Toyota Corolla (2024 year). Manual in english

385

Vehicle

specificatio

Vehicle specifications

8-1. Specifications

Maintenance data (fuel, oil

level, etc.)..................

386

Fuel information ..........

393

Tire information ...........

395

8-2. Customization

Customizable features

..................................

406

8-3. Initialization

Items to initialize .........

416

386

8-1. Specifications

8-1.Specifications

: Unladen vehicles

: Vehicles without 18-inch tires

: Vehicles with 18-inch tires for Guam and Saipan

: Vehicles with 18-inch tires except for Guam and Saipan

: For Guam and Saipan

■

Vehicle identification num-
ber

The vehicle identification num-
ber (VIN) is the legal identifier
for your vehicle. This is the pri-

mary identification number for
your Toyota. It is used in regis-
tering the ownership of your
vehicle.

On some models: This number

Maintenance data (fuel, oil level, etc.)

Dimensions and weight

Overall length

182.3 in. (4630 mm)

182.5 in. (4635 mm)

Overall width

70.1 in. (1780 mm)

Overall height

56.5 in. (1435 mm)

57.3 in. (1455 mm)

Wheelbase

106.3 in. (2700 mm)

Tread

Front

60.1 in. (1527 mm)

60.3 in. (1531 mm)

Rear

59.8 in. (1519 mm)

60.1 in. (1526 mm)

60.4 in. (1534 mm)

Vehicle capacity weight
(Occupants + luggage)

860 lb. (390 kg)

Seating capacity

Seating capacity

5 (Front 2, Rear 3)

Vehicle identification

387

8-1. Specifications

Vehicle

specificatio

is stamped under the right-hand
front seat.

This number is also stamped on
the top left of the instrument
panel.

This number is also on the Certi-
fication Label.

■

Engine number

The engine number is stamped
on the engine block as shown.

Engine

Model

2.0 L 4-cylinder (M20A-FKS)

Type

4-cylinder in line, 4-cycle, gasoline

Bore and stroke

3.17



3.84 in. (80.5



97.6 mm)

Displacement

121.3 cu. in. (1987 cm

)

Valve clearance

Automatic adjustment

Drive belt tension Automatic adjustment

Fuel

Fuel type

Unleaded gasoline only

388

8-1. Specifications

■

Oil capacity (Drain and refill

[Reference

])

: The engine oil capacity is a refer-

ence quantity to be used when
changing the engine oil. When
actually adding the engine oil,
make sure that the oil level is
between the low level mark and
refill upper limit mark. (



P.300)

Warm up and turn off the engine,
wait about 5 minutes, and check
the oil level on the dipstick.

■

Engine oil selection

“Toyota Genuine Motor Oil” is
used in your Toyota vehicle. Use
Toyota approved “Toyota Genu-
ine Motor Oil” or equivalent to
satisfy the following grade and
viscosity.

Oil grade: JASO GLV-1

Recommended viscosity: SAE
0W-8

Outside temperature

SAE 0W-8 is the best choice for
good fuel economy and good
starting in cold weather.

If SAE 0W-8 is not available,
SAE 0W-16 oil may be used
However, it must be replaced
with SAE 0W-8 at the next oil
change.

Oil viscosity (0W-8 is explained
here as an example):
• The 0W in 0W-8 indicates the

characteristic of the oil which
allows cold startability. Oils
with a lower value before the
W allow for easier starting of
the engine in cold weather.

• The 8 in 0W-8 indicates the

viscosity characteristic of the
oil when the oil is at high tem-
perature. An oil with a higher
viscosity (one with a higher
value) may be better suited if

Octane Rating

87 (Research Octane Number 91) or
higher

Fuel tank capacity
(Reference)



Vehicles without 18-inch tires

12.4 gal. (47.0 L, 10.3 Imp. gal.)



Vehicles with 18-inch tires

13.2 gal. (50.0 L, 11.0 Imp. gal.)

Lubrication system

With filter

4.4 qt. (4.2 L, 3.7 Imp.
qt.)

Without

filter

4.1 qt. (3.9 L, 3.4 Imp.
qt.)

389

8-1. Specifications

Vehicle

specificatio

the vehicle is operated at high

speeds, or under extreme

load conditions.

How to read oil container label:
The Japanese Automotive Stan-

dards Organization (JASO)

GLV-1 mark is added to some oil

containers to help you select the

oil you should use.

Cooling system

Capacity (Reference)

6.8 qt. (6.4 L, 5.6 Imp. qt.)

Coolant type

Use either of the following:



“Toyota Super Long Life Coolant”



Similar high-quality ethylene glycol-based

non-silicate, non-amine, non-nitrite, and

non-borate coolant with long-life hybrid organic

acid technology

Do not use plain water alone.

Ignition system (spark plug)

Make

DENSO FC20HR-Q8

Gap

0.032 in. (0.8 mm)

NOTICE

■

Iridium-tipped spark plugs

Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.

Electrical system (battery)

Open voltage at 68°F (20°C):

12.3 V or higher

(Turn the engine switch off and turn on the

high beam headlights for 30 seconds.)

Charging rates

5 A max.

390

8-1. Specifications

: The fluid capacity is a reference quantity.

If replacement is necessary, contact your Toyota dealer.

:Minimum pedal clearance when depressed with a force of 67.4 lbf (300

N, 30.6 kgf) while the engine is running.

:Make sure to confirm that the brake system warning light (yellow) does

not illuminate. (If the brake system warning light illuminates, refer to

P.350.)

Continuously variable transmission

Fluid capacity

9.0 qt. (8.5 L, 7.5 Imp. qt.)

Fluid type

Toyota Genuine CVT Fluid FE

NOTICE

■

Continuously variable transmission fluid type

Using continuously variable transmission fluid other than the above type

may cause abnormal noise or vibration, or damage the continuously vari-

able transmission of your vehicle.

Brakes

Pedal clearance

4.1 in. (105 mm) Min.

Pedal free play

0.04



0.24 in. (1



6 mm)

Brake pad wear limit



Front

0.06 in. (1.5 mm)



Rear

0.08 in. (2.0 mm)

Parking brake indicator

When pulling the parking brake switch for

1 to 2 seconds: comes on
When pushing the parking brake switch for

1 to 2 seconds: turns off

Fluid type

FMVSS No.116 DOT 3 or SAE J1703
FMVSS No.116 DOT 4 or SAE J1704

Steering

Free play

Less than 1.2 in. (30 mm)

391

8-1. Specifications

Vehicle

specificatio



Type A



Type B



Type C

Tires and wheels

Tire size

195/65R15 91S, T125/70D17 98M

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front

33 psi (230 kPa, 2.3 kgf/cm

or bar)



Rear

30 psi (210 kPa, 2.1 kgf/cm

or bar)



Spare

60 psi (420 kPa, 4.2 kgf/cm

or bar)

Wheel size



6 1/2J, 17



4T (compact spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

205/55R16 91H, T125/70D17 98M

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front

35 psi (240 kPa, 2.4 kgf/cm

or bar)



Rear

33 psi (230 kPa, 2.3 kgf/cm

or bar)



Spare

60 psi (420 kPa, 4.2 kgf/cm

or bar)

Wheel size



7J, 17



4T (compact spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

225/40R18 88V, T125/70D17 98M

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front

33 psi (230 kPa, 2.3 kgf/cm

or bar)



Rear

30 psi (210 kPa, 2.1 kgf/cm

or bar)



Spare

60 psi (420 kPa, 4.2 kgf/cm

or bar)

392

8-1. Specifications



Type D

A: Wedge base bulbs (clear)

B: Wedge base bulbs (amber)

Wheel size



8J, 17



4T (compact spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Tire size

225/40R18 88W, T125/70D17 98M

Tire inflation pressure
(Recommended cold tire
inflation pressure)



Front

33 psi (230 kPa, 2.3 kgf/cm

or bar)



Rear

30 psi (210 kPa, 2.1 kgf/cm

or bar)



Spare

60 psi (420 kPa, 4.2 kgf/cm

or bar)

Wheel size



8J, 17



4T (compact spare)

Wheel nut torque

76 ft•lbf (103 N•m, 10.5 kgf•m)

Light bulbs

Light bulbs

Bulb No.

Type

Exterior

Front side marker lights (bulb
type)

—

Front turn signal /parking lights
(vehicles without side turn signal
lights)

7444NA

28/8

Rear side marker lights (bulb
type)

—

Rear turn signal lights

—

Back-up lights

—

Interior

Trunk light

—

393

8-1. Specifications

Vehicle

specificatio

■

Gasoline quality

In very few cases, driveability prob-
lems may be caused by the brand of
gasoline you are using. If driveability
problems persist, try changing the
brand of gasoline. If this does not
correct the problem, consult your
Toyota dealer.

■

Recommendation of the use of
gasoline containing detergent
additives

●

Toyota recommends the use of
gasoline that contains detergent
additives to avoid the build-up of
engine deposits.

●

All gasoline sold in the U.S.A. con-
tains minimum detergent additives
to clean and/or keep clean intake
systems, per EPA’s lowest addi-
tives concentration program.

●

Toyota strongly recommends the
use of Top Tier Detergent Gaso-
line. For more information on Top
Tier Detergent Gasoline and a list
of marketers, please go to the offi-
cial website www.toptiergas.com.

■

Recommendation of the use of
low emissions gasoline

Gasolines containing oxygenates
such as ethers and ethanol, as well
as reformulated gasolines, are avail-
able in some cities. These fuels are
typically acceptable for use, provid-
ing they meet other fuel require-
ments.

Toyota recommends these fuels,
since the formulations allow for
reduced vehicle emissions.

■

Non-recommendation of the
use of blended gasoline

●

Use only gasoline containing up to
15% ethanol.
DO NOT use any flex-fuel or gas-
oline that could contain more than
15% ethanol, including from any
pump labeled E30 (30% ethanol
[

]), E50 (50% ethanol [

]), E85

(85% ethanol [

]) (which are only

some examples of fuel containing
more than 15% ethanol).

●

If you use gasohol in your vehicle,
be sure that it has an octane rat-
ing no lower than 87.

●

Toyota does not recommend the
use of gasoline containing metha-
nol.

■

Non-recommendation of the
use of gasoline containing MMT

Some gasoline contains an octane
enhancing additive called MMT
(Methylcyclopentadienyl Manga-
nese Tricarbonyl).

Toyota does not recommend the use
of gasoline that contains MMT. If
fuel containing MMT is used, your
emission control system may be

Fuel information

You must only use unleaded
gasoline.
Select octane rating of 87
(Research Octane Number
91) or higher. Use of
unleaded gasoline with an
octane rating lower than 87
may result in engine knock-
ing. Persistent knocking
can lead to engine damage.

At minimum, the gasoline you
use should meet the specifica-
tions of ASTM D4814 in the
U.S.A.

394

8-1. Specifications

adversely affected.
The malfunction indicator lamp on

the instrument cluster may come on.

If this happens, contact your Toyota

dealer for service.

■

If your engine knocks

●

Consult your Toyota dealer.

●

You may occasionally notice light

knocking for a short time while

accelerating or driving uphill. This

is normal and there is no need for

concern.

NOTICE

■

Notice on fuel quality

●

Do not use improper fuels. If

improper fuels are used, the

engine will be damaged.

●

Do not use leaded gasoline.

Leaded gasoline can cause

damage to your vehicle’s

three-way catalytic converters

causing the emission control

system to malfunction.

●

Do not use gasohol other than

the type previously stated.

Other gasohol may cause fuel

system damage or vehicle per-

formance problems.

●

Using unleaded gasoline with

an octane number or rating

lower than the level previously

stated will cause persistent

heavy knocking.

At worst, this will lead to engine

damage.

■

Fuel-related poor driveability

If poor driveability (poor hot start-

ing, vaporization, engine knock-

ing, etc.) is encountered after

using a different type of fuel, dis-

continue the use of that type of

fuel.

■

When refueling with gasohol

Take care not to spill gasohol. It

can damage your vehicle’s paint.

395

8-1. Specifications

Vehicle

specificatio



Full-size tire

Tire size (



P.397)

DOT and Tire Identification Number (TIN) (



P.397)

Uniform tire quality grading

For details, see “Uniform Tire Quality Grading” that follows.

Location of treadwear indicators (



P.305)

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands
which form the plies in a tire.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a
bias-ply tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A
tube type tire has a tube inside the tire and the tube maintains the air pres-
sure.

Load limit at maximum cold tire inflation pressure (



P.306)

Maximum cold tire inflation pressure (



P.391)

This means the pressure to which a tire may be inflated.

Summer tires or all season tires (



P.306)

Tire information

Typical tire symbols

396

8-1. Specifications

An all season tire has “M+S” on the sidewall. A tire not marked “M+S” is a
summer tire.



Compact spare tire

“TEMPORARY USE ONLY”

A compact spare tire is identified by the phrase “TEMPORARY USE ONLY”
molded on its sidewall. This tire is designed for temporary emergency use
only.

Tire size (



P.397)

DOT and Tire Identification Number (TIN) (



P.397)

Load limit at maximum cold tire inflation pressure (



P.306)

Location of treadwear indicators (



P.305)

Maximum cold tire inflation pressure (



P.391)

This means the pressure to which a tire may be inflated.

Tire ply composition and materials

Plies are layers of rubber-coated parallel cords. Cords are the strands
which form the plies in a tire.

TUBELESS or TUBE TYPE

A tubeless tire does not have a tube and air is directly put into the tire. A
tube type tire has a tube inside the tire and the tube maintains the air pres-
sure.

Radial tires or bias-ply tires

A radial tire has “RADIAL” on the sidewall. A tire not marked “RADIAL” is a
bias-ply tire.

397

8-1. Specifications

Vehicle

specificatio



Type A

DOT symbol

Tire Identification Number
(TIN)

Tire manufacturer’s identifi-
cation mark

Tire size code

Manufacturer’s optional tire
type code (3 or 4 letters)

Manufacturing week

Manufacturing year

: The DOT symbol certifies that the

tire conforms to applicable Fed-
eral Motor Vehicle Safety Stan-
dards.



Type B

DOT symbol

Tire Identification Number
(TIN)

Tire manufacturer’s identifi-
cation mark

Manufacturer’s code

Manufacturing week

Manufacturing year

: The DOT symbol certifies that the

tire conforms to applicable Fed-
eral Motor Vehicle Safety Stan-
dards.

■

Typical tire size information

The illustration indicates typical
tire size.

Tire use (P = Passenger car,
T = Temporary use)

Section width (millimeters)

Aspect ratio (tire height to
section width)

Tire construction code (R =
Radial, D = Diagonal)

Wheel diameter (inches)

Load index (2 digits or 3 dig-
its)

Typical DOT and Tire
Identification Number
(TIN)

Tire size

398

8-1. Specifications

Speed symbol (alphabet with
one letter)

■

Tire dimensions

Section width

Tire height

Wheel diameter

Bead

Sidewall

Shoulder

Tread

Belt

Inner liner

Reinforcing rubber

Carcass

Rim lines

Bead wires

Chafer

This information has been pre-
pared in accordance with regu-
lations issued by the National
Highway Traffic Safety Adminis-
tration of the U.S. Department of
Transportation.

It provides the purchasers
and/or prospective purchasers
of Toyota vehicles with informa-
tion on uniform tire quality grad-
ing.

Your Toyota dealer will help answer
any questions you may have as you
read this information.

■

DOT quality grades

All passenger vehicle tires must
conform to Federal Safety
Requirements in addition to
these grades. Quality grades
can be found where applicable
on the tire sidewall between
tread shoulder and maximum
section width.

For example: Treadwear 200 Trac-
tion AA Temperature A

■

Treadwear

The treadwear grade is a com-
parative rating based on the
wear rate of the tire when tested
under controlled conditions on a
specified government test
course.

For example, a tire graded 150

Tire section names

Uniform Tire Quality
Grading

399

8-1. Specifications

Vehicle

specificatio

would wear one and a half (1 - 1/2)
times as well on the government
course as a tire graded 100.
The relative performance of tires
depends upon the actual conditions
of their use. Performance may differ
significantly from the norm due to
variations in driving habits, service
practices and differences in road
characteristics and climate.

■

Traction AA, A, B, C

The traction grades, from high-
est to lowest, are AA, A, B and
C, and they represent the tire’s
ability to stop on wet pavement
as measured under controlled
conditions on specified govern-
ment test surfaces of asphalt
and concrete.

A tire marked C may have poor
traction performance.

Warning: The traction grade
assigned to this tire is based on
braking (straight ahead) traction
tests and does not include corner-
ing (turning) traction.

■

Temperature A, B, C

The temperature grades are A

(the highest), B, and C, repre-
senting the tire’s resistance to
the generation of heat and its
ability to dissipate heat when
tested under controlled condi-
tions on a specified indoor labo-
ratory test wheel.

Sustained high temperature can
cause the material of the tire to
degenerate and reduce tire life, and
excessive temperature can lead to
sudden tire failure.

Grade C corresponds to a level of
performance which all passenger
car tires must meet under the Fed-
eral Motor Vehicle Safety Standard
No. 109.

Grades B and A represent higher
levels of performance on the labo-
ratory test wheel than the minimum
required by law.

Warning: The temperature grades
of a tire assume that it is properly
inflated and not overloaded.

Excessive speed, underinflation, or
excessive loading, either sepa-
rately or in combination, can cause
heat buildup and possible tire fail-
ure.

Glossary of tire terminology

Tire related term

Meaning

Cold tire inflation pressure

Tire pressure when the vehicle has been
parked for three hours or more, or has not
been driven more than 1 mile or 1.5 km
under that condition

Maximum inflation pressure

The maximum cold inflated pressure to
which a tire may be inflated, shown on the
sidewall of the tire

400

8-1. Specifications

Recommended inflation pres-
sure

Cold tire inflation pressure recommended
by a manufacturer

Accessory weight

The combined weight (in excess of those
standard items which may be replaced) of
automatic transmission, power steering,
power brakes, power windows, power
seats, radio and heater, to the extent that
these items are available as fac-
tory-installed equipment (whether installed
or not)

Curb weight

The weight of a motor vehicle with stan-
dard equipment, including the maximum
capacity of fuel, oil and coolant, and if so
equipped, air conditioning and additional
weight optional engine

Maximum loaded vehicle
weight

The sum of:

(a) Curb weight

(b) Accessory weight

(d) Production options weight

Normal occupant weight

150 lb. (68 kg) times the number of occu-
pants specified in the second column of

Table 1

that follows

Occupant distribution

Distribution of occupants in a vehicle as

specified in the third column of Table 1

below

Production options weight

The combined weight of installed regular
production options weighing over 5 lb. (2.3
kg) in excess of the standard items which
they replace, not previously considered in
curb weight or accessory weight, including
heavy duty brakes, ride levelers, roof rack,
heavy duty battery, and special trim

Rim

A metal support for a tire or a tire and tube
assembly upon which the tire beads are
seated

Tire related term

Meaning

401

8-1. Specifications

Vehicle

specificatio

Rim diameter (Wheel diame-
ter)

Nominal diameter of the bead seat

Rim size designation

Rim diameter and width

Rim type designation

The industry manufacturer’s designation
for a rim by style or code

Rim width

Nominal distance between rim flanges

Vehicle capacity weight (Total
load capacity)

The rated cargo and luggage load plus 150
lb. (68 kg) times the vehicle’s designated
seating capacity

Vehicle maximum load on the
tire

The load on an individual tire that is deter-
mined by distributing to each axle its share
of the maximum loaded vehicle weight,
and dividing by two

Vehicle normal load on the tire

The load on an individual tire that is deter-
mined by distributing to each axle its share
of curb weight, accessory weight, and nor-
mal occupant weight (distributed in accor-

dance with Table 1

below), and dividing by

two

Weather side

The surface area of the rim not covered by
the inflated tire

Bead

The part of the tire that is made of steel
wires, wrapped or reinforced by ply cords
and that is shaped to fit the rim

Bead separation

A breakdown of the bond between compo-
nents in the bead

Bias ply tire

A pneumatic tire in which the ply cords that
extend to the beads are laid at alternate
angles substantially less than 90 degrees
to the centerline of the tread

Carcass

The tire structure, except tread and side-
wall rubber which, when inflated, bears the
load

Chunking

The breaking away of pieces of the tread
or sidewall

Cord

The strands forming the plies in the tire

Tire related term

Meaning

402

8-1. Specifications

Cord separation

The parting of cords from adjacent rubber
compounds

Cracking

Any parting within the tread, sidewall, or
innerliner of the tire extending to cord
material

A pneumatic tire with an inverted flange
tire and rim system in which the rim is
designed with rim flanges pointed radially
inward and the tire is designed to fit on the
underside of the rim in a manner that
encloses the rim flanges inside the air cav-
ity of the tire

Extra load tire

A tire designed to operate at higher loads
and at higher inflation pressures than the
corresponding standard tire

Groove

The space between two adjacent tread ribs

Innerliner

The layer(s) forming the inside surface of a
tubeless tire that contains the inflating
medium within the tire

Innerliner separation

The parting of the innerliner from cord
material in the carcass

Intended outboard sidewall

(a) The sidewall that contains a whitewall,
bears white lettering, or bears manufac-
turer, brand, and/or model name molding
that is higher or deeper than the same
molding on the other sidewall of the tire, or

(b) The outward facing sidewall of an
asymmetrical tire that has a particular side
that must always face outward when
mounted on a vehicle

Light truck (LT) tire

A tire designated by its manufacturer as
primarily intended for use on lightweight
trucks or multipurpose passenger vehicles

Load rating

The maximum load that a tire is rated to
carry for a given inflation pressure

Maximum load rating

The load rating for a tire at the maximum
permissible inflation pressure for that tire

Tire related term

Meaning

403

8-1. Specifications

Vehicle

specificatio

Maximum permissible inflation
pressure

The maximum cold inflation pressure to
which a tire may be inflated

Measuring rim

The rim on which a tire is fitted for physical
dimension requirements

Open splice

Any parting at any junction of tread, side-
wall, or innerliner that extends to cord
material

Outer diameter

The overall diameter of an inflated new tire

Overall width

The linear distance between the exteriors
of the sidewalls of an inflated tire, including
elevations due to labeling, decorations, or
protective bands or ribs

Passenger car tire

A tire intended for use on passenger cars,
multipurpose passenger vehicles, and
trucks, that have a gross vehicle weight
rating (GVWR) of 10,000 lb. or less.

Ply

A layer of rubber-coated parallel cords

Ply separation

A parting of rubber compound between
adjacent plies

Pneumatic tire

A mechanical device made of rubber,
chemicals, fabric and steel or other materi-
als, that, when mounted on an automotive
wheel, provides the traction and contains
the gas or fluid that sustains the load

Radial ply tire

A pneumatic tire in which the ply cords that
extend to the beads are laid at substan-
tially 90 degrees to the centerline of the
tread

Reinforced tire

A tire designed to operate at higher loads
and at higher inflation pressures than the
corresponding standard tire

Section width

The linear distance between the exteriors
of the sidewalls of an inflated tire, exclud-
ing elevations due to labeling, decoration,
or protective bands

Sidewall

That portion of a tire between the tread
and bead

Tire related term

Meaning

404

8-1. Specifications

: Table 1 -Occupant loading and distribution for vehicle normal load for var-

ious designated seating capacities

Sidewall separation

The parting of the rubber compound from
the cord material in the sidewall

Snow tire

A tire that attains a traction index equal to
or greater than 110, compared to the
ASTM E-1136 Standard Reference Test
Tire, when using the snow traction test as
described in ASTM F-1805-00, Standard
Test Method for Single Wheel Driving Trac-
tion in a Straight Line on Snow-and
Ice-Covered Surfaces, and which is

marked with an Alpine Symbol (

) on at

least one sidewall

Test rim

The rim on which a tire is fitted for testing,
and may be any rim listed as appropriate
for use with that tire

Tread

That portion of a tire that comes into con-
tact with the road

Tread rib

A tread section running circumferentially
around a tire

Tread separation

Pulling away of the tread from the tire car-
cass

Treadwear indicators (TWI)

The projections within the principal
grooves designed to give a visual indica-
tion of the degrees of wear of the tread

Wheel-holding fixture

The fixture used to hold the wheel and tire
assembly securely during testing

Tire related term

Meaning

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution in

a normally loaded vehi-

cle

2 through 4

2 in front

5 through 10

2 in front, 1 in second

seat

405

8-1. Specifications

Vehicle

specificatio

11 through 15

2 in front, 1 in second

seat, 1 in third seat, 1 in

fourth seat

16 through 20

2 in front, 2 in second

seat, 2 in third seat, 1 in

fourth seat

Designated seating

capacity, Number of

occupants

Vehicle normal load,

Number of occupants

Occupant distribution in

a normally loaded vehi-

cle

406

8-2. Customization

8-2.Customization

■

Changing by using the

audio system screen

Select

on the main menu.

Select “Vehicle customize”.

Select the item to change the

settings of from the list.

For functions that can be turned
on/off, select

(ON)/

(OFF).

■

Changing by using the

meter control switches

Select

(4.2-inch display)

(7-inch display) of the

multi-information display.

4.2-inch display meter: Press

to select the

desired item to be custom-

ized.

7-inch display meter: Press

to select the desired item

to be customized.

Press or press and hold

The available settings will differ
depending on if

is pressed or

pressed and held. Follow the

instructions on the display.

Some function settings are changed simultaneously with other func-

tions being customized. Contact your Toyota dealer for further

details.

Settings that can be changed using the audio system screen
Settings that can be changed using the meter control switches

Customizable features

Your vehicle includes a vari-

ety of electronic features

that can be personalized to

suit your preferences. The

settings of these features

can be changed using the

multi-information display,

the audio system screen, or

at your Toyota dealer.

Customizing vehicle fea-

tures

WARNING

■

During customization

As the engine needs to be run-

ning during customization, ensure

that the vehicle is parked in a

place with adequate ventilation. In

a closed area such as a garage,

exhaust gases including harmful

carbon monoxide (CO) may col-

lect and enter the vehicle. This

may lead to death or a serious

health hazard.

NOTICE

■

During customization

To prevent battery discharge,

ensure that the engine is running

while customizing features.

Customizable features

407

8-2. Customization

Vehicle

specificatio

Settings that can be changed by your Toyota dealer

Definition of symbols: O = Available, — = Not available

■

Gauges, meters and multi-information display (



P.76, 80, 83,

85, 91)

Function

Default setting Customized setting

Language

English

French

—

Spanish

Units

miles (MPG)

km (km/L)

—

km (L/100 km)

miles (MPG Impe-

rial)

Meter Style

*3, *5

Smart

Casual

—

Sporty

Dial Type

*3, *5

Tachometer

Speedometer

—

Simple (non-dial)

Eco Driving Indicator

Light

Off

—

Fuel economy display

Total average

(Average fuel

consumption

[after reset])

Trip average (Aver-

age fuel consump-

tion [after start])

—

Tank average

(Average fuel con-

sumption [after

refuel])

Audio system linked dis-

play

Off

—

Drive information type

After start

After reset

—

Drive information items

(First item)

Distance

Average vehicle

speed

—

Elapsed time

408

8-2. Customization

: For details about each function:



P.89

: The default setting varies according to country.

: 7-inch display

: If equipped

: This setting changes in accordance with My settings.

■

Door lock (



P.105, 111, 375)

■

Rear seat reminder function (



P.105)

Drive information items

(Second item)

Elapsed time

Average vehicle

speed

—

Distance

Pop-up display

Off

—

Function

Default setting Customized setting

Unlocking using a key

Driver’s door

unlocked in

one step, all

doors

unlocked in

two step

All doors unlocked

in one step

—

Automatic door locking
function

Shift position

linked door

locking opera-

tion

Off

—

Speed linked door

locking operation

Automatic door unlock-
ing function

Shift position

linked door

unlocking

operation

Off

—

Driver’s door linked

door unlocking

operation

Locking/unlocking of the
trunk when all doors are
locked/unlocked

Off

—

Function

Default setting Customized setting

Rear seat reminder
function

Off

—

Function

Default setting Customized setting

409

8-2. Customization

Vehicle

specificatio

■

Smart key system

and wireless remote control

(



P.105, 114)

: If equipped

■

Smart key system

(



P.105, 114)

: If equipped

Function

Default setting Customized setting

Operating signal (Buzz-
ers)

Off

—

1 to 7

Operation signal (Emer-
gency flashers)

Off

—

Time elapsed before
automatic door lock
function is activated if
door is not opened after
being unlocked

60 seconds

Off

—

30 seconds

120 seconds

Open door warning
buzzer

Off

—

Function

Default setting Customized setting

Smart key system

Off

—

Smart door unlocking

Driver’s door

All the doors

—

Time elapsed before
unlocking all the door
when gripping and hold-
ing the driver’s door
handle

2.0 seconds

Off

—

1.5 seconds

2.5 seconds

Number of consecutive
door lock operations

2 times

As many as

desired

—

Engine switch illumina-
tion

Off

—

410

8-2. Customization

■

Wireless remote control

(



P.102, 105, 111)

: If equipped

■

Engine switch

(



P.149)

: Vehicles with a smart key system

■

Power windows and moon roof

(



P.128, 131)

Function

Default setting Customized setting

Wireless remote control

Off

—

Unlocking operation

Driver’s door

unlocked in

one step, all

doors

unlocked in

two step

All doors unlocked

in one step

—

Trunk unlocking opera-
tion

Press and hold

(short)

One short press

—

Push twice

Press and hold

(long)

Off

Theft deterrent panic
mode

Off

—

Locking operation when
door opened

Off

—

Function

Default setting

ACC customization

Enabling/Disabling ACC
mode

On, Off

—

Function

Default setting Customized setting

Mechanical key linked
operation

Off

—

411

8-2. Customization

Vehicle

specificatio

: If equipped

■

Moon roof

(



P.131)

: If equipped

■

Automatic light control system (



P.167)

■

Lights (



P.167)

: Except for Canada

Wireless remote control
linked operation

Off

On (open only)

—

Wireless remote control
linked operation signal
(buzzer)

Off

—

Function

Default setting Customized setting

Linked operation of com-
ponents when key is
used (open only)

Slide only

Tilt only

—

Linked operation of com-
ponents when wireless
remote control is used

Slide only

Tilt only

—

Function

Default setting Customized setting

Light sensor sensitivity

Standard

-2 to 2

—

Time elapsed before
headlights automatically
turn off after doors are
closed

30 seconds

Off

—

60 seconds

90 seconds

Windshield wiper linked
headlight illumination

Off

—

Function

Default setting Customized setting

Daytime running light
system

Off

—

Function

Default setting Customized setting

412

8-2. Customization

■

PCS (Pre-Collision System) (



P.184)

: The system is automatically enabled each time the engine switch is

turned to ON.

: This setting changes in accordance with My Settings

■

LDA (Lane Departure Alert) (



P.200)

: This setting changes in accordance with My Settings

■

Dynamic radar cruise control (



P.213)

: This setting changes in accordance with My Settings

■

Proactive Driving Assist (



P.205)

Function

Customized setting

PCS (Pre-Collision Sys-

tem)

On, Off

—

Warning timing

Later, Default, Earlier

—

Function

Customized setting

LDA (Lane Departure

Alert) system

On, Off

—

Alert timing

Default, Earlier

—

Alert options

Vibration, Beep

—

Function

Customized setting

Acceleration setting

High, Mid, Low

—

Guide message

On, Off

—

Curve speed reduction

High, Mid, Low, Off

—

Function

Customized setting

Proactive Driving Assist

On, Off

—

Obstacle Anticipation

Assist

On, Off

—

Deceleration Assist

On, Off

—

Support timing

Later, Default, Earlier

—

413

8-2. Customization

Vehicle

specificatio

: This setting changes in accordance with My Settings

■

RSA (Road Sign Assist)

(



P.211)

: If equipped

■

Driver break suggestion (



P.203)

■

BSM (Blind Spot Monitor)

(



P.226)

: If equipped

■

RCTA (Rear Cross Traffic Alert) function

(



P.231)

: If equipped

Function

Customized setting

RSA (Road Sign Assist)

On, Off

—

Excess speed notifica-
tion method

None, Visual, Visual and Audible

—

Other notifications
method

None, Visual, Visual and Audible

—

Excess speed notifica-
tion level

5 mph (10 km/h), 3 mph (5 km/h), 1

mph (2 km/h)

—

Function

Customized setting

Driver break suggestion

On, Off

—

Function

Default setting Customized setting

BSM (Blind Spot Moni-
tor)

Off

—

Outside rear view mirror
indicator brightness

Bright

Dim

—

Alert timing for pres-
ence of approaching
vehicle (sensitivity)

Intermediate

Early

—

Late

Function

Default setting Customized setting

RCTA (Rear Cross Traf-
fic Alert)

Off

—

Buzzer volume

Level 2

Level 1

—

Level 3

414

8-2. Customization

■

Safe Exit Assist

(



P.237)

: If equipped

■

Automatic air conditioning system

(



P.257)

: If equipped

■

Illumination (



P.265)

Function

Default setting Customized setting

Safe Exit Assist

Off

—

Outside rearview mir-
rors display

Off

—

Detection sensitivity

Middle

High

—

Low

Function

Default setting Customized setting

Switching between out-
side air and recirculated
air mode linked to auto-
matic mode switch oper-
ation

Off

—

A/C auto switch opera-
tion

Off

—

Function

Default setting Customized setting

Time elapsed before the
interior lights turn off

15 seconds

Off

—

7.5 seconds

30 seconds

Operation after the
engine switch is turned
off

Off

—

Operation when the
doors are unlocked

Off

—

Operation when you
approach the vehicle
with the electronic key

on your person

Off

—

415

8-2. Customization

Vehicle

specificatio

: If equipped

■

Vehicle customization

●

When the smart key system is off,
Smart door unlocking cannot be
customized.

●

When the doors remain closed
after unlocking the doors and the
automatic door lock function is
activated, the signals will be gen-
erated in accordance with the
operation signal (buzzer) and the
operation signal (emergency
flashers) settings.

■

In the following situations, cus-
tomize mode in which the set-
tings can be changed through
the multi-information display
will automatically be turned off

●

The engine switch is turned off.

●

The vehicle begins to move while
the customize mode screen is dis-
played.

416

8-3. Initialization

8-3.Initialization

: If equipped

Items to initialize

The following items must be initialized for normal system
operation after such cases as the battery being reconnected,
or maintenance being performed on the vehicle:

List of items to initialize

Item

When to initialize

Reference

Message indicat-
ing maintenance is
required

• After maintenance is performed

P.289

Tire pressure warn-

ing system

• When rotating front and rear

tires which have different tire
inflation pressures

• When the tire inflation pressure

is changed such as when the
tire size is changed.

• When the tire inflation pressure

is changed such as when
changing traveling speed or load
weight

• When changing between two

registered wheel sets

P.311

Toyota Corolla (2024 year). Manual in english - page 13
