Toyota Land Cruiser Prado (2023 year). Manual in english - page 34

546

6-3. Using the storage features

Pull out the luggage cover
and hook it on the anchors.

■

Removing the luggage cover

Detach the sub cover hooks,
remove the luggage cover
from the left and right hold-
ers, and roll the luggage
cover up.

Retract the cover and
release both ends, then lift it
out.

After removing the luggage
cover, place it somewhere other
than the passenger compart-
ment.

■

Adjusting the sub cover (if equipped)

Fasten the button when the second seats are in the rear-most position.
Unfasten the buttons before sliding the second seats forward.

547

6-3. Using the storage features

teri
or f
eatu

res

WARNING

●

To avoid injury, always return the cargo hooks to their stowed positions.

●

Keep the auxiliary box closed. In the event of sudden braking or sudden
swerving, an accident may occur due to an occupant being struck by an
open auxiliary box or the items stored inside.

●

Do not allow children to climb on the luggage cover. Climbing on the lug-
gage cover could result in damage to the luggage cover, possibly causing
death or serious injury to the child.

548

6-4. Using the other interior features

Other interior features

Lift the lid while pulling up the
knob to release the lock.

Turns the cool box on/off

When on, the indicator light comes
on.

■

The cool box can be operated when



Vehicles with a manual air conditioning system

Vehicles without a smart entry & start system:
The engine switch is in the “ON” position, and the front air conditioning sys-
tem is turned on.
Vehicles with a smart entry & start system:
The engine switch is in IGNITION ON mode, and the front air conditioning
system is turned on.



Vehicles with an automatic air conditioning system

Vehicles without a smart entry & start system:
The engine switch is in the “ON” position.
Vehicles with a smart entry & start system:
The engine switch is in IGNITION ON mode.

■

If the front air conditioning system is not in use when the cool box is
turned on (vehicles with an automatic air conditioning system)

The front air conditioning system is automatically turned on.

Cool box (if equipped)

549

6-4. Using the other interior features

teri
or f
eatu

res

■

Items unsuitable for the cool box

●

Drinks in unsealed containers

●

Fragile items, perishables or anything with strong odor

●

Owner’s manual, electronic devices, CDs, etc.

■

When the indicator light flashes

The cool box is not operated when any of the following conditions occurs.

●

When the air conditioning system is off
Turn the air conditioning system on also turns on the cool box.

●

When outside air temperature is about 0



C (32



F) or below

If the indicator light continues to flash, there may be a malfunction in the sys-
tem. Turn the air conditioning system off and have it inspected by any autho-
rized Toyota retailer or Toyota authorized repairer, or any reliable repairer.

■

When using the cool box lid as an armrest

Slide the cool box lid forward or backward
as needed. Slide the lid while pulling up
the lever to release the lock.

WARNING

Keep the cool box closed. In the event of sudden braking or sudden swerv-
ing, an accident may occur due to an occupant being struck by the open
cool box or the items stored inside.

NOTICE

To prevent battery discharge, do not leave the cool box on longer than nec-
essary when the engine is stopped.

550

6-4. Using the other interior features



Type A

To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.



Type B

To set the visor in the forward
position, flip it down.
To set the visor in the side posi-
tion, flip down, unhook, and
swing it to the side.
To use the side extender, place
the visor in the side position,
then slide it backward.

Slide the cover to open.

The light turns on when the cover
is opened.

If the vanity lights remain on when the engine switch is turned off, the lights
will go off automatically after 20 minutes.

Sun visors

Vanity mirror

551

6-4. Using the other interior features

teri
or f
eatu

res

The conversation mirror can provide the driver and the front passen-
ger with a view of the rear seat area without the need to turn around.

Press in the button.

To use the overhead console when the conversation mirror is open, further
extend down the lid. (



P. 540)

NOTICE

To prevent battery discharge, do not leave the vanity lights on for extended
periods when the engine is not running.

Conversation mirror (if equipped)

552

6-4. Using the other interior features

Adjusts the hours
Adjusts the minutes
Rounds the nearest hour

: e.g. 1:00 to 1:29



1:00

1:30 to 1:59



2:00

■

The clock is displayed when



Vehicles without a smart entry & start system

The engine switch is in the “ACC” or “ON” position.



Vehicles with a smart entry & start system

The engine switch is in ACCESSORY or IGNITION ON mode.

■

When disconnecting and reconnecting battery terminals

The clock data will be reset.

Clock

1
2
3

553

6-4. Using the other interior features

teri
or f
eatu

res

The power outlet can be used for the following components:
12 V DC:
Please use as a power supply for electronic goods that use less than
12 V DC / 10 A (power consumption of 120 W).
When using electronic goods, make sure that the power consumption
of all the connected power outlets is less than 120 W.
220 V AC:
Accessories that use less than 100 W.

■

Center of console (12 V DC)

Power outlet



Vehicles with an automatic
transmission



Vehicles with a manual trans-
mission



Rear of console box

554

6-4. Using the other interior features

■

Luggage compartment (12 V DC) (if equipped)

■

Luggage compartment (220 V AC) (if equipped)

■

The power outlet can be used when



Vehicles without a smart entry & start system

12 V DC: The engine switch is in the “ACC” or “ON” position.
220 V AC: The engine switch is in the “ON” position.



Vehicles with a smart entry & start system

12 V DC: The engine switch is in ACCESSORY or IGNITION ON mode.
220 V AC: The engine switch is in IGNITION ON mode.

■

The power outlet can not be used when (220 V AC only, vehicles with
1GD-FTV engine)

The Heated Windshield Defroster (if equipped) is operating.

■

When turning the engine switch off (only for 12 V DC)

Disconnect electrical devices with charging functions, such as mobile battery
packs.
If such devices are left connected, the engine switch may not be turned off
normally.



3 door models



5 door models



3 door models



5 door models

555

6-4. Using the other interior features

teri
or f
eatu

res

■

When the Stop & Start system is used

When the engine restarts after having been stopped by the Stop & Start sys-
tem, the power outlet may be temporarily unusable, but this is not a malfunc-
tion.

NOTICE

■

To avoid damaging the power outlet

Close the power outlet lid when the power outlet is not in use.
Foreign objects or liquids that enter the power outlet may cause a short cir-
cuit.

■

To prevent blown fuse



12 V DC

Do not use an accessory that uses more than 12 V DC / 10 A (power con-
sumption of 120 W).
When using electronic goods, make sure that the power consumption of all
the connected power outlets is less than 120 W.



220 V AC

Do not use a 220 V AC appliance that requires more than 100 W.
If a 220 V AC appliance that consumes more than 100 W is used, the pro-
tection circuit will cut the power supply.

■

To prevent battery discharge

Do not use the power outlet longer than necessary when the engine is not
running.

■

Appliances that may not operate properly (220 V AC)

The following 220 V AC appliances may not operate properly even if their
power consumption is under 100 W:

●

Appliances with high initial peak wattage

●

Measuring devices that process precise data

●

Other appliances that require an extremely stable power supply

556

6-4. Using the other interior features

Fold down the armrest for use.

The coat hooks are provided with
the rear assist grips.

Armrest (if equipped)

NOTICE

To prevent damage, do not apply too heavy a load on the armrest.

Coat hooks

WARNING

Vehicles with SRS curtain shield airbags: Do not hang coat hangers or
other hard or sharp objects on the hook. If the SRS curtain shield airbags
deploy, these items may become projectiles, causing death or serious
injury.

557

6-4. Using the other interior features

teri
or f
eatu

res

An assist grip (Type A) can be used to support your body while sitting
on the seat.
An assist grip (Type B) can be used when getting in or out of the vehi-
cle and others.

Assist grip (Type A)
Assist grip (Type B)

Assist grips

1
2

WARNING

Do not use the assist grip (Type A) when getting in or out of the vehicle or
rising from your seat.

NOTICE

To prevent damage, do not hang heavy objects or put a heavy load on the
assist grip.

558

6-4. Using the other interior features

The ashtray can be installed in the
auxiliary box (type E:



P. 541) or

cup holder (



P. 536).

Ashtray (if equipped)

WARNING

■

When not in use

Keep the ashtray closed. In the event of sudden braking or sudden swerv-
ing, an accident may occur due to an occupant being struck by the open
ashtray or ash flying out.

■

To prevent fire

●

Fully extinguish matches and cigarettes before putting them in the ashtray,
then make sure the ashtray is fully closed.

●

Do not place paper or any other type of flammable object in the ashtray.

559

Maintenance and care

7-1. Maintenance and care

Cleaning and protecting

the vehicle exterior ..........560

Cleaning and protecting

the vehicle interior ...........565

7-2. Maintenance

Maintenance

requirements....................568

7-3. Do-it-yourself maintenance

Do-it-yourself service

precautions ......................571

Hood ..................................574
Engine compartment..........575
Tires...................................600
Tire inflation pressure ........612
Wheels...............................614
Air conditioning filter ..........617
Wireless remote control/

electronic key battery.......619

Checking and replacing

fuses ................................624

Light bulbs .........................628

560

7-1. Maintenance and care

Cleaning and protecting the vehicle exterior

●

Working from top to bottom, liberally apply water to the vehicle
body, wheel wells and underside of the vehicle to remove any dirt
and dust.

●

Wash the vehicle body using a sponge or soft cloth, such as a
chamois.

●

Use car wash shampoo (for parts other than matte painted parts) or
neutral detergent (for matte painted parts) and wash thoroughly
with water when the vehicle is particularly dirty

●

Wipe away any water.

●

For parts other than matte painted parts: Wax the vehicle when the
waterproof coating deteriorates.

If water does not bead on a clean surface, apply wax when the vehicle
body is cool.

●

Matte painted parts: Do not use wax or abrasive compounds on
these parts under any circumstances

●

Matte painted parts: Contact your Toyota dealer regarding dirt on
matte painted parts that cannot be cleaned with a normal car wash.

■

Automatic car washes

●

Fold the mirrors back before washing the vehicle. Start washing from the
front of the vehicle. Make sure to extend the mirrors before driving.

●

Brushes used in automatic car washes may scratch the vehicle surface,
parts (wheel, etc.) and harm your vehicle’s paint.

■

High pressure car washes

●

As water may enter the cabin, do not bring the nozzle tip near the gaps
around the doors or perimeter of the windows, or spray these areas continu-
ously.

●

Do not use the high-pressure washer too close to the bearings and oil seals
of drivetrain system parts (such as the differential gear).
If used too close to such parts, the high water pressure may cause water to
enter the parts and grease to be washed out, causing the system perfor-
mance to decrease.

●

For vehicles with rear height control air suspension, do not bring the nozzle
tip near the air suspension unit.

Perform the following to protect the vehicle and maintain it in
prime condition:

561

7-1. Maintenance and care

nan
ce and

■

Notes for a smart entry & start system (if equipped)

If the door handle becomes wet while the electronic key is within the effective
range, the door may lock and unlock repeatedly. In this case, follow the fol-
lowing correction procedures to wash the vehicle:

• Place the electronic key in a location 2 m (6 ft.) or more away from the

vehicle. (Take care to ensure that the key is not stolen.)

• Set the electronic key to battery-saving mode to disable the smart entry &

start system. (



P. 190)

■

Wheels and wheel ornaments

●

Remove any dirt immediately by using a neutral detergent.

●

Wash detergent off with water immediately after use.

●

To protect the paint from damage, make sure to observe the following pre-
cautions.
• Do not use acidic, alkaline or abrasive detergent
• Do not use hard brushes
• Do not use detergent on the wheels when they are hot, such as after driv-

ing or parking in hot weather

■

Brake pads and calipers

Rust may form if the vehicle is parked with wet brake pads or disc rotors,
causing them to stick. Before parking the vehicle after it is washed, drive
slowly and apply the brakes several times to dry the parts.

■

Bumpers

Do not scrub with abrasive cleaners.

■

Plated portions

If dirt cannot be removed, clean the parts as follows:

●

Use a soft cloth dampened with an approximately 5% solution of neutral
detergent and water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to remove any remaining moisture.

●

To remove oily deposits, use alcohol wet wipes or a similar product.

Content .. 32 33 34 35 ..
