97

2. Instrument cluster

2

Instrum

ent

clus
ter

CAMRY_U

NOTICE

■

To prevent damage to the engine and its components

●

Do not let the indicator needle of the tachometer enter the red zone, which

indicates the maximum engine speed.

●

The engine may be overheating if the engine coolant temperature gauge is

in the red zone (H). In this case, immediately stop the vehicle in a safe

place, and check the engine after it has cooled completely. (



P. 567)

98

2. Instrument cluster

CAMRY_U

The multi-information display presents the driver with a variety of driv-
ing-related data, such as the current outside temperature. The multi-
information display can also be used to change the display settings
and other settings.

Shift position (



P. 217)

Menu icon display area

Displays the following items.
When a menu icon is not selected, the outside temperature and clock are
displayed.

• Menu icons (



P. 100)

• Outside temperature (



P. 94)

• Clock

*

*

: For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM

OWNER’S MANUAL”.

Content display area

A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.

• Menu icon content (



P. 100)

• Suggestion function (



P. 108)

• Warning message (



P. 538)

Odometer/trip meter (



P. 108)

Indicators (



P. 88)

Multi-information display (4.2-inch display)

Summary of functions

1

2

3

4

5

99

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

RSA (Road Sign Assist) (if equipped) (



P. 285)

“ODO/TRIP” switch (



P. 99)

Meter control switches (



P. 99)

◆

Using the content display area

The content display area is operated using the meter control
switches.

Scroll screens

*

, change the

displayed content

*

 and move

the cursor

Press: Enter/Set

Press and hold: Reset

Return to the previous
screen

Pressing and holding the switch
will display the first screen of the
selected menu icon.

Call sending/receiving and history display

Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to “NAVIGA-
TION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

*

: When the screen can be scrolled or different content can be displayed,

a mark, such as an arrow, will be displayed to suggest which switch to
operate.

◆

Using the odometer/trip meter

Items in this area are operated using the “ODO/TRIP” switch.

Press: Change displayed item

Each time the switch is pressed,
the displayed item will be
changed.

Press and hold: Reset

Display the desired trip meter
and press and hold the switch to
reset the trip meter.

Using the multi-information display

6

7

8

1

2

3

4

100

2. Instrument cluster

CAMRY_U

Select a menu icon to display its content.

Drive information (



P. 101)

Select to display various drive data.

Audio system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Driving assist system information

Select to display the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (if equipped)

(



P. 290)

• Dynamic radar cruise control (if equipped) (



P. 306)

• LTA (Lane Tracing Assist) (



P. 270)

• RSA (Road Sign Assist) (if equipped) (



P. 285)

Warning message display (



P. 538)

Select to display warning messages and measures to be taken if a mal-
function is detected.

Settings display (



P. 103)

Select to change the meter display settings and other settings.

Menu icons

101

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

Trip (after start)

Average fuel economy

*

Displays the average fuel con-
sumption since engine start.

Average vehicle speed

Displays the average vehicle
speed since engine start.

Elapsed time

Displays the time elapsed since
engine start.

*

: Use the displayed fuel consumption as a reference only.

■

Total (after reset)

Current fuel consumption

Displays the instantaneous cur-
rent fuel consumption.

Average fuel economy

*

1, 2

Displays the average fuel con-
sumption since the display was
reset.

Average vehicle speed/
Elapsed time

*

1

Displays the average vehicle speed since reset or elapsed time since

reset, as selected in

. (



P. 103)

*

1

: Pressing and holding

 will reset the average fuel consumption and

average vehicle speed/elapsed time.

*

2

: Use the displayed fuel consumption as a reference only.

Drive information (

)

1

2

3

1

2

3

102

2. Instrument cluster

CAMRY_U

■

Tank (after refuel)

Driving range

*

1, 2

Displays the driving range with
remaining fuel.

Average fuel economy

*

1, 3

Displays the average fuel con-
sumption since the vehicle was
refueled.

*

1

: When only a small amount of fuel is added to the tank, the display may

not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.

*

2

: This distance is computed based on your average fuel consumption. As

a result, the actual distance that can be driven may differ from that dis-
played.

*

3

: Use the displayed fuel consumption as a reference only.

■

Eco Driving Indicator



P. 109

■

Speedometer

Displays the vehicle speed.

■

Tire pressure (vehicles with a tire inflation pressure display
function)



P. 474

■

Blank (No items)

Displays no drive information contents.

1

2

103

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

◆

Changing settings

Use the meter control switches on the steering wheel to change
settings.

Press

 or

 to select

.

Operate the switches to select a desired item.

Change the setting by referring to the message displayed on the
screen.

◆

Setting items

■

 LTA (Lane Tracing Assist) (



P. 270)

The following LTA system settings can be changed:

Settings display (

)

1

2

3

Item

Settings

Details

Lane center

On

Select to enable/disable the lane
centering function.

Off

Alert sensitivity

High

Select to set the warning sensi-
tivity.

Std.

Sway warning

On

Select to enable/disable the vehi-
cle sway warning.

Off

Sway sensitivity

High

Select to set the vehicle sway
warning sensitivity.

Std.

Low

104

2. Instrument cluster

CAMRY_U

■

 PCS (Pre-Collision System) (



P. 254)

The following pre-collision system settings can be changed:

■

 DRCC (Dynamic Radar Cruise Control) (



P. 290, 306)

■

 BSM (Blind Spot Monitor) function (if equipped) (



P. 330)

■

RCTA (Rear Cross Traffic Alert) function (if equipped)
(



P. 345)

■

RCD (Rear Camera Detection) function (if equipped) (



P. 354)

Item

Settings

Details

PCS

On

Select to enable/disable the pre-
collision system.

Off

Warning sensitivity

 Early

Select to change the warning
timing.

 Middle

 Late

Item

Settings

Details

Curve speed
reduction

 Strong

Select to change the vehicle
speed reduction strength.

 Weak

Off

Item

Settings

Details

BSM

On

Select to enable/disable the
Blind Spot Monitor function.

Off

Item

Settings

Details

RCTA

On

Select to enable/disable the Rear
Cross Traffic Alert function.

Off

Item

Settings

Details

RCD

On

Select to enable/disable the rear
camera detection.

Off

105

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

 RSA (Road Sign Assist) (if equipped) (



P. 285)

The following RSA settings can be changed:

Item

Settings

Details

RSA

On

Select to enable/disable the
RSA.

Off

Notification method

Excess speed
notification

Select a notification method used
to warn the driver if the vehicle
speed exceeds the speed dis-
played on the speed limit sign on
the multi-information display.
Available methods:
• No notification
• Display only
• Display and buzzer

Other notifications

Select a notification method used
to warn the driver if the system
detects the vehicle approaching
to the no-entry road when a do
not enter sign is displayed on the
multi-information display.
Available methods:
• No notification
• Display only
• Display and buzzer

Excess speed noti-
fication level

5 mph (10 km/h)

Select a speed threshold over
which the excess speed notifica-
tion will start to operate when a
speed limit sign is displayed on
the multi-information display.

3 mph (5 km/h)

1 mph (2 km/h)

106

2. Instrument cluster

CAMRY_U

■

Vehicle settings

Item

Settings

Details

 BSM (Blind Spot Monitor) (if equipped) (



P. 330)

Outside rear view
mirror indicator
brightness

Bright

Select to change the brightness
of the outside rear view mirror
indicators.

Dim

Notification timing
for presence of
approaching vehi-
cle (sensitivity)

 Early

Select to change the notification
timing for an approaching vehi-
cle.

 Middle

 Late

Only when vehicle
detected in blind
spot

RCTA (Rear Cross Traffic Alert) (if equipped) (



P. 345)

RCTA buzzer vol-
ume

1 (Low)

Select to change the volume of
the RCTA buzzer.

2 (Medium)

3 (Loud)

TPWS (Tire pressure warning system) (



P. 474)

Set pressure (tire pressure warning sys-
tem initialization)

Select to initialize the tire pres-
sure warning system. To per-
form initialization, press and hold

the

switch.

Before performing initialization,
make sure to adjust the inflation
pressure of each tire to the spec-
ified level. (



P. 475)

Change wheel (change the tire pres-
sure warning system sensor ID code
set)
(vehicles without a tire inflation pres-
sure display function)

Select to change the tire pres-
sure warning system sensor ID
code set.
To enable this function, a second
set of tire pressure warning sys-
tem sensor ID codes must be
registered by a Toyota dealer.
For information regarding chang-
ing the registered ID code set,
contact your Toyota dealer.
(



P. 477)

107

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

Meter settings

Change wheel (register tire pressure
warning system sensor ID codes)
(vehicles with a tire inflation pressure
display function)

Select to register the ID codes of
the tire pressure sensors to the
tire pressure warning system.
To register the ID codes, press

and hold the

 switch.

(



P. 477)

Rear seat reminder
(



P. 154)

On

Select to enable/disable the rear
seat reminder.

Off

Scheduled maintenance display (if equipped)

Maintenance data reset

Select to reset the message indi-
cating maintenance is required,
after the required maintenance is
performed. (



P. 448)

Item

Settings

Details

Item

Settings

Details

Language

Select to change the language
displayed.

Units

Select to change the units of
measure displayed.

 (Eco Driving

Indicator Light)

On

Select to enable/disable the Eco
Driving Indicator Light. (



P. 109)

Off

Drive information
(total [after reset])

Average vehicle
speed

Select to change the display
between average speed/elapsed
time.

Elapsed time

Pop-up display

Incoming calls

Select to enable/disable the pop-
up display.

Brightness adjust-
ment

Default setting

Select to reset the meter display
settings to the default setting.

108

2. Instrument cluster

CAMRY_U

■

Odometer

Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B

Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and dis-
play different distances independently.

To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.

Displays suggestions to the driver in the following situations. To select
a response to a displayed suggestion, use the meter control switches.

The suggestion function can be turned on/off.
(Customizable features:



P. 606)

■

Suggestion to turn off the headlights

If the headlights are left on for a certain amount of time after the
engine switch has been turned off, if the headlight switch is in the
“AUTO” position, a suggestion message will be displayed asking if
you wish to turn the headlights off. To turn the headlights off, select
“Yes”.

If a front door is opened after the engine switch is turned off, this sug-
gestion message will not be displayed.

Odometer/trip meter

Suggestion function

109

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

Eco Driving Indicator

Eco Driving Indicator will not operate under the following conditions:

●

The shift lever is in any position other than D.

●

A paddle shift switch (if equipped) is operated.

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings,
park the vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be
suspended.

■

Tire pressure (vehicles with a tire inflation pressure display function)

●

It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to the “ON” position (vehicles without a smart key
system) or IGNITION ON mode (vehicles with a smart key system). It may
also take a few minutes to display the tire inflation pressure after inflation
pressure has been adjusted.

●

“---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

■

Customization

Some functions can be customized. (



P. 103, 606)

Eco Driving Indicator Light
During Eco-friendly acceleration (Eco
driving), the Eco Driving Indicator Light
will turn on. When the acceleration
exceeds the Zone of Eco driving, or
when the vehicle is stopped, the light
turns off.

Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with
current Eco driving ratio based on
acceleration.

Eco driving ratio based on acceleration
If the acceleration exceeds the Zone of
Eco driving, the right side of the Eco
Driving Indicator Zone Display will illu-
minate.

Zone of Eco driving

1

2

3

4

110

2. Instrument cluster

CAMRY_U

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra

attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as

you may fail to see pedestrians, objects on the road, etc. ahead of the

vehicle.

■

The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal

information display. At extremely low temperatures, the information display

monitor may respond slowly, and display changes may be delayed.

For example, there is a lag between the driver’s shifting and the new gear

number appearing on the display. This lag could cause the driver to down-

shift again, causing rapid and excessive engine braking and possibly an

accident resulting in death or injury.

■

Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that

the vehicle is parked in a place with adequate ventilation. In a closed area

such as a garage, exhaust gases including harmful carbon monoxide (CO)

may collect and enter the vehicle. This may lead to death or a serious

health hazard.

NOTICE

■

While setting up the display

To prevent battery discharge, ensure that the engine is running while setting

up the display features.

111

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

The multi-information display presents the driver with a variety of driv-
ing-related data, such as the current outside temperature. The multi-
information display can also be used to change the display settings
and other settings.

Indicators (



P. 91)

Driving assist system status display area

Displays the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (if equipped)

(



P. 290)

• Dynamic radar cruise control (if equipped) (



P. 306)

• LTA (Lane Tracing Assist) (



P. 270)

Speed limit display (vehicles with a navigation system)
(U.S.A. only) /RSA (Road Sign Assist) (if equipped) (



P. 285)

Clock

For clock settings, refer to “NAVIGATION AND MULTIMEDIA SYSTEM
OWNER’S MANUAL”.

RSA (Road Sign Assist) (if equipped) (



P. 285)

Speedometer

The speedometer display can be enabled/disabled in

 on the multi-

information display. (



P. 117)

Multi-information display (7-inch display)

Summary of functions

1

2

3

4

5

6

112

2. Instrument cluster

CAMRY_U

Content display area

A variety of information can be displayed by selecting a menu icon. Addi-
tionally, warning or suggestion/advice pop-up displays will be displayed in
some situations.

• Menu icon content (



P. 114)

• Suggestion function (



P. 125)

• Warning message (



P. 538)

Odometer/trip meter (



P. 125)

Shift position (



P. 217)

Outside temperature (



P. 94)

Menu icons (



P. 114)

“ODO/TRIP” switch (



P. 113)

Meter control switches (



P. 113)

7

8

9

10

11

12

13

113

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

◆

Using the content display area

The content display area is operated using the meter control
switches.

Scroll screens

*

, change the

displayed content

*

 and move

the cursor

Press: Enter/Set

Press and hold: Reset/Dis-
play the next screen

Return to the previous
screen

Pressing and holding the switch will display the first screen of the
selected menu icon.

Call sending/receiving and history display

Linked with the hands-free system, sending or receiving call is dis-
played. For details regarding the hands-free system, refer to “NAVIGA-
TION AND MULTIMEDIA SYSTEM OWNER’S MANUAL”.

*

: When the screen can be scrolled or different content can be displayed,

a mark, such as an arrow, will be displayed to suggest which switch to
operate.

◆

Using the odometer/trip meter

Items in this area are operated using the “ODO/TRIP” switch.

Press: Change displayed item

Each time the switch is pressed,
the displayed item will be
changed.

Press and hold: Reset

Display the desired trip meter
and press and hold the switch to
reset the trip meter.

Using the multi-information display

1

2

3

4

114

2. Instrument cluster

CAMRY_U

Select a menu icon to display its content.

Warning message display (



P. 538)

This menu icon will be displayed only when a warning message can be
displayed.
Select to display warning messages and measures to be taken if a mal-
function is detected.

Eco-friendly driving information (



P. 115)

Select to display fuel consumption data in various forms.

Driving assist system information

Select to perform the following:
Display the operational status of the following systems:

• Dynamic radar cruise control with full-speed range (if equipped)

(



P. 290)

• Dynamic radar cruise control (if equipped) (



P. 306)

• LTA (Lane Tracing Assist) (



P. 270)

• RSA (Road Sign Assist) (if equipped) (



P. 285)

Display the following navigation system-linked information (if equipped):

• Route guidance
• Compass display

Audio system-linked display

Select to enable selection of an audio source or track on the meter
using the meter control switches.

Vehicle information

Select to perform the following:
Display the following information:

• Tire inflation pressure (



P. 474)

Enable/Disable the following systems:

• Intuitive parking assist (if equipped) (



P. 336)

• BSM (Blind Spot Monitor) function (if equipped) (



P. 330)

• RCTA (Rear Cross Traffic Alert) function (if equipped) (



P. 345)

This function can also be enabled/disabled on

.

Settings display (



P. 117)

Select to change the meter display settings and other settings.

Menu icons

115

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

Fuel consumption

Current fuel consumption

Displays the instantaneous cur-
rent fuel consumption.

Average fuel economy (after
start)

Displays the average fuel con-
sumption since engine start.

*

1

Driving range

Displays the driving range with remaining fuel.

*

2, 3

Gadget

*

4

The following items can be displayed by changing the settings for gad-

get content and fuel economy type on

. (



P. 117)

Eco-friendly driving information (

)

1

2

3

4

Displayable item

Content

Gadget
content

Fuel economy

type

Average
vehicle
speed

Trip
(after start)

Displays the average vehicle speed since
engine start.

Total
(after reset)

Displays the average vehicle speed since the

display was reset.

*

5

Distance

Trip
(after start)

Displays the distance driven since vehicle
start.

Total
(after reset)

Displays the distance driven since the display

was reset.

*

5

Elapsed
time

Trip
(after start)

Displays the elapsed time since engine start.

Total
(after reset)

Displays the elapsed time since the display

was reset.

*

5

116

2. Instrument cluster

CAMRY_U

Average fuel economy

Displayed item (listed below) can be changed on the fuel economy type

screen of

. (



P. 117)

●

Total (after reset)

Displays the average fuel consumption since the display was reset.

*

1, 5

●

Tank (after refuel)

Displays the average fuel consumption since the vehicle was refu-

eled.

*

1, 2

*

1

: Use the displayed fuel consumption as a reference only.

*

2

: When only a small amount of fuel is added to the tank, the display may

not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.

*

3

: This distance is computed based on your average fuel consumption. As

a result, the actual distance that can be driven may differ from that dis-
played.

*

4

: The default setting is no display.

*

5

: This display can be reset by pressing and holding

 while it is dis-

played.

■

Eco indicator

• Eco Driving Indicator



P. 126

• Driving range

Displays the driving range with remaining fuel.

When only a small amount of fuel is added to the tank, the display may
not be updated.
When refueling, turn the engine switch off. If the vehicle is refueled with-
out turning the engine switch off, the display may not be updated.

This distance is computed based on your average fuel consumption. As
a result, the actual distance that can be driven may differ from that dis-
played.

5

117

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

Speedometer display/Driving range

Speedometer display

Displays the vehicle speed.

Driving range

Displays the driving range with
remaining fuel.

When only a small amount of
fuel is added to the tank, the dis-
play may not be updated.

When refueling, turn the engine
switch off. If the vehicle is refu-
eled without turning the engine
switch off, the display may not
be updated.

This distance is computed based on your average fuel consumption. As
a result, the actual distance that can be driven may differ from that dis-
played.

◆

Changing settings

Use the meter control switches on the steering wheel to change
settings.

Press

 or

 to select

.

Operate the switches to select a desired item.

Press or press and hold

.

The available settings will differ depending on if

 is pressed or

pressed and held. Follow the instructions on the display.

1

2

Settings display (

)

1

2

3

118

2. Instrument cluster

CAMRY_U

◆

Setting items

■

 LTA (Lane Tracing Assist) (



P. 270)

Press and hold

 to change the settings of the following items:

■

 PCS (Pre-Collision System) (



P. 254)

Press and hold

 to change the settings of the following items:

■

 DRCC (Dynamic Radar Cruise Control) (



P. 290, 306)

Press and hold

 to change the settings of the following item:

Item

Settings

Details

Lane center

On

Select to enable/disable the lane
centering function.

Off

Alert sensitivity

High

Select to set the warning sensi-
tivity.

Std.

Sway warning

On

Select to enable/disable the vehi-
cle sway warning.

Off

Sway sensitivity

High

Select to set the vehicle sway
warning sensitivity.

Std.

Low

Item

Settings

Details

PCS

On

Select to enable/disable the pre-
collision system.

Off

Warning sensitivity

 Early

Select to change the warning
timing.

 Middle

 Late

Item

Settings

Details

Curve speed
reduction

 Strong

Select to change the vehicle
speed reduction strength.

 Weak

Off

119

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

 BSM (Blind Spot Monitor) (if equipped) (



P. 330)

Press

 to enable/disable the Blind Spot Monitor function.

Press and hold

 to change the settings of the following item:

■

 RCTA (Rear Cross Traffic Alert) (if equipped) (



P. 345)

Press

 to enable/disable the Rear Cross Traffic Alert function.

Press and hold

 to change the settings of the following item:

Item

Settings

Details

BSM

On

Select to enable/disable the
Blind Spot Monitor function.

Off

Item

Settings

Details

Outside rear view
mirror indicator
brightness

Bright

Select to change the brightness
of the outside rear view mirror
indicators.

Dim

Notification timing
for presence of
approaching vehi-
cle (sensitivity)

 Early

Select to change the notification
timing for an approaching vehi-
cle.

 Middle

 Late

Only when vehicle
detected in blind
spot

Item

Settings

Details

RCTA

On

Select to enable/disable the Rear
Cross Traffic Alert function.

Off

Item

Settings

Details

RCTA buzzer vol-
ume

1 (Low)

Select to change the volume of
the RCTA buzzer.

2 (Medium)

3 (Loud)

120

2. Instrument cluster

CAMRY_U

■

RCD (Rear Camera Detection) function (if equipped) (



P. 354)

Press

 to enable/disable the rear camera detection function.

■

 PKSB (Parking Support Brake) (if equipped) (



P. 360)

Press

to

enable/disable

the Parking Support Brake.

■

 Intuitive parking assist (if equipped) (



P. 336)

Press

 to enable/disable the Intuitive parking assist.

Press and hold

 to change the settings of the following item:

Item

Settings

Details

RCD

On

Select to enable/disable the rear
camera detection.

Off

Item

Settings

Details

PKSB

On

Select to enable/disable the
Parking Support Brake system.

Off

Item

Settings

Details

Intuitive parking
assist

On

Select to enable/disable the intui-
tive parking assist.

Off

Item

Settings

Details

Volume

1 (Low)

Select to change the volume of
the intuitive parking assist
buzzer.

2 (Medium)

3 (Loud)

121

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

 HUD (Head-up display) (if equipped) (



P. 128)

Press

 to enable/disable the head-up display.

Press and hold

 to change the settings of the following items:

Item

Settings

Details

HUD

On

Select to enable/disable the
head-up display.

Off

Item

Settings

Details

HUD Brightness/Position

Select to adjust the brightness/
position of the head-up display.

• Press the

/

 switch to

adjust the display brightness.

• Press the

/

 switch to

adjust the display position.

HUD Driving sup-
port

Tachometer set-
tings

Select to change the display
between the following:
• Eco Driving Indicator
• Tachometer
• No content

Navigation sys-
tem (if equipped)

Select to enable/disable head-up
display content.

Driving Assist

Compass
(if equipped)

Rotation

Select to adjust the angle of the
head-up display.

Press the

/

 switch to

adjust the display angle.

122

2. Instrument cluster

CAMRY_U

■

 RSA (Road Sign Assist) (if equipped) (



P. 285)

Press and hold

 to change the settings of the following items:

Item

Settings

Details

RSA

On

Select to enable/disable the
RSA.

Off

Notification method

Excess speed
notification

Select a notification method used
to warn the driver if the vehicle
speed exceeds the speed dis-
played on the speed limit sign on
the multi-information display.
Available methods:
• No notification
• Display only
• Display and buzzer

Other notifications

Select a notification method used
to warn the driver if the system
detects the vehicle approaching
to the no-entry road when a do
not enter sign is displayed on the
multi-information display.
Available methods:
• No notification
• Display only
• Display and buzzer

Excess speed noti-
fication level

5 mph (10 km/h)

Select a speed threshold over
which the excess speed notifica-
tion will start to operate when a
speed limit sign is displayed on
the multi-information display.

3 mph (5 km/h)

1 mph (2 km/h)

123

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■



Vehicle settings

Press and hold

 to change the settings of the following items:

Item

Settings

Details

TPWS (Tire pressure warning system) (



P. 474)

Set pressure (tire pressure warning sys-
tem initialization)

Select to initialize the tire pres-
sure warning system. To per-
form initialization, press and hold

the

switch.

Before performing initialization,
make sure to adjust the inflation
pressure of each tire to the spec-
ified level. (



P. 475)

Change wheel (change the tire pres-
sure warning system sensor ID code
set)
(vehicles without a tire inflation pres-
sure display function)

Select to change the tire pres-
sure warning system sensor ID
code set.
To enable this function, a second
set of tire pressure warning sys-
tem sensor ID codes must be
registered by a Toyota dealer.
For information regarding chang-
ing the registered ID code set,
contact your Toyota dealer.
(



P. 477)

Change wheel (register tire pressure
warning system sensor ID codes) (vehi-
cles with a tire inflation pressure display
function)

Select to register the ID codes of
the tire pressure sensors to the
tire pressure warning system. To
register the ID codes, press and

hold the

 switch.

(



P. 477)

Rear seat reminder
(



P. 154)

On

Select to enable/disable the rear
seat reminder.

Off

Scheduled maintenance display (if equipped)

Maintenance data reset

Select to reset the message indi-
cating maintenance is required,
after the required maintenance is
performed. (



P. 448)

124

2. Instrument cluster

CAMRY_U

■



Meter settings

Press and hold

 to change the settings of the following items:

*

1

: Selecting this item will only change the gadget.

*

2

: Selecting this item will turn the display of the gadget off.

Item

Settings

Details

Language

Select to change the language
displayed.

Units

Select to change the units of
measure displayed.

 (Eco Driving

Indicator Light)

On

Select to enable/disable the Eco
Driving Indicator Light. (



P. 126)

Off

Speedometer

On

Select to enable/disable the
speedometer display.

Off

Gadget content

Off

No display

Average vehicle
speed

Select to turn the display of a
gadget.

Distance

Elapsed time

Fuel economy type

Trip (after start)

*

1

Select to change the average
fuel consumption display and an
item to be displayed as gadget.

Total (after reset)

Tank
(after refuel)

*

2

Multi-information display off

Select to turn the multi-informa-
tion display off.
To turn the multi-information dis-
play on again, press any direc-

tion switch (

/

/

/

).

Pop-up display

Intersection guid-
ance (if equipped)

Select to enable/disable the pop-
up display.

Incoming calls

Brightness adjust-
ment

Default setting

Select to reset the meter display
settings to the default setting.

125

2. Instrument cluster

2

Instrum

e

nt clus

ter

CAMRY_U

■

Odometer

Displays the total distance the vehicle has been driven.

■

Trip meter A/trip meter B

Displays the distance the vehicle has been driven since the meter
was last reset. Trip meters A and B can be used to record and dis-
play different distances independently.

To reset, display the desired trip meter and press and hold the “ODO/
TRIP” switch.

Displays suggestions to the driver in the following situations. To select
a response to a displayed suggestion, use the meter control switches.

The suggestion function can be turned on/off.
(Customizable features:



P. 606)

■

Suggestion to turn off the headlights

If the headlights are left on for a certain amount of time after the
engine switch has been turned off, if the headlight switch is in the
“AUTO” position, a suggestion message will be displayed asking if
you wish to turn the headlights off. To turn the headlights off, select
“Yes”.

If a front door is opened after the engine switch is turned off, this sug-
gestion message will not be displayed.

Odometer/trip meter

Suggestion function

126

2. Instrument cluster

CAMRY_U

■

Eco Driving Indicator

Eco Driving Indicator will not operate under the following conditions:

●

The shift lever is in any position other than D.

●

A paddle shift switch (if equipped) is operated.

●

Neither normal mode nor Eco drive mode is selected. (



P. 375)

●

The vehicle speed is approximately 80 mph (130 km/h) or higher.

■

Suspension of the settings display

●

Some settings cannot be changed while driving. When changing settings,
park the vehicle in a safe place.

●

If a warning message is displayed, operation of the settings display will be
suspended.

■

Tire pressure

●

It may take a few minutes to display the tire inflation pressure after the
engine switch is turned to IGNITION ON mode. It may also take a few min-
utes to display the tire inflation pressure after inflation pressure has been
adjusted.

●

“---” may be displayed if the tire position information cannot be determined
due to unfavorable radio wave conditions.

●

Tire inflation pressure changes with temperature. The displayed values may
also be different from the values measured using a tire pressure gauge.

■

Liquid crystal display

Small spots or light spots may appear on the display. This phenomenon is
characteristic of liquid crystal displays, and there is no problem continuing to
use the display.

■

Customization

Some functions can be customized. (



P. 117, 606)

Eco Driving Indicator Light
During Eco-friendly acceleration (Eco
driving), the Eco Driving Indicator Light
will turn on. When the acceleration
exceeds the Zone of Eco driving, or
when the vehicle is stopped, the light
turns off.

Eco Driving Indicator Zone Display
Suggests the Zone of Eco driving with
current Eco driving ratio based on
acceleration.

Eco driving ratio based on acceleration
If the acceleration exceeds the Zone of
Eco driving, the right side of the Eco
Driving Indicator Zone Display will illu-
minate.

Zone of Eco driving

1

2

3

4

127

2. Instrument cluster

2

Instrum

ent

clus
ter

CAMRY_U

WARNING

■

Caution for use while driving

●

When operating the multi-information display while driving, pay extra

attention to the safety of the area around the vehicle.

●

Do not look continuously at the multi-information display while driving as

you may fail to see pedestrians, objects on the road, etc. ahead of the

vehicle.

■

The information display at low temperatures

Allow the interior of the vehicle to warm up before using the liquid crystal

information display. At extremely low temperatures, the information display

monitor may respond slowly, and display changes may be delayed.

For example, there is a lag between the driver’s shifting and the new gear

number appearing on the display. This lag could cause the driver to down-

shift again, causing rapid and excessive engine braking and possibly an

accident resulting in death or injury.

■

Cautions during setting up the display

As the engine needs to be running during setting up the display, ensure that

the vehicle is parked in a place with adequate ventilation. In a closed area

such as a garage, exhaust gases including harmful carbon monoxide (CO)

may collect and enter the vehicle. This may lead to death or a serious

health hazard.

NOTICE

■

While setting up the display

To prevent battery discharge, ensure that the engine is running while setting

up the display features.

128

2. Instrument cluster

CAMRY_U

The head-up display is linked to the meters and navigation system (if
equipped) and projects a variety of information in front of the driver,
such as the current vehicle speed.

Driving assist system status/navigation system-linked display area
(if equipped) (



P. 130)

The following pop-up displays will be displayed in certain situations:

• Pre-collision warning (pre-collision system)
• Alert from the Parking Support Brake system (if equipped)

Shift position/speed limit/RSA (Road Sign Assist) display area

• Shift position (



P. 217)

• Speed limit (vehicles with a navigation system) (U.S.A. only)
• RSA (Road Sign Assist) display (if equipped) (



P. 285)

Vehicle speed display

Eco Driving Indicator/Tachometer (



P. 131)

Information display area (



P. 131)

The following pop-up displays will be displayed in certain situations:

• Warning/message
• Hands-free system status
• Audio system operation status

Head-up display





: If equipped

Summary of functions

1

2

3

4

5
