle.

: Refer to “Panoramic view moni-

tor” of “Parking assist system” in
the “MULTIMEDIA OWNER’S
MANUAL”.

■

Intuitive parking assist pop-up
display

Regardless of whether the intuitive
parking assist is off or on (



P.285),

if an object is detected by the intui-
tive parking assist when the
Advanced Park is operating, the
intuitive parking assist pop up dis-
play will automatically be displayed
over the guidance display.

■

Brake control operation when
Advanced Park is operating

While the Advanced Park is operat-
ing, if the system determines that
the possibility of collision with
detected moving or stationary object
is high, the hybrid system output
restriction control and brake control
will operate.

If brake control operates, Advanced
Park operation will be suspended
and a message will be displayed on
the multi-information display.

■

Buzzer

Depending on surrounding sounds
or sounds from other systems, it
may be difficult to hear the buzzer of
this system.

■

If a black screen is displayed on
the Multimedia Display when
the Advanced Park is operating

The system is being affected by
radio waves or may be malfunction-
ing. If a radio antenna is installed
near a camera, move it to a location
as far from the cameras as possible.
If a radio antenna is not installed
near a camera, and the screen does
not return to normal after turning the
power switch off and then starting
the hybrid system again, have the
vehicle inspected by your Toyota
dealer.

The perpendicular parking (for-
ward/reverse) function can be
used if the target parking space
can be detected when the vehi-
cle is stopped close and perpen-
dicular to the center of the
parking space. Also, depending
on the condition of the parking
space, etc., if it is necessary to
change the direction of travel of

Perpendicular parking
(forward/reverse) function

325

4-5. Using the driving support systems

Dr
iv

ing

the vehicle, the shift position can
be changed by assistance con-
trol.

Stop the vehicle at a position
close and perpendicular to
the center of the target park-
ing space.



If there are parking space
lines

Approximately 3.3 ft. (1 m)

Approximately 8.2 ft. (2.5 m)

Approximately 19.7 ft. (6 m)

or more

Approximately 18.0 ft. (5.5 m)

or more

The system can operate even if
there is a parking space line on
only one side of the target parking
space.

: This is a reference measurement

for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.



If there is an adjacent parked
vehicle

Approximately 3.3 ft. (1 m)

Approximately 9.8 ft. (3 m) or

Approximately 19.7 ft. (6 m)

or more

Approximately 18.0 ft. (5.5 m)

or more

The system can operate even if
there is a vehicle on only one side
of the target parking space.

: This is a reference measurement

for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.

Press the Advanced Park
main switch and check that a
possible parking space is dis-

Parking using the perpen-
dicular parking (for-
ward/reverse) function

326

4-5. Using the driving support systems

played on the Multimedia
Display.



If a space which your vehicle
can be parked is detected, a
target parking space box will
be displayed.



If it is possible to parallel park
in the space, select the park-

ing space, and then select

to change to the parallel park-
ing function.



If it is possible to change the
direction which a parking
space is entered, select the
parking space, and then

select

change the

direction.



Depending on the surround-
ing environment, it may not be
possible to use this function.
According to the information
displayed on the Multimedia
Display, use the function on
another parking space.

Select “Start” button.

A buzzer will sound, an operation
message will be displayed on the
multi-information display, and
assistance will begin operating.



When the brake pedal is
released, “Moving Forward...”,
“Backing Up...” will be dis-
played and the vehicle will
begin moving for-
ward/reverse.



To cancel assistance, press
the Advanced Park main
switch.

If assistance is canceled,
“Advanced Park Canceled” will be
displayed.

If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter:



P.327

Perform operations as indi-
cated by the advice displays
until the vehicle stops in the
target parking space.

When the vehicle stops, “Advanced
Park Finished” will be displayed
and parking assistance will end.

If you select

on the Multimedia

Display, the vehicle displayed on
the parking assist completion

327

4-5. Using the driving support systems

ing

screen will rotate.

■

If you feel that the vehicle is

approaching close to a sur-

rounding vehicle, object, per-

son, or gutter

Depress the brake pedal to stop the

vehicle and then change the shift

position to change the direction of

travel of the vehicle. At this time,

assist will be suspended. However,

if the “Start” button is selected,

assist will resume and the vehicle

will move in the direction corre-

sponding to the selected shift posi-

tion.

■

When the brakes have been

operated

When the brakes have been oper-

ated, brake operation sound may be

heard. This does not indicate a mal-

function.

When exiting from a perpendic-

ular parking space, if the system

determines that exit is possible

the perpendicular exiting (for-

ward/reverse) function can be

used. Also, depending on the

surrounding environment, if it is

necessary to change the direc-

tion of travel of the vehicle, the

shift position can be changed by

assistance control.

NOTICE

■

When using the perpendicu-

lar parking (forward/reverse)

function

●

Make sure that there are no

obstructions within the yellow

guide lines and between the

vehicle and target parking spot.

If there are any obstructions

between the vehicle and the tar-

get parking space, or between

the yellow guide lines, cancel

the function.

●

As the target parking space will

not be able to be set correctly if

the surface of the parking space

is on a slope or has differences

in height, the vehicle may stray

from the target parking space or

be slanted. Therefore, do not

use the function for this kind of

parking spot.

●

When parking in a narrow park-

ing space, the vehicle may

closely approach an adjacent

parked vehicle. If a collision

seems likely, depress the brake

pedal to stop the vehicle.

●

If a detected parked vehicle is

narrow or parked extremely

close to the curb, the position at

which assistance will park the

vehicle will also be close to the

curb. If it seems likely the vehi-

cle will collide with something or

drive off of the road, depress

the brake pedal to stop the vehi-

cle, and then press the Advance

Park main switch to disable the

system.

Advanced Park perpen-

dicular exiting (for-

ward/reverse) function

328

4-5. Using the driving support systems

With the brake pedal
depressed and P shift posi-
tion selected, press the
Advanced Park main switch
and check that the exit direc-
tion selection screen is dis-
played on the Multimedia
Display.

Select an arrow on the Multi-
media Display to select the
direction you wish to exit.

If the turn signal lever is operated,
only exit to the left or right can be
selected.

Depress the brake pedal and
select “Start” button.

A buzzer will sound, an operation
message will be displayed on the
multi-information display, and

assistance will begin operating.

To cancel assistance, press the
Advanced Park main switch.

If assistance is canceled,
“Advanced Park Canceled” will be
displayed.

If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter:



P.327

Perform operations as indi-
cated by the advice displays
until the vehicle is in a posi-
tion where exit is possible.

When the vehicle reaches a posi-
tion where exit is possible, “You
can exit by moving the steering
wheel” will be displayed. If the
steering wheel is operated,
“Advanced Park Finished” will be
displayed and assistance will end.

As assistance will end while the
vehicle is moving, grip the steering
wheel and drive forward.

If the steering wheel is not oper-
ated, the vehicle will stop at the exit
position. Assistance can be ended
by depressing the accelerator pedal

Leaving a parking space
using the perpendicular
exiting (forward/reverse)
function

329

4-5. Using the driving support systems

Dr
iv

ing

or brake pedal.

■

If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter



P.327

■

Perpendicular exiting (for-
ward/reverse) function

Do not use exiting (for-
ward/reverse) function in any situa-
tion other than when exiting a
parallel parking spot. If assistance is
started unintentionally, depress the
brake pedal and stop the vehicle,
then press the Advanced Park main
switch to cancel assistance.

■

Situations in which the perpen-
dicular exiting (forward/reverse)
function will not operate

In situations such as the following,
the perpendicular exiting (for-
ward/reverse) function will not oper-
ate:

●

When a vehicle which is waiting to
park is in the exit direction

●

When a wall, column, or person is
detected as near a front or rear
center or corner sensor

■

When the brakes have been
operated



P.327

The parallel parking function
can be used if the target parking
space can be detected when the
vehicle is stopped close and
aligned with the center of the
parking space. Also, depending
on the condition of the parking
space, etc., if it is necessary to
change the direction of travel of
the vehicle, the shift position can
be changed by assistance con-
trol.

Stop the vehicle with it
aligned near the center of the
target parking space.

Advanced Park parallel
parking function

Parking using the parallel
parking function

330

4-5. Using the driving support systems



If there are parking space
lines

Approximately 3.3 ft. (1 m)

Approximately 19.7 ft. (6 m)

Approximately 14.8 ft. (4.5 m)

or more

Approximately 26.2 ft. (8 m)

or more

: This is a reference measurement

for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.



If there is an adjacent parked
vehicle

Approximately 3.3 ft. (1 m)

Approximately 23.0 ft. (7 m)

or more

Approximately 14.8 ft. (4.5 m)

or more

Approximately 26.2 ft. (8 m)

or more

: This is a reference measurement

for detection of a parking space.
Depending on the surrounding
environment, detection may not
be possible.

Press the Advanced Park
main switch and check that a
possible parking space is dis-

331

4-5. Using the driving support systems

Dr
iv

ing

played on the Multimedia
Display.



If a space which your vehicle
can be parked is detected, a
target parking space box will
be displayed.



If it is possible to perpendicu-
lar parking (forward/reverse)
in the space, select the park-

ing space, and then select

to change to the perpendicu-
lar parking (forward/reverse)
function.



Depending on the surround-
ing environment, it may not be
possible to use this function.
According to the information
displayed on the Multimedia
Display, use the function on
another parking space.

Select “Start” button.

A buzzer will sound, an operation
message will be displayed on the
multi-information display, and

assistance will begin operating.



When the brake pedal is
released, “Moving Forward...”
will be displayed and the vehi-
cle will begin moving forward.



To cancel assistance, press
the Advanced Park main
switch.

If assistance is canceled,
“Advanced Park Canceled” will be
displayed.

If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter:



P.327

Perform operations as indi-
cated by the advice displays
until the vehicle stops in the
target parking space.

When the vehicle stops, “Advanced
Park Finished” will be displayed
and parking assistance will end.

If you select

on the Multimedia

Display, the vehicle displayed on
the parking assist completion

332

4-5. Using the driving support systems

screen will rotate.

■

If you feel that the vehicle is

approaching close to a sur-

rounding vehicle, object, per-

son, or gutter



P.327

■

“No available parking space” is

displayed

Even if the vehicle is stopped paral-

lel to a parking space, an adjacent

parked vehicle may not be detected.

In this case, if the vehicle is moved

to a position that a parked vehicle

can be detected, assistance can be

started.

■

When the brakes have been

operated



P.327

NOTICE

■

When using the parallel park-

ing function

●

Make sure that there are no

obstructions within the yellow

guide lines and between the

vehicle and target parking spot.

If any obstructions are detected

within the yellow guide lines or

between the vehicle and the tar-

get parking space, the parallel

parking function will be can-

celled or suspended.

●

As the target parking space will

not be able to be set correctly if

the surface of the parking space

is on a slope or has differences

in height, the vehicle may stray

from the target parking space or

be slanted. Therefore, do not

use the parallel parking function

for this kind of parking spot.

●

If an adjacent parked vehicle is

narrow or parked extremely

close to the curb, the position at

which assistance will park the

vehicle will also be close to the

curb. If it seems likely the vehi-

cle will collide with the curb or

drive off of the road, depress

the brake pedal to stop the vehi-

cle, and then press the

Advanced Park main switch to

disable the system.

333

4-5. Using the driving support systems

ing

When exiting from a parallel

parking space, if the system

determines that exit is possible

the parallel exiting function can

be used. Also, depending on the

surrounding environment, if it is

necessary to change the direc-

tion of travel of the vehicle, the

shift position can be changed by

assistance control.

With the brake pedal

depressed and P shift posi-

tion selected, press the

Advanced Park main switch

and check that the exit direc-

tion selection screen is dis-

played on the Multimedia

Display.

Select an arrow on the Multi-

media Display to select the

direction you wish to exit.

If the turn signal lever is operated,

only exit to the left or right can be

selected.

Depress the brake pedal and

select “Start” button.

A buzzer will sound, an operation

message will be displayed on the

multi-information display, and

assistance will begin operating.
To cancel assistance, press the

Advanced Park main switch.
If assistance is canceled,

“Advanced Park Canceled” will be

displayed.
If you feel that the vehicle is

approaching close to a surround-

ing vehicle, object, person, or gut-

ter:



P.327

Perform operations as indi-

cated by the advice displays

until the vehicle is in a posi-

tion where exit is possible.

When the vehicle reaches a posi-

tion where exit is possible, “You

can exit by moving the steering

NOTICE

●

If there is a wall or other barrier

on the inner side of the parking

space, the vehicle may stop at a

position slightly outside of the

set target parking space.

Advanced Park parallel

exiting function

Leaving a parking space

using the parallel exiting

function

334

4-5. Using the driving support systems

wheel” will be displayed. If the
steering wheel is operated,
“Advanced Park Finished” will be
displayed and assistance will end.

As assistance will end while the
vehicle is moving, grip the steering
wheel and drive forward.

If the steering wheel is not oper-
ated, the vehicle will stop at the exit
position. Assistance can be ended
by depressing the accelerator pedal
or brake pedal.

■

If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter



P.327

■

Parallel exiting function

Do not use parallel exiting function
in any situation other than when
exiting a parallel parking spot. If
assistance is started unintentionally,
depress the brake pedal and stop
the vehicle, then press the
Advanced Park main switch to can-
cel assistance.

■

Situations in which the parallel
exiting function will not operate

In situations such as the following,
the parallel exiting function will not
operate:

●

When vehicles waiting at a traffic
signal in the exit direction

●

When a vehicle is stopped in the
area behind where the vehicle will
exit

●

When a wall, column, or person is
detected as near a front or rear
side sensor

●

When the vehicle has been
parked on a curb and a side sen-
sor detects the road surface

335

4-5. Using the driving support systems

Dr
iv

ing

●

When a vehicle is not parked in
front of the vehicle

●

When there is excessive space
between the front of the vehicle
and a parked vehicle

■

When the brakes have been
operated



P.327

The memory function can be
used to park in a previously reg-
istered parking space, even if
there are no parking space lines
or adjacent parked vehicles.

Up to 3 parking spaces can be
registered.

Stop the vehicle with it
aligned near the center of the
target parking space.

Approximately 3.3 ft. (1 m)

Press the main switch and

then select

If the Advanced Park main switch is
pressed at a parking space without
parking lines or any adjacent
parked vehicles, “No available
parking space” may be displayed.

Continuously select and hold

Select perpendicular parking
(forward/reverse) function or
parallel parking function.

Only parking spaces for which
assist can be performed are dis-
played.

Select the parking direction.

When perpendicular parking (for-
ward/reverse) was selected in step

Advanced Park memory
function

Registering a parking
space

336

4-5. Using the driving support systems

When parallel parking was selected
in step

Using the arrow buttons,
adjust the position of the
parking space to be regis-
tered, and then select “OK”
button.

Select “Start” button.

A buzzer will sound, an operation
message will be displayed on the
multi-information display, and
assistance will begin operating.
When the brake pedal is released,
“Moving Forward...” will be dis-
played and the vehicle will begin

moving forward.

If you feel that the vehicle is
approaching close to a surround-
ing vehicle, object, person, or gut-
ter:



P.327

Perform operations as indi-
cated by the advice displays
until the vehicle stops in the
target parking space.

Check the position that the
vehicle has stopped. If nec-
essary, adjust the position of
the parking spot to be regis-
tered using the arrow but-
tons, and then select “Reg.”
button.

“Registration Completed” will be
displayed on the Multimedia Dis-

337

4-5. Using the driving support systems

Dr
iv

ing

play.



The amount that the position
of the parking spot to be reg-
istered can be adjusted is lim-
ited.

Stop the vehicle with it
aligned near the center of the
target parking space.

Approximately 3.3 ft. (1 m)

Press the Advanced Park
main switch and check that a
possible parking space is dis-

played on the Multimedia
Display.

If the “MODE” button is displayed,
the button can be touched to
change between the memory func-
tion, perpendicular parking (for-
ward/reverse) function and parallel
parking function.

Select the desired parking
space, and then select “Start”
button.

Perform the procedure for the per-
pendicular parking (for-
ward/reverse) function from step

(



P.325)

■

If you feel that the vehicle is
approaching close to a sur-
rounding vehicle, object, per-
son, or gutter



P.327

■

When overwriting a registered
parking space

If the maximum number of parking
spaces have been registered and

is selected, a registered parking

space can be selected and then
overwritten with a new parking
space.

When parking in a parking
space registered to the
memory function

338

4-5. Using the driving support systems

■

When multiple parking spaces

are registered

Select the desired parking space,

and then select “Start” button.

■

When the brakes have been

operated



P.327

NOTICE

■

When using the memory

function (



P.327, 332)

●

The memory function is a func-

tion which provides assistance

in parking in a previously regis-

tered parking space. If the con-

dition of the road surface,

vehicle, or surrounding area dif-

fers from when registration was

performed, the parking space

may not be able to be detected

correctly or assistance may not

be provided to the point that the

vehicle is fully parked.

●

Do not register a parking space

in situations such as the follow-

ing, as the set parking space

may not be able to be registered

or assistance may not be possi-

ble later.

• When a camera lens is dirty or

covered with water droplets

• When it is raining or snowing
• When the surrounding area is

dark (at night, etc.)

●

In situations such as the follow-

ing, it may not be possible to

• When there is insufficient space

between the road and parking

space

• When the road surface around

the parking space does not

have any differences the sys-

tem can recognize

●

If a parking space has been reg-

istered in situations such as the

following, assistance may not

be able to be started later or

assistance to the registered

position may not be possible.

• When shadows are cast on the

parking space (there is a carport

over the parking space, etc.)

• When there are leaves, gar-

bage, or other objects which will

likely move, in the parking

space

• When the road surface around

the parking space has the same

repeating pattern (brick, etc.)

339

4-5. Using the driving support systems

ing

NOTICE

●

In situations such as the follow-

ing, it may not be possible for

the system to provide assis-

tance to a registered parking

spot:

• When the appearance of the

parking space is affected by the

shadow of the vehicle or trees

• When an object is detected in

the registered parking space

• When a pedestrian or passing

vehicle is detected during assis-

tance

• When the position the vehicle is

stopped when assistance is

started differs from the position

when registration was per-

formed

• When the registered parking

space cannot be reached due to

the existence of parking blocks,

etc.

• When the road surface around

the parking space has changed

(road surface has degraded or

been resurfaced)

• When the sunlight conditions

differ from when registration

was performed (due to weather

or time of day)

• When the sun is shining directly

into a camera, such as in the

early morning or evening

• When the color or brightness of

the road surface is uneven

• When a light is temporarily

shined on the parking space

(lights of another vehicle, secu-

rity light, etc.)

• When the road surface around

the parking space has the same

repeating pattern

• When there is a low protrusion

on the road surface near the

parking space

• When the parking space is on a

slope

• When a camera has been

splashed by hot or cold water

and the lens has fogged up

• When a camera lens is dirty or

covered with water droplets

• When accessories which

obstruct the view of the camera

are installed

If assistance is ended during

registration, perform registration

again.

●

When registering a parking

space to the memory function, if

the road surface cannot be

detected “No available parking

space to register” will be dis-

played.

●

When using the memory func-

tion, make sure to stop immedi-

ately in front of the stop

position. Otherwise the parking

space may not be able to be

detected correctly or assis-

tance may not be provided to

the point that the vehicle is fully

parked.

●

Do not use the memory function

if a camera has been subjected

to a strong impact or images of

the panoramic view monitor are

misaligned.

●

If a camera has been replaced,

as the installation angle of the

camera will have changed, it will

be necessary to reregister park-

ing spaces of the memory func-

tion.

340

4-5. Using the driving support systems

■

Assistance will be can-
celed when

In situations such as the follow-
ing, Advanced Park operation
will be canceled. Firmly hold the
steering wheel and depress the
brake pedal to stop the vehicle.

As system operation has been
canceled, begin the operation
again or continue parking manu-
ally, using the steering wheel.



The Advanced Park main
switch is pushed



The shift position has been
changed to P



The parking brake is engaged



A door or the back door is
opened



The driver’s seat belt is unfas-
tened



The outside rear view mirrors
are folded



The TRAC or VSC is turned
off



The TRAC, VSC or ABS oper-
ates



The power switch is pressed



The system determines assis-
tance cannot be continued in
the current parking environ-
ment



The system malfunctions



While the vehicle was

stopped, “Cancel” was
selected on the Multimedia
Display

■

Assistance will be sus-
pended when

In situations such as the follow-
ing, Advanced Park operation
will be suspended.

Assistance can be started again
by following the directions dis-
played on the Multimedia Dis-
play.

Also, when assistance is sus-
pended, if the shift position is
changed twice with the brake
pedal depressed, assistance will
be canceled in that shift posi-
tion. However, if assistance is
suspended by changing the shift
position, assistance will be can-
celed if the shift position is
changed once.



The steering wheel is oper-
ated



The accelerator pedal is
depressed



The shift position has been
changed



A moving object or stationary
object that may collide with
your vehicle has been
detected, resulting in the
operation of the hybrid system
output control/braking control.



Camera switch is pressed

Advanced Park cancel-
ation/suspension

341

4-5. Using the driving support systems

Dr
iv

ing

Select

on the Multimedia

Display, and then select
“Advanced Park”.

■

“Speed Profile”

The vehicle speed for when
assistance is performed can be
set.

This setting cannot be changed
when registering a parking
space to the memory function.

■

“Obstacle detection range”

The distance from which obsta-
cles will be avoided while assis-
tance is being performed can be
set.

■

“Preferred parking method”

The preferred parking direction
displayed when at a parking
space which perpendicular (for-
ward/reverse) or parallel parking
is possible can be set.

■

“Preferred parking direc-
tion”

The preferred parking direction
displayed when it is possible to
pull perpendicular forward or
reverse into a parking space can
be selected.

■

“Preferred exit direction
(perpendicular)”

The preferred exit direction dis-
played when it is possible to pull
forward or reverse to the left or

right out of a parking space can
be selected.

■

“Preferred exit direction
(parallel)”

The preferred exit direction dis-
played when it is possible to exit
to the left or right from a parallel
parking space can be selected.

■

“Camera view when park-
ing”

The display angle of the camera
image when using the perpen-
dicular parking (for-
ward/reverse) function or
parallel parking function can be
set.

■

“Camera view when exit-
ing”

The display angle of the camera
image when using the perpen-
dicular exiting (forward/reverse)
function or parallel parking exit
function can be set.

■

“Parking path adjustment”

The course for when parking
assistance is operating can be
adjusted inward or outward.

If the tires are worn, the path of
vehicle may be offset from the
center of the parking space. In
this case, use this setting to
adjust the parking course.

■

“Road width adjustment”

When parking assistance is
started, the amount of lateral
movement while the vehicle is
moving forward can be

Changing the Advanced
Park settings

342

4-5. Using the driving support systems

adjusted.

■

“Park position adjustment

(forward)”

The position at which perpendic-

ular parking (forward) is com-

pleted can be adjusted. (Except

when using the memory func-

tion.)

■

“Park position adjustment

(reverse)”

The position at which perpendic-

ular parking (reverse) is com-

pleted can be adjusted. (Except

when using the memory func-

tion.)

■

“Rear accessory setting”

If an accessory, such as a trailer

hitch, has been installed to the

rear of the vehicle, the length of

the rear of the vehicle can be

adjusted to help avoid colliding

with objects to the rear of the

vehicle.

■

“Clear registered parking

space”

The parking spaces registered

to the memory function can be

deleted. Parking space informa-

tion cannot be deleted when

assistance is being performed

or when registering parking

space information to the mem-

ory function.

The operating state, assistance

operation, etc. of the Advanced

Park is displayed on the Multi-

media Display. If a message is

displayed, respond according to

the content displayed.

■

If “No available parking space”

is displayed

Move the vehicle to a location where

a parking space or parking lines can

be detected.

■

If “Unavailable in current condi-

tion” is displayed

Move the vehicle to another location

and use the system.

■

If “Not enough space to exit” is

displayed

The parallel parking exit function

cannot be used due to a situation

such as the distance between your

vehicle and vehicles parked in front

of and behind your vehicle being

short, the existence of an object in

the exit direction, etc.
Check the conditions of the area

NOTICE

●

Take care when using the park

position adjustment (forward) or

park position adjustment

(reverse) for adjusting because

the vehicle may collide with

parking blocks, curb stones, or

other low objects.

●

If it is likely that your vehicle will

collide with a nearby vehi-

cle/object, parking block, curb

stone, etc., depress the brake

pedal to stop the vehicle and

press the Advanced Park main

switch to disable the system.

Advanced Park displayed

messages

343

4-5. Using the driving support systems

Dr
iv

ing

around your vehicle and exit from
the parking space manually.

■

If “Cannot control speed” is
displayed

The system judged that it cannot
adjust the speed of the vehicle when
using the system in an area with a
slope or step and assistance was
canceled.

Use the system in a level location.

■

If “Obstacle detected” is dis-
played

As a moving object or stationary
object that may collide with your
vehicle has been detected, the
hybrid system output control/braking
control operates to suspend
Advanced Park assistance.

Check the condition of the surround-
ing area. To resume assistance,
select the “Start” button on the Multi-
media Display.

■

If “No available parking space
to register” is displayed

This message is displayed when

is selected at a parking space that
cannot be detected.

Operate the system at a parking
space where differences in the road
surface can be recognized.
(



P.335)

Operate the driving mode select
switch forward or backward to
select the desired driving mode.

Indicator

Driving mode select switch

Normal mode

Provides an optimal balance of fuel
economy, quietness, and dynamic
performance. Suitable for normal
driving.

Eco drive mode

Helps the driver accelerate in an
eco-friendly manner and improve
fuel economy through moderate
throttle characteristics and by con-
trolling the operation of the air con-
ditioning system (heating/cooling).

Driving mode select

switch

The driving modes can be
selected to suit the driving
and usage conditions.

Selecting a driving mode

344

4-5. Using the driving support systems

When Eco drive mode is selected,
Eco drive mode indicator comes
on.

Sport mode

Controls the hybrid system to pro-
vide quick, powerful acceleration.
This mode also expands the possi-
ble rate of deceleration by operat-
ing the accelerator pedal and
enables acceleration/deceleration
control based on the driver’s inten-
tions. This changes the steering
feel, making it suitable for when
agile driving response is desired,
such as when driving on roads with
many curves.

When Sport mode is selected,
Sport mode indicator comes on.

Custom mode

Allows you to drive with the power
train, steering wheel and air condi-
tioning system functions set to your
preferred settings.

Custom mode settings can only be
changed on the drive mode cus-
tomization display of Multimedia
Display. (



P.552)

When the Custom mode is
selected, Custom mode indicator
comes on.

■

Operation of the air condition-
ing system in Eco drive mode

When Eco drive mode is selected,
the air conditioning system will auto-
matically be changed to eco air con-
ditioning mode.

Eco air conditioning mode controls
the heating/cooling operations and
fan speed of the air conditioning
system to enhance fuel efficiency.
To improve air conditioning perfor-
mance, perform the following opera-
tions:

●

Adjust the fan speed (



P.359)

●

Deactivate Eco drive mode

●

Turn off eco air conditioning mode
(



P.363)

■

Automatic deactivation of a
driving mode

●

Sport mode and Custom mode
are automatically deactivated and
the driving mode returns to normal
mode when the power switch is
turned to OFF.

●

Normal mode and Eco drive mode
are not deactivated until another
driving mode is selected. (Even if
the power switch is turned to OFF,
normal mode and Eco drive mode
will not be automatically deacti-
vated.)

■

Customization

The custom mode can be changed.
(Customizable features:



P.540)

345

4-5. Using the driving support systems

Dr
iv

ing

■

ECB (Electronically Con-
trolled Brake System)

The electronically controlled
system generates braking force
corresponding to the brake
operation

■

ABS (Anti-lock Brake Sys-
tem)

Helps to prevent wheel lock
when the brakes are applied
suddenly, or if the brakes are
applied while driving on a slip-
pery road surface

■

Brake assist

Generates an increased level of
braking force after the brake
pedal is depressed when the
system detects a panic stop sit-
uation

■

VSC (Vehicle Stability Con-
trol)

Helps the driver to control skid-
ding when swerving suddenly or
turning on slippery road sur-
faces.

■

Enhanced VSC (Enhanced
Vehicle Stability Control)

Provides cooperative control of
the ABS, TRAC, VSC and EPS.

Helps to maintain directional
stability when swerving on slip-
pery road surfaces by con-
trolling steering performance.

■

TRAC (Traction Control)

Helps to maintain drive power
and prevent the drive wheels
from spinning when starting the
vehicle or accelerating on slip-
pery roads

■

Active Cornering Assist
(ACA)

Helps to prevent the vehicle
from drifting to the outer side by
performing inner wheel brake
control when attempting to
accelerate while turning

■

Hill-start assist control

Helps to reduce the backward
movement of the vehicle when
starting on an uphill

■

EPS (Electric Power Steer-
ing)

Employs an electric motor to
reduce the amount of effort
needed to turn the steering

Driving assist systems

To keep driving safety and
performance, the following
systems operate automati-
cally in response to various
driving situations. Be
aware, however, that these
systems are supplementary
and should not be relied
upon too heavily when oper-
ating the vehicle.

Summary of the driving
assist systems

346

4-5. Using the driving support systems

wheel.

■

E-Four (Electronic On-
Demand AWD system)
(AWD models)

Automatically controls the drive
system such as to front-wheel
drive or AWD (all wheel drive)
according to various running
conditions including normal driv-
ing, during cornering, on a
uphill, when starting off, during
acceleration, on a slippery roads
due to snow or rain, thus con-
tributing to stable operability and
driving stability.

■

The Secondary Collision
Brake

When the SRS airbag sensor
detects a collision and the sys-
tem operates, the brakes and
brake lights are automatically
controlled to reduce the vehicle
speed and help reduce the pos-
sibility of further damage due to
a secondary collision.

■

When the TRAC/VSC/ABS sys-
tems are operating

The slip indicator light will flash
while the TRAC/VSC/ABS systems
are operating.

■

Disabling the TRAC system

If the vehicle gets stuck in mud, dirt

or snow, the TRAC system may
reduce power from the hybrid sys-
tem to the wheels.

Pressing

to turn the system off

may make it easier for you to rock
the vehicle in order to free it.

To turn the TRAC system off,

quickly press and release

The “Traction Control Turned OFF”
will be shown on the multi-informa-
tion display.

Press

again to turn the system

back on.

■

Turning off both TRAC and VSC
systems

To turn the TRAC and VSC systems

off, press and hold

for more than

3 seconds while the vehicle is
stopped.

The VSC OFF indicator light will
come on and the “Traction Control
Turned OFF” will be shown on the
multi-information display.

Press

again to turn the systems

back on.

: PCS (Pre-Collision System) will

also be disabled (only pre-collision
warning is available). The PCS
warning light will come on and a
message will be displayed on the
multi-information display.
(



P.226)

347

4-5. Using the driving support systems

Dr
iv

ing

■

When the message is dis-
played on the multi-information
display showing that TRAC has

been disabled even if

has

not been pressed

TRAC is temporary deactivated. If
the information continues to show,
contact your Toyota dealer.

■

Operating conditions of hill-
start assist control

When all of the following conditions
are met, the hill-start assist control
will operate:

●

The shift position is in a position
other than P or N (when starting
off forward/backward on an
upward incline)

●

The vehicle is stopped

●

The accelerator pedal is not
depressed

●

The parking brake is not engaged

●

The power switch is in ON

■

Automatic system cancelation
of hill-start assist control

The hill-start assist control will turn
off in any of the following situations:

●

Shift the shift position to P or N.

●

The accelerator pedal is
depressed

●

The brake pedal is depressed and
the parking brake is engaged

●

A maximum of 2 seconds have
elapsed after the brake pedal is
released

●

The power switch is turned to OFF

■

Sounds and vibrations caused
by the ABS, brake assist, VSC,
TRAC and hill-start assist con-
trol systems

●

A sound may be heard from the
engine compartment when the
brake pedal is depressed repeat-
edly, when the hybrid system is
started or just after the vehicle
begins to move. This sound does

not indicate that a malfunction has
occurred in any of these systems.

●

Any of the following conditions
may occur when the above sys-
tems are operating. None of these
indicates that a malfunction has
occurred.

• Vibrations may be felt through the

vehicle body and steering.

• A motor sound may be heard also

after the vehicle comes to a stop.

■

ECB operating sound

ECB operating sound may be heard
in the following cases, but it does
not indicate that a malfunction has
occurred.

●

Operating sound heard from the
engine compartment when the
brake pedal is operated.

●

Operating sound heard from the
engine compartment when one or
two minutes passed after the stop
of the hybrid system.

■

Active Cornering Assist opera-
tion sounds and vibrations

When the Active Cornering Assist is
operated, operation sounds and
vibrations may be generated from
the brake system, but this is not a
malfunction.

■

Automatic reactivation of TRAC
and VSC systems

After turning the TRAC and VSC
systems off, the systems will be
automatically re-enabled in the fol-
lowing situations:

●

When the power switch is turned
off

●

If only the TRAC system is turned
off, the TRAC will turn on when
vehicle speed increases
If both the TRAC and VSC sys-
tems are turned off, automatic re-
enabling will not occur when vehi-
cle speed increases.

■

Operating conditions of Active
Cornering Assist

The system operates when the fol-

348

4-5. Using the driving support systems

lowing occurs.

●

TRAC/VSC can operate

●

The driver is attempting to accel-

erate while turning

●

The system detects that the vehi-

cle is drifting to the outer side

●

The brake pedal is released

■

Reduced effectiveness of the

EPS system

The effectiveness of the EPS sys-

tem is reduced to prevent the sys-

tem from overheating when there is

frequent steering input over an

extended period of time. The steer-

ing wheel may feel heavy as a

result. Should this occur, refrain

from excessive steering input or

stop the vehicle and turn the hybrid

system off. The EPS system should

return to normal within 10 minutes.

■

Secondary Collision Brake

operating conditions

The system operates when the SRS

airbag sensor detects a collision

while the vehicle is in motion.

However, the system does not oper-

ate when the components are dam-

aged.

■

Secondary Collision Brake

automatic cancellation

The system is automatically can-

celed in any of the following situa-

tions.

●

The vehicle speed drops to

approximately 0 mph (0 km/h).

●

A certain amount of time elapses

during operation

●

The accelerator pedal is

depressed a large amount

■

If a message about AWD is

shown on the multi-information

display (AWD models)

Perform the following actions.

●

“AWD System Overheated

Switching to 2WD Mode”

AWD system is overheated. Stop

the vehicle in a safe place with the

hybrid system operating.

If the message disappears after a

while, there is no problem. If the

message remains, have the vehicle

inspected by your Toyota dealer

immediately.

●

“AWD System Overheated 2WD

Mode Engaged”

AWD system has been temporarily

released and switched to front-

wheel drive due to overheating.

Stop the vehicle in a safe place with
the hybrid system operating.

If the message disappears after a

while, AWD system will automati-

cally recover. If the message

remains, have the vehicle inspected

by your Toyota dealer immediately.

●

“AWD System Malfunction 2WD

Mode Engaged Visit Your Dealer”

A malfunction occurs in the AWD

system. Have the vehicle inspected

by your Toyota dealer immediately.

: When stopping the vehicle, do not

stop the hybrid system until the

display message has turned off.

WARNING

■

The ABS does not operate

effectively when

●

The limits of tire gripping perfor-

mance have been exceeded

(such as excessively worn tires

on a snow-covered road).

●

The vehicle hydroplanes while

driving at high speed on wet or

slick roads.

349

4-5. Using the driving support systems

ing

WARNING

■

Stopping distance when the

ABS is operating may exceed

that of normal conditions

The ABS is not designed to

shorten the vehicle’s stopping dis-

tance. Always maintain a safe dis-

tance from the vehicle in front of

you, especially in the following sit-

uations:

●

When driving on dirt, gravel or

snow-covered roads

●

When driving with tire chains

●

When driving over bumps in the

road

●

When driving over roads with

potholes or uneven surfaces

■

TRAC/VSC may not operate

effectively when

Directional control and power may

not be achievable while driving on

slippery road surfaces, even if the

TRAC/VSC system is operating.

Drive the vehicle carefully in con-

ditions where stability and power

may be lost.

■

Active Cornering Assist does

not operate effectively when

●

Do not overly rely on Active

Cornering Assist. Active Corner-

ing Assist may not operate

effectively when accelerating

down slopes or driving on slip-

pery road surfaces.

●

When Active Cornering Assist

frequently operates, Active Cor-

nering Assist may temporarily

stop operating to ensure proper

operation of the brakes, TRAC

and VSC.

■

Hill-start assist control does

not operate effectively when

●

Do not overly rely on hill-start

assist control. Hill-start assist

control may not operate effec-

tively on steep inclines and

roads covered with ice.

●

Unlike the parking brake, hill-

start assist control is not

intended to hold the vehicle sta-

tionary for an extended period

of time. Do not attempt to use

hill-start assist control to hold

the vehicle on an incline, as

doing so may lead to an acci-

dent.

■

When the TRAC/ABS/VSC is

activated

The slip indicator light flashes.

Always drive carefully. Reckless

driving may cause an accident.

Exercise particular care when the

indicator light flashes.

■

When the TRAC/VSC systems

are turned off

Be especially careful and drive at

a speed appropriate to the road

conditions. As these are the sys-

tems to help ensure vehicle stabil-

ity and driving force, do not turn

the TRAC/VSC systems off

unless necessary.

■

Replacing tires

Make sure that all tires are of the

specified size, brand, tread pat-

tern and total load capacity. In

addition, make sure that the tires

are inflated to the recommended

tire inflation pressure level.

The ABS, TRAC and VSC sys-

tems will not function correctly if

different tires are installed on the

vehicle.

Contact your Toyota dealer for

further information when replacing

tires or wheels.

350

4-5. Using the driving support systems

WARNING

■

Handling of tires and the sus-

pension

Using tires with any kind of prob-

lem or modifying the suspension

will affect the driving assist sys-

tems, and may cause a system to

malfunction.

■

Secondary Collision Brake

Do not rely solely upon the Sec-

ondary Collision Brake. This sys-

tem is designed to help reduce

the possibility of further damage

due to a secondary collision, how-

ever, that effect changes accord-

ing to various conditions. Overly

relying on the system may result

in death or serious injury.

351

4-6. Driving tips

Dr
iv

ing

4-6.Driving tips

When using Eco drive mode, the
torque corresponding to the
accelerator pedal depression
amount can be generated more
smoothly than it is in normal
conditions. In addition, the oper-
ation of the air conditioning sys-
tem (heating/cooling) will be
minimized, improving the fuel
economy. (



P.343)

The Eco-friendly driving is pos-
sible by keeping the indicate of
Hybrid System Indicator within
Eco area. (



P.89)

Shift the shift position to D when
stopped at a traffic light, or driv-
ing in heavy traffic etc. Shift the
shift position to P when parking.
When using the N, there is no
positive effect on fuel consump-
tion. In the N, the gasoline
engine operates but electricity

cannot be generated. Also,
when using the air conditioning
system, etc., the hybrid battery
(traction battery) power is con-
sumed.



Drive your vehicle smoothly.
Avoid abrupt acceleration and
deceleration. Gradual accel-
eration and deceleration will
make more effective use of
the electric motor (traction
motor) without having to use
gasoline engine power.



Avoid repeated acceleration.
Repeated acceleration con-
sumes hybrid battery (trac-
tion battery) power, resulting
in poor fuel consumption. Bat-
tery power can be restored by
driving with the accelerator
pedal slightly released.

Make sure to operate the brakes
gently and in a timely manner. A
greater amount of electrical
energy can be regenerated
when slowing down.

Repeated acceleration and
deceleration, as well as long
waits at traffic lights, will lead to
bad fuel economy. Check traffic

Hybrid Electric Vehi-

cle driving tips

For economical and ecolog-
ical driving, pay attention to
the following points:

Using Eco drive mode

Use of Hybrid System
Indicator

Changing the shift posi-
tion

Accelerator pedal/brake
pedal operation

When braking

Delays

352

4-6. Driving tips

reports before leaving and avoid
delays as much as possible.
When driving in a traffic jam,
gently release the brake pedal
to allow the vehicle to move for-
ward slightly while avoiding
overuse of the accelerator
pedal. Doing so can help control
excessive gasoline consump-
tion.

Control and maintain the vehicle
at a constant speed. Before
stopping at a toll booth or simi-
lar, allow plenty of time to
release the accelerator and gen-
tly apply the brakes. A greater
amount of electrical energy can
be regenerated when slowing
down.

Use the air conditioning only
when necessary. Doing so can
help reduce excessive gasoline
consumption.
In summer: When the ambient
temperature is high, use the
recirculated air mode. Doing so
will help to reduce the burden on
the air conditioning system and
reduce fuel consumption as
well.
In winter: Because the gasoline
engine will not automatically cut
out until it and the interior of the
vehicle are warm, it will con-

sume fuel. Also, fuel consump-
tion can be improved by
avoiding overuse of the heater.

Make sure to check the tire infla-
tion pressure frequently.
Improper tire inflation pressure
can cause poor fuel economy.
Also, as snow tires can cause
large amounts of friction, their
use on dry roads can lead to
poor fuel economy. Use tires
that are appropriate for the sea-
son.

Carrying heavy luggage will lead
to poor fuel economy. Avoid car-
rying unnecessary luggage.
Installing a large roof rack will
also cause poor fuel economy.

Since the gasoline engine starts
up and cuts out automatically
when cold, warming up the
engine is unnecessary. More-
over, frequently driving short
distances will cause the engine
to repeatedly warm up, which
can lead to excess fuel con-
sumption.

Highway driving

Air conditioning

Checking tire inflation
pressure

Luggage

Warming up before driv-
ing

Toyota Prius (2024 year). Manual in english - page 11
