Toyota Corolla (2024 year). Manual in english

353

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Low fuel level warning light

■

Driver’s and front passenger’s seat belt reminder light (warn-
ing buzzer)

: Driver’s seat belt warning buzzer:

The driver’s seat belt warning buzzer sounds to alert the driver that his or
her seat belt is not fastened. Once the engine switch is turned to ON, the
buzzer sounds. If the seat belt is still unfastened, the buzzer sounds inter-
mittently for a certain period of time after the vehicle reaches a certain
speed.

Front passenger’s seat belt warning buzzer:

The front passenger’s seat belt warning buzzer sounds to alert the front
passenger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time after the
vehicle reaches a certain speed.

Warning light

Details/Actions

Vehicles without 18-inch tires:
Indicates that remaining fuel is approximately 1.9 gal. (7.1
L, 1.6 Imp. gal.) or less

Vehicles with 18-inch tires:
Indicates that remaining fuel is approximately 2 gal. (7.5 L,
1.6 Imp. gal.) or less



Refuel the vehicle.

Warning light

Details/Actions

Warns the driver and/or front passenger to fasten their seat
belts



Fasten the seat belt.
If the front passenger’s seat is occupied, the front
passenger’s seat belt also needs to be fastened to
make the warning light (warning buzzer) turn off.

354

7-2. Steps to take in an emergency

■

Rear passengers’ seat belt reminder lights (warning buzzer)

: Rear passengers’ seat belt warning buzzer:

The rear passengers’ seat belt warning buzzer sounds to alert the rear pas-
senger that his or her seat belt is not fastened. If the seat belt is unfas-
tened, the buzzer sounds intermittently for a certain period of time, after the
seat belt is fastened and unfastened and the vehicle reaches a certain
speed.

■

Tire pressure warning light

Warning light

Details/Actions

(4.2-inch dis-

play)

(7-inch display)

Warns the rear passengers to fasten their seat belts



Fasten the seat belt.

Warning light

Details/Actions

(if equipped)

When the light comes on after blinking for approximately 1
minute (a buzzer does not sounds):

Malfunction in the tire pressure warning system



Have the system checked by your Toyota dealer.

When the light comes on (a buzzer sounds):

Low tire inflation pressure from natural causes



After the temperature of the tires has lowered suffi-
ciently, check the inflation pressure of each tire and
adjust them to the specified level. (



P.322)

Low tire inflation pressure from flat tire



Immediately stop the vehicle in a safe place and per-
form the necessary actions. (



P.358)

355

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

PCS warning light (warning buzzer)

■

LTA indicator (warning buzzer)

■

LDA indicator (warning buzzer)

■

PDA indicator (warning buzzer)

■

Dynamic radar cruise control indicator (warning buzzer)

Warning light

Details/Actions

Indicates a malfunction in the PCS (Pre-Collision System).



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

If the PCS (Pre-Collision System) or VSC (Vehicle Stability
Control) system is disabled, the PCS warning light will illu-
minate.



P.189

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LTA (Lane Tracing Assist).



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the LDA (Lane Departure Alert).



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the PDA (Proactive Driving
Assist).



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the dynamic radar cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

356

7-2. Steps to take in an emergency

■

Cruise control indicator (warning buzzer)

■

Driving assist information indicator

: If equipped

■

Slip indicator

Warning light

Details/Actions

(Orange)

Indicates a malfunction in the cruise control.



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

Warning light

Details/Actions

Indicates either of the following systems may be malfunc-
tioning.



PCS (Pre-Collision System)



LDA (Lane Departure Alert)



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

Indicates one of the following systems is malfunctioning or
disabled.



BSM (Blind Spot Monitor)



RCTA(Rear cross traffic alert)



SEA (Safe Exit Assist)



Follow the instructions displayed on the multi-infor-
mation display. (



P.360)

Warning light

Details/Actions

Indicates a malfunction in:



The VSC system;



The TRAC system; or



The hill-start assist control system



Have the vehicle inspected by your Toyota dealer
immediately.

357

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

■

Parking brake indicator

■

Brake hold operated indicator

■

Warning buzzer

In some cases, the buzzer may not
be heard due to being in a noisy
location or audio sound.

■

Front passenger detection sen-
sor, seat belt reminder and
warning buzzer

●

If luggage is placed on the front
passenger seat, the front passen-
ger detection sensor may cause
the warning light to flash and the
warning buzzer to sound even if a
passenger is not sitting in the
seat.

●

If a cushion is placed on the seat,
the sensor may not detect a pas-
senger, and the warning light may
not operate properly.

■

Operation of rear passengers’
seat belt reminder lights

●

The rear passengers’ seat belt
reminder lights will illuminate for
approximately 60 seconds after
either rear door has been opened
and closed.

●

If any rear seat belt is fastened
and then unfastened, the corre-
sponding light for that seat will illu-
minate continuously. If either rear
door is opened and closed while a
rear passengers’ seat belt light is
illuminated, it will turn off approxi-
mately 60 seconds after the door
is closed.

■

SRS warning light

This warning light system monitors
the airbag sensor assembly, front
impact sensors, side impact sensors
(front door), side impact sensors
(front), driver’s seat position sensor,
driver’s seat belt buckle switch, front
passenger seat belt buckle switch,
“AIR BAG ON” indicator light, “AIR
BAG OFF” indicator light, seat belt
pretensioners, airbags, intercon-
necting wiring and power sources.
(



P.32)

■

Electric power steering system
warning light (warning buzzer)

When the battery charge becomes
insufficient or the voltage temporar-
ily drops, the electric power steering

Warning light

Details/Actions

(Flashes)

(U.S.A.)

(Flashes)
(Canada)

It is possible that the parking brake is not fully engaged or
released



Operate the parking brake switch once again.

This light comes on the parking brake is not released. If the
light turns off after the parking brakes is fully released, the
system is operating normally.

Warning light

Details/Actions

(Flashes)

Indicates a malfunction in the brake hold system



Have the vehicle inspected by your Toyota dealer
immediately.

358

7-2. Steps to take in an emergency

system warning light may come on

and the warning buzzer may sound.

■

When the tire pressure warning

light comes on (vehicles with a

tire pressure warning system)

Inspect the tires to check if a tire is

punctured.
If a tire is punctured:



P.364

If none of the tires are punctured:

Turn the engine switch off then turn

it to ON. Check if the tire pressure

warning light comes on or blinks.



If the tire pressure warning light

blinks for approximately 1 minute

then stays on

There may be a malfunction in the

tire pressure warning system. Have

the vehicle inspected by your Toyota

dealer immediately.



If the tire pressure warning light

comes on

After the temperature of the tires

has lowered sufficiently, check

the inflation pressure of each tire

and adjust them to the specified

level.

If the warning light does not turn

off even after several minutes

have elapsed, check that the

inflation pressure of each tire is

at the specified level and perform

initialization. (



P.313)

■

The tire pressure warning light

may come on due to natural

causes (vehicles with a tire

pressure warning system)

The tire pressure warning light may

come on due to natural causes such

as natural air leaks and tire inflation

pressure changes caused by tem-

perature. In this case, adjusting the

tire inflation pressure will turn off the

warning light (after a few minutes).

■

When a tire is replaced with a

spare tire (vehicles with a tire

pressure warning system)

The compact spare tire is not

equipped with a tire pressure warn-

ing valve and transmitter. If a tire

goes flat, the tire pressure warning

light will not turn off even though the

flat tire has been replaced with the

spare tire. Replace the spare tire

with the repaired tire and adjust the

tire inflation pressure. The tire pres-

sure warning light will go off after a

few minutes.

■

Conditions that the tire pres-

sure warning system may not

function properly (vehicles with

a tire pressure warning system)



P.309

WARNING

■

If both the ABS and the brake

system warning lights remain

Stop your vehicle in a safe place

immediately and contact your Toy-

ota dealer.

The vehicle will become

extremely unstable during brak-

ing, and the ABS system may fail,

which could cause an accident

resulting in death or serious injury.

■

When the electric power

steering system warning light

comes on

When the light comes on yellow,

the assist to the power steering is

restricted. When the light comes

on red, the assist to the power

steering is lost and handling oper-

ations of the steering wheel

become extremely heavy.

When steering wheel operations

are heavier than usual, grip the

steering wheel firmly and operate

it using more force than usual.

■

If the tire pressure warning

light comes on (vehicles with

a tire pressure warning sys-

tem)

Be sure to observe the following

precautions.

Failure to do so could cause a

loss of vehicle control and result

in death or serious injury.

359

7-2. Steps to take in an emergency

Whe

trouble

ises

WARNING

●

Stop your vehicle in a safe place

as soon as possible. Adjust the

tire inflation pressure immedi-

ately.

●

If the tire pressure warning light

comes on even after tire infla-

tion pressure adjustment, it is

probable that you have a flat

tire. Check the tires. If a tire is

flat, change it with the spare tire

and have the flat tire repaired by

the nearest Toyota dealer.

●

Avoid abrupt maneuvering and

braking.

If the vehicle tires deteriorate,

you could lose control of the

steering wheel or the brakes.

■

If a blowout or sudden air

leakage should occur (vehi-

cles with a tire pressure warn-

ing system)

The tire pressure warning system

may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if

provided), should be checked

monthly when cold and inflated to

the inflation pressure recom-

mended by the vehicle manufac-

turer on the vehicle placard or tire

inflation pressure label (tire and

load information label). (If your

vehicle has tires of a different size

than the size indicated on the

vehicle placard or tire inflation

pressure label [tire and load infor-

mation label], you should deter-

mine the proper tire inflation

pressure for those tires.)

As an added safety feature, your

vehicle has been equipped with a

tire pressure monitoring system

(TPMS-tire pressure warning sys-

tem) that illuminates a low tire

pressure telltale (tire pressure

warning light) when one or more

of your tires is significantly

under-inflated. Accordingly, when

the low tire pressure telltale (tire

pressure warning light) illumi-

nates, you should stop and check

your tires as soon as possible,

and inflate them to the proper

pressure. Driving on a signifi-

cantly under-inflated tire causes

the tire to overheat and can lead

to tire failure. Under-inflation also

reduces fuel efficiency and tire

tread life, and may affect the vehi-

cle’s handling and stopping ability.
Please note that the TPMS (tire

pressure warning system) is not a

substitute for proper tire mainte-

nance, and it is the driver’s

responsibility to maintain correct

tire pressure, even if under-infla-

tion has not reached the level to

trigger illumination of the TPMS

low tire pressure telltale (tire pres-

sure warning light).
Your vehicle has also been

equipped with a TPMS (tire pres-

sure warning system) malfunc-

tion indicator to indicate when the

system is not operating properly.

The TPMS (tire pressure warning

system) malfunction indicator is

combined with the low tire pres-

sure telltale (tire pressure warning

light). When the system detects a

malfunction, the telltale will flash

for approximately one minute and

then remain continuously illumi-

nated. This sequence will con-

tinue upon subsequent vehicle

start-ups as long as the malfunc-

tion exists. When the malfunction

indicator is illuminated, the sys-

tem may not be able to detect or

signal low tire pressure as

intended.

360

7-2. Steps to take in an emergency

■

Warning messages

The warning messages explained

below may differ from the actual

messages according to operation

conditions and vehicle specifica-

tions.

■

Warning buzzer

A buzzer may sound when a mes-

sage is displayed.

The buzzer may not be audible if the

vehicle is in a noisy location or if the

audio system volume is high.

■

If “Engine Oil Level Low Add or

Replace” is displayed

The engine oil level is low. Check

WARNING

TPMS (tire pressure warning sys-

tem) malfunctions may occur for a

variety of reasons, including the

installation of replacement or

alternate tires or wheels on the

vehicle that prevent the TPMS

(tire pressure warning system)

from functioning properly. Always

check the TPMS (tire pressure

warning system) malfunction tell-

tale after replacing one or more

tires or wheels on your vehicle to

ensure that the replacement or

alternate tires and wheels allow

the TPMS (tire pressure warning

system) to continue to function

properly.

NOTICE

■

To ensure the tire pressure

warning system operates

properly (vehicles with a tire

pressure warning system)

Do not install tires with different

specifications or makers, as the

tire pressure warning system may

not operate properly.

If a warning message

is displayed

The multi-information dis-

play shows warnings for

system malfunctions and

incorrectly performed oper-

ations, and messages that

indicate a need for mainte-

nance. When a message is

displayed, perform the

appropriate corrective

action for the message.
If a warning message is dis-

played again after the

appropriate actions have

been performed, contact

your Toyota dealer.
Additionally, if a warning

light comes on or flashes at

the same time that a warn-

ing message is displayed,

take the appropriate correc-

tive action for the warning

light. (



P.350)

361

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

the level of the engine oil, and add if
necessary. (



P.300)

■

If “Engine Stopped Steering
Power Low” is displayed

This message is displayed if the
engine is stopped while driving.

When steering wheel operations are
heavier than usual, grip the steering
wheel firmly and operate it using
more force than usual.

■

If “Auto Power OFF to Conserve
Battery” is displayed

Power was cut off due to the auto-
matic power off function. Next time
when starting the engine, increase
the engine speed slightly and main-
tain that level for approximately 5
minutes to recharge the battery.

■

If “Headlight System Malfunc-
tion Visit Your Dealer” is dis-
played

The following systems may be mal-
functioning. Have the vehicle
inspected by your Toyota dealer
immediately.

●

The LED headlight system

●

AHB (Automatic High Beam)

■

If “System Malfunction Visit
Your Dealer” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

SEA (Safe Exit Assist) (if

equipped)

Have the vehicle inspected by your
Toyota dealer immediately.

■

If “System Stopped See
Owner’s Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

●

BSM (Blind Spot Monitor) (if

equipped)

●

RCTA (Rear Cross Traffic

Alert) (if equipped)

●

SEA (Safe Exit Assist) (if

equipped)

Follow the following correction
methods.

• Check the voltage of the battery

• Check the sensors that the Toyota

Safety Sense 3.0 uses for foreign
matter covering them. Remove
them if any. (



P.179)

Indicates the sensors may not be
operating properly. (



P.182)

When problems are solved and the
sensors are operational, this indica-
tion may disappear by itself.

■

If “System Stopped Front Cam-
era Low Visibility See Owner’s
Manual” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

362

7-2. Steps to take in an emergency

equipped)

Follow the following correction
methods.

• Using the windshield wipers,

remove the dirt or foreign matter
from the windshield.

• Using the air conditioning system,

defog the windshield.

• Close the hood, remove any stick-

ers,etc. to clear the obstruction in
front of the front camera.

■

If “System Stopped Front Cam-
era Out of Temperature Range
Wait until Normal Temperature”
is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

●

RSA (Road Sign Assist) (if

equipped)

Follow the following correction
methods.

• If the front camera is hot, such as

after the vehicle is parked in the
sun, use the air conditioning sys-
tem to decrease the temperature
around the front camera

• If a sunshade was used when the

vehicle was parked, depending on
its type, the sunlight reflected from
the surface of the sunshade may
cause the temperature of the front
camera to become excessively
high

• If the front camera is cold, such

after the vehicle is parked in an
extremely cold environment, use
the air conditioning system to
increase the temperature around
the front camera

■

If “System Stopped Front Radar
Sensor Blocked Clean Radar
Sensor” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction
methods.

• Check if there is any foreign mat-

ter attached to the radar sensor or
radar sensor cover and clean
them if necessary (



P.180)

• This message may be displayed

when driving in an open area with
few nearby vehicles or structures,
such as a desert, grasslands, sub-
urbs, etc.

The message may be cleared by
driving the vehicle in an area with
structures, vehicles, etc., nearby.

■

If “System Stopped Front Radar
Sensor Out of Temperature
Range Wait until Normal Tem-
perature” is displayed

Indicates one of the following sys-
tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction
methods.

The temperature of the radar sensor
is outside of the operating range.
Wait for the temperature to become
appropriate.

■

If “System Stopped Front Radar
In Self Calibration See Owner’s
Manual” is displayed

Indicates one of the following sys-

363

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

tems is disabled.

●

PCS (Pre-Collision system)

●

LDA (Lane Departure Alert)

●

LTA (Lane Tracing Assist)

●

AHB (Automatic High Beam)

●

Dynamic radar cruise control

Follow the following correction
methods.

• Check if there is any foreign mat-

ter attached to the radar sensor or
radar sensor cover and clean
them if necessary (



P.180)

• The radar sensor may be mis-

aligned and will be adjusted auto-
matically while driving. Continue
driving for a while.

■

If “Cruise Control Unavailable
See Owner’s Manual” is dis-
played

Indicates one of the following sys-
tems is disabled.

●

Dynamic radar cruise control

●

Cruise control

A message is displayed when the
driving assist switch is pushed
repeatedly.

Press the driving assist switch
quickly and firmly.

■

If “Maintenance Required
Soon” is displayed

Indicates that all maintenance
according to the driven distance on
the maintenance schedule

should

be performed soon.

Comes on approximately 4500
miles (7200 km) after the message
has been reset. If necessary, per-
form maintenance. Please reset the
message after the maintenance is
performed. (



P.289)

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-
ual Supplement” for the mainte-
nance interval applicable to your
vehicle.

■

If “Maintenance Required Visit
Your Dealer” is displayed

Indicates that all maintenance is
required to correspond to the driven
distance on the maintenance sched-
ule

Comes on approximately 5000
miles (8000 km) after the message
has been reset. (The indicator will
not work properly unless the mes-
sage has been reset.) Perform the
necessary maintenance. Please
reset the message after the mainte-
nance is performed. (



P.289)

: Refer to the separate “Scheduled

Maintenance” or “Owner’s Man-
ual Supplement” for the mainte-
nance interval applicable to your
vehicle.

■

If “Engine Maintenance
Required Visit Your Dealer” is
shown

The engine or an engine component
is malfunctioning. Have the vehicle
inspected by your Toyota dealer
immediately.

■

If a message that indicates the
need for visiting your Toyota
dealer is displayed

The system or part shown on the
multi-information display is malfunc-
tioning. Have the vehicle inspected
by your Toyota dealer immediately.

■

If a message that indicates the
need for referring to Owner’s
Manual is displayed

●

If “Engine Coolant Temp High” is
displayed, follow the instructions
accordingly. (



P.381)

●

If the following message is dis-
played on the multi-information
display, it may indicate a malfunc-
tion. Have the vehicle inspected
by your Toyota dealer immedi-
ately.

• “Smart Key System Malfunction”

●

If any of the following messages
are displayed on the multi-infor-

364

7-2. Steps to take in an emergency

mation display, it may indicate a

malfunction. Immediately stop the

vehicle and contact your Toyota

dealer.

• “Braking Power Low”

• “Charging System Malfunction”

• “Oil Pressure Low”



Stop the vehicle in a safe

place on a hard, flat surface.



Set the parking brake.



Shift the shift lever to P.



Stop the engine.



Turn on the emergency flash-

ers.

NOTICE

■

If “High Power Consumption

Power to Climate Temporar-

ily Limited” is displayed fre-

quently

There is a possible malfunction

relating to the charging system or

the battery may be deteriorating.

Have the vehicle inspected by

your Toyota dealer.

If you have a flat tire

Your vehicle is equipped

with a spare tire. The flat tire

can be replaced with the

spare tire.
For details about tires:



P.305

WARNING

■

If you have a flat tire

Do not continue driving with a flat

tire. Driving even a short distance

with a flat tire can damage the tire

and the wheel beyond repair,

which could result in an accident.

Before jacking up the

vehicle

366

7-2. Steps to take in an emergency



Type B

Jack
Wheel nut wrench
Spare tire
Jack handle

WARNING

■

Using the tire jack

Observe the following precau-

tions. Improper use of the tire jack

may cause the vehicle to sud-

denly fall off the jack, leading to

death or serious injury.

●

Do not use the tire jack for any

purpose other than replacing

tires or installing and removing

tire chains.

●

Only use the tire jack that

comes with this vehicle for

replacing a flat tire. Do not use it

on other vehicles, and do not

use other tire jacks for replacing

tires on this vehicle.

●

Put the jack properly in its jack

point.

●

Do not put any part of your body

under the vehicle while it is sup-

ported by the jack.

●

Do not start the engine or drive

the vehicle while the vehicle is

supported by the jack.

●

Do not raise the vehicle while

someone is inside.

367

7-2. Steps to take in an emergency

Whe

trouble

ises

Remove the deck mat.

Take out the jack.



Type A



Type B

For tightening
For loosening

Remove the deck mat.

(



P.367)

Remove the tool tray.



Type A



Type B

WARNING

●

When raising the vehicle, do not

put an object on or under the

jack.

●

Do not raise the vehicle to a

height greater than that required

to replace the tire.

●

Use a jack stand if it is neces-

sary to get under the vehicle.

●

When lowering the vehicle,

make sure that there is no-one

near the vehicle. If there are

people nearby, warn them

vocally before lowering.

Taking out the jack

Taking out the spare tire

368

7-2. Steps to take in an emergency

Loosen the center fastener

that secures the spare tire.

Chock the tires.

Vehicles with a steel wheel:

Remove the wheel cap (if

equipped) using the wrench.

Insert the wrench into the notch

on the wheel cap.

To protect the wheel cap, place a

rag between the wrench and the

wheel cap.

Slightly loosen the wheel

nuts (one turn).

Turn the tire jack portion

by hand until the center of the

recessed portion of the jack

WARNING

■

When storing the spare tire

Be careful not to catch fingers or

other body parts between the

spare tire and the body of the

vehicle.

Replacing a flat tire

Flat tire

Wheel chock

positions

Front left-hand

side

Behind the rear

right-hand side

tire

Front right-hand

side

Behind the rear

left-hand side tire

Rear left-hand

side

In front of the

front right-hand

side tire

Rear right-hand

side

In front of the

front left-hand

side tire

Flat tire

Wheel chock

positions

369

7-2. Steps to take in an emergency

Whe

trouble

ises

is in contact with the center of

the jack point.

Assemble the jack handle

extension.



Type A



Type B

Raise the vehicle until the tire

is slightly raised off the

ground.

Remove all the wheel nuts

and the tire.

When resting the tire on the

ground, place the tire so that the

wheel design faces up to avoid

scratching the wheel surface.

WARNING

■

Replacing a flat tire

●

Do not touch the disc wheels or

the area around the brakes

immediately after the vehicle

has been driven. After the vehi-

cle has been driven the disc

wheels and the area around the

brakes will be extremely hot.

Touching these areas with

hands, feet or other body parts

while changing a tire, etc. may

result in burns.

370

7-2. Steps to take in an emergency

Remove any dirt or foreign

matter from the wheel con-

tact surface.

If foreign matter is on the wheel

contact surface, the wheel nuts

may loosen while the vehicle is in

motion, causing the tire to come off.

Install the tire and loosely

tighten each wheel nut by

hand by approximately the

same amount.

When replacing a steel wheel with

a steel wheel (including a compact

spare tire), tighten the wheel nuts

until the tapered portion comes

into loose contact with the disc

wheel seat .

When replacing an aluminum wheel

with a steel wheel (including a com-

pact spare tire), tighten the wheel

nuts until the tapered portion

comes into loose contact with the

WARNING

●

Failure to follow these precau-

tions could cause the wheel

nuts to loosen and the tire to fall

off, resulting in death or serious

injury.

• Never use oil or grease on the

wheel bolts or wheel nuts.Oil

and grease may cause the

wheel nuts to be excessively

tightened, leading to bolt or disc

wheel damage. Remove any oil

or grease that has adhered

when installing the wheel nuts.

• After replacing a tire, check the

tightening torque as soon as

possible.

Wheel nut torque: 76 ft•lbf (103

N•m, 10.5 kgf•m)

• Do not attach a heavily dam-

aged wheel ornament, as it may

fly off the wheel while the vehi-

cle is moving.

• When installing a tire, only use

wheel nuts that have been spe-

cifically designed for that wheel.

• If there are any cracks or defor-

mations in the bolt screws, nut

threads or bolt holes of the

wheel, have the vehicle

inspected by your Toyota

dealer.

• When installing the wheel nuts,

be sure to install them with the

tapered ends facing inward.

Installing the spare tire

371

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

disc wheel seat

Lower the vehicle.

Securely tighten the wheel
nuts two or three times in the
order shown in the illustration
using a wheel nut wrench.

Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)

Stow the flat tire, tire jack and
all tools.

■

The compact spare tire

●

The compact spare tire is identi-
fied by the label “TEMPORARY

USE ONLY” on the tire sidewall.
Use the compact spare tire tempo-
rarily, and only in an emergency.

●

Make sure to check the tire infla-
tion pressure of the compact
spare tire. (



P.391)

■

When the compact spare tire is
equipped

The vehicle becomes lower when
driving with the compact spare tire
compared to when driving with stan-
dard tires.

■

After completing the tire
change (vehicles with a tire
pressure warning system)

The tire pressure warning system
must be reset. (



P.313)

■

When using the compact spare
tire (vehicles with a tire pres-
sure warning system)

As the compact spare tire is not
equipped with a tire pressure warn-
ing valve and transmitter, low infla-
tion pressure of the spare tire will
not be indicated by the tire pressure
warning system. Also, if you replace
the compact spare tire after the tire
pressure warning light comes on,
the light remains on.

■

If you have a flat front tire on a
road covered with snow or ice

Install the compact spare tire on one
of the rear wheels of the vehicle.
Perform the following steps and fit
tire chains to the front tires:

Replace a rear tire with the com-
pact spare tire.

Replace the flat front tire with the
tire removed from the rear of the
vehicle.

Fit tire chains to the front tires.

■

When reinstalling the wheel cap
(steel wheels except compact
spare tire)

Align the cutout of the wheel cap
with the valve stem as shown in the
illustration.

372

7-2. Steps to take in an emergency

WARNING

■

When using the compact

spare tire

●

Remember that the compact

spare tire provided is specifi-

cally designed for use with your

vehicle. Do not use your com-

pact spare tire on another vehi-

cle.

●

Do not use more than one com-

pact spare tires simultaneously.

●

Replace the compact spare tire

with a standard tire as soon as

possible.

●

Avoid sudden acceleration,

abrupt steering, sudden brak-

ing and shifting operations that

cause sudden engine braking.

■

When the compact spare tire

is attached

The vehicle speed may not be

correctly detected, and the follow-

ing systems may not operate cor-

rectly:
• ABS & Brake assist
• VSC
• TRAC
• Automatic High Beam
• Dynamic radar cruise control
• EPS
• PCS (Pre-Collision System)
• LDA (Lane Departure Alert)

• LTA (Lane Tracing Assist)
• Tire pressure warning system (if

equipped)

• BSM (if equipped)
• RCTA (if equipped)
• SEA (if equipped)
• Rear view monitor system
• Navigation system (if equipped)

■

Speed limit when using the

compact spare tire

Do not drive at speeds in excess

of 50 mph (80 km/h) when a com-

pact spare tire is installed on the

vehicle.
The compact spare tire is not

designed for driving at high

speeds. Failure to observe this

precaution may lead to an acci-

dent causing death or serious

injury.

■

After using the tools and jack

Before driving, make sure all the

tools and jack are securely in

place in their storage location to

reduce the possibility of personal

injury during a collision or sudden

braking.

NOTICE

■

Be careful when driving over

bumps with the compact

spare tire installed on the

vehicle.

The vehicle becomes lower when

driving with the compact spare tire

compared to when driving with

standard tires. Be careful when

driving over uneven road sur-

faces.

373

7-2. Steps to take in an emergency

Whe

trouble

ises

One of the following may be the

cause of the problem:



There may not be sufficient

fuel in the vehicle’s tank.

Refuel the vehicle.



The engine may be flooded.

Try to restart the engine again

following correct starting pro-

cedures. (



P.148, 149)



There may be a malfunction

in the engine immobilizer sys-

tem. (



P.71)

One of the following may be the

cause of the problem:



The battery may be dis-

charged. (



P.377)

NOTICE

■

Driving with tire chains and

the compact spare tire

Do not fit tire chains to the com-

pact spare tire. Tire chains may

damage the vehicle body and

adversely affect driving perfor-

mance.

■

When replacing the tires

(vehicles with a tire pressure

warning system)

When removing or fitting the

wheels, tires or the tire pressure

warning valve and transmitter,

contact your Toyota dealer as the

tire pressure warning valve and

transmitter may be damaged if not

handled correctly.

■

To avoid damage to the tire

pressure warning valves and

transmitters (vehicles with a

tire pressure warning system)

When a tire is repaired with liquid

sealants, the tire pressure warn-

ing valve and transmitter may not

operate properly. If a liquid seal-

ant is used, contact your Toyota

dealer or other qualified service

shop as soon as possible. Make

sure to replace the tire pressure

warning valve and transmitter

when replacing the tire.

If the engine will not

start

If the engine will not start

even though correct starting

procedures are being fol-

lowed (



P.148, 149), con-

sider each of the following

points:

The engine will not start

even though the starter

motor operates normally.

The starter motor turns

over slowly, the interior

lights and headlights are

dim, or the horn does not

sound or sounds at a low

volume.

374

7-2. Steps to take in an emergency



The battery terminal connec-
tions may be loose or cor-
roded. (



P.303)

The engine starting system may
be malfunctioning due to an
electrical problem such as elec-
tronic key battery depletion or a
blown fuse. However, an interim
measure is available to start the
engine. (



P.374)

One of the following may be the
cause of the problem:



The battery may be dis-
charged. (



P.377)



One or both of the battery ter-
minals may be disconnected.
(



P.303)



Vehicles without a smart key
system: There may be a mal-
function in the steering lock
system.

Contact your Toyota dealer if the
problem cannot be repaired, or if
repair procedures are unknown.

When the engine does not start,
the following steps can be used
as an interim measure to start
the engine if the engine switch is
functioning normally.
Do not use this starting proce-
dure except in case of emer-
gency.

Set the parking brake.
(



P.162)

Check that the shift lever is in
P.

Turn the engine switch to

ACC

Press and hold the engine
switch for about 15 seconds
while depressing the brake
pedal firmly.

Even if the engine can be started
using the above steps, the system
may be malfunctioning. Have the
vehicle inspected by your Toyota
dealer.

: ACC mode can be enabled/dis-

abled on the customize menu.
(



P.406)

The starter motor does
not turn over (vehicles
with a smart key system)

The starter motor does
not turn over, the interior
lights and headlights do
not turn on, or the horn
does not sound.

Emergency start function
(vehicles with a smart key
system)

375

7-2. Steps to take in an emergency

Whe

trouble

ises

■

When the electronic key does

not work properly

●

Make sure that the smart key sys-

tem has not been deactivated in

the customization setting. If it is

off, turn the function on. (Custom-

izable features:



P.406)

●

Check if battery-saving mode is

set. If it is set, cancel the function.

(



P.115)

●

The electronic key function may

be suspended. (



P.101)

If you lose your keys

New genuine keys can be

made by your Toyota dealer

using the other key (vehi-

cles without a smart key

system) or mechanical key

(vehicles with a smart key

system) and the key number

stamped on your key num-

ber plate.
Keep the plate in a safe

place such as your wallet,

not in the vehicle.

NOTICE

■

When an electronic key is lost

(vehicles with a smart key

system)

If the electronic key remains lost,

the risk of vehicle theft increases

significantly. Visit your Toyota

dealer immediately with all

remaining electronic keys that

were provided with your vehicle.

If the electronic key

does not operate prop-

erly (vehicles with a

smart key system)

If communication between

the electronic key and vehi-

cle is interrupted (



P.115)

or the electronic key cannot

be used because the battery

is depleted, the smart key

system and wireless remote

control cannot be used. In

such cases, the doors can

be opened and the engine

can be started by following

the procedure below.

NOTICE

■

In case of a smart key system

malfunction or other

key-related problems

Take your vehicle with all the elec-

tronic keys provided with your

vehicle to your Toyota dealer.

376

7-2. Steps to take in an emergency

Use the mechanical key

(



P.104) in order to perform the

following operations:

Locks all the doors

Unlocks all the doors

Turning the key unlocks the driver’s

door. Turning the key again unlocks

the other doors.

■

Key linked functions

Closes the windows and moon
roof

(turn and hold)

Opens the windows and moon
roof

(turn and hold)

:If equipped

:This setting must be customized

at your Toyota dealer.

Ensure that the shift lever is

in P and depress the brake

pedal.

Touch the electronic key to

the engine switch.

When the electronic key is

detected, a buzzer sounds and the

engine switch will turn to ON.
When the smart key system is

deactivated in customization set-

ting, the engine switch will turn to

ACC.

Firmly depress the brake
pedal and check that

shown on the multi-informa-

tion display.

Locking and unlocking

the doors

WARNING

■

When using the mechanical

key and operating the power

windows or moon roof (if

equipped)

Operate the power window or

moon roof after checking to make

sure that there is no possibility of

any passenger having any of their

body parts caught in the window

or moon roof.

Also, do not allow children to

operate the mechanical key. It is

possible for children and other

passengers to get caught in the

power window or moon roof.

Starting the engine

377

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

Press the engine switch
shortly and firmly.

In the event that the engine still
cannot be started, contact your
Toyota dealer.

■

Stopping the engine

Shift the shift lever to P and press
the engine switch as you normally
do when stopping the engine.

■

Electronic key battery

As the above procedure is a tempo-
rary measure, it is recommended
that the electronic key battery be
replaced immediately when the bat-
tery is depleted. (



P.327)

■

Changing engine switch modes

Release the brake pedal and press
the engine switch in step

above.

The engine does not start and
modes will be changed each time
the switch is pressed. (



P.152)

If the vehicle battery

is discharged

The following procedures
may be used to start the
engine if the vehicle’s bat-
tery is discharged.
You can also call your Toy-
ota dealer or a qualified
repair shop.

378

7-2. Steps to take in an emergency

If you have a set of jumper (or
booster) cables and a second
vehicle with a 12-volt battery,
you can jump start your vehicle
by following the steps below.

Vehicles with an alarm
(



P.72): Confirm that the

electronic key (vehicles with
a smart key system) or key
(vehicles without a smart key
system) is being carried.

When connecting the jumper (or
booster) cables, depending on the
situation, the alarm may activate
and doors locked. (

Open the hood. (

Connect a positive jumper cable clamp to

on your vehicle and

connect the clamp on the other end of the positive cable to

the second vehicle. Then, connect a negative cable clamp to

on the second vehicle and connect the clamp at the other end of

the negative cable to

Use jumper cables that can reach the specified terminals and connecting
point.

Positive (+) battery terminal (your vehicle)

Positive (+) battery terminal (second vehicle)

Negative (-) battery terminal (second vehicle)

Metallic point shown in the illustration

Restarting the engine

379

7-2. Steps to take in an emergency

Whe

n tr

ouble

ises

Start the engine of the sec-
ond vehicle. Increase the
engine speed slightly and
maintain at that level for
approximately 5 minutes to
recharge the battery of your
vehicle.

Vehicles with a smart key
system: Open and close any
of the doors of your vehicle
with the engine switch OFF.

Maintain the engine speed of
the second vehicle and start
the engine of your vehicle by
turning the engine switch to
ON.

Once the vehicle’s engine
has started, remove the
jumper cables in the exact
reverse order from which
they were connected.

Once the engine starts, have the
vehicle inspected at your Toyota
dealer as soon as possible.

■

Starting the engine when the
battery is discharged

The engine cannot be started by
push-starting.

■

To prevent battery discharge

●

Turn off the headlights and the
audio system while the engine is
off.

●

Turn off any unnecessary electri-
cal components when the vehicle
is running at a low speed for an
extended period, such as in heavy
traffic.

■

When the battery is removed or
discharged

●

Information stored in the ECU is

cleared. When the battery is
depleted, have the vehicle
inspected at your Toyota dealer.

●

Some systems may require initial-
ization. (



P.416)

■

When removing the battery ter-
minals

When the battery terminals are
removed, the information stored in
the ECU is cleared. Before remov-
ing the battery terminals, contact
your Toyota dealer.

■

Charging the battery

The electricity stored in the battery
will discharge gradually even when
the vehicle is not in use, due to nat-
ural discharge and the draining
effects of certain electrical appli-
ances. If the vehicle is left for a long
time, the battery may discharge,
and the engine may be unable to
start. (The battery recharges auto-
matically during driving.)

■

When recharging or replacing
the battery (vehicles with a
smart key system)

●

In some cases, it may not be pos-
sible to unlock the doors using the
smart key system when the bat-
tery is discharged. Use the wire-
less remote control or the
mechanical key to lock or unlock
the doors.

●

The engine may not start on the
first attempt after the battery has
recharged but will start normally
after the second attempt. This is
not a malfunction.

●

The engine switch mode is memo-
rized by the vehicle. When the
battery is reconnected, the system
will return to the mode it was in
before the battery was dis-
charged. Before disconnecting the
battery, turn the engine switch off.
If you are unsure what mode the
engine switch was in before the
battery discharged, be especially
careful when reconnecting the
battery.

380

7-2. Steps to take in an emergency

■

When replacing the battery

●

Use a battery that conforms to

European regulations.

●

Use a battery that the case size is

same as the previous one (LN1),

20 hour rate capacity (20HR) is

equivalent (45Ah) or greater, and

performance rating (CCA) is

equivalent (286A or 307A) or

greater.

• If the sizes differ, the battery can-

not be properly secured.

• If the 20 hour rate capacity is low,

even if the time period where the

vehicle is not used is a short time,

the battery may discharge and the

engine may not be able to start.

●

For details, consult your Toyota

dealer.

WARNING

■

When removing the battery

terminals

Always remove the negative (-)

terminal first. If the positive (+) ter-

minal contacts any metal in the

surrounding area when the posi-

tive (+) terminal is removed, a

spark may occur, leading to a fire

in addition to electrical shocks

and death or serious injury.

■

Avoiding battery fires or

explosions

Observe the following precautions

to prevent accidentally igniting the

flammable gas that may be emit-

ted from the battery:

●

Make sure each jumper cable is

connected to the correct termi-

nal and that it is not unintention-

ally in contact with any other

than the intended terminal.

●

Do not allow the other end of

the jumper cable connected to

the “+” terminal to come into

contact with any other parts or

metal surfaces in the area, such

as brackets or unpainted metal.

●

Do not allow the + and - clamps

of the jumper cables to come

into contact with each other.

●

Do not smoke, use matches,

cigarette lighters or allow open

flame near the battery.

■

Battery precautions

The battery contains poisonous

and corrosive acidic electrolyte,

while related parts contain lead

and lead compounds. Observe

the following precautions when

handling the battery:

●

When working with the battery,

always wear safety glasses and

take care not to allow any bat-

tery fluids (acid) to come into

contact with skin, clothing or the

vehicle body.

●

Do not lean over the battery.

●

In the event that battery fluid

comes into contact with the skin

or eyes, immediately wash the

affected area with water and

seek medical attention. Place a

wet sponge or cloth over the

affected area until medical

attention can be received.

●

Always wash your hands after

handling the battery support,

terminals, and other bat-

tery-related parts.

●

Do not allow children near the

battery.

381

7-2. Steps to take in an emergency

Whe

trouble

ises

Stop the vehicle in a safe

place and turn off the air con-

ditioning system, and then

stop the engine.

If you see steam: Carefully lift

the hood after the steam sub-

sides.

If you do not see steam:

Carefully lift the hood.

After the engine has cooled

down sufficiently, inspect the

NOTICE

■

When handling jumper cables

When connecting the jumper

cables, ensure that they do not

become entangled in the cooling

fan or engine drive belt.

■

When connecting jumper

cables

Make sure to connect jumper

cables to the specified terminals

and connecting point. Failure to

do so may adversely affect the

electronic devices or damage to

them.

If your vehicle over-

heats

The following may indicate

that your vehicle is over-

heating.



The engine coolant tem-

perature gauge (



P.80, 83)

is in the red zone or a loss

of engine power is experi-

enced. (For example, the

vehicle speed does not

increase.)



“Engine Coolant Temp High

Stop in a Safe Place See

Owner’s Manual” is shown

on the multi-information dis-

play.



Steam comes out from

under the hood.

Correction procedures

382

7-2. Steps to take in an emergency

hoses and radiator core (radi-

ator) for any leaks.

Radiator
Cooling fan

If a large amount of coolant leaks,

immediately contact your Toyota

dealer.

The coolant level is satisfac-

tory if it is between the “MAX”

and “MIN” lines on the reser-

voir.

Reservoir
“MAX” line
“MIN” line

Add engine coolant if neces-

sary.

Water can be used in an emer-

gency if engine coolant is unavail-

able.

Start the engine and turn the

air conditioning system on to

check that the radiator cool-

ing fan operates and to check

for coolant leaks from the

radiator or hoses.

The fan operates when the air con-

ditioning system is turned on imme-

diately after a cold start. Confirm

that the fan is operating by check-

ing the fan sound and air flow. If it is

difficult to check these, turn the air

conditioning system on and off

repeatedly. (The fan may not oper-

ate in freezing temperatures.)

If the fan is not operating:

Stop the engine immediately

and contact your Toyota

dealer.

If the fan is operating: Have

the vehicle inspected at the

nearest Toyota dealer.

WARNING

■

When inspecting under the

hood of your vehicle

Observe the following precau-

tions. Failure to do so may result

in serious injury such as burns.

383

7-2. Steps to take in an emergency

Whe

trouble

ises

Stop the engine. Set the

parking brake and shift the

shift lever to P.

Do not press the shift release but-

ton after shifting the shift lever to P.

Remove the mud, snow or

sand from around the front

wheels.

Place wood, stones or some

other material under the front

wheels to help provide trac-

tion.

Restart the engine.

Shift the shift lever to D or R

and release the parking

brake. Then, while exercising

caution, depress the acceler-

ator pedal.

■

When it is difficult to free the

vehicle

Press the

switch to turn off

TRAC.

WARNING

●

If steam is seen coming from

under the hood, do not open the

hood until the steam has sub-

sided. The engine compart-

ment may be very hot.

●

Keep hands and clothing (espe-

cially a tie, a scarf or a muffler)

away from the fan and belts.

Failure to do so may cause the

hands or clothing to be caught,

resulting in serious injury.

●

Do not loosen the coolant reser-

voir cap while the engine and

radiator are hot.

High temperature steam or

coolant could spray out.

NOTICE

■

When adding engine coolant

Add coolant slowly after the

engine has cooled down suffi-

ciently. Adding cool coolant to a

hot engine too quickly can cause

damage to the engine.

■

To prevent damage to the

cooling system

Observe the following precau-

tions:

●

Avoid contaminating the coolant

with foreign matter (such as

sand or dust etc.).

●

Do not use any coolant additive.

If the vehicle becomes

stuck

Carry out the following pro-

cedures if the tires spin or

the vehicle becomes stuck

in mud, dirt or snow:

Recovering procedure

384

7-2. Steps to take in an emergency



Type A



Type B

WARNING

■

When attempting to free a

stuck vehicle

If you choose to push the vehicle

back and forth to free it, make

sure the surrounding area is clear

to avoid striking other vehicles,

objects or people. The vehicle

may also lunge forward or lunge

back suddenly as it becomes free.

Use extreme caution.

■

When shifting the shift lever

Be careful not to shift the shift

lever with the accelerator pedal

depressed.

This may lead to unexpected

rapid acceleration of the vehicle

that may cause an accident

resulting in death or serious injury.

NOTICE

■

To avoid damaging the trans-

mission and other compo-

nents

●

Avoid spinning the front wheels

and depressing the accelerator

pedal more than necessary.

●

If the vehicle remains stuck

even after these procedures are

performed, the vehicle may

require towing to be freed.

Toyota Corolla (2024 year). Manual in english - page 12
