P. 147)

●

Opens the trunk (



P. 156)

●

Starts the engine (



P. 211)

■

Antenna location

■

Effective range (areas within which the electronic key is detected)

Smart key system



: If equipped

The following operations can be performed simply by carrying
the electronic key on your person, for example in your pocket.
(The driver should always carry the electronic key.)

Antennas outside the cabin

Antennas inside the cabin

Antenna inside the trunk

Antenna outside the trunk

When locking or unlocking the
doors

The system can be operated when
the electronic key is within about 2.3
ft. (0.7 m) of either of the front out-
side door handles. (Only the doors
detecting the key can be operated.)

When starting the engine or changing engine switch modes

The system can be operated when the electronic key is inside the
vehicle.

When opening the trunk

The system can be operated when the electronic key is within about
2.3 ft. (0.7 m) of the trunk release button.

162

3-2. Opening, closing and locking the doors

CAMRY_U

■

Alarms and warning indicators

A combination of exterior and interior alarms as well as warning messages
shown on the multi-information display are used to prevent theft of the vehicle
and accidents resulting from erroneous operation. Take appropriate mea-
sures in response to any warning message on the multi-information display.
(

P. 538)

When only an alarm sounds, circumstances and correction procedures are as
follows.

Alarm

Situation

Correction procedure

Exterior alarm sounds
once for 5 seconds

An attempt was made
to lock the vehicle while
a door was open.

Close all of the doors
and lock the doors
again.

The trunk was closed
while the electronic key
was still inside the trunk
and all the doors were
locked.

Retrieve the electronic
key from the trunk and
close the trunk lid.

Interior alarm pings
repeatedly

The engine switch was
turned to ACCESSORY
mode while the driver’s
door was open (The
driver’s door was
opened when the
engine switch was in
ACCESSORY mode).

Turn the engine switch
off and close the
driver’s door.

The engine switch was
turned off while the
driver’s door was open.

Close the driver’s door.

163

3-2. Opening, closing and locking the doors

Op
eration

f each

compo

nen

CAMRY_U

■

Battery-saving function

The battery-saving function will be activated in order to prevent the electronic
key battery and the vehicle battery from being discharged while the vehicle is
not in operation for a long time.

●

In the following situations, the smart key system may take some time to
unlock the doors.

• The electronic key has been left in an area of approximately 6 ft. (2 m) of

the outside of the vehicle for 10 minutes or longer.

• The smart key system has not been used for 5 days or longer.

●

If the smart key system has not been used for 14 days or longer, the doors
cannot be unlocked at any doors except the driver’s door. In this case, take
hold of the driver’s door handle, or use the wireless remote control or the
mechanical key, to unlock the doors.

■

Electronic Key Battery-Saving Function

When battery-saving mode is set, battery depletion is minimized by stopping
the electronic key from receiving radio waves.

■

Conditions affecting operation

The smart key system, wireless remote control and engine immobilizer sys-
tem use weak radio waves. In the following situations, the communication
between the electronic key and the vehicle may be affected, preventing the
smart key system, wireless remote control and engine immobilizer system
from operating properly. (Ways of coping:



●

When the electronic key battery is depleted

●

Near a TV tower, electric power plant, gas station, radio station, large dis-
play, airport or other facility that generates strong radio waves or electrical
noise

●

When the electronic key is in contact with, or is covered by the following
metallic objects

• Cards to which aluminum foil is attached
• Cigarette boxes that have aluminum foil inside
• Metallic wallets or bags
• Coins
• Hand warmers made of metal
• Media such as CDs and DVDs

Press

twice while pressing and

holding

. Confirm that the electronic

key indicator flashes 4 times.
While the battery-saving mode is set, the
smart key system cannot be used. To
cancel the function, press any of the elec-
tronic key buttons.

164

3-2. Opening, closing and locking the doors

CAMRY_U

●

When other wireless keys (that emit radio waves) are being used nearby

●

When carrying the electronic key together with the following devices that
emit radio waves

• Portable radio, cellular phone, cordless phone or other wireless commu-

nication devices

• Another vehicle’s electronic key, another electronic key of your vehicle, or

a wireless key that emits radio waves

• Personal computers or personal digital assistants (PDAs)
• Digital audio players
• Portable game systems

●

If window tint with a metallic content or metallic objects are attached to the
rear window

●

When the electronic key is placed near a battery charger or electronic
devices

●

When the vehicle is parked in a pay parking spot where radio waves are
emitted.

■

Note for the entry function

●

Even when the electronic key is within the effective range (detection areas),
the system may not operate properly in the following cases:

• The electronic key is too close to the window or outside door handle, near

the ground, or in a high place when the doors are locked or unlocked.

• The electronic key is near the ground or in a high place, or too close to

the rear bumper center when the trunk is opened.

• The electronic key is on the instrument panel, rear package tray or floor,

or in the door pockets or glove box when the engine is started or engine
switch modes are changed.

●

Do not leave the electronic key on top of the instrument panel or near the
door pockets when exiting the vehicle. Depending on the radio wave recep-
tion conditions, it may be detected by the antenna outside the cabin and the
door will become lockable from the outside, possibly trapping the electronic
key inside the vehicle.

●

As long as the electronic key is within the effective range, the doors may be
locked or unlocked by anyone. However, only the doors detecting the elec-
tronic key can be used to unlock the vehicle.

●

Even if the electronic key is not inside the vehicle, it may be possible to start
the engine if the electronic key is near the window.

●

The doors may unlock or lock if a large amount of water splashes on the
door handle, such as in the rain or in a car wash, when the electronic key is
within the effective range. (The doors will automatically be locked after
approximately 60 seconds if the doors are not opened and closed.)

165

3-2. Opening, closing and locking the doors

Op
eration

f each

compo

nen

CAMRY_U

●

If the wireless remote control is used to lock the doors when the electronic
key is near the vehicle, there is a possibility that the door may not be
unlocked by the entry function. (Use the wireless remote control to unlock
the doors.)

●

Touching the door lock sensor while wearing gloves may delay or prevent
lock operation. Remove the gloves and touch the lock sensor again.

●

When the lock operation is performed using the lock sensor, recognition sig-
nals will be shown up to two consecutive times. After this, no recognition
signals will be given.

●

If the door handle becomes wet while the electronic key is within the effec-
tive range, the door may lock and unlock repeatedly. In this case, follow the
following correction procedures to wash the vehicle:

• Place the electronic key in a location 6 ft. (2 m) or more away from the

vehicle. (Take care to ensure that the key is not stolen.)

• Set the electronic key to battery-saving mode to disable the smart key

system. (



P. 163)

●

If the electronic key is inside the vehicle and a door handle becomes wet
during a car wash, a message may be shown on the multi-information dis-
play and a buzzer will sound outside the vehicle. To turn off the alarm, lock
all the doors.

●

The lock sensor may not work properly if it comes into contact with ice,
snow, mud, etc. Clean the lock sensor and attempt to operate it again.

●

A sudden approach to the effective range or door handle may prevent the
doors from being unlocked. In this case, return the door handle to the origi-
nal position and check that the doors unlock before pulling the door handle
again.

●

If there is another electronic key in the detection area, it may take slightly
longer to unlock the doors after the door handle is gripped.

●

Fingernails may scrape against the door during operation of the door han-
dle. Be careful not to injure fingernails or damage the surface of the door.

: This setting can be customized at your Toyota dealer.

166

3-2. Opening, closing and locking the doors

CAMRY_U

■

When the vehicle is not driven for extended periods

●

To prevent theft of the vehicle, do not leave the electronic key within 6 ft. (2

m) of the vehicle.

●

The smart key system can be deactivated in advance. (

●

Setting the electronic key to battery-saving mode helps to reduce key bat-

tery depletion. (

P. 163)

■

To operate the system properly

Make sure to carry the electronic key when operating the system. Do not get

the electronic key too close to the vehicle when operating the system from the

outside of the vehicle.
Depending on the position and holding condition of the electronic key, the key

may not be detected correctly and the system may not operate properly. (The

alarm may go off accidentally, or the door lock prevention function may not

operate.)

■

If the smart key system does not operate properly

●

Locking and unlocking the doors and trunk: Use the mechanical key.

(



●

Starting the engine:



P. 560

■

Customization

Some functions can be customized. (



■

If the smart key system has been deactivated in a customized setting

●

Locking and unlocking the doors and opening the trunk:

Use the wireless remote control or mechanical key. (



P. 148, 157, 559)

●

Starting the engine and changing engine switch modes:



P. 560

●

Stopping the engine:



P. 212

WARNING

■

Caution regarding interference with electronic devices

●

People with implantable cardiac pacemakers, cardiac resynchronization

therapy-pacemakers or implantable cardioverter defibrillators should keep

away from the smart key system antennas. (



P. 161)

The radio waves may affect the operation of such devices. If necessary,

the entry function can be disabled. Ask your Toyota dealer for details, such

as the frequency of radio waves and timing of the emitted radio waves.

Then, consult your doctor to see if you should disable the entry function.

●

Users of any electrical medical device other than implantable cardiac

pacemakers, cardiac resynchronization therapy-pacemakers or implant-

able cardioverter defibrillators should consult the manufacturer of the

device for information about its operation under the influence of radio

waves.

Radio waves could have unexpected effects on the operation of such

medical devices.

Ask your Toyota dealer for details for disabling the entry function.

167

Op
eration

f each

compo

nen

CAMRY_U

3-3. Adjusting the seats



Manual seat

Seat position adjustment lever

Seatback angle adjustment
lever

Vertical height adjustment lever



Power seat

Seat position adjustment switch

Seatback angle adjustment
switch

Seat cushion (front) angle
adjustment switch

Vertical height adjustment
switch

Lumbar support adjustment
switch (driver’s side only)

Front seats

Adjustment procedure

168

3-3. Adjusting the seats

CAMRY_U

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat position to ensure that other passen-

gers are not injured by the moving seat.

●

Do not put your hands under the seat or near the moving parts to avoid

injury.

Fingers or hands may become jammed in the seat mechanism.

●

Make sure to leave enough space around the feet so they do not get stuck.

■

Seat adjustment

●

Be careful that the seat does not hit passengers or luggage.

●

To reduce the risk of sliding under the lap belt during a collision, do not

recline the seat more than necessary.

If the seat is too reclined, the lap belt may slide past the hips and apply

restraint forces directly to the abdomen, or your neck may contact the

shoulder belt, increasing the risk of death or serious injury in the event of

an accident.

Adjustments should not be made while driving as the seat may unexpect-

edly move and cause the driver to lose control of the vehicle.

●

Manual seat only: After adjusting the seat, make sure that the seat is

locked in position.

NOTICE

■

When adjusting a front seat

When adjusting a front seat, make sure that the head restraint does not

contact the headliner. Otherwise, the head restraint and headliner may be

damaged.

170

3-3. Adjusting the seats

CAMRY_U

WARNING

■

When folding the seatbacks down

Observe the following precautions. Failure to do so may result in death or

serious injury.

●

Do not fold the seatbacks down while driving.

●

Stop the vehicle on level ground, set the parking brake and shift the shift

lever to P.

●

Do not allow anyone to sit on a folded seatback or in the trunk while driv-

ing.

●

Do not allow children to enter the trunk.

■

When returning the seat to its original position

●

Ensure that the seat belt does not get caught between or behind the seats.

●

If the seat belt has been released from its guide, pass the seat belt through

its guide. (



P. 32)

■

Seat adjustment

Be careful not to get hands or feet pinched between the rear console box

and the rear seat when folding down the rear seatback.

■

After returning the seatback to the upright position

Observe the following precautions. Failure to do so may result in death or

serious injury.

●

Make sure the seatback is securely locked by pressing it forward and rear-

ward on the top.

●

Check that the seat belts are not twisted or caught in the seatback.

●

Make sure that the seat belt is passed through its guide.

NOTICE

■

When the right seatback is folded down

Make sure the luggage loaded in the enlarged trunk will not damage the

webbing of the rear center seat belt.

171

3-3. Adjusting the seats

Op
eration

f each

compo

nen

CAMRY_U



Adjustable type

Pull the head restraint up.

Down

Push the head restraint down while
pressing the lock release button.



Integrated type

Head restraints cannot be adjusted or removed.

■

Removing the head restraints

Head restraints

Head restraints are provided for all seats.

Lock release button

Pull the head restraint up while pressing
the lock release button.

Front seats: If the head restraint touches
the ceiling, making the removal difficult,
change the seat height or angle.
(

P. 167)

Lock
release
button

172

3-3. Adjusting the seats

CAMRY_U

■

Installing the head restraints



Front seats



Rear seats

■

Adjusting the height of the head restraints

Align the head restraint with the installa-

tion holes and push it down to the lock

position.

Press and hold the lock release button

when lowering the head restraint.

Align the head restraint with the installa-

tion holes and push it down to the lowest

lock position while pressing the lock

release button.

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

WARNING

■

Head restraint precautions

Observe the following precautions regarding the head restraints. Failure to

do so may result in death or serious injury.

●

Use the head restraints designed for each respective seat.

●

Adjust the head restraints to the correct position at all times.

●

After adjusting the head restraints, push down on them and make sure

they are locked in position.

●

Do not drive with the head restraints removed.

(However, if a head restraint interferes with installation of a child restraint

system, the head restraint can be removed to accommodate the child

restraint system:

→

P. 56)

Lock release

button

Lock release

button

173

Op
eration

f each

compo

nen

CAMRY_U

3-4. Adjusting the steering wheel and mirrors

Hold the steering wheel and
push the lever down.

Adjust to the ideal position by
moving the steering wheel hori-
zontally and vertically.

After adjustment, pull the lever up
to secure the steering wheel.

To sound the horn, press on or
close to the

mark.

Steering wheel

Adjustment procedure

Horn

174

3-4. Adjusting the steering wheel and mirrors

CAMRY_U

WARNING

■

Caution while driving

Do not adjust the steering wheel while driving.

Doing so may cause the driver to mishandle the vehicle and cause an acci-

dent, resulting in death or serious injury.

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.

Otherwise, the steering wheel may move suddenly, possibly causing an

accident, and resulting in death or serious injury. Also, the horn may not

sound if the steering wheel is not securely locked.

175

3-4. Adjusting the steering wheel and mirrors

Op
eration

f each

compo

nen

CAMRY_U

The height of the rear view mirror can be adjusted to suit your driving
posture.

Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.

Normal position

Anti-glare position

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

176

3-4. Adjusting the steering wheel and mirrors

CAMRY_U



Auto anti-glare inside rear view mirror

Responding to the level of brightness of the headlights of vehicles

behind, the reflected light is automatically reduced.
Changing automatic anti-glare

function mode
On/off

When the automatic anti-glare

function is in ON mode, the indica-

tor illuminates.
The function will set to ON mode

each time the engine switch is

turned to IGNITION ON mode.

Pressing the button turns the func-

tion to OFF mode. (The indicator

also turns off.)

■

To prevent sensor error (vehicles with an auto anti-glare inside rear view

mirror)

Indicator

To ensure that the sensors operate prop-

erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and cause an accident,

resulting in death or serious injury.

177

3-4. Adjusting the steering wheel and mirrors

Op
eration

f each

compo

nen

CAMRY_U

■

When using the outside rear view mirrors in a cold weather

When it is cold and the outside rear view mirrors are frozen, it may not be
possible to fold/extend them or adjust the mirror surface. Remove the ice,
snow, etc. covering the outside rear view mirrors.

To select a mirror to adjust, turn
the switch.

Left

Right

To adjust the mirror, operate the
switch.

Right

Down

Left

Push the mirror back in the direc-
tion of the vehicle’s rear.

Outside rear view mirrors

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjustment procedure

Folding the mirrors

178

3-4. Adjusting the steering wheel and mirrors

CAMRY_U

■

Mirror angle can be adjusted when



Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.



Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

■

When the mirrors are fogged up (vehicles with outside rear view mirror

defoggers)

The outside rear view mirrors can be cleared using the mirror defoggers. Turn

on the rear window defogger to turn on the outside rear view mirror defog-

gers. (



P. 383, 389, 397)

WARNING

■

Important points while driving

Observe the following precautions while driving.

Failure to do so may result in loss of control of the vehicle and cause an

accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly

adjusted before driving.

■

When a mirror is moving

To avoid personal injury and mirror malfunction, be careful not to get your

hand caught by the moving mirror.

■

When the mirror defoggers are operating (vehicles with outside rear

view mirror defoggers)

Do not touch the rear view mirror surfaces, as they can become very hot

and burn you.

179

Op
eration

f each

compo

nen

CAMRY_U

3-5. Opening and closing the windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing

One-touch closing

Opening

One-touch opening

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

This function can be used to prevent children from accidentally open-
ing or closing a passenger window.

Press the switch.

The indicator will come on and the
passenger windows will be locked.

The passenger windows can still
be opened and closed using the
driver’s switch even if the lock
switch is on.

■

The power windows can be operated when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

Power windows

Opening and closing procedures

Preventing accidental operation (window lock switch)

Indicator

180

3-5. Opening and closing the windows

CAMRY_U

■

Operating the power windows after turning the engine off



Vehicles without a smart key system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.



Vehicles with a smart key system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

■

Jam protection function

If an object becomes jammed between the window and the window frame
while the window is closing, window movement is stopped and the window is
opened slightly.

■

Catch protection function

If an object becomes caught between the door and window while the window
is opening, window movement is stopped.

■

When the window cannot be opened or closed

When the jam protection function or catch protection function operates
unusually and the door window cannot be opened or closed, perform the fol-
lowing operations with the power window switch of that door.

●

Vehicles without a smart key system: Stop the vehicle. With the engine
switch in the “ON” position, within 4 seconds of the jam protection function
or catch protection function activating, continuously operate the power win-
dow switch in the one-touch closing direction or one-touch opening direction
so that the door window can be opened and closed.

Vehicles with a smart key system: Stop the vehicle. With the engine switch
in IGNITION ON mode, within 4 seconds of the jam protection function or
catch protection function activating, continuously operate the power win-
dow switch in the one-touch closing direction or one-touch opening direc-
tion so that the door window can be opened and closed.

181

3-5. Opening and closing the windows

Op
eration

f each

compo

nen

CAMRY_U

●

If the door window cannot be opened and closed even when performing the
above operations, perform the following procedure for function initialization.

Vehicles without a smart key system:
Turn the engine switch to the “ON” position.

Vehicles with a smart key system:
Turn the engine switch to IGNITION ON mode.

Pull and hold the power window switch in the one-touch closing direction
and completely close the door window.

Release the power window switch for a moment, resume pulling the
switch in the one-touch closing direction, and hold it there for approxi-
mately 6 seconds or more.

Press and hold the power window switch in the one-touch opening direc-
tion. After the door window is completely opened, continue holding the
switch for an additional 1 second or more.

Release the power window switch for a moment, resume pushing the
switch in the one-touch opening direction, and hold it there for approxi-
mately 4 seconds or more.

Pull and hold the power window switch in the one-touch closing direction
again. After the door window is completely closed, continue holding the
switch for a further 1 second or more.

If you release the switch while the window is moving, start again from the
beginning.

If the window reverses and cannot be fully closed or opened, have the vehicle
inspected by your Toyota dealer.

■

Door lock linked window operation

●

Vehicles without a smart key system: The power windows can be opened
and closed using the key.

(



P. 149)

Vehicles with a smart key system: The power windows can be opened and
closed using the mechanical key.

(

●

The power windows can be opened using the wireless remote control.

(

P. 148)

: These settings must be customized at your Toyota dealer.

■

Alarm

The alarm may be triggered if the alarm is set and a power window is closed
using the door lock linked power window operation function. (



P. 83)

■

Power windows open warning buzzer

A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the power windows open.

■

Customization

Some functions can be customized. (



182

3-5. Opening and closing the windows

CAMRY_U

WARNING

Observe the following precautions.

Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the

operation for the passengers. In order to prevent accidental operation,

especially by a child, do not let a child operate the power windows. It is

possible for children and other passengers to have body parts caught in

the power window. Also, when riding with a child, it is recommended to use

the window lock switch.(

P. 179)

●

When using the wireless remote control, key or mechanical key and oper-

ating the power windows, operate the power window after checking to

make sure that there is no possibility of any passenger having any of their

body parts caught in the window. Also do not let a child operate window by

the wireless remote control, key or mechanical key. It is possible for chil-

dren and other passengers to get caught in the power window.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit

the vehicle along with the child. There may be accidental operation, due to

mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection

function.

●

The jam protection function may not work if something gets jammed just

before the window is fully closed. Be careful not to get any part of your

body jammed in the window.

■

Catch protection function

●

Never use any part of your body or clothing to intentionally activate the

catch protection function.

●

The catch protection function may not work if something gets caught just

before the window is fully opened. Be careful not to get any part of your

body or clothing caught in the window.

●

Check to make sure that all passengers

do not have any part of their body in a

position where it could be caught when

a window is being operated.

183

3-5. Opening and closing the windows

Op
eration

f each

compo

nen

CAMRY_U

Opens the moon roof

The moon roof stops slightly before
the fully open position to reduce
wind noise.

Press the switch again to fully open
the moon roof.

Closes the moon roof

: Lightly press either side of the

moon roof switch to stop the moon
roof partway.

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either side of the

moon roof switch to stop the moon
roof partway.

Moon roof



: If equipped

Use the overhead switches to open and close the moon roof and
tilt it up and down.

Opening and closing

Tilting up and down

184

3-5. Opening and closing the windows

CAMRY_U

■

The moon roof can be operated when



Vehicles without a smart key system

The engine switch is in the “ON” position.



Vehicles with a smart key system

The engine switch is in IGNITION ON mode.

■

Operating the moon roof after turning the engine off



Vehicles without a smart key system

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.



Vehicles with a smart key system

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to ACCESSORY mode or turned off. It cannot, how-
ever, be operated once either front door is opened.

■

Jam protection function

If an object is detected between the moon roof and the frame while the moon
roof is closing or tilting down, travel is stopped and the moon roof opens
slightly.

■

Sunshade

The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

■

Door lock linked moon roof operation

●

Vehicles without a smart key system: The moon roof can be opened and
closed using the key.

(



P. 149)

Vehicles with a smart key system: The moon roof can be opened and
closed using the mechanical key.

(



●

The moon roof can be opened using the wireless remote control.

(



P. 148)

: These settings must be customized at your Toyota dealer.

185

3-5. Opening and closing the windows

Op
eration

f each

compo

nen

CAMRY_U

■

When the moon roof does not close normally

Perform the following procedure:

●

If the moon roof closes but then re-opens slightly

Stop the vehicle.

Press and hold the “CLOSE” switch.

The moon roof will close, reopen and pause for approximately 10 sec-
onds.

Then it will close again, tilt up and pause for approximately 1 sec-

ond. Finally, it will tilt down, open and close.

Check to make sure that the moon roof is completely closed and then
release the switch.

●

If the moon roof tilts down but then tilts back up

Stop the vehicle.

Press and hold the “UP” switch

until the moon roof moves into the tilt

up position and stops.

Release the “UP” switch once and then press and hold the “UP” switch
again.

The moon roof will pause for approximately 10 seconds in the tilt up posi-
tion.

Then it will adjust slightly and pause for approximately 1 second.

Finally, it will tilt down, open and close.

Check to make sure that the moon roof is completely closed and then
release the switch.

: If the switch is released at the incorrect time, the procedure will have to

be performed again from the beginning.

: If the switch is released after the above mentioned 10 second pause,

automatic operation will be disabled. In that case, press and hold the
“CLOSE” or “UP” switch, and the moon roof will tilt up and pause for
approximately 1 second. Then it will tilt down, open and close. Check to
make sure that the moon roof is completely closed and then release the
switch.

If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by your Toyota dealer.

■

Alarm

The alarm may be triggered if the alarm is set and the moon roof is closed
using the door lock linked moon roof operation function. (



P. 83)

■

Moon roof open warning buzzer

A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver's
door is opened with the moon roof open.

■

Customization

Some functions can be customized. (



186

3-5. Opening and closing the windows

CAMRY_U

WARNING

Observe the following precautions.

Failure to do so may cause death or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to put their hands or heads outside the vehi-

cle while it is moving.

●

Do not sit on top of the moon roof.

■

Closing the moon roof

●

The driver is responsible for moon roof opening and closing operations.

In order to prevent accidental operation, especially by a child, do not let a

child operate the moon roof. It is possible for children and other passen-

gers to have body parts caught in the moon roof.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit

the vehicle along with the child. There may be accidental operation, due to

mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection

function.

●

The jam protection function may not work if something gets caught just

before the moon roof is fully closed. Also, the jam protection function is not

designed to operate while the switch is being pressed. Take care so that

your fingers, etc. do not get caught.

●

Check to make sure that all passengers

do not have any part of their body in a

position where it could be caught when

the moon roof is being operated.

●

When using the wireless remote con-

trol, key or mechanical key and operat-

ing the moon roof, operate the moon

roof after checking to make sure that

there is no possibility of any passenger

having any of their body parts caught in

the moon roof. Also, do not let a child

operate moon roof by the wireless

remote control, key or mechanical key.

It is possible for children and other pas-

sengers to get caught in the moon roof.

187

3-5. Opening and closing the windows

Op
eration

f each

compo

nen

CAMRY_U

Opens the electronic sunshade

Slide and hold the

switch

backward. The electronic sun-
shade will fully open automati-

cally.

Closes the electronic sunshade

Slide and hold the

switch for-

ward. The electronic sunshade will

fully close automatically.

: Quickly slide and release the

switch in either direction to stop the

electronic sunshade partway.

Tilts the panoramic moon roof up
(press)

When the panoramic moon roof is
tilted up, the electronic sunshade
will open to the half-open position
of the roof.

: Lightly press the

switch

again to stop the panoramic moon
roof partway.

Tilts the panoramic moon roof down (press and hold)

The panoramic moon roof can be tilted down only when it is in the tilt-up
position.

Panoramic moon roof



: If equipped

Use the overhead switches to operate the panoramic moon roof
and electronic sunshade.

Opening and closing the electronic sunshade

Tilting the panoramic moon roof up and down

188

3-5. Opening and closing the windows

CAMRY_U

Opens the panoramic moon roof

Slide and hold the

switch

backward. The panoramic moon
roof and electronic sunshade will
open automatically.

The panoramic moon roof can be
opened from the tilt-up position.

: Quickly slide and release the

switch in either direction to stop the
panoramic moon roof partway.

Closes the panoramic moon roof

Slide and hold the

switch

forward. The panoramic moon
roof will fully close automatically.

■

The panoramic moon roof can be operated when

The engine switch is in IGNITION ON mode.

■

Operating the panoramic moon roof after turning the engine off

The panoramic moon roof and electronic sunshade can be operated for
approximately 45 seconds after the engine switch is turned to ACCESSORY
mode or turned off. They cannot, however, be operated once either front door
is opened.

■

Jam protection function

If an object is detected between the panoramic moon roof and the frame in
the following situations, travel is stopped and the panoramic moon roof opens
slightly:

●

The panoramic moon roof is closing or tilting down.

●

The electronic sunshade is closing.

■

Door lock linked panoramic

moon roof operation

●

The panoramic moon roof can be opened and closed using the mechanical

key.

(



●

The panoramic moon roof can be opened using the wireless remote con-

trol.

(



P. 148)

: These settings must be customized at your Toyota dealer.

Opening and closing the panoramic moon roof

189

3-5. Opening and closing the windows

Op
eration

f each

compo

nen

CAMRY_U

■

Closing both the panoramic moon roof and electronic

sunshade

Slide the

switch forward.

The electronic sunshade will close to the half-open position and pause. The
panoramic moon roof will then fully close. Then the electronic sunshade will
fully close.

■

When the panoramic moon roof or electronic

sunshade does not close

normally

Perform the following procedure:

Stop the vehicle.

Turn the engine switch to IGNITION ON mode.

Slide and hold the

switch or

switch forward. Continue pressing

the switch for approximately 10 seconds after the panoramic moon roof or
electronic sunshade closes and reopens. The panoramic moon roof and
electronic sunshade will start to close.

Check that the panoramic moon roof and electronic sunshade are fully
closed and release the switch.

: If the switch is released at the incorrect time, the procedure will have to be

performed again from the beginning.

If the panoramic moon roof or electronic sunshade does not fully close even
after performing the above procedure correctly, have the vehicle inspected by
your Toyota dealer.

■

Alarm

The alarm may be triggered if the alarm is set and the panoramic moon roof is
closed using the door lock linked panoramic moon roof operation function.
(

P. 83)

■

Panoramic moon roof open warning buzzer

A buzzer sounds and a message is shown on the multi-information display in
the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the panoramic moon roof open.

■

Customization

Some functions can be customized. (


