Toyota Corolla (2024 year). Manual in english

289

6-2. Maintenance

Maintena

nce

ca
re

■

Resetting the message indicat-
ing maintenance is required

After the required maintenance is
performed according to the mainte-
nance schedule, please reset the
message.
To reset the message, follow the
procedure described below:



4.2-inch display

Press

of the meter

control switch to select

Press

to select “Vehi-

cle Settings” and then press and

hold .

Press

to select

“Scheduled Maintenance” and

then press

Press

to select “Yes”

and then press

A message will be displayed on the
multi-information display when the
reset procedure has been com-
pleted.



7-inch display

Press

of the meter

control switch to select

Press

to select “Vehi-

cle Settings” and then press and

hold .

Press

to select

“Scheduled Maintenance” and

then press

Press

to select “Yes”

and then press

A message will be displayed on the
multi-information display when the
reset procedure has been com-
pleted.

You can perform some mainte-
nance procedures by yourself.
Please be aware that do-it-your-
self maintenance may affect
warranty coverage.

The use of Toyota repair manuals is
recommended.

For details about warranty cover-
age, refer to the separate “Owner’s
Warranty Information Booklet” or
“Owner’s Manual Supplement”.

Do-it-yourself mainte-
nance

290

6-2. Maintenance

General maintenance

Listed below are the general

maintenance items that

should be performed at the

intervals specified in the

“Owner’s Warranty Informa-

tion Booklet” or “Owner’s

Manual Supplement/Sched-

uled Maintenance Guide”. It

is recommended that any

problem you notice should

be brought to the attention

of your Toyota dealer or

qualified service shop for

advice.

WARNING

■

If the engine is running

Turn the engine off and ensure

that there is adequate ventilation

before performing maintenance

checks.

Engine compartment

Items

Check points

Battery

Check the connec-

tions. (



P.303)

Brake fluid

Is the brake fluid at

the correct level?

(



P.302)

Engine coolant

Is the engine cool-

ant at the correct

level? (



P.301)

Engine oil

Is the engine oil at

the correct level?

(



P.298)

Exhaust sys-

tem

There should not

be any fumes or

strange sounds.

Radiator/con-

denser

The radiator and

condenser should

be free from for-

eign objects.

(



P.301)

Washer fluid

Is there sufficient

washer fluid?

(



P.304)

Vehicle interior

Items

Check points

Accelerator

pedal

The accelerator

pedal should move

smoothly (without

uneven pedal effort

or catching).

Continuously

variable trans-

mission “Park”

mechanism

When parked on a

slope and the shift

lever is in P, is the

vehicle securely

stopped?

Brake pedal

• Does the brake

pedal move

smoothly?

• Does the brake

pedal have

appropriate

clearance from

the floor?

(



P.390)

• Does the brake

pedal have the

correct amount

of free play?

(



P.390)

Items

Check points

291

6-2. Maintenance

Maintena

nce

ca
re

Brakes

• The vehicle

should not pull to
one side when
the brakes are
applied.

• The brakes

should work
effectively.

• The brake pedal

should not feel
spongy.

• The brake pedal

should not get
too close to the
floor when the
brakes are
applied.

Head
restraints

Do the head
restraints move
smoothly and lock
securely?

Indica-
tors/buzzers

Do the indicators
and buzzers func-
tion properly?

Lights

Do all the lights
come on?

Parking brake

• Does the park-

ing brake oper-
ate normally?

• When parked on

a slope and the
parking brake is
on, is the vehicle
securely
stopped?

Items

Check points

Seat belts

• Do the seat belts

operate
smoothly?

• The seat belts

should not be
damaged.

Seats

Do the seat con-
trols operate prop-
erly?

Steering wheel

• Does the steer-

ing wheel rotate
smoothly?

• Does the steer-

ing wheel have
the correct
amount of free
play?

• There should not

be any strange
sounds coming
from the steer-
ing wheel.

Vehicle exterior

Items

Check points

Doors/trunk

Do the doors/trunk
operate smoothly?

Engine hood

Does the engine
hood lock system
work properly?

Fluid leaks

There should not
be any signs of
fluid leakage after
the vehicle has
been parked.

Items

Check points

292

6-2. Maintenance

The OBD system determines
that a problem exists some-
where in the emission control
system. Your vehicle may not
pass the I/M test and may need
to be repaired. Contact your
Toyota dealer to service the
vehicle.



When the battery is discon-
nected or discharged

Readiness codes that are set
during ordinary driving are erased.
Also, depending on your driving
habits, the readiness codes may
not be completely set.



When the fuel tank cap is
loose

Tires

• Is the tire infla-

tion pressure
correct?

• The tires should

not be damaged
or excessively
worn.

• Have the tires

been rotated
according to the
maintenance
schedule?

• The wheel nuts

should not be
loose.

Windshield
wipers

• The wiper blades

should not show
any signs of
cracking, split-
ting, wear, con-
tamination or
deformation.

• The wiper blades

should clear the
windshield with-
out streaking or
skipping.

Items

Check points

Emission inspection

and maintenance (I/M)

programs

Some states have vehicle
emission inspection pro-
grams which include OBD
(On Board Diagnostics)
checks. The OBD system
monitors the operation of
the emission control sys-
tem.

If the malfunction indica-
tor lamp comes on

Your vehicle may not pass
the I/M test in the follow-
ing situations:

294

6-3. Do-it-yourself maintenance

6-3.Do-it-yourself maintenance

Do-it-yourself service

precautions

If you perform maintenance
by yourself, be sure to fol-
low the correct procedure
as given in these sections.

Maintenance

Items

Parts and tools

Battery condi-
tion (



P.303)

• Warm water
• Baking soda
• Grease
• Conventional

wrench (for ter-
minal clamp
bolts)

Brake fluid
level (



P.302)

• FMVSS No.116

DOT 3 or SAE
J1703 brake fluid
FMVSS No.116
DOT 4 or SAE
J1704 brake fluid

• Rag or paper

towel

• Funnel (used

only for adding
brake fluid)

Engine cool-
ant level
(



P.301)

• “Toyota Super

Long Life Cool-
ant” or a similar
high quality eth-
ylene gly-
col-based
non-silicate,
non-amine,
non-nitrite and
non-borate cool-
ant with long-life
hybrid organic
acid technology
For the U.S.A.:
“Toyota Super
Long Life Cool-
ant” is pre-mixed
with 50% cool-
ant and 50%
deionized water.
For Canada:
“Toyota Super
Long Life Cool-
ant” is pre-mixed
with 55% cool-
ant and 45%
deionized water.

• Funnel (used

only for adding
coolant)

Engine oil level
(



P.298)

• “Toyota Genuine

Motor Oil” or
equivalent

• Rag or paper

towel

• Funnel (used

only for adding
engine oil)

Fuses
(



P.331)

• Fuse with same

amperage rating
as original

Items

Parts and tools

295

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Light bulbs

(



P.334)

• Bulb with same

number and

wattage rating as

original

• Flathead screw-

driver

• Wrench

Radiator and

condenser

(



P.301)



Tire inflation

pressure

(



P.322)

• Tire pressure

gauge

• Compressed air

source

Washer fluid

(



P.304)

• Water or washer

fluid containing

antifreeze (for

winter use)

• Funnel (used

only for adding

water or washer

fluid)

WARNING

The engine compartment contains

many mechanisms and fluids that

may move suddenly, become hot,

or become electrically energized.

To avoid death or serious injury,

observe the following precautions.

■

When working on the engine

compartment

●

Keep hands, clothing and tools

away from the moving fan and

engine drive belt.

●

Be careful not to touch the

engine, radiator, exhaust mani-

fold, etc. right after driving as

they may be hot. Oil and other

fluids may also be hot.

Items

Parts and tools

●

Do not leave anything that may

burn easily, such as paper and

rags, in the engine compart-

ment.

●

Do not smoke, cause sparks or

expose an open flame to fuel or

the battery. Fuel and battery

fumes are flammable.

●

Be extremely cautious when

working on the battery. It con-

tains poisonous and corrosive

sulfuric acid.

■

When working near the elec-

tric cooling fan or radiator

grille

Be sure the engine switch is OFF.

With the engine switch in ON, the

electric cooling fan may automati-

cally start to run if the air condi-

tioning is on and/or the coolant

temperature is high. (



P.301)

■

Safety glasses

Wear safety glasses to prevent

flying or falling material, fluid

spray, etc. from getting in your

eyes.

NOTICE

■

If you remove the air cleaner

filter

Driving with the air cleaner filter

removed may cause excessive

engine wear due to dirt in the air.

296

6-3. Do-it-yourself maintenance

Pull the hood lock release

lever.

The hood will pop up slightly.

Pull the auxiliary catch lever

to the left and lift the hood.

Hold the hood open by insert-

ing the support rod into the

slot.

Hood

Opening the hood

WARNING

■

Pre-driving check

Check that the hood is fully closed

and locked.

If the hood is not locked properly,

it may open while the vehicle is in

motion and cause an accident,

which may result in death or seri-

ous injury.

■

After installing the support

rod into the slot

Make sure the rod supports the

hood securely preventing it from

falling down onto your head or

body.

NOTICE

■

When closing the hood

Be sure to return the support rod

to its clip before closing the hood.

Closing the hood with the support

rod not clipped could cause the

hood to bend.

298

6-3. Do-it-yourself maintenance

Washer fluid tank (



P.304)

Engine coolant reservoir (



P.301)

Fuse boxes (



P.331)

Engine oil filler cap (



P.300)

Engine oil level dipstick (

Battery (

Brake fluid reservoir (



P.302)

Radiator (



P.301)

Condenser (



P.301)

Electric cooling fan

With the engine at operating
temperature and turned off,
check the oil level on the dip-
stick.

Park the vehicle on level
ground. After warming up the
engine and turning it off, wait
about 5 minutes for the oil to
drain back into the bottom of
the engine.

Engine compartment

Components

Checking the engine oil

299

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Holding a rag under the end,

pull the dipstick out.

Wipe the dipstick clean.

Reinsert the dipstick fully.

Holding a rag under the end,

pull the dipstick out and

check whether the oil level is

above low level mark.

Low level mark

The shape of the dipstick may differ

depending on the type of vehicle or

engine.

Wipe the dipstick and reinsert

it fully.

■

Engine oil consumption

A certain amount of engine oil will

be consumed while driving. In the

following situations, oil consump-

tion may increase, and engine oil

may need to be refilled in between

oil maintenance intervals.

●

When the engine is new, for

example directly after purchasing

the vehicle or after replacing the

engine

●

If low quality oil or oil of an inap-

propriate viscosity is used

●

When driving at high engine

speeds or with a heavy load, or

when driving while accelerating or

decelerating frequently

●

When leaving the engine idling for

a long time, or when driving fre-

quently through heavy traffic

■

Engine oil level rise

If the vehicle is repeatedly driven

without the engine warmed up,

moisture caused by dew condensa-

tion inside the engine or fuel which

did not burn mixes into the engine

oil, resulting in a rise in engine oil

level. However, this is not a mal-

function. For example, the engine

become difficult to be warmed up in

the following situations.

●

When driving a short distance

●

When driving at a low speed

●

When the outside temperature is

low

When checking the engine oil, make

sure that the engine is warmed up. If

the engine oil level exceeds the refill

upper limit mark, contact your Toy-

ota dealer.

■

Checking the oil type and

preparing the item needed

Make sure to check the oil type

NOTICE

■

To prevent serious engine

damage

Check the oil level on a regular

basis.

Adding engine oil

300

6-3. Do-it-yourself maintenance

and prepare the items needed

before adding oil.



Engine oil selection



P.388



Oil quantity (Low level mark



Refill upper limit mark)

1.6 qt. (1.5 L, 1.3 Imp. qt.)



Item

Clean funnel

■

Adding engine oil

If the oil level is below or near

the low level mark, add engine

oil of the same type as that

already in the engine.

Remove the oil filler cap by

turning it counterclockwise.

Add engine oil slowly, check-

ing the dipstick.

Make sure that the oil level does

not exceed the refill upper limit

mark and is between the low level

mark and refill upper limit mark.

Low level mark
Refill upper limit mark

The shape of the dipstick may differ

depending on the type of vehicle

engine.

Install the oil filler cap by

turning it clockwise.

WARNING

■

Used engine oil

●

Used engine oil contains poten-

tially harmful contaminants

which may cause skin disorders

such as inflammation and skin

cancer, so care should be taken

to avoid prolonged and

repeated contact. To remove

used engine oil from your skin,

wash thoroughly with soap and

water.

●

Dispose of used oil and filters

only in a safe and acceptable

manner. Do not dispose of used

oil and filters in household trash,

in sewers or onto the ground.

Call your Toyota dealer, service

station or auto parts store for

information concerning recy-

cling or disposal.

●

Do not leave used engine oil

within the reach of children.

NOTICE

■

When replacing the engine oil

●

Be careful not to spill engine oil

on the vehicle components.

●

Avoid overfilling, or the engine

could be damaged.

●

Check the oil level on the dip-

stick every time you refill the

vehicle.

●

Be sure the engine oil filler cap

is properly tightened.

301

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

The coolant level is satisfactory

if it is between the “MAX” and

“MIN” lines on the reservoir

when the engine is cold.

Reservoir
“MAX” line
“MIN” line

If the level is on or below the “MIN”

line, add coolant up to the “MAX”

line. (



P.381)

■

Coolant selection

Only use “Toyota Super Long Life

Coolant” or a similar high quality

ethylene glycol based non-silicate,

non-amine, non-nitrite, and

non-borate coolant with long-life

hybrid organic acid technology.
For the U.S.A.:
“Toyota Super Long Life Coolant” is

a mixture of 50% coolant and 50%

deionized water. (Minimum tem-

perature: -31°F [-35°C])
For Canada:
“Toyota Super Long Life Coolant” is

a mixture of 55% coolant and 45%

deionized water. (Minimum tem-

perature: -44°F [-42°C])
For more details about coolant, con-

tact your Toyota dealer.

■

If the coolant level drops within

a short time of replenishing

Visually check the radiator, hoses,

engine coolant reservoir caps, drain

cock and water pump.

If you cannot find a leak, have your

Toyota dealer test the cap and

check for leaks in the cooling sys-

tem.

Check the radiator and con-

denser and clear away any for-

eign objects. If either of the

above parts is extremely dirty or

you are not sure of their condi-

tion, have your vehicle

inspected by your Toyota dealer.

Checking the engine cool-

ant

WARNING

■

When the engine is hot

Do not remove the engine coolant

reservoir cap.
The cooling system may be under

pressure and may spray hot cool-

ant if the cap is removed, causing

serious injuries, such as burns.

NOTICE

■

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct

mixture of water and antifreeze

must be used to provide proper

lubrication, corrosion protection

and cooling. Be sure to read the

antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to

prevent it from damaging parts or

paint.

Checking the radiator and

condenser

302

6-3. Do-it-yourself maintenance

■

Checking fluid level

The brake fluid level should be

between the “MAX” and “MIN”

lines on the tank.

■

Adding fluid

Slide and lift up the rubber

strip to partly remove it as

shown.

Disconnect the claws and

remove the service cover.

Remove the reservoir cap.

Add brake fluid slowly while

checking the fluid level.

Make sure to check the fluid

type and prepare the necessary

item.



Fluid type

FMVSS No.116 DOT 3 or SAE

J1703 brake fluid
FMVSS No.116 DOT 4 or SAE

J1704 brake fluid



Item

Clean funnel

■

Brake fluid can absorb moisture

from the air

Excess moisture in the brake fluid

can cause a dangerous loss of brak-

ing efficiency. Use only newly

opened brake fluid.

WARNING

■

When the engine is hot

Do not touch the radiator or con-

denser as they may be hot and

cause serious injuries, such as

burns.

Checking and adding the

brake fluid

303

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Check the battery as follows.

■

Battery exterior

Make sure that the battery termi-

nals are not corroded and that

there are no loose connections,

cracks, or loose clamps.

Terminals
Hold-down clamp

■

Before recharging

When recharging, the battery pro-

duces hydrogen gas which is flam-

mable and explosive. Therefore,

observe the following precautions

before recharging:

●

If recharging with the battery

installed on the vehicle, be sure to

disconnect the ground cable.

●

Make sure the charger is off when

connecting and disconnecting the

charger cables to the battery.

■

After recharging/reconnecting

the battery (vehicles with a

smart key system)

●

Unlocking the doors using the

smart key system may not be pos-

sible immediately after reconnect-

ing the battery. If this happens,

use the wireless remote control or

the mechanical key to lock/unlock

the doors.

●

Start the engine with the engine

switch in ACC. The engine may

not start with the engine switch

turned off. However, the engine

will operate normally from the sec-

ond attempt.

●

The engine switch mode is

recorded by the vehicle. If the bat-

tery is reconnected, the vehicle

will return the engine switch mode

to the status it was in before the

battery was disconnected. Make

sure to turn off the engine before

disconnecting the battery. Take

extra care when connecting the

battery if the engine switch mode

prior to discharge is unknown.

If the system will not start even after

multiple attempts, contact your Toy-

ota dealer.

WARNING

■

When filling the reservoir

Take care as brake fluid can harm

your hands and eyes and damage

painted surfaces.

If fluid gets on your hands or in

your eyes, flush the affected area

with clean water immediately.
If you still experience discomfort,

see a doctor.

NOTICE

■

If the fluid level is low or high

It is normal for the brake fluid level

to go down slightly as the brake

pads wear out or when the fluid

level in the accumulator is high.

If the reservoir needs frequent

refilling, there may be a serious

problem.

Battery

304

6-3. Do-it-yourself maintenance

Add washer fluid in the following

situations:



A washer does not work.



The warning message

appears on the multi-informa-

tion display.

WARNING

■

Chemicals in the battery

The battery contains poisonous

and corrosive sulfuric acid and

may produce hydrogen gas which

is flammable and explosive. To

reduce the risk of death or serious

injury, take the following precau-

tions while working on or near the

battery:

●

Do not cause sparks by touch-

ing the battery terminals with

tools.

●

Do not smoke or light a match

near the battery.

●

Avoid contact with eyes, skin

and clothes.

●

Never inhale or swallow electro-

lyte.

●

Wear protective safety glasses

when working near the battery.

●

Keep children away from the

battery.

■

Where to safely charge the

battery

Always charge the battery in an

open area. Do not charge the bat-

tery in a garage or closed room

where there is insufficient ventila-

tion.

■

Emergency measures regard-

ing electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean

water for at least 15 minutes

and get immediate medical

attention. If possible, continue

to apply water with a sponge or

cloth while traveling to the near-

est medical facility.

●

If electrolyte gets on your skin

Wash the affected area thor-

oughly. If you feel pain or burn-

ing, get medical attention

immediately.

●

If electrolyte gets on your

clothes

It can soak through clothing on

to your skin. Immediately take

off the clothing and follow the

procedure above if necessary.

●

If you accidentally swallow elec-

trolyte

Drink a large quantity of water

or milk. Get emergency medical

attention immediately.

■

When disconnecting the bat-

tery

Do not disconnect the negative (-)

terminal on the body side. The

disconnected negative (-) terminal

may touch the positive (+) termi-

nal, which may cause a short and

result in death or serious injury.

NOTICE

■

When recharging the battery

Never recharge the battery while

the engine is running. Also, be

sure all accessories are turned

off.

Adding the washer fluid

305

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

Check if the treadwear indica-

tors are showing on the tires.

Also check the tires for uneven

wear, such as excessive wear

on one side of the tread.
Check the spare tire condition

and pressure if not rotated.

New tread
Worn tread
Treadwear indicator

The location of treadwear indicators
is shown by a “TWI” or “

” mark,

WARNING

■

When adding washer fluid

Do not add washer fluid when the

engine is hot or running as

washer fluid contains alcohol and

may catch fire if spilled on the

engine, etc.

NOTICE

■

Do not use any fluid other

than washer fluid

Do not use soapy water or engine

antifreeze instead of washer fluid.

Doing so may cause streaking on

the vehicle’s painted surfaces, as

well as damaging the pump lead-

ing to problems of the washer

fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as

necessary.

Refer to the freezing tempera-

tures listed on the label of the

washer fluid bottle.

Tires

Replace or rotate tires in

accordance with mainte-

nance schedules and tread-

wear.

Checking tires

306

6-3. Do-it-yourself maintenance

etc., molded into the sidewall of
each tire.
Replace the tires if the treadwear
indicators are showing on a tire.

■

When to replace your vehicle’s
tires

Tires should be replaced if:

●

The treadwear indicators are
showing on a tire

●

You have tire damage such as
cuts, splits, cracks deep enough
to expose the fabric, and bulges
indicating internal damage

●

A tire goes flat repeatedly or can-
not be properly repaired due to the
size or location of a cut or other
damage

If you are not sure, consult with your
Toyota dealer.

■

Tire life

Any tire over 6 years old must be
checked by a qualified technician
even if it has seldom or never been
used or damage is not obvious.

■

Low profile tires (18-inch tires)

Generally, low profile tires will wear
more rapidly and tire grip perfor-
mance will be reduced on snowy
and/or icy roads when compared to
standard tires. Be sure to use snow
tires or tire chains on snowy and/or
icy roads and drive carefully at a
speed appropriate for road and
weather conditions.

■

Maximum load of tire

Check that the maximum load of the
replacement tire is greater than 1/2
of the Gross Axle Weight Ratings
(GAWR) of either the front axle or
the rear axle, whichever is greater.

For the GAWR, see the Certification
Label.
For the maximum load of the tire,
see the load limit at maximum cold
tire inflation pressure mentioned on
the sidewall of the tire. (



P.395)

■

Tire types

●

Summer tires

Summer tires are high-speed perfor-
mance tires best suited to highway
driving under dry conditions. Since
summer tires do not have the same
traction performance as snow tires,
summer tires are inadequate for
driving on snow-covered or icy
roads. For driving on snow-covered
roads or icy roads, the use of snow
tires is recommended. When install-
ing snow tires, be sure to replace all
four tires.

●

All season tires

All season tires are designed to pro-
vide better traction in snow and to
be adequate for driving in most win-
ter conditions as well as for use
year-round. All season tires, how-
ever, do not have adequate traction
performance compared with snow
tires in heavy or loose snow. Also,
all season tires fall short in accelera-
tion and handling performance com-
pared with summer tires in highway
driving.

●

Snow tires

For driving on snow-covered roads
or icy roads, we recommend using
snow tires. If you need snow tires,
select tires of the same size, con-
struction and load capacity as the
originally installed tires. Since your
vehicle has radial tires as original
equipment, make sure your snow

307

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

tires also have radial construction.

Do not install studded tires without

first checking local regulations for

possible restrictions. Snow tires

should be installed on all wheels.

(



P.247)

■

If the tread on snow tires wears

down below 0.16 in. (4 mm)

The effectiveness of the tires as

snow tires is lost.

■

Checking the tire valves

When replacing the tires, check the

tire valves for deformation, cracks,

and other damage.

Rotate the tires in the order

shown.

WARNING

■

When inspecting or replacing

tires

Observe the following precautions

to prevent accidents.

Failure to do so may cause dam-

age to parts of the drive train as

well as dangerous handling char-

acteristics, which may lead to an

accident resulting in death or seri-

ous injury.

●

Do not mix tires of different

makes, models or tread pat-

terns.

Also, do not mix tires of remark-

ably different treadwear.

●

Do not use tire sizes other than

those recommended by Toyota.

●

Do not mix differently con-

structed tires (radial, bias-belted

or bias-ply tires).

●

Do not mix summer, all season

and snow tires.

●

Do not use tires that have been

used on another vehicle.

Do not use tires if you do not

know how they were used previ-

ously.

NOTICE

■

Low profile tires (18-inch

tires)

Low profile tires may cause

greater damage than usual to the

tire wheel when sustaining impact

from the road surface. Therefore,

pay attention to the following:

●

Be sure to use proper tire infla-

tion pressure. If tires are

under-inflated, they may be

damaged more severely.

●

Avoid potholes, uneven pave-

ment, curbs and other road haz-

ards. Failure to do so may lead

to severe tire and wheel dam-

age.

■

If tire inflation pressure of

each tire becomes low while

driving

Do not continue driving, or your

tires and/or wheels may be

ruined.

■

Driving on rough roads

Take particular care when driving

on roads with loose surfaces or

potholes.

These conditions may cause

losses in tire inflation pressure,

reducing the cushioning ability of

the tires. In addition, driving on

rough roads may cause damage

to the tires themselves, as well as

the vehicle’s wheels and body.

Tire rotation

308

6-3. Do-it-yourself maintenance

Front

To equalize tire wear and extend
tire life, Toyota recommends that
tire rotation is carried out at the
same interval as tire inspection.

Vehicles with a tire pressure warn-
ing system: Do not fail to initialize
the tire pressure warning system
after tire rotation.

Your vehicle is equipped with a
tire pressure warning system
that uses tire pressure warning
valves and transmitters to detect
low tire inflation pressure before
serious problems arise.

The tire pressure warning sys-
tem of this vehicle adopts a
2-type warning system.



When “Adjust Pressure” is
displayed (Normal Warning)

A warning with the tire pressure
warning light and warning buzzer
when there is an unknown level of
low tire pressure with the appear-
ance of the tire due to natural air
leakage as well as the pressure
lowering due to changes in the
pressure according to the outside

temperature. (Ways of coping:



P.354, 391)



When “Immediately Check
Tire when Safe” is displayed
(Emergency Warning)

A warning with the tire pressure
warning light and warning buzzer
when there is a known level of low
tire pressure with the appearance
of the tire due to pressure suddenly
lowering. (Ways of coping:



P.354,

364)
However, the system may not be
able to detect sudden tire ruptures
(bursting, etc.).

The tire pressure detected by the
tire pressure warning system can
be displayed on the multi-informa-
tion display.

■

How to change the unit



4.2-inch display

Park the vehicle in a safe
place and turn the engine
switch off.

Changing the unit cannot be per-
formed while the vehicle is moving.

Turn the engine switch to
ON.

Tire pressure warning
system (if equipped)

309

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Pressure unit setting”.

Press

to select the

desired unit and then press



7-inch display

Park the vehicle in a safe
place and turn the engine
switch off.

Changing the unit cannot be per-
formed while the vehicle is moving.

Turn the engine switch to
ON.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Pressure unit setting”.

Press

to select the

desired unit and then press

■

Routine tire inflation pressure
checks

The tire pressure warning system
does not replace routine tire inflation
pressure checks. Make sure to
check tire inflation pressure as part
of your routine of daily vehicle
checks.

■

Tire inflation pressure

●

It may take a few minutes to dis-
play the tire inflation pressure
after the engine switch is turned to
ON. It may also take a few min-
utes to display the tire inflation
pressure after inflation pressure
has been adjusted.

●

Tire inflation pressure changes
with temperature.
The displayed values may also be
different from the values mea-
sured using a tire pressure gauge.

■

Situations in which the tire
pressure warning system may
not operate properly

●

In the following cases, the tire
pressure warning system may not
operate properly.

• If non-genuine Toyota wheels are

used.

• A tire has been replaced with a

tire that is not an OE (Original
Equipment) tire.

• A tire has been replaced with a

tire that is not of the specified size.

• Tire chains, etc. are equipped.
• An auxiliary-supported run-flat tire

is equipped.

• If a window tint that affects the

radio wave signals is installed.

• If there is a lot of snow or ice on

the vehicle, particularly around the

310

6-3. Do-it-yourself maintenance

wheels or wheel housings.

• If the tire inflation pressure is

extremely higher than the speci-

fied level.

• If tires not equipped with tire pres-

sure warning valves and transmit-

ters are used.

• If the ID code on the tire pressure

warning valves and transmitters is

not registered in the tire pressure

warning computer.

●

Performance may be affected in

the following situations.

• Near a TV tower, electric power

plant, gas station, radio station,

large display, airport or other facil-

ity that generates strong radio

waves or electrical noise.

• When carrying a portable radio,

cellular phone, cordless phone or

other wireless communication

device.

●

When the vehicle is parked, the

time taken for the warning to start

or go off could be extended.

●

When tire inflation pressure

declines rapidly for example when

a tire has burst, the warning may

not function.

■

Warning performance of the tire

pressure warning system

The warning of the tire pressure

warning system will change in

accordance with driving conditions.

For this reason, the system may

give a warning even if the tire pres-

sure does not reach a low enough

level, or if the pressure is higher

than the pressure that was adjusted

to when the system was initialized.

When replacing tires or wheels,

tire pressure warning valves and

transmitters must also be

installed.
When new tire pressure warning

valves and transmitters are

installed, new ID codes must be

registered in the tire pressure

warning computer and the tire

pressure warning system must

be initialized. Have tire pressure

warning valves and transmitter

ID codes registered by your Toy-

ota dealer. (



P.316)

■

Replacing tires and wheels

If the ID code of the tire pressure

warning valve and transmitter is not

registered, the tire pressure warning

system will not work properly. After

driving for about 20 minutes, the tire

pressure warning light blinks for 1

minute and stays on to indicate a

system malfunction.

Installing tire pressure

warning valves and trans-

mitters (vehicles with a

tire pressure warning sys-

tem)

NOTICE

■

Repairing or replacing tires,

wheels, tire pressure warn-

ing valves, transmitters and

tire valve caps

●

When removing or fitting the

wheels, tires or the tire pressure

warning valves and transmit-

ters, contact your Toyota dealer

as the tire pressure warning

valves and transmitters may be

damaged if not handled cor-

rectly.

●

Make sure to install the tire

valve caps. If the tire valve caps

are not installed, water could

enter the tire pressure warning

valves and the tire pressure

warning valves could be bound.

311

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

It is necessary to register the

position of each wheel after per-

forming a tire rotation.
Wheel position registration can

be performed by oneself. Wheel

position registration is per-

formed by driving forward with

moderate left and right turns.

However, depending on the driv-

ing conditions and driving envi-

ronment, registration may take

some time to complete.



4.2-inch display

Park the vehicle in a safe

place and turn the engine

switch off, wait for approxi-

mately 20 minutes or more,

and then start the engine.

The wheel position registration pro-

cedure cannot be performed while

the vehicle is moving.

Select

of the multi-infor-

mation display and then
press .

Press

to select

“Vehicle Settings” and then
press and hold

Press

to select

“TPWS setting” and then
press .

Press

to select

“Tire Rotation” and then
press .

Select “OK” and then press

A message indicating that wheel

position registration is being per-

formed will be displayed on the

multi-information display. “---” will

be displayed for the tire inflation

pressure of each tire and wheel

position registration will begin.

Drive straight (with occa-

sional left and right turns) at

approximately 25 mph (40

km/h) or more for approxi-

mately 10 to 30 minutes.

When wheel position registration is

complete, a message indicating

that registration has been com-

pleted and the inflation pressure of

each tire will be displayed on the

multi-information display.

NOTICE

●

When replacing tire valve caps,

do not use tire valve caps other

than those specified. The cap

may become stuck.

■

To avoid damage to the tire

pressure warning valves and

transmitters

When a tire is repaired with liquid

sealants, the tire pressure warn-

ing valve and transmitter may not

operate properly. If a liquid seal-

ant is used, contact your Toyota

dealer or other qualified service

shop as soon as possible. Make

sure to replace the tire pressure

warning valve and transmitter

when replacing the tire. (



P.310)

Registration of the posi-

tion of each wheel after

performing a tire rotation

(vehicles with a tire pres-

sure warning system)

312

6-3. Do-it-yourself maintenance

Even if it is not possible to drive
continuously at approximately 25
mph (40 km/h) or more, registration
can be completed by driving for a
long time. However, if registration
does not complete after driving for
1 hour or more, park the vehicle in
a safe place and leave it with the
engine switch in ON for approxi-
mately 15 minutes or more, and
then perform the driving procedure
again.



7-inch display

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The wheel position registration pro-
cedure cannot be performed while
the vehicle is moving.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Tire Rotation” and then

press .

Select “OK” and then press

A message indicating that wheel
position registration is being per-
formed will be displayed on the

multi-information display. “---” will
be displayed for the tire inflation
pressure of each tire and wheel
position registration will begin.

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When wheel position registration is
complete, a message indicating
that registration has been com-
pleted and the inflation pressure of
each tire will be displayed on the
multi-information display.

■

When performing wheel posi-
tion registration

●

Normally, wheel position registra-
tion can be completed within
approximately 30 minutes.

●

Wheel position registration is per-
formed while driving at a vehicle
speed of approximately 25 mph
(40 km/h) or more.

■

Wheel position registration pro-
cedure

●

If the engine switch is turned off
while registering the wheel posi-
tion, the next time the engine
switch is turned to ON, the wheel
position registration will resume
and it will not be necessary to
restart the procedure.

●

While the position of each wheel is
being determined and the inflation
pressures are not being dis-

313

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

played, if the inflation pressure of
a tire drops, the tire pressure
warning light will come on.

■

If the wheel position cannot be
registered easily

●

In the following situations, wheel
position registration may take lon-
ger than usual to be completed or
may not be possible.

• Vehicle is not driven at approxi-

mately 25 mph (40 km/h) or more

• Vehicle is driven on unpaved

roads

• If wheel position registration does

not complete after driving for 1
hour or more, park the vehicle in a
safe place for approximately 15
minutes and then drive the vehicle
again.

●

If the vehicle is reversed during
wheel position registration, all
data collected until then will be
cleared. Perform driving again.

In the following situations, it will
be necessary to perform the tire
inflation pressure setting proce-
dure of the tire pressure warning
system.



When the specified tire infla-
tion pressure has changed,
such as due to carried load,
etc.



When the tire inflation pres-
sure is changed such as
when the tire size is changed.

If the tire inflation pressure has
been adjusted to the specified
level, perform the tire inflation set-
ting procedure by selecting speci-
fied inflation pressure on the

multi-information display.

When the tire inflation pressure is
to be other than specified, such as
when tires other than the specified
size are used, etc., set the tire infla-
tion pressure using the current
pressure. Make sure to adjust the
tire inflation pressure of each tire to
the appropriate level before per-
forming tire pressure setting. The
tire pressure warning system oper-
ates based on this tire inflation
pressure.

■

Setting by selecting a spec-
ified tire inflation pressure



4.2-inch display

Park the vehicle in a safe
place and then start the
engine.

The tire inflation pressure cannot
be set while the vehicle is moving.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Tire Pressure Setting” and

then press

Setting the tire pressure
(vehicles with a tire pres-
sure warning system)

314

6-3. Do-it-yourself maintenance

Press

to select

“Setting by Specified Pres-

sure” and then press

Select the desired tire pres-

sures, then press

The tire pressure warning light will
slowly blink 3 times.

After setting the tire inflation pres-
sure, a message indicating that set-
ting has been completed will be
displayed on the multi-information
display.



7-inch display

Park the vehicle in a safe
place and then start the
engine.

The tire inflation pressure cannot
be set while the vehicle is moving.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Tire Pressure Setting” and

then press

Press

to select

“Setting by Specified Pres-

sure” and then press

Select the desired tire pres-

sures, then press

The tire pressure warning light will
slowly blink 3 times.

After setting the tire inflation pres-
sure, a message indicating that set-
ting has been completed will be
displayed on the multi-information
display.

■

If the tire inflation pressure can-
not be set easily

●

If the tire pressure warning light
does not blink 3 times when start-
ing the tire inflation pressure set-
ting procedure, the procedure
may not have started. Perform the
procedure again from the begin-
ning.

●

If tire inflation pressure setting
procedure cannot be completed
after performing the above proce-
dure, contact your Toyota dealer.

315

6-3. Do-it-yourself maintenance

Maintena

nce
a

nd
ca

■

Setting using the current

tire inflation pressure



4.2-inch display

Park the vehicle in a safe

place and then start the

engine.

The tire inflation pressure cannot

be set while the vehicle is moving.

Select

of the multi-infor-

mation display and then
press .

Press

to select

“Vehicle Settings” and then
press and hold

Press

to select

“TPWS setting” and then
press .

Press

to select

“Tire Pressure Setting” and
then press

Press

to select

“Setting by Current Pressure”
and then press

The tire pressure warning light will

slowly blink 3 times and a message

indicating that tire inflation pressure

is being set will be displayed on the

multi-information display.
After setting the tire inflation pres-

sure, a message indicating that set-

ting has been completed will be

displayed on the multi-information

display.



7-inch display

Park the vehicle in a safe

place and then start the

engine.

The tire inflation pressure cannot

be set while the vehicle is moving.

Select

of the multi-infor-

mation display and then
press .

Press

to select

“Vehicle Settings” and then
press and hold

Press

to select

“TPWS setting” and then
press .

Press

to select

“Tire Pressure Setting” and
then press

WARNING

■

Before performing tire pres-

sure setting

Make sure to adjust the tire infla-

tion pressure of each tire to the

appropriate level before perform-

ing tire pressure setting. Other-

wise, the tire pressure warning

light may not illuminate even if the

tire inflation pressure drops or

may illuminate even though the

tire inflation pressure is normal.

316

6-3. Do-it-yourself maintenance

Press

to select

“Setting by Current Pressure”

and then press

The tire pressure warning light will
slowly blink 3 times and a message
indicating that tire inflation pressure
is being set will be displayed on the
multi-information display.

After setting the tire inflation pres-
sure, a message indicating that set-
ting has been completed will be
displayed on the multi-information
display.

■

Warning performance of the tire
pressure warning system

●

When performing the tire pressure
setting using the current tire infla-
tion pressure, the warning timing
of the tire pressure warning sys-
tem will vary according to the con-
ditions under which tire pressure
setting was performed. Therefore,
a warning may be output even if
the tire inflation pressure drops
slightly or if the tire inflation pres-
sure increases above that when
the tire inflation pressure was set.

●

Make sure to perform the tire
pressure setting procedure after
adjusting the tire inflation pres-
sure. Also, make sure the tires are
cold before performing the tire
pressure setting procedure or
adjusting the tire inflation pres-
sure.

■

Tire inflation pressure setting
procedure

●

If the engine switch is turned off
while setting the tire inflation pres-
sure, the next time the engine
switch is turned to ON, the setting
procedure will resume and it will
not be necessary to restart the
procedure.

●

If the tire inflation pressure setting
procedure is started unnecessar-
ily, adjust the tire inflation pres-
sure to the specified level with the
tires cold and then perform setting
by selecting a specified tire infla-
tion pressure, or perform the tire
inflation pressure setting proce-
dure with the current tire inflation
pressure.

■

If the tire inflation pressure can-
not be set easily

●

Normally, the tire inflation pres-
sure setting procedure can be
completed in 2 or 3 minutes.

●

If tire inflation pressure setting
procedure cannot be completed
after performing the above proce-
dure, contact your Toyota dealer.

The tire pressure warning valve
and transmitter is equipped with
a unique ID code. When new
tire pressure warning valves and
transmitters are installed, new
ID codes must be registered in
the tire pressure warning com-

Registering ID codes
(vehicles with a tire pres-
sure warning system)

317

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

puter.



ID codes can be registered by
yourself, but depending on
the driving conditions and
driving environment, registra-
tion may take some time to
complete.



When using a wheel set
which all of the ID codes have
already been registered, the
wheel set can be changed in
a short amount of time.

Before performing ID code reg-
istration, make sure that no
wheels with tire pressure warn-
ing valve and transmitters
installed are near the vehicle.



4.2-inch display

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The ID code registration procedure
cannot be performed while the
vehicle is moving.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Tire Set Switching” and then

press .

Press

to select

“Register New Valve / ID” and

then press

Press

to select

“Tire Set 1” or “Tire Set 2”.

Then press

ID codes will be registered to the
displayed wheel set.

If ID codes have already been reg-
istered for that wheel set, the tire
pressure warning light will slowly
blink 3 times, and a message indi-
cating that change is occurring will
be displayed on the multi-informa-
tion display.

Select “OK” and then press

The tire pressure warning light will
slowly blink 3 times and a message
indicating that ID code registration
is being performed will be displayed
on the multi-information display.
Wheel set changing will be can-
celed and registration will begin.

When registration is being per-
formed, the tire pressure warning
light will blink for approximately 1
minute then illuminate and “---” will
be displayed for the inflation pres-

318

6-3. Do-it-yourself maintenance

sure of each tire on the multi-infor-
mation display.

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When registration is complete, the
tire pressure warning light will turn
off and a message indicating that
registration has been completed
will be displayed on the multi-infor-
mation display.

Registration may take longer than
normal to complete if the vehicle
speed cannot be maintained at
approximately 25 mph (40 km/h) or
more. If registration cannot be com-
pleted after driving for 1 hour or
more, perform the registration pro-
cedure again from the beginning.

If the tire inflation pressure of

the wheel set installed differs
from that of the previous set,
it will be necessary to per-
form the tire inflation pres-
sure setting procedure of the
tire pressure warning system.

If the specified tire inflation pres-
sure is the same, it will not be nec-
essary to perform the tire inflation
pressure setting procedure.



7-inch display

Park the vehicle in a safe
place and turn the engine
switch off, wait for approxi-
mately 20 minutes or more,
and then start the engine.

The ID code registration procedure
cannot be performed while the
vehicle is moving.

Select

of the multi-infor-

mation display and then

press .

Press

to select

“Vehicle Settings” and then

press and hold

Press

to select

“TPWS setting” and then

press .

Press

to select

“Tire Set Switching” and then

press .

Press

to select

“Register New Valve / ID” and

then press

Press

to select

“Tire Set 1” or “Tire Set 2”.

Then press

ID codes will be registered to the
displayed wheel set.

319

6-3. Do-it-yourself maintenance

Maintena

nce

ca
re

Select “OK” and then press

When registration is being per-
formed, the tire pressure warning
light will blink for approximately 1
minute then illuminate and “---” will
be displayed for the inflation pres-
sure of each tire on the multi-infor-
mation display.

Drive straight (with occa-
sional left and right turns) at
approximately 25 mph (40
km/h) or more for approxi-
mately 10 to 30 minutes.

When registration is complete, the
tire pressure warning light will turn
off and a message indicating that
registration has been completed
will be displayed on the multi-infor-
mation display.

If the tire inflation pressure of

the wheel set installed differs
from that of the previous set,
it will be necessary to per-
form the tire inflation pres-
sure setting procedure of the
tire pressure warning system.

If the specified tire inflation pres-
sure is the same, it will not be nec-
essary to perform the tire inflation
pressure setting procedure.

■

When registering ID codes

●

Normally, ID codes registration
can be completed within approxi-
mately 30 minutes.

●

ID code registration is performed
while driving at a vehicle speed of
approximately 25 mph (40 km/h)
or more.

■

If ID codes are not registered
easily

●

In the following situations, ID code
registration may take longer than
usual to be completed or may not
be possible.

• When the vehicle has not been

parked for approximately 20 min-
utes or more before being driven

• Vehicle is not driven at approxi-

mately 25 mph (40 km/h) or more

• Vehicle is driven on unpaved

roads

• Vehicle is driven near other vehi-

cles and system cannot recog-
nize tire pressure warning valve
and transmitters of your vehicle
over those of other vehicles

• Wheel with tire pressure warning

valve and transmitter installed is
inside or near the vehicle

●

If the vehicle is reversed during
registration, all data collected until
then will be cleared. Perform driv-
ing again.

●

If the tire pressure warning light
does not blink 3 times when start-
ing ID code registration proce-
dure to step

, the procedure may

not have started. Perform the pro-
cedure again from the beginning.

●

If registration does not complete
after driving for 1 hour or more,
perform the ID code registration
procedure again from the begin-
ning.

●

If the ID codes cannot be regis-
tered even when performing the
above procedure, contact your
Toyota dealer.

320

6-3. Do-it-yourself maintenance

■

Canceling ID code registration

To cancel ID code registration after
it has been started, select “Register
Valve / ID” again on the multi-infor-
mation display.

If ID code registration has been can-
celed, the tire pressure warning light
will turn off.

If the warning light does not turn off,
ID code registration may not have
been cancelled correctly. To cancel
registration, select “Register Valve /
ID” on the multi-information display.

Your vehicle is equipped with a
tire pressure warning system
with a function to register two
sets of ID codes. This allows for
registration of a second wheel
set, for example a winter set.

The wheel set can be changed
only if a second wheel set has
been registered to the system. If
a second wheel set has not
been registered, it will not be
possible to change to the
selected wheel set.

ID codes can be registered by
yourself.



Only a change between both
registered wheel set is possi-
ble, mixing between these
wheel sets is not supported.



While registering ID codes, it
may not be possible to
change between wheel sets
normally. Cancel registration

before changing between
wheel sets.



4.2-inch display

Install the desired wheel set.

Select

of the multi-infor-

mation display and then

press .

Press

select

“Vehicle Settings” and then

press .

Press

select

“TPWS setting” and then

press .

Press

select

“Tire Set Switching” and then

press .

Press

select

“Register Valve / ID” and then

press .

Press

select

“Tire Set 1” or “Tire Set 2”.

Then press

Select “OK” and then press

The tire pressure warning light will
slowly blink 3 times, a message
indicating that change is occurring
will be displayed, and the wheel set
change will begin.
Wheel set change will begin and
the tire pressure warning light will
blink for 1 minute and then illumi-
nate.

Also, while the change is being per-

Selecting wheel set (vehi-
cles with a tire pressure
warning system)

Toyota Corolla (2024 year). Manual in english - page 10
