3-2. Opening, closing and locking the doors

Before

driving

WARNING

●

If a bicycle carrier or similar

heavy object is attached to the

back door, the power back door

may not operate, causing itself

to malfunction, or the back door

may suddenly shut again after

being opened, causing some-

one’s hands, head or neck to be

caught and injured. When

installing an accessory part to

the back door, using a genuine

Toyota part is recommended.

■

Jam protection function

Observe the following precau-

tions.

Failure to do so may cause death

or serious injury.

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

caught just before the back door

fully closes. Be careful not to

catch fingers or anything else.

●

The jam protection function may

not work depending on the

shape of the object that is

caught. Be careful not to catch

fingers or anything else.

■

Close & lock (Walk-Away)

function

The back door starts to close

automatically when leaving the

back door. Check the safety of the

surrounding area to make sure

there are no obstacles or anything

that could cause any of your

belongings to get caught.

NOTICE

■

Back door spindles

The back door is equipped with

spindles that hold the back door in

place.

Observe the following precau-

tions.

Failure to do so may cause dam-

age to the back door spindle,

resulting in malfunction.

●

Do not attach any foreign

objects, such as stickers, plastic

sheets, or adhesives to the

spindle rod.

●

Do not attach any accessories

other than genuine Toyota parts

to the back door.

●

Do not place your hand on the

spindle or apply lateral forces to

it.

■

To prevent back door closer

malfunction

Do not apply excessive force to

the back door while the back door

closer is operating. Applying

excessive force may cause the

back door closer to malfunction.

■

To prevent damage to the

power back door

●

Make sure that there is no ice

between the back door and

frame that would prevent move-

ment of the back door. Operat-

ing the power back door when

excessive load is present on the

back door may cause a mal-

function.

130

3-2. Opening, closing and locking the doors

The settings of the power back

door system can be changed by
displaying “PBD” from “

Vehicle Settings” on of the

multi-information display.

(



P.96)

The changed power back door set-

tings are not reset by turning the

power switch to OFF. In order to

restore the original settings, they

need to be changed back on the

of the multi-information display.

The open position of the power

back door can be adjusted.

Stop the back door in the

desirable position. (



P.122)

Press and hold the

switch on the lower part of

the back door for approxi-

mately 2 seconds.

When the settings are completed,

the buzzer sounds 4 times.
When opening the back door the

next time, the back door will stop at

that position.

■

Canceling the adjusted open

position of the back door

Press and hold the

switch on

NOTICE

●

Do not apply excessive force to

the back door while the power

back door is operating.

●

Take care not to damage the

sensors (installed on the right

and left edges of the power

back door) with a knife or other

sharp object. If the sensor is

disconnected, the power back

door will not close automati-

cally.

■

Close & lock function

: This setting can be customized

by your Toyota dealer.

When closing the power back

door using the close & lock func-

tion, a different buzzer than the

normal one will sound before the

operation begins.
To check that the operation has

started correctly, check that a dif-

ferent buzzer than the normal one

has sounded.
Additionally, when the power back

door is fully closed and locked,

operation signals will indicate that

all of the doors have been locked.

(



P.114)

Before leaving the vehicle, make

sure that the operational signals

have operated and that all of the

doors are locked.

Changing settings of the

power back door system

(vehicles with power back

door)

Adjusting the open posi-

tion of the back door

(vehicles with power back

door)

131

3-2. Opening, closing and locking the doors

Before driving

the lower part of the back door for
approximately 7 seconds.

After the buzzer sounds 4 times, it
sounds twice more. When the
power back door does the opening
operation the next time, the door will
open to the initial settings position.

■

Customization

The opening position can be set
with the multi-information display.
(



P.96)

Priority for the stop position is given
to the last position set by either the

switch on the lower part of the

back door multi-information display.

■

Antenna location

Antenna outside the cabin
(driver’s side)

Antenna outside the cabin (front
passenger’s side) (if equipped)

Antenna outside the luggage
compartment (if equipped)

Antennas inside the cabin

Smart key system

The following operations
can be performed simply by
carrying the electronic key
on your person, for example
in your pocket. The driver
should always carry the
electronic key.



Locks and unlocks the
doors (



P.113)



Locks and unlocks the back
door (if equipped) (



P.120)



Starts the hybrid system
(



P.180)

132

3-2. Opening, closing and locking the doors

■

Effective range (areas within
which the electronic key is
detected)

When locking or unlocking the
doors

The system can be operated when
the electronic key is within about 2.3
ft. (0.7 m) of the driver’s door han-
dle, front passenger’s door handle
(if equipped) and back door opener
switch (if equipped). (Only the doors
detecting the key can be operated.)

When starting the hybrid system
or changing power switch modes

The system can be operated when
the electronic key is inside the vehi-
cle.

■

If an alarm sounds or a warning
message is displayed

An alarm sounds and warning mes-
sage displays shown on the multi-
information display are used to pro-
tect against unexpected accidents
or theft of the vehicle resulting from
erroneous operation. When a warn-
ing message is displayed, take
appropriate measures based on the
displayed message.

When only an alarm sounds, cir-
cumstances and correction proce-
dures are as follows.

●

When an exterior alarm sounds
once for 5 seconds

●

When an interior alarm pings con-
tinuously

■

If “Key Detected in Vehicle” is
shown on the multi-information
display

An attempt was made to lock the
doors using the smart key system
while the electronic key was still
inside the vehicle. Retrieve the elec-
tronic key from the vehicle and lock
the doors again.

■

Battery-saving function

The battery-saving function will be
activated in order to prevent the
electronic key battery and the 12-
volt battery from being discharged
while the vehicle is not in operation
for a long time.

●

In the following situations, the
smart key system may take some
time to unlock the doors.

• The electronic key has been left in

an area of approximately 11.5 ft.
(3.5 m) of the outside of the vehi-

Situation

Correction pro-

cedure

An attempt was
made to lock the
vehicle while a
door was open.

Close all of the
doors and lock
the doors again.

Situation

Correction pro-

cedure

The power
switch was
turned to ACC
while the driver’s
door was open
(or the driver’s
door was opened
while the power
switch was in
ACC).

Turn the power
switch to OFF
and close the
driver’s door.

133

3-2. Opening, closing and locking the doors

Before driving

cle for 40 seconds or longer.

• The smart key system has not

been used for 5 days or longer.

●

If the smart key system has not
been used for 14 days or longer,
the doors cannot be unlocked at
any doors except the driver’s
door. In this case, take hold of the
driver’s door handle, or use the
wireless remote control or the
mechanical key, to unlock the
doors.

■

Turning an electronic key to
battery-saving mode

●

When battery-saving mode is set,
battery depletion is minimized by
stopping the electronic key from
receiving radio waves.

Press

twice while pressing

and holding

Confirm that the electronic key indi-
cator flashes 4 times.
While the battery-saving mode is
set, the smart key system cannot be
used. To cancel the function, press
any of the electronic key buttons.

●

Electronic keys that will not be
used for long periods of time can
be set to the battery-saving mode
in advance.

■

When electronic key function
stops

If the position of the electronic key
has not changed for a certain
amount of time such as when the
electronic key is left somewhere, the
function of the electronic key stops
to reduce depletion of the battery.
In this case, function can automati-

cally be restored by moving the
position of the key such as by lifting
it up.

■

Conditions affecting operation

The smart key system uses weak
radio waves. In the following situa-
tions, the communication between
the electronic key and the vehicle
may be affected, preventing the
smart key system, wireless remote
control and immobilizer system from
operating properly.

●

When the electronic key battery is
depleted

●

Near a TV tower, electric power
plant, gas station, radio station,
large display, airport or other facil-
ity that generates strong radio
waves or electrical noise

●

When the electronic key is in con-
tact with, or is covered by the fol-
lowing metallic objects

• Cards to which aluminum foil is

attached

• Cigarette boxes that have alumi-

num foil inside

• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

●

When other wireless key (that
emits radio waves) is being used
nearby

●

When carrying the electronic key
together with the following devices
that emit radio waves

• Portable radio, cellular phone,

cordless phone or other wireless
communication devices

• Another vehicle’s electronic key or

a wireless key that emits radio
waves

• Personal computers or personal

digital assistants (PDAs)

• Digital audio players
• Portable game systems

●

If window tint with a metallic con-
tent or metallic objects are
attached to the rear window

●

When the electronic key is placed

134

3-2. Opening, closing and locking the doors

near a battery charger or elec-
tronic devices

●

When the vehicle is parked in a
pay parking spot where radio
waves are emitted.

If the doors cannot be
locked/unlocked using the smart key
system, lock/unlock the doors by
performing any of the following:

●

Bring the electronic key close to
either front door handle and oper-
ate the entry function.

●

Operate the wireless remote con-
trol.

If the doors cannot be
locked/unlocked using the above
methods, use the mechanical key.
(



P.110)

If the hybrid system cannot be
started using the smart key system,
refer to P.507.

■

Note for the entry function

●

Even when the electronic key is
within the effective range (detec-
tion areas), the system may not
operate properly in the following
cases:

• The electronic key is too close to

the window or outside door han-
dle, near the ground, or in a high
place when the doors are locked
or unlocked.

• The electronic key is on the instru-

ment panel, luggage compartment
or floor, or in the door pockets or
glove box when the hybrid system
is started or power switch modes
are changed.

●

Do not leave the electronic key on
top of the instrument panel or near
the door pockets when exiting the
vehicle. Depending on the radio
wave reception conditions, it may
be detected by the antenna out-
side the cabin and the door will
become lockable from the outside,
possibly trapping the electronic
key inside the vehicle.

●

As long as the electronic key is
within the effective range, the

doors may be locked or unlocked
by anyone. However, only the
doors detecting the electronic key
can be used to unlock the vehicle.

●

Even if the electronic key is not
inside the vehicle, it may be possi-
ble to start the hybrid system if the
electronic key is near the window.

●

The doors may unlock if a large
amount of water splashes on the
door handle, such as in the rain or
in a car wash when the electronic
key is within the effective range.
(The doors will automatically be
locked after approximately 60 sec-
onds if the doors are not opened
and closed.)

●

If the wireless remote control is
used to lock the doors when the
electronic key is near the vehicle,
there is a possibility that the door
may not be unlocked by the entry
function. (Use the wireless remote
control to unlock the doors.)

●

Touching the door lock sensor
while wearing gloves may delay or
prevent lock operation. Remove
the gloves and touch the lock sen-
sor again.

●

When the lock operation is per-
formed using the lock sensor, rec-
ognition signals will be shown up
to two consecutive times. After
this, no recognition signals will be
given.

●

If the door handle becomes wet
while the electronic key is within
the effective range, the door may
lock and unlock repeatedly. In that
case, follow the following correc-
tion procedures to wash the vehi-
cle:

• Place the electronic key in a loca-

tion 6 ft. (2 m) or more away from
the vehicle. (Take care to ensure
that the key is not stolen.)

• Set the electronic key to battery-

saving mode to disable the smart
key system. (



P.133)

●

If the electronic key is inside the
vehicle and a door handle

135

3-2. Opening, closing and locking the doors

Before

driving

becomes wet during a car wash, a

message may be shown on the

multi-information display and a

buzzer will sound outside the vehi-

cle. To turn off the alarm, lock all

the doors.

●

The lock sensor may not work

properly if it comes into contact

with ice, snow, mud, etc. Clean

the lock sensor and attempt to

operate it again.

●

A sudden approach to the effec-

tive range or door handle may pre-

vent the doors from being

unlocked. In this case, return the

door handle to the original position

and check that the doors unlock

before pulling the door handle

again.

●

If there is another electronic key in

the detection area, it may take

slightly longer to unlock the doors

after the door handle is gripped.

■

When the vehicle is not driven

for extended periods

●

To prevent theft of the vehicle, do

not leave the electronic key within

6 ft. (2 m) of the vehicle.

●

The smart key system can be

deactivated in advance. (



P.544)

●

Battery-saving mode can reduce

the power consumption of elec-

tronic keys. (



P.133)

■

To operate the system properly

Make sure to carry the electronic

key when operating the system. Do

not get the electronic key too close

to the vehicle when operating the

system from the outside of the vehi-

cle.
Depending on the position and hold-

ing condition of the electronic key,

the key may not be detected cor-

rectly and the system may not oper-

ate properly. (The alarm may go off

accidentally, or the door lock pre-

vention may not operate.)

■

If the smart key system does

not operate properly

●

Locking and unlocking the doors:

Use the mechanical key.

(



P.506)

●

Starting the hybrid system:



P.507

■

Customization

Settings (e.g. smart key system)

can be changed.

(Customizable features:



P.544)

If the smart key system has been

deactivated in a customized setting,

refer to the explanations for the fol-

lowing operations.

●

Locking and unlocking the doors:

Use the wireless remote control or

mechanical key. (



P.113, 506)

●

Starting the hybrid system and

changing power switch modes:



P.507

●

Stopping the hybrid system:



P.182

WARNING

■

Caution regarding interfer-

ence with electronic devices

●

People with implantable car-

diac pacemakers, cardiac

resynchronization therapy-

pacemakers or implantable car-

dioverter defibrillators should

keep away from the smart key

system antennas. (



P.131)

The radio waves may affect the

operation of such devices. If

necessary, the entry function

can be disabled. Ask your

Toyota dealer for details, such

as the frequency of radio waves

and timing of the emitted radio

waves. Then, consult your doc-

tor to see if you should disable

the entry function.

137

3-3. Adjusting the seats

Before driving

3-3.Adjusting the seats



Manual seat

Seat position adjustment
lever

Seatback angle adjustment
lever

Vertical height adjustment
lever



Power seat (if equipped for
driver’s side)

Seat position adjustment
switch

Seatback angle adjustment
switch

Seat cushion (front) angle
adjustment switch

Vertical height adjustment
switch

Lumbar support adjustment
switch

■

When adjusting the seat

Take care when adjusting the seat
so that the head restraint does not
touch the ceiling.

■

Power easy access system (if
equipped)

The driver’s seat moves in accor-
dance with power switch mode and
the driver’s seat belt condition.
(



P.159)

Front seats

The seats can be adjusted
(longitudinally, vertically,
etc.). Adjust the seat to
ensure the correct driving
posture.

Adjustment procedure

138

3-3. Adjusting the seats

■

Before folding down the

seatbacks

Park the vehicle in a safe

place.

Apply the parking brake (



P.193)

and shift the shift position to P.

(



P.188)

Adjust the position of the

front seat and the angle of

the seatback. (



P.137)

Depending on the position of the

front seat, if the seatback is folded

backward, it may interfere with the

operation of the rear seat.

Lower the head restraint of

the rear outboard seat.

(



P.140)

Vehicles with armrest: Stow

the armrest of the rear seat if

it is pulled out. (



P.386)

This step is not necessary when

operating the left side seat only.

■

Folding down the seat-

backs

While pulling the seatback angle
adjustment lever , fold the

seatback down.

WARNING

■

When adjusting the seat posi-

tion

●

Take care when adjusting the

seat position to ensure that

other passengers are not

injured by the moving seat.

●

Do not put your hands under the

seat or near the moving parts to

avoid injury.

Fingers or hands may become

jammed in the seat mechanism.

●

Make sure to leave enough

space around the feet so they

do not get stuck.

●

Manual seat only: After adjust-

ing the seat, make sure that the

seat is locked in position.

■

Seat adjustment

To reduce the risk of sliding under

the lap belt during a collision, do

not recline the seat more than

necessary.

If the seat is too reclined, the lap

belt may slide past the hips and

apply restraint forces directly to

the abdomen, or your neck may

contact the shoulder belt, increas-

ing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made

while driving as the seat may

unexpectedly move and cause

the driver to lose control of the

vehicle.

Rear seats

Folding the seatbacks can

be done with lever opera-

tion.

Folding down the rear

seatbacks

139

3-3. Adjusting the seats

Before

driving

■

Returning the rear seat-

backs

To avoid trapping the seat belt

between the seat and the inside

of the vehicle, pass the seat belt
outside the seat belt guide

and then return the seatback

securely to the locked position.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

When folding the rear seat-

backs down

●

Do not fold the seatbacks down

while driving.

●

Stop the vehicle on level

ground, set the parking brake

and shift the shift position to P.

●

Do not allow anyone to sit on a

folded seatback or in the lug-

gage compartment while driv-

ing.

●

Do not allow children to enter

the luggage compartment.

●

Do not operate the rear seat if it

is occupied.

●

Be careful not to get feet or

hands caught in the moving

parts or joints of the seats

during operation.

●

Do not allow children to operate

the seat.

■

After returning the rear seat-

back to the upright position

●

Make sure that the seatback is

securely locked in position by

lightly pushing it back and forth.

If the seatback is not securely

locked, the red marking will be

visible on the seatback lock

release lever. Make sure that

the red marking is not visible.

●

Check that the seat belts are

not twisted or caught in the

seatback.

140

3-3. Adjusting the seats

■

Front seats

Pull the head restraints up.

Down

Push the head restraint down while

pressing the lock release button

■

Rear outboard seats

Pull the head restraints up.

Down

Push the head restraint down while

pressing the lock release button

■

Rear center seat

Head restraints cannot be

adjusted.

■

Adjusting the height of the head

restraints

Make sure that the head restraints

are adjusted so that the center of

the head restraint is closest to the

top of your ears.

■

Front seats

Pull the head restraint up while

pressing the lock release button

Head restraints

Head restraints are pro-

vided for all seats.

WARNING

■

Head restraint precautions

Observe the following precautions

regarding the head restraints.

Failure to do so may result in

death or serious injury.

●

Use the head restraints

designed for each respective

seat.

●

Adjust the head restraints to the

correct position at all times.

●

After adjusting the head

restraints, push down on them

and make sure they are locked

in position.

●

Do not drive with the head

restraints removed.

Vertical adjustment

Removing the head

restraints

141

3-3. Adjusting the seats

Before driving

If the head restraint touches the
ceiling, making the removal difficult,
change the seat height or angle.
(



P.137)

■

Rear outboard seats

Pull the seatback lock
release lever and fold down
the seatback until it reaches
the position where the head
restraints can be removed.

Pull the head restraint up
while pressing the lock

release button

■

Front seats

Align the head restraint with the
installation holes and push it
down to the lock position.

Press and hold the lock release

button

when lowering the head

restraint.

■

Rear outboard seats

Pull the seatback lock
release lever and fold down
the seatback until it reaches

Installing the head
restraints

143

3-4. Adjusting the steering wheel and mirrors

Before

driving

3-4.Adjusting the steering wheel and mirrors

Hold the steering wheel and

push the lever down.

Adjust to the ideal position by

moving the steering wheel

horizontally and vertically.

After adjustment, pull the lever up

to secure the steering wheel.

To sound the horn, press on or
close to the

mark.

Steering wheel

Adjustment procedure

WARNING

■

Caution while driving

Do not adjust the steering wheel

while driving.

Doing so may cause the driver to

mishandle the vehicle and cause

an accident, resulting in death or

serious injury.

■

After adjusting the steering

wheel

Make sure that the steering wheel

is securely locked.

Otherwise, the steering wheel

may move suddenly, possibly

causing an accident, and resulting

in death or serious injury. Also,

the horn may not sound if the

steering wheel is not securely

locked.

Sounding the horn

144

3-4. Adjusting the steering wheel and mirrors

: If equipped

The height of the rear view mir-

ror can be adjusted to suit your

driving posture.
Adjust the height of the rear

view mirror by moving it up and

down.



Manual anti-glare inside rear

view mirror

Reflected light from the head-

lights of vehicles behind can be

reduced by operating the lever.

Normal position
Anti-glare position



Auto anti-glare inside rear

view mirror

Responding to the level of

brightness of the headlights of

vehicles behind, the reflected

light is automatically reduced.

■

To prevent sensor error (vehi-

cles with auto anti-glare inside

rear view mirror)

To ensure that the sensors operate

properly, do not touch or cover

them.

Inside rear view mir-

ror

The rear view mirror’s posi-

tion can be adjusted.

Adjusting the height of

rear view mirror

WARNING

■

Caution while driving

Do not adjust the position of the

mirror while driving.

Doing so may lead to mishandling

of the vehicle and cause an acci-

dent, resulting in death or serious

injury.

Anti-glare function

145

3-4. Adjusting the steering wheel and mirrors

Before

driving

: If equipped

Camera indicator

Indicates that the camera is operat-

ing normally.

Icon display area

Displays icons, adjusting gauge,

etc. (



P.147)

Select/adjust button

Press to change the setting of the

item you want to adjust.

Menu button

Press to display the icon display

area and select the item you want

to adjust.

Lever

Operate to change between digital

mirror mode and optical mirror

mode.

Digital anti-glare mode indi-

cator

In digital mirror mode, this indicates

Digital Rear-view Mir-

ror

The Digital Rear-view Mirror

is a system that uses the

camera on the rear of the

vehicle and displays its

image on the display of the

Digital Rear-view Mirror.
The Digital Rear-view Mirror

can be changed between

optical mirror mode and dig-

ital mirror mode by operat-

ing the lever.
The Digital Rear-view Mirror

allows the driver to see the

rear view despite obstruc-

tions, such as the head

restraints or luggage,

ensuring rear visibility.

Also, the rear seats are not

displayed and privacy of the

passengers is enhanced.

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

Before using the Digital Rear-

view Mirror

●

Make sure to adjust the mirror

before driving. (



P.147)

• Change to optical mirror mode

and adjust the position of the

Digital Rear-view Mirror so that

the area behind your vehicle

can be viewed properly.

• Change to digital mirror mode

and adjust the display settings.

●

As the range of the image dis-

played by the Digital Rear-view

Mirror is different from that of

the optical mirror, make sure to

check this difference before

driving.

System components

146

3-4. Adjusting the steering wheel and mirrors

that the anti-glare function is on.
(



P.147)

Operate the lever to change
between digital mirror mode and
optical mirror mode.

Digital mirror mode

Displays an image of the area
behind the vehicle.

will illuminate in this mode.

Optical mirror mode

Turns off the display of the Digital
Rear-view Mirror allows it to be
used as an optical mirror.

■

Digital mirror mode operating
condition

The power switch is turned to ON.

When the power switch is changed
from ON to OFF or ACC, the image
will disappear after several seconds.

■

When using the Digital Rear-
view Mirror in digital mirror
mode

●

If it is difficult to see the Digital
Rear-view Mirror image because
water, snow, mud, etc. is stuck to
the camera lens, operate the cam-
era cleaning washer (



P.205) or

change to optical mirror mode.

●

When the back door is open, the
Digital Rear-view Mirror image

may not display properly. Before
driving, make sure the back door
is closed.

●

If the display is difficult to see due
to reflected light, close the sun-
shade (if equipped).

●

Any of the following conditions
may occur when driving in the
dark, such as at night. None of
them indicates that a malfunction
has occurred.

• Colors of objects in the displayed

image may differ from their actual
color.

• Depending on the height of the

lights of the vehicle behind, the
area around the vehicle may
appear white and blurry.

• Automatic image adjustment for

brighter surrounding image may
cause flickering.

If it is difficult to see the displayed
image or flickering bothers you,
change to optical mirror mode.

●

The Digital Rear-view Mirror may
become hot while it is in digital
mirror mode.
This is not a malfunction.

●

Depending on your physical con-
dition or age, it may take longer
than usual to focus on the dis-
played image. In this case,
change to optical mirror mode.

●

Do not let passengers stare at the
displayed image when the vehicle
is being driven, as doing so may
cause motion sickness.

■

When the system malfunctions

If the symbol shown in the illustra-
tion is displayed when using the
Digital Rear-view Mirror in digital
mirror mode, the system may be
malfunctioning. The symbol will dis-
appear in a few seconds. Operate
the lever, change to optical mirror
mode and have the vehicle
inspected by your Toyota dealer.

Changing modes

147

3-4. Adjusting the steering wheel and mirrors

Before driving

■

Adjusting the mirror height

The height of the rear view mir-
ror can be adjusted to suit your
driving posture.

Change to optical mirror mode,
adjusting the height of the rear
view mirror by moving it up and
down.

■

Display settings (digital
mirror mode)

Settings of the display in the dig-
ital mirror mode, on/off opera-
tion of the automatic anti-glare
function, etc. can be changed.

Press the menu button.

The icons will be displayed.

Press the menu button
repeatedly and select the
item you want to adjust.

Press

change the setting.

The icons will disappear if a button
is not operated for approximately 5
seconds or more.

Adjusting the mirror

Icons

Settings

Select to adjust the bright-
ness of the display.

Select to adjust the area dis-
played up/down.

Select to adjust the area dis-
played to the left/right.

Select to adjust the angle of
the displayed image.

Select to zoom in/out the dis-
played image.

148

3-4. Adjusting the steering wheel and mirrors

: This is a function for the optical

mirror mode, however, the setting
can also be changed while using
the digital mirror mode.

■

Enabling/disabling the
automatic anti-glare func-
tion (optical mirror mode)

The automatic anti-glare func-
tion in the optical mirror mode
can be enabled/disabled. The
setting can be changed in both
the digital mirror mode and the
optical mirror mode.



When using the digital mirror
mode



P.147



When using the optical mirror
mode

Press the menu button.

The icons will be displayed.

Press

enable (ON)/disable (OFF)
the automatic anti-glare func-
tion.

The icons will disappear if a button
is not operated for approximately 5
seconds or more.

■

Adjusting the display (digital
mirror mode)

●

The icons will disappear if a button
is not operated for approximately
5 seconds or more.

●

If the displayed image is adjusted,
it may appear distorted. This is not
a malfunction.

●

If the brightness of the Digital
Rear-view Mirror is set too high, it
may cause eye strain. Adjust the
Digital Rear-view Mirror to an
appropriate brightness. If your
eyes become tired, change to
optical mirror mode.

●

The brightness of the Digital Rear-
view Mirror will change automati-
cally according to the brightness
of the area in front of your vehicle.

●

The digital anti-glare mode oper-
ates only in locations where the
surroundings are dark. Depending
on the surrounding illumination
environment, the image may not

Select to enable/disable the
automatic anti-glare func-

tion.

Responding to the bright-
ness of the headlights of
vehicles behind, the
reflected light is automati-
cally adjusted.

The automatic anti-glare
function is enabled each
time the power switch is
changed to ON.

The digital anti-glare mode
can be turned on and off.

When enabled, the bright-
ness of the display is
reduced at night to reduce
headlight glare from vehicles
to the rear.

Icons

Settings

149

3-4. Adjusting the steering wheel and mirrors

Before

driving

darken and it may not be possible

to reduce headlight glare from

vehicles to the rear.

■

To prevent the light sensors

from malfunctioning

To prevent the light sensors from

malfunctioning, do not touch or

cover them.

■

Cleaning the mirror surface

If the mirror surface is dirty, the

image on the display may be dif-

ficult to see.

Clean the mirror surface gently

using a soft dry cloth.

■

Cleaning the camera

If it is difficult to see the Digital

Rear-view Mirror image

because water, snow, mud, etc.

is stuck to the camera lens,

operate the camera cleaning

washer or change to optical mir-

ror mode. (



P.205)

■

The camera

The camera for the Digital Rear-

view Mirror is located as shown.

■

Cleaning the camera with

washer fluid

●

When cleaning the camera, it may

be difficult to see the image due to

the washer fluid. Therefore, take

care in the surrounding area while

WARNING

Observe the following precau-

tions.

Failure to do so may result in

death or serious injury.

■

While driving

●

Do not adjust the position of the

Digital Rear-view Mirror or

adjust the display settings while

driving.

Stop the vehicle and operate

the Digital Rear-view Mirror

control switches.

Failure to do so may cause a

steering wheel operation error,

resulting in an unexpected acci-

dent.

●

Always pay attention to the

vehicle’s surroundings.

The size of the vehicles and other

objects may look different when in

digital mirror mode and optical

mirror mode.

When backing up, make sure to

directly check the safety of the

area around your vehicle, espe-

cially behind the vehicle.

Additionally, if a vehicle

approaches from the rear in the

dark, such as at night, the sur-

rounding area may appear dim.

■

To prevent causes of fire

If the driver continues using the

Digital Rear-view Mirror while

smoke or odor comes from the

mirror, it may result in fire. Stop

using the system immediately and

contact your Toyota dealer.

Cleaning the Digital Rear-

view Mirror

150

3-4. Adjusting the steering wheel and mirrors

driving.

●

If washer fluid remains on the

camera lens surface after clean-

ing, the image may be difficult to

see at night due to the height or

inclination of the headlights of the

vehicle behind. In this case,

change to optical mirror mode.

●

Some dirts may not be removed

completely after cleaning. In this

case, rinse the camera lens with a

large quantity of water and then

wipe it clean with a soft cloth

dampened with water.

●

Washer fluid is sprayed onto the

camera lens surface. Therefore,

the ice, snow, etc. adhering

around the camera cannot be

removed.

■

The cooling fan

There is a cooling fan in the Digital

Rear-view Mirror. Cooling fan

sounds may be heard when using

the system.

NOTICE

■

To prevent the Digital Rear-

view Mirror from malfunction-

ing

●

Do not use detergents, such as

thinner, benzene, and alcohol to

clean the mirror. They may dis-

color, deteriorate or damage the

mirror surface.

●

Do not smoke, use matches,

use cigarette lighters or allow

open flames near the mirror. It

may damage the mirror or

cause a fire.

●

Do not remove, disassemble or

modify the mirror.

●

Do not block the vent holes of

the mirror. Otherwise, the mirror

may be hot, leading to a mal-

function or a fire.

■

To prevent the camera from

malfunctioning

●

Observe the following precau-

tions, otherwise the Digital

Rear-view Mirror may not oper-

ate properly.

• Do not strike or hit the camera

or subject it to a strong impact,

as the camera installation posi-

tion and angle may be changed.

• Do not remove, disassemble or

modify the camera.

• When washing the camera,

rinse it with a large quantity of

water and then wipe it clean

with a soft cloth dampened with

water. Do not strongly rub the

camera lens, as it may be

scratched and will not be able to

transmit a clear image.

• Do not allow organic solvent,

car wax, window cleaner or

glass coat to adhere to the cam-

era cover. If this happens, wipe

it off as soon as possible.

• Do not apply hot water to the

camera in cold weather, as the

sudden change of temperature

may cause the camera to not

operate properly.

151

3-4. Adjusting the steering wheel and mirrors

Before

driving

If you notice any of the following symptoms, refer to the following

table for the likely cause and the solution.
If the symptom is not resolved by the solution, have the vehicle

inspected by your Toyota dealer.

NOTICE

• When using a high pressure

washer to wash the vehicle, do

not directly spray the camera

and its surrounding area, as

doing so may cause the camera

to not operate properly.

●

Do not subject the camera to a

strong impact as this could

cause a malfunction.

If this happens, have the vehicle

inspected by your Toyota dealer

as soon as possible.

If you notice any symptoms

Symptom

Likely cause

Solution

The image is difficult to

see.

The mirror surface is

dirty.

Clean the mirror surface

gently, using a soft dry

cloth.

Sunlight or headlights

are shining directly into

the Digital Rear-view

Mirror.

Change to optical mirror

mode.

(If the light is coming

through, close the sun-

shade [if equipped].)

152

3-4. Adjusting the steering wheel and mirrors

The image is difficult to
see.

• The vehicle is in a dark

area.

• The vehicle is near a

TV tower, broadcast-
ing station, electric
power plant, or other
location where strong
radio waves or electri-
cal noise may be pres-
ent.

• The temperature

around the camera is
extremely high/low.

• The ambient tempera-

ture is extremely low.

• It is raining or humid.
• Sunlight or headlights

are shining directly into
the camera lens.

• The vehicle is under

fluorescent lights,
sodium lights, mer-
cury lights, etc.

• Exhaust gas is

obstructing the cam-
era.

Change to optical mirror
mode.
(Change back to digital
mirror mode when the
conditions have
improved.)

Foreign matters such as
water droplets or dust is
on the camera lens.

• Operate the dedicated

camera cleaning
washer and clean the
camera lens.
(



P.205)

• Change to optical mir-

ror mode.

The image is out of
alignment.

The back door is not fully
closed.

Fully close the back
door.

The camera or its sur-
rounding area has
received a strong
impact.

Change to optical mirror
mode and have the vehi-
cle inspected by your
Toyota dealer.

Symptom

Likely cause

Solution

153

3-4. Adjusting the steering wheel and mirrors

Before driving

The display is dim and

is displayed.

The system may be mal-
functioning.

Change to optical mirror
mode and have the vehi-
cle inspected by your
Toyota dealer.

goes off.

is displayed.

The Digital Rear-view
Mirror is extremely hot.
(The display will gradu-
ally become more dim. If
the temperature contin-
ues to increase, the Digi-
tal Rear-view Mirror will
turn off.)

Reducing the cabin tem-
perature is recom-
mended to reduce the
temperature of the mir-
ror.

(

will disappear when

the mirror becomes
cool.)

does not disap-

pear even though the
mirror is cool, have the
vehicle inspected by
your Toyota dealer.

The lever cannot be
operated properly.

The lever may be mal-
functioning.

Change to optical mirror
mode and have the vehi-
cle inspected by your
Toyota dealer.
(To change to optical
mirror mode, press and
hold the menu button for
approximately 10 sec-
onds.)

Symptom

Likely cause

Solution

154

3-4. Adjusting the steering wheel and mirrors

■

When using the outside rear

view mirrors in a cold weather

When it is cold and the outside rear

view mirrors are frozen, it may not

be possible to fold/extend them or

adjust the mirror surface. Remove

the ice, snow, etc. covering the out-

side rear view mirrors.

■

Defogging the mirrors (if

equipped)

The outside rear view mirrors can

be cleared using the mirror defog-

gers. Turn on the rear window

defogger to turn on the outside rear

view mirror defoggers.

(



P.360)

To select a mirror to adjust,

turn the switch.

Left
Right

To adjust the mirror, operate

the switch.

Up
Right
Down
Left

Outside rear view mir-

rors

The rear view mirror’s posi-

tion can be adjusted to

enable sufficient confirma-

tion of the rear view.

WARNING

■

Important points while driving

Observe the following precautions

while driving.

Failing to do so may result in loss

of control of the vehicle and cause

an accident, resulting in death or

serious injury.

●

Do not adjust the mirrors while

driving.

●

Do not drive with the mirrors

folded.

●

Both the driver and passenger

side mirrors must be extended

and properly adjusted before

driving.

■

When the mirror defoggers

are operating (if equipped)

Do not touch the rear view mirror

surfaces, as they can become

very hot and burn you.

Adjustment procedure

156

3-5. Opening, closing the windows

3-5.Opening, closing the windows

The power windows can be
opened and closed using the
switches.

Operating the switch moves the
side windows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the side window partway,

operate the switch in the opposite
direction.

■

The power windows can be
operated when

The power switch is in ON.

■

Operating the power windows
after turning the hybrid system
off

The power windows can be oper-
ated for approximately 45 seconds
even after the power switch is
turned to ACC or OFF. They cannot,
however, be operated once either
front door is opened.

■

Jam protection function

If an object becomes jammed

between the side window and the
window frame while the side window
is closing, side window movement is
stopped and the side window is
opened slightly.

■

Catch protection function

If an object becomes caught
between the door and side window
while the side window is opening,
side window movement is stopped.

■

When the power window cannot
be opened or closed

When the jam protection function or
catch protection function operates
unusually and the side window can-
not be opened and closed, perform
the following operations with the
power window switch of that door.

●

Stop the vehicle. With the power
switch in ON, within 4 seconds of
the jam protection function or
catch protection function activat-
ing, continuously operate the
power window switch in the one-
touch closing direction or one-
touch opening direction so that the
side window can be opened and
closed.

●

If the side window cannot be
opened and closed even when
performing the above operations,
perform the following procedure
for function initialization.

Turn the power switch to ON.

Pull and hold the power window
switch in the one-touch closing
direction and completely close
the side window.

Release the power window
switch for a moment, resume
pulling the switch in the one-
touch closing direction, and hold
it there for approximately 6 sec-
onds or more.

Press and hold the power win-
dow switch in the one-touch
opening direction. After the side
window is completely opened,
continue holding the switch for
an additional 1 second or more.

Power windows

Opening and closing the
power windows

157

3-5. Opening, closing the windows

Before

driving

Release the power window

switch for a moment, resume

pushing the switch in the one-

touch opening direction, and

hold it there for approximately 4

seconds or more.

Pull and hold the power window

switch in the one-touch closing

direction again. After the side

window is completely closed,

continue holding the switch for a

further 1 second or more.

If you release the switch while the

side window is moving, start again

from the beginning.

If the side window reverses and

cannot be fully closed or opened,

have the vehicle inspected by your

Toyota dealer.

■

Door lock linked power window

operation

●

The power windows can be

opened and closed using the

mechanical key.

(



P.506)

●

The power windows can be

opened using the wireless remote

control.

(



P.113)

: These settings must be custom-

ized at your Toyota dealer.

■

Power window open reminder

function

A message is shown on the multi-

information display when the power

switch is turned to OFF and the

driver’s door is opened with the

power windows open.

■

Customization

Settings (e.g. linked door lock oper-

ation) can be changed. (Customiz-

able features:



P.546)

WARNING

Observe the following precau-

tions.

Failing to do so may result in

death or serious injury.

■

Closing the power windows

●

The driver is responsible for all

the power window operations,

including the operation for the

passengers. In order to prevent

accidental operation, especially

by a child, do not let a child

operate the power windows. It is

possible for children and other

passengers to have body parts

caught in the power window.

Also, when riding with a child, it

is recommended to use the win-

dow lock switch. (



P.158)

●

Check to make sure that all pas-

sengers do not have any part of

their body in a position where it

could be caught when a power

window is being operated.

●

When using the wireless remote

control or mechanical key and

operating the power windows,

operate the power window after

checking to make sure that

there is no possibility of any

passenger having any of their

body parts caught in the side

window. Also, do not let a child

operate the power window by

the wireless remote control or

mechanical key. It is possible

for children and other passen-

gers to get caught in the power

window.

●

When exiting the vehicle, turn

the power switch to OFF, carry

the key and exit the vehicle

along with the child. There may

be accidental operation, due to

mischief, etc., that may possibly

lead to an accident.

158

3-5. Opening, closing the windows

This function can be used to

prevent children from acciden-

tally opening or closing a pas-

senger window.
Press the switch.

The indicator

will come on and

the passenger windows will be

locked.
The passenger windows can still be

opened and closed using the

driver’s switch even if the lock

switch is on.

■

The window lock switch can be

operated when

The power switch is in ON.

■

When the 12-volt battery is dis-

connected

The window lock switch is disabled.

If necessary, press the window lock

switch after reconnecting the 12-volt

battery.

WARNING

■

Jam protection function

●

Never use any part of your body

to intentionally activate the jam

protection function.

●

The jam protection function may

not work if something gets

jammed just before the side

window is fully closed. Be care-

ful not to get any part of your

body jammed in the side win-

dow.

■

Catch protection function

●

Never use any part of your body

or clothing to intentionally acti-

vate the catch protection func-

tion.

●

The catch protection function

may not work if something gets

caught just before the side win-

dow is fully opened. Be careful

not to get any part of your body

or clothing caught in the side

window.

Preventing accidental

operation (window lock

switch)

159

3-6. Favorite settings

Before driving

3-6.Favorite settings

: If equipped

When all of the following have
been performed, the driver’s
seat is automatically adjusted to
a position that allows driver to
enter and exit the vehicle easily.



The shift position has been
shifted to P.



The power switch has been
turned to OFF.



The driver’s seat belt has
been unfastened.

When any of the following has
been performed, the driver’s
seat automatically returns to its
original position.



The power switch has been
turned to ACC or ON.



The driver’s seat belt has
been fastened.

■

Operation of the power easy
access system

●

When exiting the vehicle, the
power easy access system may
not operate if the seat is already
close to the rearmost position, etc.

●

If the seat position is adjusted

Driving position mem-

ory

This feature automatically
adjusts the positions of the
driver’s seat to make enter-
ing and exiting the vehicle
easier or to suit your prefer-
ences.

When My Settings is turned
on:

Driving positions for the
registered drivers (3 pat-
terns) and guest (1 pattern)
can be registered in My Set-
tings.

When electronic key assign-
ment is registered for My
Settings, the driving posi-
tion for each driver can be
recalled (memory recall
function).

When My Settings is turned
off:

Up to 2 different driving
positions can be recorded.

Each electronic key can be
registered to recall your pre-
ferred driving position
(memory recall function).

For details about My Set-
tings, refer to P.163.

Enabling easier driver
entry and exit (power easy
access system)

160

3-6. Favorite settings

during power easy access system
operation, the automatic operation
will stop. (The seat will change to
manual operation.)

●

If the seat position is adjusted
during or after the power easy
access system operation when
the driver is exiting the vehicle, the
power easy access system will not
operate when entering the vehi-
cle.

■

Jam protection function

If a person or object interferes while
the seat is moving automatically, the
operation will stop.

■

Customization

The seat movement amount set-
tings of the power easy access sys-
tem can be customized.
(Customizable features:



P.540)

■

Recording procedure

Check that the shift position
is in P.

Turn the power switch to ON.

Adjust the driver’s seat to the
desired positions.

While pressing the “SET” but-
ton, or within 3 seconds after
the “SET” button is pressed,
press button “1” or “2” until
the buzzer sounds.

If the selected button has already
been preset, the previously
recorded position will be overwrit-

ten.

■

Recall procedure

Check that the shift position
is in P.

Turn the power switch to ON.

Press one of the buttons for
the driving position you want
to recall until the buzzer
sounds.

■

To stop the position recall oper-
ation part-way through

Perform any of the following:

●

Press the “SET” button.

●

Press button “1” or “2”.

●

Operate any of the seat adjust-
ment switches.

■

Jam protection function

If a person or object interferes while
the seat is moving automatically, the
operation will stop.

Recording/recalling a
driving position

Toyota Prius (2024 year). Manual in english - page 5
